INGERSOLL-RAND IR TOOL S12880
INGERSOLL-RAND IR TOOL S12880 branded products
SWITCH-LED-PCB-BATTERY CONNECTOR MODULE
IR D1000-K93
IR D1000-K93
SWITCH-LED-PCB-BATTERY CONNECTOR MODULE $49.00
1/2" IQV20 HAMMER DRILL
IR D5241
IR D5241
1/2" 20V Cordless Hammer Drill Bare Tool, 1100 in-lb Torque, Keyless Chuck, Pistol Grip
The Ingersoll Rand® D5241 IQV20™ Hammer Drill combines the ease and versatility of a cordless tool with the power and precision of our best-in-class, professional-grade portfolio. With 3 drill settings, 2 speed settings, a ½-inch chuck, and a 24-position clutch, it’s designed to give you the precise torque you need, whether you’re drilling through a thin layer of plaster or a solid cement wall. Also available in the D5241-K22 kit which includes the D5241 Hammer Drill, Auxiliary Handle, (2) BL2022 5.0Ah Batteries, and 20V Battery Charger.Features And Benefits
- Power: With the capacity of 1,100 in-lbs of torque, the D5241 IQV20™ Hammer Drill is designed with the pros in mind.
- 1/2 Inch Chuck: All-metal keyless chuck with carbide teeth ensure bits don’t slip when drilling through almost any material.
- 24-Position Clutch: Say goodbye to cam-outs and over-torqued fasteners. A 24 position clutch lets you fine-tune fastening depth, so you can work smarter, not harder.
- Brushless Motor: The combination of a powerful brushless motor means the D5241 IQV20™ Hammer Drill operates at the apex of performance in almost any application.
- High and Low Speed Options: Whether you’re drilling through wood, steel, or concrete, two speed options help you get the right level of torque, every time.
- Rubberized Design: The D5241 IQV20™ Hammer Drill's impact-resistant rubberized design helps reduce kickback, keeping you steady and safe.
- LED light: An LED light located at the bottom of the tool reduces shadows so you can see your work area clearly.
- Adjustable Auxiliary Handle: For high-torque applications, a removable ergonomic auxiliary arm helps keep you steady.
- IQV20™ Battery: Compatible with the entire Ingersoll Rand IQV20™ platform, giving it an extra dose of power without weighing it down.
- Also available in the D5241-K22 kit which includes the D5241 Hammer Drill, Auxiliary Handle, (2) BL2022 5.0Ah Batteries, and 20V Battery Charger.
Includes: D5241 1/2" Hammer Drill, Auxiliary Handle and Manuals. Bare tool only; batteries and charger sold separately or with other kits.
Actuation/Throttle Type/Switch Type: Trigger
Blows per Min: 28000
Built-in Light: Yes
Chuck Capacity/Bit Capacity (in): 1/2
Chuck Type: Keyless Chuck
Clutch Settings: 24
Color: Grey
Configuration/Handle Type: Pistol Grip
Configuration/Handle Type: Auxiliary Handle
Drilling Capacity in Concrete: 3/8" (10mm)
Forward Torque setting 1 (ft-lb): 60
Forward Torque setting 1 (in-lb): 717
Forward Torque setting 1 (nm): 81
Housing Material: Impact and chemical-resistant composite housing
Max Free Speed (rpm): 1800
Max Torque (ft-lb): 92
Max Torque (in-lb): 1106
Max Torque (nm): 125
Motor: Brushless Motor
Nominal Drilling Capabilities (Wood Med or Frp): 1-3/8" (35mm)
Number of Batteries Required: 1
Power Source: Battery Powered
Product Length (in): 7.8
Product Width (in): 3.1
Product Height (in): 8.7
Product Height (in) (with Battery): 11
Product Weight (lb): 3.5
Product Weight (lb) (with Battery): 5
Reversible: Reversible
RPM Setting 1: 500
Side to Center Distance (in): 1.6
Side to Center Distance (mm): 41
Sound Pressure/Power Db(A): 84 / 92
Standards/Certifications: UL/CSA/EN/IEC 62841-1, UL/CSA/EN/IEC 62841-2-3
Vibration Level (m/s2): 4.2
Vibration Uncertainy K* (m/s2): 1.5
Voltage DC: 20
Warranty: 3-year tool, 2-year Battery, 3-year Charger
Similar IR
- D5140
Supersedes
- D5140
$202.35
IQV20 POLISHER/SANDER 2 BAT KIT
IR G4621-K22
IR G4621-K22
20V Cordless Polisher/Sander 2 Battery Kit, 8300 RPM, 2" & 3" Pad
Say goodbye to stall-outs, and say hello to power that lasts all shift long. The IQV20™ Cordless Polisher/Sander comes equipped with a powerful brushless motor, compact form, and powerful battery platform that helps you tackle any task in record time. Plus, lightweight, ergonomic features designed with technicians in mind help keep operator fatigue at bay. So, whether you’re sanding down sheet metal or giving a headlight one last polish, you’ll be covered. Kit includes 6 polishing and sanding accessories (2" & 3" Roloc Pads, 3" Hook & Loop Backing Pad, 3” Wool, 3” Soft Foam, 3” Medium Foam Pads), (2) BL2012 2.5Ah Batteries, and 20V Battery Charger.Features And Benefits
- Performance: A high-power brushless motor provides extended runtime and reliability, so you can leave stall-outs and overheated equipment in the dust.
- Durability: A threaded, all-metal chuck and spindle lock keep accessories in place during tough jobs and make abrasive changes quick. IPX6 rated protection against harmful effects of water ingress.
- Ergonomics: Small size to easily reach spots where large sanders (DA/Orbital) cannot.
- Visibility: An LED light located at the foot of the tool helps reduce shadows so you can see your work area clearly.
- Flexibility: An adjustable auxiliary handle keeps you steady in any configuration.
- Reliability: Efficient, high-performance brushless motor provides extended runtime and long-term reliability.
- Compatibility: Compatible with the entire Ingersoll Rand IQV20™ platform, giving it an extra dose of power without weighing it down.
- Kit Includes: G4621 Polisher/Sander, 2" & 3" Roloc Pads, 3" Hook & Loop Backing Pad, 3" Wool Pad, 3" Soft Foam Pad, 3" Medium Foam Pad, Auxiliary Handle, (2) BL2012 2.5Ah Batteries, and 20V Battery Charger.
Includes: G4621 Polisher/Sander Tool; 2" & 3" Roloc Backing Pads; 3" Hook & Loop Backing Pad; 3" Wool; 3" Soft Foam Pad, 3" Medium Foam Pad; Auxiliary Handle; (2) BL2012 20V 2.5Ah Batteries, 20V Battery Charger, 110/120V Power Cord
Product Application and Uses: Gasket removal or cleaning corrosion and dirt off parts similar to right angle die grinders; Small size to easily reach spots where larger polisher/sanders (ex. DA/Orbital sanders) cannot reach.
Actuation/Throttle Type/Switch Type: Trigger
Anti-Restart Technology: No
Anti-Vibration Technology: No
Arbor/Collet: 5/16"-24 Thread
Color: Grey
Configuration/Handle Type: Pistol Grip
Configuration/Handle Type: Auxiliary Handle
Duty Rating: Maintenance Duty
Gear Train: Planetary
Gripping Length (in): 4
Handle Material: Overmolded Grip
Height Over Spindle (in): 1.06
Housing Material: Nylon
Lock Mechanism: Toggle Switch
Max Free Speed (rpm): 8300
Mounting Type: Arbor
Pad Diameter or Size (in): 2 & 3
Pad Face: Hook & Loop
Pad Face: Roloc
Power Source: Battery Powered
Product Length (in): 4.92
Product Width (in): 3.19
Product Height (in): 8.26
Product Height (in) (with Battery): 9.25
Product Weight (lb): 1.7
Product Weight (lb) (with Battery): 2.61
Sound Pressure/Power Db(A): 73 / 84
Speed Setting: Dual speed
Standards/Certifications: UL, IPX6 (protection against harmful effects of water ingress)
Tether Style: Not Tether Capable
Vacuum: None
Vibration Level (m/s2): 1.2
Vibration Uncertainy K* (m/s2): 0.5
Voltage DC: 20
Warranty: 3-year tool, 2-year Battery, 3-year Charger
Wheel Thickness (in): 0.5
Similar IR
- 3129KA
- 317-B
- 313-B
$319.20
4.5/5" IQV20 ANGLE GRINDER
IR G5351
IR G5351
20V Cordless Angle Grinder/Cut-off Tool, 8000 RPM, 1HP, 4.5" Wheel, Bare tool
Break free from the cord with the G5351 20V Cordless 4.5/5.0” Angle Grinder & Cut-Off Tool that brings the power of a corded tool with the mobility of a cordless. Slim and well-balanced, G5351 allows access to tight spaces and weighs 20% less than leading competitor. Tool features an extended paddle switch and unique inline battery design that eliminates interference from the forearm during use. The G5351 couples a high-performance Brushless Motor with advanced features like Anti-Kickback and overload protection for safe, reliable performance. Slim handle with rubberized grip makes the G5351 Cordless Grinder comfortable to use for long periods. Tool-free guard attachment and Spindle-lock button allow quick, easy accessory changes. Also available in the G5351-K22 kit which includes (2) 20V 5Ah batteries, and a charger.Features And Benefits
- 1.0 HP brushless motor delivers up to 8,000 RPM and makes short work of material removal on a variety of surfaces.
- The G5351 is a lightweight and compact tool weighing 5 lbs. (including battery) and 13.25" length, improving control and access to tight spaces.
- Extended paddle switch with lock-off lever prevents accidental triggering and provides a more comfortable grip when maneuvering.
- Spindle-lock design with simple button press to disengage. Spindle can be used with all 5/8”-11 and 4.5”-5.0” wheels.
- Automatic anti-kickback protection and overload protection with E-brake.
- Change guards with tool-free quick release; use with included grinding guard for material removal and surfacing, or with the included cut-off guard for fast metal cutting.
- Slim body and comfortable rubber grip provide more tool control and reduce fatigue during extended use.
- Included side-handle attaches on the left or right side
- Compatible with IQV® 20 Series Battery System.
Includes: G5351 Grinder, Type 1 (Cutting) Guard; Type 27 (Grinding) Guard; Handle, flange, nut, Spanner Wrench, Manuals. Bare tool only; batteries and charger sold separately or with other kits.
Product Application and Uses: Material Removal, Surface Preparation, Blade Sharpening, Metal Cutting. Removes material from a variety of sources including wood, steel, aluminum, ceramic, glass, concrete and stone. Optimized for industrial and automotive applications.
Actuation/Throttle Type/Switch Location: Bottom
Actuation/Throttle Type/Switch Type: Paddle Switch
Anti-Restart Technology: Yes
Anti-Vibration Technology: No
Arbor/Collet: 5/8"-11 Thread
Brake Type: Electronic
Clutch Type: Electronic Anti-Kickback Clutch
Color: Grey
Configuration/Handle Type: Right Angle
Configuration/Handle Type: Auxiliary Handle
Duty Rating: Medium Duty
Exhaust Location: Front
Grinder Type: Angle Grinder
Guard Material: Steel
Handle Material: TPE Composite
Head Style: Standard Head
Height Over Spindle (in): 3.11
Housing Material: Impact and chemical-resistant composite housing
Lock Mechanism: Lever lock in off position
Max Free Speed (rpm): 8000
Motor: Brushless Motor
Power Source: Battery Powered
Product Length (in): 13.25
Product Width (in): 3.11
Product Height (in): 4.4
Product Weight (lb): 3.5
Rated Power (hp): 1
Rated Power (kW): 0.75
Right Angle Length (in): 13.25
Right Angle Length (mm): 337
Side to Center Distance (in): 1.42
Side to Center Distance (mm): 36
Sound Pressure/Power Db(A): 76.3
Speed Setting: Single speed
Standards/Certifications: UL/CSA/EN/IEC 62841-1, UL/CSA/EN/IEC 62841-2-3
Tether Style: Not Tether Capable
Vibration Level (m/s2): 6.6
Voltage DC: 20
Warranty: 3-year tool, 2-year Battery, 3-year Charger
Wheel Diameter (in): 4.5
Wheel Diameter (in): 5
Wheel Thickness (in): 1/4
Wheel Type: Type 27 (Grinding) Type 1, 27, 41, 42 (Cutting)
$202.35
BLANK - 12" .58 HX SHK OV COL, QTY 5
IR HH1-214-12
IR HH1-214-12
12" Chipping Hammer Blank Steel, Hex Shank Oval Collar
Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world’s first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Suitable for a wide range of applications, our chipping hammer steels are available with round or hex shanks and oval or round collars.Includes: (5) Blank Steels
Product Application and Uses: Designed for making customized points. For use with Ingersoll Rand K2LA1, 2DA1SA, 3DA1SA, 4DA1SA, 1A1SA, 2A1SA, 3A1SA, 4A1SA chipping hammers.
Chisel Style: Blank
Collar Thickness (in): 0.813
Collar Type: Oval
Collar Width (in): 1.125
Housing Material: Steel
Length Under Collar (in): 9.625
Product Length (in): 12
Product Weight (lb): 1.75
Shank Length (in): 2.375
Shank SIze (in): 0.58
Shank Type: Hex
For Use With
- 1A1SA
- 2A1SA
- 2DA1SA
- 3A1SA
- 3DA1SA
- 4A1SA
- 4DA1SA
$35.00
1" FLAT CHISEL - 18" .68 RD SHK OV COL, QTY 1
IR HH1-215F-18
IR HH1-215F-18
1" Flat Chipping Hammer Chisel Steel, 18"L Round Shank Oval Collar
Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world’s first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Suitable for a wide range of applications, our chipping hammer steels are available with round or hex shanks and oval or round collars.Includes: (15) Chipping Hammer Chisel Steels
Product Application and Uses: Designed for general demolition. For use with Ingersoll Rand 2DA2SA, 3DA2SA, 4DA2SA, 1A2SA, 2A2SA, 3A2SA, 4A2SA chipping hammers
Chisel Edge Style: Flat
Chisel Style: Flat
Collar Thickness (in): 0.813
Collar Type: Oval
Collar Width (in): 1.125
Housing Material: Steel
Length Under Collar (in): 15.625
Product Length (in): 18
Product Width (in): 1
Product Weight (lb): 2.5
Shank Length (in): 2.375
Shank SIze (in): 0.68
Shank Type: Round
For Use With
- 1A2SA
- 2A2SA
- 2DA2SA
- 3A2SA
- 3DA2SA
- 4A2SA
- 4DA2SA
$52.00
1" FLAT CHISEL - 24" .68 RD SHK OV COL, QTY 5
IR HH1-215F-24
IR HH1-215F-24
1" Flat Chipping Hammer Chisel Steel, 24"L Round Shank Oval Collar
Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world’s first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Suitable for a wide range of applications, our chipping hammer steels are available with round or hex shanks and oval or round collars.Includes: (15) Chipping Hammer Chisel Steels
Product Application and Uses: Designed for general demolition. For use with Ingersoll Rand 2DA2SA, 3DA2SA, 4DA2SA, 1A2SA, 2A2SA, 3A2SA, 4A2SA chipping hammers
Chisel Edge Style: Flat
Chisel Style: Flat
Collar Thickness (in): 0.813
Collar Type: Oval
Collar Width (in): 1.125
Housing Material: Steel
Length Under Collar (in): 21.625
Product Length (in): 24
Product Width (in): 1
Product Weight (lb): 1.75
Shank Length (in): 2.375
Shank SIze (in): 0.68
Shank Type: Round
For Use With
- 1A2SA
- 2A2SA
- 2DA2SA
- 3A2SA
- 3DA2SA
- 4A2SA
- 4DA2SA
$73.00
1" FLAT CHISEL - 48"
IR HH1-215F-48
IR HH1-215F-48
1" Flat Chipping Hammer Chisel Steel, 48"L Round Shank Oval Collar
Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world’s first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Suitable for a wide range of applications, our chipping hammer steels are available with round or hex shanks and oval or round collars.Includes: (1) Chipping Hammer Chisel Steel
Product Application and Uses: Designed for general demolition. For use with Ingersoll Rand 2DA2SA, 3DA2SA, 4DA2SA, 1A2SA, 2A2SA, 3A2SA, 4A2SA chipping hammers
Chisel Edge Style: Flat
Chisel Style: Flat
Collar Thickness (in): 0.813
Collar Type: Oval
Collar Width (in): 1.125
Housing Material: Steel
Length Under Collar (in): 45.625
Product Length (in): 48
Product Width (in): 1
Product Weight (lb): 6
Shank Length (in): 2.375
Shank SIze (in): 0.68
Shank Type: Round
For Use With
- 1A2SA
- 2A2SA
- 2DA2SA
- 3A2SA
- 3DA2SA
- 4A2SA
- 4DA2SA
$122.00
1" FLAT CHISEL - 96"
IR HH1-215F-96
IR HH1-215F-96
1" Flat Chipping Hammer Chisel Steel, 96"L Round Shank Oval Collar
Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world’s first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Suitable for a wide range of applications, our chipping hammer steels are available with round or hex shanks and oval or round collars.Includes: (10) Chipping Hammer Chisel Steels
Product Application and Uses: Designed for general demolition. For use with Ingersoll Rand 2DA2SA, 3DA2SA, 4DA2SA, 1A2SA, 2A2SA, 3A2SA, 4A2SA chipping hammers
Chisel Edge Style: Flat
Chisel Style: Flat
Collar Thickness (in): 0.813
Collar Type: Oval
Collar Width (in): 1.125
Housing Material: Steel
Length Under Collar (in): 93.625
Product Length (in): 96
Product Width (in): 1
Product Weight (lb): 15.25
Shank Length (in): 2.375
Shank SIze (in): 0.68
Shank Type: Round
For Use With
- 1A2SA
- 2A2SA
- 2DA2SA
- 3A2SA
- 3DA2SA
- 4A2SA
- 4DA2SA
$222.00
POWER MOTOR
IR 7811-B
IR 7811-B
Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 250 RPM, 0.7 HP, 74 NM, Reversible
Air Consumption at Max HP (scfm): 37.3Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 250
Max Pressure (bar): 6.2
Max Torque (ft-lb): 55
Max Torque (in-lb): 655
Max Torque (nm): 74
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 5.17
Rated Power (hp): 0.7
Rated Power (kW): 0.52
Reversible: Reversible
Sound Level dB(A): 85
Speed at Max Power (rpm): 130
Torque Output @ Max HP (ft-lb): 29
Torque Output @ Max HP (nm): 38.7
Warranty: 1-year
$2,392.50
THROTTLE REGULATORASSEMBLY - 3/32" AND 3/1
IR 8000MAX-A335
IR 8000MAX-A335
THROTTLE REGULATORASSEMBLY - 3/32" AND 3/1 $15.00
