INGERSOLL-RAND IR TOOL S12880
INGERSOLL-RAND IR TOOL S12880 branded products
POWER MOTOR
IR 8232-5
IR 8232-5
Milling Air Motor, 1/4" Collet, 1650 RPM, 0.6 HP, 10.2 NM, Non-reversible
Air Consumption at Max HP (scfm): 41Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/4
Drive Type: Collet
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 11.6:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1650
Max Pressure (bar): 6.2
Max Torque (ft-lb): 7.5
Max Torque (in-lb): 90
Max Torque (nm): 10.2
Motor: Rotary Vane
Motor: Milling
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 3.62
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 840
Torque Output @ Max HP (ft-lb): 3.8
Torque Output @ Max HP (nm): 5.1
Warranty: 1-year
$2,540.00
POWER MOTOR
IR 8232-6
IR 8232-6
Milling Air Motor, 1/4" Collet, 1000 RPM, 0.6 HP, 16.3 NM, Non-reversible
Air Consumption at Max HP (scfm): 41Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/4
Drive Type: Collet
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 18.9:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 12
Max Torque (in-lb): 144
Max Torque (nm): 16.3
Motor: Rotary Vane
Motor: Milling
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 3.62
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 500
Torque Output @ Max HP (ft-lb): 6.2
Torque Output @ Max HP (nm): 8.4
Warranty: 1-year
$2,540.00
POWER MOTOR
IR 8232-7
IR 8232-7
Milling Air Motor, 1/4" Collet, 800 RPM, 0.6 HP, 20 NM, Non-reversible
Air Consumption at Max HP (scfm): 41Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/4
Drive Type: Collet
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 23.4:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 800
Max Pressure (bar): 6.2
Max Torque (ft-lb): 15
Max Torque (in-lb): 177
Max Torque (nm): 20
Motor: Rotary Vane
Motor: Milling
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 3.62
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 390
Torque Output @ Max HP (ft-lb): 8.0
Torque Output @ Max HP (nm): 10.8
Warranty: 1-year
$2,540.00
SELF-FEED DRILL - " 000" SERIES
IR 8245-203-2-CN4
IR 8245-203-2-CN4
SELF-FEED DRILL - " 000" SERIES $3,774.00
POWER MOTOR
IR 8274-2A
IR 8274-2A
Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 250 RPM, 0.65 HP, 59 NM, Reversible
Air Consumption at Max HP (scfm): 35Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 250
Max Pressure (bar): 6.2
Max Torque (ft-lb): 44
Max Torque (in-lb): 522
Max Torque (nm): 59
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 10.1
Rated Power (hp): 0.65
Rated Power (kW): 0.48
Reversible: Reversible
Sound Level dB(A): 83
Speed at Max Power (rpm): 130
Torque Output @ Max HP (ft-lb): 27
Torque Output @ Max HP (nm): 36
Warranty: 1-year
$3,350.00
POWER MOTOR
IR 8274-1A
IR 8274-1A
Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 475 RPM, 0.65 HP, 32 NM, Reversible
Air Consumption at Max HP (scfm): 35Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 475
Max Pressure (bar): 6.2
Max Torque (ft-lb): 24
Max Torque (in-lb): 283
Max Torque (nm): 32
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 10.1
Rated Power (hp): 0.65
Rated Power (kW): 0.48
Reversible: Reversible
Sound Level dB(A): 83
Speed at Max Power (rpm): 250
Torque Output @ Max HP (ft-lb): 14
Torque Output @ Max HP (nm): 19
Warranty: 1-year
$3,350.00
POWER MOTOR
IR 8274-3A
IR 8274-3A
Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 200 RPM, 0.65 HP, 71 NM, Reversible
Air Consumption at Max HP (scfm): 35Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Reduction: Triple
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 200
Max Pressure (bar): 6.2
Max Torque (ft-lb): 52
Max Torque (in-lb): 628
Max Torque (nm): 71
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 14.5
Rated Power (hp): 0.65
Rated Power (kW): 0.48
Reversible: Reversible
Sound Level dB(A): 83
Speed at Max Power (rpm): 110
Torque Output @ Max HP (ft-lb): 31
Torque Output @ Max HP (nm): 42
Warranty: 1-year
$4,000.00
POWER MOTOR
IR 8274-A
IR 8274-A
Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 800 RPM, 0.65 HP, 18 NM, Reversible
Air Consumption at Max HP (scfm): 35Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 800
Max Pressure (bar): 6.2
Max Torque (ft-lb): 13
Max Torque (in-lb): 159
Max Torque (nm): 18
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 10.1
Rated Power (hp): 0.65
Rated Power (kW): 0.48
Reversible: Reversible
Sound Level dB(A): 83
Speed at Max Power (rpm): 450
Torque Output @ Max HP (ft-lb): 7.7
Torque Output @ Max HP (nm): 10.5
Warranty: 1-year
$3,350.00
POWER MOTOR
IR 8276-2A
IR 8276-2A
Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 350 RPM, 0.9 HP, 68 NM, Non-reversible
Air Consumption at Max HP (scfm): 41.6Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 350
Max Pressure (bar): 6.2
Max Torque (ft-lb): 50
Max Torque (in-lb): 602
Max Torque (nm): 68
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 10.1
Rated Power (hp): 0.9
Rated Power (kW): 0.67
Reversible: Non-reversible
Sound Level dB(A): 78
Speed at Max Power (rpm): 180
Torque Output @ Max HP (ft-lb): 27
Torque Output @ Max HP (nm): 36
Warranty: 1-year
$3,350.00
POWER MOTOR
IR 8276-1A
IR 8276-1A
Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 700 RPM, 0.9 HP, 37 NM, Non-reversible
Air Consumption at Max HP (scfm): 41.6Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 700
Max Pressure (bar): 6.2
Max Torque (ft-lb): 27
Max Torque (in-lb): 327
Max Torque (nm): 37
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 10.1
Rated Power (hp): 0.9
Rated Power (kW): 0.67
Reversible: Non-reversible
Sound Level dB(A): 78
Speed at Max Power (rpm): 350
Torque Output @ Max HP (ft-lb): 14
Torque Output @ Max HP (nm): 18.5
Warranty: 1-year
$3,350.00
POWER MOTOR
IR 8276-4A
IR 8276-4A
Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 160 RPM, 0.9 HP, 143 NM, Non-reversible
Air Consumption at Max HP (scfm): 41.6Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Reduction: Triple
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 160
Max Pressure (bar): 6.2
Max Torque (ft-lb): 105
Max Torque (in-lb): 1266
Max Torque (nm): 143
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 14.5
Rated Power (hp): 0.9
Rated Power (kW): 0.67
Reversible: Non-reversible
Sound Level dB(A): 78
Speed at Max Power (rpm): 90
Torque Output @ Max HP (ft-lb): 53
Torque Output @ Max HP (nm): 72
Warranty: 1-year
$3,750.00
POWER MOTOR
IR 8276-3A
IR 8276-3A
Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 300 RPM, 0.9 HP, 82 NM, Non-reversible
Air Consumption at Max HP (scfm): 41.6Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Reduction: Triple
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 300
Max Pressure (bar): 6.2
Max Torque (ft-lb): 60
Max Torque (in-lb): 726
Max Torque (nm): 82
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 14.5
Rated Power (hp): 0.9
Rated Power (kW): 0.67
Reversible: Non-reversible
Sound Level dB(A): 78
Speed at Max Power (rpm): 150
Torque Output @ Max HP (ft-lb): 32
Torque Output @ Max HP (nm): 43
Warranty: 1-year
$3,775.00
POWER MOTOR
IR 8276-5A
IR 8276-5A
Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 100 RPM, 0.9 HP, 206 NM, Non-reversible
Product Application and Uses: Max torque recommendation requires shear key with 150 ft-lbs shear strengthAir Consumption at Max HP (scfm): 41.6
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Reduction: Triple
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 100
Max Pressure (bar): 6.2
Max Torque (ft-lb): 152
Max Torque (in-lb): 1823
Max Torque (nm): 206
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 14.5
Rated Power (hp): 0.9
Rated Power (kW): 0.67
Reversible: Non-reversible
Sound Level dB(A): 78
Speed at Max Power (rpm): 50
Torque Output @ Max HP (ft-lb): 96
Torque Output @ Max HP (nm): 130
Warranty: 1-year
$3,950.00
POWER MOTOR
IR 8276-6A
IR 8276-6A
Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 50 RPM, 0.9 HP, 206 NM, Non-reversible
Product Application and Uses: Max torque recommendation requires shear key with 150 ft-lbs shear strengthAir Consumption at Max HP (scfm): 41.6
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Reduction: Triple
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 50
Max Pressure (bar): 6.2
Max Torque (ft-lb): 152
Max Torque (in-lb): 1823
Max Torque (nm): 206
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 14.5
Rated Power (hp): 0.9
Rated Power (kW): 0.67
Reversible: Non-reversible
Sound Level dB(A): 78
Speed at Max Power (rpm): 25
Torque Output @ Max HP (ft-lb): 152
Torque Output @ Max HP (nm): 206
Warranty: 1-year
$3,775.00
