INGERSOLL-RAND IR TOOL S12880
INGERSOLL-RAND IR TOOL S12880 branded products
INDICATOR LIGHT MTG BRACKET FOR 1.5 TUBE
IR 48235012
IR 48235012
INDICATOR LIGHT MTG BRACKET FOR 1.5 TUBE $330.00
GM ADJUSTABLE END TRUCK ZRA1 ON ZRA2
IR 48391908
IR 48391908
GM ADJUSTABLE END TRUCK ZRA1 ON ZRA2 $1,350.00
HOIST, AIR, 1/2 TON, CLK SERIES, STEEL HOOKS, 20' LIFT, 16’ DROP, FABRIC CHAIN CONTAINER,
IR 48397947
IR 48397947
HOIST, AIR, 1/2 TON, CLK SERIES, STEEL HOOKS, 20' LIFT, 16’ DROP, FABRIC CHAIN CONTAINER, $4,536.00
FITTING - 1/4 NPT MALE TO 1/4 NPT FEMALE
IR 48401954
IR 48401954
FITTING - 1/4 NPT MALE TO 1/4 NPT FEMALE $25.00
FITTING - 1/4 NPT MALE TO 1/4 NPT MALE
IR 48401913
IR 48401913
FITTING - 1/4 NPT MALE TO 1/4 NPT MALE $21.00
ERGO BOX H/D VACUUM (2) CUP STRAIGHT TRANSFER
IR 48402077
IR 48402077
ERGO BOX H/D VACUUM (2) CUP STRAIGHT TRANSFER $25,950.00
MOTOR
IR 4840N
IR 4840N
Inline Multi-Vane Air Motor, 1" Keyed Shaft, 675 RPM, 3.2 HP, 122 NM, Reversible
Features And Benefits- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you’ll be able to spend more time focused on the job.
Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 675
Max Pressure (bar): 6.2
Max Torque (ft-lb): 90
Max Torque (in-lb): 1080
Max Torque (nm): 122
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Power Source: Air Powered
Product Length (in): 11.38
Product Width (in): 4
Product Height (in): 4
Product Weight (lb): 15.25
Rated Power (hp): 3.2
Rated Power (kW): 2.39
Reversible: Reversible
Speed at Max Power (rpm): 336
Standards/Certifications: ATEX
Starting Torque (ft-lb): 68
Starting Torque (nm): 91.7
Warranty: 1-year
$5,481.00
MOTOR
IR 4840D
IR 4840D
Inline Multi-Vane Air Motor, 1" Keyed Shaft, 9100 RPM, 3.3 HP, 9.4 NM, Reversible
Features And Benefits- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you’ll be able to spend more time focused on the job.
Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 9100
Max Pressure (bar): 6.2
Max Torque (ft-lb): 6.9
Max Torque (in-lb): 83
Max Torque (nm): 9.4
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Power Source: Air Powered
Product Length (in): 11.38
Product Width (in): 4
Product Height (in): 4
Product Weight (lb): 15.25
Rated Power (hp): 3.3
Rated Power (kW): 2.46
Reversible: Reversible
Speed at Max Power (rpm): 4550
Standards/Certifications: ATEX
Starting Torque (ft-lb): 5.2
Starting Torque (nm): 7
Warranty: 1-year
$5,675.00
MOTOR
IR 4840M/VSM-5165
IR 4840M/VSM-5165
Reversible In Line Air Motor, Round Keyed Shaft, 3.2 HP, 63 ft-lbs Stall Torque, 790 RPM
The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.Features And Benefits
- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you’ll be able to spend more time focused on the job.
Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption (cfm): 117
Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Length (in): 2.25
Drive Size (in): 1
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Ratio: 9.33:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Keyaway Length (in): 1.625
Max Free Speed (rpm): 790
Max Pressure (bar): 6.2
Max Torque (ft-lb): 63
Max Torque (in-lb): 752
Max Torque (nm): 85
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Operating Temperature Range: 0F to 150F
Power Source: Air Powered
Product Length (in): 9
Product Width (in): 4
Product Height (in): 4
Product Weight (lb): 15.25
Rated Power (hp): 3.2
Rated Power (kW): 2.39
Reversible: Reversible
Speed at Max Power (rpm): 485
Standards/Certifications: ATEX
Starting Torque (ft-lb): 47
Starting Torque (nm): 64
Warranty: 1-year
$6,500.00
MOTOR
IR 4840Q2
IR 4840Q2
Inline Multi-Vane Air Motor, 1" Square Shaft, 350 RPM, 3 HP, 224 NM, Reversible
Features And Benefits- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you’ll be able to spend more time focused on the job.
Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1
Drive Type: Square
Exhaust Location: Rear
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 350
Max Pressure (bar): 6.2
Max Torque (ft-lb): 165
Max Torque (in-lb): 1983
Max Torque (nm): 224
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Power Source: Air Powered
Product Length (in): 11.38
Product Width (in): 4
Product Height (in): 4
Product Weight (lb): 20.13
Rated Power (hp): 3
Rated Power (kW): 2.24
Reversible: Reversible
Speed at Max Power (rpm): 167
Standards/Certifications: ATEX
Starting Torque (ft-lb): 123
Starting Torque (nm): 167
Torque Output @ Max HP (ft-lb): 82
Torque Output @ Max HP (nm): 111.85
Warranty: 1-year
$6,850.00
MOTOR
IR 4840P2
IR 4840P2
Inline Multi-Vane Air Motor, 1" Square Shaft, 475 RPM, 3 HP, 170 NM, Reversible
The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.Features And Benefits
- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you’ll be able to spend more time focused on the job.
Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Length (in): 2.25
Drive Size (in): 1
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Ratio: 35.6:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Keyaway Length (in): 1.625
Max Free Speed (rpm): 475
Max Pressure (bar): 6.2
Max Torque (ft-lb): 125
Max Torque (in-lb): 1505
Max Torque (nm): 170
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Operating Temperature Range: 0F to 150F
Power Source: Air Powered
Product Length (in): 11.38
Product Width (in): 4
Product Height (in): 4
Product Weight (lb): 20.13
Rated Power (hp): 3
Rated Power (kW): 2.24
Reversible: Reversible
Speed at Max Power (rpm): 228
Standards/Certifications: ATEX
Starting Torque (ft-lb): 93
Starting Torque (nm): 126
Warranty: 1-year
$6,375.00
ADJUSTABLE END TRUCK ZRA2 ON ZRS2 GM SPEC
IR 48411786
IR 48411786
ADJUSTABLE END TRUCK ZRA2 ON ZRS2 GM SPEC $1,350.00
ADJUSTABLE END TRUCK ON ZRA1 ON ZRS2 GM SPEC
IR 48422778
IR 48422778
ADJUSTABLE END TRUCK ON ZRA1 ON ZRS2 GM SPEC $1,580.00
