EP HCR2002
223 ton Capacity, 1.97 in Stroke, Double-Acting, High Tonnage Hydraulic Cylinder
HCR Series Hydraulic Cylinders are double-acting which delivers a faster and more controlled return of the plunger compared to load/gravity return equivalents.
Enerpac High-Tonnage Cylinders are equipped with numerous special features to ensure the durability, safety, and performance needed for large-scale construction projects. Among these features are low-wear high-pressure seals, replaceable composite plunger support bearings, and a robust nitrocarburized finish on both the body and plunger.
Applications: Lift, Lower, Push
- Type: Hydraulic Cylinders
- Max Bar: 700
- Max PSI: 10150
- Product Group: Cylinders and Jacks
- Product Line: Industrial Tools
- Series: HCR
- Stroke Inches: 1.97
- Stroke MM: 50
- SubTypes: High Tonnage Cylinder
- Double-acting for fast and controlled advance and retract
- Nitrocarburized surface resists side-loading and cyclic wear
- 10% side-load resistance over full cylinder stroke
- Weather protected, inside and out
- Upper and lower replaceable bearings support the plunger throughout the stroke
- Certified lifting eyes
- Base mounting holes
- Collar threads included on models up to 250 ton. Optional on 300 ton and higher.
- Maximum working pressure up to 10,000 psi (700 bar)
- Complies to ASME B30.1
- Spare Part(s): HCR200K1
- Accessories: CATS200
