EP WPFR300V
8,500 lbs Force, Collet-Lok Swing Cylinder, Lower Flange, Right Turn
Applications: Clamp, Hold
- Type: Hydraulic Cylinders
- Max PSI: 5000
- Min PSI: 1400
- Product Group: Cylinders and Jacks
- Product Line: Work Holding Tools
- Series: WPF
- Stroke Inches: 1.65
- SubTypes: Collet Lok Swing Cylinder
- Double acting Collet-Lok action allows fully automated operation
- Additional level of safety since live hydraulics are not required to maintain clamping force
- Collet-Lok swing cylinders can be mounted by the flange or threaded into the fixture. Flanged models have manifold ports and tubing ports.
- Viton seals are standard
