INGERSOLL-RAND IR TOOL S12880

IR 48NA-A750-008

BOX

IR 48NA-A751

COVER

IR 48NB-761-036

GEAR

IR 48NB-761-029

GEAR

IR 48NB-761-078

GEAR

IR 48NB-761-045

GEAR

IR 48NB-762-078

SHAFT

IR 48NB-763

FRAME

IR 48NB-762-029

SHAFT

IR 48NB-767

RACE

IR 48NB-769

BEARING

IR 48NB-A750-029

BOX

IR 48NB-A750-045

BOX

IR 48NB-A750-036

BOX

IR 48NB-A750-078

BOX

IR 48NB-A751

COVER

IR 48RA008

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 1160 RPM, 3.1 HP, 69.8 NM, Reversible

Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Single
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 1160
Max Pressure (bar): 6.2
Max Torque (ft-lb): 51
Max Torque (in-lb): 618
Max Torque (nm): 69.8
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 44
Rated Power (hp): 3.1
Rated Power (kW): 2.31
Reversible: Reversible
Speed at Max Power (rpm): 638
Starting Torque (ft-lb): 38
Starting Torque (nm): 51.5
Warranty: 1-year

IR 48RA011

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 772 RPM, 3.1 HP, 105 NM, Reversible

Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Single
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 772
Max Pressure (bar): 6.2
Max Torque (ft-lb): 77
Max Torque (in-lb): 929
Max Torque (nm): 105
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 44
Rated Power (hp): 3.1
Rated Power (kW): 2.31
Reversible: Reversible
Speed at Max Power (rpm): 423
Starting Torque (ft-lb): 57
Starting Torque (nm): 77.3
Warranty: 1-year

IR 48RA005

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 1690 RPM, 3.1 HP, 47.5 NM, Reversible

Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Single
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 1690
Max Pressure (bar): 6.2
Max Torque (ft-lb): 35
Max Torque (in-lb): 420
Max Torque (nm): 47.5
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 44
Rated Power (hp): 3.1
Rated Power (kW): 2.31
Reversible: Reversible
Speed at Max Power (rpm): 930
Starting Torque (ft-lb): 26
Starting Torque (nm): 35.3
Warranty: 1-year

IR 48RA017

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 511 RPM, 3.1 HP, 159 NM, Reversible

Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Single
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 511
Max Pressure (bar): 6.2
Max Torque (ft-lb): 117
Max Torque (in-lb): 1407
Max Torque (nm): 159
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 44
Rated Power (hp): 3.1
Rated Power (kW): 2.31
Reversible: Reversible
Speed at Max Power (rpm): 278
Starting Torque (ft-lb): 86
Starting Torque (nm): 117
Warranty: 1-year

IR 48RA022

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 390 RPM, 3.1 HP, 209 NM, Reversible

Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Single
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 390
Max Pressure (bar): 6.2
Max Torque (ft-lb): 154
Max Torque (in-lb): 1850
Max Torque (nm): 209
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 44
Rated Power (hp): 3.1
Rated Power (kW): 2.31
Reversible: Reversible
Speed at Max Power (rpm): 213
Starting Torque (ft-lb): 113
Starting Torque (nm): 153
Warranty: 1-year

IR 48RA014

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 612 RPM, 3.1 HP, 133 NM, Reversible

Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Single
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 612
Max Pressure (bar): 6.2
Max Torque (ft-lb): 98
Max Torque (in-lb): 1177
Max Torque (nm): 133
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 44
Rated Power (hp): 3.1
Rated Power (kW): 2.31
Reversible: Reversible
Speed at Max Power (rpm): 332
Starting Torque (ft-lb): 72
Starting Torque (nm): 97.6
Warranty: 1-year

IR 48RB036

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 236 RPM, 3 HP, 317 NM, Reversible

Air Consumption at Max HP (scfm): 90
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Double
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 236
Max Pressure (bar): 6.2
Max Torque (ft-lb): 234
Max Torque (in-lb): 2806
Max Torque (nm): 317
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 75
Rated Power (hp): 3
Rated Power (kW): 2.24
Reversible: Reversible
Speed at Max Power (rpm): 131
Starting Torque (ft-lb): 167
Starting Torque (nm): 227
Warranty: 1-year

IR 48RB029

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 292 RPM, 3 HP, 256 NM, Reversible

Air Consumption at Max HP (scfm): 90
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Double
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 292
Max Pressure (bar): 6.2
Max Torque (ft-lb): 189
Max Torque (in-lb): 2266
Max Torque (nm): 256
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 75
Rated Power (hp): 3
Rated Power (kW): 2.24
Reversible: Reversible
Speed at Max Power (rpm): 162
Starting Torque (ft-lb): 135
Starting Torque (nm): 183
Warranty: 1-year

IR 48RB078

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 108 RPM, 3 HP, 696 NM, Reversible

Air Consumption at Max HP (scfm): 90
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Double
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 108
Max Pressure (bar): 6.2
Max Torque (ft-lb): 513
Max Torque (in-lb): 6160
Max Torque (nm): 696
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 75
Rated Power (hp): 3
Rated Power (kW): 2.24
Reversible: Reversible
Speed at Max Power (rpm): 60
Starting Torque (ft-lb): 364
Starting Torque (nm): 494
Warranty: 1-year

IR 49013

BEARING

IR 48RB045

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 188 RPM, 3 HP, 400 NM, Reversible

Air Consumption at Max HP (scfm): 90
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Double
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 188
Max Pressure (bar): 6.2
Max Torque (ft-lb): 295
Max Torque (in-lb): 3540
Max Torque (nm): 400
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 75
Rated Power (hp): 3
Rated Power (kW): 2.24
Reversible: Reversible
Speed at Max Power (rpm): 105
Starting Torque (ft-lb): 209
Starting Torque (nm): 283
Warranty: 1-year

IR 70011

SCREW 6-32 X .375 SCS

IR 70015SAA1HZQ100

700 SERIES ARM 10FT REACH 150LB HIGH PROFILE A1

IR 70015SAA20BA100

700 ARM 150 BAL STD A2MOUNT NO CARRIAGE 10 FT

IR 70015SAA2LZQ060

700C 150LB 6FT ZRA2 CARRIAGE LO PRO ZA QUAD

IR 70015SAA2LZT070

700C SERIES ARM 7FT REACH 150LB CAP LOW PROFILE

IR 70015SABB0BZ10E

700 ARM 10FT REACH 10FT UC ZSERVO 150LB CAP

IR 70015SABB0BA100

700 ARM 150 BAL STD BTMMNT NO CARRIAGE BA 10FT

IR 70015SABB0ZP09D

700 SERIES ARM COL MTD 9FT REACH 9FT COL 150LB CAP

IR 70015SABB0ZP08D

700 SERIES ARM COL MTD 8FT REACH 9FT COL 150LB C

IR 70015SABB0ZP100

700 ARM 150BAL STD BTM MNT NO CARRIAGE ZP 10FT

IR 70015SABB0ZQ10D

700 ARM 10FT REACH 9FT COL 150LB CAPACITY

IR 70015SABB0ZT10E

700 ARM 150 LB BAL 10' REACH 10' U/C

IR 70015SATT0ZP09A

700 ARM 150 LB 13" EXT

IR 70015SATT0ZQ070

700C SERIES ARM TOP MNT 7FT REACH QUAD COIL 150L

IR 70015SATT0ZQ080

700C SERIES ARM TOP MNT 8FT REACH QUAD COIL 150L

IR 70020SABB0ZP070

700 ARM 7FT REACH COLUMN MOUNTED 200LB CAP

IR 70020SABB0ZP100

700 SERIES ARM

IR 70020SATT0ZP090

700ARM-200#-AIR-ARM-TOPMOUNT-NOCARR-ZP-9'-NOMNT

IR 70020SATT0ZP100

700 ARM-200LB-10FT REACH-TOP MOUNT-NO CARRIAGE 700 ARM-200LB-10FT REACH-TOP MOUNT-NO CARRIAGE

IR 70035SAA2LZP080

700 SERIES ARM 8FT REACH ZRA2 LP CARRIAGE 350LB

IR 70015SABB0ZP10B

700 ARM 150 LB CAP 10' REACH 8' COLUMN

IR 70035SAA2LZQ080

700 SERIES ARM, 350-POUND BAL, ZRA2 CARRIAGE

IR 70015SABB0ZQ10B

700 ARM 10FT REACH 8FT COL 150LB CAP QUAD COIL

IR 70015SATT0ZP07A

700C ARM 7FT REACH 500LB CAP PENDANT CONTROL W/E

IR 70015SATT0ZP100

700 ARM TOP MOUNT ZA CONTROL 10FT REACH 150LB

IR 70035SABB0ZP10B

700C SERIES ARM 10FT REACH 8FT COLUMN 350LB CAP

IR 70020SAA2HZP100

700 C ARM

IR 70035SABB0ZQ100

700 ARM 10FT REACH 350LB CAP QUAD COIL

IR 70035SABB0ZQ09E

ERGO 700 ARM 350 LB CAPACITY

IR 70035SABB0ZQ10E

700 ARM 10FT REACH 10FT COL QUAD COIL 350LB CAP

IR 70035SATT0ZP100

700 SERIES ARM 350 LB. 10 FT. REACH ZA PENDANT C

IR 70035SATT0ZQ100

700 ARM 10FT REACH TOP MOUNT 350LB CAP QUAD COIL

IR 70050SAA2HZP080

ARM 700C 500LB A2 HIGH PRO PENDANT 8FT REACH

IR 70050SAA2LZP100

700 ARM 10FT REACH 500LB CAP W/CARRIAGE

IR 70050SAA2LZQ100

700 SERIES ARM, 10FT REACH, CARRIAGE MOUNTED

IR 70050SATT0ZP060

700C ARM 6 FT REACH 500 LB CAP PENDANT CONTROL

IR 70050SATT0ZP070

ARM 700C 500LB TOP MOUNT PENDANT 7FT REACH

IR 70050SATT0ZP09A

ARM 700 SERIES 500LB TOP

IR 70050SATT0ZP080

700 ARM 8FT REACH TOP MNT 500LB CAP W/PENDANT

IR 700A

IMPULSE TOOL 700A

IR 700A-230

BOLT

IR 700A-240

LINER

IR 700A-277

BOLT

IR 700A-330

BUSHING

IR 700A-41

SPACER

IR 700A-626

SPINDLE

IR 700A-626X

SHAFT

IR 700A-641

BUSHING

IR 700A-728

CAP

IR 700A-740

S-PACKING

IR 700A-741

S-PACKING

IR 700A-742

S-PACKING

IR 700A-743

S-PACKING

IR 700A-744

S-PACKING

IR 700A-745

S-PACKING

IR 700A-746

S-PACKING

IR 700A-888

PLATE

IR 700A-901

SHAFT

IR 700A-900

SPACER

IR 700A-933

WASHER

IR 700A-902

CAP

IR 700A-A11

PLATE

IR 700A-99

REPAIR KIT

IR 700A-A255

GUIDE (EQ210S-A255)

IR 700A-A200

MECHANISM

IR 700A-A3

CYLINDER

IR 700A-A40

MOTOR CASE

IR 700A-A626

SPINDLE

IR 700A-A727

HAMMER CASE

IR 700A-B211

PLATE ASSEMBLY

IR 700A-EU

IMPULSE TOOL

IR 700A-K500

MOTOR KIT

IR 700A-K600

KIT, MECHANISM
