GRACO INC. S10595
GRACO INC. S10595 branded products
HUSKY PUMP, 3300A-PA01AA1BNBNBNBN
GG 652058
GG 652058
HUSKY PUMP, 3300A-PA01AA1BNBNBNBN
Husky 3300 (ANSI/DIN/NPT) AL Pump, AL Center Section with BN Seals, BN Seats, BN Balls & BN DiaphragmThe Husky 3300 air-operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. The one-piece center section eliminates leaks and reduces maintenance on the Husky pumps when compared to other diaphragm pumps.
Overall improved efficiency (up to 40% more efficient) Highest fluid flow rate in its class Up to 5 times longer diaphragm life compared to other air operated diaphragm pumps Expanded material offering to handle endless applications Offered in ATEX configuration. Expanded material offering to handle numerous applications Flow rates up to 300 gpm (1,135 lpm) Modular stall-resistant air valve design Complete 3 inch family of diaphragm pumps available in aluminum or polypropylene center sections Heavy-duty construction Faster change over with spring loaded pilot valves
$5,860.00
HUSKY PUMP, 3300S, SS/PT/PT/A
GG 652830
GG 652830
HUSKY PUMP, 3300S, SS/PT/PT/A
Husky 3300 (3 in. NPT) SS Pump, AL Center Section, SS Seats, PTFE Balls & PTFE DiaphragmThe Husky 3300 air-operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. The one-piece center section eliminates leaks and reduces maintenance on the Husky pumps when compared to other diaphragm pumps.
Overall improved efficiency (up to 40% more efficient) Highest fluid flow rate in its class Up to 5 times longer diaphragm life compared to other air operated diaphragm pumps Expanded material offering to handle endless applications Offered in ATEX configuration. Expanded material offering to handle numerous applications Flow rates up to 300 gpm (1,135 lpm) Modular stall-resistant air valve design Complete 3 inch family of diaphragm pumps available in aluminum or polypropylene center sections Heavy-duty construction Faster change over with spring loaded pilot valves
$16,870.00
HUSKY PUMP, 1050S-E, SS/PT/PO/4E
GG 653027
GG 653027
HUSKY PUMP, 1050S-E, SS/PT/PO/4E
Husky 1050e SS Pump, NEMA 56C Gearbox, SS Center Section, SS Seats, PTFE Balls & PO DiaphragmOur Husky e-Series pumps are ideal for applications that require low pulsation and a smooth flow. The patented air charged drive allows for the elimination or reduction of pulsation WITHOUT expensive pulsation dampeners or surge tanks.
Durable Pump Technology
- Handles slurries and abrasives all without damage to the pump
- Gentle on shear sensitive material
Diaphragm Pump
- Runs dry
- No rotating or moving fluid seals
- Self-priming
Electric Drive
- Reduce energy consumption and operating costs
- Increase pump control
- Accurately meter fluid
Fluid Section
- Create the pump you need with multiple material offerings for manifolds, seats, balls, and diaphragms
Patent Pending Air Charged Drive
- Increase diaphragm life without compromising your fluid
- Ability to reduce pulsation on fluid outlet
- Stalls under pressure without additional switches and controls
$11,850.00
HUSKY PUMP, 2200P, P1, PP/SP/SP/A
GG 653500
GG 653500
HUSKY PUMP, 2200P, P1, PP/SP/SP/A
Graco 653500 Husky 2200 PP Pump, Center Flange, PP Center Section, PP Seats, SP Balls & SP Diaphragm
The Husky 2200 air-operated diaphragm pump features a single piece polypropylene center section for increased reliability and chemical compatibility, plus a patented, high-reliability modular air valve that is online serviceable. This diaphragm pump is designed with a reinforced frame for improved reliability and will help to eliminate fluid leakage.
- Overall improved air efficiency
- Highest fluid flow rate in its class
- Expanded material offering to handle endless applications
- 2 in (50.8 mm) ANSI center and end-porting options available
- High flow - 200 gpm (757 lpm) in a compact, portable size
- Fluid pressure to 125 psi (8.6 bar, 0.86 MPa)
- Lube-free operation
- Available in polypropylene and PVDF
- Model: Husky
- Series: 2200
- Air Exhaust Port Size (in): 1
- Air Exhaust Port Thread Gender: Female
- Air Exhaust Port Thread Type: NPT
- Air Inlet Size (in): 3/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Application: Industrial
- Ball Material: Santoprene
- Center Section Material: Polypropylene
- Compatible Material: Antifreeze, Detergents, Windshield Washer Fluid, Diesel Exhaust Fluid, Cutting Oil, Water, Water - Wastewater Treatment, Water, Water - Wastewater Transfer
- Connection Type: Center Flange ANSI/DIN
- Diaphragm Compatible Material: Santoprene
- Diaphragm Material: Santoprene
- Fluid Inlet Size (cm): 5.08
- Fluid Inlet Size (in): 2
- Fluid Inlet Size (mm): 50.8
- Fluid Outlet Size (cm): 5.08
- Fluid Outlet Size (in): 2
- Fluid Outlet Size (mm): 50.8
- Fluid Section Material: Polypropylene
- Manifold Configuration: Center Port
- Manifold O-Ring Material: PTFE
- Material: Polypropylene
- Maximum Air Consumption (SCFM): 140
- Maximum Air Pressure (bar): 8.6
- Maximum Air Pressure (kPa): 860
- Maximum Air Pressure (MPa): 0.86
- Maximum Air Pressure (psi): 125
- Maximum Cycle Rate (CPM): 125
- Maximum Flow Rate (GPM): 200
- Maximum Flow Rate (L/min): 757
- Maximum Fluid Pressure (bar): 8.6
- Maximum Fluid Pressure (kPa): 860
- Maximum Fluid Pressure (MPa): 0.86
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 8.6
- Maximum Fluid Pressure (kPa): 860
- Maximum Fluid Pressure (MPa): 0.86
- Maximum Fluid Pressure (psi): 125
- Maximum Operating Temperature (°C): 66
- Maximum Operating Temperature (°F): 150
- Maximum Solid Size (cm): 0.9525
- Maximum Solid Size (in): 0.375
- Maximum Solid Size (mm): 9.525
- Minimum Operating Temperature (°C): 0
- Minimum Operating Temperature (°F): 32
- Minimum Storage Temperature (°C): 0
- Minimum Storage Temperature (°F): 32
- Power Source: Air <
$6,880.00
HUSKY PUMP, 2200P, P1, PP/PT/PT/A
GG 653504
GG 653504
HUSKY PUMP, 2200P, P1, PP/PT/PT/A
Husky 2200 PP Pump, Center Flange, PP Center Section, PP Seats, PTFE Balls & PTFE DiaphragmThe Husky 2200 air-operated diaphragm pump features a single piece polypropylene center section for increased reliability and chemical compatibility, plus a patented, high-reliability modular air valve that is online serviceable. This diaphragm pump is designed with a reinforced frame for improved reliability and will help to eliminate fluid leakage.
Overall improved air efficiency Highest fluid flow rate in its class Expanded material offering to handle endless applications Available with Overmolded diaphragms (up to 5 times longer diaphragm life) 2 in (50.8 mm) ANSI center and end-porting options available High flow - 200 gpm (757 lpm) in a compact, portable size Fluid pressure to 125 psi (8.6 bar, 0.86 MPa) Lube-free operation Available in polypropylene and PVDF
$7,810.00
HUSKY PUMP, 2200P, P1, PP/PT/PO/J
GG 653505
GG 653505
HUSKY PUMP, 2200P, P1, PP/PT/PO/J
Husky 2200 PP Pump, Center Flange, PP Center Section, PP Seats, PTFE Balls & PO DiaphragmThe Husky 2200 air-operated diaphragm pump features a single piece polypropylene center section for increased reliability and chemical compatibility, plus a patented, high-reliability modular air valve that is online serviceable. This diaphragm pump is designed with a reinforced frame for improved reliability and will help to eliminate fluid leakage.
Overall improved air efficiency Highest fluid flow rate in its class Expanded material offering to handle endless applications Available with Overmolded diaphragms (up to 5 times longer diaphragm life) 2 in (50.8 mm) ANSI center and end-porting options available High flow - 200 gpm (757 lpm) in a compact, portable size Fluid pressure to 125 psi (8.6 bar, 0.86 MPa) Lube-free operation Available in polypropylene and PVDF
$8,900.00
Cylinder, Ultralife (750Cc)
GG 685971
GG 685971
CYLINDER, ULTRALIFE (750CC)
Graco 685971 Cylinder Pump, SST/ Ultra-Life for 750 cc 4 Ball Lowers
$2,970.00
HUSKY PUMP, 2200F, F2, PV/PT/PT/A
GG 653546
GG 653546
HUSKY PUMP, 2200F, F2, PV/PT/PT/A
Husky 2200 PVDF Pump, PP Center Section, PVDF Seats, PTFE Balls & PTFE DiaphragmThe Husky 2200 air-operated diaphragm pump features a single piece polypropylene center section for increased reliability and chemical compatibility, plus a patented, high-reliability modular air valve that is online serviceable. This diaphragm pump is designed with a reinforced frame for improved reliability and will help to eliminate fluid leakage.
Overall improved air efficiency Highest fluid flow rate in its class Expanded material offering to handle endless applications Available with Overmolded diaphragms (up to 5 times longer diaphragm life) 2 in (50.8 mm) ANSI center and end-porting options available High flow - 200 gpm (757 lpm) in a compact, portable size Fluid pressure to 125 psi (8.6 bar, 0.86 MPa) Lube-free operation Available in polypropylene and PVDF
$18,870.00
HUSKY PUMP, 2200F, F2, PV/PT/PO/J
GG 653547
GG 653547
HUSKY PUMP, 2200F, F2, PV/PT/PO/J
Husky 2200 PVDF Pump, PP Center Section, PVDF Seats, PTFE Balls & PO DiaphragmThe Husky 2200 air-operated diaphragm pump features a single piece polypropylene center section for increased reliability and chemical compatibility, plus a patented, high-reliability modular air valve that is online serviceable. This diaphragm pump is designed with a reinforced frame for improved reliability and will help to eliminate fluid leakage.
Overall improved air efficiency Highest fluid flow rate in its class Expanded material offering to handle endless applications Available with Overmolded diaphragms (up to 5 times longer diaphragm life) 2 in (50.8 mm) ANSI center and end-porting options available High flow - 200 gpm (757 lpm) in a compact, portable size Fluid pressure to 125 psi (8.6 bar, 0.86 MPa) Lube-free operation Available in polypropylene and PVDF
$18,870.00
HUSKY PUMP, 15120P, P2, PP/PT/PT/PT
GG 654511
GG 654511
HUSKY PUMP, 15120P, P2, PP/PT/PT/PT
Graco 654511 Husky 15120 PP Pump, End Flange, PP Center Section, PP Seats, PTFE Balls & PTFE Diaphragm
The Husky 15120 air-operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.
The one-piece center section eliminates leaks and reduces maintenance on Husky pumps when compared to other diaphragm pumps.
- Overall improved efficiency (up to 40% more efficient)
- Highest fluid flow rate in its class
- Up to 5 times longer diaphragm life compared to other air operated diaphragm pumps
- 1-1/2 in (38.1 mm) ANSI center and end-porting options available
- High flow - 120 gpm (454 lpm) in a compact, portable size
- Fluid pressure to 125 psi (8.6 bar, 0.86 MPa)
- Lube-free operation
- Available in polypropylene and PVDF
- Model: Husky
- Series: 15120
- Air Exhaust Port Size (in): 1
- Air Exhaust Port Thread Gender: Female
- Air Exhaust Port Thread Type: NPT
- Air Inlet Size (in): 1/2
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Application: Industrial
- Ball Material: PTFE
- Center Section Material: Polypropylene
- Compatible Material: Antifreeze, Detergents, Windshield Washer Fluid, Diesel Exhaust Fluid, Cutting Oil, Water, Water, Water - Wastewater Transfer
- Connection Type: End Flange ANSI/DIN
- Diaphragm Compatible Material: PTFE
- Diaphragm Material: PTFE/EPDM 2-Piece
- Fluid Inlet Size (cm): 3.81
- Fluid Inlet Size (in): 1-1/2
- Fluid Inlet Size (mm): 38.1
- Fluid Inlet Thread Gender: Female
- Fluid Outlet Size (cm): 3.81
- Fluid Outlet Size (in): 1-1/2
- Fluid Outlet Size (mm): 38.1
- Fluid Outlet Thread Gender: Female
- Fluid Section Material: Polypropylene
- Manifold Configuration: End Port
- Manifold O-Ring Material: PTFE
- Material: Polypropylene
- Maximum Air Consumption (SCFM): 85
- Maximum Air Pressure (bar): 8.6
- Maximum Air Pressure (kPa): 860
- Maximum Air Pressure (MPa): 0.86
- Maximum Air Pressure (psi): 125
- Maximum Cycle Rate (CPM): 183
- Maximum Flow Rate (GPM): 120
- Maximum Flow Rate (L/min): 454
- Maximum Fluid Pressure (bar): 8.6
- Maximum Fluid Pressure (kPa): 860
- Maximum Fluid Pressure (MPa): 0.86
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 8.6
- Maximum Fluid Pressure (kPa): 860
- Maximum Fluid Pressure (MPa): 0.86
- Maximum Fluid Pressure (psi): 125
- Maximum Operating Temperature (°C): 66
- Maximum Operating Temperature (°F): 150
- Maximum Solid Size (cm): 0.635
- Maximum Solid Size (in): 0.25
- Maximum Solid Size (mm): 6.35
- Minimum Operating Temperature (°C): 0
- Minimum Operating Temperature (°F): 32
- Minimum Storage Temperature (°C): 0
- Minimum Storage Temperature (°F): 32
$5,510.00
HUSKY PUMP, 2150P-E, A04AP2SPSPSPPT
GG 656003
GG 656003
HUSKY PUMP, 2150P-E, A04AP2SPSPSPPT
Graco 656003 Husky 2150e 2 in. (51 mm) PP Electric Diaphragm Pump, 7.5 Hp AC Motor, No CMPSR, End Port Flange, AL Center, SP Seat, SP Ball, SP Diaphragm
High energy costs coupled with air diaphragm pumps powered by compressors have a huge negative impact on your profitability. The impact to operating costs is even larger when running high flow pumps. The Graco Husky 2150e electric diaphragm pump will reduce energy consumption by up to 80%. In addition to energy costs savings, Graco’s durable diaphragm pumps reduce maintenance costs and plant downtime.
- Energy Efficient Electric Drive - reduce energy consumption up to 80% compared to traditional air operated diaphragm pumps
- Stall Under Pressure - prevent pump failures from clogged lines or closed valves
- Seal-Less Diaphragm Pump Design - eliminate leaking and failures due to run-dry pump conditions
- Durable Component Materials -Transfer slurries and abrasives with no pump damage
- Favorite Diaphragm Pump Features - Gentle on shear sensitive material, runs dry, self-primes
- Air Exhaust Port Size (in): 0.375
- Air Exhaust Port Thread Gender: Female
- Air Exhaust Port Thread Type: NPT
- Air Inlet Size (in): 0.375
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Application: Industrial
- Ball Material: Santoprene
- Center Section Material: Aluminum
- Connection Type: Flange
- Diaphragm Compatible Material: Santoprene
- Diaphragm Material: Santoprene
- Fluid Inlet Size (cm): 5
- Fluid Inlet Size (in): 2
- Fluid Inlet Size (mm): 50
- Fluid Inlet Thread Gender: Female
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 5
- Fluid Outlet Size (in): 2
- Fluid Outlet Size (mm): 50
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Fluid Section Material: Polypropylene
- Manifold Configuration: End Port
- Manifold O-Ring Material: PTFE
- Material: Polypropylene
- Maximum Air Pressure (bar): 6.9
- Maximum Air Pressure (kPa): 690
- Maximum Air Pressure (MPa): 0.69
- Maximum Air Pressure (psi): 100
- Maximum Amperage (A): 19.5/9.75A
- Maximum Cycle Rate (CPM): 160
- Maximum Flow Rate (GPD): 0.6
- Maximum Flow Rate (GPM): 100
- Maximum Flow Rate (L/min): 378.5
- Maximum Fluid Pressure (bar): 6.9
- Maximum Fluid Pressure (kPa): 690
- Maximum Fluid Pressure (MPa): 0.69
- Maximum Fluid Pressure (psi): 100
- Maximum Fluid Pressure (bar): 6.9
- Maximum Fluid Pressure (kPa): 690
- Maximum Fluid Pressure (MPa): 0.69
- Maximum Fluid Pressure (psi): 100
- Maximum Motor Speed (RPM): 1800
- Maximum Operating Temperature (°C): 82.22
- Maximum Operating Temperature (°F): 180
- Maximum Solid Size (cm): 0.64
- Maximum Solid Size (in): 0.25
- Maximum Solid Size (mm): 6.35
- Maximum Working Pressure (psi): 100
- Minimum Operating Tempera
Call for pricing
DURA-FLO 1800 PUMP, RECIP, DISPL, 18CM-SST
GG 687055
GG 687055
DURA-FLO 1800 PUMP, RECIP, DISPL, 18CM-SST
Graco 687055 Dura-Flo 1800 (430 cc) Lower, Stainless Steel, 3 UHMWPE/2 Carbon-Filled PTFE Packings
Severe Duty rod and cylinder for increased durability, Graco’s Severe Duty is a stainless steel, hard chrome cylinder and rod which prolongs the life of the pump and packings
- Model: Check-Mate
- Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill
- Compatible Material: Motor Oil, Gear Oil, Automatic Transmission Fluid, Oil
- Fluid Inlet Size (cm): 5.0800
- Fluid Inlet Size (in): 2
- Fluid Inlet Thread Gender: Female
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 1-1/2
- Fluid Outlet Thread Gender: Male
- Fluid Outlet Thread Type: NPT
- For Use With: Dura-Flo Oil Pumps
- Maximum Flow Rate (GPM): 6.9
- Maximum Operating Temperature (°F): 150
- Maximum Output (cm³): 430
- Maximum Pump Speed (CPM): 60
- Maximum Working Pressure (psi): 4700
$14,050.00
Husky Pump, 2200F, F2, Pv/Fk/Fk/A
GG 653544
GG 653544
HUSKY PUMP, 2200F, F2, PV/FK/FK/A
Graco 653544 Husky 2200 PVDF Pump, PP Center Section, PVDF Seats, FKM Balls & FKM Diaphragm
The Husky 2200 air-operated diaphragm pump features a single piece polypropylene center section for increased reliability and chemical compatibility, plus a patented, high-reliability modular air valve that is online serviceable. This diaphragm pump is designed with a reinforced frame for improved reliability and will help to eliminate fluid leakage.
- Overall improved air efficiency
- Highest fluid flow rate in its class
- Expanded material offering to handle endless applications
- 2 in (50.8 mm) ANSI center and end-porting options available
- High flow - 200 gpm (757 lpm) in a compact, portable size
- Fluid pressure to 125 psi (8.6 bar, 0.86 MPa)
- Lube-free operation
- Available in polypropylene and PVDF
- Model: Husky
- Series: 2200
- Air Exhaust Port Size (in): 1
- Air Exhaust Port Thread Gender: Female
- Air Exhaust Port Thread Type: NPT
- Air Inlet Size (in): 3/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Application: Industrial
- Ball Material: FKM (Viton)
- Center Section Material: Polypropylene
- Compatible Material: Antifreeze, Detergents, Windshield Washer Fluid, Diesel Exhaust Fluid, Cutting Oil, Water, Water - Wastewater Treatment, Water, Water - Wastewater Transfer
- Connection Type: End Flange ANSI/DIN
- Diaphragm Compatible Material: FKM
- Diaphragm Material: FKM (Viton)
- Fluid Inlet Size (cm): 5.08
- Fluid Inlet Size (in): 2
- Fluid Inlet Size (mm): 50.8
- Fluid Outlet Size (cm): 5.08
- Fluid Outlet Size (in): 2
- Fluid Outlet Size (mm): 50.8
- Fluid Section Material: PVDF (Kynar)
- Manifold Configuration: End Port
- Manifold O-Ring Material: PTFE
- Material: PVDF
- Maximum Air Consumption (SCFM): 140
- Maximum Air Pressure (bar): 8.6
- Maximum Air Pressure (kPa): 860
- Maximum Air Pressure (MPa): 0.86
- Maximum Air Pressure (psi): 125
- Maximum Cycle Rate (CPM): 125
- Maximum Flow Rate (GPM): 200
- Maximum Flow Rate (L/min): 757
- Maximum Fluid Pressure (bar): 8.6
- Maximum Fluid Pressure (kPa): 860
- Maximum Fluid Pressure (MPa): 0.86
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 8.6
- Maximum Fluid Pressure (kPa): 860
- Maximum Fluid Pressure (MPa): 0.86
- Maximum Fluid Pressure (psi): 125
- Maximum Operating Temperature ( degree C): 107
- Maximum Operating Temperature ( degree F): 225
- Maximum Solid Size (cm): 0.9525
- Maximum Solid Size (in): 0.375
- Maximum Solid Size (mm): 9.525
- Minimum Operating Temperature ( degree C): 0
- Minimum Operating Temperature ( degree F): 32
- Minimum Storage Temperature ( degree C): 0
- Minimum Storage Temperature ( degree F): 32
- Power Source: Air
$25,190.00
HUSKY PUMP, 2200P, P2, PP/SP/SP/A
GG 653507
GG 653507
HUSKY PUMP, 2200P, P2, PP/SP/SP/A
Graco 653507 Husky 2200 PP Pump, End Flange, PP Center Section, PP Seats, SP Balls & SP Diaphragm
The Husky 2200 air-operated diaphragm pump features a single piece polypropylene center section for increased reliability and chemical compatibility, plus a patented, high-reliability modular air valve that is online serviceable. This diaphragm pump is designed with a reinforced frame for improved reliability and will help to eliminate fluid leakage.
- Overall improved air efficiency
- Highest fluid flow rate in its class
- Expanded material offering to handle endless applications
- 2 in (50.8 mm) ANSI center and end-porting options available
- High flow - 200 gpm (757 lpm) in a compact, portable size
- Fluid pressure to 125 psi (8.6 bar, 0.86 MPa)
- Lube-free operation
- Available in polypropylene and PVDF
- Model: Husky
- Series: 2200
- Air Exhaust Port Size (in): 1
- Air Exhaust Port Thread Gender: Female
- Air Exhaust Port Thread Type: NPT
- Air Inlet Size (in): 3/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Application: Industrial
- Ball Material: Santoprene
- Center Section Material: Polypropylene
- Compatible Material: Antifreeze, Detergents, Windshield Washer Fluid, Diesel Exhaust Fluid, Cutting Oil, Water, Water - Wastewater Treatment, Water, Water - Wastewater Transfer
- Connection Type: End Flange ANSI/DIN
- Diaphragm Compatible Material: Santoprene
- Diaphragm Material: Santoprene
- Fluid Inlet Size (cm): 5.08
- Fluid Inlet Size (in): 2
- Fluid Inlet Size (mm): 50.8
- Fluid Outlet Size (cm): 5.08
- Fluid Outlet Size (in): 2
- Fluid Outlet Size (mm): 50.8
- Fluid Section Material: Polypropylene
- Manifold Configuration: End Port
- Manifold O-Ring Material: PTFE
- Material: Polypropylene
- Maximum Air Consumption (SCFM): 140
- Maximum Air Pressure (bar): 8.6
- Maximum Air Pressure (kPa): 860
- Maximum Air Pressure (MPa): 0.86
- Maximum Air Pressure (psi): 125
- Maximum Cycle Rate (CPM): 125
- Maximum Flow Rate (GPM): 200
- Maximum Flow Rate (L/min): 757
- Maximum Fluid Pressure (bar): 8.6
- Maximum Fluid Pressure (kPa): 860
- Maximum Fluid Pressure (MPa): 0.86
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 8.6
- Maximum Fluid Pressure (kPa): 860
- Maximum Fluid Pressure (MPa): 0.86
- Maximum Fluid Pressure (psi): 125
- Maximum Operating Temperature (°C): 66
- Maximum Operating Temperature (°F): 150
- Maximum Solid Size (cm): 0.9525
- Maximum Solid Size (in): 0.375
- Maximum Solid Size (mm): 9.525
- Minimum Operating Temperature (°C): 0
- Minimum Operating Temperature (°F): 32
- Minimum Storage Temperature (°C): 0
- Minimum Storage Temperature (°F): 32
- Power Source: Air
$6,860.00
Kit, Repair Valve
GG 747096
GG 747096
KIT, REPAIR VALVE
Graco 747096 Hydra Spray Gun Repair Valve Kit
KIT INCLUDES: PACKING, O-RING [QTY. 1], PACKING, O-RING [QTY. 1], NUT, PACKING [QTY. 1], GLAND, PACKING [QTY. 1], PACKING, FLAT [QTY. 1], GASKET, COPPER [QTY. 1], SEAT, VALVE [QTY. 1], NEEDLE, FLUID [QTY. 1], PACKING, VALVE [QTY. 2]
- Compatible Material: Sealants, Adhesives
$735.00
HUSKY PUMP, 2200P, P2, PP/PT/PT/A
GG 653511
GG 653511
HUSKY PUMP, 2200P, P2, PP/PT/PT/A
Husky 2200 PP Pump, End Flange, PP Center Section, PP Seats, PTFE Balls & PTFE DiaphragmThe Husky 2200 air-operated diaphragm pump features a single piece polypropylene center section for increased reliability and chemical compatibility, plus a patented, high-reliability modular air valve that is online serviceable. This diaphragm pump is designed with a reinforced frame for improved reliability and will help to eliminate fluid leakage.
Overall improved air efficiency Highest fluid flow rate in its class Expanded material offering to handle endless applications Available with Overmolded diaphragms (up to 5 times longer diaphragm life) 2 in (50.8 mm) ANSI center and end-porting options available High flow - 200 gpm (757 lpm) in a compact, portable size Fluid pressure to 125 psi (8.6 bar, 0.86 MPa) Lube-free operation Available in polypropylene and PVDF
$7,810.00
HUSKY PUMP, 2200P, P2, SP/SP/SP/A
GG 653528
GG 653528
HUSKY PUMP, 2200P, P2, SP/SP/SP/A
Husky 2200 PP Pump, End Flange, PP Center Section, SP Seats, SP Balls & SP DiaphragmThe Husky 2200 air-operated diaphragm pump features a single piece polypropylene center section for increased reliability and chemical compatibility, plus a patented, high-reliability modular air valve that is online serviceable. This diaphragm pump is designed with a reinforced frame for improved reliability and will help to eliminate fluid leakage.
Overall improved air efficiency Highest fluid flow rate in its class Expanded material offering to handle endless applications Available with Overmolded diaphragms (up to 5 times longer diaphragm life) 2 in (50.8 mm) ANSI center and end-porting options available High flow - 200 gpm (757 lpm) in a compact, portable size Fluid pressure to 125 psi (8.6 bar, 0.86 MPa) Lube-free operation Available in polypropylene and PVDF
$6,800.00
HUSKY PUMP, 15120P, P1, PP/SP/SP/PT
GG 654500
GG 654500
HUSKY PUMP, 15120P, P1, PP/SP/SP/PT
Graco 654500 Husky 15120 PP Pump, Center Flange, PP Center Section, PP Seats, SP Balls & SP Diaphragm
The Husky 15120 air-operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.
The one-piece center section eliminates leaks and reduces maintenance on Husky pumps when compared to other diaphragm pumps.
- Overall improved efficiency (up to 40% more efficient)
- Highest fluid flow rate in its class
- Up to 5 times longer diaphragm life compared to other air operated diaphragm pumps
- 1-1/2 in (38.1 mm) ANSI center and end-porting options available
- High flow - 120 gpm (454 lpm) in a compact, portable size
- Fluid pressure to 125 psi (8.6 bar, 0.86 MPa)
- Lube-free operation
- Available in polypropylene and PVDF
- Model: Husky
- Series: 15120
- Air Exhaust Port Size (in): 1
- Air Exhaust Port Thread Gender: Female
- Air Exhaust Port Thread Type: NPT
- Air Inlet Size (in): 1/2
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Application: Industrial
- Ball Material: Santoprene
- Center Section Material: Polypropylene
- Compatible Material: Antifreeze, Detergents, Windshield Washer Fluid, Diesel Exhaust Fluid, Cutting Oil, Water, Water - Wastewater Treatment, Water, Water - Wastewater Transfer
- Connection Type: Center Flange ANSI/DIN
- Diaphragm Compatible Material: Santoprene
- Diaphragm Material: Santoprene
- Fluid Inlet Size (cm): 3.81
- Fluid Inlet Size (in): 1-1/2
- Fluid Inlet Size (mm): 38.1
- Fluid Inlet Thread Gender: Female
- Fluid Outlet Size (cm): 3.81
- Fluid Outlet Size (in): 1-1/2
- Fluid Outlet Size (mm): 38.1
- Fluid Outlet Thread Gender: Female
- Fluid Section Material: Polypropylene
- Manifold Configuration: Center Port
- Manifold O-Ring Material: PTFE
- Material: Polypropylene
- Maximum Air Consumption (SCFM): 85
- Maximum Air Pressure (bar): 8.6
- Maximum Air Pressure (kPa): 860
- Maximum Air Pressure (MPa): 0.86
- Maximum Air Pressure (psi): 125
- Maximum Cycle Rate (CPM): 183
- Maximum Flow Rate (GPM): 120
- Maximum Flow Rate (L/min): 454
- Maximum Fluid Pressure (bar): 8.6
- Maximum Fluid Pressure (kPa): 860
- Maximum Fluid Pressure (MPa): 0.86
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 8.6
- Maximum Fluid Pressure (kPa): 860
- Maximum Fluid Pressure (MPa): 0.86
- Maximum Fluid Pressure (psi): 125
- Maximum Operating Temperature (°C): 66
- Maximum Operating Temperature (°F): 150
- Maximum Solid Size (cm): 0.635
- Maximum Solid Size (in): 0.25
- Maximum Solid Size (mm): 6.35
- Minimum Operating Temperature (°C): 0
- Minimum Operating Temperature (°F): 32
- Minimum Storage Temperature (°C): 0
- Minimum Storage Temperature (
$4,650.00
HUSKY PUMP, 15120P, P1, SP/SP/SP/PT
GG 654526
GG 654526
HUSKY PUMP, 15120P, P1, SP/SP/SP/PT
Husky 15120 PP Pump, Center Flange, PP Center Section, SP Seats, SP Balls & SP DiaphragmThe Husky 15120 air-operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.
The one-piece center section eliminates leaks and reduces maintenance on Husky pumps when compared to other diaphragm pumps.
Overall improved efficiency (up to 40% more efficient) Highest fluid flow rate in its class Up to 5 times longer diaphragm life compared to other air operated diaphragm pumps Expanded material offering to handle endless applications 1-1/2 in (38.1 mm) ANSI center and end-porting options available High flow - 120 gpm (454 lpm) in a compact, portable size Fluid pressure to 125 psi (8.6 bar, 0.86 MPa) Lube-free operation Available in polypropylene and PVDF
$4,460.00
HUSKY PUMP, 15120P, P2, PP/PT/PO/PT
GG 654512
GG 654512
HUSKY PUMP, 15120P, P2, PP/PT/PO/PT
Graco 654512 Husky 15120 PP Pump, End Flange, PP Center Section, PP Seats, PTFE Balls & PO Diaphragm
The Husky 15120 air-operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.
The one-piece center section eliminates leaks and reduces maintenance on Husky pumps when compared to other diaphragm pumps.
- Overall improved efficiency (up to 40% more efficient)
- Highest fluid flow rate in its class
- Up to 5 times longer diaphragm life compared to other air operated diaphragm pumps
- 1-1/2 in (38.1 mm) ANSI center and end-porting options available
- High flow - 120 gpm (454 lpm) in a compact, portable size
- Fluid pressure to 125 psi (8.6 bar, 0.86 MPa)
- Lube-free operation
- Available in polypropylene and PVDF
- Model: Husky
- Series: 15120
- Air Exhaust Port Size (in): 1
- Air Exhaust Port Thread Gender: Female
- Air Exhaust Port Thread Type: NPT
- Air Inlet Size (in): 1/2
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Application: Industrial
- Ball Material: PTFE
- Center Section Material: Polypropylene
- Compatible Material: Antifreeze, Detergents, Windshield Washer Fluid, Diesel Exhaust Fluid, Cutting Oil, Water, Water, Water - Wastewater Transfer
- Connection Type: End Flange ANSI/DIN
- Diaphragm Compatible Material: PTFE
- Diaphragm Material: PTFE Overmold
- Fluid Inlet Size (cm): 3.81
- Fluid Inlet Size (in): 1-1/2
- Fluid Inlet Size (mm): 38.1
- Fluid Inlet Thread Gender: Female
- Fluid Outlet Size (cm): 3.81
- Fluid Outlet Size (in): 1-1/2
- Fluid Outlet Size (mm): 38.1
- Fluid Outlet Thread Gender: Female
- Fluid Section Material: Polypropylene
- Manifold Configuration: End Port
- Manifold O-Ring Material: PTFE
- Material: Polypropylene
- Maximum Air Consumption (SCFM): 85
- Maximum Air Pressure (bar): 8.6
- Maximum Air Pressure (kPa): 860
- Maximum Air Pressure (MPa): 0.86
- Maximum Air Pressure (psi): 125
- Maximum Cycle Rate (CPM): 183
- Maximum Flow Rate (GPM): 120
- Maximum Flow Rate (L/min): 454
- Maximum Fluid Pressure (bar): 8.6
- Maximum Fluid Pressure (kPa): 860
- Maximum Fluid Pressure (MPa): 0.86
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 8.6
- Maximum Fluid Pressure (kPa): 860
- Maximum Fluid Pressure (MPa): 0.86
- Maximum Fluid Pressure (psi): 125
- Maximum Operating Temperature (°C): 66
- Maximum Operating Temperature (°F): 150
- Maximum Solid Size (cm): 0.635
- Maximum Solid Size (in): 0.25
- Maximum Solid Size (mm): 6.35
- Minimum Operating Temperature (°C): 0
- Minimum Operating Temperature (°F): 32
- Minimum Storage Temperature (°C): 0
- Minimum Storage Temperature (°F): 32
$6,710.00
HUSKY PUMP, 2200P, P2, PP/PT/PO/J
GG 653512
GG 653512
HUSKY PUMP, 2200P, P2, PP/PT/PO/J
Graco 653512 Husky 2200 PP Pump, End Flange, PP Center Section, PP Seats, PTFE Balls & PO Diaphragm
The Husky 2200 air-operated diaphragm pump features a single piece polypropylene center section for increased reliability and chemical compatibility, plus a patented, high-reliability modular air valve that is online serviceable. This diaphragm pump is designed with a reinforced frame for improved reliability and will help to eliminate fluid leakage.
- Overall improved air efficiency
- Highest fluid flow rate in its class
- Expanded material offering to handle endless applications
- 2 in (50.8 mm) ANSI center and end-porting options available
- High flow - 200 gpm (757 lpm) in a compact, portable size
- Fluid pressure to 125 psi (8.6 bar, 0.86 MPa)
- Lube-free operation
- Available in polypropylene and PVDF
- Model: Husky
- Series: 2200
- Air Exhaust Port Size (in): 1
- Air Exhaust Port Thread Gender: Female
- Air Exhaust Port Thread Type: NPT
- Air Inlet Size (in): 3/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Application: Industrial
- Ball Material: PTFE
- Center Section Material: Polypropylene
- Compatible Material: Antifreeze, Detergents, Windshield Washer Fluid, Diesel Exhaust Fluid, Cutting Oil, Water, Water - Wastewater Treatment, Water, Water - Wastewater Transfer
- Connection Type: End Flange ANSI/DIN
- Diaphragm Material: PTFE Overmold
- Fluid Inlet Size (cm): 5.08
- Fluid Inlet Size (in): 2
- Fluid Inlet Size (mm): 50.8
- Fluid Outlet Size (cm): 5.08
- Fluid Outlet Size (in): 2
- Fluid Outlet Size (mm): 50.8
- Fluid Section Material: Polypropylene
- Manifold Configuration: End Port
- Manifold O-Ring Material: PTFE
- Material: Polypropylene
- Maximum Air Consumption (SCFM): 157
- Maximum Air Pressure (bar): 8.6
- Maximum Air Pressure (kPa): 860
- Maximum Air Pressure (MPa): 0.86
- Maximum Air Pressure (psi): 125
- Maximum Cycle Rate (CPM): 155
- Maximum Flow Rate (GPM): 200
- Maximum Flow Rate (L/min): 757
- Maximum Fluid Pressure (bar): 8.6
- Maximum Fluid Pressure (kPa): 860
- Maximum Fluid Pressure (MPa): 0.86
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 8.6
- Maximum Fluid Pressure (kPa): 860
- Maximum Fluid Pressure (MPa): 0.86
- Maximum Fluid Pressure (psi): 125
- Maximum Operating Temperature (°C): 66
- Maximum Operating Temperature (°F): 150
- Maximum Solid Size (cm): 0.9525
- Maximum Solid Size (in): 0.375
- Maximum Solid Size (mm): 9.525
- Minimum Operating Temperature (°C): 0
- Minimum Operating Temperature (°F): 32
- Minimum Storage Temperature (°C): 0
- Minimum Storage Temperature (°F): 32
- Power Source: Air
$8,900.00
MANIFOLD, REMOTE FILL WITH VENT ASM
GG 77X542
GG 77X542
MANIFOLD, REMOTE FILL WITH VENT ASM
Graco 77X542 Remote-Fill Port Manifold with Vent for use with Auto-Fill Shut-Off Option Lubrication Pumps
Application: For use with optional Auto-Fill Shut-Off Electric Dyna-Star® HP and HF, G3, and Compact Dyna-Star Lubrication Systems.
- Remote-fill port manifold with vent
- Application: Off-Road Equipment
- Compatible Material: Grease
- For Use With: Compact Dyna-Star Pumps, Electric Dyna-Star Pumps, G3 Pumps, Hydraulic Dyna-Star Jakes
- Includes: Remote Fill Port Manifold, Manual Valve, Pressure Gauge, Relief Valve, Lubricant, Fittings, Hardware
- Kit Type: Remote-Fill Port Manifold
$770.00
XHD RAC TIP, SPRAY, CYLINDER, 623
GG XHD623
GG XHD623
XHD RAC TIP, SPRAY, CYLINDER, 623
Graco XHD623 XHD RAC SwitchTip, .623
With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
Application: High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures.- Saves time – no screwdriver required, change tip sizes in seconds
- For heavy-duty applications up to 7250 psi (500 bar)
- Recommended for use with Xtreme Sprayers and XTR Guns
- Model: XHD RAC
- Series: SwitchTip
- Compatible Material: Solvent borne Paints, Water-Based Paint
- For Use With: Xtreme Sprayers, XTR Airless Spray Guns
- Maximum Fan Width (cm): 35.6
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 0.57
- Maximum Flow Rate (L/min): 2.16
- Maximum Working Pressure (bar): 500
- Maximum Working Pressure (kPa): 50000
- Maximum Working Pressure (psi): 7250
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.023
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 629
GG XHD629
GG XHD629
XHD RAC TIP, SPRAY, CYLINDER, 629
XHD RAC SwitchTip, .629With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 635
GG XHD635
GG XHD635
XHD RAC TIP, SPRAY, CYLINDER, 635
XHD RAC SwitchTip, .635With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 633
GG XHD633
GG XHD633
XHD RAC TIP, SPRAY, CYLINDER, 633
XHD RAC SwitchTip, .633With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 627
GG XHD627
GG XHD627
XHD RAC TIP, SPRAY, CYLINDER, 627
Graco XHD627 XHD RAC SwitchTip, .627
With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
Application: High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures.- Saves time – no screwdriver required, change tip sizes in seconds
- For heavy-duty applications up to 7250 psi (500 bar)
- Recommended for use with Xtreme Sprayers and XTR Guns
- Model: XHD RAC
- Series: SwitchTip
- Compatible Material: Solvent borne Paints, Water-Based Paint
- For Use With: Xtreme Sprayers, XTR Airless Spray Guns
- Maximum Fan Width (cm): 35.6
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 0.74
- Maximum Flow Rate (L/min): 2.80
- Maximum Working Pressure (bar): 500
- Maximum Working Pressure (kPa): 50000
- Maximum Working Pressure (psi): 7250
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.027
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 631
GG XHD631
GG XHD631
XHD RAC TIP, SPRAY, CYLINDER, 631
Graco XHD631 XHD RAC SwitchTip, .631
With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
Application: High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures.- Saves time – no screwdriver required, change tip sizes in seconds
- For heavy-duty applications up to 7250 psi (500 bar)
- Recommended for use with Xtreme Sprayers and XTR Guns
- Model: XHD RAC
- Series: SwitchTip
- Compatible Material: Solvent borne Paints, Water-Based Paint
- For Use With: Xtreme Sprayers, XTR Airless Spray Guns
- Maximum Fan Width (cm): 35.6
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 1.03
- Maximum Flow Rate (L/min): 3.90
- Maximum Working Pressure (bar): 500
- Maximum Working Pressure (kPa): 50000
- Maximum Working Pressure (psi): 7250
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.031
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 641
GG XHD641
GG XHD641
XHD RAC TIP, SPRAY, CYLINDER, 641
Graco XHD641 XHD RAC SwitchTip, .641
With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
Application: High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures.- Saves time – no screwdriver required, change tip sizes in seconds
- For heavy-duty applications up to 7250 psi (500 bar)
- Recommended for use with Xtreme Sprayers and XTR Guns
- Model: XHD RAC
- Series: SwitchTip
- Compatible Material: Solvent borne Paints, Water-Based Paint
- For Use With: Xtreme Sprayers, XTR Airless Spray Guns
- Maximum Fan Width (cm): 35.6
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 1.80
- Maximum Flow Rate (L/min): 6.81
- Maximum Working Pressure (bar): 500
- Maximum Working Pressure (kPa): 50000
- Maximum Working Pressure (psi): 7250
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.041
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 645
GG XHD645
GG XHD645
XHD RAC TIP, SPRAY, CYLINDER, 645
Graco XHD645 XHD RAC SwitchTip, .645
With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
Application: High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures.- Saves time – no screwdriver required, change tip sizes in seconds
- For heavy-duty applications up to 7250 psi (500 bar)
- Recommended for use with Xtreme Sprayers and XTR Guns
- Model: XHD RAC
- Series: SwitchTip
- Compatible Material: Solvent borne Paints, Water-Based Paint
- For Use With: Xtreme Sprayers, XTR Airless Spray Guns
- Maximum Fan Width (cm): 35.6
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 2.17
- Maximum Flow Rate (L/min): 8.21
- Maximum Working Pressure (bar): 500
- Maximum Working Pressure (kPa): 50000
- Maximum Working Pressure (psi): 7250
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.045
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 651
GG XHD651
GG XHD651
XHD RAC TIP, SPRAY, CYLINDER, 651
Graco XHD651 XHD RAC SwitchTip, .651
With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
Application: High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures.- Saves time – no screwdriver required, change tip sizes in seconds
- For heavy-duty applications up to 7250 psi (500 bar)
- Recommended for use with Xtreme Sprayers and XTR Guns
- Model: XHD RAC
- Series: SwitchTip
- Compatible Material: Solvent borne Paints, Water-Based Paint
- For Use With: Xtreme Sprayers, XTR Airless Spray Guns
- Maximum Fan Width (cm): 35.6
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 2.79
- Maximum Flow Rate (L/min): 10.56
- Maximum Working Pressure (bar): 500
- Maximum Working Pressure (kPa): 50000
- Maximum Working Pressure (psi): 7250
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.051
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 655
GG XHD655
GG XHD655
XHD RAC TIP, SPRAY, CYLINDER, 655
Graco XHD655 XHD RAC SwitchTip, .655
With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
Application: High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures.- Saves time – no screwdriver required, change tip sizes in seconds
- For heavy-duty applications up to 7250 psi (500 bar)
- Recommended for use with Xtreme Sprayers and XTR Guns
- Model: XHD RAC
- Series: SwitchTip
- Compatible Material: Solvent borne Paints, Water-Based Paint
- For Use With: Xtreme Sprayers, XTR Airless Spray Guns
- Maximum Fan Width (cm): 35.6
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 3.25
- Maximum Flow Rate (L/min): 12.30
- Maximum Working Pressure (bar): 500
- Maximum Working Pressure (kPa): 50000
- Maximum Working Pressure (psi): 7250
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.055
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 665
GG XHD665
GG XHD665
XHD RAC TIP, SPRAY, CYLINDER, 665
Graco XHD665 XHD RAC SwitchTip, .665
With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
Application: High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures.- Saves time – no screwdriver required, change tip sizes in seconds
- For heavy-duty applications up to 7250 psi (500 bar)
- Recommended for use with Xtreme Sprayers and XTR Guns
- Model: XHD RAC
- Series: SwitchTip
- Compatible Material: Solvent borne Paints, Water-Based Paint
- For Use With: Xtreme Sprayers, XTR Airless Spray Guns
- Maximum Fan Width (cm): 35.6
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 4.53
- Maximum Flow Rate (L/min): 17.15
- Maximum Working Pressure (bar): 500
- Maximum Working Pressure (kPa): 50000
- Maximum Working Pressure (psi): 7250
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.065
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 671
GG XHD671
GG XHD671
XHD RAC TIP, SPRAY, CYLINDER, 671
XHD RAC SwitchTip, .671With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 675
GG XHD675
GG XHD675
XHD RAC TIP, SPRAY, CYLINDER, 675
XHD RAC SwitchTip, .675With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 711
GG XHD711
GG XHD711
XHD RAC TIP, SPRAY, CYLINDER, 711
XHD RAC SwitchTip, .711With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 719
GG XHD719
GG XHD719
XHD RAC TIP, SPRAY, CYLINDER, 719
XHD RAC SwitchTip, .719With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 717
GG XHD717
GG XHD717
XHD RAC TIP, SPRAY, CYLINDER, 717
XHD RAC SwitchTip, .717With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 727
GG XHD727
GG XHD727
XHD RAC TIP, SPRAY, CYLINDER, 727
XHD RAC SwitchTip, .727With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 725
GG XHD725
GG XHD725
XHD RAC TIP, SPRAY, CYLINDER, 725
Graco XHD725 XHD RAC SwitchTip, .725
With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
Application: High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures.- Saves time – no screwdriver required, change tip sizes in seconds
- For heavy-duty applications up to 7250 psi (500 bar)
- Recommended for use with Xtreme Sprayers and XTR Guns
- Model: XHD RAC
- Series: SwitchTip
- Compatible Material: Solvent borne Paints, Water-Based Paint
- For Use With: Xtreme Sprayers, XTR Airless Spray Guns
- Maximum Fan Width (cm): 40.6
- Maximum Fan Width (in): 16
- Maximum Fan Width (mm): 406
- Maximum Flow Rate (GPM): 0.67
- Maximum Flow Rate (L/min): 2.54
- Maximum Working Pressure (bar): 500
- Maximum Working Pressure (kPa): 50000
- Maximum Working Pressure (psi): 7250
- Minimum Fan Width (in): 14
- Minimum Fan Width (mm): 356
- Orifice Diameter (in): 0.025
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 815
GG XHD815
GG XHD815
XHD RAC TIP, SPRAY, CYLINDER, 815
XHD RAC SwitchTip, .815With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 771
GG XHD771
GG XHD771
XHD RAC TIP, SPRAY, CYLINDER, 771
XHD RAC SwitchTip, .771With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 817
GG XHD817
GG XHD817
XHD RAC TIP, SPRAY, CYLINDER, 817
XHD RAC SwitchTip, .817With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 819
GG XHD819
GG XHD819
XHD RAC TIP, SPRAY, CYLINDER, 819
Graco XHD819 XHD RAC SwitchTip, .819
With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
Application: High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures.- Saves time – no screwdriver required, change tip sizes in seconds
- For heavy-duty applications up to 7250 psi (500 bar)
- Recommended for use with Xtreme Sprayers and XTR Guns
- Model: XHD RAC
- Series: SwitchTip
- Compatible Material: Solvent borne Paints, Water-Based Paint
- For Use With: Xtreme Sprayers, XTR Airless Spray Guns
- Maximum Fan Width (cm): 45.7
- Maximum Fan Width (in): 18
- Maximum Fan Width (mm): 457
- Maximum Flow Rate (GPM): 0.38
- Maximum Flow Rate (L/min): 1.44
- Maximum Working Pressure (bar): 500
- Maximum Working Pressure (kPa): 50000
- Maximum Working Pressure (psi): 7250
- Minimum Fan Width (in): 16
- Minimum Fan Width (mm): 406
- Orifice Diameter (in): 0.019
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 821
GG XHD821
GG XHD821
XHD RAC TIP, SPRAY, CYLINDER, 821
Graco XHD821 XHD RAC SwitchTip, .821
With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
Application: High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures.- Saves time – no screwdriver required, change tip sizes in seconds
- For heavy-duty applications up to 7250 psi (500 bar)
- Recommended for use with Xtreme Sprayers and XTR Guns
- Model: XHD RAC
- Series: SwitchTip
- Compatible Material: Solvent borne Paints, Water-Based Paint
- For Use With: Xtreme Sprayers, XTR Airless Spray Guns
- Maximum Fan Width (cm): 45.7
- Maximum Fan Width (in): 18
- Maximum Fan Width (mm): 457
- Maximum Flow Rate (GPM): 0.47
- Maximum Flow Rate (L/min): 1.78
- Maximum Working Pressure (bar): 500
- Maximum Working Pressure (kPa): 50000
- Maximum Working Pressure (psi): 7250
- Minimum Fan Width (in): 16
- Minimum Fan Width (mm): 406
- Orifice Diameter (in): 0.021
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 825
GG XHD825
GG XHD825
XHD RAC TIP, SPRAY, CYLINDER, 825
XHD RAC SwitchTip, .825With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 827
GG XHD827
GG XHD827
XHD RAC TIP, SPRAY, CYLINDER, 827
XHD RAC SwitchTip, .827With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 831
GG XHD831
GG XHD831
XHD RAC TIP, SPRAY, CYLINDER, 831
Graco XHD831 XHD RAC SwitchTip, .831
With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
Application: High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures.- Saves time – no screwdriver required, change tip sizes in seconds
- For heavy-duty applications up to 7250 psi (500 bar)
- Recommended for use with Xtreme Sprayers and XTR Guns
- Model: XHD RAC
- Series: SwitchTip
- Compatible Material: Solvent borne Paints, Water-Based Paint
- For Use With: Xtreme Sprayers, XTR Airless Spray Guns
- Maximum Fan Width (cm): 45.7
- Maximum Fan Width (in): 18
- Maximum Fan Width (mm): 457
- Maximum Flow Rate (GPM): 1.03
- Maximum Flow Rate (L/min): 3.90
- Maximum Working Pressure (bar): 500
- Maximum Working Pressure (kPa): 50000
- Maximum Working Pressure (psi): 7250
- Minimum Fan Width (in): 16
- Minimum Fan Width (mm): 406
- Orifice Diameter (in): 0.031
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 861
GG XHD861
GG XHD861
XHD RAC TIP, SPRAY, CYLINDER, 861
XHD RAC SwitchTip, .861With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 867
GG XHD867
GG XHD867
XHD RAC TIP, SPRAY, CYLINDER, 867
XHD RAC SwitchTip, .867With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XHD RAC TIP, SPRAY, CYLINDER, 923
GG XHD923
GG XHD923
XHD RAC TIP, SPRAY, CYLINDER, 923
XHD RAC SwitchTip, .923With its Reverse-A-Clean (RAC) Tip, it’s easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds – without removing the tip guard and housing.
High-Pressure Airless Spray Tip for XTR and XHF Guns. Designed for spraying high-solids coatings at high pressures. Saves time – no screwdriver required, change tip sizes in seconds For heavy-duty applications up to 7250 psi (500 bar) Recommended for use with Xtreme Sprayers and XTR Guns Heavy-duty carbide tip
$116.50
XM SPRAYER SYSTEM, XM50, R, IS
GG XM5N00
GG XM5N00
XM SPRAYER SYSTEM, XM50, R, IS
Graco XM5N00 XM50 System, Hazardous Location, 240V, Alternator Power, No Heaters, No Junction Box, No Feed System, Remote Manifold
Engineered to handle the toughest protective coatings, the Graco XM plural-component sprayer provides precise ratio control, allows users to download historical spraying data, and handles a wide range of two-component materials.
Application: Ideally suited for marine, bridge, rail and wind energy applications, the Graco XM is fully configurable for your specific coatings job.- Variable ratio system - handles material ratios from 1:1 to 10:1
- Dosing technology assures accurate, on-ratio mixing for better yield and less waste
- Advanced, intuitive user controls provide real-time display and adjustment of ratio
- Supports multiple spray guns for added productivity
- Model: XM
- Series: 50
- Air Inlet Size (in): 3/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Fluid Inlet Size (in): 1-1/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Maximum Air Consumption (m3/min): 1.96 m3/min per lpm at 100psi
- Maximum Air Consumption (SCFM): 70 scfm/gpm at 100psi
- Maximum Air Inlet Pressure (bar): 10.3
- Maximum Air Inlet Pressure (psi): 150
- Maximum Flow Rate (GPM): 3
- Maximum Flow Rate (L/min): 11.4
- Maximum Fluid Temperature (°C): 71
- Maximum Fluid Temperature (°F): 160
- Maximum Fluid Viscosity (cP): 20000
- Maximum Fluid Temperature (°C): 71
- Maximum Fluid Temperature (°F): 160
- Maximum Fluid Viscosity (cP): 20000
- Maximum Mix Ratio: 10:1
- Maximum Operating Temperature (°C): 54
- Maximum Operating Temperature (°F): 130
- Maximum Working Pressure (bar): 358
- Maximum Working Pressure (MPa): 35.8
- Maximum Working Pressure (psi): 5200
- Minimum Flow Rate (GPM): 0.25
- Minimum Flow Rate (L/min): 0.95
- Minimum Mix Ratio: 1:1
- Mix Accuracy (%): 5%
- Power Source: Alternator
- Primary Fluid Heater Included: No
$71,260.00
XM SPRAYER SYSTEM, XM70, R, 480, JB, WP, 25, E
GG XM7H2E
GG XM7H2E
XM SPRAYER SYSTEM, XM70, R, 480, JB, WP, 25, E
XM70 Skid System, Non-Hazardous, With Electric Heated Hose and 25 Gallon Heated Hoppers, 480V Engineered to handle the toughest protective coatings, the Graco XM plural-component sprayer provides precise ratio control, allows users to download historical spraying data, and handles a wide range of two-component materials. Ideally suited for marine, bridge, rail and wind energy applications, the Graco XM is fully configurable for your specific coatings job. Variable ratio system - handles material ratios from 1:1 to 10:1 Dosing technology assures accurate, on-ratio mixing for better yield and less waste Advanced, intuitive user controls provide real-time display and adjustment of ratio USB port lets you easily access and download historical spraying data Supports multiple spray guns for added productivity
$131,940.00
XM SPRAYER SYSTEM, XM70, R, 480, JB, IS, 25, E
GG XM7K2E
GG XM7K2E
XM SPRAYER SYSTEM, XM70, R, 480, JB, IS, 25, E
Graco XM7K2E XM70, 480V, Alternator, EX Viscon HF Heaters, EX Junction Box, Heated Tanks, Agitators, Feed Pumps, Remote, Electric Hose Control
Engineered to handle the toughest protective coatings, the Graco XM plural-component sprayer provides precise ratio control, allows users to download historical spraying data, and handles a wide range of two-component materials.
Application: Ideally suited for marine, bridge, rail and wind energy applications, the Graco XM is fully configurable for your specific coatings job.- Variable ratio system - handles material ratios from 1:1 to 10:1
- Dosing technology assures accurate, on-ratio mixing for better yield and less waste
- Advanced, intuitive user controls provide real-time display and adjustment of ratio
- Supports multiple spray guns for added productivity
- Model: XM
- Series: 70
- Air Inlet Size (in): 3/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Fluid Inlet Size (in): 1-1/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Maximum Air Consumption (m3/min): 1.96 m3/min per lpm at 100psi
- Maximum Air Consumption (SCFM): 70 scfm/gpm at 100psi
- Maximum Air Inlet Pressure (bar): 10.3
- Maximum Air Inlet Pressure (psi): 150
- Maximum Flow Rate (GPM): 3
- Maximum Flow Rate (L/min): 11.4
- Maximum Fluid Temperature (°C): 71
- Maximum Fluid Temperature (°F): 160
- Maximum Fluid Viscosity (cP): 20000
- Maximum Fluid Temperature (°C): 71
- Maximum Fluid Temperature (°F): 160
- Maximum Fluid Viscosity (cP): 20000
- Maximum Mix Ratio: 10:1
- Maximum Operating Temperature (°C): 54
- Maximum Operating Temperature (°F): 130
- Maximum Working Pressure (bar): 435
- Maximum Working Pressure (MPa): 43.5
- Maximum Working Pressure (psi): 6300
- Minimum Flow Rate (GPM): 0.25
- Minimum Flow Rate (L/min): 0.95
- Minimum Mix Ratio: 1:1
- Mix Accuracy (%): 5%
- Power Source: Alternator
- Primary Fluid Heater Included: Yes
$207,030.00
XDX SERIES 20 REEL, HOSE
GG XNL65D
GG XNL65D
XDX SERIES 20 REEL, HOSE
Graco XNL65D XDX™ 20, Air/Water/Antifreeze/WWS, 1/2 in (13 mm) Inlet, 1/2 in X 50 ft (13 mm X 15 m) Hose, NPT, No Guide Arms, Black
Graco’s heavy-duty XDX hose reel features a heavy-gauge, robust, dual-pedestal metal frame, steel spool, sealed components and innovative swivel design for high-quality performance in the most demanding applications.
Application: Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks.- Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
- Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
- Optional Adjustable Arm - Easily change the arm position for your application, order with arm (XD models) or without (XN models)
- Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (107-198 meters) hose capacity for a wide variety of applications
- Series: 20
- Application: Air, Water, Antifreeze, WWS
- Color: Black
- Dry Weight (lb): 64
- Frame Type: Dual Pedestal
- Hose Inside Diameter (in): 1/2
- Hose Inside Diameter (mm): 12.7
- Hose Length (ft): 75
- Hose Length (m): 23
- Hose Reel Type: Reel with Hose
- Includes Hose: Yes
- Inlet Size (in): 1/2
- Inlet Size (mm): 12.7
- Inlet Thread Gender: Male
- Inlet Thread Type: NPSM
- Maximum Temperature (°C): 87
- Maximum Temperature (°F): 190
- Maximum Working Pressure (psi): 300
- Outlet Size (in): 1/2
- Outlet Size (mm): 12.7
- Outlet Thread Gender: Male
- Outlet Thread Type: NPT
- Overall Height (in): 25.2
- Overall Height (mm): 640
- Overall Length (in): 21
- Overall Length (mm): 533
- Overall Width (in): 7.5
- Overall Width (mm): 191
- Recommended Environment: Indoor, Outdoor
- Recommended Fluid Type: Air, Water, Antifreeze, WWS
Call for pricing
Kit, Mix Module, Rnd., Polyurea.
GG XR2323
GG XR2323
Kit, Mix Module, Rnd., Polyurea.
Call for pricing
XTR+ GUN, XTR5+, 1"HND, 4FNG, FLAT TIP
GG XTR521
GG XTR521
XTR+ GUN, XTR5+, 1"HND, 4FNG, FLAT TIP
XTR5+ Airless Spray Gun, Round Handle, 4-Finger Trigger, Flat Tip New look. New features. A self-locking needle design offers unmatched ease of breaking down for cleaning or rebuilds. Paired with a new look, you'll never think twice about grabbing the correctly pressure rated XTR+ gun for your Graco sprayer. Designed to conquer the toughest protective coatings. Self-locking needle design for faster rebuilds Flat tip provides exceptional life, pattern and finish Easily remove and clean gun filter with trigger guard integrated wrench XTR5+ maximum fluid pressure: 5000psi (345 bar, 34.5 MPa)
$534.00
XTR+ GUN, XTR5+, OVL HND, 4FNG, XHDRAC
GG XTR522
GG XTR522
XTR+ GUN, XTR5+, OVL HND, 4FNG, XHDRAC
XTR5+ Airless Spray Gun, Insulated Handle, 4-Finger Trigger, XHD RAC Tip New look. New features. A self-locking needle design offers unmatched ease of breaking down for cleaning or rebuilds. Paired with a new look, you'll never think twice about grabbing the correctly pressure rated XTR+ gun for your Graco sprayer. Designed to conquer the toughest protective coatings. Self-locking needle design for faster rebuilds XHD RAC tip provides exceptional life, pattern and finish Easily remove and clean gun filter with trigger guard integrated wrench XTR5+ maximum fluid pressure: 5000psi (345 bar, 34.5 MPa) Insulated handle for sprayer comfort
$534.00
XTR+ GUN, XTR5+, OVL HND, 2FNG, XHDRAC
GG XTR523
GG XTR523
XTR+ GUN, XTR5+, OVL HND, 2FNG, XHDRAC
Graco XTR523 XTR5+ Airless Spray Gun, Insulated Handle, 2-Finger Trigger, XHD RAC Tip
New look. New features. A self-locking needle design offers unmatched ease of breaking down for cleaning or rebuilds. Paired with a new look, you&prime, ll never think twice about grabbing the correctly pressure rated XTR+ gun for your Graco sprayer.
Application: Designed to conquer the toughest protective coatings.- Self-locking needle design for faster rebuilds
- XHD RAC tip provides exceptional life, pattern and finish
- Easily remove and clean gun filter with trigger guard integrated wrench
- Insulated handle for sprayer comfort
- Model: XTR5+
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (MPa): 34.5
- Maximum Working Pressure (psi): 5000
$534.00
XTR+ GUN, XTR5+, 1" HND, 4FNG, XHDRAC
GG XTR524
GG XTR524
XTR+ GUN, XTR5+, 1" HND, 4FNG, XHDRAC
Graco XTR524 XTR5+ Airless Spray Gun, Round Handle, 4-Finger Trigger, XHD RAC Tip
New look. New features. A self-locking needle design offers unmatched ease of breaking down for cleaning or rebuilds. Paired with a new look, you&prime, ll never think twice about grabbing the correctly pressure rated XTR+ gun for your Graco sprayer.
Application: Designed to conquer the toughest protective coatings.- Self-locking needle design for faster rebuilds
- XHD RAC tip provides exceptional life, pattern and finish
- Easily remove and clean gun filter with trigger guard integrated wrench
- Model: XTR5+
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (MPa): 34.5
- Maximum Working Pressure (psi): 5000
$534.00
XTR+ GUN, XTR7+, 1" HND, 4FNG, XHDRAC
GG XTR724
GG XTR724
XTR+ GUN, XTR7+, 1" HND, 4FNG, XHDRAC
Graco XTR724 XTR7+ Airless Spray Gun, Round Handle, 4-Finger Trigger, XHD RAC Tip
New look. New features. A self-locking needle design offers unmatched ease of breaking down for cleaning or rebuilds. Paired with a new look, you&prime, ll never think twice about grabbing the correctly pressure rated XTR+ gun for your Graco sprayer.
Application: Designed to conquer the toughest protective coatings.- Self-locking needle design for faster rebuilds
- XHD RAC tip provides exceptional life, pattern and finish
- Easily remove and clean gun filter with trigger guard integrated wrench
- Model: XTR7+
- Maximum Working Pressure (bar): 500
- Maximum Working Pressure (MPa): 50
- Maximum Working Pressure (psi): 7250
$603.00
XTR7+ Airless Spray Gun, Insulated Handle 4-Finger Trigger, XHD RAC Tip
GG XTR712
GG XTR712
XTR+ GUN, XTR7-HF, OVHND, 4FNG, XHDRAC
Graco XTR712 XTR7+ Airless Spray Gun, Insulated Handle, 4-Finger Trigger, XHD RAC Tip
New look. New features. A self-locking needle design offers unmatched ease of breaking down for cleaning or rebuilds. Paired with a new look, you'll never think twice about grabbing the correctly pressure rated XTR+ gun for your Graco sprayer.
Application: Designed to conquer the toughest protective coatings.- Self-locking needle design for faster rebuilds
- XHD RAC tip provides exceptional life, pattern and finish
- Easily remove and clean gun filter with trigger guard integrated wrench
- Insulated handle for sprayer comfort
- Model: XTR7+
Call for pricing
XTR+ GUN, XTR7+, 1" HND, 4FNG, NO TIP
GG XTR720
GG XTR720
XTR+ GUN, XTR7+, 1" HND, 4FNG, NO TIP
XTR7+ Airless Spray Gun, Round Handle, 4-Finger Trigger, No Tip New look. New features. A self-locking needle design offers unmatched ease of breaking down for cleaning or rebuilds. Paired with a new look, you'll never think twice about grabbing the correctly pressure rated XTR+ gun for your Graco sprayer. Designed to conquer the toughest protective coatings. Self-locking needle design for faster rebuilds XHD Tip Guard compatible with XHD RAC tips Easily remove and clean gun filter with trigger guard integrated wrench XTR7+ maximum fluid pressure: 7250psi (500 bar, 50 MPa)
$561.00
XTR+ GUN, XTR7+, OVL HND, 4FNG, XHDRAC
GG XTR722
GG XTR722
XTR+ GUN, XTR7+, OVL HND, 4FNG, XHDRAC
Graco XTR722 XTR7+ Airless Spray Gun, Insulated Handle, 4-Finger Trigger, XHD RAC Tip
New look. New features. A self-locking needle design offers unmatched ease of breaking down for cleaning or rebuilds. Paired with a new look, you&prime, ll never think twice about grabbing the correctly pressure rated XTR+ gun for your Graco sprayer.
Application: Designed to conquer the toughest protective coatings.- Self-locking needle design for faster rebuilds
- XHD RAC tip provides exceptional life, pattern and finish
- Easily remove and clean gun filter with trigger guard integrated wrench
- Insulated handle for sprayer comfort
- Model: XTR7+
- Maximum Working Pressure (bar): 500
- Maximum Working Pressure (MPa): 50
- Maximum Working Pressure (psi): 7250
$603.00
XTR+ GUN, XTR7+, 1" HND, 4FNG, FLT TIP
GG XTR721
GG XTR721
XTR+ GUN, XTR7+, 1" HND, 4FNG, FLT TIP
Graco XTR721 XTR7+ Airless Spray Gun, Round Handle, 4-Finger Trigger, Flat Tip
New look. New features. A self-locking needle design offers unmatched ease of breaking down for cleaning or rebuilds. Paired with a new look, you&prime, ll never think twice about grabbing the correctly pressure rated XTR+ gun for your Graco sprayer.
Application: Designed to conquer the toughest protective coatings.- Self-locking needle design for faster rebuilds
- Flat tip provides exceptional life, pattern and finish
- Easily remove and clean gun filter with trigger guard integrated wrench
- Model: XTR7+
- Maximum Working Pressure (bar): 500
- Maximum Working Pressure (MPa): 50
- Maximum Working Pressure (psi): 7250
Call for pricing
Module, Gca, Gateway, Pn
GG CGMPN0
GG CGMPN0
MODULE, GCA,GATEWAY,PN
Graco CGMPN0 PROFINET Communications Gateway Module
$1,620.00
Module, Gca, Gateway, Ep
GG CGMEP0
GG CGMEP0
MODULE, GCA,GATEWAY,EP
Graco CGMEP0 EtherNet/IP Communications Gateway Module
$1,430.00
CHECK-MATE SUPPLY UNIT, 40:1, 0 VOLT, D60, 20L
GG CM114C
GG CM114C
CHECK-MATE SUPPLY UNIT, 40:1, 0 VOLT, D60, 20L
Graco CM114C 40:1 Ratio 20 L D60 Supply Unit
Graco Supply Systems reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials from pails or drums to metering and dispensing systems.
Application: Bulk unloaders for ambient sealants, adhesives and other medium to high-viscosity materials.- 60 liter (16-gal) pail sizes provides the same proven technologies as the larger systems, but with small NXT Air Motors
- Graco D60 - Provides higher down-force and 60-liter pail capacity
- Industry-first controls give you immediate and important information at the touch of a button
- Platen wipers can be replaced in seconds
- Pump&prime, s quick-disconnect coupler, turnbuckle mount and pump cartridge packings let you service the pump without removing it from the ram
- High-quality, durable parts reduce maintenance time, maximize uptime
- Model: Check-Mate
- Series: D60
- Ambient/Warm Melt/Hot Melt: Ambient
- Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill
- Container Type: Pail
- Control Panel Material: N/A
- Material Container Volume (gal): 5.3
- Material Container Volume (l): 20
- Maximum Air Inlet Pressure (bar): 10.34
- Maximum Air Inlet Pressure (kg/cm²): 10.55
- Maximum Air Inlet Pressure (kPa): 1034
- Maximum Air Inlet Pressure (psi): 150
- Maximum Flow Rate (GPM): 1.6
- Maximum Flow Rate (L/min): 6.1
- Maximum Fluid Pressure (bar): 275.8
- Maximum Fluid Pressure (kPa): 27580
- Maximum Fluid Pressure (psi): 4000
- Maximum Fluid Pressure (bar): 275.8
- Maximum Fluid Pressure (kPa): 27580
- Maximum Fluid Pressure (psi): 4000
- Maximum Height (cm): 226.06
- Maximum Height (ft): 7.42
- Maximum Height (in): 89
- Maximum Height (m): 2.26
- Maximum Height (mm): 2260.6
- Maximum Operating Temperature (°C): 49
- Maximum Operating Temperature (°F): 120
- Maximum Working Pressure (bar): 280
- Maximum Working Pressure (kPa): 28000
- Maximum Working Pressure (MPa): 28
- Maximum Working Pressure (psi): 4000
- Minimum Height (cm): 149.86
- Minimum Height (ft): 4.92
- Minimum Height (in): 59
- Minimum Height (m): 1.5
- Minimum Height (mm): 1498.6
- Overall Depth (cm): 45.72
- Overall Depth (in): 18
- Overall Depth (mm): 457.2
- Overall Width (cm): 71.12
- Overall Width (in): 28
- Overall Width (mm): 711.2
- Power Type: Pneumatic
- Pump Ratio: 40:1
- Pump Type: Priming Piston
- Ram Material: Carbon Steel
Call for pricing
CHECK-MATE SUPPLY UNIT, 40:1, 0 VOLT, S20, 20L
GG CM123G
GG CM123G
CHECK-MATE SUPPLY UNIT, 40:1, 0 VOLT, S20, 20L
Graco CM123G 40:1 Ratio 20 L S20 Supply Unit
Graco Supply Systems reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials from pails or drums to metering and dispensing systems.
Application: Bulk unloaders for ambient sealants, adhesives and other medium to high-viscosity materials.- 20 liter (5 gal) pail sizes provides the same proven technologies as the larger systems, but with small NXT Air Motors
- Graco S20 - For low-volume applications of medium to high-viscosity materials
- Industry-first controls give you immediate and important information at the touch of a button
- Platen wipers can be replaced in seconds
- Pump&prime, s quick-disconnect coupler, turnbuckle mount and pump cartridge packings let you service the pump without removing it from the ram
- High-quality, durable parts reduce maintenance time, maximize uptime
- Model: Check-Mate
- Series: S20
- Ambient/Warm Melt/Hot Melt: Ambient
- Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill
- Container Type: Pail
- Control Panel Material: N/A
- Material Container Volume (gal): 5.3
- Material Container Volume (l): 20
- Maximum Air Inlet Pressure (bar): 8.62
- Maximum Air Inlet Pressure (kg/cm²): 8.79
- Maximum Air Inlet Pressure (kPa): 862
- Maximum Air Inlet Pressure (psi): 125
- Maximum Flow Rate (GPM): 1.6
- Maximum Flow Rate (L/min): 6.1
- Maximum Fluid Pressure (bar): 275.8
- Maximum Fluid Pressure (kPa): 27580
- Maximum Fluid Pressure (psi): 4000
- Maximum Fluid Pressure (bar): 275.8
- Maximum Fluid Pressure (kPa): 27580
- Maximum Fluid Pressure (psi): 4000
- Maximum Height (cm): 150.6
- Maximum Height (ft): 4.94
- Maximum Height (in): 59.3
- Maximum Height (m): 1.51
- Maximum Height (mm): 1506
- Maximum Operating Temperature (°C): 49
- Maximum Operating Temperature (°F): 120
- Maximum Working Pressure (bar): 280
- Maximum Working Pressure (kPa): 28000
- Maximum Working Pressure (MPa): 28
- Maximum Working Pressure (psi): 4000
- Minimum Height (cm): 90.9
- Minimum Height (ft): 2.98
- Minimum Height (in): 35.8
- Minimum Height (m): 0.91
- Minimum Height (mm): 909
- Overall Depth (cm): 48.26
- Overall Depth (in): 19
- Overall Depth (mm): 482.6
- Overall Width (cm): 43.18
- Overall Width (in): 17
- Overall Width (mm): 431.8
- Power Type: Pneumatic
- Pump Ratio: 40:1
- Pump Type: Priming Piston
- Ram Material: Carbon Steel
Call for pricing
CHECK-MATE SUPPLY UNIT, 63:1, 0 V, S20 CART, 20L
GG CM152B
GG CM152B
CHECK-MATE SUPPLY UNIT, 63:1, 0 V, S20 CART, 20L
63:1 Ratio 20 L S20 Cart Mounted Supply UnitGraco Supply Systems reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials from pails or drums to metering and dispensing systems.
Bulk unloaders for ambient sealants, adhesives and other medium to high-viscosity materials. 20 liter (5 gal) pail sizes provides the same proven technologies as the larger systems, but with small NXT Air Motors Graco S20c - Same as the S20, but includes a cart Industry-first controls give you immediate and important information at the touch of a button Quick placement of pail Platen wipers can be replaced in seconds Pump's quick-disconnect coupler, turnbuckle mount and pump cartridge packings let you service the pump without removing it from the ram High-quality, durable parts reduce maintenance time, maximize uptime
$15,970.00
Sensor, Temperature
GG C32255
GG C32255
SENSOR, TEMPERATURE
Graco C32255 RTD Sensor Helical Gear Meter
$401.00
