Air Motors
MOTOR
IR M002RHR021AR3
IR M002RHR021AR3
Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 1165 RPM, 0.19 HP, 3.9 NM, Non-reversible
Features And Benefits- Safety: Meets ATEX Standards
Air Consumption at Max HP (scfm): 11.8
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide and Anodize
Gear Ratio: 21:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1165
Max Pressure (bar): 6.2
Max Torque (ft-lb): 2.9
Max Torque (in-lb): 35
Max Torque (nm): 3.9
Motor: Rotary Vane
Motor: In line
Mounting Type: Flanged Mounting
Number of Mounting Holes: 2
Power Source: Air Powered
Product Weight (lb): 1.13
Rated Power (hp): 0.19
Rated Power (kW): 0.14
Reversible: Non-reversible
Speed at Max Power (rpm): 555
Standards/Certifications: ATEX
Starting Torque (ft-lb): 2.2
Starting Torque (nm): 2.93
Warranty: 1-year
$1,640.00
MOTOR
IR M002RVR044AR3
IR M002RVR044AR3
Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 485 RPM, 0.14 HP, 7.16 NM, Reversible
Features And Benefits- Safety: Meets ATEX Standards
Air Consumption at Max HP (scfm): 9.6
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide and Anodize
Gear Ratio: 44:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 485
Max Pressure (bar): 6.2
Max Torque (ft-lb): 5.3
Max Torque (in-lb): 63
Max Torque (nm): 7.16
Motor: Rotary Vane
Motor: In line
Mounting Type: Flanged Mounting
Number of Mounting Holes: 2
Power Source: Air Powered
Product Weight (lb): 1.13
Rated Power (hp): 0.14
Rated Power (kW): 0.1
Reversible: Reversible
Speed at Max Power (rpm): 240
Standards/Certifications: ATEX
Starting Torque (ft-lb): 4.0
Starting Torque (nm): 5.37
Warranty: 1-year
$1,522.20
Power Motor
AA 8229-1A
AA 8229-1A
Inline Multi-Vane Air Motor, 3/8"-24 Thd Spindle, 19000 RPM, 0.6 HP, 0.9 NM, Non-reversible
- Air Consumption at Max HP (scfm): 41
- Air Inlet: 1/4" NPT
- Air Pressure (psi): 90
- Arbor/Collet: 3/8"-24 Thread
- Drive Type: Threaded
- Exhaust Location: Exterior Muffler
- Finish: Black Oxide
- Gear Ratio: 1:1
- Gear Reduction: Direct Drive
- Gear Train: Planetary
- Housing Material: Steel
- Max Free Speed (rpm): 19000
- Max Pressure (bar): 6.2
- Max Torque (ft-lb): 0.7
- Max Torque (in-lb): 8.0
- Max Torque (nm): 0.9
- Motor: Rotary Vane
- Motor: In line
- Mounting Type: Foot Mount Optional
- Power Source: Air Powered
- Product Weight (lb): 2.45
- Rated Power (hp): 0.6
- Rated Power (kW): 0.45
- Reversible: Non-reversible
- Sound Level dB(A): 80
- Speed at Max Power (rpm): 9800
- Torque Output @ Max HP (ft-lb): 0.3
- Torque Output @ Max HP (nm): 0.4
- Warranty: 1-year
- Parts: 37896
$1,840.00
Air Motor Drive, Agitator-Rigid Mounting
BB 31-450
BB 31-450
Air Motor Drive, Agitator-Rigid Mounting
$1,724.00
