INGERSOLL-RAND IR TOOL S12880

IR 33SKA

Large Air Drill, Reversible Roll Throttle, 300 RPM, 3HP, No. 3 Morse Taper

Description: We have several series of large drills to meet your construction and industrial needs. The 22 Series works best for general applications, while the 33, 44, and 551 Series are better suited for opening and closing large valves, or for drilling larger holes between 1 inch (25mm) and 3 inches (76mm).

Features And Benefits:

• Side Exhaust: All the Ingersoll Rand large drills come with side exhaust to keep exhaust air pointed away from you and away from your work.
• Governed Motor: No matter which Ingersoll rand large drill series you're interested in, you can expect a governed motor that regulates air intake to keep these drills working at the peak of their power curve.

Product Application and Uses:

These air drills are designed for heavy duty drilling and reaming between 1 inch (25mm) and 3 inches (76mm).

• Actuation/Throttle Type/Switch Type: Reversible, Roll
• Air Consumption (cfm): 85
• Air Consumption (l/min): 2407
• Air Inlet: 1/2in NPT

• Capacity in Steel Drilling (in): 1-1/4
• Capacity in Steel Reaming (in): 1

• Color: Beige
• Configuration/Handle Type: T-handle
• Duty Rating: Super Duty

• Exhaust Location: Side

• Height Over Spindle (in): 14
• Length of Feed (in): 4.25

• Max Free Speed (rpm): 300
• Max Power (hp): 3
• Min Hose Size (in): 3/4

• Power Source: Air Powered

• Product Weight (lb): 25.75
• Reversible: Reversible

• Side to Center Distance (in): 1.88
• Side to Center Distance (mm): 48

• Sound Pressure/Power Db(A): 98.8 / 109.8
• Spindle Type: No. 3 Morse Taper

• Vibration Level (m/s2): <2.5
• Warranty: 1-year

• Lubrication: 50P

IR 328B

Dual Action Geared Orbital Air Sander, 8" Adhesive Pad, 5/32" Orbit, 825 RPM, 0.25 HP

Description: The smooth strength and power of the dual-action geared air sander lets you remove heavy material and body filler on large, flat surfaces, leaving a clean, swirl-free finish.

Features And Benefits:

• Dual Action: The smooth strength and power of the dual-action geared air sander lets you remove heavy material and body filler on large, flat surfaces, leaving a clean, swirl-free finish.
• Balanced: Ball-bearing construction improves balance, reduces vibration, and ensures a longer life.
• Control: With variable speed and a dual-action pad motion, you have full control of your tool's performance.
• Specifications: 5/32" Orbit, .25 HP, 825 RPM, 8" Pad, Avg air consumption 4 cfm.

Product Application and Uses:

These orbital sanders are designed for smoothing and sanding paint, fiberglass, wood and body filler.

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Lever
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/16" -24 Thread
• Average Air Consumption (cfm): 4
• Average Air Consumption (l/min): 113

• Color: Red
• Configuration/Handle Type: Palm
• Dust Collection Type: None
• Duty Rating: Maintenance Duty

• Max Free Speed (rpm): 825
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8
• Motor: Air Gear Motor

• Number of Vacuum Holes: 0
• Orbit Diameter (in): 5/32
• Pad Diameter or Size (in): 8
• Power Source: Air Powered

• Product Weight (lb): 4.7
• Rated Power (hp): 0.25

• Sound Pressure/Power Db(A): 82.7 / 93.7
• Speed Setting: Variable Speed

• Vacuum: None
• Warranty: 1-year

• Parts: 328B-825-8

IR 328B-A109

Housing Cover Assembly for Ingersoll Rand 328B Sander

IR 326

Air Cut-off Tool, Type 41, 20000 RPM, 2.3 Lbs.

Description: This heavy-duty Air Cut-Off Tool was built for hard work. With a specialty of exhaust replacement, you can cut off mufflers and tailpipes quickly, efficiently, and quietly. Great for use in any vehicle repair market.

Features And Benefits:

• Lock-Out Lever: This tool contains a unique system that prevents accidental throttle operation by utilizing a spring-loaded latch that resets each time the lever is released.
• Performance: With a guard that adjusts easily and quickly, and the ability to cut in either direction, your performance and productivity will soar when using this product.
• Reliability: Built to last, you can be sure the 326 Air Cut-Off Tool will perform reliably whenever you pull the trigger.

Product Application and Uses:

Cut Off Mufflers, Cut Off Tail Pipes, Cutting Sheet metal, Cutting Bolts And Nuts

• Includes: Tool (1), Wrenches (2), Manual Kit
• Actuation/Throttle Type/Switch Location: Top
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Load (cfm): 25
• Air Consumption @ Load (l/min): 708
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Average Air Consumption (cfm): 10
• Average Air Consumption (l/min): 283

• Color: Silver
• Configuration/Handle Type: Straight
• Duty Rating: Heavy Duty

• Exhaust Location: Front

• Guard Material: Steel
• Handle Material: Composite
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 20000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Product Length (in): 8.88

• Product Width (in): 3.8
• Product Height (in): 4.3
• Product Weight (lb): 2.3
• Reversible: Reversible

• Sound Pressure/Power Db(A): 94.3 / 107.3

• Warranty: 1-year
• Wheel Diameter (in): 2.88
• Wheel Thickness (in): 1/8
• Wheel Type: Type 41

• Accessories: 9520

• Lubrication: 50G
• Lubrication: 50P

IR 325SC4A

IR 328B-825-8

8" Dual Action Backing Pad for Ingersoll Rand 328B Series Air Sander

Product Application and Uses:

For use with Ingersoll Rand 328B Series Air Orbital Sander

• Arbor/Collet: 5/16" -24 Thread

• Max Free Speed (rpm): 10000

• Number of Vacuum Holes: 0
• Pad Diameter or Size (in): 8
• Pad Face: Adhesive

• For Use With: 328B

IR 329-338-5

IR 325A-354

Die Cutter for Ingersoll Rand 325B Air Nibbler

IR 325B

Air Nibbler, 18 Gauge Capacity, 4200 Strokes/Min

Description: Instead of shearing or sawing, the 325B Air Nibbler "nibbles" at metals, giving you better control and accuracy when cutting metals up to 18 gauge thicknesses at more than 6 feet per minute.

Features And Benefits:

• Performance: With trigger actuation, this tool is featherable for variable speed and control.
• Reliability: Engineered for top reliability, you can be sure this tool delivers the same power as it did on day one. Comes with a 1-year warranty.
• Center Cut: With this Nibbler you're able to begin cuts in the center of your metal without distorting the edges of your material.

Product Application and Uses:

Designed to cut mild steel aluminum, tin and other materials up to 18 gauge (1.2 mm).

• Includes: Tool, Manuals
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Load (cfm): 17
• Air Consumption @ Load (l/min): 481
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Average Air Consumption (cfm): 4
• Average Air Consumption (l/min): 113

• Color: Silver
• Configuration/Handle Type: Right Angle
• Duty Rating: General Duty

• Exhaust Location: Front

• Housing Material: Aluminum

• Max Free Speed (rpm): 4200
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Product Length (in): 7.3

• Product Width (in): 5.35
• Product Height (in): 4.52
• Product Weight (lb): 2.1

• Sound Pressure/Power Db(A): 96 / 107
• Steel Capacity (Gauge): 18
• Strokes (per min): 4200

• Vibration Level (m/s2): 15.9
• Warranty: 1-year

• Lubrication: 10P
• Parts: 325A-350

IR 327LS-A

Air Tire Buffer, 7/16" Hex Quick Change, 3,000 RPM, 0.5 HP

Description: Ideal for use in any vehicle repair market, this tire buffer will make quick work of patchwork, recapping, tire scuffing, and cleaning tire moldings.

Features And Benefits:

• Rear Exhaust: With a rear exhaust, you can direct debris away from your workspace, giving you unrestricted access to your job.
• Safety: Featuring a special lock-out lever technology, you never have to worry about accidental throttle operation.
• Comfort: Easily fitting in your hand, this 1.4 lb. lightweight tool will work hard so you don't have to.

Product Application and Uses:

Ideal for use in any vehicle repair market, this tire buffer will make quick work of patchwork, recapping, tire scuffing, and cleaning tire moldings.

• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Average Air Consumption (cfm): 12.5
• Average Air Consumption (l/min): 355

• Chuck Capacity/Bit Capacity (in): 7/16
• Color: Silver
• Configuration/Handle Type: Straight
• Drive Type: Hex

• Exhaust Location: Rear

• Housing Material: Aluminum

• Max Free Speed (rpm): 3000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 8.5

• Product Width (in): 1.6
• Product Height (in): 2.7
• Product Weight (lb): 1.4
• Rated Power (hp): 0.5
• Retainer Type: Quick Change

• Sound Pressure/Power Db(A): 85/96
• Standards/Certifications: CE

• Vibration Level (m/s2): 1.7
• Warranty: 1-year

• Lubrication: 50P
• Parts: 327LS-A-1
• Parts: 327LS-A-305

• Parts: 327LS-A-949
• Parts: 327LS-A-K284

IR 329-321

Work Guide for Ingersoll Rand 429 Reciprocating Saw

IR 324-700-6

6 Eraser Wheel Pads for Ingersoll Rand 324 Series Adhesive Removal Tool

Description: Rubber eraser pad accessory used to remove pinstripe tape, double-sided tape, adhesive and molding without damage to paint or surface.

Product Application and Uses:

For use with Ingersoll Rand 324 Series adhesive removal tool

• Includes: 1 eraser pad

• For Use With: 324
• For Use With: 324-1

IR 329-336

IR 33235

IR 33387-1

IR 33440

IR 328B-840

IR 328B-11

IR 3372370

IR 341A2M

Pneumatic Backfill Tamper, 5.75" Round Malleable Butt, 4" Stroke, 1-5/8" Bore

Description: With dual-action sand wipers, a built-in muffler and a side exhaust, this tool is built for heavy use. These tools are commonly used by municipal and utility crews for compacting around both utility line repairs and new installations such as street lights, fire hydrants, and telephone poles prior to pouring concrete. In addition, this proven tool is ideal for backfilling around foundations or other tight areas.

Features And Benefits:

• Durability: With a plated piston and front-end seal to protect your tool, this Backfill Tamper can be used in the toughest environments. The sand-wiper seal prevents dirt and grit from getting inside the tool.
• Reliability: Thanks to a built-in lubricator, these tools are built to run smoothly and last, while extending overall operating life. Comes with a 1-year warranty.
• Power: Thanks to its high-power output, you'll be able to breeze through any job.
• Access: This tool is as lightweight as it is powerful making compact spaces easy to reach

Product Application and Uses:

These tools are commonly used by municipal and utility crews for compacting around both utility line repairs and new installations such as street lights, fire hydrants, and telephone poles prior to pouring concrete. In addition, this proven tool is ideal for backfilling around foundations or other tight areas.

• Includes: Malleable Butt
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 29
• Air Consumption @ Load (l/min): 821
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Blows per Min: 1550
• Bore Diameter (in): 1-5/8
• Butt Diameter (in): 5.75
• Butt Material: Malleable/ Steel
• Butt Shape: Round

• Color: Beige
• Configuration/Handle Type: Straight
• Duty Rating: Super Duty

• Exhaust Location: Side

• Height Over Spindle (in): 6.7
• Housing Material: Steel
• Inline Oilers: Yes

• Max Pressure (bar): 6.2
• Min Hose Size (in): 1/2
• Muffler: Built In

• Power Source: Air Powered
• Product Length (in): 52.75

• Product Width (in): 7.56
• Product Weight (lb): 15.8
• Retainer Type: Latch

• Shank Opening: 7/8" Tapered Rod
• Side to Center Distance (in): 3.6
• Side to Center Distance (mm): 91

• Special Features: Time Tested Valve Design, Round Piston Rod, Built In Muffler, Optional Front End Butts Available.
• Standards/Certifications: Standards
• Steels: Yes
• Stroke Length (in): 4

• Warranty: 1-year

• Accessories: 34SR-383
• Accessories: 34SR-M183-5 3/4

• Lubrication: 10G
• Lubrication: 10P
• Parts: 241SR-122
• Parts: 341SR-312

• Parts: 34SR-85

IR 325A-350

Cutter for Ingersoll Rand 325 Series Air Nibbler

• For Use With: 325B

IR 327-A

3/8" Air Tire Buffer, 23,000 RPM, 0.5HP

Description: Ideal for use in any vehicle repair market, this tire buffer will make quick work of patchwork, recapping, tire scuffing, and cleaning tire moldings.

Features And Benefits:

• Rear Exhaust: With a rear exhaust, you can direct debris away from your workspace, giving you unrestricted access to your job.
• Safety: Featuring a special lock-out lever technology, you never have to worry about accidental throttle operation.
• Comfort: Easily fitting in your hand, this lightweight tool weighs less than 2 lbs. and will work hard so you don't have to.

Product Application and Uses:

Ideal for use in any vehicle repair market, this tire buffer will make quick work of patchwork, recapping, tire scuffing, and cleaning tire moldings.

• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Average Air Consumption (cfm): 5
• Average Air Consumption (l/min): 142

• Chuck Capacity/Bit Capacity (in): 3/8
• Chuck Type: Keyed Chuck
• Color: Silver
• Configuration/Handle Type: Straight

• Exhaust Location: Rear

• Housing Material: Aluminum

• Max Free Speed (rpm): 23000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 7.76

• Product Width (in): 1.6
• Product Height (in): 2.7
• Product Weight (lb): 1.8
• Rated Power (hp): 0.5

• Sound Pressure/Power Db(A): 92/103
• Standards/Certifications: CE

• Vibration Level (m/s2): 1.2
• Warranty: 1-year

• Lubrication: 50P
• Parts: 327-A-253

IR 341SR-17

IR 341SR-30

Seal for Ingersoll Rand 341, 441 Series Air Tamper

IR 341SR-31

Seal for Ingersoll Rand 341, 441 Series Air Tamper

IR 341SR-311

Silencer for Ingersoll Rand 341 Series, 441 Series Air Percussive Tamper

IR 341SR-312

Seal for Ingersoll Rand 341, 441 Series Air Tamper

Product Application and Uses:

For use with Ingersoll Rand 341 Series Air Tamper

• For Use With: 341A2M

IR 3445MAX

Air Angle Grinder/Cut-off Tool, 4.5" Wheel, 12,000 RPM, 0.88 HP, 5/8" -11 Thread, Rear Exhaust

Description: The MAX Series family of angle grinders has a tool to meet your needs, whether you're looking for a 4.5 or 5-inch option. The built-in lubricating wick optimizes the life of your angle gear set, while the safety guard protects you from debris, sparks and abrasives while you work.

Features And Benefits:

• Max Power: The 4-1/2" wheel 3445MAX grinder delivers maximum power, productivity, comfort, and reliability to tackle the toughest material removal jobs in metalworking, construction, and more.
• Work Faster, Safer: The .88 HP air motor with 12,000 RPM delivers the power you need and the internal governor maximizes speed under the load, increasing the rate of material removal.
• Built-in lubrication: Its built-in lubricating wick optimizes the life of the angle gear set by improving lubrication to the bevel and pinion gear set.
• Lightweight Comfort: The enhanced grip design increases operator comfort for extended use, and its lightweight construction, weighing less than 3.5 lbs., delivers the best power-to-weight ratio in its class.
• Material Compatibility: Cut, grind, or polish a variety of materials, including metal and concrete, with confidence thanks to the superior comfort and power.

Product Application and Uses:

Rust And Material Removal

• Includes: Wheel Guard, Flange, Nut and Wheel Nut Wrenches
• Actuation/Throttle Type/Switch Location: Bottom
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 41
• Air Consumption @ Load (l/min): 1161
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/8" -11 Thread
• Average Air Consumption (cfm): 10
• Average Air Consumption (l/min): 292

• Bearing Type: Ball Bearing

• Color: Grey
• Configuration/Handle Type: Right Angle
• Duty Rating: Heavy Duty

• Exhaust Location: Rear

• Grinder Type: Angle Grinder
• Height Over Spindle (in): 2.8
• Housing Material: Composite
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 12000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 9.31

• Product Width (in): 3.41
• Product Height (in): 6.81
• Product Weight (lb): 3.44
• Rated Power (hp): 0.88
• Right Angle Length (in): 1.9
• Right Angle Length (mm): 48

• Side to Center Distance (in): 1.3
• Side to Center Distance (mm): 33

• Sound Pressure/Power Db(A): 79.6 / 90.6
• Standards/Certifications: Ansi/Cagi B 186.1-1984, Ansi B186.1-2006, Bs En 792-7-2001

• Vibration Level (m/s2): 6.3
• Vibration Uncertainy K* (m/s2): 2.2
• Warranty: 1-year
• Wheel Diameter (in): 4.5
• Wheel Thickness (in): 1/4
• Wheel Type: Type 27 (Grinding) Type 1, 27, 41, 42 (Cutting)

• Lubrication: 10G
• Lubrication: 10P
• Parts: MG1-42-4

IR 3445MAX-M

Angle Air Grinder/Cut-off Tool, 4.5" Wheel, 12,000 RPM, 0.88 HP, M14 Arbor, Rear-Piped Away Exhaust

In keeping with the tradition of Ingersoll Rand MAX tools, the MAX series Angle Grinders deliver MAX Power, MAX Productivity, MAX Comfort and improved reliability needed to tackle the toughest material removal jobs. MAX Series Angle Grinders gives you MAX performance for the daily grinding.

Includes:

Product Application/Uses:

Features and Benefits:

• Comfort: With a lightweight composite housing and ergonomic design, the Max Series Angle Grinders are easier to work with for long periods of time.
• Power: With an ideal power-to-weight ratio, the Max Series Angle Grinders are great for high-performance material removal.
• Versatile: The Max Series Angle Grinders are a versatile set of tools you can use in most major markets, from vehicle repair and body work to construction and metal fabrication.
• 1-year warranty.

Configuration/Handle Type: Right Angle

Max Free Speed (rpm): 12000

IR 345MAX

Angle Air Grinder/Cut-off Tool, 5" Wheel, 12,000 RPM, 0.88 HP, 5/8" -11 Thread, Rear Exhaust

Description: In keeping with the tradition of Ingersoll Rand MAX tools, the MAX series Angle Grinders deliver MAX Power, MAX Productivity, MAX Comfort and improved reliability needed to tackle the toughest material removal jobs. MAX Series Angle Grinders gives you MAX performance for the daily grinding.

Features And Benefits:

• Comfort: With a lightweight composite housing and ergonomic design, the Max Series Angle Grinders are easier to work with for long periods of time.
• Power: With a .88 HP motor, 12,000 RPM and weighing less than 3.5 lbs., the 345MAX has an ideal power-to-weight ratio. The Max Series Angle Grinders are great for high-performance material removal.
• Versatile: The Max Series Angle Grinders are a versatile set of tools you can use in most major markets, from vehicle repair and body work to construction and metal fabrication. Cut, grind, or polish a variety of materials, including metal and concrete, with confidence thanks to the superior comfort and power.
• Built-in lubrication: Its built-in lubricating wick optimizes the life of the angle gear set by improving lubrication to the bevel and pinion gear set.

Product Application and Uses:

These air grinders are designed for material removal or cutting off using a rotated abrasive wheel in most major markets, from vehicle repair and body work to construction and metal fabrication.

• Includes: Tool, Spanner wrench, Large Wrench, Small Wrench, Allen Wrenches (2), Piped Away Exhaust
• Actuation/Throttle Type/Switch Location: Handle
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Free Speed (cfm): 10
• Air Consumption @ Free Speed (l/min): 283
• Air Consumption @ Load (cfm): 41
• Air Consumption @ Load (l/min): 1161
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/8" -11 Thread
• Average Air Consumption (cfm): 10
• Average Air Consumption (l/min): 292

• Bearing Type: Needle Bearing
• Bearing Type: Ball Bearing

• Color: Grey
• Configuration/Handle Type: Right Angle
• Duty Rating: Maintenance Duty

• Exhaust Location: Rear

• Grinder Type: Angle Grinder
• Guard Material: Steel
• Handle Material: Composite
• Height Over Spindle (in): 2.8
• Housing Material: Composite
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 12000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 9.6

• Product Width (in): 5.2
• Product Height (in): 5
• Product Weight (lb): 3.37
• Rated Power (hp): 0.88
• Right Angle Length (in): 8.27
• Right Angle Length (mm): 210

• Side to Center Distance (in): 1.3
• Side to Center Distance (mm): 33

• Sound Pressure/Power Db(A): 79.6 / 90.6
• Standards/Certifications: Ansi/Cagi B 186.1-1984, Ansi B186.1-2006, Bs En 792-7-2001

• Vibration Level (m/s2): 7.9
• Vibration Uncertainy K* (m/s2): 2.5
• Warranty: 1-year
• Wheel Diameter (in): 5
• Wheel Thickness (in): 1/4
• Wheel Type: Type 27 (Grinding) Type 1, 27, 41, 42 (Cutting)

• Lubrication: 10P

IR 345MAX-M

Angle Air Grinder/Cut-off Tool, 5" Wheel, 12,000 RPM, 0.88 HP, M14 Arbor, Rear Exhaust

In keeping with the tradition of Ingersoll Rand MAX tools, the MAX series Angle Grinders deliver MAX Power, MAX Productivity, MAX Comfort and improved reliability needed to tackle the toughest material removal jobs. MAX Series Angle Grinders gives you MAX performance for the daily grinding.

Includes:

Product Application/Uses:

Features and Benefits:

• Comfort: With a lightweight composite housing and ergonomic design, the Max Series Angle Grinders are easier to work with for long periods of time.
• Power: With an ideal power-to-weight ratio, the Max Series Angle Grinders are great for high-performance material removal.
• Versatile: The Max Series Angle Grinders are a versatile set of tools you can use in most major markets, from vehicle repair and body work to construction and metal fabrication.
• 1-year warranty.

Configuration/Handle Type: Right Angle

Max Free Speed (rpm): 12000

IR 34RB029

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 187 RPM, 4 HP, 507 NM, Reversible

• Air Consumption at Max HP (scfm): 180
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Drive Size (in): 1-1/2
• Drive Type: Round Keyed

• Exhaust Location: Side
• Finish: Paint, Yellow
• Gear Reduction: Double
• Gear Train: Spur Gear

• Housing Material: Steel Motor, Aluminum Gear Housing

• Max Free Speed (rpm): 187
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 374
• Max Torque (in-lb): 4487
• Max Torque (nm): 507
• Motor: Rotary Vane
• Motor: Spur Gear
• Mounting Type: Foot and Face

• Power Source: Air Powered

• Product Weight (lb): 75
• Rated Power (hp): 4
• Rated Power (kW): 2.98
• Reversible: Reversible

• Speed at Max Power (rpm): 99
• Starting Torque (ft-lb): 224
• Starting Torque (nm): 304

• Warranty: 1-year

IR 34SR-383

3" Steel Butt 7/8" Rod Tamper for Ingersoll Rand 341A2M Tamper

Product Application and Uses:

For use with Ingersoll Rand 341A2M Backfill Tamper

• For Use With: 341A2M

IR 34RB045

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 121 RPM, 4 HP, 788 NM, Reversible

• Air Consumption at Max HP (scfm): 180
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Drive Size (in): 1-1/2
• Drive Type: Round Keyed

• Exhaust Location: Side
• Finish: Paint, Yellow
• Gear Reduction: Double
• Gear Train: Spur Gear

• Housing Material: Steel Motor, Aluminum Gear Housing

• Max Free Speed (rpm): 121
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 581
• Max Torque (in-lb): 6974
• Max Torque (nm): 788
• Motor: Rotary Vane
• Motor: Spur Gear
• Mounting Type: Foot and Face

• Power Source: Air Powered

• Product Weight (lb): 75
• Rated Power (hp): 4
• Rated Power (kW): 2.98
• Reversible: Reversible

• Speed at Max Power (rpm): 63
• Starting Torque (ft-lb): 348
• Starting Torque (nm): 472

• Warranty: 1-year

IR 34RB078

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 69 RPM, 4 HP, 1370 NM, Reversible

• Air Consumption at Max HP (scfm): 180
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Drive Size (in): 1-1/2
• Drive Type: Round Keyed

• Exhaust Location: Side
• Finish: Paint, Yellow
• Gear Reduction: Double
• Gear Train: Spur Gear

• Housing Material: Steel Motor, Aluminum Gear Housing

• Max Free Speed (rpm): 69
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1010
• Max Torque (in-lb): 12126
• Max Torque (nm): 1370
• Motor: Rotary Vane
• Motor: Spur Gear
• Mounting Type: Foot and Face

• Power Source: Air Powered

• Product Weight (lb): 75
• Rated Power (hp): 4
• Rated Power (kW): 2.98
• Reversible: Reversible

• Speed at Max Power (rpm): 36
• Starting Torque (ft-lb): 606
• Starting Torque (nm): 822

• Warranty: 1-year

IR 34SR-85

Screw Replacement Part for Ingersoll Rand 341, 441 Tamper

Product Application and Uses:

For use with Ingersoll Rand 341 Series Air Tampers

• For Use With: 341A2M

IR 34U-103-4

IR 34U-58-10

Washer for Ingersoll Rand HLK Chain Hoist,, 10-Pack

IR 34U-367

IR 35-36

IR 35-42-7

IR 35-A53

IR 35-724

IR 35-A726

Anvil Assembly for Ingersoll Rand 35MAX and 36QMAX 1/2" Drive Impact Wrench

• For Use With: 36QMAX

IR 35-D727

IR 35-K249

IR 360-313

Air Belt Sander, 3/8" x13" , 20,000 RPM, 4700 SFPM, 0.6 HP, Rear Exhaust

Description: The 360-313 Pneumatic Belt Sander is engineered to make quick work of material removal and deliver smooth finishes. Whether removing spot welds, rust, deposits, or burrs, or fine-tuning a finished surface, these tools get the job done fast with a 0.6HP motor - 20% more than the leading competitor. Increase your productivity with tool-free belt changes (3/8" x 13" ) that make switching from one abrasive to the next quick and convenient, as well as a tool-free articulating arm that ensures every nook and cranny is easily reached. 360-418 also available with a 1/2" x 18" belt.

Features And Benefits:

• Strong and Reliable: .6HP motor delivers maximum removal rates to ensure you get the job done quickly and can do more jobs each day.
• Adaptable: Tool-free articulating arm ensures hard to reach areas are never overlooked and quick adjustments for whatever task is at hand.
• Adjustable: A handy power regulator ensures the right amount of power for every task.
• Ergonomic: Narrow rubber grip provides comfort to last as long as you need.
• Comfort: Built for all-day use, these lightweight sanders weigh less than 2.5 lbs. and tackle every job without sacrificing comfort and ergonomics.
• Uses: Can accomplish a wealth of sanding and finishing tasks, from removing spot welds, rust, burrs and surface deposits to final finishing and much more.
• Includes: 3/8x13" Belt Sander and (3) Norton sanding belts (60, 80 and 100 Grit)

Product Application and Uses:

For sanding on a variety of surfaces such as metal, plastic, fiberglass, wood and other materials, removing spot welds, rust, burrs and surface deposits to final surface finishing.

• Includes: 3/8 x 13" Sander, hex wrench, (3) Norton sanding belts (60, 80 and 100 Grit), Safety manual, web card
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption (cfm): 28.8
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arm Rotation: 360 Degree
• Arm Type: Pivoting
• Average Air Consumption (cfm): 28.8
• Average Air Consumption (l/min): 815

• Belt Size (in): 3/8 x 13
• Belt Speed (sfpm): 4700

• Color: Black
• Configuration/Handle Type: Straight
• Duty Rating: Maintenance Duty

• Exhaust Location: Rear

• Housing Material: Metallic with rubber over mold

• Max Free Speed (rpm): 20000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 12.4

• Product Width (in): 3.5
• Product Height (in): 3.4
• Product Weight (lb): 2.29
• Rated Power (hp): 0.6

• Sound Pressure/Power Db(A): 90 / 101
• Special Features: Tool-free belt changes, Tool Free articulating arm
• Speed Setting: Variable Speed

• Tool Type: Full-size
• Vibration Level (m/s2): 1
• Warranty: 1-year

• Lubrication: 10P
• Parts: 360-313-KIT-BELT
• Parts: TK-360-031

• Parts: TK-360-042
• Parts: TK-360-313-292
• Parts: TK-360-313-555
• Parts: TK-360-313-722
• Parts: TK-360-441
• Parts: TK-360-472

IR 360-313-KIT-BELT

Belt Kit, 3/8x13 for Ingersoll Rand 360-313 Sander

Product Application and Uses:

For use with Ingersoll Rand 360-313 belt sanders

• Includes: (1) 100 3/8x13" Grit Norton Sanding Belt, (1) 80 Grit 3/8x13" Norton Sanding Belt, (1) 60 Grit 3/8x13" Norton Sanding Belt

• For Use With: 360-313

IR 360-418

Air Belt Sander, 1/2" x18" , 20,000 RPM, 4700 SFPM, 0.6 HP, Rear Exhaust

Description: The 360-418 Pneumatic Belt Sander is engineered to make quick work of material removal and deliver smooth finishes. Whether removing spot welds, rust, deposits, or burrs, or fine-tuning a finished surface, these tools get the job done fast with a 0.6HP motor - 20% more than the leading competitor. Increase your productivity with tool-free belt changes (1/2" x 18" ) that make switching from one abrasive to the next quick and convenient, as well as a tool-free articulating arm that ensures every nook and cranny is easily reached. 360-313 also available with a 3/8" x 13" belt.

Features And Benefits:

• Strong and Reliable: .6HP motor delivers maximum removal rates to ensure you get the job done quickly and can do more jobs each day.
• Adaptable: Tool-free articulating arm ensures hard to reach areas are never overlooked and quick adjustments for whatever task is at hand.
• Adjustable: A handy power regulator ensures the right amount of power for every task.
• Ergonomic: Narrow rubber grip provides comfort to last as long as you need.
• Comfort: Built for all-day use, these lightweight sanders weigh less than 2.5 lbs. and tackle every job without sacrificing comfort and ergonomics.
• Uses: Can accomplish a wealth of sanding and finishing tasks, from removing spot welds, rust, burrs and surface deposits to final finishing and much more.
• Includes: 1/2" x18" Belt Sander and (3) Norton sanding belts (60, 80 and 100 Grit)

Product Application and Uses:

For sanding on a variety of surfaces such as metal, plastic, fiberglass, wood and other materials, removing spot welds, rust, burrs and surface deposits to final surface finishing.

• Includes: 1/2" x 18" belt sander, hex wrench, (3) Norton sanding belts (60, 80 and 100 Grit), Safety manual, web card
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption (cfm): 29.12
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arm Rotation: 360 Degree
• Arm Type: Pivoting
• Average Air Consumption (cfm): 29.12
• Average Air Consumption (l/min): 825

• Belt Size (in): 1/2 x 18
• Belt Speed (sfpm): 4700

• Color: Black
• Configuration/Handle Type: Straight
• Duty Rating: Maintenance Duty

• Exhaust Location: Rear

• Housing Material: Metallic with rubber over mold

• Max Free Speed (rpm): 20000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 14.96

• Product Width (in): 3.23
• Product Height (in): 3.54
• Product Weight (lb): 2.4
• Rated Power (hp): 0.6

• Sound Pressure/Power Db(A): 92 / 103
• Special Features: Tool-free belt changes, Tool Free articulating arm
• Speed Setting: Variable Speed

• Tool Type: Full-size
• Vibration Level (m/s2): 1
• Warranty: 1-year

• Lubrication: 10P
• Parts: 360-418-KIT-BELT
• Parts: TK-360-031

• Parts: TK-360-042
• Parts: TK-360-418-555
• Parts: TK-360-418-722
• Parts: TK-360-441
• Parts: TK-360-472

IR 360-418-KIT-BELT

Belt Kit for Ingersoll Rand 360-418 Sander

Product Application and Uses:

For use with Ingersoll Rand 360-418 belt sanders

• Includes: (1) 100 Grit 1/2X18 Norton Sanding Belt, (1) 80 Grit 1/2" X18" Norton Sanding Belt, (1) 60 Grit 1/2" X18" Norton Sanding Belt

• For Use With: 360-418

IR 371-A

1/4" Air Screwdriver, 10 ft-lb Torque, 2000 RPM, Positive Jaw Clutch, Trigger

Description: The 371-A Pistol Grip Screwdriver is an excellent choice for soft-draw applications. This tool is well-suited for light industrial applications and delivers reliable performance for driving sheet metal, self-tapping, and wood screws.

Features And Benefits:

• Performance: Positive action clutch for full torque throughout rundown.
• Ergonomics: Designed to fit perfectly in your hand, this tool allows you to work long stretches at a time. Offers convenient one-handed operation, with reverse control at trigger.
• Versatility: Variable speed throttle for easy starts.

Product Application and Uses:

The 371 Pistol Grip Screwdriver is an excellent choice for soft-draw applications. This tool is well suited for light industrial applications and delivers reliable performance for driving sheet metal, self-tapping, and wood screws.

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Adjustable Clutch: No
• Air Consumption (cfm): 3.2
• Air Consumption @ Load (cfm): 91.2
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90

• Bearing Type: Needle Bearing
• Bearing Type: Ball Bearing

• Clutch Type: Positive Jaw
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/4

• Exhaust Location: Handle-bottom
• Fastener Size: 1/4 Bolt

• Housing Material: Aluminum
• Inlet Location: Bottom of Handle

• Max Free Speed (rpm): 2000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 7.31

• Product Width (in): 1.65
• Product Height (in): 5.66
• Product Weight (lb): 2.6
• Recommended Forward Torque Range (ft-lb): 0.0-13
• Recommended Forward Torque Range (in-lb): 0.0-156
• Recommended Forward Torque Range (nm): 0 - 17.63
• Reversible: Reversible

• Screw Capacity: 1/4"

• Sound Pressure/Power Db(A): 96/107
• Speed Setting: Variable Speed

• Vibration Level (m/s2): 1.24
• Warranty: 1-year

• Lubrication: 10G
• Lubrication: 10P

IR 380P

IR 37598

IR 38559233

IR 38600714

IR 38752358

IR 38776332

IR 38966

IR 3934-53

IR 3934-A40

IR 3940-11

IR 3940-283

IR 3940-329

Reverse Valve Service Part for Ingersoll Rand Power Tools

IR 3940-36

IR 3940-658A

IR 3940A-302

Throttle Valve Plunger Service Part for Ingersoll Rand Power Tools

IR 3940B2TIEX

1" Air Impact Wrench, ATEX/Hazardous Duty, 2750 ft-lb Torque, Titanium Hammercase, D-Handle Inside Trigger

Description: Specifically designed to meet ATEX Zone 1 or Zone 2 requirements, with titanium hammer case, bronze end plates, and a corrosion preventative treatment up to 2750 ft-lbs, the 3900 Series are the premier industrial grade impact wrench in the industry. ATEX Marking ATEX 2014/34/EU Ex h IIA T6 Gb X and ISO 80079-36 Certified.

Features And Benefits:

• Environmental, Health and Safety: ISO 80079-36 and ATEX 2014/34/EU, Ex h IIA T6 Gb X Certified to meet ATEX Zone 1 or Zone 2 requirements.
• Power: High torque output of 2750 ft-lbs and 800 blows per minute. The reverse bias motor helps remove the most stubborn bolts and the twin hammer mechanism ensures consistent power and balance.
• Bronze End Plates: Thanks to the bronze end-plate and a corrosion preventative treatment, this tool is corrosion and wear resistant, which makes it great for outdoor conditions.
• Durability: With a titanium hammer case and metal housing, this tool can withstand even the harshest conditions.
• Reverse bias motor to help remove the most stubborn bolts.
• Balance: Twin hammer mechanism ensure consistent power and balance.
• Pressure-fed mechanism lubrication ensures complete coverage throughout the tool
• Integral muffler

Product Application and Uses:

Hazardous Zones, Vehicle Repair, General Industrial, Facility Maintenance

• Actuation/Throttle Type/Switch Type: Inside Trigger
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 64
• Average Air Consumption (l/min): 1812

• Blows per Min: 800

• Color: Grey
• Configuration/Handle Type: D-Handle
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Atex/Hazardous Duty

• End Plates: Bronze
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 103.4 / 114.4

• Hammer Case: Titanium
• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 100.6 / 111.6

• Max Bolt Diameter (in): 1-3/8
• Max Free Speed (rpm): 6000
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 2750
• Max Torque (in-lb): 33004
• Max Torque (nm): 3729
• Min Hose Size (in): 3/4
• Motor: Reverse Bias

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 117.9
• Product Length (in): 13.5

• Product Weight (lb): 21.2
• Quiet Tool: No
• Recommended Forward Torque Range (ft-lb): 500-1800
• Recommended Forward Torque Range (in-lb): 6001-21596
• Recommended Forward Torque Range (nm): 678-2440
• Retainer Type: Thru-hole

• Special Features: ATEX Rated, Titanium hammercase
• Standards/Certifications: Atex 2014/34/Eu, Atex Ex H Iia T6 Gb X, Iso 80079-36

• Tool Type: Full-size
• Vanes: 7
• Vibration Level (m/s2): 13.1
• Vibration Uncertainy K* (m/s2): 1.6
• Warranty: 1-year

• Accessories: SK8H9TN

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 2940-726
• Parts: 3934-123

• Parts: 3940-TK1

IR 3940P-A329

IR 3940P-283

IR 3940-TK1

Tune-up Kit for Ingersoll Rand 3940 Series Air Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 3940A1TI, 3940A2TI, 3940B1TI, 3940B2TI, 3940B2TIEX Impact wrenches

• Includes: (2) Seals, (1) Throttle Valve Spring, (1) Air Strainer Screen, (4) Gasket, (1) Rear Motor Bearing, (1) Front Motor Bearing, Vane pack, (3) Springs, (1) Ball, (1) Pin

• For Use With: 3940B2TI
• For Use With: 3940B2TIEX
• For Use With: 3940P2TI

IR 3942B1TI

No. 5 Spline Air Impact Wrench, Super Duty, 3250 ft-lb Torque, Titanium Hammercase, Thru-hole Retainer, D-Handle Inside Trigger

Description: With a titanium hammercase, bronze end plates and torque up to 3,250 ft-lbs, the 3900 Series are the premier industrial grade impacts in the industry.

Features And Benefits:

• Power: The 3900 Series delivers a high torque output of 3250 ft-lbs and 850 blows per minute.
• Bronze End Plates: Thanks to the bronze end-plate and a corrosion preventative treatment, this tool is corrosion and wear resistant, which makes it great for outdoor conditions.
• Durability: With a titanium hammer case and metal housing, this tool can withstand even the harshest conditions.
• Balance: Twin hammer mechanism ensure consistent power and balance.
• Reverse bias motor to help remove the most stubborn bolts.
• Pressure-fed mechanism lubrication ensures complete coverage throughout the tool
• Integral muffler
• Optimized for general industrial use, MRO, rail, heavy machinery, and shipbuilding

Product Application and Uses:

Heavy Industry, Oil&Gas, Foundry

• Actuation/Throttle Type/Switch Type: Inside Trigger
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 95
• Average Air Consumption (l/min): 2690

• Blows per Min: 850

• Color: Grey
• Configuration/Handle Type: D-Handle
• Drive Size (in): No. 5
• Drive Type: Spline
• Duty Rating: Super Duty

• End Plates: Bronze
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 102.7 / 113.7

• Hammer Case: Titanium
• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 99.0 / 110.0

• Max Free Speed (rpm): 5000
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 3250
• Max Torque (in-lb): 39005
• Max Torque (nm): 4407
• Min Hose Size (in): 3/4
• Motor: Reverse Bias

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Product Length (in): 14.3

• Product Weight (lb): 22.6
• Quiet Tool: No
• Recommended Forward Torque Range (ft-lb): 3000
• Recommended Forward Torque Range (in-lb): 36005
• Recommended Forward Torque Range (nm): 4068
• Retainer Type: Thru-hole

• Special Features: Titanium hammercase

• Tool Type: Full-size
• Vanes: 7
• Vibration Level (m/s2): 16.9
• Vibration Uncertainy K* (m/s2): 4.6
• Warranty: 1-year

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 3940-123

IR 3942B2TIEX

1" Air Impact Wrench, ATEX/Hazardous Duty, 3250 ft-lb Torque, Titanium Hammercase, D-Handle Inside Trigger

Description: Specifically designed to meet ATEX Zone 1 or Zone 2 requirements, with titanium hammer case, bronze end plates, and a corrosion preventative treatment up to 3250 ft-lbs, the 3900 Series are the premier industrial grade impact wrench in the industry. ATEX Marking ATEX 2014/34/EU Ex h IIA T6 Gb X and ISO 80079-36 Certified.

Features And Benefits:

• Environmental, Health and Safety: ISO 80079-36 and ATEX 2014/34/EU, Ex h IIA T6 Gb X Certified to meet ATEX Zone 1 or Zone 2 requirements.
• Power: The 3900 Series delivers a high torque output of 3250 ft-lbs and 850 blows per minute.
• Bronze End Plates: Thanks to the bronze end-plate and a corrosion preventative treatment, this tool is corrosion and wear resistant, which makes it great for outdoor conditions.
• Durability: With a titanium hammer case and metal housing, this tool can withstand even the harshest conditions.
• Reverse bias motor to help remove the most stubborn bolts.
• Balance: Twin hammer mechanism ensure consistent power and balance.
• Pressure-fed mechanism lubrication ensures complete coverage throughout the tool
• Integral muffler

Product Application and Uses:

Hazardous Environment, Heavy Industry, Oil&Gas, Foundry

• Actuation/Throttle Type/Switch Type: Inside Trigger
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 95
• Average Air Consumption (l/min): 2690

• Blows per Min: 800

• Color: Grey
• Configuration/Handle Type: D-Handle
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Atex/Hazardous Duty

• End Plates: Bronze
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 102.7 / 113.7

• Hammer Case: Titanium
• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 99.0 / 110.0

• Max Bolt Diameter (in): 1-3/8
• Max Free Speed (rpm): 5000
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 3250
• Max Torque (in-lb): 39005
• Max Torque (nm): 4407
• Min Hose Size (in): 3/4
• Motor: Reverse Bias

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 144
• Product Length (in): 14.3

• Product Weight (lb): 22.6
• Quiet Tool: No
• Recommended Forward Torque Range (ft-lb): 3000
• Recommended Forward Torque Range (in-lb): 36005
• Recommended Forward Torque Range (nm): 4068
• Retainer Type: Thru-hole

• Special Features: ATEX Rated, Titanium hammercase
• Standards/Certifications: Atex 2014/34/Eu, Atex Ex H Iia T6 Gb X, Iso 80079-36

• Tool Type: Full-size
• Vanes: 7
• Vibration Level (m/s2): 16.9
• Vibration Uncertainy K* (m/s2): 4.6
• Warranty: 1-year

• Accessories: SK8H9TN

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 2940-726
• Parts: 3940-123

• Parts: 3942-TK1

IR 3955A2TI

1-1/2" Air Impact Wrench, Super Duty, 5000 ft-lb Torque, Titanium Hammercase, Thru-hole Retainer, D-Handle Outside Trigger

Description: With a titanium hammercase, bronze end plates and torque up to 5,000 ft-lbs of torque, the 3900 Series are the premier industrial grade impacts in the industry.

Features And Benefits:

• Power: The 3900 Series delivers a high torque output of 5000 ft-lbs and 700 blows per minute.
• Bronze End Plates: Thanks to the bronze end-plate and a corrosion preventative treatment, this tool is corrosion and wear resistant, which makes it great for outdoor conditions.
• Durability: With a titanium hammer case and metal housing, this tool can withstand even the harshest conditions.
• Balance: Twin hammer mechanism ensure consistent power and balance.
• Reverse bias motor to help remove the most stubborn bolts.
• Pressure-fed mechanism lubrication ensures complete coverage throughout the tool
• Integral muffler
• Optimized for general industrial use, MRO, rail, heavy machinery, and shipbuilding
• Optimized for general industrial use, MRO, rail, heavy machinery, and shipbuilding.

Product Application and Uses:

Optimized for general industrial use, MRO, rail, heavy machinery, and shipbuilding.

• Actuation/Throttle Type/Switch Type: Outside Trigger
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 80
• Average Air Consumption (l/min): 2266

• Blows per Min: 700

• Color: Grey
• Configuration/Handle Type: D-Handle
• Drive Size (in): 1-1/2
• Drive Type: Square
• Duty Rating: Super Duty

• End Plates: Bronze
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 101.5 / 112.5

• Hammer Case: Titanium
• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 101.2 / 112.2

• Max Free Speed (rpm): 2750
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 5000
• Max Torque (in-lb): 60000
• Max Torque (nm): 6779
• Min Hose Size (in): 3/4
• Motor: Reverse Bias

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Product Length (in): 16.5

• Product Weight (lb): 34.6
• Quiet Tool: No
• Recommended Forward Torque Range (ft-lb): 3900
• Recommended Forward Torque Range (in-lb): 46803
• Recommended Forward Torque Range (nm): 5288
• Retainer Type: Thru-hole

• Special Features: Titanium hammercase

• Tool Type: High-torque
• Vibration Level (m/s2): 20.8
• Vibration Uncertainy K* (m/s2): 8.5
• Warranty: 1-year

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4

IR 3955-638

Socket Head Cap Screw Service Part for Ingersoll Rand Power Tools, Qty 4

IR 3955-283

IR 3955B2TI

IR 3955-A92

IR 3955B2TIEX

1-1/2" Air Impact Wrench, ATEX Rated, 5000 ft-lb Torque, Titanium Hammercase, D-Handle Inside Trigger

Description: Specifically designed to meet ATEX Zone 1 or Zone 2 requirements, with a titanium hammer case, bronze end plates, and a corrosion preventative treatment up to 5000 ft-lbs, the 3900 Series are the premier industrial grade impact wrench in the industry.ATEX Markings: ATEX 2014/34/EU and Ex h IIA T6 Gb XISO 80079-36 Certified

Features And Benefits:

• Environmental, Heath and Safety: ISO 80079-36 Certified and ATEX Zone 1 or Zone 2 requirements.
• Power: The 3900 Series delivers a high torque output of 5000 ft-lbs and 700 blows per minute.
• Bronze End Plates: Thanks to the bronze end-plate and a corrosion preventative treatment, this series is corrosion and wear resistant, which makes it great for outdoor conditions.
• Durability: With a titanium hammer case and metal housing, this tool can withstand even the harshest conditions.
• Balance: Twin hammer mechanism ensure consistent power and balance.
• Reverse bias motor to help remove the most stubborn bolts.
• Pressure-fed mechanism lubrication ensures complete coverage throughout the tool
• Integral muffler

Product Application and Uses:

Hazardous Zones, Vehicle Repair, General Industrial, Facility Maintenance

• Actuation/Throttle Type/Switch Type: Inside Trigger
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 80
• Average Air Consumption (l/min): 2266

• Blows per Min: 700

• Color: Grey
• Configuration/Handle Type: D-Handle
• Drive Size (in): 1-1/2
• Drive Type: Square
• Duty Rating: Atex/Hazardous Duty

• End Plates: Bronze
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 101.5 / 112.5

• Hammer Case: Titanium
• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 101.2 / 112.2

• Max Bolt Diameter (in): 1-1/2
• Max Free Speed (rpm): 2750
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 5000
• Max Torque (in-lb): 60000
• Max Torque (nm): 6779
• Min Hose Size (in): 3/4
• Motor: Reverse Bias

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 144.5
• Product Length (in): 16.6

• Product Width (in): 8.2
• Product Height (in): 5.3
• Product Weight (lb): 34.6
• Quiet Tool: No
• Recommended Forward Torque Range (ft-lb): 4700
• Recommended Forward Torque Range (in-lb): 56397
• Recommended Forward Torque Range (nm): 6372
• Retainer Type: Thru-hole

• Side to Center Distance (in): 4.1
• Side to Center Distance (mm): 104

• Special Features: ATEX Rated, Titanium hammercase
• Standards/Certifications: Atex 2014/34/Eu, Atex Ex H Iia T6 Gb X, Iso 80079-36

• Tool Type: Full-size
• Vanes: 7
• Vibration Level (m/s2): 20.8
• Vibration Uncertainy K* (m/s2): 8.5
• Warranty: 1-year

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 2950-726

IR 3955-36

Hammer Case Gasket Service Part for Ingersoll Rand Power Tools

IR 3955-53

IR 3955-D727

IR 3956B2TI

1-1/2 inch Air Impact Wrench, 5450 ft-lb Torque, Titanium Hammercase, Thru-hole Retainer, D-Handle Inside Trigger

Description: The 3956 Series Titanium Pneumatic Impacts has a 360 degrees D-auxiliary handle ensures enhanced ergonomic performance, with greater access and less operator fatigue. An increased power rating provides the confidence you need to power through the toughest of jobs. Our brand name prominently and proudly emblazoned on the side lets you know it's from the first name in impact tools: Ingersoll Rand. Because when it comes to performance, durability and reliability, there is simply no substitute for the best.

Features And Benefits:

• Performance: Best-in-class power-to-weight performance, delivering 5,450 ft-lbs (7,300 Nm) of breakaway torque.
• Ergonomic: Ergonomically enhanced 360 degrees D-auxiliary handle.
• Reliability: Assembled in the USA and backed by our broad network of parts and service to ensure unsurpassed serviceability.
• Durability: Optimized titanium hammercase, along with bronze endplates and corrosion-resistant parts.

• Includes: Hanger Bracket
• Actuation/Throttle Type/Switch Type: Inside Trigger
• Air Consumption @ Load (cfm): 105
• Air Consumption @ Load (l/min): 2971.5
• Air Inlet: 1/2 inch NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 145
• Average Air Consumption (l/min): 4103.5

• Blows per Min: 700

• Color: Grey
• Configuration/Handle Type: D-Handle
• Configuration/Handle Type: Auxiliary Handle
• Drive Size (in): 1-1/2
• Drive Type: Square
• Duty Rating: Industrial Duty

• End Plates: Bronze
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 98.8 / 109.8

• Hammer Case: Titanium
• Handle Material: Aluminum
• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 97.9 / 108.9

• Max Bolt Diameter (in): 1-1/2
• Max Free Speed (rpm): 3600
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 5384
• Max Torque (in-lb): 64610
• Max Torque (nm): 7300
• Min Hose Size (in): 3/4
• Motor: Reverse Bias

• Number of Power Settings: Continuous
• Nut-busting/Breakaway Torque (ft-lb): 5384
• Nut-busting/Breakaway Torque (in-lb): 64610
• Nut-busting/Breakaway Torque (nm): 7300
• Power Source: Air Powered
• Product Length (in): 16.68

• Product Width (in): 5.26
• Product Height (in): 11.31
• Product Weight (lb): 34.3
• Quiet Tool: No
• Recommended Forward Torque Range (ft-lb): 5178
• Recommended Forward Torque Range (in-lb): 62132
• Recommended Forward Torque Range (nm): 7020
• Retainer Type: Thru-hole

• Side to Center Distance (in): 2.67
• Side to Center Distance (mm): 68

• Standard Bolt Capacity (in): 2
• Standards/Certifications: ISO11148-6 2012, CAGIB186.1-2009, ISO 28927-2, ISO 15744

• Tool Type: High-torque
• Vanes: 7
• Vibration Level (m/s2): 16.4
• Vibration Uncertainy K* (m/s2): 5.6
• Warranty: 1-year

• Parts: TK-3956-GTK
• Parts: TK-3956TI-727

IR 3955-A40

IR 39587

IR 39849

IR 3A2SA

Air Chipping Hammer, 3" Stroke, 1725 BPM, Round Shank Oval Collar

Description: Whether you're working in construction or demolition, the A Series chipping hammers are great for any job. With its incredible power-to-weight ratio, these hammers will increase productivity and make working easy.

Features And Benefits:

• Durability: The A Series chipping hammers are equipped with a rubber buffer retainer and threaded barrels to extend the life of your product.
• Reliability: The A Series hammers have lock spring retainers that make sure the steel stays in place.
• Access: With a swan neck handle and long nozzle, you'll be able to work in tight, hard to reach spaces with ease.

Product Application and Uses:

These Air Percussive Chipping Hammers are designed for chipping, cutting, chiseling and breaking of hardened materials through repetitive application of linear impacts of a tool steel that is retained and driven by the chipper.

• Actuation/Throttle Type/Switch Type: Outside Trigger
• Air Consumption @ Load (cfm): 29
• Air Consumption @ Load (l/min): 821
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Blows per Min: 1725
• Bore Diameter (in): 1.125

• Collar Type: Oval
• Color: Beige
• Configuration/Handle Type: Swan Neck
• Duty Rating: Industrial Duty

• Height Over Spindle (in): 4
• Housing Material: Steel

• Max Pressure (bar): 6.2
• Min Hose Size (in): 1/2
• Muffler: No

• Power Source: Air Powered
• Product Length (in): 17.88

• Product Width (in): 9
• Product Weight (lb): 15.63
• Retainer Type: Lock-spring (Plain Arrow)

• Shank SIze (in): 0.68
• Shank Type: Round

• Standards/Certifications: Standards
• Steels: Yes
• Stroke Length (in): 3
