DYNABRADE INC. S12699

DY 61201

For 55 Gallon (208 L) Drum-Wheel Base Sold Separately, 120V, Dry Dust, Vac Hose-Integrated Air Line

Dynabrade's family of DrumVac Kits are a multi-industry clean air solution with fully integrated features designed to keep an operator working without being concerned with the arduous task of changing out a vacuum bag in high collection scenarios. Used in conjunction with a 55-gallon drum (sold separately), this system lends itself to one of the largest capacity portable dust collection systems in the industry.

55 Gallon drum equates to large collection capacity. No bag change-out requirements. Vacuum hose with integrated airline reduces operator fatigue. Prevents tripping hazards.

DY 61204

For 55 Gallon (208 L) Drum-Wheel Base Sold Separately, Dry Heavy Chip

Dynabrade's family of DrumVac Kits are a multi-industry clean air solution with fully integrated features designed to keep an operator working without being concerned with the arduous task of changing out a vacuum bag in high collection scenarios. Used in conjunction with a 55-gallon drum (sold separately), this system lends itself to one of the largest capacity portable dust and dry chip collection systems in the industry.

55 Gallon drum equates to large collection capacity. No bag change-out requirements. Anti-Static clean up kit eliminates static discharge to operator.

DY 61205

For 55 Gallon (208 L) Drum-Wheel Base Sold Separately, Wet Heavy Chip

Dynabrade's family of DrumVac Kits are a multi-industry clean air solution with fully integrated features designed to keep an operator working without being concerned with the arduous task of changing out a vacuum bag in high collection scenarios. Used in conjunction with a 55-gallon drum (sold separately), this system lends itself to one of the largest capacity portable dust and wet chip collection systems in the industry.

55 Gallon drum equates to large collection capacity. No bag change-out requirements. Anti-Static clean up kit eliminates static discharge to operator.

DY 61421V

20 Gallon (78 L), 15 A, 120V/60 Hz, M-Class, Stainless Steel-Conductive, Dry Only, N. America

DY 61363

DY 61420

DY 61447

DY 61495

DY 61485

DY 62410

2.50in I.D. x 6.375in O.D. x 2.75in H

DY 61467

Division 1, Auto On/Off, Silencer

DY 65265

DY 62719

DY 64449

DY 62483

9.00in I.D. x 11.50in O.D. x 2.75in H

DY 64404

230 V (AC), 3 Phase, 60 Hz, Side Exhaust,

Meets These NFPA Requirements: Interlock Pneumatic Valve with Blower and Time-Delay. Tools operate only when Downdraft Table is running. Class II, Group E Explosion-Proof Motor. Aluminum Top for Non-Spark Work Surface. Non-Spark Aluminum Blower on Collector?s Clean-Air Side. Automatic Water Level Control. Vented Sump (Main Tank). Low Voltage Control. Lockable Fused Power Disconnect

Ideal for capturing aluminum and titanium dust. Working area of 36in wide x 60in long accommodates large work pieces. Includes casters for easy maneuvering. casters also lock securely into place.

• HP: 3.0

DY 65130

DY 65132

DY 64467

DY 66402

1.86 hp, 7,200 RPM, Side Exhaust, 4,700 SFPM, for 1-1/2in W x 24in L (38 mm x 610 mm) Belts

For use on metal, glass, stone, rubber, ceramic, carbide composites and other hard to grind materials. Mounts to standard lathes. Simple tool holder mounting. Holds close tolerances.

Reduce surface finish on materials prior to a superfinishing process.In-line belt tracking prevents uneven belt stretching, as found on conventional belt tracking arrangements.

• HP: 1.86
• Max. RPM: 7200.0
• Motor RPM: 7200

DY 64986

DY 64805

DY 62340

DY 65750

3 hp, 3,450 RPM, Wet, 240 V (AC), 1 Phase, 60 Hz, 7,200 SFPM

Mounts to Standard Lathes, for Applications from Grinding to Superfinishing. Model features air-powered belt tensioning.

Model features fixed speed for faster cutting. Easily accessible belt tracking and tensioning adjustments.Coolant nozzle with adjustable flow valve.

• HP: 3.0
• Max. RPM: 3450.0
• Motor RPM: 3450

DY 65236

DY 64206

230 V, 1 Phase, 60 Hz

Eliminate airborne dust and contaminants while sanding. Working Area of 33in (84 cm) W x 60in (152 cm) L.

Ideal for use with vacuum-ready or non-vacuum tools. Dual filtration - accepts 1-micron pleated paper filters: 20in (508 mm) W x 25in (635 mm) L. Includes two filters.

• HP: 1.0

DY 62564

DY 77817

• Motor RPM: 13,300

DY 78009

Used for a wide range of applications including decorative finishing, surface conditioning and blending on a variety of metals. Tough reinforced nylon and abrasive belts allow controlled cut to eliminate gouging, run cool and leave burr free finishes.

DynaBrite belts are made of a non-woven nylon which is impregnated with abrasive grain and resin, perfect for: Light and heavy duty cleaning, Deburring, Blending, Polishing and Finishing.

DY 78018

Used for a wide range of applications including decorative finishing, surface conditioning and blending on a variety of metals. Tough reinforced nylon and abrasive belts allow controlled cut to eliminate gouging, run cool and leave burr free finishes.

DynaBrite belts are made of a non-woven nylon which is impregnated with abrasive grain and resin, perfect for: Light and heavy duty cleaning, Deburring, Blending, Polishing and Finishing.

DY 78022

Used for a wide range of applications including decorative finishing, surface conditioning and blending on a variety of metals. Tough reinforced nylon and abrasive belts allow controlled cut to eliminate gouging, run cool and leave burr free finishes.

DynaBrite belts are made of a non-woven nylon which is impregnated with abrasive grain and resin, perfect for: Light and heavy duty cleaning, Deburring, Blending, Polishing and Finishing.

DY 78047

2-dimensional open structure non woven surface conditoniing material coated throughout with aluminum oxide abrasive

produces long life and consistent finishes on ferrous and non ferrous metals

DY 78048

Used for a wide range of applications including decorative finishing, surface conditioning and blending on a variety of metals. Tough reinforced nylon and abrasive belts allow controlled cut to eliminate gouging, run cool and leave burr free finishes.

DynaBrite belts are made of a non-woven nylon which is impregnated with abrasive grain and resin, perfect for: Light and heavy duty cleaning, Deburring, Blending, Polishing and Finishing.

DY 78075

2-dimensional open structure non woven surface conditoniing material coated throughout with aluminum oxide abrasive

produces long life and consistent finishes on ferrous and non ferrous metals

DY 78076

2-dimensional open structure non woven surface conditoniing material coated throughout with aluminum oxide abrasive

produces long life and consistent finishes on ferrous and non ferrous metals

DY 78077

2-dimensional open structure non woven surface conditoniing material coated throughout with aluminum oxide abrasive

produces long life and consistent finishes on ferrous and non ferrous metals

DY 78099

A good high performance mineral that is sharp, hard and tough.

Works well under high heat and grinding pressure applications but can also be effective on many materials at lower grinding pressure levels.

DY 78101

A good high performance mineral that is sharp, hard and tough.

Works well under high heat and grinding pressure applications but can also be effective on many materials at lower grinding pressure levels.

DY 78112

A premium ceramic high performance mineral that is sharp, hard and tough. It micro fracturing and slf sharpening characteristics make it one of the most versatile minerals that works well under high heat and grinding pressure applications but can also be effective on many materials at lower grinding pressure levels.

The best choice for high heat and high grinding pressure applications that is also effective on many materials at lower grinding pressures.

DY 78113

A premium ceramic high performance mineral that is sharp, hard and tough. It micro fracturing and slf sharpening characteristics make it one of the most versatile minerals that works well under high heat and grinding pressure applications but can also be effective on many materials at lower grinding pressure levels.

The best choice for high heat and high grinding pressure applications that is also effective on many materials at lower grinding pressures.

DY 78190

Premium Fepa graded aluminum oxide abrasive offers self sharpening characteristics that provide consistent performance and cut rate on a wide variety of materials and applications

Durable X-weight backing is tough yet flexible for good performance in all disc applications

DY 78177

The most consistent cutting and finishing surface conditioning product

Provides the higher cut rate of a coaser grit while generating the finish of finer grits

DY 78122

2-dimensional open structure non woven surface conditioning material coated throughout with aluminum oxide abrasive

produces long life and consistent finishes on ferrous and non ferrous metals

DY 78291

A good choice for deburring and finishing, weld blending and finishing with one product to reduce the number of steps

Provides a controlled sustained finish

DY 78194

Premium Fepa graded aluminum oxide abrasive offers self sharpening characteristics that provide consistent performance and cut rate on a wide variety of materials and applications

Durable X-weight backing is tough yet flexible for good performance in all disc applications

DY 78294

A good choice for deburring and finishing, weld blending and finishing with one product to reduce the number of steps

Provides a controlled sustained finish

DY 78326

Dynabrite interleaf spindle mount flap wheels and wheels are an ideal choice for a broad range blending and finishing applications in metal fabrication

Less conformable than 100% non woven flap rolls and flap wheels, the alternating flaps of non woven and coated abrasive cloth provide a more aggressive cutting action for stock removal and finishing in one step

DY 78327

Dynabrite interleaf spindle mount flap wheels and wheels are an ideal choice for a broad range blending and finishing applications in metal fabrication

Less conformable than 100% non woven flap rolls and flap wheels, the alternating flaps of non woven and coated abrasive cloth provide a more aggressive cutting action for stock removal and finishing in one step

DY 78378

Thick, strong synthetic fibers and coarse abrasive with a smear-resistant adhesive for quick and easy cleaning and conditioning.

Clean welds, removal of paint/coatings, scale and oxidation.

DY 78710

Orange, 1/8in x 1-1/2in Spindle, 60K RPM Max

Cool Cutting with less Burn

for small job applications or where price is the main consideration

DY 78775

1/8in Spindle

Alumina zirconia/aluminum oxide blend provides up to 35% faster cut rate than standard aluminum oxide mounted points

Aggressive free cutting action cleans more parts in less time, increasing productivity

DY 78713

Orange, 1/8in x 1-1/2in Spindle, 105K RPM Max

Cool Cutting with less Burn

for small job applications or where price is the main consideration

DY 79034

A good high performance mineral that is sharp, hard and tough. It is a versatile mineral that works well under high heat and grinding pressure applications but can also be effective on many materials at lower grinding pressure levels.

Metalwork finishing on stainless steel and nickel alloys, forged steel and aluminum components

DY 79035

A good high performance mineral that is sharp, hard and tough. It is a versatile mineral that works well under high heat and grinding pressure applications but can also be effective on many materials at lower grinding pressure levels.

Metalwork finishing on stainless steel and nickel alloys, forged steel and aluminum components

DY 79151

The self-sharpening design is ideal for high pressure, heavy metal removal applications. Cuts cooler and lasts 50% to 200% longer than current generation of belts. Lower your total grinding costs on hard to grind materials.

Grinding, light grinding and coatings removal on stainless steel, carbon steel, titanium, nickel alloy, chrome and inconel.

DY 79367

Similar vacuum extraction rates vs. other multi-holed and screen-type abrasives (while using multi-hole back-up pad)

Enhanced extraction rates vs. standard 5in five-hole and 6in six-hole discs. 90% mineral coverage.

DY 82569

The self-sharpening design is ideal for high pressure, heavy metal removal applications. Cuts cooler and lasts 50% to 200% longer than current generation of belts. Lower your total grinding costs on hard to grind materials.

Grinding, light grinding and coatings removal on stainless steel, carbon steel, titanium, nickel alloy, chrome and inconel.

DY 79715

DY 79706

Premium 100% wool polishing pads with an integrated foam interface layer that provides maximum cutting performance on fresh, cured and worn paint surfaces.

DynaWool™. pads are the most abrasive polishing pad generating the highest cut rate.

DY 31972C

DY 40330

.5 hp, 7 Degree Offset, 20,000 RPM, Front Exhaust, 1/4-3/4in W x 18-24in L (6-19 mm x 457-610 mm) Belt

Vacuum Dynafile II allows you to vacuum while you work. Highly portable vacuum system works on tool's exhaust.

Includes self-contained 'bag-within-bag' dust collection system (50683 Reusable Felt Bag). One-micron filter rating. Bag traps over 99% of vacuum particles one micron or larger. Hook-Face Closure. Also sold separately.

• HP: 0.5
• Max. RPM: 20000.0
• Motor RPM: 20000

DY 32013

For model 61204

Dry Hat Filter for DrumVac Kit 61204 model.

DY 40353

.4 hp, 7 Degree Offset, 25,000 RPM, Front Exhaust, for 1/8in -3/4in W x 18in L (3-19 mm x 457 mm) Belts

.4 hp Dynafile II adds a lightweight, compact variation to Dynabrade?s famous Abrasive Belt Tool line. Includes 11203 Contact Arm for 1/2in wide x 18in long medium non-woven nylon belt (90292).

Designed exclusively for use with non-woven nylon belts.Excellent for setting grain lines, achieving consistent satin finishes on a variety of metals, and removing oxide and weld discoloration.

• HP: 0.4
• Max. RPM: 25000.0
• Motor RPM: 25,000

DY 40367

DY 40326

.5 hp, 7 Degree Offset, 20,000 RPM, Front Exhaust, 1/4in -3/4in W x 20-1/2in L (6-19 mm x 521 mm) Belts

Grind, deburr, blend and polish, on metal, plastic, fiberglass, composites, rubber, glass and more. Grind from contact wheel or platen pad. finish and polish using slack of belt.

Lightweight, ergonomic 7 degree offset design. Grinding head pivots 360 degrees for securing in most efficient position.

• HP: 0.5
• Max. RPM: 20000.0
• Motor RPM: 20000

DY 40610

10,500 RPM, 120 V (AC), 7 Amp, 60 Hz, for 1/8in -3/4in W x 18-34in L (3-19 mm x 457-864 mm) Belts

Electric Dynafile II runs coated abrasive and non-woven nylon belts, and is ideal for countless applications on metal, plastic, fiberglass, solid surface, stone, glass etc.

Grind with contact wheel or platen pad. Finish and polish using slack of belt. Tool accepts over 20 interchangeable contact arms, for use with belts 1/4in to 3/4in wide by 18in long. Can accept 1/8in wide or 24in long belts with purchase of additional contact arms (not included).

• HP: 1.0
• Max. RPM: 10500.0

DY 40360

DY 40759

DY 31934

DY 31909

DY 31993

DY 40760

DY 31926

DY 40782

DY 40792

DY 40793

DY 40795

DY 43500

25,000 RPM, Front Exhaust, 1/4in and 6 mm Collets

Dynabrade .4 hp (298W) Die Grinder, with extended shafts of 3in (76 mm) for reaching into previously inaccessible areas! These tools allow efficient finishing within deep work-piece channels and difficult passages!

Ideal for rapid material removal, deburring, deflashing, surface preparation, cleaning, finishing and polishing. Models accept optional carbide burrs, abrasive stones, mounted wheels and molded abrasives.

• HP: 0.4
• Max. RPM: 25000.0
• Motor RPM: 25,000

DY 43505

25,000 RPM, Rear Exhaust, 1/4in and 6 mm Collets, Extended Muffler

Dynabrade .4 hp (298W) Die Grinder, with extended shafts of 3in (76 mm) for reaching into previously inaccessible areas! These tools allow efficient finishing within deep work-piece channels and difficult passages!

Ideal for rapid material removal, deburring, deflashing, surface preparation, cleaning, finishing and polishing. Models accept optional carbide burrs, abrasive stones, mounted wheels and molded abrasives.

• HP: 0.4
• Max. RPM: 25000.0
• Motor RPM: 25,000

DY 43510

25,000 RPM, Front Exhaust, 1/4in and 6 mm Collets

Dynabrade .4 hp (298W) Die Grinder, with extended shafts of 6in (152 mm) for reaching into previously inaccessible areas! These tools allow efficient finishing within deep work-piece channels and difficult passages!

Ideal for rapid material removal, deburring, deflashing, surface preparation, cleaning, finishing and polishing. Models accept optional carbide burrs, abrasive stones, mounted wheels and molded abrasives.

• HP: 0.4
• Max. RPM: 25000.0
• Motor RPM: 25,000

DY 45214

DY 43515

25,000 RPM, Rear Exhaust, 1/4in and 6 mm Collets, Extended Muffler

Dynabrade .4 hp (298W) Die Grinder, with extended shafts of 3in (76 mm) for reaching into previously inaccessible areas! These tools allow efficient finishing within deep work-piece channels and difficult passages!

Ideal for rapid material removal, deburring, deflashing, surface preparation, cleaning, finishing and polishing. Models accept optional carbide burrs, abrasive stones, mounted wheels and molded abrasives.

• HP: 0.4
• Max. RPM: 25000.0
• Motor RPM: 25,000

DY 45215

DY 45293

DY 46001

DY 46000

12,000 RPM, Spiral-Geared, Extended Rear Exhaust, 1/4in Collet

All models have air passage to continually cool the gear box. gears last longer! Pinion piloted on rotor to reduce run-out. Needle bearing assures proper shaft alignment.

Dual wick lubrication system saturated with gear oil for extended gear life over 700 hours. This helps administer the right amount and keep the gear oil on the metal gears. Highest horsepower and torque levels of any similar competitive product.

• HP: 0.4
• Max. RPM: 12000.0
• Motor RPM: 12,000

DY 46002

20,000 RPM, Spiral-Geared, Extended Rear Exhaust, 1/4in Collet

All models have air passage to continually cool the gear box. gears last longer! Pinion piloted on rotor to reduce run-out. Needle bearing assures proper shaft alignment.

Dual wick lubrication system saturated with gear oil for extended gear life over 700 hours. This helps administer the right amount and keep the gear oil on the metal gears. Highest horsepower and torque levels of any similar competitive product.

• HP: 0.4
• Max. RPM: 20000.0
• Motor RPM: 20,000

DY 47201

3,200 RPM, Planetary-Geared, Rear Exhaust, 1/4in and 6 mm Collets, Extended Muffler

.4 hp Dynabrade Die Grinders are perfect for use on metal, fiberglass, carbon fiber, composites and more! Dynabrade's .4 hp (298 W) Die Grinders are designed for peak efficiency and longer life! Ideal for rapid material removal, deburring, finishing and polishing, these tools represent the finest in Dynabrade quality and innovation!

Integrated Safety-Lock Throttle Lever has a contoured shape for operator comfort, with new dowel-pin that minimizes lever wear. Increased Tool Life due to Unique Pre-Filter that provides extra defense against contaminants in air stream.

• HP: 0.4
• Max. RPM: 3200.0
• Motor RPM: 3,200

DY 47800

12,000 RPM, Spiral-Geared, Front Exhaust, 1/4in and 6mm Collets

All models have air passage to continually cool the gear box. gears last longer! Pinion piloted on rotor to reduce run-out. Needle bearing assures proper shaft alignment.

Dual wick lubrication system saturated with gear oil for extended gear life over 700 hours. This helps administer the right amount and keep the gear oil on the metal gears. Highest horsepower and torque levels of any similar competitive product.

• HP: 0.4
• Max. RPM: 12000.0
• Motor RPM: 12,000

DY 47802

20,000 RPM, Spiral-Geared, Front Exhaust, 1/4in and 6mm Collets

All models have air passage to continually cool the gear box. gears last longer! Pinion piloted on rotor to reduce run-out. Needle bearing assures proper shaft alignment.

Dual wick lubrication system saturated with gear oil for extended gear life over 700 hours. This helps administer the right amount and keep the gear oil on the metal gears. Highest horsepower and torque levels of any similar competitive product.

• HP: 0.4
• Max. RPM: 20000.0
• Motor RPM: 20,000

DY 47801

15,000 RPM, Spiral-Geared, Front Exhaust, 1/4in and 6mm Collets

All models have air passage to continually cool the gear box. gears last longer! Pinion piloted on rotor to reduce run-out. Needle bearing assures proper shaft alignment.

Dual wick lubrication system saturated with gear oil for extended gear life over 700 hours. This helps administer the right amount and keep the gear oil on the metal gears. Highest horsepower and torque levels of any similar competitive product.

• HP: 0.4
• Max. RPM: 15000.0
• Motor RPM: 15,000

DY 47820

.4 hp, 12,000 RPM, Geared, Front Exhaust, Locking-Type Female Pad

Includes 51344 Locking-Type Pad (2in diameter). Also accepts 3in diameter pads, sold separately.

Governor-controlled motor maintains speed under load.

• HP: 0.4
• Max. RPM: 12000.0
• Motor RPM: 12,000

DY 47822

.4 hp, 20,000 RPM, Geared, Front Exhaust, Locking-Type Female Pad

Includes 51344 Locking-Type Pad (2in diameter). Also accepts 3in diameter pads, sold separately.

Governor-controlled motor maintains speed under load.

• HP: 0.4
• Max. RPM: 20000.0
• Motor RPM: 20,000

DY 47821

.4 hp, 15,000 RPM, Geared, Front Exhaust, Locking-Type Female Pad

Includes 51344 Locking-Type Pad (2in diameter). Also accepts 3in diameter pads, sold separately.

Governor-controlled motor maintains speed under load.

• HP: 0.4
• Max. RPM: 15000.0
• Motor RPM: 15,000

DY 48205

25,000 RPM, Gearless, Extended Rear Exhaust, 1/4in and 6mm Collets

One-piece spindle keeps all rotating components on the same centerline for reduced run-out, which means lower vibration levels for enhanced operator comfort.

• HP: 0.4
• Max. RPM: 25000.0
• Motor RPM: 25,000

DY 48201

25,000 RPM, Gearless, Rear Exhaust, 1/4in and 6 mm Collets, Extended Muffler

.4 hp Dynabrade Die Grinders are perfect for use on metal, fiberglass, carbon fiber, composites and more! Dynabrade's .4 hp (298 W) Die Grinders are designed for peak efficiency and longer life! Ideal for rapid material removal, deburring, finishing and polishing, these tools represent the finest in Dynabrade quality and innovation!

Integrated Safety-Lock Throttle Lever has a contoured shape for operator comfort, with new dowel-pin that minimizes lever wear. Increased Tool Life due to Unique Pre-Filter that provides extra defense against contaminants in air stream.

• HP: 0.4
• Max. RPM: 25000.0
• Motor RPM: 25,000

DY 48315

12,000 RPM, Spiral-Geared, Rear Exhaust, 1/4in Collet

All models have air passage to continually cool the gear box. gears last longer! Pinion piloted on rotor to reduce run-out. Needle bearing assures proper shaft alignment.

Dual wick lubrication system saturated with gear oil for extended gear life over 700 hours. This helps administer the right amount and keep the gear oil on the metal gears. Highest horsepower and torque levels of any similar competitive product.

• HP: 0.4
• Max. RPM: 12000.0
• Motor RPM: 12,000

DY 48316

15,000 RPM, Spiral-Geared, Rear Exhaust, 1/4in Collet

All models have air passage to continually cool the gear box. gears last longer! Pinion piloted on rotor to reduce run-out. Needle bearing assures proper shaft alignment.

Dual wick lubrication system saturated with gear oil for extended gear life over 700 hours. This helps administer the right amount and keep the gear oil on the metal gears. Highest horsepower and torque levels of any similar competitive product.

• HP: 0.4
• Max. RPM: 15000.0
• Motor RPM: 15,000

DY 48317

20,000 RPM, Spiral-Geared, Rear Exhaust, 1/4in Collet

All models have air passage to continually cool the gear box. gears last longer! Pinion piloted on rotor to reduce run-out. Needle bearing assures proper shaft alignment.

Dual wick lubrication system saturated with gear oil for extended gear life over 700 hours. This helps administer the right amount and keep the gear oil on the metal gears. Highest horsepower and torque levels of any similar competitive product.

• HP: 0.4
• Max. RPM: 20000.0
• Motor RPM: 20,000

DY 48325

25,000 RPM, Gearless, Rear Exhaust, 1/4in and 6 mm Collets, Standard Muffler

.4 hp Dynabrade Die Grinders are perfect for use on metal, fiberglass, carbon fiber, composites and more! Dynabrade's .4 hp (298 W) Die Grinders are designed for peak efficiency and longer life! Ideal for rapid material removal, deburring, finishing and polishing, these tools represent the finest in Dynabrade quality and innovation!

Integrated Safety-Lock Throttle Lever has a contoured shape for operator comfort, with new dowel-pin that minimizes lever wear. Increased Tool Life due to Unique Pre-Filter that provides extra defense against contaminants in air stream.

• HP: 0.4
• Max. RPM: 25000.0
• Motor RPM: 25,000
