INGERSOLL-RAND IR TOOL S12880

IR 216B-A165

IR 2175-K48

IR 2190-A92

IR 216B-728

IR 2175-283

IR 2190-SRK1

IR 2190-K303

IR 2190-TK1

Tune-up Kit for Ingersoll Rand 2190 Series Impact Wrench

• Includes: (1) Vane pack, (1) Spring, (1) Front Rotor Bearing, (1) Rear Rotor Bearing, (2) Gasket, (2) O-Ring, (2) Snap Ring, (1) Spring pack

IR 22040679

IR 2171P

1" Air Impact Wrench, 1250 ft-lb Torque, Pin Retainer, Pistol

Description: The metal housing and steel hammer case of the 2171 Series Impact Wrench makes this one of the toughest tools on the market. You'll also benefit from the twin hammer impact mechanism, which provides a more even impact with every blow and makes it less sensitive to changes in air pressure.

Features And Benefits:

• Durability: This heavy-duty impact wrench is tough enough to handle harsh environments and repeated drops.
• Versatility: The 2171 Series is an ideal impact wrench for use in multiple markets, from vehicle repair and heavy machinery to general industrial and facility maintenance.
• Increased Safety: The square pin drive of the 2171 Series provides the strongest connection to the socket to increase safety, especially when doing overhead work.

Product Application and Uses:

Ideal impact wrench for use in multiple markets, from vehicle repair and heavy machinery to general industrial and facility maintenance.

• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 46
• Air Consumption @ Load (l/min): 1303
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 55
• Average Air Consumption (l/min): 1558

• Blows per Min: 1025

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Maintenance Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 97.7 / 108.7

• Hammer Case: Steel
• Handle Material: Composite
• Housing Material: Aluminum core with composite sleeve
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 95.3 / 106.3

• Max Bolt Diameter (in): 1
• Max Free Speed (rpm): 6000
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1250
• Max Torque (in-lb): 15002
• Max Torque (nm): 1695
• Min Hose Size (in): 1/2
• Motor: Reverse Bias

• Number of Power Settings: 3
• Power Source: Air Powered
• Product Length (in): 8.5

• Product Width (in): 3.5
• Product Height (in): 9.5
• Product Weight (lb): 12.32
• Recommended Forward Torque Range (ft-lb): 300-1000
• Recommended Forward Torque Range (in-lb): 3602-12002
• Recommended Forward Torque Range (nm): 407-1356
• Retainer Type: Pin Detent

• Side to Center Distance (in): 1.75
• Side to Center Distance (mm): 44

• Speed Setting: Variable Speed
• Standards/Certifications: CE

• Tool Type: Full-size
• Vanes: 6
• Vibration Level (m/s2): 11.5
• Warranty: 1-year

• Lubrication: 50P
• Parts: 2141-THK1
• Parts: 2161-36

• Parts: 2161-739
• Parts: 2161-TK2

IR 2236QTiMAX-2

Description: Ingersoll Rand has delivered the gold standard in pneumatic tools for almost 100 years - and the performance, durability, and power of the 2236 1/2 pneumatic impact is no different. Our patented Drive Xchange System lets you swap out anvils without torque-zapping adapters and extenders. Plus, a powerful motor, durable build, and quiet, efficient operation make the 2236 model the perfect choice for serious technicians. Powerful Versatility: Say goodbye to that drawer full of adapters for good. The Ingersoll Rand 2236 Pneumatic 1/2 inch impact wrench has an interchangeable anvil system that lets you tailor your tool to whatever job is at hand - without losing a single ft-lb of power. Innovation: Ingersoll Rands patented Drive Xchange System helps you get more versatility, torque, and control out of your impact wrench. Torque: The 2236 series operates with 1,500 ft-lbs of breakaway torque.

Features And Benefits:

• Patented Drive Xchange System: Helps you get more versatility, torque, and control out of your impact wrench. With 3/8," 1/2in, and 3/4" drive options and 5 different anvil lengths ranging from 2 to 10 inches, you can do more work with less equipment.
• Powerful Versatility: 1,500 ft.-lbs. of breakaway torque from a unique patented motor design.
• Quiet: 4 decibels quieter running from a patented motor design.
• Patented Direct Greasing System: Greasing your tool has never been easier. Directly grease the tools hammer for more efficient operation and increased run time.
• Reliable Performance: Stay working, and at peak power by quickly replacing worn or broken anvils.
• Ergonomic: Smaller, lighter and better balanced design under 4.5 lbs. and 7.4" overall length.
• Includes 1/2 square drive 2" extended anvil (EA42H)

Product Application and Uses:

Vehicle Repair

• Includes: DXS2 1/2in Square Drive 2" Extended Anvil (EA42H). Compatible with all DXS2 anvils and sockets. 3/8 and 3/4 drive size options as well as extended lengths sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 36
• Air Consumption @ Load (l/min): 1090
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Anvil Length: 2" Extended
• Average Air Consumption (cfm): 9
• Average Air Consumption (l/min): 255

IR 2235TIMAX-D727

IR 2235-638

Hammer Case Screw for Ingersoll Rand 2235 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2235 Series Impact Wrench

• Includes: (4) Hammercase Screws

• For Use With: 2235QPTIMAX
• For Use With: 2235TIMAX-2
• For Use With: 2235QTIMAX
• For Use With: 2235QTIMAX-G
• For Use With: 2235TIMAX-G
• For Use With: 2235TIMAX
• For Use With: 2235QTIMAX-2
• For Use With: 2235TIMAX-R
• For Use With: 2235PTIMAX

IR 2235-36RD

Hammer Case Gasket for Ingersoll Rand 2235 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2235 Series Impact Wrench

• For Use With: 2235QPTIMAX
• For Use With: 2235TIMAX-2
• For Use With: 2235QTIMAX
• For Use With: 2235QTIMAX-G
• For Use With: 2235TIMAX-G
• For Use With: 2235TIMAX
• For Use With: 2235QTIMAX-2
• For Use With: 2235TIMAX-R
• For Use With: 2235PTIMAX

IR 2235-11

End Plate for Ingersoll Rand 2235 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2235 Series Impact Wrench

• For Use With: 2235QPTIMAX
• For Use With: 2235TIMAX-2
• For Use With: 2235QTIMAX
• For Use With: 2235QTIMAX-G
• For Use With: 2235TIMAX-G
• For Use With: 2235TIMAX
• For Use With: 2235QTIMAX-2
• For Use With: 2235TIMAX-R
• For Use With: 2235PTIMAX

IR 2235-A626

Anvil for Ingersoll Rand 2235 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand standard anvil hog ring 2235 series Impact wrenches.

• Anvil Length: Standard

• Drive Size (in): 1/2
• Drive Type: Square

• Retainer Type: Friction Ring

• For Use With: 2235TIMAX-O
• For Use With: 2235QTIMAX
• For Use With: 2235QTIMAX-G
• For Use With: 2235TIMAX-G
• For Use With: 2235TIMAX
• For Use With: 2235TIMAX-R

IR 2235-11X

Wear Plate for Ingersoll Rand 2235 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2235 Series Impact Wrench

• For Use With: 2235QPTIMAX
• For Use With: 2235TIMAX-2
• For Use With: 2235QTIMAX
• For Use With: 2235QTIMAX-G
• For Use With: 2235TIMAX-G
• For Use With: 2235TIMAX
• For Use With: 2235QTIMAX-2
• For Use With: 2235TIMAX-R
• For Use With: 2235PTIMAX

IR 2235-42-7

Vane Pack for Ingersoll Rand 2235 Series Impact Wrench, Set of 7

Product Application and Uses:

For use with Ingersoll Rand 2235 Series Impact Wrench

• Includes: (7) Vanes

• For Use With: 2235QPTIMAX
• For Use With: 2235TIMAX-2
• For Use With: 2235QTIMAX
• For Use With: 2235QTIMAX-G
• For Use With: 2235TIMAX-G
• For Use With: 2235TIMAX
• For Use With: 2235QTIMAX-2
• For Use With: 2235TIMAX-R
• For Use With: 2235PTIMAX

IR 2235-THK1

Hammer Mechanism Kit for Ingersoll Rand 2235 Series Impact Wrench

Product Application and Uses:

Tool Boot for 2235 Series impact wrenches

• Includes: Hammer frame, Hammer (2), Hammer pin

• For Use With: 2235QPTIMAX
• For Use With: 2235TIMAX-2
• For Use With: 2235QTIMAX
• For Use With: 2235QTIMAX-G
• For Use With: 2235TIMAX-G
• For Use With: 2235TIMAX
• For Use With: 2235QTIMAX-2
• For Use With: 2235TIMAX-R
• For Use With: 2235PTIMAX

• Parts: 2235TIMAX-O

IR 2235MAX-A40

Housing for Ingersoll Rand 2235 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2235 Series Impact Wrench

• For Use With: 2235TIMAX-2
• For Use With: 2235TIMAX
• For Use With: 2235PTIMAX

IR 2235-53

IR 2235-TK1

Tune-up Kit for Ingersoll Rand 2235 Series Impact Wrench

Product Application and Uses:

Tool Boot for 2235 Series impact wrenches

• For Use With: 2235QPTIMAX
• For Use With: 2235TIMAX-2
• For Use With: 2235QTIMAX
• For Use With: 2235QTIMAX-G
• For Use With: 2235TIMAX-G
• For Use With: 2235TIMAX
• For Use With: 2235QTIMAX-2
• For Use With: 2235TIMAX-R
• For Use With: 2235PTIMAX

• Parts: 2235TIMAX-O

IR 2236QTiMAX

Description: Ingersoll Rand has delivered the gold standard in pneumatic tools for almost 100 years - and the performance, durability, and power of the 2236 1/2 pneumatic impact is no different. Our patented Drive Xchange System lets you swap out anvils without torque-zapping adapters and extenders. Plus, a powerful motor, durable build, and quiet, efficient operation make the 2236 model the perfect choice for serious technicians. Powerful Versatility: Say goodbye to that drawer full of adapters for good. The Ingersoll Rand 2236 Pneumatic 1/2 inch impact wrench has an interchangeable anvil system that lets you tailor your tool to whatever job is at hand - without losing a single ft-lb of power. Innovation: Ingersoll Rand's patented Drive Xchange System helps you get more versatility, torque, and control out of your impact wrench. Torque: The 2236 series operates with 1,500 ft-lbs of breakaway torque.

Features And Benefits:

• Patented Drive Xchange System: Helps you get more versatility, torque, and control out of your impact wrench. With 3/8,inch 1/2 inch , and 3/4 inch drive options and 5 different anvil lengths ranging from 2 to 10 inch, you can do more work with less equipment.
• Powerful Versatility: 1,500 ft.-lbs. of breakaway torque from a unique patented motor design.
• Quiet: 4 decibels quieter running from a patented motor design.
• Patented Direct Greasing System: Greasing your tool has never been easier. Directly grease the tool's hammer for more efficient operation and increased run time.
• Reliable Performance: Stay working, and at peak power by quickly replacing worn or broken anvils.
• Ergonomic: Smaller, lighter and better balanced design under 4.5 lbs. and 7.4 inch overall length.
• Includes 1/2 Square Drive Anvil (A41H)

Product Application and Uses:

Vehicle Repair

• Includes: DXS2 1/2 inch Square Drive Anvil (A41H). Compatible with all DXS2 anvils and sockets. 3/8 and 3/4 drive size options as well as extended lengths sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 36
• Air Consumption @ Load (l/min): 1090
• Air Inlet: 1/4 inch NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 9
• Average Air Consumption (l/min): 255

IR 2236QPTiMAX

Description: Ingersoll Rand has delivered the gold standard in pneumatic tools for almost 100 years - and the performance, durability, and power of the 2236 1/2 pneumatic impact is no different. Our patented Drive Xchange System - lets you swap out anvils without torque-zapping adapters and extenders. Plus, a powerful motor, durable build, and quiet, efficient operation make the 2236 model the perfect choice for serious technicians. Powerful Versatility: Say goodbye to that drawer full of adapters for good. The Ingersoll Rand 2236 Pneumatic 1/2 inch impact wrench has an interchangeable anvil system that lets you tailor your tool to whatever job is at hand - without losing a single ft-lb of power. Innovation: Ingersoll Rand's patented Drive Xchange System helps you get more versatility, torque, and control out of your impact wrench. Torque: The 2236 series operates with 1,500 ft-lbs of breakaway torque.

Features And Benefits:

• Patented Drive Xchange System: Helps you get more versatility, torque, and control out of your impact wrench. With 3/8,inch 1/2 inch , and 3/4 inch drive options and 5 different anvil lengths ranging from 2 to 10 inch, you can do more work with less equipment.
• Powerful Versatility: 1,500 ft.-lbs. of breakaway torque from a unique patented motor design.
• Quiet: 4 decibels quieter running from a patented motor design.
• Patented Direct Greasing System: Greasing your tool has never been easier. Directly grease the tool's hammer for more efficient operation and increased run time.
• Reliable Performance: Stay working, and at peak power by quickly replacing worn or broken anvils.
• Ergonomic: Smaller, lighter and better balanced design under 4.5 lbs. and 7.4 inch overall length.
• Includes 1/2 Square Drive Pin Anvil (AP41H)

Product Application and Uses:

Industrial

• Includes: DXS2 1/2 inch Square Drive Pin Anvil (AP41H). Compatible with all DXS2 anvils and sockets. 3/8 and 3/4 drive size options as well as extended lengths sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 36
• Air Consumption @ Load (l/min): 1090
• Air Inlet: 1/4 inch NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 9
• Average Air Consumption (l/min): 255

IR 2235P-A726

Pin Anvil for Ingersoll Rand 2235P Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2235PTIMAX and 2235QPTIMAX standard anvil pin retainer Impact wrenches.

• Anvil Length: Standard

• Drive Size (in): 1/2
• Drive Type: Square

• Retainer Type: Pin Detent

• For Use With: 2235QPTIMAX
• For Use With: 2235PTIMAX

IR 2235-97

Ball Bearing for Ingersoll Rand 2235 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2235 Series Impact Wrench

• For Use With: 2235QPTIMAX
• For Use With: 2235TIMAX-2
• For Use With: 2235QTIMAX
• For Use With: 2235QTIMAX-G
• For Use With: 2235TIMAX-G
• For Use With: 2235TIMAX
• For Use With: 2235QTIMAX-2
• For Use With: 2235TIMAX-R
• For Use With: 2235PTIMAX

IR 2236QTIMAX-G

DXS2 1/2 inch Air Impact Wrench, Quiet, 1500 ft-lb Torque, Titanium Hammercase, Friction Ring Retainer, Green

Description: The Ingersoll Rand 2236QTiMAX Visibility Series, provides the power you know and trust in vibrant colors. Ingersoll Rand has delivered the gold standard in pneumatic tools for almost 100 years - and the performance, durability, and power of the 2236 1/2 inch pneumatic impact is no different. Our patented Drive Xchange System lets you swap out anvils without torque-zapping adapters and extenders. Plus, a powerful motor, durable build, and quiet, efficient operation make the 2236 model the perfect choice for serious technicians. Powerful Versatility: Say goodbye to that drawer full of adapters for good. The Ingersoll Rand 2236 Pneumatic 1/2 inch impact wrench has an interchangeable anvil system that lets you tailor your tool to whatever job is at hand - without losing a single ft-lb of power. Innovation: Ingersoll Rand's patented Drive Xchange System helps you get more versatility, torque, and control out of your impact wrench. Torque: The 2236 series operates with 1,500 ft-lbs of breakaway torque.

Features And Benefits:

• Visibility: The green 2236QTIMAX-G impact wrench allows you to see it on the job and in the garage, while customizing your toolbox. Also available in orange and red.
• Patented Drive Xchange System: Helps you get more versatility, torque, and control out of your impact wrench. With 3/8 inch , 1/2 inch , and 3/4 inch drive options and 5 different anvil lengths ranging from 2 to 10 inch, you can do more work with less equipment.
• Powerful Versatility: 1,500 ft.-lbs. of breakaway torque from a unique patented motor design.
• Patented Direct Greasing System: Greasing your tool has never been easier. Directly grease the tool's hammer for more efficient operation and increased run time.
• Reliable Performance: Stay working, and at peak power by quickly replacing worn or broken anvils. Titanium hammer case is light weight with unyielding durability.
• Ergonomic: Smaller, lighter and better balanced design under 4.5 lbs. and 7.4 inch overall length.
• Quiet: 4 decibels quieter than the 2235TIMAX for a more user-friendly environment.
• Includes 1/2 inch Square Drive Anvil (A41H), 3/8 inch and 3/4 inch drive size options as well as extended lengths sold separately.

Product Application and Uses:

Vehicle Repair

• Includes: DXS2 1/2 inch Square Drive Anvil (A41H). Compatible with all DXS2 anvils and sockets. 3/8 inch and 3/4 inch drive size options as well as extended lengths sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 36
• Air Consumption @ Load (l/min): 1090
• Air Inlet: 1/4 inch NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 9
• Average Air Consumption (l/min): 255

• Blows per Min: 1350

• Color: Green
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/2
• Drive Type: Square
• Duty Rating: Heavy Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 96.4 / 107.4

• Hammer Case: Titanium
• Housing Material: Impact and chemical-resistant composite housing
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 94.2 / 105.2

• Max Bolt Diameter (in): 1 1/4
• Max Free Speed (rpm): 7500
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1000
• Max Torque (in-lb): 12002
• Max Torque (nm): 1356
• Min Hose Size (in

IR 22MA2

Large Air Drill, Reversible Roll Throttle, 350 RPM, 1.75HP, No. 2 Morse Taper

Description: We have several series of large drills to meet your construction and industrial needs. The 22 Series works best for general applications, while the 33, 44, and 551 Series are better suited for opening and closing large valves, or for drilling larger holes between 1 inch (25mm) and 3 inches (76mm).

Features And Benefits:

• Side Exhaust: All the Ingersoll Rand large drills come with side exhaust to keep exhaust air pointed away from you and away from your work.
• Governed Motor: No matter which Ingersoll rand large drill series you're interested in, you can expect a governed motor that regulates air intake to keep these drills working at the peak of their power curve.
• Lightweight: The 22 Series large drills are strong but lightweight for increased ease of use.
• Balling bearing support for long life and efficient operation

Product Application and Uses:

These air drills are designed for heavy duty drilling and reaming.

• Actuation/Throttle Type/Switch Type: Reversible, Roll
• Air Consumption (cfm): 55
• Air Consumption (l/min): 1558
• Air Inlet: 1/2in NPT

• Capacity in Steel Drilling (in): 7/8
• Capacity in Steel Reaming (in): 5/8

• Color: Beige
• Configuration/Handle Type: T-handle
• Duty Rating: Super Duty

• Exhaust Location: Side

• Height Over Spindle (in): 18.63
• Length of Feed (in): 2.5

• Max Free Speed (rpm): 350
• Max Power (hp): 1.75
• Min Hose Size (in): 3/4

• Power Source: Air Powered

• Product Weight (lb): 14.25
• Reversible: Reversible

• Side to Center Distance (in): 1.44
• Side to Center Distance (mm): 37

• Sound Pressure/Power Db(A): 96.1 / 97.1
• Spindle Type: No. 2 Morse Taper

• Vibration Level (m/s2): <2.5
• Warranty: 1-year

• Lubrication: 50P

IR 22SR-83-3X3/4

IR 231107K

IR 230-36

Gasket for Ingersoll Rand 231 Series Air Impact Wrench

Product Application and Uses:

For use with 231HA, 231HA-2 and 231R Series Air Impact Wrenches.

IR 231-329A

Valve for Ingersoll Rand 231C Series Impact Wrench

IR 231B-THK1

Hammer Kit for Ingersoll Rand 231 Series Air Impact Wrench

• For Use With: 231C
• For Use With: 231C-AP
• For Use With: 231HA
• For Use With: 231HA-2

IR 231-53

Rotor for Ingersoll Rand Impact Wrenches

Product Application and Uses:

For use with 236G, 232, 231, 231H, and 131 Series impact wrenches

IR 231C

1/2" Air Impact Wrench, Super Duty, 600 ft-lb Torque, Friction Ring Retainer, Pistol

Description: The heavy duty 231C impact wrench has the reliability and durability you've come to expect from the Ingersoll Rand name. The powerful tool provides an even impact and is durable enough to last through the toughest work environments.

Features And Benefits:

• Performance: Delivers a max. torque of 600 ft.-lbs. and offers enough power to install and remove stubborn bolts, lug nuts, and other hardy fasteners.
• Reliable Choice: Lightweight and easy to maintain, this impact wrench is a reliable choice for auto hobbyists and professional mechanics alike. Built to withstand harsh environments and repeated drops, this impact wrench won't let you down.
• Adjustable Power: Its adjustable power regulator lets you easily adjust power output needed for your task at hand, The twin hammer mechanism helps ensure efficient performance with impressive rotational speeds of up to 8,000 rpm.
• Comfort and Control: At 7.3 inches in length and weighing only 5.8 lbs, it's compact, ergonomic design minimizes stress on your wrists and hands, The contoured handle makes it easy to carry and control.
• Ready to Use: For added convenience, this impact wrench arrives fully lubricated, so it's ready to use out of the box. Exclusive impact mechanism Pressure-feed lubrication.

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 22
• Air Consumption @ Load (l/min): 623
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 4.2
• Average Air Consumption (l/min): 119

• Blows per Min: 1200

• Color: Silver
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/2
• Drive Type: Square
• Duty Rating: Super Duty

• End Plates: Steel
• Exhaust Location: Front
• Free Speed Sound Pressure/Power Db(A): 99.0 / 110.0

• Hammer Case: Steel
• Handle Material: Aluminum
• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer

• Max Bolt Diameter (in): 9/16
• Max Free Speed (rpm): 8000
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 600
• Max Torque (in-lb): 7196
• Max Torque (nm): 813
• Min Hose Size (in): 3/8
• Motor: Reverse Bias

• Number of Power Settings: 6
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 103.4
• Product Length (in): 7.3

• Product Width (in): 2.81
• Product Height (in): 7.7
• Product Weight (lb): 5.8
• Recommended Forward Torque Range (ft-lb): 25-300
• Recommended Forward Torque Range (in-lb): 301-3602
• Recommended Forward Torque Range (nm): 34-407
• Recommended Reverse Torque (ft-lb): 25-350
• Recommended Reverse Torque (nm): 34-475
• Retainer Type: Friction Ring

• Side to Center Distance (in): 1.4
• Side to Center Distance (mm): 36

• Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744

• Tool Type: Full-size
• Vanes: 6
• Vibration Level (m/s2): 6.5
• Warranty: 1-year

• Accessories: 231-BOOT
• Accessories: S64H1316L-PS1
• Accesso

IR 231B-A626

1/2" Anvil Assembly, Ring Retainer for Ingersoll Rand 2135, 2131 and 231 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 1/2" ring retainer impact wrench models 2135TIMAX, 2135QTIMAX, 231C, 2131C, 2131QT

• For Use With: 2135QXPA
• For Use With: 231C

IR 231-TK3

Tune-up Kit for Ingersoll Rand 231 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 231 Series Impact Wrenches.

• Includes: Felt, Bearings, Socket Retainer, O-Rings, Spring, Gaskets, Seals, Vane pack

• For Use With: 231C
• For Use With: 231C-AP
• For Use With: 231HA
• For Use With: 231HA-2

IR 231B-A726

Anvil Assembly Replacement Part for Ingersoll Rand 2135 Series Pin Anvil Impact Wrench

• For Use With: 2131PEX
• For Use With: 2135PTIMAX

IR 231XP-724

Hammer for Ingersoll Rand Air Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2130, 2132, 2135, 231, 232 and 231H Series impact wrenches

IR 231HA-2

1/2" Air Impact Wrench, 2" Ext Anvil, Super Duty, 600 ft-lb Torque, Friction Ring Retainer, Pistol

Description: The 231HA Series is the ideal impact wrench for any job you take it to, from facility maintenance and industrial work to vehicle repair and tire work. Tough and durable with a powerful vane motor, this impact wrench won't let you down.

Features And Benefits:

• Durability: This impact wrench is tough enough to handle harsh environments, repeated drops and run-ins with any number of chemicals.
• Access: Pressure-fed lubrication system. Handle exhaust directs air away from user.
• Power Regulation: Adjustable power regulation in forward and reverse.
• Extended Reach: The 2-inch extended anvil provides you with increased reach that's invaluable when working with deeper fasteners.
• Easy to Service: Easy to service two-piece construction.
• Comfort: Contoured handle for comfort and control.

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 22
• Air Consumption @ Load (l/min): 623
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Anvil Length: 2" Extended
• Average Air Consumption (cfm): 4.2
• Average Air Consumption (l/min): 119

• Blows per Min: 1150

• Color: Silver
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/2
• Drive Type: Square
• Duty Rating: Super Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 94.0 / 105.0

• Hammer Case: Steel
• Handle Material: Aluminum
• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer

• Max Bolt Diameter (in): 9/16
• Max Free Speed (rpm): 8000
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 600
• Max Torque (in-lb): 7196
• Max Torque (nm): 813
• Min Hose Size (in): 3/8
• Motor: Reverse Bias

• Number of Power Settings: 6
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 172.1
• Product Length (in): 9.1

• Product Width (in): 2.75
• Product Height (in): 7.9
• Product Weight (lb): 6.1
• Recommended Forward Torque Range (ft-lb): 25-300
• Recommended Forward Torque Range (in-lb): 301-3602
• Recommended Forward Torque Range (nm): 34-407
• Recommended Reverse Torque (ft-lb): 25-350
• Recommended Reverse Torque (nm): 34-475
• Retainer Type: Friction Ring

• Side to Center Distance (in): 1.4
• Side to Center Distance (mm): 36

• Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744

• Tool Type: Full-size
• Vanes: 6
• Vibration Level (m/s2): 6.5
• Warranty: 1-year

• Accessories: 231-BOOT
• Accessories: S64H1316L-PS1
• Accessories: S64H1516L-PS1
• Accessories: S64H34L-PS1
• Accessories: S64H78L-PS1
• Accessories: S64M17L-PS1
• Accessories: S64M18L-PS1
• Accessories: S64M21L-PS1
• Accessories: S64M22L-PS1
• Accessories: S64M24L-PS1
• Accessories: S64M26L-PS1
• Accessories: SK4H13N

• Lubrication: 105-LBK1
• Lub

IR 231-704

IR 232TGSL

1/2 inch Air Impact Wrench, Super Duty, 625 ft-lb Torque, Friction Ring Retainer, Pistol

Description: If you're looking for NASCAR pitstop-level speeds, the 232TGSL 1/2 inch is the impact wrench for you. Its powerful vane motor and smooth trigger actuation will help you fly through vehicle repair jobs with an added level of confidence and control.

Features And Benefits:

• POWER: The 232TGSL impact gun delivers 625 ft/lbs of maximum reverse torque to give technicians the power they need to complete tough repairs.
• SPEED: This pneumatic thunder gun is the fastest 1/2 inch impact wrench in the Ingersoll Rand line, at 10,000 RPM, to deliver pit crew speed.
• Durability: The steel hammer case and metal housing in the 232TGSL 1/2 inch makes this impact wrench strong and durable to last through any job.
• Warranty: Your 232TGSL 1/2 inch comes with a one-year standard warranty to protect against any manufacturing defects.

Product Application and Uses:

Automotive Vehicle Service Racing

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 23
• Air Consumption @ Load (l/min): 651
• Air Inlet: 1/4 inch NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 5.4
• Average Air Consumption (l/min): 153

• Blows per Min: 1250

• Color: Yellow
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/2
• Drive Type: Square
• Duty Rating: Super Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 105.3 / 109.3

• Hammer Case: Steel
• Handle Material: Aluminum
• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer

• Max Bolt Diameter (in): 9/16
• Max Free Speed (rpm): 10000
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 625
• Max Torque (in-lb): 7497
• Max Torque (nm): 847
• Min Hose Size (in): 3/8
• Motor: Reverse Bias

• Number of Power Settings: 6
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 104.1
• Product Length (in): 7.3

• Product Width (in): 2.8
• Product Height (in): 7.3
• Product Weight (lb): 6
• Recommended Forward Torque Range (ft-lb): 500
• Recommended Forward Torque Range (in-lb): 6001
• Recommended Forward Torque Range (nm): 678
• Retainer Type: Friction Ring

• Side to Center Distance (in): 1.4
• Side to Center Distance (mm): 36

• Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744

• Tool Type: Full-size
• Vanes: 6
• Warranty: 1-year

• Accessories: 232TGSL-P32
• Accessories: S64H1316L-PS1
• Accessories: S64H1516L-PS1
• Accessories: S64H34L-PS1
• Accessories: S64H78L-PS1
• Accessories: S64M17L-PS1
• Accessories: S64M18L-PS1
• Accessories: S64M21L-PS1
• Accessories: S64M22L-PS1
• Accessories: S64M24L-PS1
• Accessories: S64M26L-PS1

• Lubrication: 105-LBK1
• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 231XP-THK1

IR 231G-51

Throttle Valve Spring for Ingersoll Rand for 231G Series Impact Wrench

• For Use With: 231G
• For Use With: 231GXP
• For Use With: 231GXP-K

IR 231-665

Screw for Ingersoll Rand 231H Series Impact Wrench

IR 231G-747

Grip for Ingersoll Rand 231G Impact Wrench

• For Use With: 231G
• For Use With: 231GXP
• For Use With: 231GXP-K

IR 231HP-TK1

Tune-up Kit for Ingersoll Rand 231H Series Impact Wrench

• Includes: Bearings, Spring, O-Rings, Gaskets, Seat, Ball, Seals, Valve, Retainers, Vane pack

• For Use With: 231HA
• For Use With: 231HA-2

IR 231-664

Reverse Valve Dentent Spring Replacement Part for Ingersoll Rand 231C Series Impact Wrench

IR 236

1/2 inch Air Impact Wrench, 450 ft-lb Torque, Friction Ring Retainer, Pistol

Description: If you work in vehicle repair, this impact wrench will see you through every job that walks in the door. The 236 1/2 inch is strong and reliable, with a power regulator that allows for increased control from start to finish.

Features And Benefits:

• RELIABILITY: The 236 1/2 inch Impact Wrench will put in overtime on your toughest projects. Each part is tested for quality, so you can be sure it'll deliver a high-performance output every time.
• POWER: This impact wrench comes with a finely tuned vane motor that pairs smoothly with the jumbo hammer impact mechanism on the 236 1/2 inch impact wrench for maximum power.
• WARRANTY: A one-year warranty comes standard on all 236 1/2 inch impact wrenches

Product Application and Uses:

Vehicle Repair Or Maintenance Repair

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 24
• Air Consumption @ Load (l/min): 680
• Air Inlet: 1/4 inch NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 4.3
• Average Air Consumption (l/min): 122

• Blows per Min: 1200

• Color: Silver
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/2
• Drive Type: Square
• Duty Rating: General Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 90.3 / 101.3

• Hammer Case: Steel
• Handle Material: Aluminum
• Housing Material: Aluminum
• Impact Mechanism: Jumbo Hammer

• Max Bolt Diameter (in): 1/2
• Max Free Speed (rpm): 7400
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 450
• Max Torque (in-lb): 5400
• Max Torque (nm): 610
• Min Hose Size (in): 3/8
• Motor: Non-Biased

• Number of Power Settings: 2
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 84.9
• Product Length (in): 7

• Product Width (in): 2.6
• Product Height (in): 7.2
• Product Weight (lb): 5.3
• Retainer Type: Friction Ring

• Side to Center Distance (in): 1.3
• Side to Center Distance (mm): 33

• Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744

• Tool Type: Full-size
• Vanes: 6
• Vibration Level (m/s2): 12
• Warranty: 1-year

• Accessories: 236-BOOT
• Accessories: S64H1316L-PS1
• Accessories: S64H1516L-PS1
• Accessories: S64H34L-PS1
• Accessories: S64H78L-PS1
• Accessories: S64M17L-PS1
• Accessories: S64M18L-PS1
• Accessories: S64M21L-PS1
• Accessories: S64M22L-PS1
• Accessories: S64M24L-PS1
• Accessories: S64M26L-PS1
• Accessories: SK4H13N

• Lubrication: 105-LBK1
• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 236-A626
• Parts: 236-TK1

IR 2372896

IR 241SR-17

IR 241SR-122

Screen for Ingersoll Rand 130A1M, 241A1M, 341 and 441 Series Air Rammer

Product Application and Uses:

For use with Ingersoll Rand 130A1M, 241A1M, 341A2M Air Rammers

• For Use With: 130A1M
• For Use With: 241A1M
• For Use With: 341A2M

IR 241SR-33A

IR 241SR-31

IR 236-A626

Anvil Assembly for Ingersoll Rand 236G Impact Wrench

• For Use With: 236
• For Use With: 236G

IR 241SR-30

IR 241SR-311

IR 236-TK1

Tune-up Kit for Ingersoll Rand 236G Impact Wrench

• Includes: Throttle valve, exhaust silencer, trigger, bearing retainer, rear rotor bearing, rotor, cylinder dowel and hammer case bushing

• For Use With: 236
• For Use With: 236G

IR 236-52

IR 241SR-5

IR 241SR-A124

IR 241SR-A160

IR 3DA-549

IR 3DA-85

IR 3DA-A1

IR 3RL2-705

IR 3RL2-A552

IR 3RL-42-5

IR 3RL-511

IR 3RL-80

IR 3RLM-A37

IR 3RLN-216

IR 3RP-435

IR 3S3-408

IR 4000892

IR 401-22

IR 401-3

IR 401-53

IR 401-718

IR 401-718-5

IR 405-159

Throttle Valve Face for Ingersoll Rand Impact/Angle Wrenches

• For Use With: 231C
• For Use With: 2705P1
• For Use With: 2707P1
• For Use With: 9RSQ83
• For Use With: 9SQ83

IR 401-42A-6

Vane Pack for Ingersoll Rand 1702, 211, 212, 215 Series Impact Wrench, 6-Pack

• For Use With: 1702P1
• For Use With: 1702P4
• For Use With: 1702SB1

IR 40723

IR 40807-1

IR 40808

IR 409

Air Die Grinder, 27,000 RPM, 0.5HP, 1/4in & 6mm Collets, Front Exhaust

Description: With a powerful vane motor and ergonomic front exhaust to direct air away from your workspace, the 409 Die Grinder is a tough tool to have in your arsenal.

Features And Benefits:

• Comfort: This die grinder is lightweight and ergonomic, so you can do more work for longer stretches of time.
• Access: The compact 409 Die Grinder allows you to reach tighter spaces with ease.
• Increased Safety: With a locking throttle lever that resets each time the lever is released, the 409 increases operator safety by preventing accidental throttle operation.

Product Application and Uses:

De-burring, Polishing, Porting, Smoothing Edges, Weld Grinding

• Includes: Tool, (2) Wrenches, 6mm Collet and Manuals
• Actuation/Throttle Type/Switch Location: Bottom
• Actuation/Throttle Type/Switch Type: Lever
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Arbor/Collet: 6mm

• Bearing Type: Ball Bearing

• Configuration/Handle Type: Straight
• Duty Rating: Medium Duty

• Exhaust Location: Front

• Grinder Type: Die Grinder
• Housing Material: Aluminum
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 27000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 5.87

• Product Width (in): 3.46
• Product Height (in): 2.36
• Product Weight (lb): 1.2
• Rated Power (hp): 0.5

• Side to Center Distance (in): 1.73
• Side to Center Distance (mm): 44

• Sound Pressure/Power Db(A): 90.9 / 101.9
• Speed Setting: Variable Speed
• Standards/Certifications: 2006/42/Ec, Iso 28927-12, Iso 15744, Iso 11148-9

• Vibration Level (m/s2): 6.4
• Warranty: 1-year
• Wheel Type: Burr

• Lubrication: 10G
• Lubrication: 10P
• Parts: 03A-VAR-KIT
• Parts: 308A-42-4

• Parts: 308A-K69

IR 4151

Random Orbital Air Sander, 3/16" Orbit, 6" Vinyl Pad, 12,000 RPM, 0.2 HP

Description: This vacuum-ready, low-vibration air sander produces an ultra-high-quality finish on every job. Extracting dust and particles through and around the pad, this tool keeps foreign matter away from the motor to ensure smooth operation.

Features And Benefits:

• Vacuum Ready: This random orbital air sander can connect to a number of central or portable vacuum system.
• Durability- Whether you drop it or use it in harsh conditions, this sander can withstand it.
• Performance: Equipped with a 12,000 RPM motor with a 3/16-inch orbit, this sander always has a swirl-free finish.

Product Application and Uses:

Smoothing, Sanding, Automotive Repair

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Lever
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/16" -24 Thread
• Average Air Consumption (cfm): 8
• Average Air Consumption (l/min): 226

• Color: Black
• Configuration/Handle Type: Palm
• Dust Collection Port Size: 25mm end size to connect with the hose
• Dust Collection Type: Vacuum Hose Mount
• Duty Rating: Maintenance Duty

• Exhaust Location: Rear

• Housing Material: Composite

• Max Free Speed (rpm): 12000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16
• Motor: Air Gear Motor

• Number of Vacuum Holes: 6
• Orbit Diameter (in): 3/16
• Pad Diameter or Size (in): 6
• Pad Face: Adhesive
• Power Source: Air Powered
• Product Length (in): 7.48

• Product Width (in): 6.8
• Product Height (in): 4.8
• Product Weight (lb): 1.92
• Rated Power (hp): 0.2

• Shroud Style: Short

• Sound Pressure/Power Db(A): 81.6 / 92.6
• Special Features: Lubrication-free motor
• Speed Setting: Variable Speed
• Standards/Certifications: Ce

• Vacuum: Vacuum Ready/Central Vacuum
• Vibration Level (m/s2): 7.5
• Warranty: 1-year

• Accessories: 4151JV

• Parts: VPAD-6

IR 4151-2

Random Orbital Air Sander, 3/16" Orbit, 6" Vinyl Pad, 12,000 RPM, 0.2 HP

Description: This vacuum-ready, low-vibration air sander produces an ultra high-quality finish on every job. Extracting dust and particles through and around the pad, this tool keeps foreign matter away from the motor to ensure smooth operation.

Features And Benefits:

• Vacuum Ready: This random orbital air sander can connect to a number of central or portable vacuum system.
• Durability: Whether you drop it or use it in harsh conditions, this sander can withstand it.
• Performance: Equipped with a 12,000 RPM motor with a 3/16-inch orbit, this sander always has a swirl-free finish.

Product Application and Uses:

These Air Orbital Sanders are designed for smoothing and sanding welds, paint, fiber glass wood and body filler, feather edging, removing rust and preparing metal surfaces.

• Includes: Tool with pad, 2 vacuum shrouds, manuals
• Actuation/Throttle Type/Switch Type: Lever
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/16" -24 Thread
• Average Air Consumption (cfm): 8
• Average Air Consumption (l/min): 226

• Color: Black
• Configuration/Handle Type: Extended Palm
• Dust Collection Port Size: 25mm end size to connect with the hose
• Dust Collection Type: Vacuum Hose Mount
• Duty Rating: Industrial Duty

• Exhaust Location: Rear

• Handle Material: Composite
• Housing Material: Composite

• Max Free Speed (rpm): 12000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16
• Motor: Gearless

• Number of Vacuum Holes: 6
• Orbit Diameter (in): 3/16
• Pad Diameter or Size (in): 6
• Pad Face: Adhesive
• Power Source: Air Powered
• Product Length (in): 9.9

• Product Height (in): 4.8
• Product Weight (lb): 2.46
• Rated Power (hp): 0.2

• Shroud Style: Short

• Sound Pressure/Power Db(A): 81.6
• Speed Setting: Variable Speed

• Vacuum: Vacuum Ready/Central Vacuum
• Vibration Level (m/s2): 6.2
• Warranty: 1-year

• Accessories: VPAD-6

• Lubrication: 10G
• Lubrication: 10P
• Parts: VPAD-6

IR 4151-5

Random Orbital Air Sander, 3/16" Orbit, 5" Vinyl Pad, 12,000 RPM, 0.2 HP

Description: This vacuum-ready, low-vibration air sander produces an ultra high-quality finish on every job. Extracting dust and particles through and around the pad, this tool keeps foreign matter away from the motor to ensure smooth operation.

Features And Benefits:

• Vacuum Ready: This random orbital air sander can connect to a number of central or portable vacuum system.
• Durability: Whether you drop it or use it in harsh conditions, this sander can withstand it.
• Performance: Equipped with a 12,000 RPM motor with a 3/16-inch orbit, this sander always has a swirl-free finish.

Product Application and Uses:

These Air Orbital Sanders are designed for smoothing and sanding welds, paint, fiber glass wood and body filler, feather edging, removing rust and preparing metal surfaces.

• Includes: Tool with pad, 2 vacuum shrouds, manuals
• Actuation/Throttle Type/Switch Type: Lever
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/16" -24 Thread
• Average Air Consumption (cfm): 8
• Average Air Consumption (l/min): 226

• Color: Black
• Configuration/Handle Type: Palm
• Dust Collection Port Size: 25mm end size to connect with the hose
• Dust Collection Type: Vacuum Hose Mount
• Duty Rating: Industrial Duty

• Exhaust Location: Rear

• Handle Material: Composite
• Housing Material: Composite

• Max Free Speed (rpm): 12000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16
• Motor: Gearless

• Number of Vacuum Holes: 6
• Orbit Diameter (in): 3/16
• Pad Diameter or Size (in): 5
• Pad Face: Adhesive
• Power Source: Air Powered
• Product Length (in): 7

• Product Height (in): 4.8
• Product Weight (lb): 1.92
• Rated Power (hp): 0.2

• Shroud Style: Short

• Sound Pressure/Power Db(A): 81.6
• Speed Setting: Variable Speed

• Vacuum: Vacuum Ready/Central Vacuum
• Vibration Level (m/s2): 6.2
• Warranty: 1-year

• Accessories: 49096-1

• Lubrication: 10G
• Lubrication: 10P
• Parts: RSVK-5

IR 4151-65

O-Ring Replacement Part for Ingersoll Rand 4151 Series Orbital Sander

IR 4151-797

Snap Ring for Ingersoll Rand 4151 Series Orbital Sander

IR 4151-A165

Regulator Assembly for Ingersoll Rand 4151 Orbital Sander

IR 4151-A809A-32

32MM Sleeve Kit for Ingersoll Rand 4151 Series Orbital Sander

IR 4151-A810

Muffler Assembly for Ingersoll Rand 4151 Series Orbital Sander

IR 4151-HL

Random Orbital Air Sander, 3/16" Orbit, 6" Hook & Loop, 12,000 RPM, 0.2 HP

Description: This vacuum-ready, low-vibration air sander produces an ultra high-quality finish on every job. Extracting dust and particles through and around the pad, this tool keeps foreign matter away from the motor to ensure smooth operation.

Features And Benefits:

• Vacuum Ready: This random orbital air sander can connect to a number of central or portable vacuum system.
• Durability: Whether you drop it or use it in harsh conditions, this sander can withstand it.
• Performance: Equipped with a 12,000 RPM motor with a 3/16-inch orbit, this sander always has a swirl-free finish.

Product Application and Uses:

These Air Orbital Sanders are designed for smoothing and sanding welds, paint, fiber glass wood and body filler, feather edging, removing rust and preparing metal surfaces.

• Includes: Tool with pad, 2 vacuum shrouds, manuals
• Actuation/Throttle Type/Switch Type: Lever
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/16" -24 Thread
• Average Air Consumption (cfm): 8
• Average Air Consumption (l/min): 226

• Color: Black
• Configuration/Handle Type: Palm
• Dust Collection Port Size: 25mm end size to connect with the hose
• Dust Collection Type: Vacuum Hose Mount
• Duty Rating: Industrial Duty

• Exhaust Location: Rear

• Handle Material: Composite
• Housing Material: Composite

• Max Free Speed (rpm): 12000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16
• Motor: Gearless

• Number of Vacuum Holes: 6
• Orbit Diameter (in): 3/16
• Pad Diameter or Size (in): 6
• Pad Face: Hook & Loop
• Power Source: Air Powered
• Product Length (in): 7.48

• Product Width (in): 6.5
• Product Height (in): 4.8
• Product Weight (lb): 1.92
• Rated Power (hp): 0.2

• Shroud Style: Short

• Sound Pressure/Power Db(A): 81.6
• Speed Setting: Variable Speed

• Vacuum: Vacuum Ready/Central Vacuum
• Vibration Level (m/s2): 7
• Warranty: 1-year

• Accessories: VPAD-6HL

• Lubrication: 10G
• Lubrication: 10P

IR 4151-HL-2

Random Orbital Air Sander, 3/16" Orbit, 6" Hook & Loop, 12,000 RPM, 0.2 HP

Description: This vacuum-ready, low-vibration air sander produces an ultra high-quality finish on every job. Extracting dust and particles through and around the pad, this tool keeps foreign matter away from the motor to ensure smooth operation.

Features And Benefits:

• Vacuum Ready: This random orbital air sander can connect to a number of central or portable vacuum system.
• Durability: Whether you drop it or use it in harsh conditions, this sander can withstand it.
• Performance: Equipped with a 12,000 RPM motor with a 3/16-inch orbit, this sander always has a swirl-free finish.

Product Application and Uses:

These Air Orbital Sanders are designed for smoothing and sanding welds, paint, fiber glass wood and body filler, feather edging, removing rust and preparing metal surfaces.

• Includes: Tool with pad, 2 vacuum shrouds, manuals
• Actuation/Throttle Type/Switch Type: Lever
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/16" -24 Thread
• Average Air Consumption (cfm): 8
• Average Air Consumption (l/min): 226

• Configuration/Handle Type: Extended Palm
• Dust Collection Port Size: 25mm end size to connect with the hose
• Dust Collection Type: Vacuum Hose Mount
• Duty Rating: Industrial Duty

• Exhaust Location: Rear

• Handle Material: Composite
• Housing Material: Composite

• Max Free Speed (rpm): 12000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16
• Motor: Gearless

• Number of Vacuum Holes: 6
• Orbit Diameter (in): 3/16
• Pad Diameter or Size (in): 6
• Pad Face: Hook & Loop
• Power Source: Air Powered
• Product Length (in): 9.9

• Product Height (in): 4.8
• Product Weight (lb): 2.46
• Rated Power (hp): 0.2

• Shroud Style: Short

• Sound Pressure/Power Db(A): 81.6
• Speed Setting: Variable Speed

• Vacuum: Vacuum Ready/Central Vacuum
• Vibration Level (m/s2): 6.2
• Warranty: 1-year

• Accessories: VPAD-6HL

• Lubrication: 10G
• Lubrication: 10P

IR 4152

Random Orbital Air Sander, 3/32" Orbit, 6" Adhesive Pad, 12,000 RPM, 0.2 HP

Description: This vacuum-ready, low-vibration air sander produces an ultra high-quality finish on every job. Extracting dust and particles through and around the pad, this tool keeps foreign matter away from the motor to ensure smooth operation.

Features And Benefits:

• Vacuum Ready: This random orbital air sander can connect to a number of central or portable vacuum system.
• Durability: Whether you drop it or use it in harsh conditions, this sander can withstand it.
• Performance: Equipped with a 12,000 RPM motor with a 3/32-inch orbit, this sander always has a swirl-free finish.

Product Application and Uses:

These Air Orbital Sanders are designed for smoothing and sanding welds, paint, fiber glass wood and body filler, feather edging, removing rust and preparing metal surfaces.

• Includes: Tool with pad, 2 vacuum shrouds, manuals
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption (cfm): 8
• Air Consumption (l/min): 226
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/16" -24 Thread
• Average Air Consumption (cfm): 8
• Average Air Consumption (l/min): 226

• Color: Red
• Configuration/Handle Type: Palm
• Dust Collection Port Size: 25mm end size to connect with the hose
• Dust Collection Type: Vacuum Hose Mount
• Duty Rating: Industrial Duty

• Exhaust Location: Rear

• Handle Material: Composite
• Housing Material: Composite

• Max Free Speed (rpm): 12000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16
• Motor: Gearless

• Number of Vacuum Holes: 6
• Orbit Diameter (in): 3/32
• Pad Diameter or Size (in): 6
• Pad Face: Adhesive
• Power Source: Air Powered
• Product Length (in): 7.48

• Product Height (in): 4.8
• Product Weight (lb): 1.8
• Rated Power (hp): 0.2

• Shroud Style: Short

• Sound Pressure/Power Db(A): 81.6
• Speed Setting: Variable Speed

• Vacuum: Vacuum Ready/Central Vacuum
• Vibration Level (m/s2): 8.2
• Warranty: 1-year

• Accessories: 4151JV

• Lubrication: 10G
• Lubrication: 10P
• Parts: VPAD-6

IR 4152-HL

Random Orbital Air Sander, 3/32" Orbit, 6" Hook & Loop, 12000 RPM, 0.2 HP

Description: This vacuum-ready, low-vibration air sander produces an ultra high-quality finish on every job. Extracting dust and particles through and around the pad, this tool keeps foreign matter away from the motor to ensure smooth operation.

Features And Benefits:

• Vacuum Ready: This random orbital air sander can connect to a number of central or portable vacuum system.
• Durability: Whether you drop it or use it in harsh conditions, this sander can withstand it.
• Performance: Equipped with a 12,000 RPM motor with a 3/32-inch orbit, this sander always has a swirl-free finish.

Product Application and Uses:

These Air Orbital Sanders are designed for smoothing and sanding welds, paint, fiber glass wood and body filler, feather edging, removing rust and preparing metal surfaces.

• Includes: Tool with pad, 2 vacuum shrouds, manuals
• Actuation/Throttle Type/Switch Type: Lever
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/16" -24 Thread
• Average Air Consumption (cfm): 8
• Average Air Consumption (l/min): 226

• Color: Red
• Configuration/Handle Type: Palm
• Dust Collection Port Size: 25mm end size to connect with the hose
• Dust Collection Type: Vacuum Hose Mount
• Duty Rating: Industrial Duty

• Exhaust Location: Rear

• Handle Material: Composite
• Housing Material: Composite

• Max Free Speed (rpm): 12000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16
• Motor: Gearless

• Number of Vacuum Holes: 6
• Orbit Diameter (in): 3/32
• Pad Diameter or Size (in): 6
• Pad Face: Hook & Loop
• Power Source: Air Powered
• Product Length (in): 7.48

• Product Width (in): 4
• Product Height (in): 4.8
• Product Weight (lb): 1.92
• Rated Power (hp): 0.2

• Shroud Style: Short

• Sound Pressure/Power Db(A): 81.6
• Speed Setting: Variable Speed

• Vacuum: Vacuum Ready/Central Vacuum
• Vibration Level (m/s2): 7
• Warranty: 1-year

• Accessories: VPAD-6HL

• Lubrication: 10G
• Lubrication: 10P

IR 41595

IR 41623

IR 41PA10PSQ4
