ENERPAC S100272

EP XC1B2LK

• Type: Service Kit

• Series: XC
• SubTypes: Repair Part

EP XC1CSK

• Type: Service Kit

• Series: XC
• SubTypes: Repair Part

EP RACH602005

• Type: Service Kit

• SubTypes: Tube

EP RACL504

RACL-Series Aluminum Cylinders include a lock nut that gives the reassurance of safe mechanical load holding for extended periods. Each cylinder is single-acting with a high-strength return spring for rapid retraction. The integral stop ring prevents plunger over-travel. All are equipped with bolt-on hardened steel saddles and a steel base plate for increased durability.

Enerpac RACL Lock Nut Aluminum Hydraulic Cylinders can change the way you think about your cylinder applications. With approximately half of the weight of equivalent steel models, they combine an impressive power to weight ratio with the convenience of easier transport and positioning. RACL cylinders are rated for 10,000 psi (700 bar) and comply with ASME B30.1.

Aluminum is not only lightweight, but also inherently less corrosive than steel, which makes it a great material for use in many caustic environments. For enhanced protection, Enerpac RACL Aluminum Cylinders are finished with an anodized hard coat finish to resist damage and extend cylinder life.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RACL
• Stroke Inches: 3.94
• Stroke MM: 100
• SubTypes: Aluminum Lock Nut Cylinder

• Aluminum Lock Nut provides mechanical load holding for extended periods
• Hardened steel stop ring increases cylinder life and resistance to side-loads of up to 5%
• Hard coat finish on all surfaces resists damage and extends cylinder life
• Composite bearings increase cylinder life and side load resistance
• Handles included on all models
• Steel base plate and saddle for protection against load-induced damage
• Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacity
• High-strength return spring for rapid cylinder retraction
• CR400 coupler and dustcap included on all models
• All cylinders meet ASME B-30.1 standards

• Accessories: CATS50

EP RACL204

RACL-Series Aluminum Cylinders include a lock nut that gives the reassurance of safe mechanical load holding for extended periods. Each cylinder is single-acting with a high-strength return spring for rapid retraction. The integral stop ring prevents plunger over-travel. All are equipped with bolt-on hardened steel saddles and a steel base plate for increased durability.

Enerpac RACL Lock Nut Aluminum Hydraulic Cylinders can change the way you think about your cylinder applications. With approximately half of the weight of equivalent steel models, they combine an impressive power to weight ratio with the convenience of easier transport and positioning. RACL cylinders are rated for 10,000 psi (700 bar) and comply with ASME B30.1.

Aluminum is not only lightweight, but also inherently less corrosive than steel, which makes it a great material for use in many caustic environments. For enhanced protection, Enerpac RACL Aluminum Cylinders are finished with an anodized hard coat finish to resist damage and extend cylinder life.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RACL
• Stroke Inches: 3.94
• Stroke MM: 100
• SubTypes: Aluminum Lock Nut Cylinder

• Aluminum Lock Nut provides mechanical load holding for extended periods
• Hardened steel stop ring increases cylinder life and resistance to side-loads of up to 5%
• Hard coat finish on all surfaces resists damage and extends cylinder life
• Composite bearings increase cylinder life and side load resistance
• Handles included on all models
• Steel base plate and saddle for protection against load-induced damage
• Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacity
• High-strength return spring for rapid cylinder retraction
• CR400 coupler and dustcap included on all models
• All cylinders meet ASME B-30.1 standards

EP RAR1004

RAR-Series Double Acting Hydraulic Cylinders provide a rapid and more controlled plunger retraction than spring return or load return types. The hydraulic return method continues to work effectively regardless of hose lengths and system losses, maintaining efficiency and productivity. Each RAR Cylinder is rated for up to 10,000 psi (700 bar) and compliant with ASME B30.1.

The aluminum construction of RAR Cylinders means they are not only lightweight, but also less corrosive than steel equivalents. This helps to maintain durability in many caustic environments. For enhanced protection, RAR Aluminum Cylinders are finished with an anodized hard coat finish to resist damage and extend cylinder life. Handles featured on all models enhance their portability.

Each RAR Cylinder is equipped with a bolt-on hardened steel saddle and a steel base plate for increased durability. Optional Tilt Saddles can help to support the load evenly and alleviate unwanted side-load.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RAR
• Stroke Inches: 3.94
• Stroke MM: 100
• SubTypes: Aluminum Cylinder

• Double-acting for rapid retraction, regardless of hose lengths and system losses
• Composite bearings increase cylinder life and side load resistance
• Hard coat finish on all surfaces resists damage and extends cylinder life
• Handles included on all models
• Steel base plate and saddle for protection against load- induced damage
• Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacity
• Built-in safety valve prevents accidental over-pressurization

• Accessories: CATS101

EP RAL502

Simplex RAL Series Aluminum Hydraulic Cylinders feature lock nut that provide the reassurance of safe mechanical load holding for extended periods. These are approximately half the weight of steel equivalents and are expertly engineered to withstand tough applications in harsh conditions.

Aluminum is not only lighter, but also inherently less corrosive than steel, which makes it a great material for use in many caustic environments. A carrying handle provided on all RAL cylinders also enhance portability.

Inside the cylinder is a high-strength return spring for plunger retraction and stop rings for protection against blow out. The cylinder exterior is finished with an anodized hard coat to extend cylinder life, and a wiper protects the inner cylinder assembly from dirt, moisture, and other contaminants.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Line: Hydraulic Tools
• Series: RAL
• Stroke Inches: 2
• Stroke MM: 50.8
• SubTypes: Aluminum Locknut Cylinder

• Capacity Imperial Tons: 50
• Capacity KN: 444,8

• Approximately half the weight of steel cylinders
• Lock nut for mechanical load holding for extended periods
• Heavy duty spring delivers fast and full retraction
• Hard anodized coating reduces wear and corrosion
• Stop rings prevent piston blow-out
• Wiper protects inner cylinder from dirt.
• Meets ANSI/ASME B30.1 Safety Standards
• Load tested under 125% of the nominal capacity
• For working pressures up to 10,000 psi (700 bar)

EP RAR100K50

• Type: Service Kit

• SubTypes: Repair Kit

EP RARH3010

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10150

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RARH
• Stroke Inches: 9.84
• Stroke MM: 250
• SubTypes: Aluminum Hollow Plunger Cylinder

• Lighter and shorter collapsed height than equivalent RACH single-acting models
• Double-acting for rapid retraction, regardless of hose lengths or system losses
• Built-in safety valve prevents accidental overpressurization
• Hollow plunger design allows for both pull and push forces
• Composite bearings increase cylinder life and side load resistance
• Hard coat finish on all surfaces resists damage and extends cylinder life
• Handles included on all models
• Floating center tube increases seal life
• Steel baseplate and saddle for protection against load-induced damage
• Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacity
• CR400 coupler and dust cap included on all models
• All cylinders meet ASME B-30.1 standards

• Accessories: HP3015

EP RARH606

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10150

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RARH
• Stroke Inches: 5.91
• Stroke MM: 150
• SubTypes: Aluminum Hollow Plunger Cylinder

• Lighter and shorter collapsed height than equivalent RACH single-acting models
• Double-acting for rapid retraction, regardless of hose lengths or system losses
• Built-in safety valve prevents accidental overpressurization
• Hollow plunger design allows for both pull and push forces
• Composite bearings increase cylinder life and side load resistance
• Hard coat finish on all surfaces resists damage and extends cylinder life
• Handles included on all models
• Floating center tube increases seal life
• Steel baseplate and saddle for protection against load-induced damage
• Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacity
• CR400 coupler and dust cap included on all models
• All cylinders meet ASME B-30.1 standards

• Accessories: HP5016

EP RC10010

RC-TRIO is the next generation of the legendary Enerpac RC-Series single acting hydraulic cylinders. These hydraulic jacks include many advanced features to ensure superior durability, versatility, and productivity.

A pre-tensioned spring provides fast plunger retraction and enhanced productivity. The robust bearing system features composite wear bands and a hardened stop ring to resist side-load which minimizes damage and repairs. The plunger wiper, high-grade polyethylene seals and tough external finishes also help towards an extended service life.

With so many hydraulic cylinder models to choose from, we’re confident you’ll find the perfect match for your applications, and if you already own prior RC-Series cylinders, the good news is the new cylinders share the same familiar dimensions and threads for full compatibility.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RC
• Stroke Inches: 10.25
• Stroke MM: 260
• SubTypes: General Purpose Cylinder

• Bearing system with composite wear bands for optimal sideload resistance
• Strengthened stop ring improves durability and side load resistance
• Trio Hybrid pre-tensioned spring system provides faster retraction
• High-grade polyethylene seals for low wear and long service life
• Plunger wiper reduces contamination, extending cylinder life.
• Collar and plunger threads and base mounting holes enable easy fixturing (on most models)
• Standard certified lifting eyes on cylinder models above 55 lbs. (25 kg) weight.
• Interchangeable with optional CHM6 carrying handle
• Designed for use in all positions
• Baked enamel finish for increased corrosion resistance
• Includes CR400 coupler, dust cap and collar thread protector
• RC-Series model numbers, external dimensions and threads remain unchanged from prior RC Series cylinders

• Spare Part(s): RC100044, HCL50045, RC10010040, RC100NK0, RC100NKS3, RC100NKS, RC100NKB1, RC100NKB2, RC100NKB3, RC100NKB4, RC100NKW
• Accessories: CATS100, CHM6

EP RC10044

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Stop Ring

EP RC1006K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RC1010

RC-TRIO is the next generation of the legendary Enerpac RC-Series single acting hydraulic cylinders. These hydraulic jacks include many advanced features to ensure superior durability, versatility, and productivity.

A pre-tensioned spring provides fast plunger retraction and enhanced productivity. The robust bearing system features composite wear bands and a hardened stop ring to resist side-load which minimizes damage and repairs. The plunger wiper, high-grade polyethylene seals and tough external finishes also help towards an extended service life.

With so many hydraulic cylinder models to choose from, we’re confident you’ll find the perfect match for your applications, and if you already own prior RC-Series cylinders, the good news is the new cylinders share the same familiar dimensions and threads for full compatibility.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RC
• Stroke Inches: 10.13
• Stroke MM: 257
• SubTypes: General Purpose Cylinder

• Bearing system with composite wear bands for optimal sideload resistance
• Strengthened stop ring improves durability and side load resistance
• Trio Hybrid pre-tensioned spring system provides faster retraction
• High-grade polyethylene seals for low wear and long service life
• Plunger wiper reduces contamination, extending cylinder life.
• Collar and plunger threads and base mounting holes enable easy fixturing (on most models)
• Standard certified lifting eyes on cylinder models above 55 lbs. (25 kg) weight.
• Interchangeable with optional CHM6 carrying handle
• Designed for use in all positions
• Baked enamel finish for increased corrosion resistance
• Includes CR400 coupler, dust cap and collar thread protector
• RC-Series model numbers, external dimensions and threads remain unchanged from prior RC Series cylinders

• Spare Part(s): RC106044, RC1010040, RC10NK0, RC10K35, RC10NKS, RC10NKB2, RC10NKB3, RC10NKW
• Accessories: A92, A102G, CATS12, JBI10, RB10, AW102, REB10, REP10

EP RC102K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Seal Kit

EP RC10K52

• Type: Service Kit

• SubTypes: Repair Kit

EP RC10K71

• Type: Service Kit

• SubTypes: Repair Kit

EP RC10K72

• Type: Service Kit

• SubTypes: Repair Kit

EP RC10NK0

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RC15044

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Stop Ring

EP RC15K1

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RC15K31

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Spring Kit

EP RC15K32

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Spring Kit

EP RC15K51

• Type: Service Kit

• SubTypes: Repair Kit

EP RC15K71

• Type: Service Kit

• SubTypes: Repair Kit

EP RC15NK0

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RC25K51

• Type: Service Kit

• SubTypes: Repair Kit

EP RC25K52

• Type: Service Kit

• SubTypes: Repair Kit

EP RC25K71

• Type: Service Kit

• SubTypes: Repair Kit

EP RC25K72

• Type: Service Kit

• SubTypes: Repair Kit

EP RC5010

RC-TRIO is the next generation of the legendary Enerpac RC-Series single acting hydraulic cylinders. These hydraulic jacks include many advanced features to ensure superior durability, versatility, and productivity.

A pre-tensioned spring provides fast plunger retraction and enhanced productivity. The robust bearing system features composite wear bands and a hardened stop ring to resist side-load which minimizes damage and repairs. The plunger wiper, high-grade polyethylene seals and tough external finishes also help towards an extended service life.

With so many hydraulic cylinder models to choose from, we’re confident you’ll find the perfect match for your applications, and if you already own prior RC-Series cylinders, the good news is the new cylinders share the same familiar dimensions and threads for full compatibility.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RC
• Stroke Inches: 10.25
• Stroke MM: 260
• SubTypes: General Purpose Cylinder

• Bearing system with composite wear bands for optimal sideload resistance
• Strengthened stop ring improves durability and side load resistance
• Trio Hybrid pre-tensioned spring system provides faster retraction
• High-grade polyethylene seals for low wear and long service life
• Plunger wiper reduces contamination, extending cylinder life.
• Collar and plunger threads and base mounting holes enable easy fixturing (on most models)
• Standard certified lifting eyes on cylinder models above 55 lbs. (25 kg) weight.
• Interchangeable with optional CHM6 carrying handle
• Designed for use in all positions
• Baked enamel finish for increased corrosion resistance
• Includes CR400 coupler, dust cap and collar thread protector
• RC-Series model numbers, external dimensions and threads remain unchanged from prior RC Series cylinders

• Spare Part(s): RC50044, HCL50045, RC5010040, RC50NK0, RC50NKS1, RC50NKS, RC50NKB1, RC50NKB2, RC50NKW
• Accessories: CATS100, JBI50, CHM6

EP RC506K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RC50K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RC50K1

• Type: Service Kit

• SubTypes: Repair Kit

EP RC50K51

• Type: Service Kit

• SubTypes: Repair Kit

EP RC53K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RC55

RC-TRIO is the next generation of the legendary Enerpac RC-Series single acting hydraulic cylinders. These hydraulic jacks include many advanced features to ensure superior durability, versatility, and productivity.

A pre-tensioned spring provides fast plunger retraction and enhanced productivity. The robust bearing system features composite wear bands and a hardened stop ring to resist side-load which minimizes damage and repairs. The plunger wiper, high-grade polyethylene seals and tough external finishes also help towards an extended service life.

With so many hydraulic cylinder models to choose from, we’re confident you’ll find the perfect match for your applications, and if you already own prior RC-Series cylinders, the good news is the new cylinders share the same familiar dimensions and threads for full compatibility.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RC
• Stroke Inches: 5
• Stroke MM: 127
• SubTypes: General Purpose Cylinder

• Bearing system with composite wear bands for optimal sideload resistance
• Strengthened stop ring improves durability and side load resistance
• Trio Hybrid pre-tensioned spring system provides faster retraction
• High-grade polyethylene seals for low wear and long service life
• Plunger wiper reduces contamination, extending cylinder life.
• Collar and plunger threads and base mounting holes enable easy fixturing (on most models)
• Standard certified lifting eyes on cylinder models above 55 lbs. (25 kg) weight.
• Interchangeable with optional CHM6 carrying handle
• Designed for use in all positions
• Baked enamel finish for increased corrosion resistance
• Includes CR400 coupler, dust cap and collar thread protector
• RC-Series model numbers, external dimensions and threads remain unchanged from prior RC Series cylinders

• Spare Part(s): RC5044, RC55040, RC5NK0, RC5K33, RC5NKS, RC5NKB1, RC5NKB2, RC5NKW1
• Accessories: A53F, A53G, RB5, AW51, AW53, REB5, REP5

EP RC5K30

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Spring Kit

EP RC603A

Simplex RC Series Hollow Plunger Hydraulic Cylinders offer the versatility needed to take on a wide range of applications. The hollow plunger design allows bars or rods to be pulled through the inside bore to enable pulling and pushing applications - ideal for tensioning cables, bolts, and pulling sleeves or bearings.

Inside the cylinder is a high-strength return spring for plunger retraction and stop rings for blow out protection. The cylinder exterior is finished with an enamel coating to extend cylinder life, and a wiper protects the inner cylinder assembly from dirt, moisture, and other contaminants.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Line: Hydraulic Tools
• Series: RC - Simplex
• Stroke Inches: 3
• Stroke MM: 76.2
• SubTypes: Center Hole Cylinder

• Capacity Imperial Tons: 60
• Capacity KN: 533,8

• Induction hardened piston rod for added strength eliminates the need for a saddle.
• Collar threads for easy fixing of components.
• Hollow plunger design allows for both push & pull forces.
• Large center hole for greater flexibility.
• Heavy duty spring delivers fast and full retraction
• Stop rings prevent piston blow-out
• Wiper protects inner cylinder from dirt.
• Meets ANSI/ASME B30.1 Safety Standards
• Load tested under 125% of the nominal capacity
• For working pressures up to 10,000 psi (700 bar)

EP RC5NKS

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Seal Kit

EP RC756K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RCH1003

RCH-Series Hollow Plunger Cylinders offer versatility in testing, maintenance, and tensioning applications. The hollow plunger design allows for push, pull or lifting applications. 

Enerpac cylinders are built to withstand tough conditions and demanding applications. These RCH cylinders have a baked enamel finish to resist corrosion. The center hole design has base holes and collar threads for easy fixturing. For models over 20 tons, the RCH series has nickel-plated floating center tube to reduce side load damage and increase the product life. 

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RCH
• Stroke Inches: 3
• Stroke MM: 76
• SubTypes: Hollow Plunger Cylinder

• Hollow plunger design allows for both pull and push forces
• Single-acting spring return
• Nickel-plated, floating center tube on models over 20 tons increases product life
• Baked enamel finish for increased corrosion resistance
• Collar threads for easy fixturing
• Features CR400 Coupler

• Set Includes: CR400
• Spare Part(s): RCH1003K
• Accessories: HP10016

EP RCH121K1

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RCH202

RCH-Series Hollow Plunger Cylinders offer versatility in testing, maintenance, and tensioning applications. The hollow plunger design allows for push, pull or lifting applications. 

Enerpac cylinders are built to withstand tough conditions and demanding applications. These RCH cylinders have a baked enamel finish to resist corrosion. The center hole design has base holes and collar threads for easy fixturing. For models over 20 tons, the RCH series has nickel-plated floating center tube to reduce side load damage and increase the product life. 

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RCH
• Stroke Inches: 2
• Stroke MM: 49
• SubTypes: Hollow Plunger Cylinder

• Hollow plunger design allows for both pull and push forces
• Single-acting spring return
• Nickel-plated, floating center tube on models over 20 tons increases product life
• Baked enamel finish for increased corrosion resistance
• Collar threads for easy fixturing
• Features CR400 Coupler

• Set Includes: CR400
• Spare Part(s): RCH202K, CF707110, CB894045, RCH202KV1
• Accessories: HP202

EP RCH202K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RCH302K2

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RCH603K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RCH302

RCH-Series Hollow Plunger Cylinders offer versatility in testing, maintenance, and tensioning applications. The hollow plunger design allows for push, pull or lifting applications. 

Enerpac cylinders are built to withstand tough conditions and demanding applications. These RCH cylinders have a baked enamel finish to resist corrosion. The center hole design has base holes and collar threads for easy fixturing. For models over 20 tons, the RCH series has nickel-plated floating center tube to reduce side load damage and increase the product life. 

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RCH
• Stroke Inches: 2.5
• Stroke MM: 64
• SubTypes: Hollow Plunger Cylinder

• Hollow plunger design allows for both pull and push forces
• Single-acting spring return
• Nickel-plated, floating center tube on models over 20 tons increases product life
• Baked enamel finish for increased corrosion resistance
• Collar threads for easy fixturing
• Features CR400 Coupler

• Set Includes: CR400
• Spare Part(s): RCH302K2, CH259110, CF698045, RWH302KV
• Accessories: HP3015

EP RCH603K1

• Type: Service Kit

• SubTypes: Repair Kit

EP RCS1002K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RCS302

RCS-Series Low Profile Hydraulic Cylinders provide superior durability, performance longevity, safety, and quality in a compact and convenient footprint. These low profile hydraulic jacks are the perfect choice for general lifting and production applications where space is limited or constrained. A low collapsed height, short stroke, and solid construction enables safety and stability in both vertical and horizontal orientations.

Many low-profile hydraulic cylinders rely on the weight of the load to retract the plunger. RCS cylinders are different and include a powerful return spring, which is faster, convenient, and more productive. The entire RCS cylinder range is rated for high-pressure; 10,000 psi (700 bar).

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RCS
• Stroke Inches: 2.44
• Stroke MM: 62
• SubTypes: Low Height Cylinder

• Lightweight, low profile design for use in confined spaces
• Baked enamel finish for increased corrosion resistance
• Plunger wiper reduces contamination, extending cylinder life
• CR-400 coupler and dust cap included on all models
• Grooved plunger end with threaded holes for mounting tilt saddles
• Plated steel plungers
• Single-acting spring return

• Spare Part(s): RCS302K, DC5215900, RCS302KV
• Accessories: CATS53

EP RCS302K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RCS502K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RD1610

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000
• Min Bar: 35

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools, Work Holding Tools
• Series: RD
• Stroke Inches: 10.25
• Stroke MM: 260
• SubTypes: General Purpose Cylinder

• Designed for long life, the best choice for production applications
• Unique mounting configurations simplify fixturing
• Baked enamel finish for increased corrosion resistance
• Double-acting operation develops force in both directions, providing maximum versatility
• Plunger wiper reduces contamination, extending cylinder life

• Accessories: AD181, AD182, AD183, AD152

EP RD166

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000
• Min Bar: 35

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools, Work Holding Tools
• Series: RD
• Stroke Inches: 6.25
• Stroke MM: 159
• SubTypes: General Purpose Cylinder

• Designed for long life, the best choice for production applications
• Unique mounting configurations simplify fixturing
• Baked enamel finish for increased corrosion resistance
• Double-acting operation develops force in both directions, providing maximum versatility
• Plunger wiper reduces contamination, extending cylinder life

• Accessories: AD181, AD182, AD183, AD152

EP RD46K2

• Type: Service Kit

• SubTypes: Repair Part

EP RD2510

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000
• Min Bar: 35

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools, Work Holding Tools
• Series: RD
• Stroke Inches: 10.25
• Stroke MM: 260
• SubTypes: General Purpose Cylinder

• Designed for long life, the best choice for production applications
• Unique mounting configurations simplify fixturing
• Baked enamel finish for increased corrosion resistance
• Double-acting operation develops force in both directions, providing maximum versatility
• Plunger wiper reduces contamination, extending cylinder life

• Accessories: AD191, AD192, AD193, AD153

EP RD91

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000
• Min Bar: 35

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools, Work Holding Tools
• Series: RD
• Stroke Inches: 1.13
• Stroke MM: 28
• SubTypes: General Purpose Cylinder

• Designed for long life, the best choice for production applications
• Unique mounting configurations simplify fixturing
• Baked enamel finish for increased corrosion resistance
• Double-acting operation develops force in both directions, providing maximum versatility
• Plunger wiper reduces contamination, extending cylinder life

• Accessories: AD171, AD172, AD173, AD151

EP RD910K2

• Type: Service Kit

• SubTypes: Repair Kit

EP RD93

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000
• Min Bar: 35

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools, Work Holding Tools
• Series: RD
• Stroke Inches: 3.13
• Stroke MM: 79
• SubTypes: General Purpose Cylinder

• Designed for long life, the best choice for production applications
• Unique mounting configurations simplify fixturing
• Baked enamel finish for increased corrosion resistance
• Double-acting operation develops force in both directions, providing maximum versatility
• Plunger wiper reduces contamination, extending cylinder life

• Accessories: AD171, AD172, AD173, AD151

EP RJA1538

• Multiple-tooth pawls for strength & safety.
• Large base ensures a firm foundation.
• Drop-forged, alloy steel, heat-treated components.
• Plated springs to resist corrosion.
• Double-lever sockets for jacking in close quarters.
• Our Jack design specifications meet or exceed ANSI / ASME B30.1 Safety Standards.
• The RJA1538 pole jack is designed for pole pulling applications. Chain and I-Beam are ordered separately.
• Carrying handles make the positioning and transporting of the 10 (44,5), 15 (89) and 20 (133,4) ton (kN) ratchet jacks simple.

• Type: Jack

• Product Line: Mechanical Tools
• Series: RJ
• Stroke Inches: 21.25
• Stroke MM: 539.8
• SubTypes: Ratchet Jacks

• Capacity Imperial Tons: 8
• Capacity KN: 71,2

• Accessories: SLB70

EP RJ86A

• Multiple-tooth pawls for strength & safety.
• Large base ensures a firm foundation.
• Drop-forged, alloy steel, heat-treated components.
• Plated springs to resist corrosion.
• Double-lever sockets for jacking in close quarters.
• Our Jack design specifications meet or exceed ANSI / ASME B30.1 Safety Standards
• Carrying handles make the positioning and transporting of the 10 (44,5), 15 (89) and 20 (133,4) ton (kN) ratchet jacks simple.

• Type: Jack

• Product Line: Mechanical Tools
• Series: RJ
• Stroke Inches: 13
• Stroke MM: 330.2
• SubTypes: Ratchet Jacks

• Capacity Imperial Tons: 5
• Capacity KN: 44,5

• Accessories: SLB36

EP RK848586A02

• Type: ERP

• SubTypes: Component

EP RK848586A01

• Type: ERP

EP RLP19312

This low-profile hexagon cassette is for use with compatible RSL-Series modular drive units. The low-profile design with an optimum nose radius gives you the access needed for hassle-free bolting in tight spaces.

For heavy use and enduring durability, RLP-Series Cassettes are constructed from robust steel and are easily fixed to the RSL Drive Unit using four Allen Key Bolts.

The wide range of interchangeable hexagon cassette sizes provides the versatility to complete a wide range of bolting applications. For exceptionally tight spaces consider the RLP Slimline Stepped Width Cassettes which can also be used with the same drive unit.

Constant torque output provides accuracy of ±3% across full stroke.

• Type: Torque Wrench

• Product Group: Torque Wrenches, Torque Wrench Pumps
• Product Line: Bolting Tools
• Series: RLP
• SubTypes: Cassette - Imperial or Metric

• Accessories: ERT19024

EP RLL1502

• Load-return - for weighing, lifting and positioning applications.
• Lock nut tested to 150% of rated load.
• Lock nut provides safe mechanical load holding for an extended period of time.
• Red band warns operator to end of stroke, over-flow port prevents over-stroke.
• Built-in tilt saddle to improve side-load resistance.
• Body, lock nut and saddle feature black nitride coating to improve corrosion and wear resistance.
• Low-Profile for use in confined areas.

• Type: Hydraulic Cylinders
• Max PSI: 10150

• Product Line: Hydraulic Tools
• Series: RLL
• Stroke Inches: 1.77
• Stroke MM: 45
• SubTypes: High Tonnage Lock Nut Cylinder

• Capacity Imperial Tons: 158
• Capacity KN: 1429
• Capacity Metric Tons: 143

EP RLT111

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10150

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RLT
• Stroke Inches: 1.57
• Stroke MM: 40
• SubTypes: Low Height Telescopic Cylinder

• Single-Acting, load return
• Nitrocarburization surface treatment for improved load and wear resistance and corrosion protection
• The longer stroke length of telescopic cylinders will save you time and simplify projects by moving a load a greater distance and eliminating the use of temporary cribbing.
• For use in confined spaces: machinery positioning, tool fastening
• Mounting bolt holes for easy fixturing
• Up to 3% side-load of maximum capacity
• Design safety factor complies with ASME B30.1 & EN1494
• CR400 coupler for compatibility with standard product
• High-Alloy steel for maximum strength
• 1st Stage: maximum load capacity at lower stroke.
• 2nd Stage: extended stroke with lower capacity than the 1st stage.
• Final Stage: maximum stroke extension with lowest capacity.

EP RLS302

• Compact low-profile design.
• HD spring for fast retraction.
• Grooved plunger to stabilize the load.
• Stop ring for piston blow-out protection.
• Rod wiper protects inner cylinder from dirt.
• Plated piston to resist scoring & corrosion.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Line: Hydraulic Tools
• Series: RLS
• Stroke Inches: 2.44
• Stroke MM: 62
• SubTypes: Low Height Cylinder

• Capacity Imperial Tons: 30
• Capacity KN: 266,9

EP RR1006K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RR5013K1

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RR1010

RR-Series Cylinders are the ideal choice whenever you need to retract the plunger quickly with precise control. These popular rams are rugged enough to withstand high-cycle and demanding job site uses - making them incredibly effective within both the construction and manufacturing industries. RR Cylinders are available in long stroke models to lift or push a load a greater distance, which will save you time and minimize or eliminate the need for temporary cribbing.

The collar thread, plunger thread, base mounting holes, removable saddle and optional accessories make these some of the most versatile cylinders available. Optional accessories include flat, grooved, and tilt saddles on models up to 75-ton. These are secured to the plunger for use both horizontally and upside down.

The RR range is extensive, with capacities ranging from 10 to 500 imperial tons (101 - 5108 kN), and maximum plunger strokes from 2.25" Â to 48" Â (57 - 1219 mm). Each RR Cylinder available for sale is rated for up to 10,000 psi (700 bar) and compliant with ASME B30.1.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RR
• Stroke Inches: 10
• Stroke MM: 254
• SubTypes: General Purpose Cylinder

• Collar threads and plunger threads for easy fixturing
• Baked enamel finish for increased corrosion resistance
• Removable hardened saddles protect plunger during lifting and pressing
• Built-in safety valve prevents accidental over-pressurization
• Plunger wiper reduces contamination, extending cylinder life
• CR400 coupler included on all models

• Spare Part(s): RR1012K, RR1012KV
• Accessories: CATS12

EP RR506

RR-Series Cylinders are the ideal choice whenever you need to retract the plunger quickly with precise control. These popular rams are rugged enough to withstand high-cycle and demanding job site uses - making them incredibly effective within both the construction and manufacturing industries. RR Cylinders are available in long stroke models to lift or push a load a greater distance, which will save you time and minimize or eliminate the need for temporary cribbing.

The collar thread, plunger thread, base mounting holes, removable saddle and optional accessories make these some of the most versatile cylinders available. Optional accessories include flat, grooved, and tilt saddles on models up to 75-ton. These are secured to the plunger for use both horizontally and upside down.

The RR range is extensive, with capacities ranging from 10 to 500 imperial tons (101 - 5108 kN), and maximum plunger strokes from 2.25" Â to 48" Â (57 - 1219 mm). Each RR Cylinder available for sale is rated for up to 10,000 psi (700 bar) and compliant with ASME B30.1.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RR
• Stroke Inches: 6.13
• Stroke MM: 156
• SubTypes: General Purpose Cylinder

• Collar threads and plunger threads for easy fixturing
• Baked enamel finish for increased corrosion resistance
• Removable hardened saddles protect plunger during lifting and pressing
• Built-in safety valve prevents accidental over-pressurization
• Plunger wiper reduces contamination, extending cylinder life
• CR400 coupler included on all models

• Spare Part(s): RR5013K1, L345045, G586900SR-7000, RR5013KV
• Accessories: CATS100

EP RR7513

RR-Series Cylinders are the ideal choice whenever you need to retract the plunger quickly with precise control. These popular rams are rugged enough to withstand high-cycle and demanding job site uses - making them incredibly effective within both the construction and manufacturing industries. RR Cylinders are available in long stroke models to lift or push a load a greater distance, which will save you time and minimize or eliminate the need for temporary cribbing.

The collar thread, plunger thread, base mounting holes, removable saddle and optional accessories make these some of the most versatile cylinders available. Optional accessories include flat, grooved, and tilt saddles on models up to 75-ton. These are secured to the plunger for use both horizontally and upside down.

The RR range is extensive, with capacities ranging from 10 to 500 imperial tons (101 - 5108 kN), and maximum plunger strokes from 2.25" Â to 48" Â (57 - 1219 mm). Each RR Cylinder available for sale is rated for up to 10,000 psi (700 bar) and compliant with ASME B30.1.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RR
• Stroke Inches: 13.13
• Stroke MM: 333
• SubTypes: General Purpose Cylinder

• Collar threads and plunger threads for easy fixturing
• Baked enamel finish for increased corrosion resistance
• Removable hardened saddles protect plunger during lifting and pressing
• Built-in safety valve prevents accidental over-pressurization
• Plunger wiper reduces contamination, extending cylinder life
• CR400 coupler included on all models

• Spare Part(s): RR756K, L345045, G586900SR-7000
• Accessories: CATS100

EP RR314K2

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RR756k

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP S1500SMK

• Type: Service Kit

• SubTypes: Manifold Kit

EP S1500SK

• Type: Service Kit

• SubTypes: Seal Kit

EP RSM300K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP S1500DK

• Type: Service Kit

• SubTypes: Drive Unit Rebuild Kit

EP RTE30X

• Type: Torque Wrench Accessory

• Product Group: Torque Wrenches, Torque Wrench Pumps
• Product Line: Bolting Tools
• Series: RTEX
• SubTypes: Reaction Tube Extension

• Full torque rated
• Increases tool fit in restricted access areas

EP S1500SDRK

• Type: Service Kit

• SubTypes: Square Drive Retainer

EP RRH1006

RRH-Series Hollow Plunger Hydraulic Cylinders are ideal for tensioning, testing, pulling, and lifting applications. The hollow bore, base threaded holes and collar thread allow attachments that enable the cylinder to deliver both pull and push forces.

RRH double-acting center-hole hydraulic cylinders feature two connection ports to provide hydraulic flow to both advance and retract the plunger. This provides a more controlled retraction than single-acting cylinders.

Cylinders in the RRH-Series are constructed from high-alloy steel and finished with a baked enamel exterior coating. Collar threads and base holes for easy fixturing are provided as standard.

Enerpac has designed and manufactured 10,000 psi (700 bar) high-pressure hydraulic cylinders for many decades. We use only the highest quality materials to ensure they can withstand the most demanding applications. All RRH cylinders meet the safety standards required for high-pressure hydraulic tools.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RRH
• Stroke Inches: 6
• Stroke MM: 153
• SubTypes: Hollow Plunger Cylinder

• Relief valves prevent damage in case of over-pressurization
• Baked enamel finish for increased corrosion resistance
• Collar threads enable easy fixturing
• Double-acting operation for fast retraction
• Nickel-plated, floating center tube increases product life
• Hollow plunger allows for both pull and push forces
• CR-400 couplers and dust caps included on all models
• Plunger wiper reduces contamination, extending cylinder life

• Accessories: HP10016

EP RRH603K4

• Type: Service Kit

• SubTypes: Repair Kit

EP S1500RK

• Type: Service Kit

• SubTypes: Ratchet Kit

EP RSL19000FSK

• Type: Service Kit

• SubTypes: Front Cap and Seal Kit

EP RSM500K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RSM200K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP RRH606

RRH-Series Hollow Plunger Hydraulic Cylinders are ideal for tensioning, testing, pulling, and lifting applications. The hollow bore, base threaded holes and collar thread allow attachments that enable the cylinder to deliver both pull and push forces.

RRH double-acting center-hole hydraulic cylinders feature two connection ports to provide hydraulic flow to both advance and retract the plunger. This provides a more controlled retraction than single-acting cylinders.

Cylinders in the RRH-Series are constructed from high-alloy steel and finished with a baked enamel exterior coating. Collar threads and base holes for easy fixturing are provided as standard.

Enerpac has designed and manufactured 10,000 psi (700 bar) high-pressure hydraulic cylinders for many decades. We use only the highest quality materials to ensure they can withstand the most demanding applications. All RRH cylinders meet the safety standards required for high-pressure hydraulic tools.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RRH
• Stroke Inches: 6.5
• Stroke MM: 166
• SubTypes: Hollow Plunger Cylinder

• Relief valves prevent damage in case of over-pressurization
• Baked enamel finish for increased corrosion resistance
• Collar threads enable easy fixturing
• Double-acting operation for fast retraction
• Nickel-plated, floating center tube increases product life
• Hollow plunger allows for both pull and push forces
• CR-400 couplers and dust caps included on all models
• Plunger wiper reduces contamination, extending cylinder life

• Accessories: HP5016

EP S3037

• Type: Service Kit

• SubTypes: Gasket

EP S6000PX

• Type: Torque Wrench
• Max PSI: 10000

• Product Group: Torque Wrenches, Torque Wrench Pumps
• Product Line: Bolting Tools
• Series: S-PX
• SubTypes: Square Drive Torque Wrench

• Compact, high-strength uni-body construction provides a small operating radius without sacrificing endurance
• 35° rotation angle and rapid return stroke for fast operation
• Tough manifold design with added safety feature for enhanced operator safety
• 360° click-on reaction arm with quick release lever provides easier handling, even when wearing gloves
• Includes robust handle which mounts on both sides of tool for extra maneuverability
• Push button square drive release for quickly reversing the square drive for tightening or loosening
• Fitted with enhanced tilt and swivel TSP300 manifold for horizontal and vertical maneuverability, with greater durability
• Constant torque output provides accuracy of +/-3% across full stroke
• Optional Angle-of-Turn Indicator provides measurement of rotation

• Set Includes: SWH10A, TSP300, SD60108
• Accessories: BUS02, BUS03, BUS04, BUS05, BUS06, BUS07, BUS08, BUS09, BUS10, BUS11, BUS12, MCS7500C, SWH10S, AOT60, RTE60X, SRS601X, SRS602X, SRS603X

EP RRH1003

RRH-Series Hollow Plunger Hydraulic Cylinders are ideal for tensioning, testing, pulling, and lifting applications. The hollow bore, base threaded holes and collar thread allow attachments that enable the cylinder to deliver both pull and push forces.

RRH double-acting center-hole hydraulic cylinders feature two connection ports to provide hydraulic flow to both advance and retract the plunger. This provides a more controlled retraction than single-acting cylinders.

Cylinders in the RRH-Series are constructed from high-alloy steel and finished with a baked enamel exterior coating. Collar threads and base holes for easy fixturing are provided as standard.

Enerpac has designed and manufactured 10,000 psi (700 bar) high-pressure hydraulic cylinders for many decades. We use only the highest quality materials to ensure they can withstand the most demanding applications. All RRH cylinders meet the safety standards required for high-pressure hydraulic tools.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RRH
• Stroke Inches: 3
• Stroke MM: 76
• SubTypes: Hollow Plunger Cylinder

• Relief valves prevent damage in case of over-pressurization
• Baked enamel finish for increased corrosion resistance
• Collar threads enable easy fixturing
• Double-acting operation for fast retraction
• Nickel-plated, floating center tube increases product life
• Hollow plunger allows for both pull and push forces
• CR-400 couplers and dust caps included on all models
• Plunger wiper reduces contamination, extending cylinder life

• Accessories: HP10016

EP S90964

• Type: Component

EP RSM750K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP S93582

• Type: ERP

EP SB1

• Type: Spreader Accessory

• Product Group: Flange Maintenance Tools
• Product Line: Industrial Tools, Bolting Tools
• SubTypes: Safety Block

EP RW53

• Type: Hydraulic Cylinders
• Max Bar: 350
• Max PSI: 10000
• Min PSI: 600

• Product Group: Cylinders and Jacks
• Product Line: Work Holding Tools
• Series: RW
• Stroke Inches: 3.17
• SubTypes: Workholding General Purpose Cylinder

• Cylindrical models
• High pressure design when additional force is required
• Long stroke lengths in a compact design, well suited for welding applications
• Collar mounting threads and base mounting holes allow flexible mounting options
• Cylinders are provided with hardened saddles for additional plunger protection
• Snap-in saddles are easily removed for adapting to different plunger devices
• Chrome plated plunger with bronze upper and lower bearing provides a long cylinder life

EP S1500GK

• Type: Service Kit

• SubTypes: Guard Kit

EP RSM1500K

• Type: Service Kit

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• SubTypes: Repair Kit

EP SC00HTB

• Type: Cylinder And PumpSet
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks, Pumps
• Product Line: Industrial Tools
• Series: SCTB
• Stroke Inches: n/a
• Stroke MM: n/a
• SubTypes: Toolbox Set - Flex

• Capacity Imperial Tons: n/a
• Capacity KN: n/a

• Option to upgrade to a complete hydraulic solution
• Will work effortlessly with your Enerpac tool of choice, giving you everything you need to tackle a wide range of jobs.
• Convenient and portable, this set comes in a durable, easy to carry box.

• Set Includes: P392, GA45GC, HC7206C, HF100

EP S3000XSK

• Type: Service Kit

• SubTypes: Seal Kit
