INGERSOLL-RAND IR TOOL S12880

IR 212-A40

IR 2131-283

IR 2115QTIMAX

3/8in Air Impact Wrench, Quiet, 300 ft-lb Torque, Titanium Hammercase, Friction Ring Retainer, Pistol

Description: The 2115TiMAX delivers best in class performance for a tool less than six inches long and weighing less than two and a half pounds. The minimal size of this tool will allow greater access to tight spaces, while the minimal weight will reduce operator fatigue...all while still delivering MAX performance.

Features And Benefits:

• Durable: With a titanium hammer case and composite housing, this wrench can withstand anything, including repeated drops and harsh environments. In fact, we provide a 2-year warranty to prove it.
• Versatile: This tool is so versatile, it can be used in just about any market.
• Easier access to grease fitting - for quicker maintenance and less downtime.
• Enhanced socket retention.
• 7-vane Motor delivers added power with less weight.
• Finely tuned twin hammer impact mechanism and motor deliver more torque, durability, and efficiency.
• Feather-touch trigger provides maximum control of this air impact wrench.
• Anodized end plate for enhanced durability.
• Optimized for the vehicle repair industry, body shops, general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding, and construction.
• Patented quiet tool technology reducing sound levels without compromising best-in-class power performance.
• Patented one-hand forward/reverse control for easy operation.
• Optimized air flow for maximized performance when using this pneumatic impact wrench.

Product Application and Uses:

General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 17
• Air Consumption @ Load (l/min): 481
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 4
• Average Air Consumption (l/min): 113

• Blows per Min: 1500

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/8
• Drive Type: Square
• Duty Rating: Maintenance Duty

• End Plates: Aluminum with Hard-coating
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 89.7 / 100.7

• Hammer Case: Titanium
• Handle Material: Composite
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 93.2 / 104.2

• Max Bolt Diameter (in): 7/16
• Max Free Speed (rpm): 15000
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 300
• Max Torque (in-lb): 3602
• Max Torque (nm): 407
• Min Hose Size (in): 3/8
• Motor: Reverse Bias

• Number of Power Settings: 4
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 120.9
• Product Length (in): 6

• Product Width (in): 2.2
• Product Height (in): 6.7
• Product Weight (lb): 2.48
• Quiet Tool: Yes
• Recommended Forward Torque Range (ft-lb): 250
• Recommended Forward Torque Range (in-lb): 3000
• Recommended Forward Torque Range (nm): 339
• Retainer Type: Friction Ring

• Side to Center Distance (in): 1.1
• Side to Center Distance (mm): 28

• Special Features: Quiet Tool, Titanium Hammercase, 2-year Max warranty
• Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744

IR 2131-57

Clip for Ingersoll Rand Impact Wrench

Product Application and Uses:

For use with ingersoll rand 2115, 2125, 2131, 2135, and 2350 Series Impact Wrenches

IR 2131-3

IR 2131-97

Cylinder Ball Bearing Replacement Part for Ingersoll Rand Power Tools

Product Application and Uses:

For use with Ingersoll Rand 2030 Series, 2035 Series, 2100 Series, 2112 Series, 2115 Series, 2125 Series, 2130 Series, 2131 Series, 2132 Series, 2135 Series, 2141 Series, 2145 Series, 2151 Series, 2155 Series, 2235 Series, 231 Series, 2350 Series, 2904 Series, 2906 Series Impact Wrench and 109 Series Ratchet Wrench

IR 2131-A249

IR 2131-A329

Reverse Valve Assembly for Ingersoll Rand Impact Wrenches

Product Application and Uses:

For use with 2100, 2130, 2131, 231, 2350, 2705 Series impact wrenches

IR 2131-D565

ATS Bush Assembly for Ingersoll Rand 2112, 2130, 2131, 2132 Series Impact Wrench

IR 2131-42A-6

Vane Pack for Ingersoll Rand 2130 Series, 2131 Series, 231 Series, 2350 Series, 2705 Series Impact Wrench

IR 2131-D93

ATS Trigger Assembly for Ingersoll Rand 2131, 2132 Series Impact Wrench

IR 2131-K75

Button Kit for Ingersoll Rand 2131 Series Impact Wrench

IR 2131PEX

1/2" Air Impact Wrench, ATEX/Hazardous Duty, 600 ft-lb Torque, Pin Retainer, Pistol

Description: Specifically designed to meet ATEX Zone 1 or Zone 2 requirements, this 2130 Series Impact Wrench was built to help you succeed. Reliable and durable from your first to your last job, this wrench will see you through.ATEX Marking: ATEX 2014/34/EU and Ex h IIA T6 Gb XISO 80079-36 Certified

Features And Benefits:

• Durability: Thanks to its steel hammer case and composite housing, this wrench will endure anything, from repeated drops to harsh chemicals. It'll never let you down.
• Bronze bushing reduces risk of sparks
• Twin hammer mechanism ensure consistent power and balance
• Pressure-fed mechanism lubrication ensures complete coverage throughout the tool
• Feather-touch trigger allows precise delivery of pressure and speed
• Composite Housing is impact and chemical resistant to extend the life of the tool.
• ATEX Marking: ATEX 2014/34/EU and Ex h IIA T6 Gb X
• ISO 80079-36 Certified

Product Application and Uses:

Hazardous Environment, Heavy Industry, Oil&Gas, Foundry

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Feather-touch Trigger
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 4.8

• Blows per Min: 1250

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/2
• Drive Type: Square
• Duty Rating: Atex/Hazardous Duty

• End Plates: Aluminum with Hard-coating
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 86.4 / 97.4

• Hammer Case: Steel
• Handle Material: Composite
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 90.4 / 101.4

• Max Bolt Diameter (in): 9/16
• Max Free Speed (rpm): 10250
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 600
• Max Torque (in-lb): 7196
• Max Torque (nm): 813
• Min Hose Size (in): 3/8
• Motor: Reverse Bias

• Number of Power Settings: 4
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 122
• Product Length (in): 7.3

• Product Width (in): 2.7
• Product Height (in): 7.2
• Product Weight (lb): 4.9
• Recommended Forward Torque Range (ft-lb): 450
• Recommended Forward Torque Range (in-lb): 5399
• Recommended Forward Torque Range (nm): 610
• Retainer Type: Pin Detent

• Side to Center Distance (in): 1.35
• Side to Center Distance (mm): 34

• Special Features: ATEX Rated
• Standards/Certifications: Atex 2014/34/Eu, Atex Ex H Iia T6 Gb X, Iso 80079-36

• Tool Type: Full-size
• Vanes: 6
• Vibration Level (m/s2): 8.31
• Warranty: 1-year

• Accessories: S64H1316L-PS1
• Accessories: S64H1516L-PS1
• Accessories: S64H34L-PS1
• Accessories: S64H78L-PS1
• Accessories: S64M17L-PS1
• Accessories: S64M18L-PS1
• Accessories: S64M19L-PS1
• Accessories: S64M21L-PS1
• Accessories: S64M22L-PS1
• Accessories: S64M24L-PS1
• Accessories: S64M26L-PS1
• Accessories: S64M27L-PS1

• Lubrication: 105-LBK1
• Lubrication: 10G
• Lubrication: 10P

IR 2131QT-311

Exhaust Silencer for Ingersoll Rand 2131, 2132, 2135, 2350 Series Impact Wrench

IR 2135-3

Cylinder for Ingersoll Rand 2135 Series Impact Wrench

IR 2135-36

Gasket for Ingersoll Rand 2135 Series Impact Wrench

IR 2135-638

Hammer Case Screw 4-pc for Ingersoll Rand 2135 Series Impact Wrench

Description: For use with Ingersoll Rand 2135 Series Impact Wrenches

• Includes: (4) Hammer case screws

• For Use With: 2135PQXPA
• For Use With: 2135PTIMAX
• For Use With: 2135PTIMAX-A
• For Use With: 2135PTIMAX-AP
• For Use With: 2135QXPA
• For Use With: 2135QXPA-2

IR 2135-42A-7

Vane pack for Ingersoll Rand 2135 Series Impact Wrench, 7-Pack

IR 2135-425

Socket Retainer Spring Replacement Part for Ingersoll Rand 2135 Series Impact Wrench

IR 2135-D249A

Power Regulator Assembly for Ingersoll Rand 2135 Series Impact Wrench

• For Use With: 2135PQXPA
• For Use With: 2135QXPA-2

IR 2135-D565A

IR 2135-D727A

IR 2135-D93

Trigger Assembly for Ingersoll Rand 2135 Series Impact Wrench

• Includes: includes trigger, and O-ring

IR 2135-D93B

Trigger Assembly Replacement Part for Ingersoll Rand 2135 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2135TIMAX Impact Wrench.

• For Use With: 2135PTIMAX

IR 2135-K303

Inlet Parts Kit for Ingersoll Rand 2135 Series Impact Wrench

• Includes: Washer, O-ring Seal, Throttle Spring, Throttle Valve, Valve Seat, Seat Support, Retainer

• For Use With: 2135PTIMAX
• For Use With: 2135PTIMAX-A
• For Use With: 2135PQXPA
• For Use With: 2135QXPA
• For Use With: 2135QXPA-2

IR 2135PTIMAX

1/2" Air Impact Wrench, 1100 ft-lb Torque, Titanium Hammercase, Pin Retainer, Pistol

Description: Powerful, durable and reliable, the 2135PTiMAX Series Impact Wrench will excel in any market.

Features And Benefits:

• Power: This wrench's high torque output and power regulator allow easy control over your tool.
• Durability: With a composite housing and a hammer case made of titanium, this wrench can endure repeated drops and harsh environments.
• Reliability: With twin hammer mechanism and powerful motor, the 2135PTiMAX is built not only for performance, but to last. Comes with a 1-year warranty.

Product Application and Uses:

Designed to remove and install threaded fasteners for vehicle repair, general industrial, facility maintenance applications.

• Actuation/Throttle Type/Switch Type: Trigger
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 5
• Average Air Consumption (l/min): 142

• Blows per Min: 1250

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/2
• Drive Type: Square
• Duty Rating: Maintenance Duty

• End Plates: Aluminum with Hard-coating
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 109.2 / 120.2

• Hammer Case: Titanium
• Handle Material: Composite
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 99.8 / 110.8

• Max Bolt Diameter (in): 9/16
• Max Free Speed (rpm): 9800
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 780
• Max Torque (in-lb): 9364
• Max Torque (nm): 1058
• Min Hose Size (in): 3/8
• Motor: Reverse Bias

• Number of Power Settings: 4
• Nut-busting/Breakaway Torque (ft-lb): 1100
• Nut-busting/Breakaway Torque (in-lb): 13196
• Nut-busting/Breakaway Torque (nm): 1491
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 278.48
• Product Length (in): 7.35

• Product Width (in): 2.7
• Product Height (in): 7.2
• Product Weight (lb): 3.95
• Recommended Forward Torque Range (ft-lb): 600
• Recommended Forward Torque Range (in-lb): 7196
• Recommended Forward Torque Range (nm): 813
• Retainer Type: Pin Detent

• Side to Center Distance (in): 1.37
• Side to Center Distance (mm): 35

• Special Features: Titanium Hammer case
• Speed Setting: Variable Speed
• Standards/Certifications: CE

• Tool Type: Full-size
• Vanes: 7
• Vibration Level (m/s2): 13.3
• Warranty: 1-year

• Accessories: 2135M-BOOT
• Accessories: 2350-BOOT

• Lubrication: 105-LBK1
• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 2135-638
• Parts: 2135-THK1

• Parts: 2135-TK2
• Parts: 2135PTI-THK1
• Parts: 231B-A726

IR 2135PTIMAX-A40

IR 2135-K75

Button kit for Ingersoll Rand 2135 Series Impact Wrench

IR 2135TIMAX-A40

Housing Assembly for Ingersoll Rand 2135 Series Impact Wrench

IR 2135PTI-A40

IR 2135-THK1

Hammer Kit for Ingersoll Rand 2135 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2135Timax and 2135QTimax Impact Wrenches.

• Includes: Hammer Case Gasket, (2) Hammers, (2) Hammer Pins, Anvil Assembly, Grease Kit

• For Use With: 2135QXPA

IR 2135-TK2

Tune-up Kit for Ingersoll Rand 2135 Series Impact Wrench

• Includes: Socket Retainer, Gaskets, Inlet parts kit, Vane pack, O-Rings, Seals, Bearings, Grease kit

• For Use With: 2135PTIMAX
• For Use With: 2135PTIMAX-A
• For Use With: 2135PTIMAX-AP
• For Use With: 2135QTL-2
• For Use With: 2135QXPA
• For Use With: 2135QXPA-2

IR 2141-11

End Plate for Ingersoll Rand 2141 and 2145 Series Impact Wrench

IR 2141-283

Gasket for Ingersoll Rand 2141 Series Impact Wrench

IR 2141-36

IR 2141-3

Cylinder for Ingersoll Rand 2141 Series Impact Wrench

IR 2141-57

Inlet Clip Replacement Partfor Ingersoll Rand 2141 Series, 2145 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2145 Series Impact Wrench

IR 2141-638

Screw for Ingersoll Rand 2141 Series Impact Wrench

IR 2141-53

IR 2135-941

Bushing for Ingersoll Rand 2135 Series Impact Wrench

IR 2141-704

IR 2141-724

Hammer for Ingersoll Rand 2141 Series Impact Wrench

IR 2141-42-6

Vane Pack, Set of 6 for Ingersoll Rand 2141 Series Impact Wrench

IR 2141-A329

Valve Assembly Kit for Ingersoll Rand 2141 Series, 2145 Series, 2155 Series Impact Wrench

IR 2145-11

Front End Plate for Ingersoll Rand 2145 Series Impact Wrench

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6

IR 2141-A40

IR 2141-A93

Trigger Assembly for Ingersoll Rand 2141, 2145 Series Impact Wrench

IR 2145-11X

Wear Plate for Ingersoll Rand 2145 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2145QIMAX, 2145QIMAX-3, 2145QIMAX-6, and 2155QIMAX Impacts

• For Use With: 2145QIMAX
• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6
• For Use With: 2155QIMAX

IR 2141-A626

IR 2141-K303

Inlet Kit Replacement Part

Product Application and Uses:

For Use with Ingersoll Rand 2145QiMAX and 2155QiMAX Series Impact Wrenches

• Includes: O-ring Seal, Throttle Spring, Throttle Valve, Valve Seat, Seat Support, Retainer

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-3-AP
• For Use With: 2145QIMAX-6
• For Use With: 2145QIMAX-6-AP
• For Use With: 2145QIMAX-AP
• For Use With: 2145QIMAX-SP
• For Use With: 2155QIMAX

IR 2145QIMAX-6-A40

IR 2146-A3

Cylinder Rotor Pressure Gauge Assembly for Ingersoll Rand 2146 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2146Q1MAX, 2146Q1MAX-3, 2146Q1MAX-6 and 2146Q2MAX Impact Wrenches

• Includes: Ball Bearing Cylinder, Spacer, Cylinder, Rotor

• For Use With: 2146Q1MAX
• For Use With: 2146Q1MAX-3
• For Use With: 2146Q1MAX-6
• For Use With: 2146Q2MAX

IR 2146Q1MAX

3/4" Air Impact Wrench, Quiet, 2000 ft-lb Torque, Friction Ring-Thru-hole Retainer, Pistol

Description: The 2146MAX Series Impact Wrenches- including the 2146Q1MAX, is the most powerful 3/4" impact in its class. These tools have been engineered with an innovative pressure gauge that ensures optimized air flow and pressure. These quiet impact wrenches help you maximize productivity across a range of jobs and tackle anything that comes your way. And because you can avoid operating below and above the recommended 90 PSI air pressure, your tool will last longer and perform more reliably. Work more and spend less, the 2146MAX Series helps you do what you do best.

Features And Benefits:

• Cold-forged twin hammer impact mechanism and motor deliver 2,000 ft-lbs of Nut Busting Torque, durability, and efficiency
• Steel hammer case stands up to drops and everyday abuse
• Patented one-hand forward/reverse and feather-touch trigger provides maximum control
• Ingersoll Rand's Quiet Technology reduces the sound of the tool, sparing your ears without sacrificing a single ounce of power
• Pressure gauge improves productivity and prolongs product life
• A lightweight, balanced, air impact wrench that weighs just 7.8 lbs
• Standard 3/4" drive size and length for access to confined bolt locations
• Impact and chemical-resistant housing protects against repeated drops and exposure to shop fluids
• Optimized for the vehicle repair industry, heavy trucks, tire lanes, fleet maintenance, body shops, general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding and construction

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 36
• Air Consumption @ Load (l/min): 1090
• Air Inlet: 1/2in NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 14
• Average Air Consumption (l/min): 396

• Blows per Min: 1075

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Maintenance Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 88.8 / 99.8

• Hammer Case: Steel
• Handle Material: Composite
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 94.3 /105.3

• Max Bolt Diameter (in): 1
• Max Free Speed (rpm): 5500
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1453
• Max Torque (in-lb): 17436
• Max Torque (nm): 1970
• Min Hose Size (in): 1/2
• Motor: Reverse Bias

• Number of Power Settings: 4
• Nut-busting/Breakaway Torque (ft-lb): 2000
• Nut-busting/Breakaway Torque (in-lb): 24003
• Nut-busting/Breakaway Torque (nm): 2712
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 256.4
• Product Length (in): 8.47

• Product Width (in): 3.5
• Product Height (in): 8.19
• Product Weight (lb): 7.8
• Quiet Tool: Yes
• Recommended Forward Torque Range (ft-lb): 200-900
• Recommended Forward Torque Range (in-lb): 2390-10798
• Recommended Forward Torque Range (nm): 27

IR 2146Q2MAX

1" Air Impact Wrench, Quiet, 2000 ft-lb Torque, Friction Ring-Thru-hole Retainer, Pistol

Description: The 2146MAX Series Impact Wrenches - including the 2146Q2MAX, is the most powerful impact in its class. These quiet impact wrenches help you maximize productivity across a range of jobs and tackle anything that comes your way. And because you can avoid operating below and above the recommended 90 PSI air pressure, your tool will last longer and perform more reliably. Work more and spend less - the 2146MAX Series helps you do what you do best.

Features And Benefits:

• Cold-forged twin hammer impact mechanism and motor deliver 2,000 ft-lbs of Nut Busting Torque, durability, and efficiency
• Steel hammer case stands up to drops and everyday abuse
• Patented one-hand forward/reverse and feather-touch trigger provides maximum control
• Ingersoll Rand's Quiet Technology reduces the sound of the tool, sparing your ears without sacrificing a single ounce of power
• Pressure gauge improves productivity and prolongs product life
• A lightweight, balanced, air impact wrench that weighs just 8.0 lbs
• 1" Drive Square for larger socket sizes
• Impact and chemical-resistant housing protects against repeated drops and exposure to shop fluids
• Optimized for the vehicle repair industry, heavy trucks, tire lanes, fleet maintenance, body shops, general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding and construction

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 36
• Air Consumption @ Load (l/min): 1090
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 14
• Average Air Consumption (l/min): 396

• Blows per Min: 1075

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Maintenance Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 88.8 / 99.8

• Hammer Case: Steel
• Handle Material: Composite
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 94.3 /105.3

• Max Bolt Diameter (in): 1
• Max Free Speed (rpm): 5500
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1453
• Max Torque (in-lb): 17436
• Max Torque (nm): 1970
• Min Hose Size (in): 1/2
• Motor: Reverse Bias

• Number of Power Settings: 4
• Nut-busting/Breakaway Torque (ft-lb): 2000
• Nut-busting/Breakaway Torque (in-lb): 24003
• Nut-busting/Breakaway Torque (nm): 2712
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 250
• Product Length (in): 8.5

• Product Width (in): 3.5
• Product Height (in): 8.2
• Product Weight (lb): 8
• Quiet Tool: Yes
• Recommended Forward Torque Range (ft-lb): 200-900
• Recommended Forward Torque Range (in-lb): 2390-10798
• Recommended Forward Torque Range (nm): 270-1220
• Recommended Reverse Torque (ft-lb): 199-1003
• Recommended Reverse Torque (nm): 270-1360
• Retainer Type: Fricti

IR 2145QIMAX-A40

Housing Assembly for Ingersoll Rand 2145QiMAX Impact Wrench

• For Use With: 2145QIMAX

IR 2146-638

IR 2146-TK2

Tune Up Kit for Ingersoll Rand 2146 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2146Q1MAX, 2146Q1MAX-3, 2146Q1MAX-6 and 2146Q2MAX Impact Wrenches

• Includes: Motor Gasket, O-Ring (Front-Black), O-Ring (Back-Red), (6) Vanes, (4) M4 Motor Screws, Hammer Case Gasket, O-Ring, Reverse Valve O-Ring (Black-Top), Reverse Valve O-Ring (Bottom-Blue), Inlet Parts Kit (O-Ring Seal, Throttle Spring, Throttle Valve, Valve Seat, Seat Support, Retainer)

• For Use With: 2146Q1MAX
• For Use With: 2146Q1MAX-3
• For Use With: 2146Q1MAX-6
• For Use With: 2146Q2MAX

IR 2145-A626

Anvil Assembly for Ingersoll Rand 2145TIMAX Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2145QIMAX Standard Anvil

• For Use With: 2145QIMAX-AP
• For Use With: 2146Q1MAX

IR 2145-K75RD

Button Kit for Ingersoll Rand 2145, 2155 Series Impact Wrench

Product Application and Uses:

For use with 2145 and 2155 Series Impact Wrench

• Includes: Forward, Reverse Buttons

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6
• For Use With: 2155QIMAX

IR 2145-THK2

Hammer Mechanism Replacement Part for Ingersoll Rand 2145 and 2155 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2145 and 2155 Series Impact Wrench

• Includes: (2) Hammer, Hammer Frame, (2) Hammer pins

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-3-AP
• For Use With: 2145QIMAX-6
• For Use With: 2145QIMAX-6-AP
• For Use With: 2145QIMAX-AP
• For Use With: 2145QIMAX-SP
• For Use With: 2155QIMAX

IR 2146-K75

Button Kit for Ingersoll Rand 2146 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2146Q1MAX, 2146Q1MAX-3, 2146Q1MAX-6 and 2146Q2MAX Impact Wrenches

• Includes: Forward and Reverse Buttons

• For Use With: 2146Q1MAX
• For Use With: 2146Q1MAX-3
• For Use With: 2146Q1MAX-6
• For Use With: 2146Q2MAX

IR 2155-K425

Socket Retainer Kit for Ingersoll Rand W8000 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand W8000 Series Air Impact Wrenches.

• Includes: Socket Retainer Spring and O-Ring

• For Use With: W8171
• For Use With: W8171-K2
• For Use With: W8191
• For Use With: W8191-K2
• For Use With: W8571
• For Use With: W8571-K2
• For Use With: W8591
• For Use With: W8591-K2

IR 2145-D727

Hammer Case Assembly for Ingersoll Rand 2145, 2155 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2145, 2155 Series Impact Wrench

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6
• For Use With: 2155QIMAX

IR 2145-42-7

Vane Pack for Ingersoll Rand 2145 Series Impact Wrench, 7-Pack

Product Application and Uses:

For use with Ingersoll Rand 2145 Series Impact Wrench

• Includes: (7) vanes

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6

IR 2145QIMAX-300

IR 2145-TK2

Tune-up Kit for Ingersoll Rand 2145 Series Impact Wrench

• For Use With: 2145QIMAX-AP
• For Use With: 2155QIMAX

IR 2146-42-6

IR 2145-36RD

Hammer Case Gasket for Ingersoll Rand 2145 Series Impact Wrench

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6

IR 2145QIMAX

IR 2145-53

Rotor for Ingersoll Rand 2145 Series Impact Wrench

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6

IR 2146-A11

End Plate for Ingersoll Rand 2146 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2146Q1MAX, 2146Q1MAX-3, 2146Q1MAX-6 and 2146Q2MAX Impact Wrenches

• Includes: Front Endplate, Bearing

• For Use With: 2146Q1MAX
• For Use With: 2146Q1MAX-3
• For Use With: 2146Q1MAX-6
• For Use With: 2146Q2MAX

IR 2146Q1MAX-3

3/4" Air Impact Wrench, 3" Ext Anvil, Quiet, 2,000 ft-lb Torque, Friction Ring-Thru-hole Retainer, Pistol

Description: The 2146MAX Series Impact Wrenches- including the 2146Q1MAX-3, is the most powerful 3/4" impact in its class. These tools have been engineered with an innovative pressure gauge that ensures optimized air flow and pressure. These quiet impact wrenches help you maximize productivity across a range of jobs and tackle anything that comes your way. And because you can avoid operating below and above the recommended 90 PSI air pressure, your tool will last longer and perform more reliably. Work more and spend less, the 2146MAX Series helps you do what you do best.

Features And Benefits:

• Cold-forged twin hammer impact mechanism and motor deliver 2,000 ft-lbs of Nut Busting Torque, durability, and efficiency
• Steel hammer case stands up to drops and everyday abuse
• Patented one-hand forward/reverse and feather-touch trigger provides maximum control
• Ingersoll Rand's Quiet Technology reduces the sound of the tool, sparing your ears without sacrificing a single ounce of power
• Pressure gauge improves productivity and prolongs product life
• A lightweight, balanced, air impact wrench that weighs just 8.8 lbs
• Extended reach 3" anvil provides better accessibility to bolts
• Impact and chemical-resistant housing protects against repeated drops and exposure to shop fluids
• Optimized for the vehicle repair industry, heavy trucks, tire lanes, fleet maintenance, body shops, general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding and construction

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 36
• Air Consumption @ Load (l/min): 1090
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: 3" Extended
• Average Air Consumption (cfm): 14
• Average Air Consumption (l/min): 396

• Blows per Min: 1075

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Maintenance Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 88.8 / 99.8

• Hammer Case: Steel
• Handle Material: Composite
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 94.3 /105.3

• Max Bolt Diameter (in): 1
• Max Free Speed (rpm): 5500
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1453
• Max Torque (in-lb): 17436
• Max Torque (nm): 1970
• Min Hose Size (in): 1/2
• Motor: Reverse Bias

• Number of Power Settings: 4
• Nut-busting/Breakaway Torque (ft-lb): 2000
• Nut-busting/Breakaway Torque (in-lb): 24003
• Nut-busting/Breakaway Torque (nm): 2712
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 227.3
• Product Length (in): 11.5

• Product Width (in): 3.5
• Product Height (in): 8.2
• Product Weight (lb): 8.8
• Quiet Tool: Yes
• Recommended Forward Torque Range (ft-lb): 200-900
• Recommended Forward Torque Range (in-lb): 2390-10798
• Recommended Forward Torque Range (n

IR 2146-K3

Cylinder for Ingersoll Rand 2146 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2146Q1MAX, 2146Q1MAX-3, 2146Q1MAX-6 and 2146Q2MAX Impact Wrenches

• For Use With: 2146Q1MAX
• For Use With: 2146Q1MAX-3
• For Use With: 2146Q1MAX-6
• For Use With: 2146Q2MAX

IR 2145-D565

Inlet Bushing Assembly for Ingersoll Rand 2145 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2145 Series Impact Wrench

• Includes: Inlet bushing, Inlet Pre-screen, Inlet Clip, Inlet Parts Kit

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6

IR 2145-D93BK

Trigger Assembly for Ingersoll Rand 2145, 2155 Series Impact Wrench

Product Application and Uses:

For use with 2145 and 2155 Series Impact Wrench

• Includes: Trigger, O-ring

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6
• For Use With: 2155QIMAX

IR 2146Q1MAX-6

3/4" Air Impact Wrench, 6" Ext Anvil, Quiet, 2,000 ft-lb Torque, Friction Ring-Thru-hole Retainer, Pistol

Description: The 2146MAX Series Impact Wrenches- including the 2146Q1MAX-6, is the most powerful 3/4" impact in its class. These tools have been engineered with an innovative pressure gauge that ensures optimized air flow and pressure. These quiet impact wrenches help you maximize productivity across a range of jobs and tackle anything that comes your way. And because you can avoid operating below and above the recommended 90 PSI air pressure, your tool will last longer and perform more reliably. Work more and spend less, the 2146MAX Series helps you do what you do best.

Features And Benefits:

• Cold-forged twin hammer impact mechanism and motor deliver 2,000 ft-lbs of Nut Busting Torque, durability, and efficiency
• Steel hammer case stands up to drops and everyday abuse
• Patented one-hand forward/reverse and feather-touch trigger provides maximum control
• Ingersoll Rand's Quiet Technology reduces the sound of the tool, sparing your ears without sacrificing a single ounce of power
• Pressure gauge improves productivity and prolongs product life
• A lightweight, balanced, air impact wrench that weighs just 10.1 lbs
• Long reach 6" extended anvil for improved access to bolts
• Impact and chemical-resistant housing protects against repeated drops and exposure to shop fluids
• Optimized for the vehicle repair industry, heavy trucks, tire lanes, fleet maintenance, body shops, general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding and construction

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 36
• Air Consumption @ Load (l/min): 1090
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: 6" Extended
• Average Air Consumption (cfm): 14
• Average Air Consumption (l/min): 396

• Blows per Min: 1075

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Maintenance Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 88.8 / 99.8

• Hammer Case: Steel
• Handle Material: Composite
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 94.3 /105.3

• Max Bolt Diameter (in): 1
• Max Free Speed (rpm): 5500
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1453
• Max Torque (in-lb): 17436
• Max Torque (nm): 1970
• Min Hose Size (in): 1/2
• Motor: Reverse Bias

• Number of Power Settings: 4
• Nut-busting/Breakaway Torque (ft-lb): 2000
• Nut-busting/Breakaway Torque (in-lb): 24003
• Nut-busting/Breakaway Torque (nm): 2712
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 198
• Product Length (in): 14.5

• Product Width (in): 3.5
• Product Height (in): 8.2
• Product Weight (lb): 10.1
• Quiet Tool: Yes
• Recommended Forward Torque Range (ft-lb): 200-900
• Recommended Forward Torque Range (in-lb): 2390-10798
• Recommended Forward Torque Range (nm): <

IR 2161-11

IR 2161-12

IR 2161-207

Motor Clamp Washer Service Part for Ingersoll Rand Power Tools

IR 2161-36

Hammer Case Gasket for Ingersoll Rand 2161, 2171 Series Impact Wrench

• For Use With: 2161P
• For Use With: 2161XP
• For Use With: 2161XP-6
• For Use With: 2171P
• For Use With: 2171XP

IR 2161-366

Vertical Hanger Kit Service Part for Ingersoll Rand Impact Wrench

• For Use With: 2161P
• For Use With: 2925P1TI

IR 2161-638

IR 2161-739

Backcap Gasket for Ingersoll Rand 2161 and 2171 Series Impact Wrench

• For Use With: 2161P
• For Use With: 2161XP
• For Use With: 2161XP-6
• For Use With: 2171P
• For Use With: 2171XP

IR 2161-A465A

IR 2161-A93

IR 2161-TK2

Tune-up Kit for Ingersoll Rand 2161 Series Impact Wrench

• For Use With: 2161P
• For Use With: 2161XP
• For Use With: 2161XP-6
• For Use With: 2171P
• For Use With: 2171XP

IR 2161XP-626

3/4" Drive Anvil for 2161XP Air Impact Wrench

• For Use With: 2161XP

IR 216B-53

IR 216B

3/8" Air Impact Wrench, 200 ft-lb Torque, Friction Ring Retainer, Inline

Description: Full of power with an easy to access design, the 216B Straight Impact Wrench ensures every job is a job well done.

Features And Benefits:

• Durable: Combining an aluminum hammer case with metal housing ensures this wrench is both durable and lightweight.
• Power: The ball and cam mechanism delivers a high output of power without ever risking your tool stalling out.
• Access: Thanks to its straight grip and overall design, this impact wrench is great for use in hard-to-reach spaces.

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Butteryfly Trigger
• Air Consumption @ Load (cfm): 19
• Air Consumption @ Load (l/min): 538
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 3
• Average Air Consumption (l/min): 85

• Blows per Min: 1600

• Color: Silver
• Configuration/Handle Type: Straight
• Drive Size (in): 3/8
• Drive Type: Square
• Duty Rating: General Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 94.8 / 105.8

• Hammer Case: Aluminum
• Handle Material: Aluminum
• Housing Material: Aluminum
• Impact Mechanism: Pin Clutch
• Impacting Sound Pressure/Power Db(A): 90.0 / 101.0

• Max Bolt Diameter (in): 7/16
• Max Free Speed (rpm): 8500
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 200
• Max Torque (in-lb): 2400
• Max Torque (nm): 271
• Min Hose Size (in): 3/8
• Motor: Non-Biased

• Power Source: Air Powered
• Product Length (in): 7.7

• Product Width (in): 2.3
• Product Height (in): 1.9
• Product Weight (lb): 2.8
• Recommended Forward Torque Range (ft-lb): 15-160
• Recommended Forward Torque Range (in-lb): 177-1921
• Recommended Forward Torque Range (nm): 20-217
• Retainer Type: Friction Ring

• Side to Center Distance (in): 1.2
• Side to Center Distance (mm): 30

• Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744

• Tool Type: Full-size
• Vanes: 6
• Vibration Level (m/s2): 5.2
• Warranty: 1-year

• Accessories: SK3H8N
• Accessories: SK3M8N

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 216B-A626

IR 216B-A11

IR 216B-704

IR 216B-630

IR 216B-721

IR 216B-A626

Anvil Assembly Replacement Part For Ingersoll Rand 216B Series Air Impact Wrench

• For Use With: 216B

IR 216B-A165

IR 2175-K48

IR 2190-A92

IR 216B-728

IR 2175-283

IR 2190-SRK1
