Air Motors

GG N22LH0

GG N22LN0

GG N22LT0

GG N22RN0

GG N34LH0

GG N34LN0

GG N34LT0

GG N34RN0

GG N65DT0

GG N65LH0

IR 150BMPD88R54-020R

IR 150BMPE88R54-000

IR 150TJPF88R54-30O

IR 1801N

Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 1990 RPM, 1.4 HP, 19 NM, Non-reversible

• Air Consumption at Max HP (scfm): 46
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Drive Size (in): 5/8
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Ratio: 1:1
• Gear Reduction: Direct Drive
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 1990
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 14
• Max Torque (in-lb): 168
• Max Torque (nm): 19
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 2
• Power Source: Air Powered

• Product Weight (lb): 5.38
• Rated Power (hp): 1.4
• Rated Power (kW): 1.04
• Reversible: Non-reversible

• Speed at Max Power (rpm): 918
• Starting Torque (ft-lb): 10
• Starting Torque (nm): 14.2

• Warranty: 1-year

• Parts: R1801-A123

IR 1801P

Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 1050 RPM, 1.35 HP, 31.2 NM, Non-reversible

• Air Consumption at Max HP (scfm): 46
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Drive Size (in): 5/8
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 1050
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 23
• Max Torque (in-lb): 276
• Max Torque (nm): 31.2
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 2
• Power Source: Air Powered
• Product Length (in): 8.5

• Product Weight (lb): 5.75
• Rated Power (hp): 1.35
• Rated Power (kW): 1.01
• Reversible: Non-reversible

• Speed at Max Power (rpm): 500
• Starting Torque (ft-lb): 17
• Starting Torque (nm): 23.3

• Warranty: 1-year

• Parts: R1801-A123

IR 1801Q

Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 650 RPM, 1.35 HP, 54.2 NM, Non-reversible

• Air Consumption at Max HP (scfm): 46
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Drive Size (in): 5/8
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 650
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 40
• Max Torque (in-lb): 480
• Max Torque (nm): 54.2
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 2
• Power Source: Air Powered

• Product Weight (lb): 5.75
• Rated Power (hp): 1.35
• Rated Power (kW): 1.01
• Reversible: Non-reversible

• Speed at Max Power (rpm): 300
• Starting Torque (ft-lb): 30
• Starting Torque (nm): 40.7

• Warranty: 1-year

• Parts: R1801-A123

IR 1801W

Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 370 RPM, 1.35 HP, 94.9 NM, Non-reversible

• Air Consumption at Max HP (scfm): 46
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Drive Size (in): 5/8
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 370
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 70
• Max Torque (in-lb): 840
• Max Torque (nm): 94.9
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 2
• Power Source: Air Powered

• Product Weight (lb): 5.75
• Rated Power (hp): 1.35
• Rated Power (kW): 1.01
• Reversible: Non-reversible

• Speed at Max Power (rpm): 175
• Starting Torque (ft-lb): 52
• Starting Torque (nm): 70.5

• Warranty: 1-year

• Parts: R1801-A123

IR 1841N

Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 1700 RPM, 1.2 HP, 17 NM, Reversible

• Air Consumption at Max HP (scfm): 43
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Drive Size (in): 5/8
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 1700
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 13
• Max Torque (in-lb): 150
• Max Torque (nm): 17
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 2
• Power Source: Air Powered

• Product Weight (lb): 5.5
• Rated Power (hp): 1.2
• Rated Power (kW): 0.89
• Reversible: Reversible

• Speed at Max Power (rpm): 800
• Starting Torque (ft-lb): 9.3
• Starting Torque (nm): 12.6

• Warranty: 1-year

• Parts: R1801-A123

IR 1841P

Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 900 RPM, 1.1 HP, 27.1 NM, Reversible

• Air Consumption at Max HP (scfm): 43
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Drive Size (in): 5/8
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 900
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 20
• Max Torque (in-lb): 240
• Max Torque (nm): 27.1
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 2
• Power Source: Air Powered

• Product Weight (lb): 5.88
• Rated Power (hp): 1.1
• Rated Power (kW): 0.82
• Reversible: Reversible

• Speed at Max Power (rpm): 430
• Starting Torque (ft-lb): 15
• Starting Torque (nm): 20.3

• Warranty: 1-year

• Parts: R1801-A123

IR 1841W

Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 320 RPM, 1.1 HP, 81.4 NM, Reversible

• Air Consumption at Max HP (scfm): 43
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Drive Size (in): 5/8
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 320
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 60
• Max Torque (in-lb): 720
• Max Torque (nm): 81.4
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 2
• Power Source: Air Powered

• Product Weight (lb): 5.88
• Rated Power (hp): 1.1
• Rated Power (kW): 0.82
• Reversible: Reversible

• Speed at Max Power (rpm): 150
• Starting Torque (ft-lb): 45
• Starting Torque (nm): 61

• Warranty: 1-year

• Parts: R1801-A123

IR 34RA017

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 325 RPM, 4.1 HP, 311 NM, Reversible

• Air Consumption at Max HP (scfm): 183
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Drive Size (in): 1-1/2
• Drive Type: Round Keyed

• Exhaust Location: Side
• Finish: Paint, Yellow
• Gear Reduction: Single
• Gear Train: Spur Gear

• Housing Material: Steel Motor, Aluminum Gear Housing

• Max Free Speed (rpm): 325
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 229
• Max Torque (in-lb): 2753
• Max Torque (nm): 311
• Motor: Rotary Vane
• Motor: Spur Gear
• Mounting Type: Foot and Face

• Power Source: Air Powered

• Product Weight (lb): 43
• Rated Power (hp): 4.1
• Rated Power (kW): 3.06
• Reversible: Reversible

• Speed at Max Power (rpm): 168
• Starting Torque (ft-lb): 148
• Starting Torque (nm): 201

• Warranty: 1-year

IR 34RA022

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 245 RPM, 4.1 HP, 408 NM, Reversible

• Air Consumption at Max HP (scfm): 183
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Drive Size (in): 1-1/2
• Drive Type: Round Keyed

• Exhaust Location: Side
• Finish: Paint, Yellow
• Gear Reduction: Single
• Gear Train: Spur Gear

• Housing Material: Steel Motor, Aluminum Gear Housing

• Max Free Speed (rpm): 245
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 301
• Max Torque (in-lb): 3611
• Max Torque (nm): 408
• Motor: Rotary Vane
• Motor: Spur Gear
• Mounting Type: Foot and Face

• Power Source: Air Powered

• Product Weight (lb): 43
• Rated Power (hp): 4.1
• Rated Power (kW): 3.06
• Reversible: Reversible

• Speed at Max Power (rpm): 128
• Starting Torque (ft-lb): 195
• Starting Torque (nm): 264

• Warranty: 1-year

IR 34RB029

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 187 RPM, 4 HP, 507 NM, Reversible

• Air Consumption at Max HP (scfm): 180
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Drive Size (in): 1-1/2
• Drive Type: Round Keyed

• Exhaust Location: Side
• Finish: Paint, Yellow
• Gear Reduction: Double
• Gear Train: Spur Gear

• Housing Material: Steel Motor, Aluminum Gear Housing

• Max Free Speed (rpm): 187
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 374
• Max Torque (in-lb): 4487
• Max Torque (nm): 507
• Motor: Rotary Vane
• Motor: Spur Gear
• Mounting Type: Foot and Face

• Power Source: Air Powered

• Product Weight (lb): 75
• Rated Power (hp): 4
• Rated Power (kW): 2.98
• Reversible: Reversible

• Speed at Max Power (rpm): 99
• Starting Torque (ft-lb): 224
• Starting Torque (nm): 304

• Warranty: 1-year

IR 34RB045

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 121 RPM, 4 HP, 788 NM, Reversible

• Air Consumption at Max HP (scfm): 180
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Drive Size (in): 1-1/2
• Drive Type: Round Keyed

• Exhaust Location: Side
• Finish: Paint, Yellow
• Gear Reduction: Double
• Gear Train: Spur Gear

• Housing Material: Steel Motor, Aluminum Gear Housing

• Max Free Speed (rpm): 121
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 581
• Max Torque (in-lb): 6974
• Max Torque (nm): 788
• Motor: Rotary Vane
• Motor: Spur Gear
• Mounting Type: Foot and Face

• Power Source: Air Powered

• Product Weight (lb): 75
• Rated Power (hp): 4
• Rated Power (kW): 2.98
• Reversible: Reversible

• Speed at Max Power (rpm): 63
• Starting Torque (ft-lb): 348
• Starting Torque (nm): 472

• Warranty: 1-year

IR 3800M2/A123
