Dura-Flo NXT 2-Ball Piston Pump, 10:1, De-Icing Exhaust Motor, DataTrak, CS, UHM W/Leather Packings

GG P10ECK

Dura-Flo NXT 2-Ball Piston Pump, 10:1, De-Icing Exhaust Motor, DataTrak, CS, UHM W/Leather Packings

Call for pricing

CHECK-MATE PUMP, 20:1 70 0/060 SS SD

GG P20LSS

CHECK-MATE PUMP, 20:1 70 0/060 SS SD

Graco P20LSS 20:1 - 60cc Check-Mate Pump with NXT 700 Air Motor, Severe Duty Stainless Steel Construction

Graco Supply Pumps reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials to metering and dispensing systems. Maximize your plant&prime, s production capacity.

Application: Long-lasting durability - Check-Mate pumps are a time-tested, proven performer

NXT 700 Air Motor
Low Noise
Modular design for easier maintenance
Highest technology air motor on the market
60cc Check-Mate Lower
Severe Duty coatings on rods and cylinder Extends production time
Standard Threaded Coupler -
Replaceable Seat
Minimizes service costs
Cast Outlet and Inlet Housing
- NEW Xtreme® Coupler
  - Replaceable Outlet Fitting
    - Piston Valve with Floating Piston Seal
      - Replaceable Seat
        Minimizes service costs
        Floating Priming Plate
        Provides uniform flow
        Cast Outlet and Inlet Housing
        Improves structural integrity
        NEW Cartridge Throat Packings
        Allows for easy servicing without removing from ram
        Modular Air Valve
        De-icing controls
        Up to 50% quieter than previous models
        Modular air valve - eliminates stalling, easy-to-repair
        Hard Part Coatings
        Standard Severe Duty™ coating on rods and cylinder maximizes wear life

        Model: Check-Mate
        Ambient/Warm Melt/Hot Melt: Ambient
        Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill
        Fluid Outlet Size (in): 3/4
        Fluid Outlet Thread Gender: Male
        Fluid Outlet Thread Type: NPT
        Includes: Motor, Displacement Pump, Washer Lock (6), Screw
        Material: Stainless Steel
        Maximum Working Pressure (bar): 138
        Maximum Working Pressure (kPa): 13800
        Maximum Working Pressure (MPa): 13.8
        Maximum Working Pressure (psi): 2000
        Power Type: Pneumatic
        Pump Ratio: 20:1

$10,390.00

CHECK-MATE PUMP 36:1 3400/200 CS SD

GG P36LCS

CHECK-MATE PUMP 36:1 3400/200 CS SD

Graco P36LCS 36:1 - 200cc Check-Mate Pump with NXT 3400 Air Motor, Severe Duty Carbon Steel Construction

Application: Long-lasting durability - Check-Mate pumps are a time-tested, proven performer

NXT 3400 Air Motor
Low Noise
Modular design for easier maintenance
Rugged body armor won&prime, t rust or dent
Highest technology air motor on the market
200cc Check-Mate Lower
Severe Duty coatings on rods and cylinder Extends production time
Xtreme Coupler - No tool connection
Quick-disconnect coupler for easy maintenance
Replaceable Seat
Minimizes service costs
Cast Outlet and Inlet Housing
- NEW Xtreme® Coupler
  - Replaceable Outlet Fitting
    - Piston Valve with Floating Piston Seal
      - Replaceable Seat
        Minimizes service costs
        Floating Priming Plate
        Provides uniform flow
        Cast Outlet and Inlet Housing
        Improves structural integrity
        NEW Cartridge Throat Packings
        Allows for easy servicing without removing from ram
        Modular Air Valve
        De-icing controls
        Up to 50% quieter than previous models
        Modular air valve - eliminates stalling, easy-to-repair
        Hard Part Coatings
        Standard Severe Duty™ coating on rods and cylinder maximizes wear life

        Model: Check-Mate
        Ambient/Warm Melt/Hot Melt: Ambient
        Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill
        Fluid Outlet Size (in): 1
        Fluid Outlet Size (mm): 25.4000
        Fluid Outlet Thread Gender: Female
        Fluid Outlet Thread Type: NPT
        Includes: Motor, Displacement Pump, Rod Tie, Adaptor Rod, Coupling Assembly, Cover, Clip, Coupler
        Material: Carbon Steel
        Maximum Working Pressure (bar): 248
        Maximum Working Pressure (kPa): 24800
        Maximum Working Pressure (MPa): 24.8
        Maximum Working Pressure (psi): 3600
        Power Type: Pneumatic
        Pump Ratio: 36:1

$12,950.00

CHECK-MATE PUMP, 40:1 2200/100 CS SD

GG P40LCS

CHECK-MATE PUMP, 40:1 2200/100 CS SD

Graco P40LCS 40:1 - 100cc Check-Mate Pump with NXT 2200 Air Motor, Severe Duty Carbon Steel Construction

Application: Long-lasting durability - Check-Mate pumps are a time-tested, proven performer

NXT 2200 Air Motor
Low Noise
Modular design for easier maintenance
Rugged body armor won&prime, t rust or dent
Highest technology air motor on the market
100cc Check-Mate Lower
Severe Duty coatings on rods and cylinder Extends production time
Xtreme Coupler - No tool connection
Quick-disconnect coupler for easy maintenance
Replaceable Seat
Minimizes service costs
Cast Outlet and Inlet Housing
- NEW Xtreme® Coupler
  - Replaceable Outlet Fitting
    - Piston Valve with Floating Piston Seal
      - Replaceable Seat
        Minimizes service costs
        Floating Priming Plate
        Provides uniform flow
        Cast Outlet and Inlet Housing
        Improves structural integrity
        NEW Cartridge Throat Packings
        Allows for easy servicing without removing from ram
        Modular Air Valve
        De-icing controls
        Up to 50% quieter than previous models
        Modular air valve - eliminates stalling, easy-to-repair
        Hard Part Coatings
        Standard Severe Duty™ coating on rods and cylinder maximizes wear life

        Model: Check-Mate
        Ambient/Warm Melt/Hot Melt: Ambient
        Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill
        Fluid Outlet Size (in): 3/4
        Fluid Outlet Thread Gender: Male
        Fluid Outlet Thread Type: NPT
        Includes: Motor, Displacement Pump
        Material: Carbon Steel
        Maximum Working Pressure (bar): 280
        Maximum Working Pressure (kPa): 28000
        Maximum Working Pressure (MPa): 28
        Maximum Working Pressure (psi): 4000
        Power Type: Pneumatic
        Pump Ratio: 40:1
