Hydraullic Units

EP CH202950SR

• Type: Service Kit

• SubTypes: Relief Valve

EP CR400

The C-Series High Flow Hydraulic Coupler is the standard used on most Enerpac pumps and cylinders up to 10,000 psi (700 bar). These 3/8" high flow couplers provide a quick and secure connections, allowing a flow up to 2100 in3/min (35 liters) per minute.

They can be purchased as a complete set or individually as male and female halves. Included is a "2-in-1" dust cap for use with both on male and female components.

• Type: Coupler
• Max Bar: 700
• Max PSI: 10000

• Product Group: Couplers
• Product Line: Industrial Tools, Work Holding Tools, Bolting Tools
• Series: C
• SubTypes: High Flow Coupler

• 3/8" High Flow Couplers
• Standard equipment on most Enerpac cylinders
• Reccomended for use on all Enerpac pumps and cylinders where space and porting permits
• Include " 2-in-1" dust cap for use on male and female coupler halves
• Dimension A is total length when male and female halves are connected.

• Spare Part(s): C604K1

EP G2535L

This G-Series Liquid Filled Pressure Gauge contains glycerin to protect pressure sensing parts from vibration, sudden pressure changes, and moisture.

The dual scale face shows both psi and bar readings, and the extensive range includes a wide selection of models with maximum working pressures ranging from 100 to 15000 psi (7 to 1000 bar).

When using your gauges for high-cycle applications, we recommend using gauge snubbers or needle valves.

• Type: Gauge
• Max Bar: 700
• Max PSI: 10000

• Product Group: Gauges, Pumps
• Product Line: Industrial Tools, Work Holding Tools
• Series: G
• SubTypes: Pressure Gauge

• Calibrated in dual scale reading in psi and bar
• All pressure sensing parts sealed and dampened by glycerine for long life
• Includes safety blow-out disk and pressure equalizing membrane
• Gauge snubbers or needle valves recommended for high cycle applications

EP FZ-1616

EP P-392

EP PUD-1100B

EP RC-154

SPX C53C

EP CDB-180502

EP HC-7206

EP HF101

The Enerpac HF-series Hydraulic Oil is specially formulated for powered hydraulic pumps. The HF-series oil contains anti-sludge, anti-rust, and anti-foam additives for overall superior performance. The HF-series hydraulic oil prevents cavitation and offers maximum volumetric efficiency and maximum heat transfer.

The HF-series oil is not for use in hand pumps. Use the Enerpac LX-Series Oil for hand powered pumps.

Offered in 1 quart, 1 gallon, 5 gallon and 55-gallon sizes. The HF-series hydraulic oil has a viscosity index of 100 min.

• Type: Hydraulic Oil

• Product Group: Pumps
• Product Line: Industrial Tools, Work Holding Tools, Bolting Tools
• Series: HF
• SubTypes: Oil

• Specially formulated for power pumps
  • maximum volumetric efficiency
  • maximum heat transfer
  • prevents cavitation
  • anti-sludge, anti-rust, anti-foam additives
• Maximum film protective lubricity
  • anti-oxidation additives
• High viscosity index ensures maximum lubricity over a wide range of operation temperatures.

EP LX-101

EP RC-102

EP RCH-302

EP VMMD-003

EP XA-11

EP ZU4K

• Type: Service Kit

• SubTypes: Seal Kit

EP CDB40K

• Type: Service Kit

EP CF180900SR

• Type: ERP

• Product Group: Pumps
• SubTypes: Reservoir Kit

EP CF318028

• Type: Service Kit

• SubTypes: Screw

EP GA-2

EP HC-9206C

EP PACG5002SB

Enerpac PACG Air Hydraulic Pumps are for designed for intermittent to medium duty workholding applications up to 5,000 psi. Valve mount options include, remote, and mountings for DO3 and VP valves.

Enerpac Turbo II Air Over Hydraulic Pumps generate the hydraulic pressure you need using the air pressure you have available. The Air Saver Piston reduces air consumption, and the pump can start at low pressures from 50-125 psi.

Turbo II Air-Hydraulic Pumps are best suited to medium or lower cycle applications. They provide the power and speed needed for simple clamping circuits and mostly single acting tools. At only 75 dBA, the Turbo II Series helps to keep the noise level to a minimum.

Choose from a range with maximum working pressure of either 5,000 or 10,000psi, and various reservoir capacities from 116 - 462 in3 (2100 - 7500 cm3).

Turbo II Air Over Hydraulic Pump Series :

• PATG - Treadle for foot or hand operation
• PARG - Pendant Operation
• PAMG - Manual lever operated. For double-acting applications
• PACG - For remote valve mount. For workholding, 5000 psi (350 bar).
• PASG - Includes mount for a single DO3 Valve. For workholding, 5000 psi (350 bar).

• Type: Hydraulic Pump
• Max Bar: 350
• Max PSI: 5000

• Product Group: Pumps
• Product Line: Work Holding Tools
• Series: PACG
• SubTypes: Air Pump

• On-demand stall-restart operation maintains system pressure, providing clamping security
• External adjustable pressure relief valve (behind sight glass)
• Internal pressure relief valve provides overload protection
• Reduced noise level to 75 dBA
• Operating air pressure: 50-125 psi - enables pump to start at low air pressure**
• Hydraulic to air ratio: 45:1
• Reinforced heavy-duty lightweight reservoir for applications in tough environments
• Five valve mounting options provide flexibility in setup and operation
• Fully serviceable air motor assembly
• User supplied valves

** NOTE: From 50-125 psi air inlet pressure. Performance is significantly diminished below 50 psi. Performance may vary compared to listed values due to seal friction, internal pressure drops and manufacturing tolerances. Be sure to allow some flexibility on air inlet pressure.

EP RCH-121

EP ZCP-3
