GRACO INC. S10595

GG 26B701

GG 26B618

AGITATOR, 6:1 GEAR REDUCTION

Graco 26B618 Back-Geared Radial Piston Agitator, In-Drum, heavy duty, 2 inch Bung Mount

Speed up savings when agitating high viscosity material. The radial piston air motor that powers this back-geared agitator uses up to 85 percent less compressed air than a comparable rotary vane motor.

• Installs quickly for immediate cost savings
• Needs no air line lubrication to keep running well
• Operates more quietly than comparable rotary vane agitator air motors

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• For Use With: 55 Gallon (208 Liter) Drum

• Maximum Air Inlet Pressure (bar): 5
• Maximum Air Inlet Pressure (kPa): 500
• Maximum Air Inlet Pressure (psi): 70

• Maximum Speed (RPM): 83

• Maximum Viscosity (cP): 3000

• Maximum Working Pressure (bar): 5
• Maximum Working Pressure (kPa): 500
• Maximum Working Pressure (psi): 70

• Motor Type: Pneumatic - Radial Piston

• Power Rating (HP): 0.16

GG 26B720

GG 26B712

GG 26B721

GG 26B727

GG 26B736

KIT, TOOL, AUTO GUN ALIGNMENT

Graco 26B736 Graco Gauge alignment tool for automatic air-assisted spray gun air caps

Precise air cap orientation is critical to automatic finishing, especially in flat line systems. Use this tool to set and keep the air cap of your PerformAA Auto Air Assist Spray Gun at the exact angle needed to optimize spray performance.

• The Graco Gauge is unique in wood and metal finishing, no other automatic air assist sprayer has this accessory.

GG 26B800

GG 26B801

GG 26B867

GG 26B868

GG 26B869

GG 26B914

GG 26B915

GG 26C051

GG 26C064

CHARGER, WOE WITH CHAMBER AND BOWL

Graco 26C064 Waste Oil Evacuation System with 24 gal (90 l) Steel Tank, Suction Probes, Sight Glass, Oil Drain Funnel and Adapters

For shops requiring flexibility when it comes to removing used fluids, use Graco's multi-purpose used oil evacuation system.

• Large Offset Collection Pan - Wide offset collection bowl prevents splashing.
• Vacuum Gauge - Ensure peak performance with easy-to-read vacuum gauge.
• Easy to Drain- Pressurize using shop air for easy oil evacuation.
• Large 24 Gallon (90 Liter) Capacity Receiver - Perfect for small to large shops without an evacuation system.
• Sight Glass - Inspect oil quality via large, clear evacuation chamber and verify amount extracted.

• Model: Oil Ace

• Compatible Fluid: Used Oil, ATF

• Maximum Operating Temperature ( degree C): 90
• Maximum Operating Temperature ( degree F): 194

• Minimum Operating Temperature ( degree C): -1
• Minimum Operating Temperature ( degree F): 30

• Overall Height (cm): 150 to 180
• Overall Height (in): 59.0 to 70.8
• Overall Length (cm): 61
• Overall Length (in): 24
• Overall Length (mm): 609.6
• Overall Width (cm): 40.6
• Overall Width (in): 16
• Overall Width (mm): 406.4000

GG 26C092

GG 26C116

GG 26C121

GG 26C122

GG 26C171

GG XHD535

XHD RAC TIP, SPRAY, CYLINDER, 535

Graco XHD535 XHD RAC SwitchTip, .535

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 30.5
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 305

• Maximum Flow Rate (GPM): 1.31
• Maximum Flow Rate (L/min): 4.96

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 10
• Minimum Fan Width (mm): 254

• Orifice Diameter (in): 0.035

GG XHD621

XHD RAC TIP, SPRAY, CYLINDER, 621

Graco XHD621 XHD RAC SwitchTip, .621

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.021

GG XHD561

XHD RAC TIP, SPRAY, CYLINDER, 561

Graco XHD561 XHD RAC SwitchTip, .561

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 30.5
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 305

• Maximum Flow Rate (GPM): 4.00
• Maximum Flow Rate (L/min): 15.14

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 10
• Minimum Fan Width (mm): 254

• Orifice Diameter (in): 0.061

GG XHD511

XHD RAC TIP, SPRAY, CYLINDER, 511

Graco XHD511 XHD RAC SwitchTip, .511

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 30.5
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 305

• Maximum Flow Rate (GPM): 0.12
• Maximum Flow Rate (L/min): 0.45

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 10
• Minimum Fan Width (mm): 254

• Orifice Diameter (in): 0.011

GG XHD525

XHD RAC TIP, SPRAY, CYLINDER, 525

Graco XHD525 XHD RAC SwitchTip, .525

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 30.5
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 305

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.54

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 10
• Minimum Fan Width (mm): 254

• Orifice Diameter (in): 0.025

GG XHD625

XHD RAC TIP, SPRAY, CYLINDER, 625

Graco XHD625 XHD RAC SwitchTip, .625

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.54

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.025

GG XHD623

XHD RAC TIP, SPRAY, CYLINDER, 623

Graco XHD623 XHD RAC SwitchTip, .623

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.57
• Maximum Flow Rate (L/min): 2.16

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.023

GG XHD629

XHD RAC TIP, SPRAY, CYLINDER, 629

Graco XHD629 XHD RAC SwitchTip, .629

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.90
• Maximum Flow Rate (L/min): 3.41

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.029

GG XHD635

XHD RAC TIP, SPRAY, CYLINDER, 635

Graco XHD635 XHD RAC SwitchTip, .635

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 1.31
• Maximum Flow Rate (L/min): 4.96

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.035

GG XHD633

XHD RAC TIP, SPRAY, CYLINDER, 633

Graco XHD633 XHD RAC SwitchTip, .633

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solventborne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 1.17
• Maximum Flow Rate (L/min): 4.43

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.033

GG XHD627

XHD RAC TIP, SPRAY, CYLINDER, 627

Graco XHD627 XHD RAC SwitchTip, .627

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.74
• Maximum Flow Rate (L/min): 2.80

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.027

GG XHD631

XHD RAC TIP, SPRAY, CYLINDER, 631

Graco XHD631 XHD RAC SwitchTip, .631

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 1.03
• Maximum Flow Rate (L/min): 3.90

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.031

GG XHD641

XHD RAC TIP, SPRAY, CYLINDER, 641

Graco XHD641 XHD RAC SwitchTip, .641

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 1.80
• Maximum Flow Rate (L/min): 6.81

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.041

GG XHD645

XHD RAC TIP, SPRAY, CYLINDER, 645

Graco XHD645 XHD RAC SwitchTip, .645

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 2.17
• Maximum Flow Rate (L/min): 8.21

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.045

GG XHD651

XHD RAC TIP, SPRAY, CYLINDER, 651

Graco XHD651 XHD RAC SwitchTip, .651

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 2.79
• Maximum Flow Rate (L/min): 10.56

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.051

GG XHD655

XHD RAC TIP, SPRAY, CYLINDER, 655

Graco XHD655 XHD RAC SwitchTip, .655

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 3.25
• Maximum Flow Rate (L/min): 12.30

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.055

GG XHD665

XHD RAC TIP, SPRAY, CYLINDER, 665

Graco XHD665 XHD RAC SwitchTip, .665

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 4.53
• Maximum Flow Rate (L/min): 17.15

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.065

GG XHD671

XHD RAC TIP, SPRAY, CYLINDER, 671

Graco XHD671 XHD RAC SwitchTip, .671

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 5.41
• Maximum Flow Rate (L/min): 20.48

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.071

GG XHD675

XHD RAC TIP, SPRAY, CYLINDER, 675

Graco XHD675 XHD RAC SwitchTip, .675

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solventborne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 6.04
• Maximum Flow Rate (L/min): 22.86

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.075

GG XHD711

XHD RAC TIP, SPRAY, CYLINDER, 711

Graco XHD711 XHD RAC SwitchTip, .711

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solventborne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 40.6
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 406

• Maximum Flow Rate (GPM): 0.12
• Maximum Flow Rate (L/min): 0.45

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 14
• Minimum Fan Width (mm): 356

• Orifice Diameter (in): 0.011

GG XHD719

XHD RAC TIP, SPRAY, CYLINDER, 719

Graco XHD719 XHD RAC SwitchTip, .719

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 40.6
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 406

• Maximum Flow Rate (GPM): 0.38
• Maximum Flow Rate (L/min): 1.44

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 14
• Minimum Fan Width (mm): 356

• Orifice Diameter (in): 0.019

GG XHD717

XHD RAC TIP, SPRAY, CYLINDER, 717

Graco XHD717 XHD RAC SwitchTip, .717

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 40.6
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 406

• Maximum Flow Rate (GPM): 0.31
• Maximum Flow Rate (L/min): 1.17

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 14
• Minimum Fan Width (mm): 356

• Orifice Diameter (in): 0.017

GG XHD727

XHD RAC TIP, SPRAY, CYLINDER, 727

Graco XHD727 XHD RAC SwitchTip, .727

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 40.6
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 406

• Maximum Flow Rate (GPM): 0.74
• Maximum Flow Rate (L/min): 2.80

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 14
• Minimum Fan Width (mm): 356

• Orifice Diameter (in): 0.027

GG XHD725

XHD RAC TIP, SPRAY, CYLINDER, 725

Graco XHD725 XHD RAC SwitchTip, .725

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 40.6
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 406

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.54

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 14
• Minimum Fan Width (mm): 356

• Orifice Diameter (in): 0.025

GG XHD815

XHD RAC TIP, SPRAY, CYLINDER, 815

Graco XHD815 XHD RAC SwitchTip, .815

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 45.7
• Maximum Fan Width (in): 18
• Maximum Fan Width (mm): 457

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 16
• Minimum Fan Width (mm): 406

• Orifice Diameter (in): 0.015

GG XHD771

XHD RAC TIP, SPRAY, CYLINDER, 771

Graco XHD771 XHD RAC SwitchTip, .771

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 40.6
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 406

• Maximum Flow Rate (GPM): 5.41
• Maximum Flow Rate (L/min): 20.48

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 14
• Minimum Fan Width (mm): 356

• Orifice Diameter (in): 0.071

GG XHD817

XHD RAC TIP, SPRAY, CYLINDER, 817

Graco XHD817 XHD RAC SwitchTip, .817

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 45.7
• Maximum Fan Width (in): 18
• Maximum Fan Width (mm): 457

• Maximum Flow Rate (GPM): 0.31
• Maximum Flow Rate (L/min): 1.17

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 16
• Minimum Fan Width (mm): 406

• Orifice Diameter (in): 0.017

GG XHD819

XHD RAC TIP, SPRAY, CYLINDER, 819

Graco XHD819 XHD RAC SwitchTip, .819

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 45.7
• Maximum Fan Width (in): 18
• Maximum Fan Width (mm): 457

• Maximum Flow Rate (GPM): 0.38
• Maximum Flow Rate (L/min): 1.44

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 16
• Minimum Fan Width (mm): 406

• Orifice Diameter (in): 0.019

GG XHD821

XHD RAC TIP, SPRAY, CYLINDER, 821

Graco XHD821 XHD RAC SwitchTip, .821

With its Reverse-A-Clean (RAC) Tip, it's easy to clear clogs. The Switch Tip design lets you change tip sizes in seconds - without removing the tip guard and housing.

• Saves time - no screwdriver required, change tip sizes in seconds
• For heavy-duty applications up to 7250 psi (500 bar)
• Recommended for use with Xtreme Sprayers and XTR Guns

• Model: XHD RAC
• Series: SwitchTip

• Compatible Material: Solvent borne Paints, Water-Based Paint

• For Use With: Xtreme Sprayers, XTR Airless Spray Guns

• Maximum Fan Width (cm): 45.7
• Maximum Fan Width (in): 18
• Maximum Fan Width (mm): 457

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (psi): 7250

• Minimum Fan Width (in): 16
• Minimum Fan Width (mm): 406

• Orifice Diameter (in): 0.021

GG 256389

GG 256262

GG 256206

GG 256200

T1 PUMP

Graco 256200 T1 Supply Pump (Stainless Steel): 2:1 Fluid to Air Ratio

Gracos family of transfer pumps maintain performance in any environment. Transfer pumps are required to feed chemical to your Reactor spray machine or any other equipment requiring fluid transfer. Consider your material viscosities, desired output rate, interior ceiling height of your rig, and available air pressure when choosing your ideal transfer pump.

• Provide consistent feed pressures and flow rates for dependable results
• Lower pressure drops with higher viscosity materials at any ambient temperature
• Designed and manufactured by the worldwide leader in pump technology
• Quick-release bung adapter for easy drum removal without interference from hose connections
• Stainless steel wetted parts for corrosion-resistance
• PTFE seals for improved performance and less maintenance

• Model: T1

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Compatible Material: Polyurethane Foam, Polyurea

• Cycles Per Gallon: 40

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 12.5
• Maximum Air Inlet Pressure (kPa): 1250
• Maximum Air Inlet Pressure (MPa): 1.2
• Maximum Air Inlet Pressure (psi): 180

• Maximum Continuous Cycle Rate (CPM): 100

• Maximum Flow Rate (GPM): 2.5
• Maximum Flow Rate (L/min): 9.5

• Maximum Operating Temperature ( degree C): 82
• Maximum Operating Temperature ( degree F): 180

• Maximum Working Pressure (bar): 25
• Maximum Working Pressure (kPa): 2500
• Maximum Working Pressure (MPa): 2.5
• Maximum Working Pressure (psi): 360

• Package Options: Bare

• Pump Ratio: 2:1

GG 256456

GG 256216

LDP5 VALVE, METERED, RIGID EXT

Graco 256216 LDP5 Electronic Preset Meter - Rigid Extension - 1/2 in. (13 mm) Inlet - Trigger Guard and Swivel Cover Included - NPT

Gracos LDP5 meters are perfect for lower-volume service application in small service shops, fast lube centers and automotive dealerships. These meters are capable of metering petroleum, synthetic based oil and anti-freeze up to 5 gpm (19 lpm).

• Easy to read LCD screen keeps dispenses precise.
• Inlet 1/2 in. NPT with swivel.
• Rugged meter body is impact resistant for long life.
• Preset meter automatically shuts-off flow when preset quantity has been dispensed.
• 5 year warranty. See manufacturers website for details.

• Model: LDP5

• Approvals: CE

• Compatible Material: Oil, Antifreeze

• Dispense Type: Preset

• Display Type: Electronic

• Extension Type: Rigid

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Extension, Trigger Guard, Swivel Cover
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 5
• Maximum Flow Rate (L/min): 19

• Maximum Operating Temperature ( degree C): 49
• Maximum Operating Temperature ( degree F): 120

• Maximum Storage Temperature ( degree C): 49
• Maximum Storage Temperature ( degree F): 120

• Maximum Working Pressure (bar): 69
• Maximum Working Pressure (kPa): 6900
• Maximum Working Pressure (MPa): 7
• Maximum Working Pressure (psi): 1000
• Meter Accuracy (%): plus/minus 00.5

• Metering Gun Weight (kg): 1.36
• Metering Gun Weight (lb): 3

• Minimum Flow Rate (GPM): 0.1
• Minimum Flow Rate (L/min): 0.4

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Nozzle Type: Automatic

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Type: NPT

• Overall Height (cm): 8.3
• Overall Height (in): 3.25
• Overall Height (mm): 83
• Overall Length (cm): 28
• Overall Length (in): 11
• Overall Length (mm): 280
• Overall Width (cm): 8.3
• Overall Width (in): 3.25
• Overall Width (mm): 83

• Recommended Environment: Indoor

GG 256292

GG 256290

VALVE,CLR/CAT CHG,LP,3-C LR

Graco 256290 3 Color Low Pressure Valve Stack, 4 Valves

GG 256457

GG 256459

GG 256385

GG 256460

GG 256219

GG 256463

GG 256462

GG 256466

GG 256464

GG 256486

MATRIX METER VALVE, 15, RIGID

Graco 256486 Matrix Electronic Dispense Meter, 14 gpm or Less, 1/2 in npt(f) swivel with rigid extension, high flow, quick-close nozzle for oil

Ultra-durable Matrix meters stand up to tough use, backed by a 7-year warranty (3 years on electronics). The keypad gives technicians control right from the meter, and dispense data can be associated with the work order for paperless transactions.

• Large LCD Display and Simple Operator Controls

  Adjusts for reading in all lighting conditions with easy set up and navigation.

  • Long Battery Life

    Uses four off-the-shelf batteries - no charging station needed.

    • Wireless Radio

      Built-in radio

      • Fluid Swivel

        1/2 inch NPT fluid inlet option meets standard and high-flow requirements




        • Approvals: FCC, Industry Canada (IC), C-Tick, CE
        • Compatible Material: Oil, ATF, Antifreeze
        • Extension Type: Rigid
        • Fluid Inlet Thread Gender: Female
        • Fluid Outlet Thread Gender: Female
        • Includes: Meter, Extension, Nozzle, Swivel Boot
        • Inlet Size (cm): 1.27
        • Inlet Size (in): 0.5
        • Inlet Size (mm): 12.7
        • Inlet Thread Type: NPT
        • Maximum Flow Rate (GPM): 14
        • Maximum Flow Rate (L/min): 53
        • Maximum Operating Temperature ( degree C): 70
        • Maximum Operating Temperature ( degree F): 158
        • Maximum Storage Temperature ( degree C): 70
        • Maximum Storage Temperature ( degree F): 158
        • Maximum Working Pressure (bar): 103.4
        • Maximum Working Pressure (kPa): 10300
        • Maximum Working Pressure (MPa): 10.3
        • Maximum Working Pressure (psi): 1500
        • Meter Accuracy (%): plus/minus 00.5
        • Meter Technology: Oval Gear
        • Metering Gun Weight (kg): 2.3
        • Metering Gun Weight (lb): 5
        • Minimum Flow Rate (GPM): 0.1
        • Minimum Flow Rate (L/min): 0.4
        • Minimum Operating Temperature ( degree C): -16
        • Minimum Operating Temperature ( degree F): 4
        • Nozzle Type: High Flow, Quick Close
        • Outlet Size (cm): 1.905
        • Outlet Size (in): 0.75
        • Outlet Size (mm): 19.05
        • Outlet Thread Type: Straight Thread O-Ring Boss
        • Overall Height (cm): 14.605
        • Overall Height (in): 5.75
        • Overall Height (mm): 146.05
        • Overall Length (cm): 33
        • Overall Length (in): 13
        • Overall Length (mm): 330
        • Overall Width (cm): 9.525
        • Overall Width (in): 3.75
        • Overall Width (mm): 95.25
        • Recommended Environment: Indoor

GG 256548

REACTOR HEATED HOSE, 3500, W/SCUFF, 1/2" , 50'

Graco 256548 50 ft (15 m) High Pressure Heated Hose with Thermocouple Scuff Guard and 1/2 in Inside Diameter

Graco's heated hoses are designed specifically for use with Reactor Equipment. Hoses are a key component to the total system, making it important to achieve accurate and uniform heating for the best application possible.

• New multi-strand copper heating element has greatly increased hose quality:

  Provides 10-times* the flex life compared to previous flat copper heating element

  Long-term, even heating without hot spots

  Backwards compatible with existing Reactor heated hoses

  • Copper-heated hoses are designed specifically for use with Graco proportioners
  • Covered with proprietary butyl cover for protection against moisture sensitive isocyanate
  • Different fitting sizes on the isocyanate and resin hoses prevent accidentally connecting the wrong hoses together
  • Hoses use custom designed splice kit to electrically connect hoses without having to run copper under the fittings
  • Helix-design whip hose uses braided copper wires for added flexibility and longer life




  • Model: Reactor Heated Hoses
  • Series: Mesh Scuff
  • For Use With: Plural Component Proportioners
  • Hose Length (ft): 50
  • Hose Length (m): 15.2
  • Maximum Working Pressure (bar): 241
  • Maximum Working Pressure (kPa): 24100
  • Maximum Working Pressure (MPa): 24.1
  • Maximum Working Pressure (psi): 3500

GG 256494

GG H43810

GG 102774

GG 116635

GG 127476

GG 127482

GG 15C852

GG 15D564

GG 15D592

GG 15J647

GG 15U938

GG 15J821

GG 16P451

GG 222869

GG 222974

GG 223016

GG 223059

GG 224433

GG 224438

GG 224450

GG 224935

GG 224936

GG 233082

GG 233131

GG 233150

GG 233698

GG 233829

GG 233834

GG 233836

GG 233946

GG 233952
