Grinders

IR 5109MAX-24

Air Die Grinder, 20,000 RPM, 0.3 HP, 1/4" Collet, Rear Exhaust, Top Mounted Lever, 24-Piece

Description: MAX Series premium die grinders are now offered in more configurations and speeds, ensuring you have the best tool for any job. A powerful 0.4HP motor and speeds ranging from 12,000 to 35,000 RPM in angle, straight, and extended tools adds greater flexibility to your tool box. Designed for everyday use in vehicle repair and industrial settings, you won't have to choose between topnotch performance or your wallet.

Features And Benefits:

• MAX Power: With a 0.4HP (0.3kW) motor and speeds up to 20,000 RPM, MAX Series Die Grinders deliver best in class power to tackle the toughest jobs.
• MAX Comfort: Enhanced ergonomic grip design and low profile level throttle reduces operator fatigue & maximizes operator comfort during extended runtimes.
• MAX Cleanliness: Optimal lube-free vanes eliminates the need for daily oiling and oil contamination of the work piece and surrounding environment.

Product Application and Uses:

Grinding welds, prepping quarter panels for primer and paint, cleaning wheel hubs, removing glue and gasket adhesives, cutting sheet metal, brackets, and bolts, and polishing surfaces.

• Includes: (24) 5109MAX Die Grinders, 1/4" collet, 24 Large Wrenches, 24 Small Wrenches
• Actuation/Throttle Type/Switch Location: Top
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Free Speed (cfm): 25
• Air Consumption @ Free Speed (l/min): 708
• Air Consumption @ Load (cfm): 21
• Air Consumption @ Load (l/min): 600
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Average Air Consumption (cfm): 5.3
• Average Air Consumption (l/min): 150

• Bearing Type: Ball Bearing

• Color: Grey
• Configuration/Handle Type: Straight
• Duty Rating: Heavy Duty

• Exhaust Location: Rear

• Grinder Type: Die Grinder
• Handle Material: Composite
• Housing Material: Composite
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 20000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 6.6

• Product Height (in): 2.7
• Product Weight (lb): 1.1
• Rated Power (hp): 0.3
• Rated Power (kW): 0.22371

• Side to Center Distance (in): 0.75
• Side to Center Distance (mm): 19

• Sound Pressure/Power Db(A): 83.3 / 94.3
• Special Features: Lube-Free Motor
• Speed Setting: Variable Speed
• Standards/Certifications: 2006/42/Ec, En Iso 28927, En Iso 15744, En Iso 11148-9

• Vibration Level (m/s2): 1.8
• Vibration Uncertainy K* (m/s2): 0.8
• Warranty: 1-year
• Wheel Type: Burr

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Lubrication: 67-4T
• Lubrication: 67-LBK1
• Parts: 5108MAX-K284
• Parts: RG1-42L-LF-5

IR 5208MAX

Extended Air Die Grinder, 25,000 RPM, 0.4 HP, 1/4" Collet, Rear Exhaust

Description: MAX Series premium die grinders are now offered in more configurations and speeds, ensuring you have the best tool for any job. A powerful 0.4HP motor and speeds ranging from 12,000 to 35,000 RPM in angle, straight, and extended tools adds greater flexibility to your tool box. Designed for everyday use in vehicle repair and industrial settings, you won't have to choose between topnotch performance or your wallet.

Features And Benefits:

• MAX Power: With a 0.4HP (0.3kW) motor and speeds up to 25,000 RPM, MAX Series Die Grinders deliver best in class power to tackle the toughest jobs.
• MAX Comfort: Enhanced ergonomic grip design and low profile level throttle reduces operator fatigue & maximizes operator comfort during extended runtimes.
• MAX Cleanliness: Optimal lube-free vanes eliminates the need for daily oiling and oil contamination of the work piece and surrounding environment.

Product Application and Uses:

Grinding welds, prepping quarter panels for primer and paint, cleaning wheel hubs, removing glue and gasket adhesives, cutting sheet metal, brackets, and bolts, and polishing surfaces.

• Includes: Tool, (3) Wrenches, 1/4" Collet, Piped Away Exhaust Kit, Service Clamp Block and Manuals
• Actuation/Throttle Type/Switch Location: Bottom
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Free Speed (cfm): 25
• Air Consumption @ Free Speed (l/min): 708
• Air Consumption @ Load (cfm): 25
• Air Consumption @ Load (l/min): 708
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Average Air Consumption (cfm): 6
• Average Air Consumption (l/min): 170

• Bearing Type: Ball Bearing

• Color: Grey
• Configuration/Handle Type: Extended Straight
• Duty Rating: Heavy Duty

• Exhaust Location: Rear

• Grinder Type: Die Grinder
• Handle Material: Composite
• Housing Material: Composite
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 25000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 9.6

• Product Height (in): 1.6
• Product Weight (lb): 1.4
• Rated Power (hp): 0.4
• Rated Power (kW): 0.29828000000000005

• Side to Center Distance (in): 0.79
• Side to Center Distance (mm): 20

• Sound Pressure/Power Db(A): 85.5 / 86.5
• Special Features: Lube-Free Motor
• Speed Setting: Variable Speed
• Standards/Certifications: 2006/42/Ec, En Iso 28927, En Iso 15744, En Iso 11148-9

• Vibration Level (m/s2): 2.98
• Vibration Uncertainy K* (m/s2): 0.4
• Warranty: 1-year
• Wheel Type: Burr

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Lubrication: 67-4T
• Lubrication: 67-LBK1
• Parts: 5108MAX-K284
• Parts: RG1-42L-LF-5

IR 545MAX

Air Angle Grinder, 5" Type 27 Wheel, 12,000 RPM, 2.5 HP, 5/8" -11 Thread, Rear Exhaust

Description: Take your productivity to the MAX with the 5445MAX and 545MAX Series 2.5 HP Air Angle Grinders from Ingersoll Rand. Featuring a 2.5 hp motor that delivers the best power-to-weight ratio to maximize material removal, dramatically reducing job completion time on even the hardest alloys. At just over 4lbs, its compact construction is comfortable for all day use without operator fatigue. Durable, high strength internal components are built for long run times, reducing maintenance costs and operator downtime. An governed motor optimizes air consumption for the task at hand, delivering more power when you need it while increasing the life of abrasives and reducing consumable costs. A tool-free adjustable guard allows for orientation changes in seconds and spindle lock enables quick abrasive changeovers with a single spanner wrench. For colossal power in a compact size, keep your operators running with the 545MAX Series Angle Grinders.

Features And Benefits:

• Power: 2.5 hp motor delivers the best power-to-weight ratio to maximize material removal, dramatically reducing job completion time on even the hardest alloys.
• Performance: Governed motor optimizes air consumption for the task at hand, delivering more power when you need it while increasing the life of abrasives and reducing consumable costs.
• Productivity: No more excessive accessories. A tool-free adjustable guard allows for orientation changes in seconds and spindle lock enables quick abrasive changeovers with a single spanner wrench.
• Durability: Durable, high strength internal components are built for long run times, reducing maintenance costs and operator downtime.
• Comfort: At just over 4lbs, its compact construction packs a punch with a best-in-class power-to-weight ratio for all day use without operator fatigue.

Product Application and Uses:

Designed for material removal using a rotated abrasive wheel for general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding, construction, aerospace, and metal fabrication.

• Includes: Tool, 1 Wrench, Safety Manual, Auxiliary Handle, Allen wrench, Screw
• Actuation/Throttle Type/Switch Location: Handle
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Free Speed (cfm): 32.33
• Air Consumption @ Free Speed (l/min): 916
• Air Consumption @ Load (cfm): 76.75
• Air Consumption @ Load (l/min): 2174
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/8" -11 Thread
• Average Air Consumption (cfm): 76.75
• Average Air Consumption (l/min): 2174

• Bearing Type: Ball Bearing
• Bearing Type: Needle Bearing

• Color: Grey
• Configuration/Handle Type: Right Angle
• Configuration/Handle Type: Auxiliary Handle
• Duty Rating: Industrial Duty

• Exhaust Location: Rear

• Grinder Type: Angle Grinder
• Gripping Length (in): 5.4
• Guard Material: Steel
• Handle Material: Composite
• Height Over Spindle (in): 4.17
• Housing Material: Aluminum core with composite sleeve
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 12000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 1/2

• Power Source: Air Powered
• Product Length (in): 9.33

• Product Height (in): 5.5
• Product Weight (lb): 4.12
• Rated Power (hp): 2.5
• Rated Power (kW): 1.86

• Side to Cen

IR 61H120G4

Air Die Grinder, 12,000 RPM, 1.25 HP, 1/4" Collet, Side Exhaust

Description: Ingersoll Rand Pro Series are tough, easy to handle, and ready to tackle any project you need them for. They are specially designed for heavy duty applications. With their superior power output, they are best suited for big tasks involving heavy material removal in foundries, welding shops, fabrication facilities, steel mills or shipyards.

Features And Benefits:

• RELIABILITY: The 61 Pro Series comes with a built-in mist lubricator, motor controller and grit rejection system, to prolong tool life and increase performance.
• POWER: With a powerful 1.25 HP vane motor and 12,000 RPM, these grinders remove materials at top speed for maximum efficiency.
• DURABILITY: Featuring tough metal housing, these tools can withstand harsh environments and repeated drops with ease.
• ACCESS: With extended length and low profile, you can reach tight, hard-to-reach spaces.

• Air Consumption @ Load (cfm): 37
• Air Consumption @ Load (l/min): 1048
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"

• Configuration/Handle Type: Straight

• Exhaust Location: Side

• Max Free Speed (rpm): 12000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 1/2

• Power Source: Air Powered
• Product Length (in): 15.5

• Product Weight (lb): 4.3
• Rated Power (hp): 1.25

• Warranty: 1-year

IR 61H150G4

Air Die Grinder, 15,000 RPM, 1.33 HP, 1/4" Collet, Side Exhaust

Description: Ingersoll Rand Pro Series are tough, easy to handle, and ready to tackle any project you need them for. They are specially designed for heavy duty applications. With their superior power output, they are best suited for big tasks involving heavy material removal in foundries, welding shops, fabrication facilities, steel mills or shipyards.

Features And Benefits:

• POWER: With a powerful 1.33 HP vane motor and high power 15,000 RPM output, these grinders remove materials at top speed for maximum efficiency.
• RELIABILITY: The 61 Pro Series comes with a built-in mist lubricator, motor controller and grit rejection system, to prolong tool life and increase performance.
• DURABILITY: Featuring tough metal housing, these tools can withstand harsh environments and repeated drops with ease.
• ACCESS: With extended length and low profile, you can reach tight, hard-to-reach spaces.

• Air Consumption @ Load (cfm): 40
• Air Consumption @ Load (l/min): 1133
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"

• Exhaust Location: Side

• Max Free Speed (rpm): 15000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 1/2

• Power Source: Air Powered
• Product Length (in): 15.5

• Product Weight (lb): 4.3
• Rated Power (hp): 1.33

• Speed Setting: Variable Speed

• Warranty: 1-year

IR 61H-TK1

IR 7114-E

Air Pencil Grinder, 20,000 RPM, 1/8" Collet

Description: Made with a metal housing and equipped with a vane motor, the rear exhaust ARO Series Die Grinder is one tough tool. It's straight configuration and lever actuation throttle make it an ideal tool for industrial jobs and even aerospace projects.

Features And Benefits:

• Comfort: Lightweight and easy to handle, this tool is easy to use for longer periods of time.
• Access: Get your work done fast with this compact tool, which can reach tight spaces and hard-to-access angles
• Durable: With a durable metal housing, this tool is built to last.

Product Application and Uses:

Ideal tool for industrial jobs and even aerospace projects.

• Actuation/Throttle Type/Switch Location: Handle
• Actuation/Throttle Type/Switch Type: Lever
• Air Pressure (psi): 90
• Arbor/Collet: 1/8"
• Average Air Consumption (cfm): 6
• Average Air Consumption (l/min): 2.8

• Configuration/Handle Type: Straight

• Grinder Type: Die Grinder

• Max Free Speed (rpm): 20000
• Max Pressure (bar): 6.2

• Power Source: Air Powered
• Product Length (in): 6

• Product Weight (lb): 13

• Spindle Offset (in): 0.5

• Vibration Level (m/s2): 3.9
• Warranty: 1-year

IR 77A60P109

Air Angle Grinder, 9" Type 27/28 Wheel, 6000 RPM, 1.5 HP, 5/8" - 11 Thread, Side Exhaust

• Air Pressure (psi): 90

• Configuration/Handle Type: Right Angle

• Max Pressure (bar): 6.2

• Power Source: Air Powered

• Warranty: 1-year

IR 77A75P107

Air Angle Grinder, 7" Type 27/28 Wheel, 7500 RPM 1.5 HP, 5/8" -11 Thread, Side Exhaust

Description: From shipbuilding to general construction, the 77 Pro Series Angle Grinders are equipped to handle even the toughest of jobs.

Features And Benefits:

• Reliability: With a built-in mist lubricator and motor controller to extend tool life and regulate performance, you can count on these grinders to work the way you want them to any time you pull the trigger.
• Power: These grinders feature high-powered motors that allow you to remove material quickly and easily.
• Durability: Built to last, these metal housed grinders can withstand repeated drops and harsh environments.

• Actuation/Throttle Type/Switch Type: Lever
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/8" -11 Thread

• Configuration/Handle Type: Right Angle

• Exhaust Location: Rear

• Max Free Speed (rpm): 7500
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered

• Rated Power (hp): 1.5

• Sound Pressure/Power Db(A): 88.7

• Vibration Level (m/s2): 2.6
• Warranty: 1-year
• Wheel Diameter (in): 7
• Wheel Thickness (in): 1/4
• Wheel Type: Type 27, 28

IR 77H120H84

Air Grinder, 4" Type 1 Wheel, 12,000 RPM, 1.5 HP, 1/2" -13 Thread

Description: Ingersoll Rand Pro Series are tough, easy to handle, and ready to tackle any project you need them for. They are specially designed for heavy duty applications. With their superior power output, they are best suited for big tasks involving heavy material removal in foundries, welding shops, fabrication facilities, steel mills or shipyards.

Features And Benefits:

• Reliability: With a built-in mist lubricator and motor controller to extend tool life and regulate performance, you can count on these grinders to work the way you want them to any time you pull the trigger.
• Power: High powered 1.5 HP and 12,000 RPM motor allow for quick and easy material removal without breaking a sweat.
• Durability: Ingersoll Rand tools are built to withstand harsh conditions and repeated drops, and this series is no different.

Product Application and Uses:

Specially designed for heavy duty applications best suited for big tasks involving heavy material removal in foundries, welding shops, fabrication facilities, steel mills or shipyards.

• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/2" -13 Thread

• Configuration/Handle Type: Straight
• Duty Rating: Industrial Duty

• Guard Material: Steel
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 12000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 1/2
• Mounting Type: Arbor

• Power Source: Air Powered

• Rated Power (hp): 1.5
• Rated Power (kW): 1.12

• Sound Pressure/Power Db(A): 82.4 / 93.4

• Vibration Level (m/s2): 2.8
• Vibration Uncertainy K* (m/s2): 1.2
• Warranty: 1-year
• Wheel Diameter (in): 4
• Wheel Thickness (in): 1
• Wheel Type: Type 1

IR 77H90L10

Cone and Plug Air Grinder, 9000 RPM, 1.5 HP, 5/8 in-11 Thread, Side Exhaust

Description: Ingersoll Rand Pro Series are tough, easy to handle, and ready to tackle any project you need them for. They are specially designed for heavy duty applications. With their superior power output, they are best suited for big tasks involving heavy material removal in foundries, welding shops, fabrication facilities, steel mills or shipyards.

Features And Benefits:

• Reliability: With a built-in mist lubricator and motor controller to extend tool life and regulate performance, you can count on these grinders to work the way you want them to any time you pull the trigger.
• Versatile: Compatible with piped-away exhaust kits to make your job easier.

Product Application and Uses:

Specially designed for heavy duty applications best suited for big tasks involving heavy material removal in foundries, welding shops, fabrication facilities, steel mills or shipyards.

• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Load (cfm): 37
• Air Consumption @ Load (l/min): 1048
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/8" -11 Thread

• Color: Black
• Configuration/Handle Type: Straight

• Exhaust Location: Side

• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 9000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 1/2

• Power Source: Air Powered
• Product Length (in): 16.44

• Product Weight (lb): 6
• Rated Power (hp): 1.5
• Rated Power (kW): 1.1

• Vibration Level (m/s2): 4.2
• Vibration Uncertainy K* (m/s2): 3.5
• Warranty: 1-year
• Wheel Type: Cone

IR 8015139

IR 80199599

IR 88H60-129

IR 88H60-23

IR 88H60-27

IR 88H60-67

IR 88H60-961A

IR 88V60-106-9

IR 88V60-38

IR 88V60-53

IR 88V60-86A

IR 88V60-A25

IR 88V60-A524

IR 88V60S106

Vertical Air Grinder, 5" Type 6/11 Wheel, 6000 RPM, 2.1 HP, 5/8 in-11 Thread, Side Exhaust

Description: Ingersoll Rand Pro Series are tough, easy to handle, and ready to tackle any project you need them for. They are specially designed for heavy duty applications. With their superior power output, they are best suited for big tasks involving heavy material removal in foundries, welding shops, fabrication facilities, steel mills or shipyards.

Features And Benefits:

• Safety: The 88 Pro Series' lock-out lever, guard and side-handle safety is designed to increase comfort and block sparks and debris.
• Durability: You can count on the 88 Pro Series to withstand chemical spills, repeated drops, and other harsh environments.
• Reliability: The patented motor controller removes material faster, prevents over speeding and reduces operator fatigue.

Product Application and Uses:

Heavy Stock Removal And Rough Grinding In Metal Fabrication Operations

• Includes: Guard
• Actuation/Throttle Type/Switch Location: Top
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Load (cfm): 61
• Air Consumption @ Load (l/min): 1728
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/8" -11 Thread

• Bearing Type: Ball Bearing

• Color: Black
• Configuration/Handle Type: Vertical
• Duty Rating: Heavy Duty

• Exhaust Location: Side

• Grinder Type: Grinder Type 6/11
• Height Over Spindle (in): 6.1
• Housing Material: Aluminum
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 6000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/4

• Power Source: Air Powered
• Product Length (in): 15.9

• Product Height (in): 8.2
• Product Weight (lb): 8.38
• Rated Power (hp): 2.1

• Sound Pressure/Power Db(A): 86 / 99

• Vibration Level (m/s2): <2.5
• Warranty: 1-year
• Wheel Diameter (in): 5 or 6
• Wheel Type: Type 6, 11

• Lubrication: 50G
• Lubrication: 50P
