Valves and Cylinders

GG 15T454

GG 15Y980

GG 161023

GG 164233

GG 164480

GG 164679

GG 164704

GG 165964

GG 167475

GG 168211

GG 176519

GG 191125

GG 2004186

GG 21535-00

GG 217521

GG 244937

ENDURE VALVE,DISP.,400DEG F,1/2NPT

• Compatible Material: 2K Sealants, Adhesives

GG 247713

SDV15 VALVE, FLEX EXT

Graco 247713 SDV15 Series Oil Control Valve - Flexible Extension - 1/2 in. (13 mm) Inlet - NPT

For standard and heavy-duty applications, both indoor and outdoor, the SDV15 control valves are designed to perform in larger dealerships with longer plumbing runs and greater fluid usage. The control valve is compatible with a wide range of nozzles and fluid extensions and is capable of pumping oil up to 15 gpm (56.8 lpm).

• Lock-on/Lock-off trigger allows hands free operation
• Sturdy cast body designed for use in tough environments
• Inlet 1/2 in. NPT with swivel

• Model: SDV15

• Compatible Material: Oil

• Dispense Type: Manual

• Display Type: N/A

• Extension Type: Flexible

• Includes: Nozzle, Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Operating Temperature (°C): 82
• Maximum Operating Temperature (°F): 180

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (psi): 1500

• Minimum Operating Temperature (°C): -40
• Minimum Operating Temperature (°F): -40

• Outlet Size (cm): 1.905
• Outlet Size (in): 3/4
• Outlet Size (mm): 19.05
• Outlet Thread Gender: Female
• Outlet Thread Type: Straight Thread O-Ring Boss

• Recommended Environment: Indoor, Outdoor

GG 247718

XDV20 VALVE, RIGID

Graco 247718 XDV20 Series Control Valve - Rigid Extension - 1/2 in. (13 mm) Inlet - NPT

For standard and heavy-duty applications, both indoor and outdoor, the XDV20 control valves are designed to perform in larger dealerships with longer plumbing runs and greater fluid usage. The control valve is compatible with a wide range of nozzles and fluid extensions and is capable of pumping oil up to 20 gpm (75.7 lpm).

• Lock-on/Lock-off trigger allows hands free operation
• Sturdy cast body designed for use in tough environments
• Inlet 1/2 in. NPT with swivel

• Model: XDV20

• Compatible Material: Oil, Antifreeze

• Dispense Type: Manual

• Display Type: N/A

• Extension Type: Rigid

• Includes: Nozzle, Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Operating Temperature (°C): 82
• Maximum Operating Temperature (°F): 180

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (psi): 1500

• Minimum Operating Temperature (°C): -40
• Minimum Operating Temperature (°F): -40

• Outlet Size (cm): 2.2225
• Outlet Size (in): 7/8
• Outlet Size (mm): 22.225
• Outlet Thread Gender: Female
• Outlet Thread Type: Straight Thread O-Ring

• Recommended Environment: Indoor, Outdoor

GG 295623

GG 295624

GG 298842

GG 502473

GG SA915005

GG SA916K

GG SN751001
