Air Motors
Motor
IR 3800U
Inline Multi-Vane Air Motor, 3/4" Keyed Shaft, 220 RPM, 1.45 HP, 189 NM, Non-reversible
- Air Consumption at Max HP (scfm): 48
- Air Inlet: 1/2" NPT
- Air Pressure (psi): 90
- Drive Size (in): 3/4
- Drive Type: Round Keyed
- Exhaust Location: Rear
- Finish: Black Oxide
- Gear Reduction: Double
- Gear Train: Planetary
- Housing Material: Steel
- Keyaway Length (in): 1.5
- Max Free Speed (rpm): 220
- Max Pressure (bar): 6.2
- Max Torque (ft-lb): 139
- Max Torque (in-lb): 1673
- Max Torque (nm): 189
- Motor: Rotary Vane
- Motor: In line
- Mounting Type: Face
- Number of Mounting Holes: 6
- Power Source: Air Powered
- Product Length (in): 8.69
- Product Width (in): 3.25
- Product Height (in): 3.25
- Product Weight (lb): 8.5
- Rated Power (hp): 1.45
- Rated Power (kW): 1.08
- Reversible: Non-reversible
- Speed at Max Power (rpm): 105
- Standards/Certifications: ATEX
- Starting Torque (ft-lb): 105
- Starting Torque (nm): 142
- Warranty: 1-year
Motor
IR 3840Q
Inline Multi-Vane Air Motor, 3/4" Keyed Shaft, 280 RPM, 1.35 HP, 106 NM, Reversible
- Air Consumption at Max HP (scfm): 44
- Air Inlet: 1/2" NPT
- Air Pressure (psi): 90
- Drive Size (in): 3/4
- Drive Type: Round Keyed
- Exhaust Location: Rear
- Finish: Black Oxide
- Gear Reduction: Double
- Gear Train: Planetary
- Housing Material: Steel
- Keyaway Length (in): 1.5
- Max Free Speed (rpm): 280
- Max Pressure (bar): 6.2
- Max Torque (ft-lb): 78
- Max Torque (in-lb): 938
- Max Torque (nm): 106
- Motor: Rotary Vane
- Motor: In line
- Mounting Type: Face
- Number of Mounting Holes: 6
- Power Source: Air Powered
- Product Length (in): 8.69
- Product Width (in): 3.25
- Product Height (in): 3.25
- Product Weight (lb): 8.75
- Rated Power (hp): 1.35
- Rated Power (kW): 1.01
- Reversible: Reversible
- Speed at Max Power (rpm): 130
- Standards/Certifications: ATEX
- Starting Torque (ft-lb): 60
- Starting Torque (nm): 81.4
- Warranty: 1-year
Motor
IR 3840R
Inline Multi-Vane Air Motor, 3/4" Keyed Shaft, 238 RPM, 1.35 HP, 125 NM, Reversible
- Air Consumption at Max HP (scfm): 44
- Air Inlet: 1/2" NPT
- Air Pressure (psi): 90
- Drive Size (in): 3/4
- Drive Type: Round Keyed
- Exhaust Location: Rear
- Finish: Black Oxide
- Gear Reduction: Double
- Gear Train: Planetary
- Housing Material: Steel
- Keyaway Length (in): 1.5
- Max Free Speed (rpm): 238
- Max Pressure (bar): 6.2
- Max Torque (ft-lb): 92
- Max Torque (in-lb): 1106
- Max Torque (nm): 125
- Motor: Rotary Vane
- Motor: In line
- Mounting Type: Face
- Number of Mounting Holes: 6
- Power Source: Air Powered
- Product Length (in): 8.69
- Product Width (in): 3.25
- Product Height (in): 3.25
- Product Weight (lb): 8.75
- Rated Power (hp): 1.35
- Rated Power (kW): 1.01
- Reversible: Reversible
- Speed at Max Power (rpm): 122
- Standards/Certifications: ATEX
- Starting Torque (ft-lb): 69
- Starting Torque (nm): 93
- Warranty: 1-year
Motor
IR 4800M
Inline Multi-Vane Air Motor, 1" Keyed Shaft, 1050 RPM, 3.7 HP, 93.6 NM, Non-reversible
Description: The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.
Features And Benefits:
- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you'll be able to spend more time focused on the job.
Product Application and Uses:
Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
- Air Consumption at Max HP (scfm): 95
- Air Inlet: 1/2" NPT
- Air Pressure (psi): 90
- Drive Size (in): 1
- Drive Type: Round Keyed
- Exhaust Location: Rear
- Finish: Black Oxide
- Gear Reduction: Single
- Gear Train: Planetary
- Housing Material: Steel
- Max Free Speed (rpm): 1050
- Max Pressure (bar): 6.2
- Max Torque (ft-lb): 69
- Max Torque (in-lb): 828
- Max Torque (nm): 93.6
- Motor: Rotary Vane
- Motor: In line
- Mounting Type: Face
- Number of Mounting Holes: 6
- Power Source: Air Powered
- Product Length (in): 11.38
- Product Width (in): 4
- Product Height (in): 4
- Product Weight (lb): 15.25
- Rated Power (hp): 3.7
- Rated Power (kW): 2.76
- Reversible: Non-reversible
- Speed at Max Power (rpm): 560
- Standards/Certifications: ATEX
- Starting Torque (ft-lb): 51
- Starting Torque (nm): 69.2
- Warranty: 1-year
- Parts: 518-104
- Parts: R4901-102
Air Motor, 3.5 HP, Non-Reversable
IR 4800Q
Inline Multi-Vane Air Motor, 1" Keyed Shaft, 375 RPM, 3.5 HP, 235 NM, Non-reversible
Description: The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.
Features And Benefits:
- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you'll be able to spend more time focused on the job.
Product Application and Uses:
Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
- Air Consumption at Max HP (scfm): 95
- Air Inlet: 1/2" NPT
- Air Pressure (psi): 90
- Drive Size (in): 1
- Drive Type: Round Keyed
- Exhaust Location: Rear
- Finish: Black Oxide
- Gear Reduction: Double
- Gear Train: Planetary
- Housing Material: Steel
- Max Free Speed (rpm): 375
- Max Pressure (bar): 6.2
- Max Torque (ft-lb): 173
- Max Torque (in-lb): 2080
- Max Torque (nm): 235
- Motor: Rotary Vane
- Motor: In line
- Mounting Type: Face
- Number of Mounting Holes: 6
- Power Source: Air Powered
- Product Length (in): 11.38
- Product Width (in): 4
- Product Height (in): 4
- Product Weight (lb): 19.75
- Rated Power (hp): 3.5
- Rated Power (kW): 2.61
- Reversible: Non-reversible
- Speed at Max Power (rpm): 194
- Standards/Certifications: ATEX
- Starting Torque (ft-lb): 129
- Starting Torque (nm): 175
- Warranty: 1-year
- Parts: 518-104
- Parts: R4901-102
Motor
IR 4800S
Inline Multi-Vane Air Motor, 1" Keyed Shaft, 275 RPM, 3.5 HP, 323 NM, Non-reversible
Description: The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.
Features And Benefits:
- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you'll be able to spend more time focused on the job.
Product Application and Uses:
Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
- Air Consumption at Max HP (scfm): 95
- Air Inlet: 1/2" NPT
- Air Pressure (psi): 90
- Drive Size (in): 1
- Drive Type: Round Keyed
- Exhaust Location: Rear
- Finish: Black Oxide
- Gear Reduction: Double
- Gear Train: Planetary
- Housing Material: Steel
- Max Free Speed (rpm): 275
- Max Pressure (bar): 6.2
- Max Torque (ft-lb): 238
- Max Torque (in-lb): 2859
- Max Torque (nm): 323
- Motor: Rotary Vane
- Motor: In line
- Mounting Type: Face
- Number of Mounting Holes: 6
- Power Source: Air Powered
- Product Length (in): 11.38
- Product Width (in): 4
- Product Height (in): 4
- Product Weight (lb): 19.75
- Rated Power (hp): 3.5
- Rated Power (kW): 2.61
- Reversible: Non-reversible
- Speed at Max Power (rpm): 146
- Standards/Certifications: ATEX
- Starting Torque (ft-lb): 178
- Starting Torque (nm): 241
- Warranty: 1-year
- Parts: 518-104
- Parts: R4901-102
Motor
IR 4800U
Inline Multi-Vane Air Motor, 1" Keyed Shaft, 185 RPM, 3.5 HP, 480 NM, Non-reversible
Description: The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.
Features And Benefits:
- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you'll be able to spend more time focused on the job.
Product Application and Uses:
Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
- Air Consumption at Max HP (scfm): 95
- Air Inlet: 1/2" NPT
- Air Pressure (psi): 90
- Drive Length (in): 2.25
- Drive Size (in): 1
- Drive Type: Round Keyed
- Exhaust Location: Rear
- Finish: Black Oxide
- Gear Ratio: 53.5:1
- Gear Reduction: Double
- Gear Train: Planetary
- Housing Material: Steel
- Keyaway Length (in): 1.625
- Max Free Speed (rpm): 185
- Max Pressure (bar): 6.2
- Max Torque (ft-lb): 354
- Max Torque (in-lb): 4248
- Max Torque (nm): 480
- Motor: Rotary Vane
- Motor: In line
- Mounting Type: Face
- Number of Mounting Holes: 6
- Operating Temperature Range: 0F to 150F
- Power Source: Air Powered
- Product Length (in): 11.38
- Product Width (in): 4
- Product Height (in): 4
- Product Weight (lb): 19.75
- Rated Power (hp): 3.5
- Rated Power (kW): 2.61
- Reversible: Non-reversible
- Speed at Max Power (rpm): 97
- Standards/Certifications: ATEX
- Starting Torque (ft-lb): 265
- Starting Torque (nm): 359
- Warranty: 1-year
- Parts: 518-104
- Parts: R4901-102
Motor
IR 4840Q
Inline Multi-Vane Air Motor, 1" Keyed Shaft, 350 RPM, 3 HP, 224 NM, Reversible
Features And Benefits:
- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you'll be able to spend more time focused on the job.
Product Application and Uses:
Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
- Air Consumption at Max HP (scfm): 95
- Air Inlet: 1/2" NPT
- Air Pressure (psi): 90
- Drive Size (in): 1
- Drive Type: Round Keyed
- Exhaust Location: Rear
- Finish: Black Oxide
- Gear Reduction: Double
- Gear Train: Planetary
- Housing Material: Steel
- Max Free Speed (rpm): 350
- Max Pressure (bar): 6.2
- Max Torque (ft-lb): 165
- Max Torque (in-lb): 1983
- Max Torque (nm): 224
- Motor: Rotary Vane
- Motor: In line
- Mounting Type: Face
- Number of Mounting Holes: 6
- Power Source: Air Powered
- Product Length (in): 11.38
- Product Width (in): 4
- Product Height (in): 4
- Product Weight (lb): 20.13
- Rated Power (hp): 3
- Rated Power (kW): 2.24
- Reversible: Reversible
- Speed at Max Power (rpm): 167
- Standards/Certifications: ATEX
- Starting Torque (ft-lb): 123
- Starting Torque (nm): 167
- Warranty: 1-year
- Parts: 518-104
- Parts: R4901-102
Motor 3.7HP, 230/1/60 w/ 12 In. Cord SS3L3
IR 56283138
Motor 3.7HP, 230/1/60 w/ 12 In. Cord SS3L3
