GRACO INC. S10595

GG SA906002

GG SA920K

GG SA925K

GG SA914004

GG SA908005

GG SA920002

GG SDL2DB

SDX SERIES 10 REEL, HOSE

Graco SDL2DB SDX 10, Air/Water/Antifreeze/WWS, 3/8 in (10 mm) Inlet, Bare Reel (3/8 in X 50 ft (10 mm X 15 m) Capacity), NPT, Overhead Mount, Metallic Blue

Choose Graco's flagship SDX hose reels for high-quality performance and versatility. Built using specially crafted components, including a rigid metal frame and low-friction swivels, it's available in five colors

• Includes a stainless-steel swivel shaft for extended service life when transporting air, water, antifreeze, windshield wash solvent and other fluids.
• Low-Friction Cartridge Swivel - Provides smooth reel performance with an easy-to-replace swivel cartridge, simplifying repairs.
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (10.7-19.8 meters) hose (NPT air/water) capacity for a wide variety of applications
• Durable Finish - Baked-on enamel finish protects reel from corrosion

• Model: SDX
• Series: 10

• Application: Air, Water

• Bare Reel: 1

• Color: Metallic Blue

• Frame Type: Single Pedestal

• Hose Inside Diameter (in): 3/8
• Hose Inside Diameter (mm): 9.525
• Hose Length (ft): 50
• Hose Length (m): 15

• Hose Reel Type: Bare Reel
• Includes Hose: No
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Female
• Inlet Thread Type: NPSM

• Maximum Temperature ( degree C): 87
• Maximum Temperature ( degree F): 190

• Maximum Working Pressure (psi): 300

• Minimum Temperature ( degree C): -28
• Minimum Temperature ( degree F): -20

• Mount Location: Overhead Mount

• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPT

• Overall Height (in): 19.5
• Overall Height (mm): 498
• Overall Length (in): 17.1
• Overall Length (mm): 435
• Overall Width (in): 7
• Overall Width (mm): 177

• Recommended Environment: Indoor, Limited Outdoor
• Recommended Fluid Type: Air, Water, Antifreeze, WWS

GG SDM33B

SDX SERIES 10 REEL, HOSE

Graco SDM33B SDX 10, Oil, 1/2 in (13 mm) Inlet, 1/2 in X 35 ft (13 mm X 11 m) Hose, NPT, Overhead Mount, Metallic Blue

Choose Graco's flagship SDX hose reels for high-quality performance and versatility. Built using specially crafted components, including a rigid metal frame and low-friction swivels, it's available in five colors

• Low-Friction Cartridge Swivel - Provides smooth reel performance with an easy-to-replace swivel cartridge, simplifying repairs.
• Increased Spring Power - Every SDX oil hose reel recoils to the exact same assigned length for a clean, uniform look.
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (10.7-19.8 meters) hose (NPT air/water) capacity for a wide variety of applications
• Durable Finish - Baked-on enamel finish protects reel from corrosion

• Model: SDX
• Series: 10

• Application: Oil

• Color: Metallic Blue

• Frame Type: Single Pedestal

• Hose Inside Diameter (in): 1/2
• Hose Inside Diameter (mm): 12.7
• Hose Length (ft): 35
• Hose Length (m): 11

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Male
• Inlet Thread Type: NPSM

• Maximum Temperature ( degree C): 87
• Maximum Temperature ( degree F): 190

• Maximum Working Pressure (psi): 2000

• Minimum Temperature ( degree C): -28
• Minimum Temperature ( degree F): -20

• Mount Location: Overhead Mount

• Outlet Size (in): 1/2
• Outlet Size (mm): 12.7
• Outlet Thread Gender: Male
• Outlet Thread Type: NPT

• Overall Height (in): 19.5
• Overall Height (mm): 498
• Overall Length (in): 17.1
• Overall Length (mm): 435
• Overall Width (in): 7
• Overall Width (mm): 177

• Recommended Environment: Indoor, Limited Outdoor
• Recommended Fluid Type: Oil

GG SA925-1A

GG R5A160

APPLICATOR, BELL, 50MM, 1.5

Graco R5A160 ProBell Applicator, Standard, Solvent borne, 50 mm bell cup, 1.5 mm nozzle

Combining rotary bell atomization with electrostatic technology is proven to provide up to 95 percent transfer efficiency. This ProBell rotary atomizer fits on a solid wrist robot, reciprocator or fixed mount.

• System integration uses existing PLC (programmable logic controller) or new installation.
• Coiled fluid tube controls electrostatic resistivity for a wide range of material.
• Aluminum bell cup with serrated edge has equally spaced axial grooves that act as channels for paint flow, producing uniform particles. This makes it ideal for atomizing difficult material like clear coats.

• Model: ProBell

• Applicator Type: Automatic

• Bell Cup Edge Type: Serrated
• Bell Cup Material: Aluminum Standard
• Bell Cup Size (cm): 5
• Bell Cup Size (in): 2.0
• Bell Cup Size (mm): 50

• Compatible Paint Type: Solvent borne

• For Use With: Standard Bell Systems

• Gun Activation: Automatic
• Gun Model: Solvent borne
• Gun Mount: Standard
• Gun Type: Rotary Applicator

• Maximum Air Pressure (bar): 7.0

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Current Draw (µA): 150

• Maximum Fluid Pressure (bar): 10.3
• Maximum Fluid Pressure (kPa): 1030
• Maximum Fluid Pressure (MPa): 1.03
• Maximum Fluid Pressure (psi): 150

• Maximum Fluid Pressure (bar): 10.3
• Maximum Fluid Pressure (kPa): 1030
• Maximum Fluid Pressure (MPa): 1.03
• Maximum Fluid Pressure (psi): 150

• Maximum Turbine Speed (RPM): 60000
• Maximum Viscosity (cSt): 150

• Maximum Working Pressure (bar): 10.3
• Maximum Working Pressure (kPa): 1030
• Maximum Working Pressure (MPa): 1
• Maximum Working Pressure (psi): 150

• Minimum Bearing Air Pressure (bar): 5
• Minimum Bearing Air Pressure (MPa): 0.5
• Minimum Bearing Air Pressure (psi): 70

• Minimum Viscosity (cSt): 30

• Nozzle Size (cm): 0.15
• Nozzle Size (in): 0.059
• Nozzle Size (mm): 1.5

• Output Voltage (kV): 100

GG SDM65B

SDX SERIES 20 REEL, HOSE

Graco SDM65B SDX 20, Oil, 1/2 in (13 mm) Inlet, 1/2 in X 50 ft (13 mm X 15 m) Hose, NPT, Overhead Mount, Metallic Blue

Choose Graco's flagship SDX hose reels for high-quality performance and versatility. Built using specially crafted components, including a rigid metal frame and low-friction swivels, it's available in five colors

• Low-Friction Cartridge Swivel - Provides smooth reel performance with an easy-to-replace swivel cartridge, simplifying repairs.
• Increased Spring Power - Every SDX oil hose reel recoils to the exact same assigned length for a clean, uniform look.
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (10.7-19.8 meters) hose (NPT air/water) capacity for a wide variety of applications
• Durable Finish - Baked-on enamel finish protects reel from corrosion

• Model: SDX
• Series: 20

• Application: Oil

• Color: Metallic Blue

• Frame Type: Single Pedestal

• Hose Inside Diameter (in): 1/2
• Hose Inside Diameter (mm): 12.7
• Hose Length (ft): 50
• Hose Length (m): 15

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Male
• Inlet Thread Type: NPSM

• Maximum Temperature ( degree C): 87
• Maximum Temperature ( degree F): 190

• Maximum Working Pressure (psi): 2000

• Minimum Temperature ( degree C): -28
• Minimum Temperature ( degree F): -20

• Mount Location: Overhead Mount

• Outlet Size (in): 1/2
• Outlet Size (mm): 12.7
• Outlet Thread Gender: Male
• Outlet Thread Type: NPT

• Overall Height (in): 21.8
• Overall Height (mm): 554
• Overall Length (in): 19.2
• Overall Length (mm): 487
• Overall Width (in): 7
• Overall Width (mm): 177

• Recommended Environment: Indoor, Limited Outdoor
• Recommended Fluid Type: Oil

GG SDU.A02AAA2AA0C21

SANIFORCE DRUM UNLOADER SYSTEM, RAM, HYGIENIC

Graco SDU.A02AAA2AA0C21 SaniForce Ram Unit, SST Frame, 5:1 PP, Inflatable Seal, Enclosed Pneumatic Controls

SaniForce Drum Unloader systems are built to handle your thickest, toughest food, personal care, and pharmaceutical ingredient transfer. With up to 99% evacuation rates the SaniForce systems reduce product waste while providing a solution to transfer products up to 2,000,000 cps utilizing sanitary designed high pressure piston pumps. Ram systems increase food safety by creating a sealed system with the container and improve worker ergonomics by preventing injury due to manual scooping and dumping of containers and ingredients. The inflatable seal system it is flexible enough to accomodate multiple drum shapes and sizes. With multiple pump, control, plate, and frame options the systems are configurable to match requirements of most users applications.

• Reduce material waste with up to 99% material evacuation
• Improve worker ergonomics by eliminating hazards associated with scooping and dumping options
• Improve food safety by creating a sealed system with the container and inflatable seal design - eliminates food contamination from air borne or worker contaminates
• Electronic controls for system automation of container evacuation and precise batch control with use of scale or flow meter
• Configurable systems to meet requirements of almost any ingredient unloading application

• Model: SaniForce 2.0 Drum Unloader
• Series: A

• Ambient/Warm Melt/Hot Melt: 90
• Application: Food, Personal Care

• Compatible Drum Height (cm): 101.6
• Compatible Drum Height (in): 40
• Compatible Drum Height (mm): 1016
• Compatible Drum Inside Diameter (cm): 54.6-59.0
• Compatible Drum Inside Diameter (in): 21.5-23.25
• Compatible Drum Inside Diameter (mm): 546-590

• Container Type: Drum
• Control Panel Material: Stainless Steel
• Control Panel Type: Enclosed

• Finish/Coating: Bead Blast

• Frame Material: Stainless Steel

• Material Container Volume (gal): 55
• Material Container Volume (l): 208

• Maximum Air Inlet Pressure (bar): 6.89
• Maximum Air Inlet Pressure (kg/cm 2): 7.03
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (GPM): 13
• Maximum Flow Rate (L/min): 49.2

• Maximum Fluid Pressure (bar): 28.7
• Maximum Fluid Pressure (kPa): 2870
• Maximum Fluid Pressure (psi): 410

• Maximum Fluid Pressure (bar): 28.7
• Maximum Fluid Pressure (kPa): 2870
• Maximum Fluid Pressure (psi): 410

• Maximum Height (cm): 295
• Maximum Height (ft): 9.7
• Maximum Height (in): 116
• Maximum Height (m): 2.95
• Maximum Height (mm): 2946

• Maximum Operating Temperature ( degree C): 32
• Maximum Operating Temperature ( degree F): 90

• Maximum Working Pressure (bar): 28.7
• Maximum Working Pressure (kPa): 2870
• Maximum Working Pressure (MPa): 2.9
• Maximum Working Pressure (psi): 410

• Minimum Height (cm): 194
• Minimum Height (ft): 6.4
• Minimum Height (in): 76.2
• Minimum Height (m): 1.94
• Minimum Height (mm): 1935

• Overall Depth

GG SDL65F

SDX SERIES 20 REEL, HOSE

Graco SDL65F SDX 20, Air/Water/Antifreeze/WWS, 1/2 in (13 mm) Inlet, 1/2 in X 50 ft (13 mm X 15 m) Hose, NPT, Overhead Mount, Yellow

Choose Graco's flagship SDX hose reels for high-quality performance and versatility. Built using specially crafted components, including a rigid metal frame and low-friction swivels, it's available in five colors

• Includes a stainless-steel swivel shaft for extended service life when transporting air, water, antifreeze, windshield wash solvent and other fluids.
• Low-Friction Cartridge Swivel - Provides smooth reel performance with an easy-to-replace swivel cartridge, simplifying repairs.
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (10.7-19.8 meters) hose (NPT air/water) capacity for a wide variety of applications
• Durable Finish - Baked-on enamel finish protects reel from corrosion

• Model: SDX
• Series: 20

• Application: Air, Water, Antifreeze, WWS

• Color: Yellow

• Frame Type: Single Pedestal

• Hose Inside Diameter (in): 1/2
• Hose Inside Diameter (mm): 12.7
• Hose Length (ft): 50
• Hose Length (m): 15

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Male
• Inlet Thread Type: NPSM

• Maximum Temperature ( degree C): 87
• Maximum Temperature ( degree F): 190

• Maximum Working Pressure (psi): 300

• Minimum Temperature ( degree C): -28
• Minimum Temperature ( degree F): -20

• Mount Location: Overhead Mount

• Outlet Size (in): 1/2
• Outlet Size (mm): 12.7
• Outlet Thread Gender: Male
• Outlet Thread Type: NPT

• Overall Height (in): 21.8
• Overall Height (mm): 554
• Overall Length (in): 19.2
• Overall Length (mm): 487
• Overall Width (in): 7
• Overall Width (mm): 177

• Recommended Environment: Indoor, Limited Outdoor
• Recommended Fluid Type: Air, Water, Antifreeze, WWS

GG SDU.A02AAA2AE0C21

SANIFORCE DRUM UNLOADER SYSTEM, RAM, HYGIENIC

Graco SDU.A02AAA2AE0C21 SaniForce Ram Unit, SST Frame, 5:1 PP, Inflatable Seal, Enclosed Pneumatic Controls

SaniForce Drum Unloader systems are built to handle your thickest, toughest food, personal care, and pharmaceutical ingredient transfer. With up to 99% evacuation rates the SaniForce systems reduce product waste while providing a solution to transfer products up to 2,000,000 cps utilizing sanitary designed high pressure piston pumps. Ram systems increase food safety by creating a sealed system with the container and improve worker ergonomics by preventing injury due to manual scooping and dumping of containers and ingredients. The inflatable seal system it is flexible enough to accomodate multiple drum shapes and sizes. With multiple pump, control, plate, and frame options the systems are configurable to match requirements of most users applications.

• Reduce material waste with up to 99% material evacuation
• Improve worker ergonomics by eliminating hazards associated with scooping and dumping options
• Improve food safety by creating a sealed system with the container and inflatable seal design - eliminates food contamination from air borne or worker contaminates
• Electronic controls for system automation of container evacuation and precise batch control with use of scale or flow meter
• Configurable systems to meet requirements of almost any ingredient unloading application

• Model: SaniForce 2.0 Drum Unloader
• Series: A

• Ambient/Warm Melt/Hot Melt: 90
• Application: Food, Personal Care

• Compatible Drum Height (cm): 101.6
• Compatible Drum Height (in): 40
• Compatible Drum Height (mm): 1016
• Compatible Drum Inside Diameter (cm): 54.6-59.0
• Compatible Drum Inside Diameter (in): 21.5-23.25
• Compatible Drum Inside Diameter (mm): 546-590

• Container Type: Drum
• Control Panel Material: Stainless Steel
• Control Panel Type: Enclosed

• Finish/Coating: Bead Blast

• Frame Material: Stainless Steel

• Includes: Stainless Steel Ram Piston Rods

• Material Container Volume (gal): 55
• Material Container Volume (l): 208

• Maximum Air Inlet Pressure (bar): 6.89
• Maximum Air Inlet Pressure (kg/cm 2): 7.03
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (GPM): 13
• Maximum Flow Rate (L/min): 49.2

• Maximum Fluid Pressure (bar): 28.7
• Maximum Fluid Pressure (kPa): 2870
• Maximum Fluid Pressure (psi): 410

• Maximum Fluid Pressure (bar): 28.7
• Maximum Fluid Pressure (kPa): 2870
• Maximum Fluid Pressure (psi): 410

• Maximum Height (cm): 295
• Maximum Height (ft): 9.7
• Maximum Height (in): 116
• Maximum Height (m): 2.95
• Maximum Height (mm): 2946

• Maximum Operating Temperature ( degree C): 32
• Maximum Operating Temperature ( degree F): 90

• Maximum Working Pressure (bar): 28.7
• Maximum Working Pressure (kPa): 2870
• Maximum Working Pressure (MPa): 2.9
• Maximum Working Pressure (psi): 410

• Minimum Height (cm): 194
• Minimum Height (ft): 6.4
• Minimum Height (in): 76.2
• Minimum Height (m): 1.94

GG SDM6HB

SDX SERIES 20 REEL, HOSE

Graco SDM6HB SDX 20, Oil, 1/2 in (13 mm) Inlet, 1/2 in X 50 ft (13 mm X 15 m) Hose, NPT, Tank/Bench Mount, Metallic Blue

Choose Graco's flagship SDX hose reels for high-quality performance and versatility. Built using specially crafted components, including a rigid metal frame and low-friction swivels, it's available in five colors

• Low-Friction Cartridge Swivel - Provides smooth reel performance with an easy-to-replace swivel cartridge, simplifying repairs.
• Increased Spring Power - Every SDX oil hose reel recoils to the exact same assigned length for a clean, uniform look.
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (10.7-19.8 meters) hose (NPT air/water) capacity for a wide variety of applications
• Durable Finish - Baked-on enamel finish protects reel from corrosion

• Model: SDX
• Series: 20

• Application: Oil

• Color: Metallic Blue

• Frame Type: Single Pedestal

• Hose Inside Diameter (in): 1/2
• Hose Inside Diameter (mm): 12.7
• Hose Length (ft): 50
• Hose Length (m): 15

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Male
• Inlet Thread Type: NPSM

• Maximum Temperature ( degree C): 87
• Maximum Temperature ( degree F): 190

• Maximum Working Pressure (psi): 2000

• Minimum Temperature ( degree C): -28
• Minimum Temperature ( degree F): -20

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 1/2
• Outlet Size (mm): 12.7
• Outlet Thread Gender: Male
• Outlet Thread Type: NPT

• Overall Height (in): 21.8
• Overall Height (mm): 554
• Overall Length (in): 19.2
• Overall Length (mm): 487
• Overall Width (in): 7
• Overall Width (mm): 177

• Recommended Environment: Indoor, Limited Outdoor
• Recommended Fluid Type: Oil

GG SDL65D

SDX SERIES 20 REEL, HOSE

Graco SDL65D SDX 20, Air/Water/Antifreeze/WWS, 1/2 in (13 mm) Inlet, 1/2 in X 50 ft (13 mm X 15 m) Hose, NPT, Overhead Mount, Black

Choose Graco's flagship SDX hose reels for high-quality performance and versatility. Built using specially crafted components, including a rigid metal frame and low-friction swivels, it's available in five colors

• Includes a stainless-steel swivel shaft for extended service life when transporting air, water, antifreeze, windshield wash solvent and other fluids.
• Low-Friction Cartridge Swivel - Provides smooth reel performance with an easy-to-replace swivel cartridge, simplifying repairs.
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (10.7-19.8 meters) hose (NPT air/water) capacity for a wide variety of applications
• Durable Finish - Baked-on enamel finish protects reel from corrosion

• Model: SDX
• Series: 20

• Application: Air, Water, Antifreeze, WWS

• Color: Black

• Frame Type: Single Pedestal

• Hose Inside Diameter (in): 1/2
• Hose Inside Diameter (mm): 12.7
• Hose Length (ft): 50
• Hose Length (m): 15

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Male
• Inlet Thread Type: NPSM

• Maximum Temperature ( degree C): 87
• Maximum Temperature ( degree F): 190

• Maximum Working Pressure (psi): 300

• Minimum Temperature ( degree C): -28
• Minimum Temperature ( degree F): -20

• Mount Location: Overhead Mount

• Outlet Size (in): 1/2
• Outlet Size (mm): 12.7
• Outlet Thread Gender: Male
• Outlet Thread Type: NPT

• Overall Height (in): 21.8
• Overall Height (mm): 554
• Overall Length (in): 19.2
• Overall Length (mm): 487
• Overall Width (in): 7
• Overall Width (mm): 177

• Recommended Environment: Indoor, Limited Outdoor
• Recommended Fluid Type: Air, Water, Antifreeze, WWS

GG SG225001

GG SDU.A02AAA3AE0C21

SANIFORCE DRUM UNLOADER SYSTEM, RAM, HYGIENIC

Graco SDU.A02AAA3AE0C21 SaniForce Ram Unit, SST Frame, 5:1 PP, Inflatable Seal, Electronic Controls

SaniForce Drum Unloader systems are built to handle your thickest, toughest food, personal care, and pharmaceutical ingredient transfer. With up to 99% evacuation rates the SaniForce systems reduce product waste while providing a solution to transfer products up to 2,000,000 cps utilizing sanitary designed high pressure piston pumps. Ram systems increase food safety by creating a sealed system with the container and improve worker ergonomics by preventing injury due to manual scooping and dumping of containers and ingredients. The inflatable seal system it is flexible enough to accomodate multiple drum shapes and sizes. With multiple pump, control, plate, and frame options the systems are configurable to match requirements of most users applications.

• Reduce material waste with up to 99% material evacuation
• Improve worker ergonomics by eliminating hazards associated with scooping and dumping options
• Improve food safety by creating a sealed system with the container and inflatable seal design - eliminates food contamination from air borne or worker contaminates
• Electronic controls for system automation of container evacuation and precise batch control with use of scale or flow meter
• Configurable systems to meet requirements of almost any ingredient unloading application

• Model: SaniForce 2.0 Drum Unloader
• Series: A

• Ambient/Warm Melt/Hot Melt: 90
• Application: Food, Personal Care

• Compatible Drum Height (cm): 101.6
• Compatible Drum Height (in): 40
• Compatible Drum Height (mm): 1016
• Compatible Drum Inside Diameter (cm): 54.6-59.0
• Compatible Drum Inside Diameter (in): 21.5-23.25
• Compatible Drum Inside Diameter (mm): 546-590

• Container Type: Drum
• Control Panel Material: Stainless Steel
• Control Panel Type: Enclosed

• Finish/Coating: Bead Blast

• Frame Material: Stainless Steel

• Includes: Stainless Steel Ram Piston Rods

• Material Container Volume (gal): 55
• Material Container Volume (l): 208

• Maximum Air Inlet Pressure (bar): 6.89
• Maximum Air Inlet Pressure (kg/cm 2): 7.03
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (GPM): 13
• Maximum Flow Rate (L/min): 49.2

• Maximum Fluid Pressure (bar): 28.7
• Maximum Fluid Pressure (kPa): 2870
• Maximum Fluid Pressure (psi): 410

• Maximum Fluid Pressure (bar): 28.7
• Maximum Fluid Pressure (kPa): 2870
• Maximum Fluid Pressure (psi): 410

• Maximum Height (cm): 295
• Maximum Height (ft): 9.7
• Maximum Height (in): 116
• Maximum Height (m): 2.95
• Maximum Height (mm): 2946

• Maximum Operating Temperature ( degree C): 32
• Maximum Operating Temperature ( degree F): 90

• Maximum Working Pressure (bar): 28.7
• Maximum Working Pressure (kPa): 2870
• Maximum Working Pressure (MPa): 2.9
• Maximum Working Pressure (psi): 410

• Minimum Height (cm): 194
• Minimum Height (ft): 6.4
• Minimum Height (in): 76.2
• Minimum Height (m): 1.94
• Minimu

GG SG263-1A

GG SK553

GG SM314001

GG SM313003

GG SM321001

GG SN712009

GG SN713005

GG SN713006

GG SN713007

GG SN713-1A-078-669

GG SN751-1A

LSR INJECTOR,ASSY,COLOR

GG SP15.0103

SANIFORCE AODD PUMP, 15903A.PS02ASSASSPTEOEP21

Graco SP15.0103 SaniForce 2.0 3A Series Pneumatic Diaphragm Pump, 1590, S02A, SSA, SS, FK, E, C21

SaniForce pneumatic diaphragm pumps are designed to meet requirements for the most rigorous food, beverage, personal care, and pharmaceutical transfer applications. SaniForce AODD pumps reduce the amount of tri-clamps and gaskets utilized in the fluid path creating a pump that is easier to sanitize and clean as well as quicker and easier to disassemble and maintain. Handle solids up to 3.8 inches in diameter and allow for vertical and horizontal pump installation. 316L stainless steel fluid section and multiple elastomer options provide flexibility to handle almost any material and cleaning chemical. Elastomer options for high temperature fluids or steam cleaning options.

• Flow rates up to 150 gpm (567 lpm) and pressure up to 125 psi (8.6 bar)
• Handle solids up to 3.8(96.5 mm) in diameter
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design.
• Multiple approval and certification options: 3A, ATEX, USP Class VI, CE, 3.1 certification
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• Multiple internal elastomers to be compatible with you material and cleaning chemicals
• Tri-clamp and sanitary DIN connections available

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: PTFE

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Connection Type: Tri-Clamp

• Diaphragm Compatible Material: EPDM
• Diaphragm Material: EPDM Overmolded

• Fluid Inlet Size (cm): 3.8
• Fluid Inlet Size (in): 1-1/2
• Fluid Inlet Size (mm): 38.1

• Fluid Outlet Size (cm): 3.81
• Fluid Outlet Size (in): 1-1/2
• Fluid Outlet Size (mm): 38.1
• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material Certification: EN 1024:2004 Type 2.1 (Standard)

• Maximum Air Consumption (SCFM): 150
• Maximum Air Pressure (bar): 6.9

• Maximum Air Pressure (kPa): 690
• Maximum Air Pressure (MPa): 0.689
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 165

• Maximum Flow Rate (GPM): 90
• Maximum Flow Rate (L/min): 341

• Maximum Fluid Pressure (bar): 8.27
• Maximum Fluid Pressure (kPa): 827
• Maximum Fluid Pressure (MPa): 0.827
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Pressure (bar): 8.27
• Maximum Fluid Pressure (kPa): 827
• Maximum Fluid Pressure (MPa): 0.827
• Maximum Fluid Pressure (psi): 120

• Maximum Operating Temperature ( degree C): 135
• Maximum Operating Temperature ( degree F): 275

• Maximum Solid Size (cm): 1.27
• Maximum Solid Size (in): 0.5
• Maximum Solid Size (mm): 12.7

• Minimum Operating Tempe

GG SN751K

GG SSP-119

GG SP415007

GG SSP-120

GG SP415010

GG SSP-133

GG SSP-122

GG SSP-159

GG SSP-114

GG SSP-161

GG SSP-164

GG SSP-163

GG SSP-162

GG SSP-165

GG SSP-166

GG TC228R

GG TC397J

CHECK-MATE TANDEM SUPPLY UNIT,55:1,PXOVER,3.0,200L

GG TC3B4L

CHECK-MATE SUPPLY UNIT,TNDM,55:1,EXOVER,3.0,200L

GG TDEL8R

DURA-FLO TANDEM SUPPLY UNIT, 47:1, PXOVER, 6.5, 200L

Graco TDEL8R 47:1 Ratio 200 L 6.5 RAM Tandem Supply Unit

Graco Supply Systems reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials from pails or drums to metering and dispensing systems.

• For large drums up to 200 liter (55 gal)
• Graco D200s - For heavy-duty, high-volume applications of high-viscosity materials. Provides more down-force for difficult-to-move materials
• Industry-first controls give you immediate and important information at the touch of a button
• Platen wipers can be replaced in seconds
• Pumps quick-disconnect coupler, turnbuckle mount and pump cartridge packings let you service the pump without removing it from the ram
• High-quality, durable parts reduce maintenance time, maximize uptime

• Model: Dura-Flo

• Ambient/Warm Melt/Hot Melt: Ambient
• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill

• Container Type: Drum

• Material Container Volume (gal): 52.8
• Material Container Volume (l): 200

• Maximum Air Inlet Pressure (bar): 8.62
• Maximum Air Inlet Pressure (kg/cm 2): 8.79
• Maximum Air Inlet Pressure (kPa): 862
• Maximum Air Inlet Pressure (psi): 125

• Maximum Flow Rate (GPM): 6.9
• Maximum Flow Rate (L/min): 26.1

• Maximum Fluid Pressure (bar): 324.1
• Maximum Fluid Pressure (kPa): 32410
• Maximum Fluid Pressure (psi): 4700

• Maximum Fluid Pressure (bar): 324.1
• Maximum Fluid Pressure (kPa): 32410
• Maximum Fluid Pressure (psi): 4700

• Maximum Operating Temperature ( degree C): 49
• Maximum Operating Temperature ( degree F): 120

• Power Type: Pneumatic

• Pump Ratio: 47:1
• Pump Type: Double Ball

• Ram Material: Carbon Steel

GG TE120-0001

QUANTM PUMP, QTE-ALFC1SPSPSPPTA100

Graco TE120-0001 QUANTM i120, 2" NPT, Aluminum Electric Diaphragm Pump, 200-240 V, AL Center, SP Seat, SP Ball, SP Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design

  Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature

  Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump

  Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback

  Quiet operation reduces plant noise and improves employee safety and health

  Smart pump control provides more accurate flow set points and built-in I/O

• Efficient Electric Motor Powder-coated aluminum electric drive240 VAC 3 motor with 15 ft cord and NEMA L15-20 plugNon-hazardous
• Materials of Construction Aluminum fluid section with NPT end portInternal components include Santoprene seat, Santoprene ball, Santoprene diaphragm and PTFE manifold o-ring

• Model: QUANTM
• Series: i120

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: Santoprene

• Center Section Material: Aluminum

• Connection Type: NPT

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: Santoprene

• Fluid Inlet Size (in): 2
• Fluid Inlet Size (mm): 51
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 2
• Fluid Outlet Size (mm): 50.8
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section: Aluminum, End Port, NPT
• Fluid Section Material: Aluminum

• Hazardous Location Approval: None

• Manifold Configuration: End Port
• Manifold O-Ring Material: <

GG TE120-0032

QUANTM PUMP, QTE-ALFC1SSPTPOPTA100

Graco TE120-0032 QUANTM i120, 2" NPT, Aluminum Electric Diaphragm Pump, 200-240 V, AL Center, SS Seat, PT Ball, PO Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design

  Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature

  Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump

  Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback

  Quiet operation reduces plant noise and improves employee safety and health

  Smart pump control provides more accurate flow set points and built-in I/O

• Efficient Electric Motor Powder-coated aluminum electric drive240 VAC 3 phase motor with 15 ft cord and NEMA L15-20 plugNon-hazardous
• Materials of Construction Aluminum fluid section with NPT end portInternal components include 316 stainless steel seat, PTFE ball, PTFE Overmold diaphragm and PTFE manifold o-ring

• Model: QUANTM
• Series: i120

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: PTFE

• Center Section Material: Aluminum

• Connection Type: NPT

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: PTFE Overmold

• Fluid Inlet Size (in): 2
• Fluid Inlet Size (mm): 51
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 2
• Fluid Outlet Size (mm): 50.8
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section: Aluminum, End Port, NPT
• Fluid Section Material: Aluminum

• Hazardous Location Approval: None

• Manifold Configuration: End Port
• Manifold O-Ring Ma

GG TE120-0014

QUANTM PUMP, QTE-PPFC1PPSPSPPTP200

Graco TE120-0014 QUANTM i120, 2" Flange, Polypropylene Electric Diaphragm Pump, 200-240 V, AL Center, PP Seat, SP Ball, SP Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design

  Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature

  Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump

  Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback

  Quiet operation reduces plant noise and improves employee safety and health

  Smart pump control provides more accurate flow set points and built-in I/O

• Efficient Electric Motor Powder-coated aluminum electric drive240 VAC 3 phase motor with 15 ft cord and NEMA L15-20 plugNon-hazardous
• Materials of Construction Polypropylene fluid section with end flangeInternal components include polypropylene seat, Santoprene ball, Santoprene diaphragm and PTFE manifold o-ring

• Model: QUANTM
• Series: i120

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: Santoprene

• Center Section Material: Aluminum

• Connection Type: Flange

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: Santoprene

• Fluid Inlet Size (in): 2
• Fluid Inlet Size (mm): 51
• Fluid Inlet Thread Gender: Flange
• Fluid Inlet Thread Type: Flange

• Fluid Outlet Size (in): 2
• Fluid Outlet Size (mm): 50.8
• Fluid Outlet Thread Gender: Flange
• Fluid Outlet Thread Type: Flange
• Fluid Section: Polypropylene, End Flange
• Fluid Section Material: Polypropylene

• Hazardous Location Approval: None

• Manifold Configuration: End Flange
• Manifold O-Ring Material: PTFE

• Maximum A

GG TE120-0037

QUANTM PUMP, QTE-ALFC1SASDPSPTA100

Graco TE120-0037 QUANTM i120, 2" NPT, Aluminum Electric Diaphragm Pump, 200-240 V, AL Center, SA Seat, SD Ball, PS Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design

  Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature

  Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump

  Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback

  Quiet operation reduces plant noise and improves employee safety and health

  Smart pump control provides more accurate flow set points and built-in I/O

• Efficient Electric Motor Powder-coated aluminum electric drive240 VAC 3 phase motor with 15 ft cord and NEMA L15-20 plugNon-hazardous
• Materials of Construction Aluminum fluid section with NPT end portInternal components include PTFE seat, 440C stainless steel ball, PTFE/Santoprene 2-piece diaphragm and PTFE manifold o-ring

• Model: QUANTM
• Series: i120

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: 440C Stainless Steel

• Center Section Material: Aluminum

• Connection Type: NPT

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: PTFE/Santoprene 2-Piece

• Fluid Inlet Size (in): 2
• Fluid Inlet Size (mm): 51
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 2
• Fluid Outlet Size (mm): 50.8
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section: Aluminum, End Port, NPT
• Fluid Section Material: Aluminum

• Hazardous Location Approval: None

• Manifold Configuration: E

GG TE120-0007

QUANTM PUMP, QTE-ALFC1BNBNBN-A100

Graco TE120-0007 QUANTM i120, 2" NPT, Aluminum Electric Diaphragm Pump, 200-240 V, AL Center, BN Seat, BN Ball, BN Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design

  Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature

  Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump

  Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback

  Quiet operation reduces plant noise and improves employee safety and health

  Smart pump control provides more accurate flow set points and built-in I/O

• Efficient Electric Motor Powder-coated aluminum electric drive240 VAC 3 phase motor with 15 ft cord and NEMA L15-20 plugNon-hazardous
• Materials of Construction Aluminum fluid section with NPT end portInternal components include Buna-N seat, Buna-N ball, Buna-N diaphragm and Buna-N manifold o-ring

• Model: QUANTM
• Series: i120

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: Buna-N

• Center Section Material: Aluminum

• Connection Type: NPT

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: Buna-N

• Fluid Inlet Size (in): 2
• Fluid Inlet Size (mm): 51
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 2
• Fluid Outlet Size (mm): 50.8
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section: Aluminum, End Port, NPT
• Fluid Section Material: Aluminum

• Hazardous Location Approval: None

• Manifold Configuration: End Port
• Manifold O-Ring Material: Buna-N

GG TE30-0020

QUANTM QUANTM PUMP, QTC-ALFC5SSPTPOPTA100

Graco TE30-0020 QUANTM i30, 1" NPT, Aluminum Electric Diaphragm Pump, 120 VAC 1Ph, AL Center, SS Seat, PT Ball, PO Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design

  Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature

  Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump

  Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback

  Quiet operation reduces plant noise and improves employee safety and health

  Smart pump control provides more accurate flow set points and built-in I/O

• Efficient Electric Motor Powder-coated aluminum electric drive 120 VAC motor with 15 ft cord and NEMA 5-15 plugNon-hazardous
• Materials of Construction Aluminum fluid section with NPT end portInternal components include 316 stainless steel seat, PTFE ball, PTFE overmold diaphragm and PTFE manifold o-ring

• Model: QUANTM
• Series: i30

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: PTFE

• Center Section Material: Aluminum

• Connection Type: NPT

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: PTFE Overmold

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section: Aluminum, End Port, NPT
• Fluid Section Material: Aluminum

• Hazardous Location Approval: None

• Manifold Configuration: End Port
• Manifold O-Ring Mate

GG TE120-0026

QUANTM PUMP, QTE-ALFC1SSSDPSPTA100

Graco TE120-0026 QUANTM i120, 2" NPT, Aluminum Electric Diaphragm Pump, 200-240 V, AL Center, SS Seat, SD Ball, PS Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design

  Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature

  Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump

  Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback

  Quiet operation reduces plant noise and improves employee safety and health

  Smart pump control provides more accurate flow set points and built-in I/O

• Efficient Electric Motor Powder-coated aluminum electric drive240 VAC 3 phase motor with 15 ft cord and NEMA L15-20 plugNon-hazardous
• Materials of Construction Aluminum fluid section with NPT end portInternal components include 316 stainless steel seat, 440C stainless steel ball, PTFE/Santoprene 2-piece diaphragm and PTFE manifold o-ring

• Model: QUANTM
• Series: i120

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: 440C Stainless Steel

• Center Section Material: Aluminum

• Connection Type: NPT

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: PTFE/Santoprene 2-Piece

• Fluid Inlet Size (in): 2
• Fluid Inlet Size (mm): 51
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 2
• Fluid Outlet Size (mm): 50.8
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section: Aluminum, End Port, NPT
• Fluid Section Material: Aluminum

• Hazardous Location Approval: None

• Manifold Confi

GG TE120-0017

QUANTM PUMP, QTE-SSFC1SPSPSPPTS100

Graco TE120-0017 QUANTM i120, 2" NPT, Stainless Steel Electric Diaphragm Pump, 200-240 V, AL Center, SP Seat, SP Ball, SP Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design

  Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature

  Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump

  Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback

  Quiet operation reduces plant noise and improves employee safety and health

  Smart pump control provides more accurate flow set points and built-in I/O

• Efficient Electric Motor Powder-coated aluminum electric drive240 VAC 3 phase motor with 15 ft cord and NEMA L15-20 plugNon-hazardous
• Materials of Construction 316 stainless steel fluid section with NPT end portInternal components include Santoprene seat, Santoprene ball, Santoprene diaphragm and PTFE manifold o-ring

• Model: QUANTM
• Series: i120

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: Santoprene

• Center Section Material: Aluminum

• Connection Type: NPT

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: Santoprene

• Fluid Inlet Size (in): 2
• Fluid Inlet Size (mm): 51
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 2
• Fluid Outlet Size (mm): 50.8
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section: 316 Stainless Steel, End Port, NPT
• Fluid Section Material: 316 Stainless Steel

• Hazardous Location Appro

GG TE30-0014

QUANTM QUANTM PUMP, QTC-ALFC5SPSPSPPTA100

Graco TE30-0014 QUANTM i30, 1" NPT, Aluminum Electric Diaphragm Pump, 120 VAC 1Ph, AL Center, SP Seat, SP Ball, SP Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design

  Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature

  Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump

  Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback

  Quiet operation reduces plant noise and improves employee safety and health

  Smart pump control provides more accurate flow set points and built-in I/O

• Efficient Electric Motor Powder-coated aluminum electric drive 120 VAC motor with 15 ft cord and NEMA 5-15 plugNon-hazardous
• Materials of Construction Aluminum fluid section with NPT end portInternal components include Santoprene seat, Santoprene ball, Santoprene diaphragm and PTFE manifold o-ring

• Model: QUANTM
• Series: i30

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: Santoprene

• Center Section Material: Aluminum

• Connection Type: NPT

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: Santoprene

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section: Aluminum, End Port, NPT
• Fluid Section Material: Aluminum

• Hazardous Location Approval: None

• Manifold Configuration: End Port
• Manifold O-Ring Materia

GG TE120-0024

QUANTM PUMP, QTE-ALFC1TPTPTP-A100

Graco TE120-0024 QUANTM i120, 2" NPT, Aluminum Electric Diaphragm Pump, 200-240 V, AL Center, TP Seat, TP Ball, TP Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design

  Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature

  Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump

  Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback

  Quiet operation reduces plant noise and improves employee safety and health

  Smart pump control provides more accurate flow set points and built-in I/O

• Efficient Electric Motor Powder-coated aluminum electric drive240 VAC 3 phase motor with 15 ft cord and NEMA L15-20 plugNon-hazardous
• Materials of Construction Aluminum fluid section with NPT end portInternal components include TPE (Hytrel) seat, TPE (Hytrel) ball, TPE (Hytrel) diaphragm and TPE (Hytrel) manifold o-ring

• Model: QUANTM
• Series: i120

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: TPE (Hytrel)

• Center Section Material: Aluminum

• Connection Type: NPT

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: TPE (Hytrel)

• Fluid Inlet Size (in): 2
• Fluid Inlet Size (mm): 51
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 2
• Fluid Outlet Size (mm): 50.8
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section: Aluminum, End Port, NPT
• Fluid Section Material: Aluminum

• Hazardous Location Approval: None

• Manifold Configuration: End Port
• Mani

GG TE120-0036

QUANTM PUMP, QTE-PPFC1BNBNBN-P200

Graco TE120-0036 QUANTM i120, 2" Flange, Polypropylene Electric Diaphragm Pump, 200-240 V, AL Center, BN Seat, BN Ball, BN Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design
  • Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
  • Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
  • Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
  • Quiet operation reduces plant noise and improves employee safety and health
  • Smart pump control provides more accurate flow set points and built-in I/O
• Efficient Electric Motor
  • Powder-coated aluminum electric drive
  • 240 VAC 3Ph motor with 15 ft cord and NEMA L15-20 plug
  • Non-hazardous
• Materials of Construction
  • Polypropylene fluid section with end flange
  • Internal components include Buna-N seat, Buna-N ball, Buna-N diaphragm and Buna-N manifold o-ring

• Model: QUANTM
• Series: i120

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: Buna-N

• Center Section Material: Aluminum

• Connection Type: Flange

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: Buna-N

• Fluid Inlet Size (in): 2
• Fluid Inlet Size (mm): 51
• Fluid Inlet Thread Gender: Flange
• Fluid Inlet Thread Type: Flange

• Fluid Outlet Size (in): 2
• Fluid Outlet Size (mm): 50.8
• Fluid Outlet Thread Gender: Flange
• Fluid Outlet Thread Type: Flange
• Fluid Section: Polypropylene, End Flange
• Fluid Section Material: Polypropylene

• Hazardous Location Approval: None

• Manifold Configuration: End Flange
• Manifold O-Ring Material: Buna-N

• Maximum Ambient Temperature ( d

GG TE120-1207

QUANTM PUMP, QTE-SSFE7SASDPSPTS100

Graco TE120-1207 QUANTM i120, 2" NPT, Stainless Steel Electric Diaphragm Pump, 380 - 480 VAC 3Ph, FEP AL Center, SA Seat, SD Ball, PS Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design
  • Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
  • Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
  • Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
  • Quiet operation reduces plant noise and improves employee safety and health
  • Smart pump control provides more accurate flow set points and built-in I/O
• Efficient Electric Motor
  • FEP Coated Aluminum electric drive
  • 380-480 VAC 3Ph motor with 15 ft flying leads
  • Non-hazardous
• Materials of Construction
  • 316 Stainless Steel fluid section with NPT End Port
  • Internal components include 17-4 Stainless Steel seats, 440-C Stainless Steel balls, and PTFE/Santoprene 2-Piece diaphragms

• Model: QUANTM
• Series: i120

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: 440-C Stainless Steel

• Center Section Material: FEP Coated Aluminum

• Connection Type: NPT

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: PTFE/Santoprene 2-Piece

• Fluid Inlet Size (in): 2
• Fluid Inlet Size (mm): 50.8
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 2
• Fluid Outlet Size (mm): 50.8
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section: 316 Stainless Steel, End Port, NPT
• Fluid Section Material: 316 Stainless

GG TE120-0023

QUANTM PUMP, QTE-PPFC1SPSPSPPTP200

Graco TE120-0023 QUANTM i120, 2" Flange, Polypropylene Electric Diaphragm Pump, 200-240 V, AL Center, SP Seat, SP Ball, SP Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design

  Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature

  Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump

  Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback

  Quiet operation reduces plant noise and improves employee safety and health

  Smart pump control provides more accurate flow set points and built-in I/O

• Efficient Electric Motor Powder-coated aluminum electric drive240 VAC 3 phase motor with 15 ft cord and NEMA L15-20 plugNon-hazardous
• Materials of Construction Polypropylene fluid section with end flangeInternal components include Santoprene seat, Santoprene ball, Santoprene diaphragm and PTFE manifold o-ring

• Model: QUANTM
• Series: i120

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: Santoprene

• Center Section Material: Aluminum

• Connection Type: Flange

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: Santoprene

• Fluid Inlet Size (in): 2
• Fluid Inlet Size (mm): 51
• Fluid Inlet Thread Gender: Flange
• Fluid Inlet Thread Type: Flange

• Fluid Outlet Size (in): 2
• Fluid Outlet Size (mm): 50.8
• Fluid Outlet Thread Gender: Flange
• Fluid Outlet Thread Type: Flange
• Fluid Section: Polypropylene, End Flange
• Fluid Section Material: Polypropylene

• Hazardous Location Approval: None

• Manifold Configuration: End Flange
• Manifold O-Ring Material: PTFE

• Maximum Ambi

GG TE30-0002

QUANTM PUMP, QTC-SSFC5SAPTPSPTS100

Graco TE30-0002 QUANTM i30, 1" NPT, Stainless Steel Electric Diaphragm Pump, 120 VAC 1Ph, AL Center, SS Seat, PT Ball, PS Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design
  • Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
  • Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
  • Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
  • Quiet operation reduces plant noise and improves employee safety and health
  • Smart pump control provides more accurate flow set points and built-in I/O
• Efficient Electric Motor
  • Powder-coated aluminum electric drive
  • 120 VAC 1Ph motor with 15 ft cord and NEMA 5-15 plug
  • Non-hazardous
• Materials of Construction
  • Stainless steel fluid section with NPT end port
  • Internal components include 316 stainless steel seat, PTFE ball, PTFE/Santoprene 2-piece diaphragm and PTFE manifold o-ring

• Model: QUANTM
• Series: i30

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: PTFE

• Center Section Material: Aluminum

• Connection Type: NPT

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: PTFE/Santoprene 2-Piece

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section: Stainless Steel, End Port, NPT
• Fluid Section Material: Stainless Steel

• Hazardous Locatio

GG TE30-0006

QUANTM QUANTM PUMP, QTC-ALFC5SSSSPSPTA100

Graco TE30-0006 QUANTM i30, 1" NPT, Aluminum Electric Diaphragm Pump, 120 VAC 1Ph, AL Center, SS Seat, SS Ball, PS Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design

  Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature

  Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump

  Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback

  Quiet operation reduces plant noise and improves employee safety and health

  Smart pump control provides more accurate flow set points and built-in I/O

• Efficient Electric Motor Powder-coated aluminum electric drive 120 VAC motor with 15 ft cord and NEMA 5-15 plugNon-hazardous
• Materials of Construction Aluminum fluid section with NPT end portInternal components include 316 stainless steel seat, 316 stainless steel ball, PTFE/Santoprene 2-piece diaphragm and PTFE manifold o-ring

• Model: QUANTM
• Series: i30

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: 316 Stainless Steel

• Center Section Material: Aluminum

• Connection Type: NPT

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: PTFE/Santoprene 2-Piece

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section: Aluminum, End Port, NPT
• Fluid Section Material: Aluminum

• Hazardous Location Approval: None

• Manifold Configura

GG TE120-0173

QUANTM PUMP, QTE-SSFC3SSPTPOPTS100

Graco TE120-0173 QUANTM i120, 2" NPT, Stainless Steel Electric Diaphragm Pump, 200-240 V, AL Center, SS Seat, PT Ball, PO Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design

  Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature

  Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump

  Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback

  Quiet operation reduces plant noise and improves employee safety and health

  Smart pump control provides more accurate flow set points and built-in I/O

• Efficient Electric Motor Powder-coated aluminum electric drive240 VAC 3 phase motor with 15 ft flying leadsCID1 Groups C,D,T4 Zone 1 AEx d b IIB T4 Gb hazardous location approval
• Materials of Construction 316 stainless steel fluid section with NPT end portInternal components include 316 stainless steel seat, PTFE ball, PTFE Overmold diaphragm and PTFE manifold o-ring

• Model: QUANTM
• Series: i120

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: PTFE

• Center Section Material: Aluminum

• Connection Type: NPT

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: PTFE Overmold

• Fluid Inlet Size (in): 2
• Fluid Inlet Size (mm): 51
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 2
• Fluid Outlet Size (mm): 50.8
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section: 316 Stainless Steel, End Port, NPT
• Fluid Section Material: 316 Stainless St

GG TE30-0039

QUANTM QUANTM PUMP, QTC-ALFC5SSSSPOPTA100

Graco TE30-0039 QUANTM i30, 1" NPT, Aluminum Electric Diaphragm Pump, 120 VAC 1Ph, AL Center, SS Seat, SS Ball, PO Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design

  Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature

  Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump

  Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback

  Quiet operation reduces plant noise and improves employee safety and health

  Smart pump control provides more accurate flow set points and built-in I/O

• Efficient Electric Motor Powder-coated aluminum electric drive 120 VAC motor with 15 ft cord and NEMA 5-15 plugNon-hazardous
• Materials of Construction Aluminum fluid section with NPT end portInternal components include 316 stainless steel seat, 316 stainless steel ball, PTFE overmold diaphragm and PTFE manifold o-ring

• Model: QUANTM
• Series: i30

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: 316 Stainless Steel

• Center Section Material: Aluminum

• Connection Type: NPT

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: PTFE Overmold

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section: Aluminum, End Port, NPT
• Fluid Section Material: Aluminum

• Hazardous Location Approval: None

• Manifold Configuration: End Port

GG TE30-0015

QUANTM QUANTM PUMP, QTC-ALFC5ACACPSPTA200

Graco TE30-0015 QUANTM i30, 1" BSPT, Aluminum Electric Diaphragm Pump, 120 VAC 1Ph, AL Center, AC Seat, AC Ball, PS Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

• Revolutionary Design

  Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature

  Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump

  Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback

  Quiet operation reduces plant noise and improves employee safety and health

  Smart pump control provides more accurate flow set points and built-in I/O

• Efficient Electric Motor Powder-coated aluminum electric drive 120 VAC motor with 15 ft cord and NEMA 5-15 plugNon-hazardous
• Materials of Construction Aluminum fluid section with BSPT end portInternal components include acetal seat, acetal ball, PTFE/Santoprene 2-piece diaphragm and PTFE manifold o-ring

• Model: QUANTM
• Series: i30

• Application: Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer

• Ball Material: Acetal

• Center Section Material: Aluminum

• Connection Type: BSPT

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: PTFE/Santoprene 2-Piece

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: BSPT

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: BSPT
• Fluid Section: Aluminum, End Port, BSPT
• Fluid Section Material: Aluminum
