Pumps

BB 107074-21

BB 41-818121

BB GEM2-D1S1G51

BB GEM2-D2D1050

BB MOD-104009-1

BB MX1212PU-0DW0000

BB MX1212PU-QDW1S25

BB MX1212UC-00C1S00

BB MX1212UC-QDW1S25

BB MX1231PU

BB MX1231PU-0DC1S00

BB MX1231PU-PDC1S50

BB MX3523PU-SAH

BB MX3536PU-SAH

BB MX3560PU-SAC1S55

BB MX412PP-QDC1S50

BB MX412UC

BB MX412UC-0DW0000

BB MX412UC-QDC1S25

GG 01/0085/99N

GG 0897M-HP

GG CM114C

CHECK-MATE SUPPLY UNIT, 40:1, 0 VOLT, D60, 20L

Graco CM114C 40:1 Ratio 20 L D60 Supply Unit

Graco Supply Systems reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials from pails or drums to metering and dispensing systems.

• 60 liter (16-gal) pail sizes provides the same proven technologies as the larger systems, but with small NXT Air Motors
• Graco D60 - Provides higher down-force and 60-liter pail capacity
• Industry-first controls give you immediate and important information at the touch of a button
• Platen wipers can be replaced in seconds
• Pumps quick-disconnect coupler, turnbuckle mount and pump cartridge packings let you service the pump without removing it from the ram
• High-quality, durable parts reduce maintenance time, maximize uptime

• Model: Check-Mate
• Series: D60

• Ambient/Warm Melt/Hot Melt: Ambient
• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill

• Container Type: Pail
• Control Panel Material: N/A

• Material Container Volume (gal): 5.3
• Material Container Volume (l): 20

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kg/cm²): 10.55
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Flow Rate (GPM): 1.6
• Maximum Flow Rate (L/min): 6.1

• Maximum Fluid Pressure (bar): 275.8
• Maximum Fluid Pressure (kPa): 27580
• Maximum Fluid Pressure (psi): 4000

• Maximum Fluid Pressure (bar): 275.8
• Maximum Fluid Pressure (kPa): 27580
• Maximum Fluid Pressure (psi): 4000

• Maximum Height (cm): 226.06
• Maximum Height (ft): 7.42
• Maximum Height (in): 89
• Maximum Height (m): 2.26
• Maximum Height (mm): 2260.6

• Maximum Operating Temperature (°C): 49
• Maximum Operating Temperature (°F): 120

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (MPa): 28
• Maximum Working Pressure (psi): 4000

• Minimum Height (cm): 149.86
• Minimum Height (ft): 4.92
• Minimum Height (in): 59
• Minimum Height (m): 1.5
• Minimum Height (mm): 1498.6

• Overall Depth (cm): 45.72
• Overall Depth (in): 18
• Overall Depth (mm): 457.2

• Overall Width (cm): 71.12
• Overall Width (in): 28
• Overall Width (mm): 711.2

• Power Type: Pneumatic

• Pump Ratio: 40:1
• Pump Type: Priming Piston

• Ram Material: Carbon Steel

GG CM155B

CHECK-MATE SUPPLY UNIT, 63:1, 0 VOLT, D200, 20L

Graco CM155B 63:1 Ratio 20 L D200 Supply Unit

Graco Supply Systems reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials from pails or drums to metering and dispensing systems.

• For large drums up to 200 liter (55 gal)
• Graco D200 - For high-volume in-plant applications
• Industry-first controls give you immediate and important information at the touch of a button
• Platen wipers can be replaced in seconds
• Pumps quick-disconnect coupler, turnbuckle mount and pump cartridge packings let you service the pump without removing it from the ram
• High-quality, durable parts reduce maintenance time, maximize uptime

• Model: Check-Mate
• Series: D200

• Ambient/Warm Melt/Hot Melt: Ambient
• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill

• Container Type: Pail
• Control Panel Material: N/A

• Material Container Volume (gal): 5.3
• Material Container Volume (l): 20

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kg/cm²): 10.55
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Flow Rate (GPM): 1.6
• Maximum Flow Rate (L/min): 6.1

• Maximum Fluid Pressure (bar): 434.4
• Maximum Fluid Pressure (kPa): 43440
• Maximum Fluid Pressure (psi): 6300

• Maximum Fluid Pressure (bar): 434.4
• Maximum Fluid Pressure (kPa): 43440
• Maximum Fluid Pressure (psi): 6300

• Maximum Height (cm): 259.9
• Maximum Height (ft): 8.53
• Maximum Height (in): 102.3
• Maximum Height (m): 2.6
• Maximum Height (mm): 2599

• Maximum Operating Temperature (°C): 49
• Maximum Operating Temperature (°F): 120

• Maximum Working Pressure (bar): 441
• Maximum Working Pressure (kPa): 44100
• Maximum Working Pressure (MPa): 44.1
• Maximum Working Pressure (psi): 6300

• Minimum Height (cm): 164.6
• Minimum Height (ft): 5.4
• Minimum Height (in): 64.8
• Minimum Height (m): 1.65
• Minimum Height (mm): 1646

• Overall Depth (cm): 63.5
• Overall Depth (in): 25
• Overall Depth (mm): 635

• Overall Width (cm): 106.7
• Overall Width (in): 42
• Overall Width (mm): 1067

• Power Type: Pneumatic

• Pump Ratio: 63:1
• Pump Type: Priming Piston

• Ram Material: Carbon Steel

GG CM165A

GG CM1T2F

CHECK-MATE SUPPLY UNIT, 63:1, 0 V, S20 CART, 20L

Graco CM1T2F Supply Unit, Check-Mate, 63:1, S/S, Severe Duty, 3 in. S20c Ram, Integrated Air Controls, 20L S/S Flat Platen, Single PTFE Wiper

Graco Supply Systems reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials from pails or drums to metering and dispensing systems.

• 20 liter (5 gal) pail sizes provides the same proven technologies as the larger systems, but with small NXT Air Motors
• Graco S20c - Same as the S20, but includes a cart
• Industry-first controls give you immediate and important information at the touch of a button
• Platen wipers can be replaced in seconds
• Pumps quick-disconnect coupler, turnbuckle mount and pump cartridge packings let you service the pump without removing it from the ram
• High-quality, durable parts reduce maintenance time, maximize uptime

• Model: Check-Mate
• Series: S20c

• Ambient/Warm Melt/Hot Melt: Ambient
• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill

• Container Type: Pail

• Material Container Volume (gal): 5.3
• Material Container Volume (l): 20

• Maximum Air Inlet Pressure (bar): 8.62
• Maximum Air Inlet Pressure (kg/cm²): 8.79
• Maximum Air Inlet Pressure (kPa): 862
• Maximum Air Inlet Pressure (psi): 125

• Maximum Flow Rate (GPM): 1.6
• Maximum Flow Rate (L/min): 6.1

• Maximum Fluid Pressure (bar): 434.4
• Maximum Fluid Pressure (kPa): 43440
• Maximum Fluid Pressure (psi): 6300

• Maximum Fluid Pressure (bar): 434.4
• Maximum Fluid Pressure (kPa): 43440
• Maximum Fluid Pressure (psi): 6300

• Maximum Height (cm): 228.6
• Maximum Height (ft): 7.5
• Maximum Height (in): 90
• Maximum Height (m): 2.29
• Maximum Height (mm): 2286

• Maximum Operating Temperature (°C): 49
• Maximum Operating Temperature (°F): 120

• Maximum Working Pressure (bar): 441
• Maximum Working Pressure (kPa): 44100
• Maximum Working Pressure (MPa): 44.1
• Maximum Working Pressure (psi): 6300

• Minimum Height (cm): 165.1
• Minimum Height (ft): 5.42
• Minimum Height (in): 65
• Minimum Height (m): 1.65
• Minimum Height (mm): 1651

• Overall Depth (cm): 66.1
• Overall Depth (in): 26
• Overall Depth (mm): 661

• Overall Width (cm): 56.2
• Overall Width (in): 22.1
• Overall Width (mm): 562

• Power Type: Pneumatic

• Pump Ratio: 63:1
• Pump Type: Priming Piston

• Ram Material: Carbon Steel
