Pumps

BB PX1304-5P

BB PX1304-8P

EP PACG3002SB

Enerpac PACG Air Hydraulic Pumps are for designed for intermittent to medium duty workholding applications up to 5,000 psi. Valve mount options include, remote, and mountings for DO3 and VP valves.

Enerpac Turbo II Air Over Hydraulic Pumps generate the hydraulic pressure you need using the air pressure you have available. The Air Saver Piston reduces air consumption, and the pump can start at low pressures from 50-125 psi.

Turbo II Air-Hydraulic Pumps are best suited to medium or lower cycle applications. They provide the power and speed needed for simple clamping circuits and mostly single acting tools. At only 75 dBA, the Turbo II Series helps to keep the noise level to a minimum.

Choose from a range with maximum working pressure of either 5,000 or 10,000psi, and various reservoir capacities from 116 - 462 in3 (2100 - 7500 cm3).

Turbo II Air Over Hydraulic Pump Series :

• PATG - Treadle for foot or hand operation
• PARG - Pendant Operation
• PAMG - Manual lever operated. For double-acting applications
• PACG - For remote valve mount. For workholding, 5000 psi (350 bar).
• PASG - Includes mount for a single DO3 Valve. For workholding, 5000 psi (350 bar).

• Type: Hydraulic Pump
• Max Bar: 350
• Max PSI: 5000

• Product Group: Pumps
• Product Line: Work Holding Tools
• Series: PACG
• SubTypes: Air Pump

• On-demand stall-restart operation maintains system pressure, providing clamping security
• External adjustable pressure relief valve (behind sight glass)
• Internal pressure relief valve provides overload protection
• Reduced noise level to 75 dBA
• Operating air pressure: 50-125 psi - enables pump to start at low air pressure**
• Hydraulic to air ratio: 45:1
• Reinforced heavy-duty lightweight reservoir for applications in tough environments
• Five valve mounting options provide flexibility in setup and operation
• Fully serviceable air motor assembly
• User supplied valves

** NOTE: From 50-125 psi air inlet pressure. Performance is significantly diminished below 50 psi. Performance may vary compared to listed values due to seal friction, internal pressure drops and manufacturing tolerances. Be sure to allow some flexibility on air inlet pressure.

GG 01/0038-R/98

GG 01/0045/98

GG 01/0084/98

GG 01/0086/99N

GG 01/0092/89

GG 01/0092-P/89

GG 01/0093/89

GG 01/0093-P/89

GG 01/0094-1/89

GG 01/0094-P/89

GG 01/0151-2/98

GG 01/0152-1/87

GG 01/0670/97

GG 01/1666/11

GG 01/2706-2.0/99

GG 01/2707-2/97

GG 01/2728/98

GG 01/2803/98

GG 01/2805-1/11

GG 01/2825-2/87

GG CM152B

CHECK-MATE SUPPLY UNIT, 63:1, 0 V, S20 CART, 20L

Graco CM152B 63:1 Ratio 20 L S20 Cart Mounted Supply Unit

Graco Supply Systems reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials from pails or drums to metering and dispensing systems.

• 20 liter (5 gal) pail sizes provides the same proven technologies as the larger systems, but with small NXT Air Motors
• Graco S20c - Same as the S20, but includes a cart
• Industry-first controls give you immediate and important information at the touch of a button
• Platen wipers can be replaced in seconds
• Pumps quick-disconnect coupler, turnbuckle mount and pump cartridge packings let you service the pump without removing it from the ram
• High-quality, durable parts reduce maintenance time, maximize uptime

• Model: Check-Mate
• Series: S20c

• Ambient/Warm Melt/Hot Melt: Ambient
• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill

• Container Type: Pail

• Material Container Volume (gal): 5.3
• Material Container Volume (l): 20

• Maximum Air Inlet Pressure (bar): 8.62
• Maximum Air Inlet Pressure (kg/cm²): 8.79
• Maximum Air Inlet Pressure (kPa): 862
• Maximum Air Inlet Pressure (psi): 125

• Maximum Flow Rate (GPM): 1.6
• Maximum Flow Rate (L/min): 6.1

• Maximum Fluid Pressure (bar): 434.4
• Maximum Fluid Pressure (kPa): 43440
• Maximum Fluid Pressure (psi): 6300

• Maximum Fluid Pressure (bar): 434.4
• Maximum Fluid Pressure (kPa): 43440
• Maximum Fluid Pressure (psi): 6300

• Maximum Height (cm): 228.6
• Maximum Height (ft): 7.5
• Maximum Height (in): 90
• Maximum Height (m): 2.29
• Maximum Height (mm): 2286

• Maximum Operating Temperature (°C): 49
• Maximum Operating Temperature (°F): 120

• Maximum Working Pressure (bar): 441
• Maximum Working Pressure (kPa): 44100
• Maximum Working Pressure (MPa): 44.1
• Maximum Working Pressure (psi): 6300

• Minimum Height (cm): 165.1
• Minimum Height (ft): 5.42
• Minimum Height (in): 65
• Minimum Height (m): 1.65
• Minimum Height (mm): 1651

• Overall Depth (cm): 66.1
• Overall Depth (in): 26
• Overall Depth (mm): 661

• Overall Width (cm): 56.2
• Overall Width (in): 22.1
• Overall Width (mm): 562

• Power Type: Pneumatic

• Pump Ratio: 63:1
• Pump Type: Priming Piston

• Ram Material: Carbon Steel

GG CM1T4F

CHECK-MATE SUPPLY UNIT, 63:1, 0 VOLT, D60, 20L

Graco CM1T4F Supply Unit, Check-Mate, 63:1, S/S, Severe Duty, 3 in. D60 Ram, Integrated Air Controls, 20L S/S Flat Platen, Single PTFE Wiper

Graco Supply Systems reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials from pails or drums to metering and dispensing systems.

• 60 liter (16-gal) pail sizes provides the same proven technologies as the larger systems, but with small NXT Air Motors
• Graco D60 - Provides higher down-force and 60-liter pail capacity
• Industry-first controls give you immediate and important information at the touch of a button
• Platen wipers can be replaced in seconds
• Pumps quick-disconnect coupler, turnbuckle mount and pump cartridge packings let you service the pump without removing it from the ram
• High-quality, durable parts reduce maintenance time, maximize uptime

• Model: Check-Mate
• Series: D60

• Ambient/Warm Melt/Hot Melt: Ambient
• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill

• Container Type: Pail
• Control Panel Material: N/A

• Material Container Volume (gal): 5.3
• Material Container Volume (l): 20

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kg/cm²): 10.55
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Flow Rate (GPM): 1.6
• Maximum Flow Rate (L/min): 6.1

• Maximum Fluid Pressure (bar): 434.4
• Maximum Fluid Pressure (kPa): 43440
• Maximum Fluid Pressure (psi): 6300

• Maximum Fluid Pressure (bar): 434.4
• Maximum Fluid Pressure (kPa): 43440
• Maximum Fluid Pressure (psi): 6300

• Maximum Height (cm): 226.06
• Maximum Height (ft): 7.42
• Maximum Height (in): 89
• Maximum Height (m): 2.26
• Maximum Height (mm): 2260.6

• Maximum Operating Temperature (°C): 49
• Maximum Operating Temperature (°F): 120

• Maximum Working Pressure (bar): 441
• Maximum Working Pressure (kPa): 44100
• Maximum Working Pressure (MPa): 44.1
• Maximum Working Pressure (psi): 6300

• Minimum Height (cm): 149.86
• Minimum Height (ft): 4.92
• Minimum Height (in): 59
• Minimum Height (m): 1.5
• Minimum Height (mm): 1498.6

• Overall Depth (cm): 45.72
• Overall Depth (in): 18
• Overall Depth (mm): 457.2

• Overall Width (cm): 71.12
• Overall Width (in): 28
• Overall Width (mm): 711.2

• Power Type: Pneumatic

• Pump Ratio: 63:1
• Pump Type: Priming Piston

• Ram Material: Carbon Steel
