ENERPAC S100272

EP RC1010

RC-TRIO is the next generation of the legendary Enerpac RC-Series single acting hydraulic cylinders. These hydraulic jacks include many advanced features to ensure superior durability, versatility, and productivity.

A pre-tensioned spring provides fast plunger retraction and enhanced productivity. The robust bearing system features composite wear bands and a hardened stop ring to resist side-load which minimizes damage and repairs. The plunger wiper, high-grade polyethylene seals and tough external finishes also help towards an extended service life.

With so many hydraulic cylinder models to choose from, we’re confident you’ll find the perfect match for your applications, and if you already own prior RC-Series cylinders, the good news is the new cylinders share the same familiar dimensions and threads for full compatibility.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RC
• Stroke Inches: 10.13
• Stroke MM: 257
• SubTypes: General Purpose Cylinder

• Bearing system with composite wear bands for optimal sideload resistance
• Strengthened stop ring improves durability and side load resistance
• Trio Hybrid pre-tensioned spring system provides faster retraction
• High-grade polyethylene seals for low wear and long service life
• Plunger wiper reduces contamination, extending cylinder life.
• Collar and plunger threads and base mounting holes enable easy fixturing (on most models)
• Standard certified lifting eyes on cylinder models above 55 lbs. (25 kg) weight.
• Interchangeable with optional CHM6 carrying handle
• Designed for use in all positions
• Baked enamel finish for increased corrosion resistance
• Includes CR400 coupler, dust cap and collar thread protector
• RC-Series model numbers, external dimensions and threads remain unchanged from prior RC Series cylinders

• Spare Part(s): RC106044, RC1010040, RC10NK0, RC10K35, RC10NKS, RC10NKB2, RC10NKB3, RC10NKW
• Accessories: A92, A102G, CATS12, JBI10, RB10, AW102, REB10, REP10

EP PAM1042K3

• Type: Service Kit

• Product Group: Pumps
• SubTypes: Repair Kit

EP PARG1105N

Enerpac Turbo II Air Over Hydraulic Pumps generate the hydraulic pressure you need using the air pressure you have available. The Air Saver Piston reduces air consumption, and the pump can start at low pressures from 50-125 psi.

Turbo II Air-Hydraulic Pumps are best suited to medium or lower cycle applications. They provide all the power and speed needed for simple clamping circuits and mostly single acting tools. At only 75 dBA, the Turbo II Series helps to keep the noise level to a minimum.

Choose from a range with maximum working pressure of either 5,000 or 10,000psi, and various reservoir capacities from 116 - 462 in3 (2100 - 7500 cm3).

Each PARG pump variant includes a 3-way, 3-position valve for Advance / Hold / Retract functions.

Turbo II Air Over Hydraulic Pump Series :

• PATG - Treadle for foot or hand operation
• PARG - Pendant Operation
• PAMG - Manual lever operated. For double-acting applications
• PACG - For remote valve mount. For work holding, 5000 psi (350 bar).
• PASG - Includes mount for a single DO3 Valve.

• Type: Hydraulic Pump
• Max Bar: 700
• Max PSI: 10000

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: PARG
• SubTypes: Air Pump

• High efficiency cast aluminum air motor for increased life and reduced air consumption
• Reinforced heavy-duty reservoir for applications in tough environments
• New generation air saver piston with rugged one-piece design reduces air consumption and operating costs
• Return-to-tank port for use in remote valve applications
• Quiet - only 76dBA with low air consumption of 12 scfm
• Operating air pressure: 40-125 psi, enables pump to start at extremely low pressure
• Internal pressure relief valve provides overload protection

EP F9

• Type: Fitting

• Product Line: Hydraulic Tools
• Series: F - Simplex
• SubTypes: Street Elbow

EP TR630

• Type: Coupler
• Max Bar: 700
• Max PSI: 10000

• Product Group: Couplers
• Product Line: Industrial Tools
• Series: TR - Coupler
• SubTypes: Spin-on Coupler

• Enerpac hydraulic couplers provide quick connection of hydraulic lines
• 10,000 and 11,600 psi 1/4" couplers for torque wrenches
• 10,000 psi 3/8" couplers for cylinders, tools and pumps
• Dimension A is total length when male and female halves are connected.

EP RACD3010

• Technical coating reduces wear & corrosion.
• Steel piston for protection against load damage.
• Chrome plated sleeve for extra protection.
• Stop rings for piston blow-out protection.
• Rod wiper protects inner cylinder from dirt.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Line: Hydraulic Tools
• Series: RACD
• Stroke Inches: 10
• Stroke MM: 254
• SubTypes: Aluminum Center Hole Cylinder

• Capacity Imperial Tons: 30
• Capacity KN: 266,9

EP V-182

EP BSH7527

• Type: Torque Wrench Accessory

• Product Group: Torque Wrenches, Torque Wrench Pumps
• Product Line: Bolting Tools
• Series: BSH
• SubTypes: Socket - Imperial Metric

EP DC4997900K

• Type: Service Kit

• SubTypes: Gasket

EP CH-604

EP DC8101223

• Type: Service Kit

• SubTypes: Repair Part

EP P181190W

• Type: Service Kit

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Relief Valve

EP AD-142

EP VM2K1

• Type: Service Kit

• SubTypes: Repair Part

EP DD1190950SR

• Type: ERP

• SubTypes: Repair Part

EP XLK1

• Type: Pump Accessory

• Product Group: Pumps
• Product Line: Industrial Tools
• SubTypes: Joy Stick Lever Kit

EP BHY32A

EP 46459E

• Type: Hydraulic Cylinders

• Product Group: Cylinders and Jacks
• SubTypes: Repair Part

EP PRV-3

EP DA610900SR

• Type: Service Kit

• SubTypes: Repair Kit

EP RAC-504

EP LW-16

EP DC8181827

• Type: Service Kit

• SubTypes: Power Board

EP 54490K

• Type: ERP

• SubTypes: Repair Part

EP 68389E

• Type: Service Kit

• SubTypes: Gasket

EP CW151028

• Type: Service Kit

• SubTypes: Screw

EP DA5290900SR1

• Type: ERP

• SubTypes: Repair Part

EP 42747E

• Type: Service Kit

• SubTypes: Piston Kit

EP CDB-70502

EP ZU4208BB-QH

• Type: Hydraulic Pump

• Product Group: Pumps
• Series: ZU

EP V2000K

EP 68830E

• Type: Service Kit

• SubTypes: Piston Kit

EP 90333

• Type: Service Kit

EP RC-506

EP B1003503

• Type: Service Kit

• SubTypes: O-Ring Kit

EP G2513L

This G-Series Liquid Filled Pressure Gauge contains glycerin to protect pressure sensing parts from vibration, sudden pressure changes, and moisture.

The dual scale face shows both psi and bar readings, and the extensive range includes a wide selection of models with maximum working pressures ranging from 100 to 15000 psi (7 to 1000 bar).

When using your gauges for high-cycle applications, we recommend using gauge snubbers or needle valves.

• Type: Gauge
• Max Bar: 40
• Max PSI: 600

• Product Group: Gauges, Pumps
• Product Line: Industrial Tools, Work Holding Tools
• Series: G
• SubTypes: Pressure Gauge

• Calibrated in dual scale reading in psi and bar
• All pressure sensing parts sealed and dampened by glycerine for long life
• Includes safety blow-out disk and pressure equalizing membrane
• Gauge snubbers or needle valves recommended for high cycle applications

EP DC9661066

• Type: Service Kit

• SubTypes: Washer

EP HF102

The Enerpac HF-series Hydraulic Oil is specially formulated for powered hydraulic pumps. The HF-series oil contains anti-sludge, anti-rust, and anti-foam additives for overall superior performance. The HF-series hydraulic oil prevents cavitation and offers maximum volumetric efficiency and maximum heat transfer.

The HF-series oil is not for use in hand pumps. Use the Enerpac LX-Series Oil for hand powered pumps.

Offered in 1 quart, 1 gallon, 5 gallon and 55-gallon sizes. The HF-series hydraulic oil has a viscosity index of 100 min.

• Type: Hydraulic Oil

• Product Group: Pumps
• Product Line: Industrial Tools, Work Holding Tools, Bolting Tools
• Series: HF
• SubTypes: Oil

• Specially formulated for power pumps
  • maximum volumetric efficiency
  • maximum heat transfer
  • prevents cavitation
  • anti-sludge, anti-rust, anti-foam additives
• Maximum film protective lubricity
  • anti-oxidation additives
• High viscosity index ensures maximum lubricity over a wide range of operation temperatures.

EP BSH7530

• Type: Torque Wrench Accessory

• Product Group: Torque Wrenches, Torque Wrench Pumps
• Product Line: Bolting Tools
• Series: BSH
• SubTypes: Socket - Imperial Metric

EP REB-5

EP VE33

• Type: Valve
• Max Bar: 700
• Max PSI: 10000

• Product Group: Valves, Pumps
• Product Line: Industrial Tools, Work Holding Tools
• Series: VE
• SubTypes: Directional Control Valve

• Advance/Hold/Retract operation of single-acting cylinders
• Solenoid Operation
• Pump mounting will retrofit on most Enerpac Pumps
• Standard " locking" feature on VE Series 3-position valves
• User adjustable relief valves allow the operator to easily set the working pressure

EP W8308X

W-Series Low Profile Hexagon Cassettes work with your compatible drive unit, giving you the access needed for hassle-free bolting in tight spaces.

ATEX declared. Calibration certificate included. All W-Series X-edition cassettes are CE - ATEX declared and are shipped complete with a calibration certificate.

Robustly constructed from steel especially for heavy use and enduring durability, these robust cassettes are designed to ensure a low total cost of ownership. Fast release in the compatible drive units enable rapid exchange of cassettes - no tools required and no pins to lose!

The optimum nose radius in each cassette offers the ideal strength to size ratio for restricted clearance applications. (For exceptionally tight spaces consider the UltraSlim Cassettes).

Constant torque output provides accuracy of plus/minus 3% across full stroke.

• Type: Torque Wrench
• Max PSI: 10000

• Product Group: Torque Wrenches, Torque Wrench Pumps
• Product Line: Bolting Tools
• Series: W - Cassette
• SubTypes: Cassette - Imperial

• Accessories: W8308R212, W8308R215, W8308R300, WTE80, WRP80

EP NC6075

NC-Series Hydraulic Nut Splitters use a single blade configuration suited to general nut cutting applications across a wide range of industries.

The heat-treated steel blade with its optimized cutting head geometry cuts from one side, and the powerful internal spring brings it back to its starting position.

NC-Series Nut Cutters are compact, simple, and easy to use. The ergonomic design ensures comfortable use, thanks to the carefully considered angled head design and handle position.

Nuts are often difficult to remove, and while loosening them using tightening tools is possible, this generally requires larger equipment and takes more time.

Using a cutting torch or a hammer and chisel presents safety risks and can cause damage to the joint components. They also involve significantly longer setup and operational time.

Nut splitting with the Enerpac Hydraulic Nut Splitters is the safest and most efficient method - taking less time and avoiding costly damage to joint components.

• Type: Cutter
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cutters
• Product Line: Industrial Tools, Bolting Tools
• Series: NC
• SubTypes: Nut Cutter

• Capacity Imperial Tons: 90
• Capacity KN: 882

• Compact and ergonomic design, easy to use
• Unique angled head design
• Single-acting, spring return cylinder
• Heavy duty chisels can be reground
• Nut Splitters include spare chisel, spare set screw and wrench used to secure the chisel. A CR-400 coupler is standard.
• For applications with bolt sizes that are common to two tool model sizes, we recommend to select the larger of the two tools for the best results.
• These are not suited for square, star, round or stainless steel nuts. Maximum allowable hardness of nuts to be split is HRc-44.
• For materials and sizes not specified, contact Enerpac Technical Services.

• Accessories: NCB6075

EP BHR16A

EP LGM204

• Type: Puller

• Product Group: Pullers
• Product Line: Industrial Tools
• Series: LGM
• SubTypes: Lock-Grip Puller Mechanical

• Capacity Imperial Tons: 4
• Capacity KN: 35,6

• LGM-Series Pullers are an ideal solution for pulling small to medium-size wheels, sprockets, bearings and other similar shaft mounted parts. The puller's selfcentering closing system allows all jaws to move simultaneously, making it easy for a single operator to mount the puller and to perform the application. Turning the puller handle locks the jaws onto the application, allowing the desired object to be pulled free when the spindle is turned.
• Quickly and easily mount on a wide range of applications
• Lock-on jaws offer a secure grip for safe and easy operation
• Synchronous jaw movement enables entire pulling job to be performed by a single operator
• LGM-Series Pullers MUST be used with a point protector if the shaft end does not contain a drilled center hole. One point protector is included with every puller.
• Always wear safety goggles and gloves while using pullers.

• Set Includes: SGM0404

EP R515245-2

• Type: Service Kit

• SubTypes: Plug

EP CR703018

• Type: Service Kit

• SubTypes: Repair Part

EP G2509L

This G-Series Liquid Filled Pressure Gauge contains glycerin to protect pressure sensing parts from vibration, sudden pressure changes, and moisture.

The dual scale face shows both psi and bar readings, and the extensive range includes a wide selection of models with maximum working pressures ranging from 100 to 15000 psi (7 to 1000 bar).

When using your gauges for high-cycle applications, we recommend using gauge snubbers or needle valves.

• Type: Gauge
• Max Bar: 7
• Max PSI: 100

• Product Group: Gauges, Pumps
• Product Line: Industrial Tools, Work Holding Tools
• Series: G
• SubTypes: Pressure Gauge

• Calibrated in dual scale reading in psi and bar
• All pressure sensing parts sealed and dampened by glycerine for long life
• Includes safety blow-out disk and pressure equalizing membrane
• Gauge snubbers or needle valves recommended for high cycle applications

EP 85C-RAMK

• Type: Service Kit

• SubTypes: Repair Kit

EP H9350

H900-Series Hydraulic Hoses are designed to comply with the Material Handling Institute IJ100 hose specification. They provide the durability needed for repeated heavy-duty high-pressure applications and offer the optimum combination of flexibility and low &lsquo

EP DS1018118E

• Type: ERP

• SubTypes: Repair Part

EP F10

• Type: Fitting

• Product Line: Hydraulic Tools
• Series: F - Simplex
• SubTypes: Reducer Fitting

EP DC3076118

• Type: Service Kit

• SubTypes: Repair Part

EP JHA1506K2

• Type: Service Kit

• SubTypes: Repair Part

EP RA106

• Type: Hydraulic Cylinders

• Product Group: Cylinders and Jacks

EP HC-9310

EP FZ-1612

EP RC-502

EP 54659

• Type: ERP

EP RR-1006

EP E393SDK

• Type: Service Kit

• SubTypes: Square Drive Kit

EP RCS302

RCS-Series Low Profile Hydraulic Cylinders provide superior durability, performance longevity, safety, and quality in a compact and convenient footprint. These low profile hydraulic jacks are the perfect choice for general lifting and production applications where space is limited or constrained. A low collapsed height, short stroke, and solid construction enables safety and stability in both vertical and horizontal orientations.

Many low-profile hydraulic cylinders rely on the weight of the load to retract the plunger. RCS cylinders are different and include a powerful return spring, which is faster, convenient, and more productive. The entire RCS cylinder range is rated for high-pressure; 10,000 psi (700 bar).

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: RCS
• Stroke Inches: 2.44
• Stroke MM: 62
• SubTypes: Low Height Cylinder

• Lightweight, low profile design for use in confined spaces
• Baked enamel finish for increased corrosion resistance
• Plunger wiper reduces contamination, extending cylinder life
• CR-400 coupler and dust cap included on all models
• Grooved plunger end with threaded holes for mounting tilt saddles
• Plated steel plungers
• Single-acting spring return

• Spare Part(s): RCS302K, DC5215900, RCS302KV
• Accessories: CATS53

EP CATS52

• Type: Cylinder Accessories

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: CATS
• SubTypes: Tilt Saddle

• With safety and convenience in mind the new tilt saddles are designed to allow bolting to the cylinder - which means they can be used safely in any orientation without the risk of the saddle dropping off.
• CATS-Tilt Saddles use a nitrocarburization surface treatment for improved corrosion protection, helping to maintain a professional look through their usage life.

EP SULS-121

EP B11A

• Simplex air bags operate on standard shop air up to 116 psi (8 bar)
• All models include 2 ply Kevlar with neoprene.
• Wide variety of safety controllers for single & multiple bag systems.
• Light weight makes the Simplex air bags easy to set up.
• Y Connector allows control of two bags from one singlefitting controller.
• Dual Deadmand Controller used for precise inflation anddeflation control.

• Type: Jack
• Max Bar: 32
• Max PSI: 116

• Series: B
• Stroke Inches: 5.9
• Stroke MM: 149.9
• SubTypes: Air Lifting Bags

• Capacity Imperial Tons: 10.8
• Capacity KN: 96,1

• Accessories: BHR16A, BHR32A, BHB16A, BHB32A, BHY16A, BHY32A, BC12, BC2A, BC3A, BC9A, BC8A, BC6A, BC11, BC1A, BC4A

EP RLS302

• Compact low-profile design.
• HD spring for fast retraction.
• Grooved plunger to stabilize the load.
• Stop ring for piston blow-out protection.
• Rod wiper protects inner cylinder from dirt.
• Plated piston to resist scoring & corrosion.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000

• Product Line: Hydraulic Tools
• Series: RLS
• Stroke Inches: 2.44
• Stroke MM: 62
• SubTypes: Low Height Cylinder

• Capacity Imperial Tons: 30
• Capacity KN: 266,9

EP RC-1006

EP XA12VG

Enerpac XA Series Air Driven Hydraulic Foot Pumps are ideal choice for hands-free operation.

All models offer two control pedals for adding and releasing pressure to the tool. A pedal lock function can be used in the retract position. The XA foot pump provides fine metering controls to apply the mandatory stroke and force.

This air hydraulic foot pump provides a closed hydraulic system that prevents contamination and allows pump usage in any position.

The XA series foot pump has many optional features that can be ordered separately including:

• ½ Gallon Oil Reservoir
• Joy-stick Lever Kit
• Hydraulic Swivel Connector

The maximum operating pressure for this pump is 10,000 psi (700 bar). Maximum flow rates at rated pressure 15 in3/min (1.97L).

• Type: Hydraulic Pump
• Max Bar: 700
• Max PSI: 10000

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: XA
• SubTypes: Air Pump

• Higher oil flow for increased productivity
• Variable oil flow and fine metering for precise control
• Closed hydraulic system prevents contamination and allows pump usage in any position
• Pedal lock function for retract position
• External adjustable pressure setting valve
• ATEX Certified.* Includes ground screw for explosion protection

• Accessories: XPG1, XLK1, XSC1, RFL102

EP A61

Enerpac A-Series hydraulic manifolds allow you to split the flow of hydraulic oil from a central block.

A64, A65, and A66 manifolds have a 3/8" -18 NPT female port and maximum operating pressure of 10,000 psi (700 bar).

A63, A60, and A61 manifolds have a SAE #4 female port and a maximum operating pressure of 5,000 psi (350 bar).

• Type: Manifold
• Max Bar: 350
• Max PSI: 5000

• Product Group: Manifolds, Pumps
• Product Line: Work Holding Tools
• Series: A - Manifold
• SubTypes: Long Manifold

• Easy to connect
• Mounting holes on all models

EP STLD51

• Type: Work Holding Clamp
• Max PSI: 5000
• Min PSI: 500

• Product Group: Workholding Tools
• Product Line: Work Holding Tools
• Series: ST
• Stroke Inches: 0.89
• SubTypes: Swing Clamp - Threaded Body

• Body thread for precise cylinder height positioning
• Threaded port connection
• Easy installation and removal
• Greatest flexibility in fixture design
• 30, 45 and 60 degree swing angles available on request
• Enerpac threaded body swing clamps are threaded directly into the fixture.
• The cylinder height is adjusted to the appropriate height, and then locked in place using a jam nut

EP F3

• Type: Fitting

• Product Line: Hydraulic Tools
• Series: F - Simplex
• SubTypes: Nipple

EP GF510P

GF-Series gauges are calibrated with dual scales for reading for pressure and force.

The force readings allow you to measure external loads, such as those supported by a cylinder or jack, or the force used for pressing parts.

The glycerin within the gauge protects pressure sensing parts from vibration, sudden changes in pressure and from moisture.

The GF-Series Gauges feature a 4” (100 mm) diameter face for easy readability, and a stainless-steel casing for corrosion resistance.

• Type: Gauge
• Max Bar: 700
• Max PSI: 10000

• Product Group: Gauges, Pumps
• Product Line: Industrial Tools
• Series: GF
• SubTypes: Force and Pressure Gauge

• Excellent readability; 4 inch diameter gauge face.
• Fast, easy installation
• Stainless steel gauge cases for corrosion resistance
• Calibrated with dual scale reading for psi and bar

EP CH601299

• Type: Service Kit

• SubTypes: Repair Part

EP SC10HTB

• Type: Cylinder And PumpSet
• Max Bar: 700
• Max PSI: 10000

• Product Group: Cylinders and Jacks, Pumps
• Product Line: Industrial Tools
• Series: SCTB
• Stroke Inches: .44 - 6.13
• Stroke MM: 11 - 156
• SubTypes: Toolbox Set - MRO

• Capacity Imperial Tons: 10
• Capacity KN: 89,0

• Designed to enhance job-site performance
• Provides a convenient and portable solution for all your lifting, pushing or pulling requirements up to 10 ton
• Industrial strength container keeps tools organized and secure
• Complete with base plate for extra stability.

• Set Includes: P392, GA45GC, HC7206C, HF100, RC106, JBI10, RCS101, RSM100, RCH123, WR5

EP RD910K2

• Type: Service Kit

• SubTypes: Repair Kit

EP RSL19000FSK

• Type: Service Kit

• SubTypes: Front Cap and Seal Kit

EP 44595E

• Type: Service Kit

• SubTypes: Screw

EP DC8372378

• Type: Service Kit

• SubTypes: Fuse

EP 86269E

• Type: Service Kit

• SubTypes: Gasket

EP RCH-123

EP DD1774271

• Type: Service Kit

• SubTypes: Thread Protector

EP V42K

• Type: ERP

• SubTypes: Repair Part

EP P-2282

EP V152K

• Type: Service Kit

• SubTypes: Repair Kit

EP PUJ1401B

PU Series electric over hydraulic pumps combine economy with high-performance - ideal for intermittent use when working with small to medium size cylinders and other hydraulic tools.

All models in the series are 2-speed for enhanced productivity, and each is supplied with a 10 ft (3 m) cord and control pendant for operator safety. The high-strength molded shroud with integral handle protects the motor from contamination and damage in industrial environments.

Within the PU Series is a selection of pumps that offer a choice of reservoir capacities, valve functions and voltage.

PUD1100 Series

• For advance and retract of single-acting cylinders
• For applications not requiring load holding
• Ideal for punching applications

PUD1300 Series

• Providing advance, hold, and retract of single-acting cylinders
• Ideal for applications requiring load holding
• For applications requiring solenoid valves

PUJ-Series

• Manual valves provide advance, hold, and retract operation
• 3 and 4-way valves for single or double-acting cylinders

• Type: Hydraulic Pump
• Max Bar: 700
• Max PSI: 10000

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: PU
• SubTypes: Electric Pump - Economy

• The economic choice for small to medium sized tools.
• Lightweight, compact, and portable.
• Two-speed operation reduces cycle times for improved productivity.
• Ideal for intermittent duty cycles.
• Works well with long extension cords or generator-driven electrical power supplies.
• 115 VAC 50/60-cycle universal motor will operate under poor voltage supply.
• 24 VAC remote motor control with 10 ft (3 m) cord for operator safety.
• Starts under full load.
• High-strength shroud with integral handle protects the motor from contamination and damage.

EP W2200X

W-Series Low Profile Hexagon Cassettes work with your compatible drive unit, giving you the access needed for hassle-free bolting in tight spaces.

ATEX declared. Calibration certificate included. All W-Series X-edition cassettes are CE - ATEX declared and are shipped complete with a calibration certificate.

Robustly constructed from steel especially for heavy use and enduring durability, these robust cassettes are designed to ensure a low total cost of ownership. Fast release in the compatible drive units enable rapid exchange of cassettes - no tools required and no pins to lose!

The optimum nose radius in each cassette offers the ideal strength to size ratio for restricted clearance applications. (For exceptionally tight spaces consider the UltraSlim Cassettes).

Constant torque output provides accuracy of plus/minus 3% across full stroke.

• Type: Torque Wrench

• Product Group: Torque Wrenches, Torque Wrench Pumps
• Product Line: Bolting Tools
• Series: W - Cassette
• SubTypes: Cassette - Imperial or Metric

• Accessories: W2200R107, W2200R110, WTE20, WRP20

EP AD181

• Type: Cylinder Accessories

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools, Work Holding Tools
• Series: AD
• SubTypes: Foot Mount

EP ZE3408SB

Enerpac ZE3 electric hydraulic pumps are based on our Z Pump platform - our most efficient and market proven design. Z-Class high-efficiency pumps offer higher oil flow and by-pass pressure, cooler running and 18% less current draw than comparable pumps.

The ZE3 pump utilizes the same robust valves, reservoir, and pump components as larger pumps in the ZE family. Combined with the efficient, easy to service pumping element, the ZE3 is suited to continuous use in manufacturing and workshop environments.

The 1.0 hp (0.75 kW) induction motor in the ZE3 enables productive flow rates, cooler running temperatures, quieter operation, and less power consumption than pumps with standard universal motors.

Multiple valve and control options allow you to match the pump to a wide range of pressing, punching, and many other operations.

• Type: Hydraulic Pump
• Max PSI: 10000

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: ZE
• SubTypes: Electric Pump - High Flow

• 1.0 hp (0.75 kW) induction motor for long life and quiet operation.
• Features Z-Class high-efficiency pump design; higher oil flow and by-pass pressure, cooler running and requires up to 18% less current draw than comparable pumps.
• Totally enclosed, fan-cooled industrial electric motors for an extended life and to stand up to harsh industrial environments.
• 75 dBA sound level.
• Low-voltage pendant, on certain models, provides additional safety for the operator.
• Multiple valve and reservoir configurations provide application specific models to match the most demanding industrial applications.
• Models available to suit single-acting or double-acting cylinders.
• High-strength, molded electrical enclosure protects electronics, power supplies and LCD readout from harsh industrial environments.
• LCD readout on electric valve models provides diagnostic and readout capabilities.
• IP54 Rating for superior dust and water protection.
• Wide range of optional factory installed accessories; including return line filter, pressure gauge, heat exchanger, skid bar, roll cage, foot switch, and more.

• Accessories: ZPF, SBZ4, ZRC04, ZPTU4, ZLSU4, ZCF2, ZHEE04

EP ZE3320MB

Enerpac ZE3 electric hydraulic pumps are based on our Z Pump platform - our most efficient and market proven design. Z-Class high-efficiency pumps offer higher oil flow and by-pass pressure, cooler running and 18% less current draw than comparable pumps.

The ZE3 pump utilizes the same robust valves, reservoir, and pump components as larger pumps in the ZE family. Combined with the efficient, easy to service pumping element, the ZE3 is suited to continuous use in manufacturing and workshop environments.

The 1.0 hp (0.75 kW) induction motor in the ZE3 enables productive flow rates, cooler running temperatures, quieter operation, and less power consumption than pumps with standard universal motors.

Multiple valve and control options allow you to match the pump to a wide range of pressing, punching, and many other operations.

• Type: Hydraulic Pump
• Max PSI: 10000

• Product Group: Pumps
• Product Line: Industrial Tools
• Series: ZE
• SubTypes: Electric Pump - High Flow

• 1.0 hp (0.75 kW) induction motor for long life and quiet operation.
• Features Z-Class high-efficiency pump design; higher oil flow and by-pass pressure, cooler running and requires up to 18% less current draw than comparable pumps.
• Totally enclosed, fan-cooled industrial electric motors for an extended life and to stand up to harsh industrial environments.
• 75 dBA sound level.
• Low-voltage pendant, on certain models, provides additional safety for the operator.
• Multiple valve and reservoir configurations provide application specific models to match the most demanding industrial applications.
• Models available to suit single-acting or double-acting cylinders.
• High-strength, molded electrical enclosure protects electronics, power supplies and LCD readout from harsh industrial environments.
• LCD readout on electric valve models provides diagnostic and readout capabilities.
• IP54 Rating for superior dust and water protection.
• Wide range of optional factory installed accessories; including return line filter, pressure gauge, heat exchanger, skid bar, roll cage, foot switch, and more.

• Accessories: ZPF, SBZ4, ZRC20, ZPSE3

EP BSH1046

• Type: Torque Wrench Accessory

• Product Group: Torque Wrenches, Torque Wrench Pumps
• Product Line: Bolting Tools
• Series: BSH
• SubTypes: Socket - Imperial Metric

EP HCRL1006

HCRL Series High Tonnage Hydraulic Cylinders feature a lock nut to provide mechanical load holding for extended periods of time. These double-acting cylinders use hydraulic force to deliver a faster and more controlled return of the plunger than load/gravity return equivalents. Tilt saddles are provided as standard on all HCRL cylinders which allow up to 5 degrees of load misalignment.

All Enerpac High-Tonnage Cylinders are equipped with numerous special features to ensure the durability, safety, and performance needed for large-scale construction projects. Among these features are low-wear high-pressure seals, replaceable composite plunger support bearings, and a robust nitrocarburized finish on both the body and plunger.

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10150

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: HCRL
• Stroke Inches: 5.91
• Stroke MM: 150
• SubTypes: High Tonnage Lock Nut Cylinder

• Ensures safety by providing mechanical load holding for extended periods
• Low friction lock nut spins easily, saving time and effort
• Double acting hydraulic return for fast advance and retract
• Integrated tilt saddle allows up to 5 degrees of misalignment
• Nitrocarburized surface resists side-loading and cyclic wear
• 10% side-load resistance over full cylinder stroke
• Stop-ring prevents plunger blow-out
• Weather protected, inside and out
• Upper and lower replaceable bearings support the plunger throughout the stroke
• Certified lifting eyes
• Base mounting holes and collar thread included as standard.
• HCRL-Series Cylinders are available with up to 1000-ton capacity and 24-inch stroke upon request.
• Maximum working pressure up to 10,000 psi (700 bar)
• Complies to ASME B30.1

• Accessories: CHM6

EP LGM203

• Type: Puller

• Product Group: Pullers
• Product Line: Industrial Tools
• Series: LGM
• SubTypes: Lock-Grip Puller Mechanical

• Capacity Imperial Tons: 3
• Capacity KN: 26,7

• LGM-Series Pullers are an ideal solution for pulling small to medium-size wheels, sprockets, bearings and other similar shaft mounted parts. The puller's selfcentering closing system allows all jaws to move simultaneously, making it easy for a single operator to mount the puller and to perform the application. Turning the puller handle locks the jaws onto the application, allowing the desired object to be pulled free when the spindle is turned.
• Quickly and easily mount on a wide range of applications
• Lock-on jaws offer a secure grip for safe and easy operation
• Synchronous jaw movement enables entire pulling job to be performed by a single operator
• LGM-Series Pullers MUST be used with a point protector if the shaft end does not contain a drilled center hole. One point protector is included with every puller.
• Always wear safety goggles and gloves while using pullers.

• Set Includes: SGM0404

EP WM1584207

• Type: Service Kit

• SubTypes: Oil Reservoir

EP MPK2

• Type: Service Kit

• SubTypes: Manifold Kit

EP RD2510

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000
• Min Bar: 35

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools, Work Holding Tools
• Series: RD
• Stroke Inches: 10.25
• Stroke MM: 260
• SubTypes: General Purpose Cylinder

• Designed for long life, the best choice for production applications
• Unique mounting configurations simplify fixturing
• Baked enamel finish for increased corrosion resistance
• Double-acting operation develops force in both directions, providing maximum versatility
• Plunger wiper reduces contamination, extending cylinder life

• Accessories: AD191, AD192, AD193, AD153

EP BSH7532

• Type: Torque Wrench Accessory

• Product Group: Torque Wrenches, Torque Wrench Pumps
• Product Line: Bolting Tools
• Series: BSH
• SubTypes: Socket - Metric

EP RC15K51

• Type: Service Kit

• SubTypes: Repair Kit

EP CN58110

• Type: Service Kit

• SubTypes: Spring Kit

EP DC2778378

• Type: Service Kit

• SubTypes: Fuse

EP TRK-2
