Grinders

FP UT8715-20

IR 23A-VARBR-6

IR 23A-VAR-GR

Surface Prep Accessory Kit, 50-Piece

Product Application and Uses:

For use with 1/4" Collet Die Grinders

• Includes: (4) 1/4" Shank Carbide Burs, (5) 1/8" Shank Mounted Points, (5) 1/4" Shank Mounted Points, (1) 2" Quick Change Disc Backing Pad, (1) 3" Quick Change Disc Backing Pad, (6) 2" 36 Grit Sanding Discs, (9) 2" Various Grit Surface and Conditioning Discs, (2) 2" Paint and Corrosion Removal Discs, (2) 2" High Strength Buffing Discs, (5) 3" 36 Grit Sanding Discs, (9) 3" Various Grit Surface Conditioning Discs, (1) Carrying Case
• Arbor/Collet: 1/4"

IR 301B2MK

Angle Air Die Grinder 2" Pad Kit, 21,000 RPM, 0.25 HP, 1/4" & 6mm Collets, Front Exhaust

Description: As part of an expanded line of long-lasting, economical, general purpose grinders, the 301B delivers a number of beneficial features in one compact package. Right-angle configuration provides easy access to tight spots, so you can grind, break sharp edges, de-burr, port, and polish virtually anywhere! Kit includes (4) 2" coarse pads, (4) 2" medium pads, Blow-molded case.

Features And Benefits:

• Performance: Powerful motor with precision gearing offers .25 HP at 21,000 RPM.
• Durable: Ball-bearing construction offers improved balance, reduces vibration, and ensures a longer product life.
• Strong: Aluminum housing withstands tough operating conditions.
• Lightweight: Small and sturdy design weighs only 1.02 lbs and provides easy operation and the right angle configuration allows better access to tight spots.
• Front exhaust: Helps keep work surface clean.
• Safety: 1/4" and 6mm collets and a intefral self-locking throttle lever that prevents accidental start up.
• Usage: Use this air die grinder as a handheld power rotary tool die grinding, cutting, polishing and more.
• Kit Includes: (4) 2" coarse pads, (4) 2" medium pads, Blow-molded case.

Product Application and Uses:

Use this air die grinder as a handheld power rotary tool for de-burring, polishing, porting, smoothing edges, weld grinding and more.

• Includes: 301B Air Angle Die Grinder, (4) 2" coarse pads, (4) 2" medium pads, Blow-molded case, 1/4" and 6mm collets, (2) Wrenches and Manuals
• Actuation/Throttle Type/Switch Location: Bottom
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 24
• Air Consumption @ Load (l/min): 680
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Arbor/Collet: 6mm
• Average Air Consumption (cfm): 6
• Average Air Consumption (l/min): 170

• Bearing Type: Ball Bearing

• Configuration/Handle Type: Right Angle
• Duty Rating: Medium Duty

• Exhaust Location: Front

• Grinder Type: Die Grinder
• Handle Material: Aluminum
• Height Over Spindle (in): 3
• Housing Material: Aluminum
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 21000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 5.27

• Product Width (in): 3.5
• Product Height (in): 2
• Product Weight (lb): 1.02
• Rated Power (hp): 0.25
• Right Angle Length (in): 2
• Right Angle Length (mm): 51

• Side to Center Distance (in): 0.54
• Side to Center Distance (mm): 14

• Sound Pressure/Power Db(A): 91.8 / 104.8
• Speed Setting: Variable Speed
• Standards/Certifications: 2006/42/Ec, En Iso 28927-12, En Iso 15744

• Vibration Level (m/s2): 5.9
• Warranty: 1-year

• Complete Tool Kits: 301BK
• Complete Tool Kits: 301B3MK
• Complete Tool Kits: 301B32MK

• Lubrication: 10G
• Lubrication: 10P
• Parts: 02A-VAR-KIT
• Parts: 301-42-4

• Parts: 301-K591A

IR 301B32MK

Angle Air Die Grinder 2" & 3" Pad Kit, 21,000 RPM, 0.25 HP, 1/4" & 6mm Collets, Front Exhaust

Description: As part of an expanded line of long-lasting, economical, general purpose grinders, the 301B delivers a number of beneficial features in one compact package. Right-angle configuration provides easy access to tight spots, so you can grind, break sharp edges, de-burr, port, and polish virtually anywhere! Kit Includes (2) 2" coarse pads, (2) 2" medium pads, (2) 3" coarse pads, (2) 3" medium pads, and a Blow-molded case.

Features And Benefits:

• Performance: Powerful motor with precision gearing offers .25 HP at 21,000 RPM.
• Durable: Ball-bearing construction offers improved balance, reduces vibration, and ensures a longer product life.
• Strong: Aluminum housing withstands tough operating conditions.
• Lightweight: Small and sturdy design weighs only 1.02 lbs and provides easy operation and the right angle configuration allows better access to tight spots.
• Front exhaust: Helps keep work surface clean.
• Safety: 1/4" and 6mm collets and a intefral self-locking throttle lever that prevents accidental start up.
• Usage: Use this air die grinder as a handheld power rotary tool die grinding, cutting, polishing and more.
• Kit Includes: (2) 2" coarse pads, (2) 2" medium pads, (2) 3" coarse pads, (2) 3" medium pads, and a Blow-molded case.

Product Application and Uses:

Use this air die grinder as a handheld power rotary tool for de-burring, polishing, porting, smoothing edges, weld grinding and more.

• Includes: 301B Air Angle Die Grinder, (2) 2" coarse pads, (2) 2" medium pads, (2) 3" coarse pads, (2) 3" medium pads, Blow-molded case, 1/4" and 6mm collets, (2) Wrenches and Manuals
• Actuation/Throttle Type/Switch Location: Bottom
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 24
• Air Consumption @ Load (l/min): 680
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Arbor/Collet: 6mm
• Average Air Consumption (cfm): 6
• Average Air Consumption (l/min): 170

• Bearing Type: Ball Bearing

• Configuration/Handle Type: Right Angle
• Duty Rating: Medium Duty

• Exhaust Location: Front

• Grinder Type: Die Grinder
• Handle Material: Aluminum
• Height Over Spindle (in): 3
• Housing Material: Aluminum
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 21000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 5.27

• Product Width (in): 3.5
• Product Height (in): 2
• Product Weight (lb): 1.02
• Rated Power (hp): 0.25
• Right Angle Length (in): 2
• Right Angle Length (mm): 51

• Side to Center Distance (in): 0.54
• Side to Center Distance (mm): 14

• Sound Pressure/Power Db(A): 91.8 / 104.8
• Speed Setting: Variable Speed
• Standards/Certifications: 2006/42/Ec, En Iso 28927-12, En Iso 15744

• Vibration Level (m/s2): 5.9
• Warranty: 1-year

• Complete Tool Kits: 301BK
• Complete Tool Kits: 301B2MK
• Complete Tool Kits: 301B3MK

• Lubrication: 10G
• Lubrication: 10P
• Parts: 02A-VAR-KIT
• Parts: 301-42-4

• Parts: 301-K591A

IR 301B3MK

Angle Air Die Grinder 3" Pad Kit, 21,000 RPM, 0.25 HP, 1/4" & 6mm Collets, Front Exhaust

Description: As part of an expanded line of long-lasting, economical, general purpose grinders, the 301B delivers a number of beneficial features in one compact package. Right-angle configuration provides easy access to tight spots, so you can grind, break sharp edges, de-burr, port, and polish virtually anywhere! Kit includes (4) 3" coarse pads, (4) 3" medium pads, and a Blow-molded case.

Features And Benefits:

• Performance: Powerful motor with precision gearing offers .25 HP at 21,000 RPM.
• Durable: Ball-bearing construction offers improved balance, reduces vibration, and ensures a longer product life.
• Strong: Aluminum housing withstands tough operating conditions.
• Lightweight: Small and sturdy design weighs only 1.02 lbs and provides easy operation and the right angle configuration allows better access to tight spots.
• Front exhaust: Helps keep work surface clean.
• Safety: 1/4" and 6mm collets and a intefral self-locking throttle lever that prevents accidental start up.
• Usage: Use this air die grinder as a handheld power rotary tool die grinding, cutting, polishing and more.
• Kit Includes: (4) 3" coarse pads, (4) 3" medium pads, Blow-molded case.

Product Application and Uses:

Use this air die grinder as a handheld power rotary tool for de-burring, polishing, porting, smoothing edges, weld grinding and more.

• Includes: 301B Angle Die Grinder, (4) 3" coarse pads, (4) 3" medium pads, Blow-molded case, 1/4" and 6mm collets, (2) Wrenches and Manuals.
• Actuation/Throttle Type/Switch Location: Bottom
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 24
• Air Consumption @ Load (l/min): 680
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Arbor/Collet: 6mm
• Average Air Consumption (cfm): 6
• Average Air Consumption (l/min): 170

• Bearing Type: Ball Bearing

• Configuration/Handle Type: Right Angle
• Duty Rating: Medium Duty

• Exhaust Location: Front

• Grinder Type: Die Grinder
• Handle Material: Aluminum
• Height Over Spindle (in): 3
• Housing Material: Aluminum
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 21000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 5.27

• Product Width (in): 3.5
• Product Height (in): 2
• Product Weight (lb): 1.02
• Rated Power (hp): 0.25
• Right Angle Length (in): 2
• Right Angle Length (mm): 51

• Side to Center Distance (in): 0.54
• Side to Center Distance (mm): 14

• Sound Pressure/Power Db(A): 91.8 / 104.8
• Speed Setting: Variable Speed
• Standards/Certifications: 2006/42/Ec, En Iso 28927-12, En Iso 15744

• Vibration Level (m/s2): 5.9
• Warranty: 1-year

• Complete Tool Kits: 301BK
• Complete Tool Kits: 301B2MK
• Complete Tool Kits: 301B32MK

• Lubrication: 10G
• Lubrication: 10P
• Parts: 02A-VAR-KIT
• Parts: 301-42-4

• Parts: 301-K591A

IR 302BK

Angle Air Die Grinder 2" & 3" Pad Kit, 20,000 RPM, 0.33 HP, 1/4" Collet, Rear Exhaust

Description: Lightweight and durable for ultimate performance, the 302B die grinder is the perfect choice. These powerful grinders feature .33 HP and 20,000 RPM, a composite grip for superior ergonomics and comfort, and can be used in various applications including porting, weld breaking, de-burring, polish-ing and grinding. Kit includes 2" and 3" Quick Change Backing Pads, a Variety of 2" and 3" Quick Change Sanding Disks, 2" and 3" Quick Change Coarse and Medium Polishing Disks, and a Blow-molded Carrying Case

Features And Benefits:

• Power: Powerful motor with precision gearing offers .33 HP at 20,000 RPM.
• Durable: Ball-bearing construction offers improved balance, reduces vibration, and ensures a longer product life.
• Lightweight: Lightweight at only 1lb., the ergonomic composite housing protects tool from cold air and offers greater operator comfort.
• Piped Away Exhaust Ready: These die grinders are compatible with "piped away" exhaust kits, so you can transfer exhaust away from you and your workspace.
• Reliability: Integral safety-lock throttle lever prevents accidental start up.
• Built-In Lubrication: Built-in lubricating wick increases angle gear life.
• Rear exhaust directs air away from the operator.
• Kit Includes: 2" and 3" Quick Change Backing Pads, a Variety of 2" and 3" Quick Change Sanding Disks, 2" and 3" Quick Change Coarse and Medium Polishing Disks, and a Blow-molded Carrying Case

Product Application and Uses:

Deburring, Grinding, Polishing, Porting, Weld Breaking

• Includes: Right Angle 302B Die Grinder, 2" and 3" Quick Change Backing Pads, A Variety of 2" and 3" Quick Change Sanding Disks, 2" and 3" Quick Change Coarse and Medium Polishing Disks, Blow-molded Carrying Case, 1/4" Collet.
• Actuation/Throttle Type/Switch Location: Bottom
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 23
• Air Consumption @ Load (l/min): 651
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Average Air Consumption (cfm): 6
• Average Air Consumption (l/min): 170

• Bearing Type: Ball Bearing

• Configuration/Handle Type: Right Angle
• Duty Rating: Medium Duty

• Exhaust Location: Rear

• Grinder Type: Die Grinder
• Handle Material: Composite
• Height Over Spindle (in): 3
• Housing Material: Aluminum
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 20000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Pad Diameter or Size (in): 2
• Pad Diameter or Size (in): 3
• Power Source: Air Powered
• Product Length (in): 6.93

• Product Width (in): 3.74
• Product Height (in): 2.36
• Product Weight (lb): 1.28
• Rated Power (hp): 0.33
• Right Angle Length (in): 2
• Right Angle Length (mm): 51

• Side to Center Distance (in): 0.53
• Side to Center Distance (mm): 13

• Sound Pressure/Power Db(A): 90.0 / 101.0
• Speed Setting: Variable Speed
• Standards/Certifications: 2006/42/Ec, En Iso 28927-12, En Iso 15744, En Iso 11148-9

• Vibration Level (m/s2): 5.5
• Vibration Uncertainy K* (m/s2): 1.5
• Warranty: 1-year

• Lubrication: 10G
• Lubrication: 10P
• Parts: 03A-VAR-KIT
• Parts: 301-K591A

IR 307A-27

IR 307A-699

IR 307A-A11

IR 307BK

Air Die Grinder Stone Kit, 28,000 RPM, 0.25 HP, 1/4" Collet, Front Exhaust

Description: Ingersoll Rand's 307B general purpose Air Die Grinder is durable, reliable, and cost-effective. Designed for porting, light weld grinding, smoothing sharp edges, de-burring, and polishing. Their compact design offers exceptional maneuverability, versatility, and accessibility for difficult-to-reach spots. Kit includes 10 mounted grinding tips and a blow-molded case.

Features And Benefits:

• Performance: Powerful vane motor delivers .25 HP and 28,000 RPM.
• Durable: Ball-bearing construction improves balance, reduces vibration, and ensures a longer life. Built-in lubricating wick increases gear life.
• Reliable: Strong aluminum housing withstands tough operating conditions and powerful vane motor will make the 307B a trusted tool in your arsenal for years to come.
• Safety: Integral safety-lock throttle lever prevents accidental start up.
• Comfort: Weighing under 1 lb., this small and lightweight design provides easy operation, and greater access to tight spots.
• Front exhaust: Helps keep work surface clean.
• Kit includes 10 abrasive stones, and a blow-molded carrying case.

Product Application and Uses:

Designed for porting, light weld grinding, smoothing sharp edges, de-burring, and polishing.

• Includes: 307B Air Die Grinder, (10) Abrasive Stones, a Blow-molded Case, (2) Wrenches, 1/4" Collet.
• Actuation/Throttle Type/Switch Location: Top, Bottom (straight tool)
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 24
• Air Consumption @ Load (l/min): 680
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Average Air Consumption (cfm): 6
• Average Air Consumption (l/min): 170

• Bearing Type: Ball Bearing

• Configuration/Handle Type: Straight
• Duty Rating: Medium Duty

• Exhaust Location: Front

• Grinder Type: Die Grinder
• Housing Material: Aluminum
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 28000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 5.19

• Product Height (in): 2.1
• Product Weight (lb): 0.73
• Rated Power (hp): 0.25

• Side to Center Distance (in): 0.65
• Side to Center Distance (mm): 17

• Sound Pressure/Power Db(A): 83.0 / 94.0
• Speed Setting: Variable Speed
• Standards/Certifications: 2006/42/Ec, En Iso 28927-12, En Iso 15744, En Iso 11148-9

• Vibration Level (m/s2): 4.5
• Vibration Uncertainy K* (m/s2): 1.1
• Warranty: 1-year
• Wheel Type: Burr

• Lubrication: 10G
• Lubrication: 10P
• Parts: 301-42-4
• Parts: 301-69A

IR 308A-699

IR 308A-A400

IR 308BK

Air Die Grinder Burr Kit, 25,000 RPM, 0.33 HP, 1/4" Collet, Rear Exhaust

Description: Lightweight and durable for ultimate performance, the 308B die grinder is the perfect choice. These powerful grinders feature a composite grip for superior ergonomics and comfort, and can be used in various applications including porting, weld breaking, de-burring, polishing and grinding. Kit includes 4 burrs.

Features And Benefits:

• Performance: Powerful vane motor delivers 0.33 HP and 25,000 RPM free speed.
• Durable: Ball-bearing construction improves balance, reduces vibration, and ensures a longer life. Built-in lubricating wick increases gear life.
• Lightweight: At only 1lb., the ergonomic composite housing protects this tool from cold air and offers greater operator comfort.
• Safety: Integral safety-lock throttle lever prevents accidental start up.
• Piped Away Exhaust Ready: These die grinders are compatible with "piped away" exhaust kits, so you can transfer exhaust away from you and your workspace.
• Rear exhaust directs air away from the operator
• Kit Includes: 4 burrs and a blow-molded carrying case.

Product Application and Uses:

Designed for various applications including porting, weld breaking, de-burring, polishing and grinding.

• Includes: 308B Straight Air Die Grinder, 4 Burrs (Cylindrical bit super cut burr, Cylindrical bit super cut burr, 3/8" ball shaped super cut burr, Tree shaped super cut burr), a Blow-molded Carrying Case, 1/4" Collet, (2) Wrenches.
• Actuation/Throttle Type/Switch Location: Top, Bottom (straight tool)
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 28
• Air Consumption @ Load (l/min): 793
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Average Air Consumption (cfm): 7
• Average Air Consumption (l/min): 198

• Bearing Type: Ball Bearing

• Configuration/Handle Type: Straight
• Duty Rating: Medium Duty

• Exhaust Location: Rear

• Grinder Type: Die Grinder
• Housing Material: Composite
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 25000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 6.85

• Product Width (in): 4
• Product Height (in): 2.5
• Product Weight (lb): 1.02
• Rated Power (hp): 0.33

• Side to Center Distance (in): 0.71
• Side to Center Distance (mm): 18

• Sound Pressure/Power Db(A): 92.0 / 103.0
• Speed Setting: Variable Speed
• Standards/Certifications: 2006/42/Ec, En Iso 28927-12, En Iso 15744, En Iso 11148-9

• Vibration Level (m/s2): 3.7
• Warranty: 1-year
• Wheel Type: Burr

• Accessories: 814TIN

• Lubrication: 10G
• Lubrication: 10P
• Parts: 301-69A
• Parts: 3102-42-4

IR 3107G

Air Die Grinder, 27,000 RPM, 0.33 HP, 1/4" Collet, Rear Exhaust

Description: Ingersoll Rand's EDGE Series 3017G 1/4" Air Straight Die Grinder is the right tool for the job. It offers a ball-bearing construction that is sturdy yet lightweight. Features include a 1/3-horsepower motor, a 1/4-inch collet, a rear exhaust, and a self-locking throttle. An ergonomic grip makes this pneumatic grinder comfortable to hold and use and provides exceptional torque accuracy. Offering longer life and higher free speed at 27,000 rpm, this general purpose air grinder is designed for finishing, cutting, polishing, porting, light weld grinding, and breaking sharp edges.

Features And Benefits:

• Powered by compressed air and comes with a 1/3 HP motor, a 1/4" collet, rear exhaust and a self-locking throttle. With 27,000 rpm, it will power through difficult jobs.
• Contoured grip gives greater comfort and control. Its ergonomic design delivers exceptional torque precision, as well as increased productivity and safety.
• The 3107G is light and sturdy at only 1 lb. It has a ball bearing construction and is exceptionally rugged, compact and lightweight.
• Use this air grinder as a handheld power rotary tool for grinding, cutting, polishing and more.
• Each componet, mechanism and function has undergone rigerous testing to ensure its long-lasting performace.

Product Application and Uses:

Finishing, cutting, polishing, porting, light weld grinding, and breaking sharp edges.

• Includes: tool, Large Wrench, Small Wrench
• Actuation/Throttle Type/Switch Location: Handle
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Free Speed (cfm): 3
• Air Consumption @ Free Speed (l/min): 85
• Air Consumption @ Load (cfm): 18
• Air Consumption @ Load (l/min): 500
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Average Air Consumption (cfm): 3
• Average Air Consumption (l/min): 85

• Bearing Type: Ball Bearing

• Configuration/Handle Type: Straight
• Duty Rating: Heavy Duty

• Exhaust Location: Rear

• Grinder Type: Die Grinder
• Guard Material: Steel
• Handle Material: Composite
• Height Over Spindle (in): 2.36
• Housing Material: Composite
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 27000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 6.6

• Product Width (in): 2.87
• Product Height (in): 1.46
• Product Weight (lb): 1
• Rated Power (hp): 0.33
• Right Angle Length (in): 4.92
• Right Angle Length (mm): 125

• Side to Center Distance (in): 0.67
• Side to Center Distance (mm): 17

• Sound Pressure/Power Db(A): 92.4 / 103.4

• Vibration Level (m/s2): 2.6
• Warranty: 1-year

• Accessories: 9800

• Lubrication: 10P
• Parts: 02A-VAR-KIT
• Parts: 03A-VAR-KIT

IR 320PG

Air Pencil Grinder, 60,000 RPM

Description: A slim profile pencil grinder makes it ideal for intricate spaces, precise grinders to final cleaning and polishing dies, to mold finishing, light deburring and flash removal

Features And Benefits:

• COMFORT: Complete with a custom TPU grip, low vibration and noise and an oversized speed control knob, the 320PG was designed for enhanced user comfort and safety.
• PRODUCTIVITY: The countless capabilities of the 320PG allow for more tasks to be completed with a singular tool, allowing for maximum versatility and productivity.
• VALUE: Affordability across the board is a top priority for the 320PG, which provides high quality performance at a budget-conscious price point.

Product Application and Uses:

For precision grinding and applications in confined spaces. Used for final cleaning and polishing of dies, mold finishing, intricate grinding applications, light deburring and flash removal.

• Includes: (1) Tool, (2) Wrench, (1) Hose Assy, (1) Sleeve Exhaust
• Actuation/Throttle Type/Switch Type: Twist
• Air Consumption @ Load (cfm): 8
• Air Consumption @ Load (l/min): 220
• Air Inlet: 1/8" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/8"

• Bearing Type: Ball Bearing

• Color: Grey
• Configuration/Handle Type: Straight
• Duty Rating: Maintenance Duty

• Exhaust Location: Rear

• Grinder Type: Pencil Grinder
• Handle Material: Alloy with TPU Grip
• Hose Length (ft): 4.75
• Housing Material: Aluminum Alloy

• Max Free Speed (rpm): 60000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 1/4

• Pencil Diameter (in): 0.74
• Power Source: Air Powered
• Product Length (in): 5.51

• Product Width (in): 0.74
• Product Height (in): 0.74
• Product Weight (lb): 0.51
• Rated Power (hp): 0.1

• Side to Center Distance (in): 0.37
• Side to Center Distance (mm): 9

• Sound Pressure/Power Db(A): 78 / 89
• Speed Setting: Variable Speed
• Spindle Offset (in): 0.37
• Standards/Certifications: CE, EAC, UKCA

• Vibration Level (m/s2): <3.2
• Warranty: 1-year
• Wheel Type: Burr, Mounted Points

• Accessories: 320-KCB5
• Accessories: 320-KMP5

• Complete Tool Kits: 320PGK

• Lubrication: 10G
• Lubrication: 10P
• Parts: 320-26
• Parts: 320-40

• Parts: 320-747
• Parts: 320PGK-75

IR 320PGK

Air Pencil Grinder Kit, 60,000 RPM, 5 Mounted Points & 5 Carbide Burrs

Description: A slim profile pencil grinder makes it ideal for intricate spaces, precise grinders to final cleaning and polishing dies, to mold finishing, light deburring and flash removal. Also includes 5 assorted mounted points and carbide burrs in a hard case.

Features And Benefits:

• COMFORT: Complete with a custom TPU grip, low vibration and noise and an oversized speed control knob, the 320PG was designed for enhanced user comfort and safety.
• PRODUCTIVITY: The countless capabilities of the 320PG allow for more tasks to be completed with a singular tool, allowing for maximum versatility and productivity.
• VALUE: Affordability across the board is a top priority for the 320PG, which provides high quality performance at a budget-conscious price point.
• Includes 5 assorted mounted points and 5 assorted carbide burrs.

Product Application and Uses:

For precision grinding and applications in confined spaces. Used for final cleaning and polishing of dies, mold finishing, intricate grinding applications, light deburring and flash removal.

• Includes: (1) Tool, (2) Wrench, (1) Hose Assy, (1) Sleeve Exhaust, 5 Mounted points, 5 Carbide Burrs
• Actuation/Throttle Type/Switch Type: Twist
• Air Consumption @ Load (cfm): 8
• Air Consumption @ Load (l/min): 220
• Air Inlet: 1/8" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/8"

• Bearing Type: Ball Bearing

• Color: Grey
• Configuration/Handle Type: Straight
• Duty Rating: Maintenance Duty

• Exhaust Location: Rear

• Grinder Type: Pencil Grinder
• Handle Material: Alloy with TPU Grip
• Hose Length (ft): 4.75
• Housing Material: Aluminum Alloy

• Max Free Speed (rpm): 60000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 1/4

• Pencil Diameter (in): 0.74
• Power Source: Air Powered
• Product Length (in): 5.51

• Product Width (in): 0.74
• Product Height (in): 0.74
• Product Weight (lb): 0.51
• Rated Power (hp): 0.1

• Side to Center Distance (in): 0.37
• Side to Center Distance (mm): 9

• Sound Pressure/Power Db(A): 78 / 89
• Speed Setting: Variable Speed
• Spindle Offset (in): 0.37
• Standards/Certifications: CE, EAC, UKCA

• Vibration Level (m/s2): <3.2
• Warranty: 1-year
• Wheel Type: Burr, Mounted Points

• Accessories: 320-KCB5
• Accessories: 320-KMP5

• Lubrication: 10G
• Lubrication: 10P
• Parts: 320-26
• Parts: 320-40

• Parts: 320-747
• Parts: 320PGK-75

IR 335SC4A

Air Die Grinder, 35,000 RPM, 0.37 HP, 1/4" and 6mm Collet, Rear Exhaust

Features And Benefits:

• Comfort: The Revolution Series Die Grinder has composite housing that is lightweight, contoured for comfort, and protects operators from temperature fluctuations.
• Performance: precision gearing and components contribute to long and reliable tool life.
• 1-year warranty.

Product Application and Uses:

Finishing, cutting, polishing, porting, light weld grinding, and breaking sharp edges.

• Includes: Tool, Large Wrench, Small Wrench, 6mm collet
• Actuation/Throttle Type/Switch Location: Handle
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Load (cfm): 30
• Air Consumption @ Load (l/min): 851
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Arbor/Collet: 6mm

• Bearing Type: Ball Bearing

• Configuration/Handle Type: Straight
• Duty Rating: Heavy Duty

• Exhaust Location: Rear

• Grinder Type: Die Grinder
• Guard Material: Steel
• Handle Material: Composite
• Height Over Spindle (in): 2.68
• Housing Material: Composite
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 35000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 6.5

• Product Weight (lb): 0.9
• Rated Power (hp): 0.37
• Right Angle Length (in): 6.69
• Right Angle Length (mm): 170

• Side to Center Distance (in): 0.79
• Side to Center Distance (mm): 20

• Sound Pressure/Power Db(A): 78.4 / 89.4

• Vibration Level (m/s2): 3
• Warranty: 1-year

• Lubrication: 10P
• Parts: 03A-VAR-KIT

IR 3445MAX-M

Angle Air Grinder/Cut-off Tool, 4.5" Wheel, 12,000 RPM, 0.88 HP, M14 Arbor, Rear-Piped Away Exhaust

In keeping with the tradition of Ingersoll Rand MAX tools, the MAX series Angle Grinders deliver MAX Power, MAX Productivity, MAX Comfort and improved reliability needed to tackle the toughest material removal jobs. MAX Series Angle Grinders gives you MAX performance for the daily grinding.

Includes:

Product Application/Uses:

Features and Benefits:

• Comfort: With a lightweight composite housing and ergonomic design, the Max Series Angle Grinders are easier to work with for long periods of time.
• Power: With an ideal power-to-weight ratio, the Max Series Angle Grinders are great for high-performance material removal.
• Versatile: The Max Series Angle Grinders are a versatile set of tools you can use in most major markets, from vehicle repair and body work to construction and metal fabrication.
• 1-year warranty.

Configuration/Handle Type: Right Angle

Max Free Speed (rpm): 12000

IR 345MAX-M

Angle Air Grinder/Cut-off Tool, 5" Wheel, 12,000 RPM, 0.88 HP, M14 Arbor, Rear Exhaust

In keeping with the tradition of Ingersoll Rand MAX tools, the MAX series Angle Grinders deliver MAX Power, MAX Productivity, MAX Comfort and improved reliability needed to tackle the toughest material removal jobs. MAX Series Angle Grinders gives you MAX performance for the daily grinding.

Includes:

Product Application/Uses:

Features and Benefits:

• Comfort: With a lightweight composite housing and ergonomic design, the Max Series Angle Grinders are easier to work with for long periods of time.
• Power: With an ideal power-to-weight ratio, the Max Series Angle Grinders are great for high-performance material removal.
• Versatile: The Max Series Angle Grinders are a versatile set of tools you can use in most major markets, from vehicle repair and body work to construction and metal fabrication.
• 1-year warranty.

Configuration/Handle Type: Right Angle

Max Free Speed (rpm): 12000

IR 401B07

7" Straight Blank Air Hammer Chisel Steel 0.401 Shank

Description: Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world's first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Tested to meet the harshest of environments, Ingersoll Rand is proud to offer pneumatic hammer accessories. All chisels are built from high-quality steel for the utmost in quality, strength, and durability.

Product Application and Uses:

Designed for making customized points. For use with .401 Air Hammers and RIveters.

• Includes: (5) Blank Steels

• Chisel Style: Blank

• Housing Material: Steel

• Product Length (in): 7

• Product Weight (lb): 0.5

• Shank SIze (in): 0.401
• Shank Type: Round

• For Use With: 115
• For Use With: 115K
• For Use With: 116
• For Use With: 116-EU
• For Use With: 116H-EU
• For Use With: 116K
• For Use With: 117
• For Use With: 117-EU
• For Use With: 117K
• For Use With: 119MAX
• For Use With: 119MAXK
• For Use With: 121/Q
• For Use With: 121/Q-EU
• For Use With: 121/QH-EU
• For Use With: 123MAX
• For Use With: 123MAXK
• For Use With: 135MAX
• For Use With: 135MAXK
• For Use With: 772
• For Use With: AVC10A1
• For Use With: AVC10C1

• For Use With: AVC12A1
• For Use With: AVC13A1
• For Use With: LA426-EU
• For Use With: LA427-EU

IR 422G-K105

IR 5102MAX-591A

IR 5102MAX-A552-1.25

IR 5104MAX

Angle Air Die Grinder, 12,000 RPM, 0.4 HP, 1/4" Collet, Rear Exhaust

Description: MAX Series premium die grinders are now offered in more configurations and speeds, ensuring you have the best tool for any job. A powerful 0.4HP motor and speeds ranging from 12,000 to 35,000 RPM in angle, straight, and extended tools adds greater flexibility to your tool box. Designed for everyday use in vehicle repair and industrial settings, you won't have to choose between topnotch performance or your wallet.

Features And Benefits:

• MAX Power: With a 0.4HP (0.3kW) motor and speeds up to 12,000 RPM, MAX Series Die Grinders deliver best in class power to tackle the toughest jobs.
• MAX Productivity: Spindle lock feature allows for quick abrasive changeovers reducing operator downtime.
• MAX Comfort: Enhanced ergonomic grip design and low profile level throttle reduces operator fatigue & maximizes operator comfort during extended runtimes.
• MAX Cleanliness: Optimal lube-free vanes eliminates the need for daily oiling and oil contamination of the work piece and surrounding environment.

Product Application and Uses:

Grinding welds, prepping quarter panels for primer and paint, cleaning wheel hubs, removing glue and gasket adhesives, cutting sheet metal, brackets, and bolts, and polishing surfaces.

• Includes: Tool, (2) Wrenches, 1/4" Collet, Piped Away Exhaust Kit, Service Clamp Block and Manuals
• Actuation/Throttle Type/Switch Location: Bottom
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Free Speed (cfm): 25
• Air Consumption @ Free Speed (l/min): 708
• Air Consumption @ Load (cfm): 25
• Air Consumption @ Load (l/min): 708
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Average Air Consumption (cfm): 6
• Average Air Consumption (l/min): 170

• Bearing Type: Ball Bearing

• Color: Grey
• Configuration/Handle Type: Right Angle
• Duty Rating: Heavy Duty

• Exhaust Location: Rear

• Grinder Type: Die Grinder
• Handle Material: Composite
• Height Over Spindle (in): 3.4
• Housing Material: Composite
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 12000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 7

• Product Height (in): 3.43
• Product Weight (lb): 1.4
• Rated Power (hp): 0.4
• Rated Power (kW): 0.29828000000000005
• Right Angle Length (in): 2
• Right Angle Length (mm): 51

• Side to Center Distance (in): 0.79
• Side to Center Distance (mm): 20

• Sound Pressure/Power Db(A): 85.6 / 96.6
• Special Features: Lube-free Motor, Spindle Lock
• Speed Setting: Variable Speed
• Standards/Certifications: 2006/42/Ec, En Iso 28927, En Iso 15744, En Iso 11148-9

• Vibration Level (m/s2): 4
• Vibration Uncertainy K* (m/s2): 1
• Warranty: 1-year
• Wheel Type: Burr

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Lubrication: 67-4T
• Lubrication: 67-LBK1
• Parts: 5108MAX-K284
• Parts: RG1-42L-LF-5
