GRACO INC. S10595
SPRA VALVE, SPRAY 8 IN DIA
GG 563276
SPRA VALVE, SPRAY 8 IN DIA
Air-lube Control Valve and Nozzle Assembly - 8 in. spray diameter, wideConserves air–air required only during spray interval
Versatile–can be used with any centralized lube system or mechanical oiler and will handle grease or oil
External mix nozzle purges itself and prevents clogging
Saves lubricant by spraying smaller amounts at frequent intervals, provides better film, with no waste
8 in. spray diameter, wide
Lubriquip part number 510-652-230 Trabon part number 10652-W PH PUMP
GG 563393
PH PUMP
PH Pump™ without ReservoirModular pump and reservoir design plus built-in features enable the PH Manual Pump to be customized for a wide range of applications. The PH Manual Pump permits increased standardization with resultant economies in spare parts stocking and greater employee familiarity with plant or job site lubrication systems. This pump is sturdily built with aluminum and steel components to meet the high standards of performance and quality you expect from Graco products. It is a compact, space-saving unit.
Built-in volume indicator provides easy verification that lubricant is being delivered to the system and that divider valves are completing lube cycles. Interchangeable reservoirs make it convenient to expand or contract the lube distribution system, to switch from oil to grease or from grease to oil – without replacing the entire system. Wide applicability is provided by an optional two- or four outlet valve that mounts under the pump outlet. This valve allows the pump to serve up to four different systems or to supply one or two separate manual reversing systems. Single-acting positive displacement pump design minimizes the number of moving and wearing parts for extended pump life and reduced maintenance. Built-in automatic relief valve protects system components from over-pressure. Built-in outlet check valve prevents back pressure from damaging pump and minimizes chance for contaminants to get into the pump or the lube supply. 3,000 psi (207 bar) pressure gauge provides a fast check on system status. Lubriquip part number 521-800-000 XP SYSTEM, 1:1, 145/145, BF, CH
GG 572102
XP SYSTEM, 1:1, 145/145, BF, CH
XP70-hf Cart System, Hazardous Location, 1:1 Bare, 240VTwo-component spraying made easy and affordable. The XP-hf system combines the popular XP70 Sprayers with the powerful XL 10000 air motor. Combining these two technologies, you get more flow - getting jobs done faster and with less wear and tear. Engineered for more flow capacity, the Graco XP70-hf is great for applications where you want to spray with multiple guns or larger tip sizes. Flexible options for mix ratio, pressure and flow rate – choose the right system for the application. If you occasionally change materials, the Graco XP Sprayers are the right choice. That’s because you can change the ratio by simply changing out one or two pump lowers. Available in 1:1, 1.5:1, 2:1, 2.5:1, 3:1 and 4:1 mix ratios.
High-pressure performance for two-part high-solids coatings. Reduced material waste No more throwing away unused mixed material at the end of the day Save money by using less clean-up solvent Consistent material quality - no more guesswork or human error in measuring materials Easy to operate - minimal training required Reduced maintenance costs Rated for 7250 psi (500 bar, 50 MPa) to handle viscous materials and long hose lengths Check Valve, 1/2npt, F, 45psi, HC
GG 94/0351-2/50
Check Valve, 1/2npt, F, 45psi, HC Check Valve, 1/2Npt, Vit, Ss, Adj, 50-150
GG 94/0360-2/98
Check Valve, 1/2Npt, Vit, Ss, Adj, 50-150 Fitting, Bushing, 1/8Nptx10-32, Brs
GG 94/0463/96
Fitting, Bushing, 1/8Nptx10-32, Brs
KIT, REPAIR, PACKING
GG 17K162
KIT, REPAIR, PACKING
Pump Packing Repair Kit Replace a worn or damaged pump with genuine Graco parts. Refer to the parts manual for your sprayer to ensure part compatibility Graco’s dedication to delivering the highest quality products also allows you to protect your investment by offering products that can be repaired to ensure years of reliable service. High quality parts have years of service, but wear parts will need replacement over time. Use Genuine Graco parts to keep your sprayer in peak working order for years to come. Graco Tech Support can further assist with troubleshooting sprayer operation
