Impacts

IR 2925-12

IR 2925-53

IR 2925-724

IR 2925-B40

IR 2925P1TI

3/4" Air Impact Wrench, Super Duty, 1100 ft-lb Torque, Titanium Hammercase, Thru-hole Retainer, Pistol

Description: Armed with a titanium hammer case and a special corrosion preventative treatment, this series is rust and corrosion resistant.

Features And Benefits:

• Durability: Thanks to a titanium hammer case, this wrench is both lightweight and durable.
• Reliability: The 2925 Series' twin hammer impact mechanism means it's less sensitive to air pressure fluctuation, which means you never have to worry about your location affecting your wrench's effectiveness.
• Bronze endplates and a corrosion preventative treatment prevents internal in outdoor, wet environments.
• Pressure-fed mechanism lubrication ensures complete coverage throughout the tool.
• Optimized for general industrial use, rail, heavy machinery, oil and gas, and shipbuilding.
• Integral muffler
• 1-year warranty

Product Application and Uses:

Optimized for general industrial use, rail, heavy machinery, oil and gas, and shipbuilding

• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 60
• Air Consumption @ Load (l/min): 1699
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 12
• Average Air Consumption (l/min): 340

• Blows per Min: 1050

• Color: Black
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Super Duty

• End Plates: Bronze
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 99.6 / 110.6

• Hammer Case: Titanium
• Handle Material: Composite
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 95.9 / 106.9

• Max Bolt Diameter (in): 1.125
• Max Free Speed (rpm): 5200
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1497
• Max Torque (in-lb): 17967
• Max Torque (nm): 2030
• Min Hose Size (in): 1/2
• Motor: Non-Biased

• Number of Power Settings: 3
• Power Source: Air Powered
• Product Length (in): 8.9

• Product Width (in): 3.5
• Product Height (in): 9.6
• Product Weight (lb): 12
• Recommended Forward Torque Range (ft-lb): 1298
• Recommended Forward Torque Range (in-lb): 15577
• Recommended Forward Torque Range (nm): 1760
• Retainer Type: Thru-hole

• Side to Center Distance (in): 1.75
• Side to Center Distance (mm): 44

• Special Features: Titanium Hammer case
• Speed Setting: Variable Speed
• Standards/Certifications: CE

• Tool Type: Full-size
• Vanes: 7
• Vibration Level (m/s2): 10.5
• Warranty: 1-year

• Lubrication: 10P
• Parts: 2161-366
• Parts: 2910-726

• Parts: 2925-42-7
• Parts: 834-61

IR 2925P3TI

1" Air Impact Wrench, Heavy Duty, 1450 ft-lb Torque, Titanium Hammercase, Thru-hole Retainer, Pistol

Description: Armed with a titanium hammer case and a special corrosion preventative treatment, this series is rust and corrosion resistant.

Features And Benefits:

• Thanks to a titanium hammer case, this wrench is both lightweight and durable.
• The twin hammer impact mechanism means it's less sensitive to air pressure fluctuation, which means you never have to worry about your location affecting your wrench's effectiveness.
• Bronze endplates and a corrosion preventative treatment prevents internal in outdoor, wet environments.
• Pressure-fed mechanism lubrication ensures complete coverage throughout the tool.
• Optimized for general industrial use, rail, heavy machinery, oil and gas, and shipbuilding.
• Integral muffler.
• 3/8" NPT inlet.

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 60
• Air Consumption @ Load (l/min): 1699
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard

• Blows per Min: 1050

• Color: Black
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Heavy Duty

• End Plates: Bronze
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 99.6 / 110.6

• Hammer Case: Titanium
• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 95.9 / 106.6

• Max Bolt Diameter (in): 1-1/8
• Max Free Speed (rpm): 5200
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1497
• Max Torque (in-lb): 17967
• Max Torque (nm): 2030
• Min Hose Size (in): 1/2
• Motor: Non-Biased

• Number of Power Settings: 3
• Power Source: Air Powered
• Product Length (in): 9

• Product Width (in): 3.5
• Product Height (in): 9.6
• Product Weight (lb): 12.2
• Recommended Forward Torque Range (ft-lb): 1298
• Recommended Forward Torque Range (in-lb): 15577
• Recommended Forward Torque Range (nm): 1760
• Retainer Type: Thru-hole

• Side to Center Distance (in): 1.8
• Side to Center Distance (mm): 46

• Special Features: Titanium hammercase
• Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744

• Tool Type: Full-size
• Vanes: 7
• Vibration Level (m/s2): 10.5
• Warranty: 1-year

• Accessories: SK8H9TN

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 834-61

IR 2925RBP1TI

3/4" Air Impact Wrench, Heavy Duty, 1600 ft-lb Torque, Titanium Hammercase, Thru-hole Retainer, Pistol

Description: Armed with a titanium hammer case and special Corrode-x, this Series is rust and corrosion resistant.

Features And Benefits:

• Thanks to a titanium hammer case, this wrench is both lightweight and durable.
• The twin hammer impact mechanism means it's less sensitive to air pressure fluctuation, which means you never have to worry about your location affecting your wrench's effectiveness.
• Bronze endplates and a corrosion preventative treatment prevents internal in outdoor, wet environments.
• Pressure-fed mechanism lubrication ensures complete coverage throughout the tool.
• Optimized for general industrial use, rail, heavy machinery, oil and gas, and shipbuilding.
• Integral muffler.

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 60
• Air Consumption @ Load (l/min): 1699
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 12
• Average Air Consumption (l/min): 340

• Blows per Min: 1050

• Color: Black
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Heavy Duty

• End Plates: Bronze
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 99.6 / 110.6

• Hammer Case: Titanium
• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 95.9 / 106.9

• Max Bolt Diameter (in): 1-1/8
• Max Free Speed (rpm): 5200
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1497
• Max Torque (in-lb): 17967
• Max Torque (nm): 2030
• Min Hose Size (in): 1/2
• Motor: Reverse Bias

• Number of Power Settings: 3
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 133.3
• Product Length (in): 8.9

• Product Width (in): 3.5
• Product Height (in): 9.6
• Product Weight (lb): 12
• Recommended Forward Torque Range (ft-lb): 1298
• Recommended Forward Torque Range (in-lb): 15577
• Recommended Forward Torque Range (nm): 1760
• Retainer Type: Thru-hole

• Side to Center Distance (in): 1.8
• Side to Center Distance (mm): 46

• Special Features: Titanium hammercase
• Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744

• Tool Type: Full-size
• Vanes: 7
• Vibration Level (m/s2): 10.5
• Warranty: 1-year

• Accessories: SK6H8N

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 2910-726
• Parts: 834-61

IR 2925RBP1TIEX

3/4" Air Impact Wrench, ATEX/Hazardous Duty, 1600 ft-lb Torque, Titanium Hammercase, Pistol

Description: Specifically designed to meet ATEX Zone 1 or Zone 2 requirements and armed with a titanium hammer case and a corrosion preventative treatment, this ATEX certified impact wrench is rust and corrosion resistant.ATEX Marking: ATEX 2014/34/EU and Ex h IIA T6 Gb XISO 80079-36 Certified

Features And Benefits:

• Durability: Bronze end plates and a corrosion preventative treatment prevent internal corrosion and wear in wet, outdoor environments. And thanks to a titanium hammer case, this impact wrench is both lightweight and durable.
• Reliability: The 2925 Series' twin hammer impact mechanism means it's less sensitive to air pressure fluctuation, which means you never have to worry about your location affecting your wrench's effectiveness.
• Control: This tool features a feather-touch trigger that provides users precise delivery of pressure and speed.
• Pressure-fed mechanism lubrication ensures complete coverage throughout the tool
• Integral muffler
• ATEX markings: ATEX 2014/34/EU and Ex h IIA T6 Gb X
• ISO 80079-36 Certified
• 3/8" NPT inlet
• 1-year warranty

Product Application and Uses:

Optimized For General Industrial Use, Rail, Heavy Machinery, Oil And Gas, And Shipbuilding

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Feather-touch Trigger
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 60

• Blows per Min: 1050

• Color: Black
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Atex/Hazardous Duty

• End Plates: Bronze
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 99.6 / 110.6

• Hammer Case: Titanium
• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 95.9 / 106.9

• Max Bolt Diameter (in): 1-1/8
• Max Free Speed (rpm): 5200
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1497
• Max Torque (in-lb): 17967
• Max Torque (nm): 2030
• Min Hose Size (in): 1/2
• Motor: Reverse Bias

• Number of Power Settings: 3
• Power Source: Air Powered
• Product Length (in): 8.9

• Product Width (in): 3.5
• Product Height (in): 9.6
• Product Weight (lb): 12
• Recommended Forward Torque Range (ft-lb): 1298
• Recommended Forward Torque Range (in-lb): 15577
• Recommended Forward Torque Range (nm): 1760
• Retainer Type: Thru-hole

• Side to Center Distance (in): 1.8
• Side to Center Distance (mm): 46

• Special Features: ATEX Rated, Titanium hammercase
• Standards/Certifications: Atex 2014/34/Eu, Atex Ex H Iia T6 Gb X, Iso 80079-36

• Tool Type: Full-size
• Vanes: 7
• Vibration Level (m/s2): 10.5
• Warranty: 1-year

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 2910-726
• Parts: 834-61

IR 2925RBP3TI

1" Air Impact Wrench, Super Duty, 1600 ft-lb Torque, Titanium Hammercase, Thru-hole Retainer, Pistol

Description: Armed with a titanium hammer case and a special corrosion preventative treatment, this series is rust and corrosion resistant.

Features And Benefits:

• Thanks to a titanium hammer case, this wrench is both lightweight and durable.
• The twin hammer impact mechanism means it's less sensitive to air pressure fluctuation, which means you never have to worry about your location affecting your wrench's effectiveness.
• Bronze endplates and a corrosion preventative treatment prevents internal in outdoor, wet environments.
• Pressure-fed mechanism lubrication ensures complete coverage throughout the tool.
• Optimized for general industrial use, rail, heavy machinery, oil and gas, and shipbuilding.
• Integral muffler

Product Application and Uses:

Optimized for general industrial use, rail, heavy machinery, oil and gas, and shipbuilding

• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 60
• Air Consumption @ Load (l/min): 1699
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 12
• Average Air Consumption (l/min): 340

• Blows per Min: 1050

• Color: Black
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Super Duty

• End Plates: Bronze
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 99.6 / 110.6

• Hammer Case: Titanium
• Handle Material: Composite
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 95.9 / 106.9

• Max Bolt Diameter (in): 1.125
• Max Free Speed (rpm): 5200
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1497
• Max Torque (in-lb): 17967
• Max Torque (nm): 2030
• Min Hose Size (in): 1/2
• Motor: Reverse Bias

• Number of Power Settings: 3
• Power Source: Air Powered
• Product Length (in): 9.04

• Product Width (in): 3.5
• Product Height (in): 9.6
• Product Weight (lb): 12
• Recommended Forward Torque Range (ft-lb): 1298
• Recommended Forward Torque Range (in-lb): 15577
• Recommended Forward Torque Range (nm): 1760
• Retainer Type: Thru-hole

• Side to Center Distance (in): 1.74
• Side to Center Distance (mm): 44

• Special Features: Titanium Hammer case
• Speed Setting: Variable Speed
• Standards/Certifications: CE

• Tool Type: Full-size
• Vanes: 7
• Warranty: 1-year

• Lubrication: 10P
• Parts: 2910-826
• Parts: 2925-42-7

• Parts: 834-61

IR 293

1" Air Impact Wrench, Super Duty, 2000 ft-lb Torque, Thru-hole Retainer, Pistol

Description: With a twin hammer impact mechanism and a finely tuned motor, the 293 Series is great for any job, from vehicle repair, to heavy machinery.

Features And Benefits:

• Durability: This wrench can withstand drops or harsh conditions, thanks to its steel hammer case and metal housing.
• Reliability: With a twin hammer impact mechanism that delivers even blows every time, and a power regulator that helps keep control, you'll never doubt that this wrench will perform the way you want it to. Comes with a 1-year warranty.
• Safety: Thanks to its square thru-hole anvil, this wrench offers a stronger connection to the socket, so you never have to sacrifice performance for safety.

Product Application and Uses:

This pneumatic impact wrench is especially suited for working on trucks, agricultural equipment, and other heavy duty machinery.

• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 64
• Air Consumption @ Load (l/min): 1812
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 12
• Average Air Consumption (l/min): 340

• Blows per Min: 810

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Super Duty

• End Plates: Bronze
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 87.3 / 98.3

• Hammer Case: Steel
• Handle Material: Composite
• Housing Material: Aluminum core with composite sleeve
• Impact Mechanism: Twin Hammer

• Max Bolt Diameter (in): 1.375
• Max Free Speed (rpm): 3500
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 2000
• Max Torque (in-lb): 24003
• Max Torque (nm): 2712
• Min Hose Size (in): 3/4
• Motor: Non-Biased

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Product Length (in): 11.3

• Product Width (in): 4
• Product Height (in): 6
• Product Weight (lb): 22.8
• Recommended Forward Torque Range (ft-lb): 1000-1600
• Recommended Forward Torque Range (in-lb): 12002-19197
• Recommended Forward Torque Range (nm): 1356-2169
• Retainer Type: Thru-hole

• Side to Center Distance (in): 2
• Side to Center Distance (mm): 51

• Speed Setting: Variable Speed
• Standards/Certifications: CE

• Tool Type: Full-size
• Vanes: 6
• Vibration Level (m/s2): 18.1
• Warranty: 1-year

• Lubrication: 50P
• Parts: 2934-366
• Parts: 2940-TK3

IR 2934-53

IR 2934-A1

IR 2934A90

IR 2934-A92A

IR 2934B2

1" Air Impact Wrench, Super Duty, 1500 ft-lb Torque, Thru-hole Retainer, D-Handle Inside Trigger

Description: The twin hammer impact mechanism ensures this series is reliable, durable, and will produce the same output every time.

Features And Benefits:

• Durability: This Series features an iron hammer case and metal housing that'll withstand harsh conditions and drops.
• Reliability: Resistant to fluctuations in air pressures, this series will work just as well in any condition. Comes with a 1-year warranty.
• Great for Outdoor Environments: This wrench contains a bronze end-plate that increases durability and is corrosion resistant.

Product Application and Uses:

Optimized for general industrial use, rail, heavy machinery, oil and gas, and shipbuilding

• Actuation/Throttle Type/Switch Type: Inside Trigger
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 47
• Average Air Consumption (l/min): 1331

• Blows per Min: 750

• Color: Grey
• Configuration/Handle Type: D-Handle
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Super Duty

• End Plates: Bronze
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 94.9 / 105.9

• Handle Material: Composite
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 94.5 / 105.5

• Max Bolt Diameter (in): 1.125
• Max Free Speed (rpm): 6600
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1500
• Max Torque (in-lb): 18002
• Max Torque (nm): 2034
• Min Hose Size (in): 3/4
• Motor: Non-Biased

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Product Length (in): 11.25

• Product Width (in): 4.4
• Product Height (in): 6.7
• Product Weight (lb): 18.5
• Recommended Forward Torque Range (ft-lb): 1100
• Recommended Forward Torque Range (in-lb): 13196
• Recommended Forward Torque Range (nm): 1491
• Recommended Reverse Torque (ft-lb): 500-1099
• Recommended Reverse Torque (nm): 678-1490
• Retainer Type: Thru-hole

• Side to Center Distance (in): 2.2
• Side to Center Distance (mm): 56

• Speed Setting: Variable Speed
• Standards/Certifications: CE

• Tool Type: Full-size
• Vanes: 6
• Vibration Level (m/s2): 18.8
• Warranty: 1-year

• Accessories: RR10015S

• Lubrication: 10P
• Parts: 2934-42-6
• Parts: 2934-TK3

IR 2934B9

1" Air Impact Wrench, Super Duty, 750 ft-lb Torque, Thru-hole Retainer, D-Handle Inside Trigger

Description: The twin hammer impact mechanism ensures this series is reliable, durable, and will produce the same output every time.

Features And Benefits:

• Durability: This Series features an iron hammer case and metal housing that'll withstand harsh conditions and drops.
• Reliability: Resistant to fluctuations in air pressures, this series will work just as well in any condition. Comes with a 1-year warranty.
• Great for Outdoor Environments: This wrench contains a bronze end-plate that increases durability and is corrosion resistant.

Product Application and Uses:

Optimized for general industrial use, rail, heavy machinery, oil and gas, and shipbuilding

• Actuation/Throttle Type/Switch Type: Inside Trigger
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 47
• Average Air Consumption (l/min): 1331

• Blows per Min: 780

• Color: Grey
• Configuration/Handle Type: D-Handle
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Super Duty

• End Plates: Bronze
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 93.2 / 104.2

• Handle Material: Composite
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 94.5 / 105.5

• Max Bolt Diameter (in): 1.125
• Max Free Speed (rpm): 5300
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 750
• Max Torque (in-lb): 9001
• Max Torque (nm): 1017
• Min Hose Size (in): 3/4
• Motor: Non-Biased

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Product Length (in): 18.63

• Product Width (in): 4.4
• Product Height (in): 6.7
• Product Weight (lb): 35.75
• Recommended Forward Torque Range (ft-lb): 500-656
• Recommended Forward Torque Range (in-lb): 6001-7877
• Recommended Forward Torque Range (nm): 678-890
• Recommended Reverse Torque (ft-lb): 500-656
• Recommended Reverse Torque (nm): 678-890
• Retainer Type: Thru-hole

• Side to Center Distance (in): 1.63
• Side to Center Distance (mm): 41

• Speed Setting: Variable Speed
• Standards/Certifications: CE

• Tool Type: Full-size
• Vanes: 6
• Vibration Level (m/s2): 30.8
• Warranty: 1-year

• Lubrication: 10P
• Parts: 2934-42-6
• Parts: 2934-A827

• Parts: 2934-TK3

IR 2934-K23

IR 2934P-302

IR 2940-301

IR 2940-314-6

IR 2940-53

IR 2940-A40

IR 2940-A727

IR 2940B1

No. 5 Spline Impact Wrench, 1600 ft-lb Torque, D-Handle Inside Trigger

• Actuation/Throttle Type/Switch Type: Inside Trigger
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard

• Blows per Min: 850

• Color: Grey
• Configuration/Handle Type: D-Handle
• Drive Size (in): No. 5
• Drive Type: Spline
• Duty Rating: Industrial Duty

• Exhaust Location: Bottom

• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer

• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1601
• Max Torque (in-lb): 19206
• Max Torque (nm): 2170
• Min Hose Size (in): 3/4
• Motor: Non-Biased

• Power Source: Air Powered
• Product Length (in): 10.2

• Product Width (in): 22.1
• Product Height (in): 6.5
• Product Weight (lb): 22
• Recommended Forward Torque Range (ft-lb): 1003-1601
• Recommended Forward Torque Range (in-lb): 12037-19206
• Recommended Forward Torque Range (nm): 1360 - 2170
• Recommended Reverse Torque (ft-lb): 1003-1601
• Recommended Reverse Torque (nm): 1360-2170

• Side to Center Distance (in): 11.1
• Side to Center Distance (mm): 282

• Sound Pressure/Power Db(A): 94.8 / 105.8

• Tool Type: Full-size
• Vibration Level (m/s2): 17.8
• Vibration Uncertainy K* (m/s2): 3.4
• Warranty: 1-year

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 2940-A703
• Parts: 2940-TK3

IR 2940P2

1" Air Impact Wrench, 1600 ft-lb Torque, 810 BPM, Pistol

• Actuation/Throttle Type/Switch Type: Trigger
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard

• Blows per Min: 810

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Industrial Duty

• Exhaust Location: Bottom

• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer

• Max Bolt Diameter (in): 1-3/8
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1601
• Max Torque (in-lb): 19206
• Max Torque (nm): 2170
• Min Hose Size (in): 3/4
• Motor: Non-Biased

• Power Source: Air Powered

• Recommended Forward Torque Range (ft-lb): 1003-1601
• Recommended Forward Torque Range (in-lb): 12037-19206
• Recommended Forward Torque Range (nm): 1360 - 2170
• Recommended Reverse Torque (ft-lb): 1003-1601
• Recommended Reverse Torque (nm): 1360-2170

• Sound Pressure/Power Db(A): 94.2 / 105.2

• Tool Type: Full-size
• Vibration Level (m/s2): 18.1
• Vibration Uncertainy K* (m/s2): 5.6
• Warranty: 1-year

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 2940-TK3
