GRACO INC. S10595

GG 556638

FITTING, ELBOW-MALE 3/16T X 1/8 NPT

Graco 556638 Fitting - Brass Male Tube Elbows 3/16 in. (4.8 mm) Tube x 1/8 in. (3.2 mm) NPTF

• Brass Male Tube Elbow
• 3/16 inch (4.8 mm) tube x 1/8 inch (3.2 mm) NPTF
• Lubriquip part number 435-440-030

• Application: On-Road Vehicles

• Compatible Material: Oil, Grease

• Connection Type: Tube End, Threaded

• For Use With: Tube

• Material: Brass

GG 557349

PLUG, PIPE, SOC HD 1/8 NPTF

Graco 557349 Trabon MSP Divider Valve - Outlet Port Plug, NPT

• Outlet Port Plug - 1 outlet port plug is required for each Svalve section
• NPT
• Lubriquip part number 503-485-000

• Color: Black

• Connection Type: Threaded

• Finish/Coating: Everlube
• Fits Diameter (in): 0.187
• Fits Diameter (mm): 5

• For Use With: Pipe

• Material: Steel

• Overall Length (cm): 0.7925
• Overall Length (in): 0.312
• Overall Length (mm): 8

GG 556032

ELEMENT, FILTER, 20 MICRON

Graco 556032 Replacement Element for Cartridge Oil Filter - 20 Micron, Lubriquip part number 183-100-106

• Pressure Filter - Replacement Elements - 20 micron

• For Use With: Meter-Flo Pump Packages, Cartridge Oil Filters

GG 557494

NUT, LOCK 3/8-24

Graco 557494 Trabon MX Divider Valve - Tie Rod Nut

• MX tie rod nut (8 required per assembly)
• Lubriquip part number 510-506-001

• Model: Trabon
• Series: MX

• Finish/Coating: Zinc

• Grade: C

• Inside Diameter (in): 0.375
• Inside Diameter (mm): 9.525

• Nut Type: Lock Nut

• Overall Height (in): 0.415
• Overall Height (mm): 10.541
• Overall Width (in): 0.5625
• Overall Width (mm): 14.2875

GG 557732

ROD, TIE, MSP, 4 SECTON

Graco 557732 Trabon MSP Divider Valve - 4 Section Tie Rod (3 Required)

• 4-Section Tie Rods
• Three tie rods and tie rod nuts required for assembly
• Lubriquip part number 527-001-830

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

GG 557392

ADAPTER, 1/8 NPTF HEX

Graco 557392 Pipe Extension - 1/8 NPT male X 1/8 NPT female, 3/4 long

• 1/8 NPTF Thread Pipe Extension Nipple - Steel
• 3/4overall length
• Lubriquip part number 509-027-000

• Connection Type: Threaded

• Finish/Coating: Zinc

• For Use With: Pipe

• Material: Steel

GG 557438

DISK, .688 2950 PSI BLUE

Graco 557438 Replacement Rupture Disk, 11/16 in, 2950 psi, Blue

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Lubriquip part number 509-297-000
• Trabon part number 9297

• Color: Blue

• Maximum Working Pressure (bar): 203
• Maximum Working Pressure (kPa): 20326
• Maximum Working Pressure (MPa): 20.3
• Maximum Working Pressure (psi): 2950

• Number of Pieces: 6

• Overall Diameter (cm): 1.7
• Overall Diameter (in): 0.688

• Overall Diameter (mm): 17

GG 557518

ROD, TIE MJ 6

Graco 557518 Trabon MJ Divider Valve - 6 Section Tie Rod (2 Required)

• 6-Section Tie Rods
• Two tie rods and tie rod nuts required for assembly.
• NPSF
• Trabon part number 10999-6

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment

GG 557433

DISK, .688 1450 PSI YELLOW

Graco 557433 Replacement Rupture Disk, 11/16 in, 1450 psi, Yellow

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Lubriquip part number 509-292-000
• Trabon part number 9292

• Color: Yellow

• Maximum Working Pressure (bar): 100
• Maximum Working Pressure (kPa): 9991
• Maximum Working Pressure (MPa): 10
• Maximum Working Pressure (psi): 1450

• Number of Pieces: 6

• Overall Diameter (cm): 1.7
• Overall Diameter (in): 0.688

• Overall Diameter (mm): 17

GG 557428

DISK, .375 2950/7300 PSI BLU

Graco 557428 Replacement Rupture Disk, 3/8 in, 7300 psi, Blue

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Lubriquip part number 509-283-000
• Trabon part number 9283

• Color: Blue

• Maximum Working Pressure (bar): 503
• Maximum Working Pressure (kPa): 50297
• Maximum Working Pressure (MPa): 50.3
• Maximum Working Pressure (psi): 7300

• Number of Pieces: 1

• Overall Diameter (cm): 1
• Overall Diameter (in): 0.375

• Overall Diameter (mm): 10

GG 557439

DISK, .688 3250 PSI PURP

Graco 557439 Replacement Rupture Disk, 11/16 in, 3250 psi, Purple

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Lubriquip part number 509-298-000
• Trabon part number 9298

• Color: Purple

• Maximum Working Pressure (bar): 224
• Maximum Working Pressure (kPa): 22393
• Maximum Working Pressure (MPa): 22.4
• Maximum Working Pressure (psi): 3250

• Number of Pieces: 6

• Overall Diameter (cm): 1.7
• Overall Diameter (in): 0.688

• Overall Diameter (mm): 17

GG 557374

FITTING, FILL STUD, 1/4 NPT

Graco 557374 Trabon Style Fill Stud, 1/4 inch NPT male

• Trabon Style Fill Stud
• Lubriquip part number 506-189-001
• Trabon part number 6189-1

• Series: Trabon

• Connection Type: Threaded

• End A Inlet Thread Gender: None

• Maximum Working Pressure (psi): 500

• Outlet Size (in): 1/4-18 NPTF
• Outlet Thread Gender: Male

GG 557735

ROD, TIE, MSP, 7 SECTION

Graco 557735 Trabon MSP Divider Valve - 7 Section Tie Rod (3 Required)

• 7-Section Tie Rods
• Three tie rods and tie rod nuts required for assembly
• Lubriquip part number 527-001-860

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

GG 557734

ROD, TIE, MSP, 6 SECTION

Graco 557734 Trabon MSP Divider Valve - 6 Section Tie Rod (3 Required)

• 6-Section Tie Rods
• Three tie rods and tie rod nuts required for assembly
• Lubriquip part number 527-001-850

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

GG 557427

DISK, .375 2650/6400 PSI PNK

Graco 557427 Replacement Rupture Disk, 3/8 in, 6400 psi, Pink

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Lubriquip part number 509-282-000
• Trabon part number 9282

• Color: Pink

• Maximum Working Pressure (bar): 441
• Maximum Working Pressure (kPa): 44096
• Maximum Working Pressure (MPa): 44.1
• Maximum Working Pressure (psi): 6400

• Number of Pieces: 1

• Overall Diameter (cm): 1
• Overall Diameter (in): 0.375

• Overall Diameter (mm): 10

GG 557425

DISK, .375 2050/5500 PSI OR

Graco 557425 Replacement Rupture Disk, 3/8 in, 5500 psi, Orange

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Lubriquip part number 509-280-000
• Trabon part number 9280

• Color: Orange

• Maximum Working Pressure (bar): 379
• Maximum Working Pressure (kPa): 37895
• Maximum Working Pressure (MPa): 37.9
• Maximum Working Pressure (psi): 5500

• Number of Pieces: 1

• Overall Diameter (cm): 1
• Overall Diameter (in): 0.375

• Overall Diameter (mm): 10

GG 557736

ROD, TIE, MSP, 8 SECTION

Graco 557736 Trabon MSP Divider Valve - 8 Section Tie Rod (3 Required)

• 8-Section Tie Rods
• Three tie rods and tie rod nuts required for assembly
• Lubriquip part number 527-001-870

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

GG 557490

ROD, TIE, MX 5

Graco 557490 Trabon MX Divider Valve - 5 Section Tie Rod

• 5-Section Tie Rods
• Lubriquip part number 510-505-050
• Trabon part number 10505-5

• Model: Trabon
• Series: MX

• Application: In-Plant Machinery

GG 557700

STRAINER, 138 MICRON

Graco 557700 Replacement Filter Element, 149 micron/100 mesh, Lubriquip part number 525-766-010

• Replacement element for filter assemblies 563507, 557517, 564406

• For Use With: In-Line Oil & Grease Strainers

GG 557488

ROD, TIE, MX 3

Graco 557488 Trabon MX Divider Valve - 3 Section Tie Rod

• 3-Section Tie Rods
• Lubriquip part number 510-505-030
• Trabon part number 10505-3

• Model: Trabon
• Series: MX

• Application: In-Plant Machinery

GG 557515

ROD, TIE, FEEDER, MJ-3

Graco 557515 Trabon MJ Divider Valve - 3 Section Tie Rod (2 Required)

• 3-Section Tie Rods
• Two tie rods and tie rod nuts required for assembly.
• NPSF
• Trabon part number 10999-3

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment

GG 557434

DISK, .688 1750 PSI RED

Graco 557434 Replacement Rupture Disk, 11/16 in, 1750 psi, Red

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Lubriquip part number 509-293-000
• Trabon part number 9293

• Color: Red

• Maximum Working Pressure (bar): 121
• Maximum Working Pressure (kPa): 12058
• Maximum Working Pressure (MPa): 12.1
• Maximum Working Pressure (psi): 1750

• Number of Pieces: 6

• Overall Diameter (cm): 1.7
• Overall Diameter (in): 0.688

• Overall Diameter (mm): 17

GG 557546

BRACKET, SWITCH, T-CYCLE

Graco 557546 Replacement Bracket for Cycle Switch

• Replacement bracket for 563272, 563273, 564357
• Lubriquip part number 511-968-002

GG 557436

DISK, .688 2350 PSI ALUM

Graco 557436 Replacement Rupture Disk, 11/16 in, 2350 psi, Aluminum

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Lubriquip part number 509-295-000
• Trabon part number 9295

• Color: Aluminum

• Maximum Working Pressure (bar): 162
• Maximum Working Pressure (kPa): 16192
• Maximum Working Pressure (MPa): 16.2
• Maximum Working Pressure (psi): 2350

• Number of Pieces: 6

• Overall Diameter (cm): 1.7
• Overall Diameter (in): 0.688

• Overall Diameter (mm): 17

GG 557731

ROD, TIE, MSP, 3 SECTION

Graco 557731 Trabon MSP Divider Valve - 3 Section Tie Rod (3 Required)

• 3-Section Tie Rods
• Three tie rods and tie rod nuts required for assembly
• Lubriquip part number 527-001-820

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

GG 557733

ROD, TIE, MSP, 5 SECTION

Graco 557733 Trabon MSP Divider Valve - 5 Section Tie Rod (3 Required)

• 5-Section Tie Rods
• Three tie rods and tie rod nuts required for assembly
• Lubriquip part number 527-001-840

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

GG 557797

CAP, FILL, RESERVOIR

Graco 557797 Reservoir Fill Cap

• Fill Cup
• Lubriquip part number 534-147-000
• Trabon part number 34147

• For Use With: LubeMaster Pumps

GG 557766

ROD, TIE, MXP, 3 SECTION

Graco 557766 Trabon MXP Divider Valve - 3 Section Tie Rod (3 Required)

• 3-Section Tie Rod
• Three required per assembly
• Lubriquip part number 527-300-270

• Model: Trabon
• Series: MXP

• Application: In-Plant Machinery

GG 557804

FILTER, 25 MICRON, 3 5/8 LG

Graco 557804 Replacement Filter Cartridge, 25-micron Standard, Lubriquip part 540-272-001, replaces part 540-272-000 and Trabon part 40272, Genuine Trabon replacement element for Lubriquip assemblies 183-000-010, 183-000-011, 183-000-050, 183-000-051, 183-000-150, 183-000-151

• 25 micron Replacement Filter Element
• 2-5/8 in (67 mm) OD x 3-5/8 in (92 mm) Standard Length Element

• For Use With: Cartridge Oil Filters

GG 557813

METER-FLO PUMP, 18/30 CU IN/MIN CCW NPT

Graco 557813 Meter-Flo Electric Pump, 30 cu in/min (492 cc/min) @ 1,725 rpm, NPT Ports, CCW

With its solid pump housing, these rugged gear pumps are designed for dependable operation in high demand applications. The gear pump is available with a direct-coupled 1/2 horsepower motor capable of 1,725 rpm's with output volumes of 245 cubic inches per minute (4015 cc/min).

• Ideal for applications requiring continuous oil delivery up to 1,000 lubrication points
• Positive displacement helps assure constant delivery of proper volume.
• Match-ground heat-treated steel gears are enclosed in a rigid, cast-iron housing to assure dependability and long life.
• Adjustable pressure relief valve protects pump against overload conditions.
• Meter-flo pumps are available with a special coupling that allows easy replacement of older Meter-Flo pumps.
• Lubriquip part number 540-800-001

• Model: Meter-Flo

• Application: In-Plant Machinery

• Compatible Material: Oil
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.5
• Fluid Outlet Size (mm): 12.7000
• Fluid Outlet Thread Type: NPT

• Maximum Flow Rate (ci/min): 30

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum SUS Grade (SUS): 3000

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

• Minimum Operating Temperature ( degree C): 10
• Minimum Operating Temperature ( degree F): 50

• Minimum SUS Grade (SUS): 300

• Power Type: Electric

GG 557815

METER-FLO PUMP, 55/83 CU IN/MIN CCW NPT

Graco 557815 Meter-Flo Electric Pump, 84 cu in/min (1377 cc/min) @ 1,725 rpm, NPT Ports, CCW

With its solid pump housing, these rugged gear pumps are designed for dependable operation in high demand applications. The gear pump is available with a direct-coupled 1/2 horsepower motor capable of 1,725 rpm's with output volumes of 245 cubic inches per minute (4015 cc/min).

• Ideal for applications requiring continuous oil delivery up to 1,000 lubrication points
• Positive displacement helps assure constant delivery of proper volume.
• Match-ground heat-treated steel gears are enclosed in a rigid, cast-iron housing to assure dependability and long life.
• Adjustable pressure relief valve protects pump against overload conditions.
• Meter-flo pumps are available with a special coupling that allows easy replacement of older Meter-Flo pumps.
• Lubriquip part number 540-800-021

• Model: Meter-Flo

• Application: In-Plant Machinery

• Compatible Material: Oil
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.5
• Fluid Outlet Size (mm): 12.7000
• Fluid Outlet Thread Type: NPT

• Maximum Flow Rate (ci/min): 84

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum SUS Grade (SUS): 3000

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

• Minimum Operating Temperature ( degree C): 10
• Minimum Operating Temperature ( degree F): 50

• Minimum SUS Grade (SUS): 300

• Power Type: Electric

GG 557816

METER-FLO PUMP, 76/116 CU IN/MIN CCW NPT

Graco 557816 Meter-Flo Electric Pump, 117 cu in/min (1917 cc/min) @ 1,725 rpm, NPT Ports, CCW

With its solid pump housing, these rugged gear pumps are designed for dependable operation in high demand applications. The gear pump is available with a direct-coupled 1/2 horsepower motor capable of 1,725 rpm's with output volumes of 245 cubic inches per minute (4015 cc/min).

• Ideal for applications requiring continuous oil delivery up to 1,000 lubrication points
• Positive displacement helps assure constant delivery of proper volume.
• Match-ground heat-treated steel gears are enclosed in a rigid, cast-iron housing to assure dependability and long life.
• Adjustable pressure relief valve protects pump against overload conditions.
• Meter-flo pumps are available with a special coupling that allows easy replacement of older Meter-Flo pumps.
• Lubriquip part number 540-800-041

• Model: Meter-Flo

• Application: In-Plant Machinery

• Compatible Material: Oil
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.5
• Fluid Outlet Size (mm): 12.7000
• Fluid Outlet Thread Type: NPT

• Maximum Flow Rate (ci/min): 117

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum SUS Grade (SUS): 3000

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

• Minimum Operating Temperature ( degree C): 10
• Minimum Operating Temperature ( degree F): 50

• Minimum SUS Grade (SUS): 300

• Power Type: Electric

GG 557814

METER-FLO PUMP, 9/14 CU IN/MIN CCW NPT

Graco 557814 Meter-Flo Electric Pump, 14 cu in/min (229 cc/min) @ 1,725 rpm, NPT Ports, CCW

With its solid pump housing, these rugged gear pumps are designed for dependable operation in high demand applications. The gear pump is available with a direct-coupled 1/2 horsepower motor capable of 1,725 rpm's with output volumes of 245 cubic inches per minute (4015 cc/min).

• Ideal for applications requiring continuous oil delivery up to 1,000 lubrication points
• Positive displacement helps assure constant delivery of proper volume.
• Match-ground heat-treated steel gears are enclosed in a rigid, cast-iron housing to assure dependability and long life.
• Adjustable pressure relief valve protects pump against overload conditions.
• Meter-flo pumps are available with a special coupling that allows easy replacement of older Meter-Flo pumps.
• Lubriquip part number 540-800-011

• Model: Meter-Flo

• Application: In-Plant Machinery

• Compatible Material: Oil
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.5
• Fluid Outlet Size (mm): 12.7000
• Fluid Outlet Thread Type: NPT

• Maximum Flow Rate (ci/min): 14

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum SUS Grade (SUS): 3000

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

• Minimum Operating Temperature ( degree C): 10
• Minimum Operating Temperature ( degree F): 50

• Minimum SUS Grade (SUS): 300

• Power Type: Electric

GG 557807

FILTER, 25 MICRON, 9-5/8" LG

Graco 557807 Replacement Filter Cartridge, 25-micron Ex-Lng, Lubriquip part 540-275-001, replaces part 540-275-000 and Trabon part 40275, Genuine Trabon replacement filter element for Lubriquip filter assemblies 183-000-080, 183-000-081, 183-000-120, 183-000-121, 183-000-210, 183-000-211

• 25 micron Replacement Filter Element
• 2-5/8 in (67 mm) OD x 9-5/8 in (92 mm) Extra Long Element

• For Use With: Cartridge Oil Filters

GG 557829

SWITCH, PRESS ADJ, 1000-4700 PSI

Graco 557829 Moisture-Resistant Single Control Pressure Switch, 4700 psi (324 bar)

Turns off your pump or controller and activates venting once the lube system reaches the desired pressure level.

• Easy to visually adjust line pressure and reset pressure to ensure your lube system has vented properly
• LED lights visually display pressure switch functions
• Modern 4-pin M12 micro-connector easily connects to the G3 and other controllers, 124595 4-pin M12 micro-connector sold separately
• Sends an alarm signal to alert either a high or low pressure condition
• Available for hydraulic pressures from 400 to 4700 psi (28 to 324 bar)
• 1/4 in NPT thread allows quick connection to injector systems
• Lubriquip part number 542-210-120

• Model: Trabon
• Adjustable: Adjustable

• Application: On-Road Vehicles, Off-Road Equipment

• Inlet Size (cm): 0.635
• Inlet Size (in): 0.25
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Maximum Operating Pressure (psi): 4700

• Power Connection Type: NEMA-4

GG 557818

METER-FLO PUMP, 26/40 CU IN/MIN CCW NPT

Graco 557818 Meter-Flo Electric Pump, 40 cu in/min (655 cc/min) @ 1,725 rpm, NPT Ports, CCW

With its solid pump housing, these rugged gear pumps are designed for dependable operation in high demand applications. The gear pump is available with a direct-coupled 1/2 horsepower motor capable of 1,725 rpm's with output volumes of 245 cubic inches per minute (4015 cc/min).

• Ideal for applications requiring continuous oil delivery up to 1,000 lubrication points
• Positive displacement helps assure constant delivery of proper volume.
• Match-ground heat-treated steel gears are enclosed in a rigid, cast-iron housing to assure dependability and long life.
• Adjustable pressure relief valve protects pump against overload conditions.
• Meter-flo pumps are available with a special coupling that allows easy replacement of older Meter-Flo pumps.
• Lubriquip part number 540-800-091

• Model: Meter-Flo

• Application: In-Plant Machinery

• Compatible Material: Oil
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.5
• Fluid Outlet Size (mm): 12.7000
• Fluid Outlet Thread Type: NPT

• Maximum Flow Rate (ci/min): 40

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum SUS Grade (SUS): 3000

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

• Minimum Operating Temperature ( degree C): 10
• Minimum Operating Temperature ( degree F): 50

• Minimum SUS Grade (SUS): 300

• Power Type: Electric

GG 557866

GAUGE, 3000 PSI 1/4NPT C/B LIQ

Graco 557866 Pressure Gauge, Back-Mounted, 0-3000 psi, 2 1/2 in. Dial Diameter

• Dial Diameter (cm): 6
• Dial Diameter (in): 2.5
• Dial Diameter (mm): 64

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

GG 557941

GG 557931

GREASE JOCKEY ELECTRIC VALVE, ASSY, SOLENOID, 3 WAY, 24 VDC

Graco 557931 3-Way Solenoid Valve Kit - 24 VDC

• 24 VDC replacement solenoid
• Lubriquip part number 550-250-265

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Air

• Material: Brass

• Maximum Voltage (V dc): 24

• Port Size (cm): 0.1191
• Port Size (in): 0.046875
• Port Size (mm): 1.1913

• Power Rating (W): 7

GG 557998

KIT, RELIEF VLV VIKING PUMP

Graco 557998 Meter-Flo Relief Valve Repair Kit

• Meter-Flo Relief Valve Repair Kit - 540-800-XX1 Models
• Lubriquip part number 560-001-920

• For Use With: Viking Pumps

• Includes: Poppet, Cap, Spring, Hardware

• Kit Type: Repair Kit

GG 558015

GG 558021

CABLE, CONN 6'

Graco 558021 Mini-Straight Connection Cable - 6 ft, 3-Pin

• 3-pin cable, straight connector, 6 feet (1.83 m)
• Lubriquip part number 570-999-080

• Amperage (A): 13

• For Use With: MSP Divider Valves, Proximity Switches, Air Oil Lubrication System

• IP Rating: IP68 NEMA 6P
• Jacket Material: PVC

GG 558022

CABLE, CONN 12'

Graco 558022 Mini-Straight Connection Cable - 12 ft, 3-Pin

• 3-pin cable, straight connector, 12 feet (3.66 m)
• Lubriquip part number 570-999-090

• For Use With: MSP Divider Valves, Proximity Switches, Air Oil Lubrication System

GG 558025

CABLE, CONN CABLE 4PN 24V

Graco 558025 Proximity Switch Connector Cable - 24 V, 12 ft, 4-Pin, Straight Connector, Polarity, PNP

• 4-pin cable, straight connector, polarity, PNP, 12 feet (3.66 m)
• Lubriquip part number 570-999-953

• For Use With: Proximity Switches

GG 558024

CABLE, 5 PIN W/ CONN

Graco 558024 Proximity Switch Connector Cable - 12 ft, 5-Pin

• 5-pin cable, straight connector, 12 feet (3.66 m)
• Lubriquip part number 570-999-170

• For Use With: Proximity Switches

GG 558188

GG 558190

GG 558189

NUT, BRASS 5/32 TUBE COMPR

Graco 558189 Thrif-T Luber Hardware - TLCN-00 - Compression Nut

• Thrif-T Luber Hardware - TLCN-00 - Compression Nut
• Lubriquip part number 435-390-070

• Inside Diameter (in): 0.3125
• Inside Diameter (mm): 7.9375

• Material: Brass

• Nut Type: Hex Nut

GG 558730

O-RING, -908 VITON

Graco 558730 O-Ring, Viton

• Lubriquip part number GOV-060-020

• For Use With: Husky 1050e Pump, SaniForce 1040e Pump

• Inside Diameter (cm): 1.6
• Inside Diameter (in): 0.644
• Inside Diameter (mm): 16.4

• Material: Viton

• Number of Pieces: 1

• Outside Diameter (cm): 2.1
• Outside Diameter (in): 0.818
• Outside Diameter (mm): 20.8

GG 558692

O-RING, -113 VITON-A 75 DURO

• Lubriquip part number 422-041-130
• Trabon part number 25613-V
• Manzel part number 22X4-113

• Inside Diameter (cm): 1.4
• Inside Diameter (in): 0.549
• Inside Diameter (mm): 13.9

• Material: Viton

• Number of Pieces: 1

• Outside Diameter (cm): 1.9
• Outside Diameter (in): 0.755
• Outside Diameter (mm): 19.2

GG 558906

COUPLER, 1/4, W/CHECK

Graco 558906 Mating Coupler/Coupling for grease fill stud on Trabon Reservoirs, 1/4 in. NPT female, with Check

• Mating Coupler for Trabon Grease Fill Stud
• Former part numbers: Lubriquip 506-322-000, Trabon 6322
• Mates to fill stud 557374
• Trabon part number 6322

• Series: Trabon

• Connection Type: Threaded

• End A Inlet Thread Gender: Female
• End A Inlet Thread Type: NPTF

• Finish/Coating: Cadium

• Inlet Size (in): 1/4-18

• Inlet Thread Gender: Female

• Material: Brass

• Maximum Working Pressure (bar): 21
• Maximum Working Pressure (kPa): 2100
• Maximum Working Pressure (MPa): 2.1
• Maximum Working Pressure (psi): 300

• Outlet Size (in): 1/4 inch diameter Quick Disconnect, mates to air chuck style grease fill stud used on Trabon grease reservoirs
• Outlet Thread Gender: None

GG 558927

BRACKET, MTG RTN FILTER

Graco 558927 Filter Mounting Bracket

• Filter Mounting Bracket
• Lubriquip part number 521-010-440

• Color: Gray

• Finish/Coating: Paint

• For Use With: Spin-On Filter

• Material: Steel

• Overall Height (cm): 12.5425
• Overall Height (in): 4.938
• Overall Height (mm): 125.4252
• Overall Length (cm): 6
• Overall Length (in): 2.5
• Overall Length (mm): 64
• Overall Width (cm): 6.985
• Overall Width (in): 2.75
• Overall Width (mm): 69.85

GG 558949

METER-FLO PUMP, 55/83 CU IN/MIN CW NPT

Graco 558949 Meter-Flo Electric Pump, 84 cu in/min (1377 cc/min) @ 1,725 rpm, NPT Ports, CW

With its solid pump housing, these rugged gear pumps are designed for dependable operation in high demand applications. The gear pump is available with a direct-coupled 1/2 horsepower motor capable of 1,725 rpm's with output volumes of 245 cubic inches per minute (4015 cc/min).

• Ideal for applications requiring continuous oil delivery up to 1,000 lubrication points
• Positive displacement helps assure constant delivery of proper volume.
• Match-ground heat-treated steel gears are enclosed in a rigid, cast-iron housing to assure dependability and long life.
• Adjustable pressure relief valve protects pump against overload conditions.
• Meter-flo pumps are available with a special coupling that allows easy replacement of older Meter-Flo pumps.
• Lubriquip part number 540-800-031

• Model: Meter-Flo

• Application: In-Plant Machinery

• Compatible Material: Oil
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.5
• Fluid Outlet Size (mm): 12.7000
• Fluid Outlet Thread Type: NPT

• Maximum Flow Rate (ci/min): 84

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum SUS Grade (SUS): 3000

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

• Minimum Operating Temperature ( degree C): 10
• Minimum Operating Temperature ( degree F): 50

• Minimum SUS Grade (SUS): 300

• Power Type: Electric

GG 560543

COUPLING, ANCHOR CROSS 1/8

Graco 560543 Cross Anchor Fitting, 1/8 in. NPSF

• Cross Anchor Fitting, 1/8 in. NPSF
• Lubriquip part number 509-189-000
• Trabon part number 9189

• Connection Type: Threaded

• Finish/Coating: Zinc

• For Use With: Hose

• Material: Steel

GG 560643

BLOCK, INLET SECTION, MJ

Graco 560643 Trabon MJ Divider Valve - Standard Inlet

• Standard Inlet (Must be ordered in multiples of five)
• NPSF
• Lubriquip part number 510-992-002

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment

• Inlet Size (cm): 0.3175
• Inlet Size (in): 1/8
• Inlet Size (mm): 3.175

• Inlet Thread Type: NPSF

GG 560620

BLOCK, INLET MACH MX

Graco 560620 Trabon MX Divider Valve - MX Inlet

• MX inlet
• Lubriquip part number 510-914-003

• Model: Trabon
• Series: MX

• Application: In-Plant Machinery

• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Type: NPT

GG 560645

BLOCK, END SECTION MJ

Graco 560645 Trabon MJ Divider Valve - Standard End Section

• Standard end section (Must be ordered in multiples of five)
• NPSF
• Lubriquip part number 510-994-002

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment

• Outlet Thread Type: NPSF

GG 560919

BLOCK, INLET, MSP/MHH NPSF

Graco 560919 Manzel MHH Divider Valve - Inlet - 1/4-18 NPSF

• Standard Inlet
• 1/4-18 NPSF (NPT)
• Lubriquip part number 527-001-800

• Model: Manzel
• Series: MHH

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPSF

GG 562502

MJ VALVE, BLOCK, STD SECTION, MJ-15S

Graco 562502 Trabon MJ Series-Flo Divider Valve - MJ-15S - 0.030 in cu (0.49 cm cu )

The Trabon MJ series features a compact and easily customizable design that can be tailor fit to meet a variety of specific lube requirements. Capable of handling grease grades up to NLGI #1.

• Space efficient - from 6 to 16 points from one block assembly
• Built-in outlet check valves ensure accurate lube delivery, every time
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 001-015-001

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 0.030

• Divider Valve Series: MJ

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 200

• Maximum NLGI Grade: #1

• Maximum Operating Temperature ( degree C): 93
• Maximum Operating Temperature ( degree F): 200

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (psi): 2000

• Minimum Working Pressure (psi): 200

• Number of Outlets: 1

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 561471

GG 562503

MJ VALVE, ASSY MJ 5T

Graco 562503 Trabon MJ Series-Flo Divider Valve - MJ-5T - 0.005 in cu (0.082 cm cu )

The Trabon MJ series features a compact and easily customizable design that can be tailor fit to meet a variety of specific lube requirements. Capable of handling grease grades up to NLGI #1.

• Space efficient - from 6 to 16 points from one block assembly
• Built-in outlet check valves ensure accurate lube delivery, every time
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 001-005-002

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 0.005

• Divider Valve Series: MJ

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 200

• Maximum NLGI Grade: #1

• Maximum Operating Temperature ( degree C): 93
• Maximum Operating Temperature ( degree F): 200

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (psi): 2000

• Minimum Working Pressure (psi): 200

• Number of Outlets: 2

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 562504

MJ VALVE, ASSY MJ 10T

Graco 562504 Trabon MJ Series-Flo Divider Valve - MJ-10T - 0.010 in cu (0.16 cm cu )

The Trabon MJ series features a compact and easily customizable design that can be tailor fit to meet a variety of specific lube requirements. Capable of handling grease grades up to NLGI #1.

• Space efficient - from 6 to 16 points from one block assembly
• Built-in outlet check valves ensure accurate lube delivery, every time
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 001-010-002

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 0.010

• Divider Valve Series: MJ

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 200

• Maximum NLGI Grade: #1

• Maximum Operating Temperature ( degree C): 93
• Maximum Operating Temperature ( degree F): 200

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (psi): 2000

• Minimum Working Pressure (psi): 200

• Number of Outlets: 2

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 562505

MJ VALVE, ASSY MJ 15T

Graco 562505 Trabon MJ Series-Flo Divider Valve - MJ-15T - 0.015 in cu (0.246 cm cu )

The Trabon MJ series features a compact and easily customizable design that can be tailor fit to meet a variety of specific lube requirements. Capable of handling grease grades up to NLGI #1.

• Space efficient - from 6 to 16 points from one block assembly
• Built-in outlet check valves ensure accurate lube delivery, every time
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 001-015-002

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 0.015

• Divider Valve Series: MJ

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 200

• Maximum NLGI Grade: #1

• Maximum Operating Temperature ( degree C): 93
• Maximum Operating Temperature ( degree F): 200

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (psi): 2000

• Minimum Working Pressure (psi): 200

• Number of Outlets: 2

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 562510

MJ VALVE, ASSY IND MJ 10T

Graco 562510 Trabon MJ Series-Flo Divider Valve with Right Hand Cycle Pin - MJ-10T - 0.010 in cu (0.16 cm cu )

The Trabon MJ series features a compact and easily customizable design that can be tailor fit to meet a variety of specific lube requirements. Capable of handling grease grades up to NLGI #1.

• Space efficient - from 6 to 16 points from one block assembly
• Built-in outlet check valves ensure accurate lube delivery, every time
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 001-010-602

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: Cycle Indicator

• Discharge Per Piston Stroke (in cu ): 0.010

• Divider Valve Series: MJ

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 60

• Maximum NLGI Grade: #1

• Maximum Operating Temperature ( degree C): 93
• Maximum Operating Temperature ( degree F): 200

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (psi): 2000

• Minimum Working Pressure (psi): 200

• Number of Outlets: 2

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 562511

MJ VALVE, ASSY IND MJ 15T

Graco 562511 Trabon MJ Series-Flo Divider Valve with Right Hand Cycle Pin - MJ-15T - 0.015 in cu (0.246 cm cu )

The Trabon MJ series features a compact and easily customizable design that can be tailor fit to meet a variety of specific lube requirements. Capable of handling grease grades up to NLGI #1.

• Space efficient - from 6 to 16 points from one block assembly
• Built-in outlet check valves ensure accurate lube delivery, every time
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 001-015-602

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: Cycle Indicator

• Discharge Per Piston Stroke (in cu ): 0.015

• Divider Valve Series: MJ

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 60

• Maximum NLGI Grade: #1

• Maximum Operating Temperature ( degree C): 93
• Maximum Operating Temperature ( degree F): 200

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (psi): 2000

• Minimum Working Pressure (psi): 200

• Number of Outlets: 2

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 562516

MX VALVE, ASSY 050S

Graco 562516 Trabon MX Divider Valve - MX-50S - 0.100 in cu (1.64 cm cu )

Greater output volumes for heavy service requirements make the Trabon MX Series ideal for steel and paper mill systems with its economical and compact design.

• Lubricates large bearings
• Delivers up to 0.3 cubic inches (4.92 cubic centimeters) per cycle and has a wide range of accessories to monitor critical lubrication points
• Durable design withstands harsh environments and operating conditions
• Can be easily accessorized with magnetic and electronic proximity switch cycle indicators to provide positive assurance of a successful lube event
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 004-050-001

• Model: Trabon
• Series: MX

• Application: In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 0.100

• Divider Valve Series: MX

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 200

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 93
• Maximum Operating Temperature ( degree F): 200

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (psi): 3000

• Minimum Working Pressure (psi): 200

• Number of Outlets: 1

• Outlet Size (cm): 0.635
• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 562517

MX VALVE, ASSY 050T

Graco 562517 Trabon MX Divider Valve - MX-50T - 0.050 in cu (0.82 cm cu )

Greater output volumes for heavy service requirements make the Trabon MX Series ideal for steel and paper mill systems with its economical and compact design.

• Lubricates large bearings
• Delivers up to 0.3 cubic inches (4.92 cubic centimeters) per cycle and has a wide range of accessories to monitor critical lubrication points
• Durable design withstands harsh environments and operating conditions
• Can be easily accessorized with magnetic and electronic proximity switch cycle indicators to provide positive assurance of a successful lube event
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 004-050-002

• Model: Trabon
• Series: MX

• Application: In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 0.050

• Divider Valve Series: MX

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 200

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 93
• Maximum Operating Temperature ( degree F): 200

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (psi): 3000

• Minimum Working Pressure (psi): 200

• Number of Outlets: 2

• Outlet Size (cm): 0.635
• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 562521

MX VALVE, ASSY 125S IND RH

Graco 562521 Trabon MX Divider Valve with Right Hand Cycle Pin Indicator - MX-125S - 0.250 in cu (4.10 cm cu )

Greater output volumes for heavy service requirements make the Trabon MX Series ideal for steel and paper mill systems with its economical and compact design.

• Lubricates large bearings
• Delivers up to 0.3 cubic inches (4.92 cubic centimeters) per cycle and has a wide range of accessories to monitor critical lubrication points
• Durable design withstands harsh environments and operating conditions
• Can be easily accessorized with magnetic and electronic proximity switch cycle indicators to provide positive assurance of a successful lube event
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 004-125-601

• Model: Trabon
• Series: MX

• Application: In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: Cycle Indicator

• Discharge Per Piston Stroke (in cu ): 0.250

• Divider Valve Series: MX

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 60

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 93
• Maximum Operating Temperature ( degree F): 200

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (psi): 3000

• Minimum Working Pressure (psi): 200

• Number of Outlets: 1

• Outlet Size (cm): 0.635
• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 562540

MX VALVE, ASSY 100S

Graco 562540 Trabon MX Divider Valve - MX-100S - 0.200 in cu (3.28 cm cu )

Greater output volumes for heavy service requirements make the Trabon MX Series ideal for steel and paper mill systems with its economical and compact design.

• Lubricates large bearings
• Delivers up to 0.3 cubic inches (4.92 cubic centimeters) per cycle and has a wide range of accessories to monitor critical lubrication points
• Durable design withstands harsh environments and operating conditions
• Can be easily accessorized with magnetic and electronic proximity switch cycle indicators to provide positive assurance of a successful lube event
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 004-100-001

• Model: Trabon
• Series: MX

• Application: In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 0.200

• Divider Valve Series: MX

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 200

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 93
• Maximum Operating Temperature ( degree F): 200

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (psi): 3000

• Minimum Working Pressure (psi): 200

• Number of Outlets: 1

• Outlet Size (cm): 0.635
• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 562573

MGO VALVE, ASSY MGO 600S SAE

Graco 562573 Trabon MGO Modular Divider Valve - MGO-600S - 1.200 in cu (19.7 cm cu )

While critical bearings are hard at work on your largest machine tools, Gracos line of centralized and automatic lubrication systems is delivering precise amounts of lubricant at frequent intervals to every lube point - even in hard to reach areas.

• Lubricates large bearings
• Delivers up to 1.2 cubic inches (19.7 cubic centimeters) per cycle and has a wide range of accessories to monitor critical lubrication points
• Largest output available with 22 outlets and 11 working sections
• TFE standard seals allow for maximum fluid compatibility and high temperature use
• Lubriquip part number 007-600-031

• Model: Trabon
• Series: MGO

• Application: In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 1.200

• Divider Valve Series: MGO

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 185

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 176

• Maximum Working Pressure (bar): 413.7
• Maximum Working Pressure (kg/cm 2): 421.8
• Maximum Working Pressure (kPa): 41370
• Maximum Working Pressure (psi): 6000

• Minimum Working Pressure (psi): 200

• Number of Outlets: 1

• Outlet Size (in): 7/8
• Outlet Thread Gender: Female
• Outlet Thread Type: SAE ORB

GG 562586

GG 562657

GG 562682

MHH VALVE, ASSY 18S

Graco 562682 Manzel MHH Modular Divider Valve .018 Single

Same capable design as the Trabon MSP Series, with even tighter and more exacting tolerances.

• Quick change valve sections can be removed from the base assembly without disturbing any lube lines - minimizing labor cost and maximizing your machine uptime
• Can be easily accessorized with magnetic and electronic proximity switch cycle indicators to provide positive assurance of a successful lube event
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 106-000-495

• Model: Manzel
• Series: MHH

• Application: In-Plant Machinery, Compressor Equipment

• Compatible Material: Oil, Grease

• Cycle Indicator: Cycle Pin

• Discharge Per Piston Stroke (in cu ): 0.018

• Divider Valve Series: MHH

• Inlet Thread Gender: Female
• Inlet Thread Type: NPS, SAE

• Material: Steel

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 517
• Maximum Working Pressure (kPa): 51700
• Maximum Working Pressure (psi): 7500

• Number of Outlets: 1

• Outlet Size (in): 1/8 - 27, 7/16 - 20
• Outlet Thread Gender: Female
• Outlet Thread Type: NPS, SAE

GG 562724

MSP VALVE, ASSY MSP 25T

Graco 562724 Trabon MSP Modular Divider Valve - MSP-25T - 0.025 in cu (0.41 cm cu )

The Trabon MSP Series sets the industry standard for quality, reliability, and ease of use features. It was the original modular-style series progressive divider valve and is still the best!

• Quick change valve sections can be removed from the base assembly without disturbing any lube lines - minimizing labor cost and maximizing your machine uptime
• Accessories such as magnetic and electronic proximity switch cycle indicators provide positive assurance of a successful lube event.
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 106-100-215

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 0.025

• Divider Valve Series: MSP

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 200

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 176
• Maximum Operating Temperature ( degree F): 350

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (psi): 3500

• Minimum Working Pressure (bar): 14

• Minimum Working Pressure (psi): 200

• Number of Outlets: 2

GG 562723

MSP VALVE, ASSY MSP 20T

Graco 562723 Trabon MSP Modular Divider Valve - MSP-20T - 0.020 in cu (0.33 cm cu )

The Trabon MSP Series sets the industry standard for quality, reliability, and ease of use features. It was the original modular-style series progressive divider valve and is still the best!

• Quick change valve sections can be removed from the base assembly without disturbing any lube lines - minimizing labor cost and maximizing your machine uptime
• Accessories such as magnetic and electronic proximity switch cycle indicators provide positive assurance of a successful lube event.
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 106-100-205

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 0.020

• Divider Valve Series: MSP

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 200

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 176
• Maximum Operating Temperature ( degree F): 350

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (psi): 3500

• Minimum Working Pressure (bar): 14

• Minimum Working Pressure (psi): 200

• Number of Outlets: 2

GG 277360

KIT, REPAIR, PUMP SEAL

Graco 277360 3 in. Piston Seal Repair Kit- UHMWPE

GG 277351

HOSE, CPLD, 3/8" X3', 4000WPR

Graco 277351 BlueMax II HP Airless Whip Hose, 3/8 in x 3 ft, 4000 psi

The BlueMax II HP Whip Hose provides more flexibility and increased operator control at the gun. This BlueMax II Whip Hose has a 3/8 inch diameter and is 3 feet long and rated for up to 4000 psi.

• Lighter Weight

  Over 10% lighter weight and increased hose flexibility improves under pressure

• Highest Safety Standards

  Conductive core meets the highest worldwide safety standards unlike competitive ground wire hose designs

• Minimal Hose Coil Memory

  BlueMax II Hose has superior flexibility and reduced coil memory providing ease of use during coiling and uncoiling

• Model: BlueMax II
• Series: Whip Hose

• Connection Type: Male x Female

• Hose Diameter (in): 3/8
• Hose Length (cm): 91
• Hose Length (ft): 3
• Hose Length (in): 36
• Hose Length (m): 0.9
• Hose Length (mm): 912

• Inside Diameter (cm): 0.9525
• Inside Diameter (in): 3/8
• Inside Diameter (mm): 9.525

• Material: Nylon

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (kPa): 27600
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 280560

METER,HELICAL GEAR W/IS SENSOR

Graco 280560 HG6000 Helical Gear Fluid Flow Meter, 6000 psi (410 bar) max, 190 - 22, 700 cc/min flow range

• Accuracy (%): +/- 0.25

GG 277362

KIT, REPAIR, PUMP SEAL

Graco 277362 3.5 in. Piston Seal Repair Kit- UHMWPE

GG 286109

RAC 5 TIP, SPRAY

Graco 286109 RAC 5 SwitchTip, 109

The Reverse-A-Clean (RAC) 109 RAC 5 SwitchTip is designed for narrower surfaces and thinner materials. The 109 SwitchTip has a 0.009 inch orifice and produces a 2 to 4 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 10.2
• Maximum Fan Width (in): 2
• Maximum Fan Width (mm): 102

• Maximum Flow Rate (GPM): 0.09
• Maximum Flow Rate (L/min): 0.34

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 2
• Minimum Fan Width (mm): 51

• Orifice Diameter (in): 0.009

• Pattern Size (in): 2 to 4
• Pattern Size (mm): 50.8 to 101.6

GG 286121

RAC 5 TIP, SPRAY

Graco 286121 RAC 5 SwitchTip, 121

The Reverse-A-Clean (RAC) 121 RAC 5 SwitchTip is designed for narrower surfaces. The 121 SwitchTip has a 0.021 inch orifice and produces a 2 to 4 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 10.2
• Maximum Fan Width (in): 2
• Maximum Fan Width (mm): 102

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 2
• Minimum Fan Width (mm): 51

• Orifice Diameter (in): 0.021

• Pattern Size (in): 2 to 4
• Pattern Size (mm): 50.8 to 101.6

GG 286207

RAC 5 TIP, SPRAY

Graco 286207 RAC 5 SwitchTip, 207

The Reverse-A-Clean (RAC) 207 RAC 5 SwitchTip is designed for narrower surfaces and thinner materials. The 207 SwitchTip has a 0.007 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Clear Coating, Lacquer, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 15.2
  • Maximum Fan Width (in): 4
  • Maximum Fan Width (mm): 152
  • Maximum Flow Rate (GPM): 0.05
  • Maximum Flow Rate (L/min): 0.19
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 4
  • Minimum Fan Width (mm): 102
  • Orifice Diameter (in): 0.007

GG 279037

PUMP, FTB100, 1:1, 200L DRUM, METL

Graco 279037 Fast-Ball 100 55 Gallon Drum, Universal Pump, Steel Tube

Application:

• In-line design with fewer parts for less pump wear
• Double-acting pump provides reliable fluid flow
• Differential air motor ensures smooth pumping

• Model: Fast-Ball
• Series: 100

• Air Inlet Size (in): 1/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Compatible Material: ATF, Gear Lube, Oil

• Cycles Per Gallon: 31

• Fluid Inlet Size (in): 1
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 0.75
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Maximum Air Inlet Pressure (psi): 150

• Maximum Continuous Cycle Rate (CPM): 170

• Maximum Working Pressure (psi): 150

• Power Type: Pneumatic

• Pump Ratio: 1:1

GG 280545

GG 277869

CONTROL BOX, PROMIX 2KS EASYKEY REPL.

GG 277358

KIT, REPAIR, PUMP SEAL

Graco 277358 4 in. Piston Seal Repair Kit- UHMWPE

GG 286211

RAC 5 TIP, SPRAY

Graco 286211 RAC 5 SwitchTip, 211

The Reverse-A-Clean (RAC) 211 RAC 5 SwitchTip is designed for narrower surfaces and thin materials. The 211 SwitchTip has a 0.011 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Clear Coating, Lacquer, Oil-Based Stain

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.12
• Maximum Flow Rate (L/min): 0.45

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.011

GG 286111

RAC 5 TIP, SPRAY

Graco 286111 RAC 5 SwitchTip, 111

The Reverse-A-Clean (RAC) 111 RAC 5 SwitchTip is designed for narrower surfaces and thin materials. The 111 SwitchTip has a 0.011 inch orifice and produces a 2 to 4 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 10.2
• Maximum Fan Width (in): 2
• Maximum Fan Width (mm): 102

• Maximum Flow Rate (GPM): 0.12
• Maximum Flow Rate (L/min): 0.45

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 2
• Minimum Fan Width (mm): 51

• Orifice Diameter (in): 0.011

• Pattern Size (in): 2 to 4
• Pattern Size (mm): 50.8 to 101.6

GG 286209

RAC 5 TIP, SPRAY

Graco 286209 RAC 5 SwitchTip, 209

The Reverse-A-Clean (RAC) 209 RAC 5 SwitchTip is designed for narrower surfaces and thinner materials. The 209 SwitchTip has a 0.009 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Clear Coating, Lacquer, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 15.2
  • Maximum Fan Width (in): 4
  • Maximum Fan Width (mm): 152
  • Maximum Flow Rate (GPM): 0.09
  • Maximum Flow Rate (L/min): 0.34
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 4
  • Minimum Fan Width (mm): 102
  • Orifice Diameter (in): 0.009

GG 286113

RAC 5 TIP, SPRAY

Graco 286113 RAC 5 SwitchTip, 113

The Reverse-A-Clean (RAC) 113 RAC 5 SwitchTip is designed for narrower surfaces. The 113 SwitchTip has a 0.013 inch orifice and produces a 2 to 4 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 10.2
• Maximum Fan Width (in): 2
• Maximum Fan Width (mm): 102

• Maximum Flow Rate (GPM): 0.18
• Maximum Flow Rate (L/min): 0.68

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 2
• Minimum Fan Width (mm): 51

• Orifice Diameter (in): 0.013

• Pattern Size (in): 2 to 4
• Pattern Size (mm): 50.8 to 101.6

GG 286213

RAC 5 TIP, SPRAY

Graco 286213 RAC 5 SwitchTip, 213

The Reverse-A-Clean (RAC) 213 RAC 5 SwitchTip is designed for narrower surfaces. The 213 SwitchTip has a 0.013 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 15.2
  • Maximum Fan Width (in): 4
  • Maximum Fan Width (mm): 152
  • Maximum Flow Rate (GPM): 0.18
  • Maximum Flow Rate (L/min): 0.68
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 4
  • Minimum Fan Width (mm): 102
  • Orifice Diameter (in): 0.013

GG 279022

KING SPRAYER, CONTRACTOR, 70:1, B150

Graco 279022 Contractor King 70:1 Air Powered Airless Sprayer, Big 150 (2-F Gun)

Introducing the newest member of the King family The Contractor King 70:1. Designed around single-person mobility and high performance, this affordable line of air-powered sprayers is the perfect addition to every Contractors fleet.

• Proven King quality with Anti-icing technology

  Field-proven design virtually eliminates icing to keep you spraying

  Durable aluminum, steel and composite construction for years of service

  Delivers superior finish with no pulsation, even with multiple guns

  Simple design for easy serviceability

  Oversized porting for maximum air flow

• Easy to move and transport

  Nearly 38 kg lighter than comparable models for easy, one-person handling

  Chrome-plated, welded-steel frame for years of service

  Integrated lifting points for easy positioning on any jobsite

  Flat proof tires resist jobsite debris for maximum convenience

• Simple maintenance with proven design and performance

  QuickChange Endurance pump, for quick and for easy on-the-job pump removal and maintenance

  Chromex Rod and Stainless Steel cylinder for maximum life and performance

  Fleet-friendly design uses the same wear parts as your other King sprayers

  Xtreme Seal UHMWPE & Leather packings for ultimate durability with most materials

  QuickAccess intake valve for easy access to lower ball check

• Big 150 package includes:

  2-Finger Silver Plus HP Gun

  XHD 417 and XHD 519 SwitchTips with XHD guard

  1/4x 1.8m Extreme Duty Airless whip hose

  3x 3/8x 15m Extreme Duty Airless hose (45m in total)

• Big 150 Package Includes:

  Silver Plus Gun OR Silver Plus HP Gun (2 Finger Model)

  XHD 417, XHD 519 SwitchTips and Guard

  1/4 in x 6 ft Extreme Duty Airless Whip Hose

  3 - 3/8 in x 50 ft Extreme Duty Airless Hose (150 ft total)
