INGERSOLL-RAND IR TOOL S12880

IR QXWD2AT018PS06

3/8in 20V, Cordless Angle QX Limitless Precision Fastening, 159 in-lb, 500 RPM

Description: QX Connected Series has been instrumental in helping more organizations take control of their fastening processes through its simple, flexible, and capable performance. With the QX Limitless platform we're adding connected, controlled, and compliant to the bottom line. Dual-band communication technology delivers a seamless, uninterrupted connection - and across a greater communication rage than other cordless fastening systems can offer. QX Limitless can accommodate more tools in a single system, too - up to 10 tools on INSIGHTqcx controllers. Plus, it keeps unwanted connections at bay, meeting more of today's stringent corporate cybersecurity regulations to ensure greater data protection. Add in speedy data transfer and multiple programming methods, and there's simply no limit to the impact the QX Limitless system can have on your fastening projects and applications.

Features And Benefits:

• CONNECTIVITY: The QX-Limitless platform enhances seamless, plant-wide connectivity across a broader range where access points share the same SSID and password. Incorporating dual band communication technology, the system helps to eliminate communication breakdowns in high-traffic work zones to ensure no loss in production.
• Dual Band Communication Seamlessly Switches Between 2.4 and 5 Ghz Bands
• Industry-Leading Communication Range for Plant-Wide Connectivity Up to 65 Meters
• Reduces Limitation of Communications Distance Between Tools and Controller
• COMPLETE CONTROL: The QX-Limitless limits your hardware footprint by connecting more tools on a single platform. This fast, reliable system delivers greater control over more tools, delivering quick, complete data transfer between devices and reducing installation costs. Plus, your tools are ready for the next cycle much sooner, ensuring increased production efficiency.
• Connects Up to 10 Tools with INSIGHTqcx Controllers
• Limits Hardware Footprint
• Up to 40% Reduction in Initial Hardware Investments
• Transfers End of Run Fastening Data Quickly
• Tools Are Ready for the Next Cycle 50% Faster

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/8
• Drive Type: Square

• Max Free Speed (rpm): 500
• Max Torque (ft-lb): 13
• Max Torque (in-lb): 159
• Max Torque (nm): 18
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 24.34

• Product Weight (lb): 2.8
• Recommended Forward Torque Range (ft-lb): 2.7-13
• Recommended Forward Torque Range (in-lb): 32-159
• Recommended Forward Torque Range (nm): 3.6-18
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 0.51
• Side to Center Distance (mm): 13

• User Interface: Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: 2.4 GHz Wi-Fi
• Wireless Tool Tracking: 5 GHz Wi-Fi
• Wireless Tool Tracking: USB-C
• Wireless Tool Tracking: 802.15.4
• Wireless Tool Tracking: Bluetooth

IR QXWD2AT005PQ04

1/4" Hex 20V, Cordless Angle QX Limitless Precision Fastening, 44 in-lb, 1213 RPM

Description: QX Connected Series has been instrumental in helping more organizations take control of their fastening processes through its simple, flexible, and capable performance. With the QX Limitless platform we're adding connected, controlled, and compliant' to the bottom line. Dual-band communication technology delivers a seamless, uninterrupted connection - and across a greater communication rage than other cordless fastening systems can offer. QX Limitless can accommodate more tools in a single system, too - up to 10 tools on INSIGHTqcx controllers. Plus, it keeps unwanted connections at bay, meeting more of today's stringent corporate cybersecurity regulations to ensure greater data protection. Add in speedy data transfer and multiple programming methods, and there's simply no limit to the impact the QX Limitless system can have on your fastening projects and applications.

Features And Benefits:

• CONNECTIVITY: The QX-Limitless platform enhances seamless, plant-wide connectivity across a broader range where access points share the same SSID and password. Incorporating dual band communication technology, the system helps to eliminate communication breakdowns in high-traffic work zones to ensure no loss in production.
• Dual Band Communication Seamlessly Switches Between 2.4 and 5 Ghz Bands
• Industry-Leading Communication Range for Plant-Wide Connectivity Up to 65 Meters
• Reduces Limitation of Communications Distance Between Tools and Controller
• COMPLETE CONTROL: The QX-Limitless limits your hardware footprint by connecting more tools on a single platform. This fast, reliable system delivers greater control over more tools, delivering quick, complete data transfer between devices and reducing installation costs. Plus, your tools are ready for the next cycle much sooner, ensuring increased production efficiency.
• Connects Up to 10 Tools with INSIGHTqcx Controllers
• Limits Hardware Footprint
• Up to 40% Reduction in Initial Hardware Investments
• Transfers End of Run Fastening Data Quickly
• Tools Are Ready for the Next Cycle 50% Faster

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1/4
• Drive Type: Hex

• Max Free Speed (rpm): 1213
• Max Torque (ft-lb): 3.7
• Max Torque (in-lb): 44
• Max Torque (nm): 5
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 21.73

• Product Weight (lb): 2.5
• Recommended Forward Torque Range (ft-lb): 0.7-3.7
• Recommended Forward Torque Range (in-lb): 8.9-44
• Recommended Forward Torque Range (nm): 1.0-5
• Retainer Type: Quick Change
• Reversible: Reversible

• Side to Center Distance (in): 0.36
• Side to Center Distance (mm): 9

• User Interface: Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: 2.4 GHz Wi-Fi
• Wireless Tool Tracking: 5 GHz Wi-Fi
• Wireless Tool Tracking: USB-C
• Wireless Tool Tracking: 802.15.4
• Wireless Tool Tracking: Bluetooth

IR QXWD2AT027PS06

3/8in 20V, Cordless Angle QX Limitless Precision Fastening, 239 in-lb, 330 RPM

Description: QX Connected Series has been instrumental in helping more organizations take control of their fastening processes through its simple, flexible, and capable performance. With the QX Limitless platform we're adding connected, controlled, and compliant to the bottom line. Dual-band communication technology delivers a seamless, uninterrupted connection - and across a greater communication rage than other cordless fastening systems can offer. QX Limitless can accommodate more tools in a single system, too - up to 10 tools on INSIGHTqcx controllers. Plus, it keeps unwanted connections at bay, meeting more of today's stringent corporate cybersecurity regulations to ensure greater data protection. Add in speedy data transfer and multiple programming methods, and there's simply no limit to the impact the QX Limitless system can have on your fastening projects and applications.

Features And Benefits:

• CONNECTIVITY: The QX-Limitless platform enhances seamless, plant-wide connectivity across a broader range where access points share the same SSID and password. Incorporating dual band communication technology, the system helps to eliminate communication breakdowns in high-traffic work zones to ensure no loss in production.
• Dual Band Communication Seamlessly Switches Between 2.4 and 5 Ghz Bands
• Industry-Leading Communication Range for Plant-Wide Connectivity Up to 65 Meters
• Reduces Limitation of Communications Distance Between Tools and Controller
• COMPLETE CONTROL: The QX-Limitless limits your hardware footprint by connecting more tools on a single platform. This fast, reliable system delivers greater control over more tools, delivering quick, complete data transfer between devices and reducing installation costs. Plus, your tools are ready for the next cycle much sooner, ensuring increased production efficiency.
• Connects Up to 10 Tools with INSIGHTqcx Controllers
• Limits Hardware Footprint
• Up to 40% Reduction in Initial Hardware Investments
• Transfers End of Run Fastening Data Quickly
• Tools Are Ready for the Next Cycle 50% Faster

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/8
• Drive Type: Square

• Max Free Speed (rpm): 330
• Max Torque (ft-lb): 20
• Max Torque (in-lb): 239
• Max Torque (nm): 27
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 21.73

• Product Weight (lb): 3.7
• Recommended Forward Torque Range (ft-lb): 4.0-20
• Recommended Forward Torque Range (in-lb): 48-239
• Recommended Forward Torque Range (nm): 5.4-27
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 0.67
• Side to Center Distance (mm): 17

• User Interface: Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: 2.4 GHz Wi-Fi
• Wireless Tool Tracking: 5 GHz Wi-Fi
• Wireless Tool Tracking: USB-C
• Wireless Tool Tracking: 802.15.4
• Wireless Tool Tracking: Bluetooth

IR QXWD2AT027ES06

3/8in 20V, Cordless Angle ETS QX Limitless Precision Fastening, 239 in-lb, 330 RPM

Description: QX Connected Series has been instrumental in helping more organizations take control of their fastening processes through its simple, flexible, and capable performance. With the QX Limitless platform we're adding connected, controlled, and compliant to the bottom line. Dual-band communication technology delivers a seamless, uninterrupted connection - and across a greater communication rage than other cordless fastening systems can offer. QX Limitless can accommodate more tools in a single system, too - up to 10 tools on INSIGHTqcx controllers. Plus, it keeps unwanted connections at bay, meeting more of today's stringent corporate cybersecurity regulations to ensure greater data protection. Add in speedy data transfer and multiple programming methods, and there's simply no limit to the impact the QX Limitless system can have on your fastening projects and applications.

Features And Benefits:

• CONNECTIVITY: The QX-Limitless platform enhances seamless, plant-wide connectivity across a broader range where access points share the same SSID and password. Incorporating dual band communication technology, the system helps to eliminate communication breakdowns in high-traffic work zones to ensure no loss in production.
• Dual Band Communication Seamlessly Switches Between 2.4 and 5 Ghz Bands
• Industry-Leading Communication Range for Plant-Wide Connectivity Up to 65 Meters
• Reduces Limitation of Communications Distance Between Tools and Controller
• COMPLETE CONTROL: The QX-Limitless limits your hardware footprint by connecting more tools on a single platform. This fast, reliable system delivers greater control over more tools, delivering quick, complete data transfer between devices and reducing installation costs. Plus, your tools are ready for the next cycle much sooner, ensuring increased production efficiency.
• Connects Up to 10 Tools with INSIGHTqcx Controllers
• Limits Hardware Footprint
• Up to 40% Reduction in Initial Hardware Investments
• Transfers End of Run Fastening Data Quickly
• Tools Are Ready for the Next Cycle 50% Faster

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle-ETS (ergonomic tightening system)
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/8
• Drive Type: Square

• Max Free Speed (rpm): 330
• Max Torque (ft-lb): 20
• Max Torque (in-lb): 239
• Max Torque (nm): 27
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 2.7

• Product Weight (lb): 3.7
• Recommended Forward Torque Range (ft-lb): 4.0-20
• Recommended Forward Torque Range (in-lb): 48-239
• Recommended Forward Torque Range (nm): 5.4-27
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 0.68
• Side to Center Distance (mm): 17

• User Interface: Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: 2.4 GHz Wi-Fi
• Wireless Tool Tracking: 5 GHz Wi-Fi
• Wireless Tool Tracking: USB-C
• Wireless Tool Tracking: 802.15.4
• Wireless Tool Tracking: Bluetooth

IR QXWD2PT012ES06

3/8in 20V, Cordless ETS QX Limitless Precision Fastening, 106 in-lb, 750 RPM, Pistol

Description: QX Connected Series has been instrumental in helping more organizations take control of their fastening processes through its simple, flexible, and capable performance. With the QX Limitless platform we're adding connected, controlled, and compliant to the bottom line. Dual-band communication technology delivers a seamless, uninterrupted connection - and across a greater communication rage than other cordless fastening systems can offer. QX Limitless can accommodate more tools in a single system, too - up to 10 tools on INSIGHTqcx controllers. Plus, it keeps unwanted connections at bay, meeting more of today's stringent corporate cybersecurity regulations to ensure greater data protection. Add in speedy data transfer and multiple programming methods, and there's simply no limit to the impact the QX Limitless system can have on your fastening projects and applications.

Features And Benefits:

• CONNECTIVITY: The QX-Limitless platform enhances seamless, plant-wide connectivity across a broader range where access points share the same SSID and password. Incorporating dual band communication technology, the system helps to eliminate communication breakdowns in high-traffic work zones to ensure no loss in production.
• Dual Band Communication Seamlessly Switches Between 2.4 and 5 Ghz Bands
• Industry-Leading Communication Range for Plant-Wide Connectivity Up to 65 Meters
• Reduces Limitation of Communications Distance Between Tools and Controller
• COMPLETE CONTROL: The QX-Limitless limits your hardware footprint by connecting more tools on a single platform. This fast, reliable system delivers greater control over more tools, delivering quick, complete data transfer between devices and reducing installation costs. Plus, your tools are ready for the next cycle much sooner, ensuring increased production efficiency.
• Connects Up to 10 Tools with INSIGHTqcx Controllers
• Limits Hardware Footprint
• Up to 40% Reduction in Initial Hardware Investments
• Transfers End of Run Fastening Data Quickly
• Tools Are Ready for the Next Cycle 50% Faster

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol - ETS (ergonomic tightening system)
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/8
• Drive Type: Square

• Max Free Speed (rpm): 750
• Max Torque (ft-lb): 8.9
• Max Torque (in-lb): 106
• Max Torque (nm): 12
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 7.99

• Product Weight (lb): 2
• Recommended Forward Torque Range (ft-lb): 1.8-8.9
• Recommended Forward Torque Range (in-lb): 21-106
• Recommended Forward Torque Range (nm): 2.4-12
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 1
• Side to Center Distance (mm): 25

• User Interface: Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: 2.4 GHz Wi-Fi
• Wireless Tool Tracking: 5 GHz Wi-Fi
• Wireless Tool Tracking: USB-C
• Wireless Tool Tracking: 802.15.4
• Wireless Tool Tracking: Bluetooth

IR QXWD2PT012PS06

3/8in 20V, Cordless QX Limitless Precision Fastening, 106 in-lb, 750 RPM, Pistol

Description: QX Connected Series has been instrumental in helping more organizations take control of their fastening processes through its simple, flexible, and capable performance. With the QX Limitless platform we're adding connected, controlled, and compliant to the bottom line. Dual-band communication technology delivers a seamless, uninterrupted connection - and across a greater communication rage than other cordless fastening systems can offer. QX Limitless can accommodate more tools in a single system, too - up to 10 tools on INSIGHTqcx controllers. Plus, it keeps unwanted connections at bay, meeting more of today's stringent corporate cybersecurity regulations to ensure greater data protection. Add in speedy data transfer and multiple programming methods, and there's simply no limit to the impact the QX Limitless system can have on your fastening projects and applications.

Features And Benefits:

• CONNECTIVITY: The QX-Limitless platform enhances seamless, plant-wide connectivity across a broader range where access points share the same SSID and password. Incorporating dual band communication technology, the system helps to eliminate communication breakdowns in high-traffic work zones to ensure no loss in production.
• Dual Band Communication Seamlessly Switches Between 2.4 and 5 Ghz Bands
• Industry-Leading Communication Range for Plant-Wide Connectivity Up to 65 Meters
• Reduces Limitation of Communications Distance Between Tools and Controller
• COMPLETE CONTROL: The QX-Limitless limits your hardware footprint by connecting more tools on a single platform. This fast, reliable system delivers greater control over more tools, delivering quick, complete data transfer between devices and reducing installation costs. Plus, your tools are ready for the next cycle much sooner, ensuring increased production efficiency.
• Connects Up to 10 Tools with INSIGHTqcx Controllers
• Limits Hardware Footprint
• Up to 40% Reduction in Initial Hardware Investments
• Transfers End of Run Fastening Data Quickly
• Tools Are Ready for the Next Cycle 50% Faster

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/8
• Drive Type: Square

• Max Free Speed (rpm): 750
• Max Torque (ft-lb): 8.9
• Max Torque (in-lb): 106
• Max Torque (nm): 12
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 8.35

• Product Weight (lb): 2
• Recommended Forward Torque Range (ft-lb): 1.8-8.9
• Recommended Forward Torque Range (in-lb): 21-106
• Recommended Forward Torque Range (nm): 2.4-12
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 0.8
• Side to Center Distance (mm): 20

• User Interface: Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: 2.4 GHz Wi-Fi
• Wireless Tool Tracking: 5 GHz Wi-Fi
• Wireless Tool Tracking: USB-C
• Wireless Tool Tracking: 802.15.4
• Wireless Tool Tracking: Bluetooth

IR QXWD2PT024ES06

3/8in 20V, Cordless ETS QX Limitless Precision Fastening, 212 in-lb, 330 RPM, Pistol

Description: QX Connected Series has been instrumental in helping more organizations take control of their fastening processes through its simple, flexible, and capable performance. With the QX Limitless platform we're adding connected, controlled, and compliant to the bottom line. Dual-band communication technology delivers a seamless, uninterrupted connection - and across a greater communication rage than other cordless fastening systems can offer. QX Limitless can accommodate more tools in a single system, too - up to 10 tools on INSIGHTqcx controllers. Plus, it keeps unwanted connections at bay, meeting more of today's stringent corporate cybersecurity regulations to ensure greater data protection. Add in speedy data transfer and multiple programming methods, and there's simply no limit to the impact the QX Limitless system can have on your fastening projects and applications.

Features And Benefits:

• CONNECTIVITY: The QX-Limitless platform enhances seamless, plant-wide connectivity across a broader range where access points share the same SSID and password. Incorporating dual band communication technology, the system helps to eliminate communication breakdowns in high-traffic work zones to ensure no loss in production.
• Dual Band Communication Seamlessly Switches Between 2.4 and 5 Ghz Bands
• Industry-Leading Communication Range for Plant-Wide Connectivity Up to 65 Meters
• Reduces Limitation of Communications Distance Between Tools and Controller
• COMPLETE CONTROL: The QX-Limitless limits your hardware footprint by connecting more tools on a single platform. This fast, reliable system delivers greater control over more tools, delivering quick, complete data transfer between devices and reducing installation costs. Plus, your tools are ready for the next cycle much sooner, ensuring increased production efficiency.
• Connects Up to 10 Tools with INSIGHTqcx Controllers
• Limits Hardware Footprint
• Up to 40% Reduction in Initial Hardware Investments
• Transfers End of Run Fastening Data Quickly
• Tools Are Ready for the Next Cycle 50% Faster

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol - ETS (ergonomic tightening system)
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/8
• Drive Type: Square

• Max Free Speed (rpm): 330
• Max Torque (ft-lb): 18
• Max Torque (in-lb): 212
• Max Torque (nm): 24
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 8.35

• Product Weight (lb): 2
• Recommended Forward Torque Range (ft-lb): -
• Recommended Forward Torque Range (in-lb): -
• Recommended Forward Torque Range (nm): 4.8 - 24
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 1
• Side to Center Distance (mm): 25

• User Interface: Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: 2.4 GHz Wi-Fi
• Wireless Tool Tracking: 5 GHz Wi-Fi
• Wireless Tool Tracking: USB-C
• Wireless Tool Tracking: 802.15.4
• Wireless Tool Tracking: Bluetooth

IR QXWD5AT080ES08

1/2in 40V, Cordless Angle ETS QX Limitless Precision Fastening, 708 in-lb, 375 RPM

Description: QX Connected Series has been instrumental in helping more organizations take control of their fastening processes through its simple, flexible, and capable performance. With the QX Limitless platform we're adding connected, controlled, and compliant to the bottom line. Dual-band communication technology delivers a seamless, uninterrupted connection - and across a greater communication rage than other cordless fastening systems can offer. QX Limitless can accommodate more tools in a single system, too - up to 10 tools on INSIGHTqcx controllers. Plus, it keeps unwanted connections at bay, meeting more of today's stringent corporate cybersecurity regulations to ensure greater data protection. Add in speedy data transfer and multiple programming methods, and there's simply no limit to the impact the QX Limitless system can have on your fastening projects and applications.

Features And Benefits:

• CONNECTIVITY: The QX-Limitless platform enhances seamless, plant-wide connectivity across a broader range where access points share the same SSID and password. Incorporating dual band communication technology, the system helps to eliminate communication breakdowns in high-traffic work zones to ensure no loss in production.
• Dual Band Communication Seamlessly Switches Between 2.4 and 5 Ghz Bands
• Industry-Leading Communication Range for Plant-Wide Connectivity Up to 65 Meters
• Reduces Limitation of Communications Distance Between Tools and Controller
• COMPLETE CONTROL: The QX-Limitless limits your hardware footprint by connecting more tools on a single platform. This fast, reliable system delivers greater control over more tools, delivering quick, complete data transfer between devices and reducing installation costs. Plus, your tools are ready for the next cycle much sooner, ensuring increased production efficiency.
• Connects Up to 10 Tools with INSIGHTqcx Controllers
• Limits Hardware Footprint
• Up to 40% Reduction in Initial Hardware Investments
• Transfers End of Run Fastening Data Quickly
• Tools Are Ready for the Next Cycle 50% Faster

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle-ETS (ergonomic tightening system)
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1/2
• Drive Type: Square

• Max Free Speed (rpm): 375
• Max Torque (ft-lb): 59
• Max Torque (in-lb): 708
• Max Torque (nm): 80
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 23.1

• Product Weight (lb): 5
• Recommended Forward Torque Range (ft-lb): 8.9-59
• Recommended Forward Torque Range (in-lb): 106-708
• Recommended Forward Torque Range (nm): 12.0-80
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 0.85
• Side to Center Distance (mm): 22

• User Interface: Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: 2.4 GHz Wi-Fi
• Wireless Tool Tracking: 5 GHz Wi-Fi
• Wireless Tool Tracking: USB-C
• Wireless Tool Tracking: 802.15.4
• Wireless Tool Tracking: Bluetooth

IR QXX2A52T0396PS12

3/4" 20V Cordless Angle Torque Wrench, 3496 in-lb, Bare Tool, Bluetooth/802.15.4

Description: The innovative QX Series Cordless Angle Torque Multiplier will reduce your bolting time and cost, while ensuring repeatable accuracy for all torque-critical joints. Designed with a premium Norbar gearbox and an efficient, time-tested closed-loop transducer, the Torque Multiplier is world-class in quality, control and programmable configurations to maximize your productivity. Offer option for Insight Connect Android APP Link

Features And Benefits:

• Closed-loop transducer delivers a torque accuracy of +/- 5%
• Enhanced quantitative feedback - displaying the actual measured torque or angle result
• Integrated gearbox provides premium quality and accuracy
• Brushless Motor offers maximum durability
• Intuitive qualitative feedback using Green, Red, and Yellow indicators
• 360 degree adjustable handle, with 6 mm threaded port for eye hooks or other tethering points, provides operator comfort, flexibility and safety options
• Standard or custom reaction arms available to match your application needs
• Optional wireless communication for process control with I/O and data collections (USB connection standard)
• 1,200 cycles of onboard tightening data storage
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Heavy Duty

• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame

• Max Free Speed (rpm): 21
• Max Torque (ft-lb): 291
• Max Torque (in-lb): 3496
• Max Torque (nm): 395
• Motor: Brushless Motor

• Power Source: Battery Powered

• Reaction Bar: Yes
• Recommended Forward Torque Range (ft-lb): 58-291
• Recommended Forward Torque Range (in-lb): 699-3496
• Recommended Forward Torque Range (nm): 79-395
• Retainer Type: Thru-hole
• Reversible: Reversible

• Tether Style: Tether Included
• User Interface: No Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4

• Accessories: BC1161
• Accessories: BL4011

• Parts: NSP-299-CIR72
• Parts: NSP-299-M5X45

• Parts: NSP-766-W2222
• Parts: NSP-A48
• Parts: VP2-364
• Parts: VP2-377A
• Parts: VP2-400-T
• Parts: VP2-405
• Parts: VP2-405-2
• Parts: VP2-49
• Parts: VP2-49-2
• Parts: VP2-667
• Parts: VP2-78
• Parts: VP2-981
• Parts: VP2-A48

IR QXX2A52T0594PS12

3/4" 20V Cordless Angle Torque Wrench, Bare Tool, 5257 in-lb, Bluetooth/802.15.4

Description: The innovative QX Series Cordless Angle Torque Multiplier will reduce your bolting time and cost, while ensuring repeatable accuracy for all torque-critical joints. Designed with a premium Norbar gearbox and an efficient, time-tested closed-loop transducer, the Torque Multiplier is world-class in quality, control and programmable configurations to maximize your productivity. Offer option for Insight Connect Android APP Link

Features And Benefits:

• Closed-loop transducer delivers a torque accuracy of +/- 5%
• Enhanced quantitative feedback - displaying the actual measured torque or angle result
• Integrated gearbox provides premium quality and accuracy
• Brushless Motor offers maximum durability
• Intuitive qualitative feedback using Green, Red, and Yellow indicators
• 360 degree adjustable handle, with 6 mm threaded port for eye hooks or other tethering points, provides operator comfort, flexibility and safety options
• Standard or custom reaction arms available to match your application needs
• Optional wireless communication for process control with I/O and data collections (USB connection standard)
• 1,200 cycles of onboard tightening data storage
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Heavy Duty

• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame

• Max Free Speed (rpm): 14
• Max Torque (ft-lb): 438
• Max Torque (in-lb): 5257
• Max Torque (nm): 594
• Motor: Brushless Motor

• Power Source: Battery Powered

• Reaction Bar: Yes
• Recommended Forward Torque Range (ft-lb): 88-438
• Recommended Forward Torque Range (in-lb): 1053-5257
• Recommended Forward Torque Range (nm): 119-594
• Retainer Type: Thru-hole
• Reversible: Reversible

• Tether Style: Tether Included
• User Interface: No Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4

• Accessories: BC1161
• Accessories: BL4011

• Parts: NSP-299-CIR72
• Parts: NSP-299-M5X45

• Parts: NSP-766-W2222
• Parts: NSP-A48
• Parts: VP2-364
• Parts: VP2-377A
• Parts: VP2-400-T
• Parts: VP2-405
• Parts: VP2-405-2
• Parts: VP2-49
• Parts: VP2-49-2
• Parts: VP2-667
• Parts: VP2-78
• Parts: VP2-981
• Parts: VP2-A48

IR QXX2A52T0880PS12

IR QXX2AT18PS6

IR QXX2AT27ES6

IR QXX2AT27PS6

IR QXX2PT04PS4

IR QXX2PT12PQ4

IR QXX2PT18EQ4

IR QXX2PT18ES6

IR QXX2PT200NPS12

QX Cordless Pistol Torque Multiplier, 30-148 ft-lbs. Torque, 8 RPM, Wireless Enabled Communication

The innovative QX Series Cordless Torque Multiplier will reduce your bolting time and cost, while ensuring repeatable accuracy for all torque-critical joints. Designed with a premium Norbar gearbox and an efficient, time-tested closed-loop transducer, the Torque Multiplier offers proven quality, control and programmable configurations to maximize your productivity.

Features and Benefits:

• Closed-loop transducer delivers a torque accuracy of +/- 5%
• Integrated gearbox provides premium quality and accuracy
• Brushless Motor offers maximum durability
• Multi-function display module with cycle status alert and audible alarm offers instant feedback and easy setup
• 360 degrees adjustable handle, with 6 mm threaded port for eye hooks or other tethering points, provides operator comfort, flexibility and safety options
• Standard or custom reaction arms available
• Ingersoll Rand's ICS software provides operators the ability to access and program basic fastening strategies, as well as more advanced options to adapt to the most complicated bolting applications

IR QXX5A45T0180PS12

3/4" 40V Cordless Angle Torque Wrench, 1593 in-lb, Bare Tool, Bluetooth/802.15.4

Description: Meet the tool that's taking torque to the next level - the QX Series 40V Cordless Torque Multiplier, packed with all the power and precision to perform like no wrench has before. A highly evolved 40V addition to the QX Series, QX Series 40V Cordless Torque Multiplier is more rugged, powerful, and twice as fast as its 20V QX Series counterpart while still offering premium accuracy, comfort, and control. An on-board persistent clock automatically timestamps, an advanced cooling fan extends runtime, and an ergonomic handle maximizes support. But next-gen torque demands next-gen tech, which is why the 40V seamlessly integrates with the INSIGHT Connect app and INSIGHTqcx Controller to easily log tightening data, program tool functions, and so much more. Unmatched speed, unbound accessibility, unmistakable data - only with the uncompromising QX Series 40V Cordless Torque Multiplier.

Features And Benefits:

• Closed-loop transducer delivers a torque accuracy of +/- 5%
• Enhanced quantitative feedback - displaying the actual measured torque or angle result
• Integrated gearbox provides premium quality and accuracy
• Brushless Motor offers maximum durability
• Intuitive qualitative feedback using Green, Red, and Yellow indicators
• 360 degree adjustable handle, with 6 mm threaded port for eye hooks or other tethering points, provides operator comfort, flexibility and safety options
• Standard or custom reaction arms available to match your application needs
• Optional wireless communication for process control with I/O and data collections (USB connection standard)
• 1,200 cycles of onboard tightening data storage
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key
• Offer option for Insight Connect Android APP

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Heavy Duty

• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame

• Max Free Speed (rpm): 110
• Max Torque (ft-lb): 133
• Max Torque (in-lb): 1593
• Max Torque (nm): 180
• Motor: Brushless Motor

• Power Source: Battery Powered

• Reaction Bar: Yes
• Recommended Forward Torque Range (ft-lb): 12-133
• Recommended Forward Torque Range (in-lb): 142-1593
• Recommended Forward Torque Range (nm): 16-180
• Retainer Type: Thru-hole
• Reversible: Reversible

• Tether Style: Tether Included
• User Interface: No Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4

• Accessories: BC1161
• Accessories: BL4011

• Parts: NSP-299-CIR72
• Parts: NSP-299-M5X45

• Parts: NSP-766-W2222
• Parts: NSP-A48
• Parts: VP2-364
• Parts: VP2-377A
• Parts: VP2-400-T
• Parts: VP2-405
• Parts: VP2-405-2
• Parts: VP2-49
• Parts:

IR QXX2PT500NPS12

QX Cordless Pistol Torque Multiplier, 74-369 ft-lbs. Torque, 8 RPM, Wireless Enabled Communication

The innovative QX Series Cordless Torque Multiplier will reduce your bolting time and cost, while ensuring repeatable accuracy for all torque-critical joints. Designed with a premium Norbar, gearbox and an efficient, time-tested closed-loop transducer, the Torque Multiplier offers proven quality, control and programmable configurations to maximize your productivity.

Features and Benefits:

• Closed-loop transducer delivers a torque accuracy of +/- 5%
• Integrated gearbox provides premium quality and accuracy
• Brushless Motor offers maximum durability
• Multi-function display module with cycle status alert and audible alarm offers instant feedback and easy setup
• 360 degree adjustable handle, with 6 mm threaded port for eye hooks or other tethering points, provides operator comfort, flexibility and safety options
• Standard or custom reaction arms available
• Ingersoll Rand's ICS software provides operators the ability to access and program basic fastening strategies, as well as more advanced options to adapt to the most complicated bolting applications

IR QXX5A45T0270PS12

3/4" 40V Cordless Angle Torque Wrench, 2390 in-lb, Bare Tool, Bluetooth/802.15.4

Description: Meet the tool that's taking torque to the next level - the QX Series 40V Cordless Torque Multiplier, packed with all the power and precision to perform like no wrench has before. A highly evolved 40V addition to the QX Series, QX Series 40V Cordless Torque Multiplier is more rugged, powerful, and twice as fast as its 20V QX Series counterpart while still offering premium accuracy, comfort, and control. An on-board persistent clock automatically timestamps, an advanced cooling fan extends runtime, and an ergonomic handle maximizes support. But next-gen torque demands next-gen tech, which is why the 40V seamlessly integrates with the INSIGHT Connect app and INSIGHTqcx Controller to easily log tightening data, program tool functions, and so much more. Unmatched speed, unbound accessibility, unmistakable data - only with the uncompromising QX Series 40V Cordless Torque Multiplier.

Features And Benefits:

• Closed-loop transducer delivers a torque accuracy of +/- 5%
• Enhanced quantitative feedback - displaying the actual measured torque or angle result
• Integrated gearbox provides premium quality and accuracy
• Brushless Motor offers maximum durability
• Intuitive qualitative feedback using Green, Red, and Yellow indicators
• 360 degree adjustable handle, with 6 mm threaded port for eye hooks or other tethering points, provides operator comfort, flexibility and safety options
• Standard or custom reaction arms available to match your application needs
• Optional wireless communication for process control with I/O and data collections (USB connection standard)
• 1,200 cycles of onboard tightening data storage
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key
• Offer option for Insight Connect Android APP

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Heavy Duty

• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame

• Max Free Speed (rpm): 77
• Max Torque (ft-lb): 200
• Max Torque (in-lb): 2390
• Max Torque (nm): 270
• Motor: Brushless Motor

• Power Source: Battery Powered

• Reaction Bar: Yes
• Recommended Forward Torque Range (ft-lb): 40-200
• Recommended Forward Torque Range (in-lb): 478-2390
• Recommended Forward Torque Range (nm): 54-270
• Retainer Type: Thru-hole
• Reversible: Reversible

• Tether Style: Tether Included
• User Interface: No Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4

• Accessories: BC1161
• Accessories: BL4011

• Parts: NSP-299-CIR72
• Parts: NSP-299-M5X45

• Parts: NSP-766-W2222
• Parts: NSP-A48
• Parts: VP2-364
• Parts: VP2-377A
• Parts: VP2-400-T
• Parts: VP2-405
• Parts: VP2-405-2
• Parts: VP2-49
• Parts:

IR QXX5AT80ES08

IR QXXD2AT015PS06

3/8in 20V Cordless QX Precision Fastening Angle Screwdriver, 133 in-lb Torque, 600 RPM, Display

Description: A member of the QX Connect Series Precision Fastening System, the 20V QXXD Cordless Precision Screwdriver offer the full feature set of the QX Connect Series. With up to 32 programmable configurations, wireless data transmission and on tool display, Bluetooth connectivity, this tool is designed to improve accuracy and productivity of your precision fastening and assembly operations. Reducing torque reaction doesn't have to be complicated with the QX Connect Series Ergonomic Tightening System. The Bluetooth capability further enhances mobility by enabling users to wirelessly program the QX Connect Series assembly tools using the INSIGHT Connect App.

Features And Benefits:

• Now Comes with 32 programmable tightening configuration.
• Bluetooth further adds mobility to enable Wireless programming using the INSIGHT Connect app.
• Enhanced quantitative feedback - displaying the actual measured torque or angle result.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• All QX Series IQV20 tools are compatible with both the BL2022 and BL2012 batteries. The BL2022 is optimum for longer use applications while the BL2012 is ideal for tighter spaces and reduced weight. The 20 volt batteries utilize our 20V battery charger.
• Offer option for Insight Connect Android APP LINK
• Optional ergonomic tightening system to reduce torque reaction experienced by operator.
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Insight Connect Android and IOS App, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/8
• Drive Type: Square

• Max Free Speed (rpm): 600
• Max Torque (ft-lb): 11
• Max Torque (in-lb): 133
• Max Torque (nm): 15
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 20.67

• Product Height (in) (with Battery): 3.94
• Product Weight (lb): 2.6
• Recommended Forward Torque Range (ft-lb): 2.2-11
• Recommended Forward Torque Range (in-lb): 27-133
• Recommended Forward Torque Range (nm): 3-15
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 0.49
• Side to Center Distance (mm): 12

• User Interface: Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4
• Wireless Tool Tracking: USB-C

IR QXX5A72T1080PS16

1" 40V Cordless Angle Torque Wrench, 9559 in-lb, Bare Tool, Bluetooth/802.15.4

Description: Meet the tool that's taking torque to the next level - the QX Series 40V Cordless Torque Multiplier, packed with all the power and precision to perform like no wrench has before. A highly evolved 40V addition to the QX Series, QX Series 40V Cordless Torque Multiplier is more rugged, powerful, and twice as fast as its 20V QX Series counterpart while still offering premium accuracy, comfort, and control. An on-board persistent clock automatically timestamps, an advanced cooling fan extends runtime, and an ergonomic handle maximizes support. But next-gen torque demands next-gen tech, which is why the 40V seamlessly integrates with the INSIGHT Connect app and INSIGHTqcx Controller to easily log tightening data, program tool functions, and so much more. Unmatched speed, unbound accessibility, unmistakable data - only with the uncompromising QX Series 40V Cordless Torque Multiplier.

Features And Benefits:

• Closed-loop transducer delivers a torque accuracy of +/- 5%
• Enhanced quantitative feedback - displaying the actual measured torque or angle result
• Integrated gearbox provides premium quality and accuracy
• Brushless Motor offers maximum durability
• Intuitive qualitative feedback using Green, Red, and Yellow indicators
• 360 degree adjustable handle, with 6 mm threaded port for eye hooks or other tethering points, provides operator comfort, flexibility and safety options
• Standard or custom reaction arms available to match your application needs
• Optional wireless communication for process control with I/O and data collections (USB connection standard)
• 1,200 cycles of onboard tightening data storage
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key
• Offer option for Insight Connect Android APP

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Heavy Duty

• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame

• Max Free Speed (rpm): 19
• Max Torque (ft-lb): 797
• Max Torque (in-lb): 9559
• Max Torque (nm): 1080
• Motor: Brushless Motor

• Power Source: Battery Powered

• Reaction Bar: Yes
• Recommended Forward Torque Range (ft-lb): 159-797
• Recommended Forward Torque Range (in-lb): 1912-9559
• Recommended Forward Torque Range (nm): 216-1080
• Retainer Type: Thru-hole
• Reversible: Reversible

• Tether Style: Tether Included
• User Interface: No Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4

• Accessories: BC1161
• Accessories: BL4011

• Parts: NSP-299-CIR72
• Parts: NSP-299-M5X45

• Parts: NSP-766-W2222
• Parts: NSP-A48
• Parts: VP2-364
• Parts: VP2-377A
• Parts: VP2-400-T
• Parts: VP2-405
• Parts: VP2-405-2
• Parts: VP2-49
• Parts:

IR QXX5A52T0880PS12

3/4" 40V Cordless Angle Torque Wrench, 7789 in-lb, Bare Tool, Bluetooth/802.15.4

Description: Meet the tool that's taking torque to the next level - the QX Series 40V Cordless Torque Multiplier, packed with all the power and precision to perform like no wrench has before. A highly evolved 40V addition to the QX Series, QX Series 40V Cordless Torque Multiplier is more rugged, powerful, and twice as fast as its 20V QX Series counterpart while still offering premium accuracy, comfort, and control. An on-board persistent clock automatically timestamps, an advanced cooling fan extends runtime, and an ergonomic handle maximizes support. But next-gen torque demands next-gen tech, which is why the 40V seamlessly integrates with the INSIGHT Connect app and INSIGHTqcx Controller to easily log tightening data, program tool functions, and so much more. Unmatched speed, unbound accessibility, unmistakable data - only with the uncompromising QX Series 40V Cordless Torque Multiplier.

Features And Benefits:

• Closed-loop transducer delivers a torque accuracy of +/- 5%
• Enhanced quantitative feedback - displaying the actual measured torque or angle result
• Integrated gearbox provides premium quality and accuracy
• Brushless Motor offers maximum durability
• Intuitive qualitative feedback using Green, Red, and Yellow indicators
• 360 degree adjustable handle, with 6 mm threaded port for eye hooks or other tethering points, provides operator comfort, flexibility and safety options
• Standard or custom reaction arms available to match your application needs
• Optional wireless communication for process control with I/O and data collections (USB connection standard)
• 1,200 cycles of onboard tightening data storage
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key
• Offer option for Insight Connect Android APP

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Heavy Duty

• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame

• Max Free Speed (rpm): 23
• Max Torque (ft-lb): 649
• Max Torque (in-lb): 7789
• Max Torque (nm): 880
• Motor: Brushless Motor

• Power Source: Battery Powered

• Reaction Bar: Yes
• Recommended Forward Torque Range (ft-lb): 133-649
• Recommended Forward Torque Range (in-lb): 1593-7789
• Recommended Forward Torque Range (nm): 180-880
• Retainer Type: Thru-hole
• Reversible: Reversible

• Tether Style: Tether Included
• User Interface: No Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4

• Accessories: BC1161
• Accessories: BL4011

• Parts: NSP-299-CIR72
• Parts: NSP-299-M5X45

• Parts: NSP-766-W2222
• Parts: NSP-A48
• Parts: VP2-364
• Parts: VP2-377A
• Parts: VP2-400-T
• Parts: VP2-405
• Parts: VP2-405-2
• Parts: VP2-49
• Part

IR QXXD2AT000E000

IR QXXD2PT004PQ04

1/4" Hex 20V Cordless QX Precision Fastening Screwdriver, 35 in-lb Torque, 1500 RPM, Display, Pistol

Description: A member of the QX Connect Series Precision Fastening System, the 20V QXXD Cordless Precision Screwdriver offer the full feature set of the QX Connect Series. With up to 32 programmable configurations, wireless data transmission and on tool display, Bluetooth connectivity, this tool is designed to improve accuracy and productivity of your precision fastening and assembly operations. Reducing torque reaction doesn't have to be complicated with the QX Connect Series Ergonomic Tightening System. The Bluetooth capability further enhances mobility by enabling users to wirelessly program the QX Connect Series assembly tools using the INSIGHT Connect App.

Features And Benefits:

• Now Comes with 32 programmable tightening configuration.
• Bluetooth further adds mobility to enable Wireless programming using the INSIGHT Connect app.
• Enhanced quantitative feedback - displaying the actual measured torque or angle result.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• All QX Series IQV20 tools are compatible with both the BL2022 and BL2012 batteries. The BL2022 is optimum for longer use applications while the BL2012 is ideal for tighter spaces and reduced weight. The 20 volt batteries utilize our 20V battery charger.
• Offer option for Insight Connect Android APP LINK
• Optional ergonomic tightening system to reduce torque reaction experienced by operator.
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Insight Connect Android and IOS App, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1/4
• Drive Type: Hex

• Max Free Speed (rpm): 1500
• Max Torque (ft-lb): 3.0
• Max Torque (in-lb): 35
• Max Torque (nm): 4
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 8.48

• Product Height (in) (with Battery): 10.07
• Product Weight (lb): 2
• Recommended Forward Torque Range (ft-lb): 0.6-3.0
• Recommended Forward Torque Range (in-lb): 7.1-35
• Recommended Forward Torque Range (nm): 0.8-4
• Retainer Type: Quick Change
• Reversible: Reversible

• Side to Center Distance (in): 1
• Side to Center Distance (mm): 25

• Sound Pressure/Power Db(A): < 70.0

• User Interface: Display
• Vibration Level (m/s2): < 2.5
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4
• Wireless Tool Tracking: USB-C

IR QXXD2AT010PS06

3/8in 20V Cordless QX Precision Fastening Angle Screwdriver, 89 in-lb Torque, 936 RPM, Display

Description: A member of the QX Connect Series Precision Fastening System, the 20V QXXD Cordless Precision Screwdriver offer the full feature set of the QX Connect Series. With up to 32 programmable configurations, wireless data transmission and on tool display, Bluetooth connectivity, this tool is designed to improve accuracy and productivity of your precision fastening and assembly operations. Reducing torque reaction doesn't have to be complicated with the QX Connect Series Ergonomic Tightening System. The Bluetooth capability further enhances mobility by enabling users to wirelessly program the QX Connect Series assembly tools using the INSIGHT Connect App.

Features And Benefits:

• Now Comes with 32 programmable tightening configuration.
• Bluetooth further adds mobility to enable Wireless programming using the INSIGHT Connect app.
• Enhanced quantitative feedback - displaying the actual measured torque or angle result.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• All QX Series IQV20 tools are compatible with both the BL2022 and BL2012 batteries. The BL2022 is optimum for longer use applications while the BL2012 is ideal for tighter spaces and reduced weight. The 20 volt batteries utilize our 20V battery charger.
• Offer option for Insight Connect Android APP LINK
• Optional ergonomic tightening system to reduce torque reaction experienced by operator.
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Insight Connect Android and IOS App, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/8
• Drive Type: Square

• Max Free Speed (rpm): 936
• Max Torque (ft-lb): 7.4
• Max Torque (in-lb): 89
• Max Torque (nm): 10
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 20.67

• Product Height (in) (with Battery): 3.94
• Product Weight (lb): 2.6
• Recommended Forward Torque Range (ft-lb): 1.5-7.4
• Recommended Forward Torque Range (in-lb): 18-89
• Recommended Forward Torque Range (nm): 2.0-10
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 0.49
• Side to Center Distance (mm): 12

• User Interface: Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4
• Wireless Tool Tracking: USB-C

IR QXX5A72T1620PS16

1" 40V Cordless Angle Torque Wrench, 14338 in-lb, Bare Tool, Bluetooth/802.15.4

Description: Meet the tool that's taking torque to the next level - the QX Series 40V Cordless Torque Multiplier, packed with all the power and precision to perform like no wrench has before. A highly evolved 40V addition to the QX Series, QX Series 40V Cordless Torque Multiplier is more rugged, powerful, and twice as fast as its 20V QX Series counterpart while still offering premium accuracy, comfort, and control. An on-board persistent clock automatically timestamps, an advanced cooling fan extends runtime, and an ergonomic handle maximizes support. But next-gen torque demands next-gen tech, which is why the 40V seamlessly integrates with the INSIGHT Connect app and INSIGHTqcx Controller to easily log tightening data, program tool functions, and so much more. Unmatched speed, unbound accessibility, unmistakable data - only with the uncompromising QX Series 40V Cordless Torque Multiplier.

Features And Benefits:

• Closed-loop transducer delivers a torque accuracy of +/- 5%
• Enhanced quantitative feedback - displaying the actual measured torque or angle result
• Integrated gearbox provides premium quality and accuracy
• Brushless Motor offers maximum durability
• Intuitive qualitative feedback using Green, Red, and Yellow indicators
• 360 degree adjustable handle, with 6 mm threaded port for eye hooks or other tethering points, provides operator comfort, flexibility and safety options
• Standard or custom reaction arms available to match your application needs
• Optional wireless communication for process control with I/O and data collections (USB connection standard)
• 1,200 cycles of onboard tightening data storage
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key
• Offer option for Insight Connect Android APP

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Heavy Duty

• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame

• Max Free Speed (rpm): 13
• Max Torque (ft-lb): 1195
• Max Torque (in-lb): 14338
• Max Torque (nm): 1620
• Motor: Brushless Motor

• Power Source: Battery Powered

• Reaction Bar: Yes
• Recommended Forward Torque Range (ft-lb): 239-1195
• Recommended Forward Torque Range (in-lb): 2868-14338
• Recommended Forward Torque Range (nm): 324-1620
• Retainer Type: Thru-hole
• Reversible: Reversible

• Tether Style: Tether Included
• User Interface: No Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4

• Accessories: BC1161
• Accessories: BL4011

• Parts: NSP-299-CIR72
• Parts: NSP-299-M5X45

• Parts: NSP-766-W2222
• Parts: NSP-A48
• Parts: VP2-364
• Parts: VP2-377A
• Parts: VP2-400-T
• Parts: VP2-405
• Parts: VP2-405-2
• Parts: VP2-49
• P

IR QXXD2PT000P000

IR QXXD2AT018PS06

3/8in 20V Cordless QX Precision Fastening Angle Screwdriver, 159 in-lb Torque, 500 RPM, Display

Description: A member of the QX Connect Series Precision Fastening System, the 20V QXXD Cordless Precision Screwdriver offer the full feature set of the QX Connect Series. With up to 32 programmable configurations, wireless data transmission and on tool display, Bluetooth connectivity, this tool is designed to improve accuracy and productivity of your precision fastening and assembly operations. Reducing torque reaction doesn't have to be complicated with the QX Connect Series Ergonomic Tightening System. The Bluetooth capability further enhances mobility by enabling users to wirelessly program the QX Connect Series assembly tools using the INSIGHT Connect App.

Features And Benefits:

• Now Comes with 32 programmable tightening configuration.
• Bluetooth further adds mobility to enable Wireless programming using the INSIGHT Connect app.
• Enhanced quantitative feedback - displaying the actual measured torque or angle result.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• All QX Series IQV20 tools are compatible with both the BL2022 and BL2012 batteries. The BL2022 is optimum for longer use applications while the BL2012 is ideal for tighter spaces and reduced weight. The 20 volt batteries utilize our 20V battery charger.
• Offer option for Insight Connect Android APP LINK
• Optional ergonomic tightening system to reduce torque reaction experienced by operator.
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Insight Connect Android and IOS App, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/8
• Drive Type: Square

• Max Free Speed (rpm): 500
• Max Torque (ft-lb): 13
• Max Torque (in-lb): 159
• Max Torque (nm): 18
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 24.34

• Product Height (in) (with Battery): 3.94
• Product Weight (lb): 2.8
• Recommended Forward Torque Range (ft-lb): 2.7-13
• Recommended Forward Torque Range (in-lb): 32-159
• Recommended Forward Torque Range (nm): 3.6-18
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 0.51
• Side to Center Distance (mm): 13

• User Interface: Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4
• Wireless Tool Tracking: USB-C

IR QXXD2AT000P000

IR QXXD2AT027ES06

3/8in 20V Cordless QX Precision Fastening ETS Angle Wrench, 239 in-lb Torque, 330 RPM, Display

Description: A member of the QX Connect Series Precision Fastening System, the 20V QXXD Cordless Precision Screwdriver offer the full feature set of the QX Connect Series. With up to 32 programmable configurations, wireless data transmission and on tool display, Bluetooth connectivity, this tool is designed to improve accuracy and productivity of your precision fastening and assembly operations. The Bluetooth capability further enhances mobility by enabling users to wirelessly program the QX Connect Series assembly tools using the INSIGHT Connect App. Reducing torque reaction doesn't have to be complicated with the QX Connect Series Ergonomic Tightening System. Control and ergonomics, not compromise - that is what the QX ETS is all about. The QX ETS offers all the capabilities found in the QX Series platform, without the torque reaction.

Features And Benefits:

• Now Comes with 32 programmable tightening configuration.
• Bluetooth further adds mobility to enable Wireless programming using the INSIGHT Connect app.
• Enhanced quantitative feedback - displaying the actual measured torque or angle result.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• All QX Series IQV20 tools are compatible with both the BL2022 and BL2012 batteries. The BL2022 is optimum for longer use applications while the BL2012 is ideal for tighter spaces and reduced weight. The 20 volt batteries utilize our 20V battery charger.
• Offer option for Insight Connect Android APP LINK
• Optional ergonomic tightening system to reduce torque reaction experienced by operator.
• Standard QX Direct Drive Mode: when disabling the ETS* Mode, these tools can be used as a QX standard drive mode.
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Insight Connect Android and IOS App, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key
• Ergonomically enhanced motor control algorithm significantly reduces the average force experienced by the operator during the tightening process
• Red tool highlights provide a clear indication of ETS* tool identity vs standard QX tool
• Continuously blue light above the keypad provides operator assurance that ETS* is ACTIVE
• In addition to the standard direct drive mode, each tool configuration can be independently programmed to utilize one of the three available ETS* modes (Ergonomic Mode, Performance Mode, Productivity Mode), simplifying setup.
• Ergonomic Mode: with the lowest energy pulses, is ideal for hard joints or when arm, wrist, or tool angles are most difficult.
• Performance Mode: with medium energy pulses, is the best all-purpose mode.
• Productivity Mode: with the highest energy pulses, is the fastest mode. Ideal for soft joints or when high production rates are required.

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle-ETS (ergonomic tightening system)
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/8
• Drive Type: Square

• Max Free Speed (rpm): 330
• Max Torque (ft-lb): 20
• Max Torque (in-lb): 239
• Max Torque (nm): 27
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 21.73

• Prod

IR QXXD2PT000E000

IR QXXD2PT004PS04

1/4" 20V Cordless QX Precision Fastening Screwdriver, 35 in-lb Torque, 1500 RPM, Display, Pistol

Description: A member of the QX Connect Series Precision Fastening System, the 20V QXXD Cordless Precision Screwdriver offer the full feature set of the QX Connect Series. With up to 32 programmable configurations, wireless data transmission and on tool display, Bluetooth connectivity, this tool is designed to improve accuracy and productivity of your precision fastening and assembly operations. Reducing torque reaction doesn't have to be complicated with the QX Connect Series Ergonomic Tightening System. The Bluetooth capability further enhances mobility by enabling users to wirelessly program the QX Connect Series assembly tools using the INSIGHT Connect App.

Features And Benefits:

• Now Comes with 32 programmable tightening configuration.
• Bluetooth further adds mobility to enable Wireless programming using the INSIGHT Connect app.
• Enhanced quantitative feedback - displaying the actual measured torque or angle result.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• All QX Series IQV20 tools are compatible with both the BL2022 and BL2012 batteries. The BL2022 is optimum for longer use applications while the BL2012 is ideal for tighter spaces and reduced weight. The 20 volt batteries utilize our 20V battery charger.
• Offer option for Insight Connect Android APP LINK
• Optional ergonomic tightening system to reduce torque reaction experienced by operator.
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Insight Connect Android and IOS App, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1/4
• Drive Type: Square

• Max Free Speed (rpm): 1500
• Max Torque (ft-lb): 3.0
• Max Torque (in-lb): 35
• Max Torque (nm): 4
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 8.2

• Product Height (in) (with Battery): 10.07
• Product Weight (lb): 2
• Recommended Forward Torque Range (ft-lb): 0.6-3.0
• Recommended Forward Torque Range (in-lb): 7.1-35
• Recommended Forward Torque Range (nm): 0.8-4
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 1
• Side to Center Distance (mm): 25

• Sound Pressure/Power Db(A): < 70.0

• User Interface: Display
• Vibration Level (m/s2): < 2.5
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4
• Wireless Tool Tracking: USB-C

IR QXXD2AT018PQ04

1/4" Hex 20V Cordless QX Precision Fastening Angle Screwdriver, 159 in-lb Torque, 500 RPM, Display

Description: A member of the QX Connect Series Precision Fastening System, the 20V QXXD Cordless Precision Screwdriver offer the full feature set of the QX Connect Series. With up to 32 programmable configurations, wireless data transmission and on tool display, Bluetooth connectivity, this tool is designed to improve accuracy and productivity of your precision fastening and assembly operations. Reducing torque reaction doesn't have to be complicated with the QX Connect Series Ergonomic Tightening System. The Bluetooth capability further enhances mobility by enabling users to wirelessly program the QX Connect Series assembly tools using the INSIGHT Connect App.

Features And Benefits:

• Now Comes with 32 programmable tightening configuration.
• Bluetooth further adds mobility to enable Wireless programming using the INSIGHT Connect app.
• Enhanced quantitative feedback - displaying the actual measured torque or angle result.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• All QX Series IQV20 tools are compatible with both the BL2022 and BL2012 batteries. The BL2022 is optimum for longer use applications while the BL2012 is ideal for tighter spaces and reduced weight. The 20 volt batteries utilize our 20V battery charger.
• Offer option for Insight Connect Android APP LINK
• Optional ergonomic tightening system to reduce torque reaction experienced by operator.
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Insight Connect Android and IOS App, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1/4
• Drive Type: Hex

• Max Free Speed (rpm): 500
• Max Torque (ft-lb): 13
• Max Torque (in-lb): 159
• Max Torque (nm): 18
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 24.34

• Product Height (in) (with Battery): 3.94
• Product Weight (lb): 2.8
• Recommended Forward Torque Range (ft-lb): 2.7-13
• Recommended Forward Torque Range (in-lb): 32-159
• Recommended Forward Torque Range (nm): 3.6-18
• Retainer Type: Quick Change
• Reversible: Reversible

• Side to Center Distance (in): 0.51
• Side to Center Distance (mm): 13

• User Interface: Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4
• Wireless Tool Tracking: USB-C

IR QXXD2PT008EQ04

1/4" Hex 20V Cordless QX Precision Fastening ETS Screwdriver, 70 in-lb Torque, 1150 RPM, Display, Pistol

Description: A member of the QX Connect Series Precision Fastening System, the 20V QXXD Cordless Precision Screwdriver offer the full feature set of the QX Connect Series. With up to 32 programmable configurations, wireless data transmission and on tool display, Bluetooth connectivity, this tool is designed to improve accuracy and productivity of your precision fastening and assembly operations. The Bluetooth capability further enhances mobility by enabling users to wirelessly program the QX Connect Series assembly tools using the INSIGHT Connect App. Reducing torque reaction doesn't have to be complicated with the QX Connect Series Ergonomic Tightening System. Control and ergonomics, not compromise - that is what the QX ETS is all about. The QX ETS offers all the capabilities found in the QX Series platform, without the torque reaction.

Features And Benefits:

• Now Comes with 32 programmable tightening configuration.
• Bluetooth further adds mobility to enable Wireless programming using the INSIGHT Connect app.
• Enhanced quantitative feedback - displaying the actual measured torque or angle result.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• All QX Series IQV20 tools are compatible with both the BL2022 and BL2012 batteries. The BL2022 is optimum for longer use applications while the BL2012 is ideal for tighter spaces and reduced weight. The 20 volt batteries utilize our 20V battery charger.
• Offer option for Insight Connect Android APP LINK
• Optional ergonomic tightening system to reduce torque reaction experienced by operator.
• Standard QX Direct Drive Mode: when disabling the ETS* Mode, these tools can be used as a QX standard drive mode.
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Insight Connect Android and IOS App, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key
• Ergonomically enhanced motor control algorithm significantly reduces the average force experienced by the operator during the tightening process
• Red tool highlights provide a clear indication of ETS* tool identity vs standard QX tool
• Continuously blue light above the keypad provides operator assurance that ETS* is ACTIVE
• In addition to the standard direct drive mode, each tool configuration can be independently programmed to utilize one of the three available ETS* modes (Ergonomic Mode, Performance Mode, Productivity Mode), simplifying setup.
• Ergonomic Mode: with the lowest energy pulses, is ideal for hard joints or when arm, wrist, or tool angles are most difficult.
• Performance Mode: with medium energy pulses, is the best all-purpose mode.
• Productivity Mode: with the highest energy pulses, is the fastest mode. Ideal for soft joints or when high production rates are required.

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol - ETS (ergonomic tightening system)
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1/4
• Drive Type: Hex

• Max Free Speed (rpm): 1150
• Max Torque (ft-lb): 5.9
• Max Torque (in-lb): 71
• Max Torque (nm): 8
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 8.13
