Diaphragm

GG 233052

KIT, ACCY, DRUM PKG

Husky 515 55 gal (208 liter) AC Transfer Pump Package with AC Seats, PTFE Balls, PTFE Diaphragms & SS Tube

The Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.

The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability.

Center and end porting options.No mechanical seals to cause fluid leaks or failuresRuns quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levelsEasy-to-service air valve and ball checksOperates on as little as 20 psi (1.4 bar, 0.14 MPa)Split manifold option to pump multiple fluids without mixingDelivery up to 15 gpm (56.7 lpm)Easy-to-service air valve and ball checksReliable air valve for years of dependable performance

GG 233776

TRITON PUMP, DIAPHRAGM, 1:1, AL BSPP

Triton Air-Operated Diaphragm Pump, Bare, Aluminum, BSPP

Effective alternative to traditional pressure pots and standard diaphragm pumps

Double diaphragm pump designed specifically for finishing applications

Low pulsation output provides smooth pump changeover

Low shear design for minimal degradation of shear sensitive materials

Rugged aluminum and stainless steel construction handles a wide variety of fluids

GG 233777

TRITON PUMP, DIAPHRAGM, 1:1, SST BSPP

Triton Air-Operated Diaphragm Pump, Bare, SST, BSPP

Effective alternative to traditional pressure pots and standard diaphragm pumps

Double diaphragm pump designed specifically for finishing applications

Low pulsation output provides smooth pump changeover

Low shear design for minimal degradation of shear sensitive materials

Rugged aluminum and stainless steel construction handles a wide variety of fluids

GG 237613

PUMP, BILLDOG, 33

GG 241407

HUSKY PUMP, 716A-PP01AA1-1PPBNBNPT

Husky 716 Air Operated Diaphragm Pump with Single-Direction Manifolds, PP/BN/BN

The Husky 716 air operated diaphragm pump features an external controller for remote control capabilities.

Center- and end-portingNo mechanical seals which causes fluid leaks or failuresRuns quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levelsEasy-to-service air valve and ball checks3/4 in (19.05 mm) center- and end-portingNo seals to leak or failQuiet running less than 85 dBa with easy-to-use remote muffler capability for even lower noise levelsEasy-to-service air valve and ball checks

GG 243307

HUSKY PUMP, 716A-PP01AA1-3ACPTPTPT

Husky 716 AL Air Operated Double Diaphragm Metal Pump with AC Seat, PTFE Ball, and PTFE Diaphragm

The Husky 716 air operated diaphragm pump features an external controller for remote control capabilities.

Center- and end-portingNo mechanical seals which causes fluid leaks or failuresRuns quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levelsEasy-to-service air valve and ball checks3/4 in (19.05 mm) center- and end-portingNo seals to leak or failQuiet running less than 85 dBa with easy-to-use remote muffler capability for even lower noise levelsEasy-to-service air valve and ball checks

GG 246367

HUSKY PUMP, 716 DRUM W/RISER

Husky 716 Diaphragm Pump with Drum Riser Tube

The Husky 716 air operated diaphragm pump features an external controller for remote control capabilities.

Center- and end-portingNo mechanical seals which causes fluid leaks or failuresRuns quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levelsEasy-to-service air valve and ball checks3/4 in (19.05 mm) center- and end-portingNo seals to leak or failQuiet running less than 85 dBa with easy-to-use remote muffler capability for even lower noise levelsEasy-to-service air valve and ball checks

GG 246368

HUSKY PUMP, 1050 W/RISER

Husky 1050 Diaphragm Pump with Drum Riser Tube

The Husky 1050 air-operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. The one-piece center section eliminates leaks and reduces maintenance on Husky pumps when compared to other diaphragm pumps.

Longer Diaphragm Life

• Up to 5x longer diaphragm life for less maintenance and downtime

Modular Air Valve

• Stall-free, low pulsation operation provides smooth and rapid changeover

One-Piece Center Section

• Eliminates air leaks for more efficient operation

Four Bolt Joint Design

• Bolted design provides even sealing pressure for leak-free operation

Multiple Ports

• Increased number of ports for installation flexibility

Optional Features

• DataTrak - Runaway protection and tracks material usage
• Pulse Output - Cycle count capability

Spring loaded, externally serviceable pilot valves for faster change over and reduced pulsation30% more efficient than the market leader20% increase in fluid flow compared to the Husky 1040

GG 24B764

HUSKY PUMP, 2150P-PA01AP2PPPTPOPT

Husky 2150 PP Pump, AL Center Section, PP Seats, PTFE Balls & PO Diaphragm

The Husky 2150 air operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.

Overall improved efficiency (up to 40% more efficient)Highest fluid flow rate in its classUp to 5 times longer diaphragm life compared to other air operated diaphragm pumpsExpanded material offering to handle endless applicationsFewer parts than industry peers, the air valve is externally accessible so it can be serviced quickly and easily without uninstalling the diaphragm pump2 in. (51 mm) ANSI end-portingFluid flow up to 150 gpm (568 lpm)Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)Lube-free operationEpoxy-coated air section for tough environmental conditionsAvailable in aluminum, 316 stainless steel, ductile iron and polypropylene

GG 24B780

HUSKY PUMP, 1590S-PS01AS1SSPTPOPT

Husky 1590 SS Pump, SS Center Section, SS Seats, PTFE Balls & PO Diaphragm

The Husky 1590 air-operated diaphragm pump features a patented, high-reliability closed center air valve that is online serviceable and an epoxy-coated air section for tough environmental conditions.

Up to 5 times longer diaphragm life compared to other air operated diaphragm pumps in its classExpanded material offering to handle endless applicationsFewer parts than industry peers, the air valve is externally accessible so it can be serviced quickly and easily without uninstalling the diaphragm pumpOffered in ATEX configuration.1-1/2 in. (38.1 mm) ANSI end-portingHigh flow - 100 gpm (378 lpm) in a compact, portable sizeFluid pressure to 120 psi (8.4 bar, 0.84 MPa)Lube-free operationAvailable in polypropylene, aluminum and stainless steelEpoxy-coated air section for tough environmental conditions

GG 24B781

HUSKY PUMP, 1590S-PA01AS1SSPTPOPT

Husky 1590 SS Pump, AL Center Section, SS Seats, PTFE Balls & PO Diaphragm

The Husky 1590 air-operated diaphragm pump features a patented, high-reliability closed center air valve that is online serviceable and an epoxy-coated air section for tough environmental conditions.

Up to 5 times longer diaphragm life compared to other air operated diaphragm pumps in its classExpanded material offering to handle endless applicationsFewer parts than industry peers, the air valve is externally accessible so it can be serviced quickly and easily without uninstalling the diaphragm pumpOffered in ATEX configuration.1-1/2 in. (38.1 mm) ANSI end-portingHigh flow - 100 gpm (378 lpm) in a compact, portable sizeFluid pressure to 120 psi (8.4 bar, 0.84 MPa)Lube-free operationAvailable in polypropylene, aluminum and stainless steelEpoxy-coated air section for tough environmental conditions

GG 24B782

HUSKY PUMP, 2150A-PA01AA1SSPTPOPT

Husky 2150 AL Air Operated Double Diaphragm Metal Pump, SS/PT/PO

The Husky 2150 air operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.

Overall improved efficiency (up to 40% more efficient)Highest fluid flow rate in its classUp to 5 times longer diaphragm life compared to other air operated diaphragm pumpsExpanded material offering to handle endless applicationsFewer parts than industry peers, the air valve is externally accessible so it can be serviced quickly and easily without uninstalling the diaphragm pump2 in. (51 mm) ANSI end-portingFluid flow up to 150 gpm (568 lpm)Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)Lube-free operationEpoxy-coated air section for tough environmental conditionsAvailable in aluminum, 316 stainless steel, ductile iron and polypropylene

GG 24B783

HUSKY PUMP, 2150S-PS01S1SSPTPOPT

Husky 2150 2 in. (51 mm) NPT SS Pump, SS Center Section, SS Seats, PTFE Balls & PO Diaphragm

The Husky 2150 air operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.

Overall improved efficiency (up to 40% more efficient)Highest fluid flow rate in its classUp to 5 times longer diaphragm life compared to other air operated diaphragm pumpsExpanded material offering to handle endless applicationsFewer parts than industry peers, the air valve is externally accessible so it can be serviced quickly and easily without uninstalling the diaphragm pump2 in. (51 mm) ANSI end-portingFluid flow up to 150 gpm (568 lpm)Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)Lube-free operationEpoxy-coated air section for tough environmental conditionsAvailable in aluminum, 316 stainless steel, ductile iron and polypropylene

GG 24B833

HUSKY PUMP, 2150F-PA01AF2PVPTPOPT

Husky 2150 PVDF Pump, AL Center Section, PVDF Seats, PTFE Balls & PO Diaphragm

The Husky 2150 air operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.

Overall improved efficiency (up to 40% more efficient)Highest fluid flow rate in its classUp to 5 times longer diaphragm life compared to other air operated diaphragm pumpsExpanded material offering to handle endless applicationsFewer parts than industry peers, the air valve is externally accessible so it can be serviced quickly and easily without uninstalling the diaphragm pump2 in. (51 mm) ANSI end-portingFluid flow up to 150 gpm (568 lpm)Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)Lube-free operationEpoxy-coated air section for tough environmental conditionsAvailable in aluminum, 316 stainless steel, ductile iron and polypropylene

GG 24N095

HUSKY PUMP, 515F-PP01AP3PVPTPOPT

Husky 515 PVDF Pump, PP Center Section, PVDF Seats, PTFE Balls & PO Diaphragm

The Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.

The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability.

Center and end porting options.No mechanical seals to cause fluid leaks or failuresRuns quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levelsEasy-to-service air valve and ball checksOperates on as little as 20 psi (1.4 bar, 0.14 MPa)Split manifold option to pump multiple fluids without mixingDelivery up to 15 gpm (56.7 lpm)Easy-to-service air valve and ball checksReliable air valve for years of dependable performance

GG 24N096

HUSKY PUMP, 515AC-PP01AA3ACPTPOPT

Husky 515 1/2 in NPT AC Pump, PP Center Section, AC Seats, PTFE Balls & PO Diaphragm

Our Husky air-operated double diaphragm pumps are loaded with features to help you get the job done right, every time, and are built to save you money. The Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability.

Rugged construction

• Resists corrosion for reliable performance and long life

Heavy-duty design

• Offers long life, increased productivity and lower overall cost of ownership

Benefits of the Husky 515 double diaphragm pump

• Center and end porting options.
• No mechanical seals to cause fluid leaks or failures
• Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels
• Easy-to-service air valve and ball checks
• Operates on as little as 20 psi (1.4 bar, 0.14 MPa)
• Split manifold option to pump multiple fluids without mixing

Fully-groundable acetal modelDelivery up to 15 gpm (56.7 lpm)Easy-to-service air valve and ball checksReliable air valve for years of dependable performanceLube-free for cleaner operationDataTrakâ„¢ available to prevent pump runaway and track material usage

GG 24N098

HUSKY PUMP, 515AC-PP01AAC4ACPTPOPT

Husky 515 1/2 in. (13 mm) BSP AC Pump, PP Center Section, AC Seats, PTFE Balls & PO Diaphragm

Our Husky air-operated double diaphragm pumps are loaded with features to help you get the job done right, every time, and are built to save you money. The Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability.

Rugged construction

• Resists corrosion for reliable performance and long life

Heavy-duty design

• Offers long life, increased productivity and lower overall cost of ownership

Benefits of the Husky 515 double diaphragm pump

• Center and end porting options.
• No mechanical seals to cause fluid leaks or failures
• Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels
• Easy-to-service air valve and ball checks
• Operates on as little as 20 psi (1.4 bar, 0.14 MPa)
• Split manifold option to pump multiple fluids without mixing

Fully-groundable acetal modelDelivery up to 15 gpm (56.7 lpm)Easy-to-service air valve and ball checksReliable air valve for years of dependable performanceLube-free for cleaner operationDataTrakâ„¢ available to prevent pump runaway and track material usage

GG 24N258

HUSKY PUMP, 716A-PP01AA1SSPTPOPT

Husky 716 AL Pump, PP Center Section, SS Seats, PTFE Balls & PO Diaphragm

The Husky 716 air operated diaphragm pump features an external controller for remote control capabilities.

Center- and end-portingNo mechanical seals which causes fluid leaks or failuresRuns quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levelsEasy-to-service air valve and ball checks3/4 in (19.05 mm) center- and end-portingNo seals to leak or failQuiet running less than 85 dBa with easy-to-use remote muffler capability for even lower noise levelsEasy-to-service air valve and ball checks

GG 24W348

ENDURA-FLO PUMP, 4:1 AODD, 150, TRI, ADV

Endura-Flo 4D150, 4:1 Air Operated Diaphragm Pump, 150cc, Tri-Clamp, DataTrakThe Endura-Flo 4D offers the industry’s highest-pressure ratio at 4:1. This easy to install pump is ideal for fluid transfer and supply, paint circulation, and piggable paint systems. Low pulsation output and smooth changeover for quick color changes ultimately save you time and money.Endure-Flo diaphragms last longer against extreme operating conditionsEasy access to critical components for fast online maintenancePumps offer low pulsation output and smooth changeover for quick color changes, saving you time and moneyMinimal solvent to flush and consistent startup pressure make it perfect for multiple color change and piggable systemsCustom mounting options include rotatable fluid manifolds, mounting brackets and spring loaded check cartridgesDataTrek option prevents runaway and tracks material usage

GG 24W349

ENDURA-FLO PUMP, 4:1 AODD, 150, NPT, ADV

Endura-Flo 4D150, 4:1 Air Operated Diaphragm Pump, 150cc, NPT, DataTrakThe Endura-Flo 4D offers the industry’s highest-pressure ratio at 4:1. This easy to install pump is ideal for fluid transfer and supply, paint circulation, and piggable paint systems. Low pulsation output and smooth changeover for quick color changes ultimately save you time and money.Endure-Flo diaphragms last longer against extreme operating conditionsEasy access to critical components for fast online maintenancePumps offer low pulsation output and smooth changeover for quick color changes, saving you time and moneyMinimal solvent to flush and consistent startup pressure make it perfect for multiple color change and piggable systemsCustom mounting options include rotatable fluid manifolds, mounting brackets and spring loaded check cartridgesDataTrek option prevents runaway and tracks material usage

GG 24W350

ENDURA-FLO PUMP, 4:1 AODD, 150, BSP, ADV

Endura-Flo 4D150, 4:1 Air Operated Diaphragm Pump, 150cc, BSPP, DataTrakThe Endura-Flo 4D offers the industry’s highest-pressure ratio at 4:1. This easy to install pump is ideal for fluid transfer and supply, paint circulation, and piggable paint systems. Low pulsation output and smooth changeover for quick color changes ultimately save you time and money.Endure-Flo diaphragms last longer against extreme operating conditionsEasy access to critical components for fast online maintenancePumps offer low pulsation output and smooth changeover for quick color changes, saving you time and moneyMinimal solvent to flush and consistent startup pressure make it perfect for multiple color change and piggable systemsCustom mounting options include rotatable fluid manifolds, mounting brackets and spring loaded check cartridgesDataTrek option prevents runaway and tracks material usage

GG 24W353

ENDURA-FLO PUMP, 4:1 AODD, 350, BSP, STD

Endura-Flo 4D350, 4:1 Air Operated Diaphragm Pump, 350cc, BSPPThe Endura-Flo 4D offers the industry’s highest-pressure ratio at 4:1. This easy to install pump is ideal for fluid transfer and supply, paint circulation, and piggable paint systems. Low pulsation output and smooth changeover for quick color changes ultimately save you time and money.Endure-Flo diaphragms last longer against extreme operating conditionsEasy access to critical components for fast online maintenancePumps offer low pulsation output and smooth changeover for quick color changes, saving you time and moneyMinimal solvent to flush and consistent startup pressure make it perfect for multiple color change and piggable systemsCustom mounting options include rotatable fluid manifolds, mounting brackets and spring loaded check cartridges

GG 24W758

HUSKY PUMP, 1050HP, A01AS1SSSPSSPT

Husky 1050HP 1 in. (25.4 mm) NPT SS Pump, AL Center Section, SS Seats, SP Balls & SP Diaphragm

The Husky 1050HP air-operated diaphragm pump is the first pump on the market that allows users to choose between low pressure and high pressure operating modes with Graco’s low-high pressure mode valve. High pressure operation isn’t always required, so switch to the low pressure mode to reduce air consumption up to 50%. These features combined with the quality and reliability of our standard Husky diaphragm pump design make this one of the most unique high pressure diaphragm pumps on the market.

Benefits of the Husky 1050HP Double Diaphragm Pump

• Increased fluid pressure without sacrificing flow
• Low-high pressure mode valve lets you operate the pump as a standard AODD or a high pressure AODD
• Reduce air consumption up to 50% with the low pressure mode
• Same repair parts as the Husky 1050 diaphragm pump

External Pilots

• Ease of maintenance
• Reduced down-time (quick change time)
• Spring loaded for faster change over

Modular Air Valve

• Ease of maintenance
• Stall and lube free

Fluid Manifold

• Stainless Steel or Aluminum

Additional Diaphragm

• For high pressure operation

Low/High Pressure Operation Valve

• Selectable operating setting
• Reduces air consumption
• Only use high pressure when required

Wetted Components

• Utilizes same parts as Husky 1050 which reduces repair part inventory

GG 24W762

HUSKY PUMP, 1050HP, SP/SP/SP/A

Husky 1050HP 1 in. (25.4 mm) NPT AL Pump, AL Center Section, SP Seats, SP Balls & SP Diaphragm

The Husky 1050HP air-operated diaphragm pump is the first pump on the market that allows users to choose between low pressure and high pressure operating modes with Graco’s low-high pressure mode valve. High pressure operation isn’t always required, so switch to the low pressure mode to reduce air consumption up to 50%. These features combined with the quality and reliability of our standard Husky diaphragm pump design make this one of the most unique high pressure diaphragm pumps on the market.

Benefits of the Husky 1050HP Double Diaphragm Pump

• Increased fluid pressure without sacrificing flow
• Low-high pressure mode valve lets you operate the pump as a standard AODD or a high pressure AODD
• Reduce air consumption up to 50% with the low pressure mode
• Same repair parts as the Husky 1050 diaphragm pump

External Pilots

• Ease of maintenance
• Reduced down-time (quick change time)
• Spring loaded for faster change over

Modular Air Valve

• Ease of maintenance
• Stall and lube free

Fluid Manifold

• Stainless Steel or Aluminum

Additional Diaphragm

• For high pressure operation

Low/High Pressure Operation Valve

• Selectable operating setting
• Reduces air consumption
• Only use high pressure when required

Wetted Components

• Utilizes same parts as Husky 1050 which reduces repair part inventory

GG 24X421

CHEMSAFE PUMP, 1590PT-P01A-PT3-PT-PT-PO

ChemSafe 1590 Air Operated Double Diaphragm Plastic Pump with NPT Port

Graco's ChemSafe pumps feature PTFE or UHMWPE (ultra high molecular weight polyethylene) corrosion-resistant fluid paths, which make them ideal for corrosive and abrasive chemicals. There's no exposed metals and they can be configured in various materials to meet most abrasion, temperature, and chemical compatibility requirements. Plus they're dead-head capable and achieve high flow rates while minimizing air consumption and operational noise.

Max flow rate of 85.2 gpm (322 lpm)High quality machined design provides a precision fit and superior chemical containment compared to molded pumpsCorrosion-resistant exterior with no exposed metal reduces maintenance, extends pump life and offers clean, safe operationRemovable air motor offers easy and intuitive maintenance ensuring maximum pump performance and availabilityIdeal for corrosive and abrasive liquids such as acids, fuels, glues, paints, resins, inks, or wastewater
