GRACO INC. S10595

GG 253545

KIT,REPAIR,THROAT SEAL,HOTMLT

KIT INCLUDES: NUT, PACKING [QTY. 1], PACKING, U-CUP [QTY. 2], WASHER, SEAL, BACK-UP [QTY. 1], PACKING, O-RING [QTY. 1], LUBRICANT, TUBE, 1 OZ [QTY. 1], WASHER, ROD, SCRAPER [QTY. 1], WASHER, SCRAPER, GREASE ZONE [QTY. 1], LUBRICANT, SYNTHETIC, GREASE, 3 OZ [QTY. 1]

GG 253597

PUMP, DISP, RECIP MAX WPR 1000PS

Graco 253597 Dura-Flo 1000 cc Lower, Carbon Steel, UHMWPE/Leather Packings

GG 253626

KIT, DIAPHRAGM, PTFE-EPDM, 1040

Graco 253626 PTFE/EPDM Overmold Diaphragm Kit for 1-inch Pump

GG 253628

GG 253692

FRAME, ACCY, STAND, PUMP

Graco 253692 Floor Stand for NXT, E-Flo DC and Viscount Motors (750-2000 cc)

GG 253741

HOUSING,VALVE,SEAT

GG 253742

HOUSING,VALVE, SEAT

GG 253743

HOUSING, VALVE, SEAT, ASSY

GG 253744

KIT, REPAIR, PACKING

Graco 253744 UHMWPE and Leather Packings Repair Kit, for Dura-Flo 1800 (standard for 249992, L430SM, L430CM)

KIT INCLUDES: GLAND, PACKING, MALE [QTY. 1], GLAND, PACKING, FEMALE [QTY. 1], PACKING, VEE [QTY. 3], GLAND, PACKING, FEMALE [QTY. 1], PACKING, VEE [QTY. 3], PACKING, VEE, UHMWPE, SUBMICRON [QTY. 2], GLAND, PACKING, MALE [QTY. 1], PACKING, VEE, LEATHER [QTY. 4 ], PACKING, O-RING [QTY. 1], SEAL, ACETAL [QTY. 2], PACKING, O-RING [QTY. 1]

GG 253745

KIT, REPAIR, PACKINGS

Graco 253745 UHMWPE and Leather Packings Repair Kit, for Dura-Flo 2400 (standard for 249991, L580SM)

KIT INCLUDES: PACKING, VEE [QTY. 3], GLAND, PACKING, MALE [QTY. 1], GLAND, PACKING, FEMALE [QTY. 1], PACKING, VEE [QTY. 3], GLAND, PACKING, MALE [QTY. 1], GLAND, PACKING, FEMALE [QTY. 1], PACKING, VEE, UHMWPE, [QTY. 2], PACKING, VEE, LEATHER [QTY. 4 ], PACKING, O-RING [QTY. 1], SEAL, ACETAL [QTY. 2], PACKING, O-RING [QTY. 1]

GG 255057

GG 255058

GG 255060

KIT, DIAPHRAGM-F2 PT

Graco 255060 PTFE Diaphragm Kit for 1.5-inch Pump

GG 255061

KIT, REPAIR, AIR VALVE, SST

Graco 255061 Air Valve Repair Kit

GG 255082

GG 255122

GG 255143

KIT, BRACKET, MOUNTING

Graco 255143 NXT Wall Mounting Kit

GG 255148

GG 255149

GG 255150

GG 255160

KIT, REPAIR,SEAT/NEEDLE

Graco 255160 Needle/ Seat Repair Kit for G40 Air Assisted Spray Gun

GG 255179

MD2 VALVE,DISPENSE,1:1,SOFT SEATS

Graco 255179 1:1 Ratio Soft Seat MD2 Valve

Accurately dispenses and mixes two-component sealants and adhesives.

• Minimizes maintenance time and costs while maximizing dispense time
• Designed with fewer parts and is easy to clean
• Streamlines maintenance and service Complete modular design adapts to different installation needs
• No unique tools required

• Model: MD2

• Air Inlet Size (in): 1/8
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Thermal Management, Molding

• Compatible Material: Sealants, Adhesives

GG 255180

MD2 VALVE,DISPENSE,1:1 HARD SEATS

Graco 255180 1:1 Ratio Hard Seat MD2 Valve

Accurately dispenses and mixes two-component sealants and adhesives.

• Minimizes maintenance time and costs while maximizing dispense time
• Designed with fewer parts and is easy to clean
• Streamlines maintenance and service Complete modular design adapts to different installation needs
• No unique tools required

• Model: MD2

• Air Inlet Size (in): 1/8
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Thermal Management, Molding

GG 255182

MD2 VALVE,DISPENSE,10:1 HARD SEATS

Graco 255182 10:1 Ratio Hard Seat MD2 Valve

Accurately dispenses and mixes two-component sealants and adhesives.

• Minimizes maintenance time and costs while maximizing dispense time
• Designed with fewer parts and is easy to clean
• Streamlines maintenance and service Complete modular design adapts to different installation needs
• No unique tools required

• Model: MD2

• Air Inlet Size (in): 1/8
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Thermal Management, Molding

GG 255194

GG 255197

GG 255204

KIT, REPAIR, PUMP

Graco 255204 210ES Pump Repair Kit

All packings should be replaced at one time to keep wear even. For use with Graco models 190ES, 210ES or other Graco 200 series sprayers. Kit includes all components to replace the packing set for the pump

• All packings should be replaced at one time to keep wear even
• For use with Graco models 190ES, 210ES or other Graco 200 series sprayers
• Keep a spare kit on hand to minimize sprayer downtime

• For Use With: Pro190ES Cart, Pro190ES Stand, Pro210ES Cart, Pro210ES Stand, Pro230ES Stand, Pro230ES Cart, Pro270ES Stand, Pro270ES Cart, Pro270GS

GG 255208

HANDLE, 2K DISP. VALVE, ELEC.

Graco 255208 MD2 Valve Electric Switch Handle

Convert any MD2 valve to a hand held valve with an internal normally open switch

GG 255216

GG 255249

LEVER, 2K DISPENSE VALVE

Graco 255249 2K Dispense Valve Lever

• Model: PR70

• For Use With: MD2 Valve Handle

• Product Type: Actuated Lever

GG 255277

LDP5 VALVE, METERED, FLEX EXT

Graco 255277 LDP5 Electronic Preset Meter - Flexible Extension - 1/2 in. (13 mm) Inlet - Trigger Guard and Swivel Cover Not Included - NPT

Gracos LDP5 meters are perfect for lower-volume service application in small service shops, fast lube centers and automotive dealerships. These meters are capable of metering petroleum, synthetic based oil and anti-freeze up to 5 gpm (19 lpm).

• Easy to read LCD screen keeps dispenses precise.
• Inlet 1/2 in. NPT with swivel.
• Rugged meter body is impact resistant for long life.
• Preset meter automatically shuts-off flow when preset quantity has been dispensed.
• 5 year warranty. See manufacturers website for details.

• Model: LDP5

• Approvals: CE

• Compatible Material: Oil, Antifreeze

• Dispense Type: Preset

• Display Type: Electronic

• Extension Type: Flexible

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• Maximum Operating Temperature ( degree C): 49
• Maximum Operating Temperature ( degree F): 120

• Maximum Storage Temperature ( degree C): 49
• Maximum Storage Temperature ( degree F): 120

• Maximum Working Pressure (bar): 69
• Maximum Working Pressure (kPa): 6900
• Maximum Working Pressure (MPa): 6.9
• Maximum Working Pressure (psi): 1000
• Meter Accuracy (%): plus/minus 00.5
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 1.36
• Metering Gun Weight (lb): 3

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Nozzle Type: Automatic

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Type: NPT

• Overall Height (cm): 8.3
• Overall Height (in): 3.25
• Overall Height (mm): 83
• Overall Length (cm): 28
• Overall Length (in): 11
• Overall Length (mm): 280
• Overall Width (cm): 8.3
• Overall Width (in): 3.25
• Overall Width (mm): 83

• Recommended Environment: Indoor

GG 255280

GG 255285

GG 255281

GG 255308

GG 255305

GG 255513

KIT,COMPLETE SEAL, L250CS

KIT INCLUDES: PACKING, VEE [QTY. 3], PACKING, VEE [QTY. 2], PACKING, O-RING [QTY. 2], PACKING, UHMWPE, CM1000 [QTY. 2], GLAND, MALE CM1000 FOOT VALVE [QTY. 1], GLAND, FEMALE CM1000 FOOT VALVE [QTY. 1], BEARING, PISTON GUIDE CM250 [QTY. 1], PACKING, PTFE 250 [QTY. 2], PACKING, O-RING [QTY. 1], GLAND, PACKING, FEMALE [QTY. 1], GLAND, PACKING MALE [QTY. 1], SEAL, PISTON [QTY. 1], WIPER [QTY. 1], SEAL, (8, 10 CM) [QTY. 1]

GG 255470

GG 255477

GG 255510

KIT, COMPLETE SEAL, L200CM

KIT INCLUDES: PACKING, O-RING [QTY. 1], PACKING, VEE [QTY. 2], PACKING, O-RING [QTY. 2], PACKING, U-CUP, CM200 [QTY. 1], SEAL, CM200 WETCUP COVER [QTY. 1], WIPER, CM200 WETCUP COVER [QTY. 1], SPACER, U-CUP, CM200 - CM250 [QTY. 1], BEARING, PISTON GUIDE CM200 [QTY. 1], PACKING, O-RING [QTY. 1], GLAND, PACKING FEMALE [QTY. 1], GLAND, PACKING MALE [QTY. 1], PACKING, VEE [QTY. 2], SEAL, PISTON [QTY. 1], SEAL, (8, 10 CM) [QTY. 1], SEAL, VALVE [QTY. 1], SPACER, U-CUP BEARING, CM200 [QTY. 1]

GG 255511

GG 255517

KIT,COMPLETE SEAL, L500CS

KIT INCLUDES: PACKING, O-RING [QTY. 1], PACKING, O-RING [QTY. 1], PACKING, VEE [QTY. 2], PACKING, VEE [QTY. 3], PACKING, VEE [QTY. 2], PACKING, VEE, PTFE [QTY. 2], BEARING, PISTON GUIDE CM500 [QTY. 1], SEAL, ACETAL [QTY. 3], GLAND, PACKING FEMALE [QTY. 1], GLAND, PACKING, FEMALE [QTY. 1], GLAND, PACKINGMALE [QTY. 1], GLAND, PACKING, MALE [QTY. 1], SEAL, PISTON [QTY. 1], SEAL, VALVE [QTY. 1]

GG 255415

GG 255461

GG 255446

MD2 VALVE, ASSY, 10:1, HS, GUN, ELEC

Graco 255446 10:1 Wide Ratio, Hard Seat, Electric Actuated, Non-adjustable Snuff-back, Manual Handle

Manual gun option for mixing dispense (MD) valve for 2 component materials supports minimizing maintenance while maximizing production.

• Wide ratio valve with center injection tip works well when the low volume material has a much lower viscosity than the high volume material. Frequent cleaning intervals may be required to maintain the tip.
• Carbide hard seats and hardened needles are good for abrasive material and stall against pressure applications.
• Hand held valve with electric switch signals the controller to open and close the ports on the MD2 valve. The process uses a remote four-way air control (not included, must be ordered separately).
• Snuff-back control prevents dripping as it brings material back into the valve until next dispense.
• Hand held electric handle eases manual dispense.

• Model: Two Component Mixing Dispense Valve
• Series: MD2

• Air Inlet Size (in): 1/8
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Thermal Management, Molding

• Compatible Material: 2K Sealants, Adhesives

• Component Type: Plural-Component

• Fluid Inlet Size (in): 9/16-18
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: UNF

• Fluid Outlet Size (in): 7/8-9
• Fluid Outlet Thread Gender: Male
• Fluid Outlet Thread Type: UNC

• Gun Activation: Manual

• Includes: 2K Dispense Handle, 10:1 Hard Seat Dispense Valve, 10:1 Ratio Check Kit, 10:1 Night Cap, ASM Aid Tool
• Inlet Size (in): 9/16-18

• Maximum Viscosity (cP): 1000000

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

• Mount Hole Thread Gender: Female
• Mount Hole Thread Type: Metric

GG 255328

GG 255508

KIT, CMPL. SEAL, L100CM

Graco 255508 100 cc Check-Mate Carbon Steel MaxLife Displacement Pump Complete Seal Kit

KIT INCLUDES: PACKING, O-RING [QTY. 1], PACKING, U-CUP, CM100 [QTY. 1], SPACER, U-CUP, CM100 [QTY. 1], PACKING, O-RING, PTFE [QTY. 2], PACKING, O-RING, PTFE [QTY. 1], PACKING, LEATHER, CM100 [QTY. 2], PACKING, UHMWPE, CM450 [QTY. 2], SEAL, CM100 WETCUP COVER [QTY. 1], WIPER, CM100 WETCUP COVER [QTY. 1], GLAND, MALE CM450 FOOT VALVE [QTY. 1], GLAND, FEMALE CM450 FOOT VALVE [QTY. 1], BEARING, PISTON GUIDE CM100 [QTY. 1], SEAL, PISTON (4.5 CM) [QTY. 1], SEAL, VALVE [QTY. 1], SEAL, [QTY. 1], PACKING, O-RING, #233 [QTY. 1], SPACER, U-CUP BEARING, CM100 [QTY. 1], RING, RETAINING [QTY. 1]

GG 255442

MD2 VALVE,ASSY,1:1,HS,GUN,AIR

Graco 255442 1:1 Ratio Hard Seat Air-Actuated Gun Trigger

Accurately dispenses and mixes two-component sealants and adhesives.

• Model: MD2

• Air Inlet Size (in): 1/8
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Thermal Management, Molding

GG 255530

GG 255468

KIT,ACC.,LIGHT TOWER,TC RAM

KIT INCLUDES: LIGHT, TOWER, AMBIENT RAM, M12 [QTY. 1], SUPPRESSOR, BOX SNAP, FERRITE [QTY. 1]

GG 255338

GG 255523

KIT,THROAT, L100CS

KIT INCLUDES: PACKING, O-RING [QTY. 1], PACKING, VEE [QTY. 3], PACKING, VEE, PTFE [QTY. 2], GLAND, PACKING FEMALE [QTY. 1], GLAND, PACKING MALE [QTY. 1]

GG 255552

KIT, PISTON, L200 (ALL)

Graco 255552 Piston Seal Metal and Soft Kit- 200cc Lowers

KIT INCLUDES: PACKING, O-RING [QTY. 2], BEARING, PISTON GUIDE CM200 [QTY. 1], SEAT, PISTON, SST [QTY. 1], SEAL, PISTON [QTY. 1], SEAT, PISTON [QTY. 1], SEAL, (8, 10 CM) [QTY. 1]

GG 255467

GG 255539

GG 255518

KIT, CMPL. SEAL, L500CM

Graco 255518 500 cc Check-Mate Carbon Steel MaxLife Displacement Pump Complete Seal Kit

KIT INCLUDES: PACKING, O-RING [QTY. 1], PACKING, O-RING [QTY. 1], PACKING, O-RING [QTY. 1], PACKING, VEE [QTY. 2], PACKING, U-CUP, CM500 [QTY. 1], SEAL, CM500 WETCUP COVER [QTY. 1], WIPER, CM500 WETCUP COVER [QTY. 1], SPACER, U-CUP, CM500 [QTY. 1], BEARING, PISTON GUIDE CM500 [QTY. 1], SEAL, ACETAL [QTY. 3], GLAND, PACKING FEMALE [QTY. 1], GLAND, PACKINGMALE [QTY. 1], PACKING, VEE [QTY. 2], SEAL, PISTON [QTY. 1], SEAL, VALVE [QTY. 1], SPACER, U-CUP BEARING, CM500 [QTY. 1]

GG 255547

GG 255512

GG 255557

KIT, INTAKE, L100CS

KIT INCLUDES: PACKING, UHMWPE, CM450 [QTY. 2], GLAND, MALE CM450 FOOT VALVE [QTY. 1], GLAND, FEMALE CM450 FOOT VALVE [QTY. 1], NUT, PACKING, CM100 [QTY. 1], VALVE, INTAKE, CM100 [QTY. 1], PACKING, PFTE 100 [QTY. 2], SEAL, VALVE [QTY. 1], SEAT, INTAKE (6 CM) [QTY. 1], SEAL, [QTY. 1]

GG 255561

KIT, INTAKE, L250CS

Graco 255561 Intake Valve Seal Metal and Soft Kit- 250 CS Lowers

KIT INCLUDES: PACKING, UHMWPE, CM1000 [QTY. 2], GLAND, MALE CM1000 FOOT VALVE [QTY. 1], GLAND, FEMALE CM1000 FOOT VALVE [QTY. 1], NUT, PACKING [QTY. 1], PACKING, PTFE 250 [QTY. 2], SEAT, VALVE [QTY. 1], WIPER [QTY. 1], SEAL, (8, 10 CM) [QTY. 1], VALVE, INTAKE [QTY. 1]

• Compatible Material: Motor Oil, Gear Oil, Automatic Transmission Fluid, Oil

GG 255559

KIT, INTAKE, L200CS

Graco 255559 Intake Valve Seal Metal and Soft Kit- 200 CS Lowers

KIT INCLUDES: PACKING, VEE [QTY. 2], PACKING, VEE [QTY. 2], GLAND, PACKING FEMALE [QTY. 1], GLAND, PACKING MALE [QTY. 1], SEAT, VALVE [QTY. 1], SEAL, (8, 10 CM) [QTY. 1], VALVE, INTAKE [QTY. 1], SEAL, VALVE [QTY. 1], NUT, PACKING [QTY. 1]

GG 255570

GG 255569

KIT, DISP ROD, L100CS

KIT INCLUDES: PACKING, O-RING, PTFE [QTY. 2], ROD, PISTON 100 [QTY. 1], SEAL, [QTY. 1]

GG 255571

KIT, DISP ROD, L200CS/L200SS

KIT INCLUDES: PACKING, O-RING [QTY. 2], ROD, PISTON 200 [QTY. 1], SEAL, (8, 10 CM) [QTY. 1]

GG 255573

KIT, DISP ROD, L250CS/L250SS

Graco 255573 Displacement Rod Kit- 250 CS and 250 SS Lowers

KIT INCLUDES: PACKING, O-RING [QTY. 2], ROD, PISTON 250 [QTY. 1], SEAL, (8, 10 CM) [QTY. 1]

GG 255575

GG 255579

GG 255582

GG 255588

GG 255592

GG 255593

KIT, CYLINDER, L200CS/L200SS

KIT INCLUDES: PACKING, O-RING [QTY. 2], BEARING, PISTON GUIDE CM200 [QTY. 1], CYLINDER, CM 200 SEVERE-DUTY [QTY. 1], SEAL, PISTON [QTY. 1], SEAL, (8, 10 CM) [QTY. 1]

• Compatible Material: Motor Oil, Gear Oil, Automatic Transmission Fluid, Oil

GG 255601

GG 255607

GG 255625

GG 255392

GG 255648

RAM, 3" WITH AIR CONTROLS

GG 255650

KIT, AIR CONTROL, RAM PKG

Graco 255650 Air Controls RAM Package

KIT INCLUDES: CONTROL, AIR [QTY. 1], LABEL, VALVE, SHUTOFF, AIRCONTROL [QTY. 1]

• Model: Check-Mate

GG 255651

KIT, REG, AIR MOTOR, RAM PKG

KIT INCLUDES: REGULATOR, MODULAR, 3/4 NPT [QTY. 1], O-RING, [QTY. 1], SCREW, CAP, SOCKET HEAD [QTY. 2]

GG 255662

KIT, PLATEN W/PTFE, 55 GL, EPDM

KIT INCLUDES: PLATE, WIPER 55GAL EPDM W/ PTFE [QTY. 1], KIT INCLUDES: PLATE, WIPER 55GAL EPDM [QTY. 1],

GG 255663

KIT, PLATEN, 55 GL, EPDM

KIT INCLUDES: PLATE, WIPER 55GAL EPDM [QTY. 1], KIT INCLUDES: PLATE, WIPER 55GAL NEOPRENE [QTY. 1],

GG 255675

KIT,PNEUMATIC X-OVER,3

KIT INCLUDES: FITTING, TEE, STREET [QTY. 2], FITTING, NIPPLE, HEX [QTY. 2], VALVE, PNEUMATIC, 3-WAY, N.C. [QTY. 2], VALVE, BALL, VENTED, .750 [QTY. 2], TUBING, NYLON, ROUND [QTY. 0.5 ], BUSHING, REDUCING [QTY. 4 ], FITTING, TUBE, QD [QTY. 2], FITTING, TUBE, QD ( 90 DEG SWIVEL) [QTY. 2], FITTING, TUBE, MALE (1/4 NPT) [QTY. 2], BRACKET, CORSSOVER, PAINTED 3 in. [QTY. 2], BRACKET, LIMIT VALVE [QTY. 2], WASHER, PLAIN [QTY. 4 ], SCREW, CAP, SCH [QTY. 4 ], WASHER, LOCK, #10 [QTY. 6 ], NUT, HEX MSCR [QTY. 4 ], VALVE, LIMIT, AIR [QTY. 2], WASHER, FLAT [QTY. 4 ], SCREW, CAP, SOCKET HD [QTY. 4 ], WASHER, LOCK, SPRING [QTY. 4 ], NUT, HEX MSCR [QTY. 4 ], WASHER, LOCK [QTY. 6 ], SCREW, CAP, SOCKET HEAD [QTY. 6 ], PLATE, MOUNTING, 4-WAY VALVE [QTY. 1], VALVE, AIR, REMOTE, 4 WAY [QTY. 1], SCREW, SHC, 10-24X1.125, S [QTY. 2],

GG 255687

KIT, REPAIR, RAM PISTON, 3"

KIT INCLUDES: RETAINER, RETAINING RING 1.88 BORE [QTY. 2], SPRING, COMPRESSION [QTY. 2], RING, RETAINING, INTERNAL [QTY. 2], PACKING, O-RING, BUNA-N [QTY. 4 ], PACKING, O-RING [QTY. 2], BEARING, RAM END CAP [QTY. 2], NUT, FULL HEX [QTY. 2], WASHER, SPRING LOCK [QTY. 2], PACKING, O-RING [QTY. 2], LUBRICANT, TUBE, 1 OZ [QTY. 1]

GG 255688

RAM,6.5" , WITH AIR CONTROLS

GG 255719

GG 255720

GG 255727

GG 255765

BOARD, CIRCUIT, PROMIX PLUS CONTROL

Graco 255765 Fluid Station Control Board for ProMix 2KS Plural Component Proportioner

GG 255581

GG 255767

BOARD, ASSY, PROMIX PLUS EASYKEY

Graco 255767 EasyKey Display Board for ProControl 1KS

GG 255854

GG 255857

GG 255858

GG 255884

GG 255616

GG 255901

MD2 VALVE, DISPENSE, 1:1, ELITE, SNUFF

Graco 255901 MD2 Valve, 1:1 Ratio, Elite Hard Seat, Non-adjustable Snuff-back

Mixing dispense (MD) valve for 2 component materials minimizes maintenance while maximizing production.

• 1:1 ratio nose handles a wide range of material.
• Hard seats with Elite construction withstand highly abrasive material at least 10 times longer than standard construction. (Data verified in Graco test environment.)
• Snuff-back control prevents dripping as it brings material back into the valve until next dispense.
• No unique tools are required for maintenance or repair.
• Grease isolation chamber protects moisture sensitive materials and has accessible grease fittings for easy maintenance
• No unique tools required

• Model: Two Component Mixing Dispense Valve
• Series: MD2

• Air Inlet Size (in): 1/8
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Thermal Management, Molding

• Compatible Material: Sealants, Adhesives

• Component Type: Plural-Component

• Fluid Inlet Size (cm): 1.42875
• Fluid Inlet Size (in): 9/16
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: UNF

• Fluid Outlet Size (in): 7/8
• Fluid Outlet Thread Type: UNC

• Gun Activation: Automatic

• Includes: Dispense Valve, 1:1 Ratio Night Cap, 1:1 Ratio Check Adapter, ASM Aid Tool

• Maximum Viscosity (cP): 1000000

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kg/cm 2): 210.9
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (psi): 3000

• Mount Hole Thread Gender: Female
• Mount Hole Thread Type: Metric

GG 255902

MD2 VALVE, DISPENSE, 10:1, ELITE, SNUFF

Graco 255902 MD2 Valve, 10:1 Ratio, Elite Hard Seat, Non-adjustable Snuff-back

Mixing dispense (MD) valve for 2 component materials minimizes maintenance while maximizing production.

• 10:1 ratio nose handles a wide range of material.
• Hard seats with Elite construction withstand highly abrasive material at least 10 times longer than standard construction. (Data verified in Graco test environment.)
• Snuff-back control prevents dripping as it brings material back into the valve until next dispense.
• Independent air cylinder improves mean time to repair (MTTR).
• No unique tools are required for maintenance or repair.
• No unique tools required

• Model: Two Component Mixing Dispense Valve
• Series: MD2

• Air Inlet Size (in): 1/8
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Thermal Management, Molding

• Compatible Material: Sealants, Adhesives

• Component Type: Plural-Component

• Fluid Inlet Size (cm): 1.42875
• Fluid Inlet Size (in): 9/16
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: UNF

• Fluid Outlet Size (in): 7/8
• Fluid Outlet Thread Type: UNC

• Gun Activation: Automatic

• Includes: Dispense Valve, 10:1 Ratio Night Cap, 10:1 Ratio Check Adapter, ASM Aid Tool

• Maximum Viscosity (cP): 1000000

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kg/cm 2): 210.9
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (psi): 3000

• Mount Hole Thread Gender: Female
• Mount Hole Thread Type: Metric

GG 255664

KIT, PLATEN, 55 GL, NEOPRENE

KIT INCLUDES: PLATE, WIPER 55GAL NEOPRENE [QTY. 1], KIT INCLUDES: FITTING, TEE, STREET [QTY. 2], FITTING, NIPPLE, HEX [QTY. 2], VALVE, PNEUMATIC, 3-WAY, N.C. [QTY. 2], VALVE, BALL, VENTED, .750 [QTY. 2], TUBING, NYLON, ROUND [QTY. 0.5 ], BUSHING, REDUCING [QTY. 4 ], FITTING, TUBE, QD [QTY. 2], FITTING, TUBE, QD ( 90 DEG SWIVEL) [QTY. 2], FITTING, TUBE, MALE (1/4 NPT) [QTY. 2], BRACKET, CORSSOVER, PAINTED 3 in. [QTY. 2], BRACKET, LIMIT VALVE [QTY. 2], WASHER, PLAIN [QTY. 4 ], SCREW, CAP, SCH [QTY. 4 ], WASHER, LOCK, #10 [QTY. 6 ], NUT, HEX MSCR [QTY. 4 ], VALVE, LIMIT, AIR [QTY. 2], WASHER, FLAT [QTY. 4 ], SCREW, CAP, SOCKET HD [QTY. 4 ], WASHER, LOCK, SPRING [QTY. 4 ], NUT, HEX MSCR [QTY. 4 ], WASHER, LOCK [QTY. 6 ], SCREW, CAP, SOCKET HEAD [QTY. 6 ], PLATE, MOUNTING, 4-WAY VALVE [QTY. 1], VALVE, AIR, REMOTE, 4 WAY [QTY. 1],

GG 256238

GG 256356

GG 256399

VALVE, PRESS,BLEED

Graco 256399 Pressure Bleed Valve for ProMix 2KS and 3KS Proportioner
