Grinders

IR 88V-K301

IR 99H60-638

IR 99HL60H106

Extended Air Grinder, 6" Type 1 Wheel, 6,000 RPM, 3HP, 5/8 in-11 Thread, Side Exhaust

Description: The 99 Series Type 1 Grinder is designed for the toughest jobs. With a patented motor controller that maximizes material-removal rate and prevents over speeding, this grinder is both safe to use and powerful.

Features And Benefits:

• Safety: A lock-out lever and guard safety provide extra safety measures and increased operator comfort.
• Cleaner Workspaces: Compatible with piped-away exhaust kits to keep your worksite free from exhaust air.
• Durability: The 99 Series Type 1 Grinder's built-in mist lubricator automatically oils the motor to keep your grinder in top condition.
• 1-year warranty.

Product Application and Uses:

Automotive, general assembly, metal fabrication, plant maintenance, production prep, aerospace, shipbuilding

• Includes: Tools, Large Wrench, Small Wrench
• Actuation/Throttle Type/Switch Location: Handle
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Load (cfm): 84
• Air Consumption @ Load (l/min): 2379
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Bearing Type: Ball Bearing

• Configuration/Handle Type: Straight
• Duty Rating: Industrial Duty

• Exhaust Location: Side

• Grinder Type: Horizontal Grinder
• Guard Material: Steel
• Handle Material: Composite
• Height Over Spindle (in): 5.91
• Housing Material: Steel
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 6000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/4

• Power Source: Air Powered
• Product Length (in): 20.5

• Product Weight (lb): 13.5
• Rated Power (hp): 3

• Sound Pressure/Power Db(A): 82.8/93.8

• Vibration Level (m/s2): <2.5
• Warranty: 1-year
• Wheel Diameter (in): 6
• Wheel Thickness (in): 1
• Wheel Type: Type 1

• Lubrication: 10P

IR 99HL60H108

Extended Air Grinder, 8" Type 1 Wheel, 6,000 RPM, 3HP, 5/8 in-11 Thread, Side Exhaust

Features And Benefits:

• Safety: A lock-out lever and guard safety provide extra safety measures and increased operator comfort.
• Cleaner Workspaces: Compatible with piped-away exhaust kits to keep your worksite free from exhaust air.
• Durability: The 99 Series Type 1 Grinder's built-in mist lubricator automatically oils the motor to keep your grinder in top condition.

• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/8" -11 Thread

• Color: Black
• Configuration/Handle Type: Straight

• Exhaust Location: Side

• Grinder Type: Horizontal Grinder
• Guard Material: Steel
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 6000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/4

• Power Source: Air Powered

• Rated Power (hp): 3

• Warranty: 1-year
• Wheel Diameter (in): 8
• Wheel Thickness (in): 1
• Wheel Type: Type 1

• Parts: 99V/99H-TK3

IR 99V60-155

IR 99V60-638

IR 99V60-A25A

IR 99V60-A302

IR 99V85P107

Vertical Air Grinder, 7" Type 27/28 Wheel, 8,500 RPM, 3 HP, 5/8 in-11 Thread, Side Exhaust

Description: The 99 Series Vertical Grinders are tough and reliable, with a number of features that help you get the job done faster, easier and safer.

Features And Benefits:

• Power: The 99 Series Vertical Grinder sports a powerful vane motor and an ideal power-to-weight ratio.
• Safety: The included guard on the 99 Series block sparks and debris from flying back at you, while the locking throttle lever prevents accidental throttle operation.
• Reliable: Made with you in mind, the 99 Series Vertical Grinder is a trusted tool that will last you years to come. Comes with a 1-year warranty.

Product Application and Uses:

These air grinders are designed for material removal or cutting off using a rotated abrasive wheel.

• Includes: Tool, Large Wrench, Small Wrench
• Actuation/Throttle Type/Switch Location: Handle
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Load (cfm): 84
• Air Consumption @ Load (l/min): 2379
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Bearing Type: Ball Bearing

• Color: Black
• Configuration/Handle Type: Vertical
• Duty Rating: Industrial Duty

• Exhaust Location: Side

• Grinder Type: Vertical Grinder
• Guard Material: Steel
• Handle Material: Composite
• Height Over Spindle (in): 6.9
• Housing Material: Steel
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 8500
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/4

• Power Source: Air Powered
• Product Length (in): 6.88

• Product Weight (lb): 11.25
• Rated Power (hp): 3
• Right Angle Length (in): 7.95
• Right Angle Length (mm): 202

• Sound Pressure/Power Db(A): 103 / 104

• Vibration Level (m/s2): 3.6
• Warranty: 1-year
• Wheel Diameter (in): 7
• Wheel Thickness (in): 1/4
• Wheel Type: Type 27, 28

• Lubrication: 10P

IR AG1-11

IR AG121-106-4

Guard for Ingersoll Rand G2 Series Air Grinder

IR AG1-303S

IR AG1-311A

IR AG1-311B

IR AG1-318

IR AG1-A161

IR AG1-A34

IR AG1-A465

IR AG1-A53-3A

IR AG210-4-G4

Arbor for Ingersoll Rand G1 and G2 Die Grinder

IR AG210-4-W2

IR AG210-531

IR AG220-340

IR AG230-338-5

IR AG230-340M
