INGERSOLL-RAND IR TOOL S12880
Die Grinder
IR 3107G
Air Die Grinder, 27,000 RPM, 0.33 HP, 1/4" Collet, Rear Exhaust
Description: Ingersoll Rand's EDGE Series 3017G 1/4" Air Straight Die Grinder is the right tool for the job. It offers a ball-bearing construction that is sturdy yet lightweight. Features include a 1/3-horsepower motor, a 1/4-inch collet, a rear exhaust, and a self-locking throttle. An ergonomic grip makes this pneumatic grinder comfortable to hold and use and provides exceptional torque accuracy. Offering longer life and higher free speed at 27,000 rpm, this general purpose air grinder is designed for finishing, cutting, polishing, porting, light weld grinding, and breaking sharp edges.
Features And Benefits:
- Powered by compressed air and comes with a 1/3 HP motor, a 1/4" collet, rear exhaust and a self-locking throttle. With 27,000 rpm, it will power through difficult jobs.
- Contoured grip gives greater comfort and control. Its ergonomic design delivers exceptional torque precision, as well as increased productivity and safety.
- The 3107G is light and sturdy at only 1 lb. It has a ball bearing construction and is exceptionally rugged, compact and lightweight.
- Use this air grinder as a handheld power rotary tool for grinding, cutting, polishing and more.
- Each componet, mechanism and function has undergone rigerous testing to ensure its long-lasting performace.
Product Application and Uses:
Finishing, cutting, polishing, porting, light weld grinding, and breaking sharp edges.
- Includes: tool, Large Wrench, Small Wrench
- Actuation/Throttle Type/Switch Location: Handle
- Actuation/Throttle Type/Switch Type: Safety Lever
- Air Consumption @ Free Speed (cfm): 3
- Air Consumption @ Free Speed (l/min): 85
- Air Consumption @ Load (cfm): 18
- Air Consumption @ Load (l/min): 500
- Air Inlet: 1/4" NPT
- Air Pressure (psi): 90
- Arbor/Collet: 1/4"
- Average Air Consumption (cfm): 3
- Average Air Consumption (l/min): 85
- Bearing Type: Ball Bearing
- Configuration/Handle Type: Straight
- Duty Rating: Heavy Duty
- Exhaust Location: Rear
- Grinder Type: Die Grinder
- Guard Material: Steel
- Handle Material: Composite
- Height Over Spindle (in): 2.36
- Housing Material: Composite
- Lock Mechanism: Lever lock in off position
- Max Free Speed (rpm): 27000
- Max Pressure (bar): 6.2
- Min Hose Size (in): 3/8
- Power Source: Air Powered
- Product Length (in): 6.6
- Product Width (in): 2.87
- Product Height (in): 1.46
- Product Weight (lb): 1
- Rated Power (hp): 0.33
- Right Angle Length (in): 4.92
- Right Angle Length (mm): 125
- Side to Center Distance (in): 0.67
- Side to Center Distance (mm): 17
- Sound Pressure/Power Db(A): 92.4 / 103.4
- Vibration Level (m/s2): 2.6
- Warranty: 1-year
- Accessories: 9800
- Lubrication: 10P
- Parts: 02A-VAR-KIT
- Parts: 03A-VAR-KIT
Throttle Valve Plunger
IR 3940-302
Throttle Valve Plunger Service Part for Ingersoll Rand Power Tools
Throttle Valve Stem
IR 402-302
Throttle Valve Stem for Ingersoll Rand 231C, 2707P1, 2705P1 Impact Wrench
- For Use With: 231C
- For Use With: 2705P1
- For Use With: 2707P1
Seat
IR 402-303
Throttle Valve Seat for Ingersoll Rand 231C, 2707P1, 2705P1
- For Use With: 231C
- For Use With: 2705P1
- For Use With: 2707P1
Screwdriver, Push to Start, Lever Permit
IR 41SA10LPQ4
Screwdriver, Push to Start, Lever Permit
Tamper 441A2
IR 441A2
Pneumatic Backfill Tamper, 5.75" Round Malleable Butt, 4" Stroke, 2" Bore
Description: With dual-action sand wipers, a built-in muffler and a side exhaust, this tool is built for heavy use. These tools are commonly used by municipal and utility crews for compacting around both utility line repairs and new installations such as street lights, fire hydrants, and telephone poles prior to pouring concrete. In addition, this proven tool is ideal for backfilling around foundations or other tight areas.
Features And Benefits:
- Durability: With a plated piston and front-end seal to protect your tool, this Backfill Tamper can be used in the toughest environments. The sand-wiper seal prevents dirt and grit from getting inside the tool.
- Reliability: Thanks to a built-in lubricator, these tools are built to run smoothly and last, while extending overall operating life. Comes with a 1-year warranty.
- Power: Thanks to its high-power output, you'll be able to breeze through any job.
Product Application and Uses:
These tools are commonly used by municipal and utility crews for compacting around both utility line repairs and new installations such as street lights, fire hydrants, and telephone poles prior to pouring concrete. In addition, this proven tool is ideal for backfilling around foundations or other tight areas.
- Actuation/Throttle Type/Switch Type: Lever
- Air Consumption @ Load (cfm): 36
- Air Consumption @ Load (l/min): 1020
- Air Inlet: 3/8" NPT
- Air Pressure (psi): 90
- Blows per Min: 1750
- Bore Diameter (in): 2
- Butt Diameter (in): 5.75
- Butt Material: Malleable/ Steel
- Butt Shape: Round
- Color: Beige
- Configuration/Handle Type: Straight
- Duty Rating: Super Duty
- Exhaust Location: Side
- Housing Material: Steel
- Inline Oilers: Yes
- Max Pressure (bar): 6.2
- Min Hose Size (in): 1/2
- Muffler: Built In
- Power Source: Air Powered
- Product Length (in): 50.88
- Product Weight (lb): 21.4
- Retainer Type: Latch
- Shank Opening: 1" Tapered Rod
- Special Features: Time Tested Valve Design, Round Piston Rod, Built In Muffler, Optional Front End Butts Available.
- Steels: Yes
- Stroke Length (in): 4
- Warranty: 1-year
- Accessories: 34SR-M183-5 3/4
- Accessories: 44SR-M183-5 3/4
- Lubrication: 10G
- Lubrication: 10P
3In Chisel - 14In, 1-1/4In x 6In, Qty 1
IR 50193879
3" Pavement Breaker/Digger Chisel Steel, 14" L Hex 1-1/4" x 6" Shank
Description: Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world's first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Choose from a complete line of tool steels for your pavement breaker, with products for many applications including concrete, asphalt, excavation, and general demolition.
Product Application and Uses:
Designed for concrete demolition and asphalt cutting. For use with Ingersoll Rand MX60B, MX90B pavement breakers.
- Includes: (10) Chisel Steels
- Chisel Style: 3" Wide
- Collar Type: Round
- Collar Width (in): 1.563
- Housing Material: Steel
- Length Under Collar (in): 14
- Product Length (in): 20
- Product Width (in): 3
- Product Weight (lb): 7.5
- Shank Length (in): 6
- Shank SIze (in): 1-1/4 x 6
- Shank Type: Hex
- For Use With: MX60B
- For Use With: MX90B
Bearing (105589)
IR 508-97
Rear Motor Bearing Service Part for Ingersoll Rand Power Tools
Jib, Medium Duty With 16 Foot Boom A2 Rail
IR 7050JA2F16144
Jib, Medium Duty With 16 Foot Boom A2 Rail
Ctr Blade
IR 7802S-6021
Shear Blades for Ingersoll Rand 7802SA Air Shears
Product Application and Uses:
For use with Ingersoll Rand 7802SA Air Shears
- For Use With: 7802SA
Power Motor
IR 8231-9B
Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 475 RPM, 0.5 HP, 26.2 NM, Reversible
- Air Consumption at Max HP (scfm): 41
- Air Inlet: 1/4" NPT
- Air Pressure (psi): 90
- Drive Size (in): 3/8
- Drive Type: Round Keyed
- Exhaust Location: Exterior Muffler
- Finish: Black Oxide
- Gear Ratio: 38.1:1
- Gear Reduction: Double
- Gear Train: Planetary
- Housing Material: Steel
- Max Free Speed (rpm): 475
- Max Pressure (bar): 6.2
- Max Torque (ft-lb): 19
- Max Torque (in-lb): 232
- Max Torque (nm): 26.2
- Motor: Rotary Vane
- Motor: In line
- Mounting Type: Foot Mount Optional
- Power Source: Air Powered
- Product Weight (lb): 2.98
- Rated Power (hp): 0.5
- Rated Power (kW): 0.37
- Reversible: Reversible
- Sound Level dB(A): 80
- Speed at Max Power (rpm): 240
- Torque Output @ Max HP (ft-lb): 11
- Torque Output @ Max HP (nm): 14.9
- Warranty: 1-year
- Parts: 37896
Transformer 3Ph, 230V/110V, 60Hz Ul
IR 9056.4523.4
Transformer 3Ph, 230V/110V, 60Hz Ul
5 Piece Chisel Set
IR 9500
7" Hammer Chisel Set, .401" Shank, 5-Piece
Description: Tested to withstand the harshest environments, Ingersoll Rand is proud to offer pneumatic hammer chisels kits. All chisels are built from high-quality steel for the utmost in quality, strength, and durability. This 5-piece set includes the following chisels: tapered punch, flat chisel, panel cutter, sheet metal cutter, spot weld breaker. Pair with your Ingersoll Rand 114GQC Edge Series Air Hammer.
Features And Benefits:
- Quality: Built from high quality steel.
- 5-Piece Set: Includes tapered punch, flat chisel, panel cutter, sheet metal cutter and spot weld breaker.
- For Use With: Ingersoll Rand 114GQC Edge Series Air Hammer.
Product Application and Uses:
For use with Ingersoll Rand 114GQC Edge Series Air Hammer
- Includes: 5-piece set (tapered punch, flat chisel, panel cutter, sheet metal cutter and spot weld breaker.)
- For Use With: 114GQC
- For Use With: 116
- For Use With: 116-EU
- For Use With: 116H-EU
- For Use With: 116K
- For Use With: 117
- For Use With: 117-EU
- For Use With: 117K
- For Use With: 119MAX
- For Use With: 119MAXH
- For Use With: 119MAXHK
- For Use With: 119MAXK
- For Use With: 121-K6
- For Use With: 123MAX
- For Use With: 135MAX
- For Use With: 135MAXH
- For Use With: 135MAXK
- For Use With: LA426-EU
- For Use With: LA427-EU
