GRACO INC. S10595
GRACO INC. S10595 branded products
FUSION AP GUN, AF2929, FT0624
GG 247113
GG 247113
FUSION AP GUN, AF2929, FT0624
Graco 247113 Flat Pattern Fusion Air-Purge Gun with 0.024 in (0.61 mm) Orifice Size, 0.029 in (0.74 mm) Impingement Port and 12-14 in (305-356 mm) Pattern Size
With long-life mix chamber and durable side seals, Fusion guns are designed to reduce maintenance and downtime, and provide a better mix.
Application: For high output spray polyurethane foam and polyurea applications.- Easy air-blast tip cleaning reduces build-up and tip clogging.
- Long-lasting side seals means less downtime for maintenance
- Quick-release fluid housing - lets you easily change the mix chambers without tools
- Ergonomic handle
- Model: Fusion AP
- Series: Flat
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Compatible Material: Adhesives, Polyurethane, Polyurea, Polyurethane Coating, Spray Polyurethane Foam
- Fluid Orifice Size (cm): 0.061
- Fluid Orifice Size (in): 0.024
- Fluid Orifice Size (mm): 0.61
- Gun Type: Air Purge Gun
- Gun Weight (g): 1130
- Gun Weight (kg): 1.1
- Gun Weight (lb): 2.5
- Gun Weight (oz): 40
- Impingement Port Size (in): 0.029
- Impingement Port Size (mm): 0.70
- Maximum Air Inlet Pressure (bar): 9
- Maximum Air Inlet Pressure (kPa): 900
- Maximum Air Inlet Pressure (MPa): 0.9
- Maximum Air Inlet Pressure (psi): 130
- Maximum Air Pressure (bar): 9
- Maximum Air Pressure (kPa): 900
- Maximum Air Pressure (MPa): 0.9
- Maximum Air Pressure (psi): 130
- Maximum Flow Rate @ PSI (lb/min): 50
- Maximum Fluid Pressure (bar): 241
- Maximum Fluid Pressure (kPa): 24100
- Maximum Fluid Pressure (MPa): 24.1
- Maximum Fluid Pressure (psi): 3500
- Maximum Fluid Temperature (°C): 93
- Maximum Fluid Temperature (°F): 200
- Maximum Fluid Pressure (bar): 241
- Maximum Fluid Pressure (kPa): 24100
- Maximum Fluid Pressure (MPa): 24.1
- Maximum Fluid Pressure (psi): 3500
- Maximum Fluid Temperature (°C): 93
- Maximum Fluid Temperature (°F): 200
- Minimum Air Inlet Pressure (bar): 5.5
- Minimum Air Inlet Pressure (kPa): 550
- Minimum Air Inlet Pressure (MPa): 0.55
- Minimum Air Inlet Pressure (psi): 80
- Mix Chamber: 00 (.029)
- Overall Height (cm): 20.6
- Overall Height (in): 8.1
- Overall Height (mm): 206
- Overall Length (cm): 19.1
- Overall Length (in): 7.5
- Overall Length (mm): 191
- Overall Width (cm): 8.4
- Overall Width (in): 3.3
- Overall Width (mm): 84
- Pattern Size (in): 12-14 in @ 24 in from target
$3,940.00
XDV20 VALVE, FLEX
GG 247721
GG 247721
XDV20 VALVE, FLEX
XDV20 Series Control Valve - Flexible Extension - 1/2 in. (13 mm) Inlet - NPTFor standard and heavy-duty applications, both indoor and outdoor, the XDV20 control valves are designed to perform in larger dealerships with longer plumbing runs and greater fluid usage. The control valve is compatible with a wide range of nozzles and fluid extensions and is capable of pumping oil up to 20 gpm (75.7 lpm).
High-flow, non-metered oil dispense for Automotive dealerships, Heavy-duty dealerships, Fast lube centers, Fleet service facilities, In-plant, Lube trucks, and Mining. Lock-on/Lock-off trigger allows hands free operation Sturdy cast body designed for use in tough environments Inlet 1/2 in. NPT with swivel Features flexible extension with high flow nozzle
$516.00
SDV15 Valve, Gear Lube Ext.
GG 247714
GG 247714
SDV15 Valve, Gear Lube Ext.
Graco 247714 SDV15 Series Gear Fluid Control Valve - Gear Extension - 1/2 in. (13 mm) Inlet - NPT
For standard and heavy-duty applications, both indoor and outdoor, the SDV15 control valves are designed to perform in larger dealerships with longer plumbing runs and greater fluid usage. The control valve is compatible with a wide range of nozzles and fluid extensions and is capable of pumping oil up to 15 gpm (56.8 lpm).
Application: Typical applications include Automotive dealerships, Heavy-duty dealerships, Fast lube centers, Fleet service facilities, Service shops, In-plant, Lube trucks, and Mining.- Lock-on/Lock-off trigger allows hands free operation
- Sturdy cast body designed for use in tough environments
- Inlet 1/2 in. NPT with swivel
- Model: SDV15
- Compatible Material: Gear Lube
- Dispense Type: Manual
- Display Type: N/A
- Extension Type: Gear Lube
- Includes: Nozzle, Extension
- Inlet Size (cm): 1.27
- Inlet Size (in): 1/2
- Inlet Size (mm): 12.7
- Inlet Thread Gender: Female
- Inlet Thread Type: NPT
- Maximum Operating Temperature (°C): 82
- Maximum Operating Temperature (°F): 180
- Maximum Working Pressure (bar): 103.4
- Maximum Working Pressure (kPa): 10340
- Maximum Working Pressure (psi): 1500
- Minimum Operating Temperature (°C): -40
- Minimum Operating Temperature (°F): -40
- Outlet Size (cm): 1.905
- Outlet Size (in): 3/4
- Outlet Size (mm): 19.05
- Outlet Thread Gender: Female
- Outlet Thread Type: Straight Thread O-Ring Boss
- Recommended Environment: Indoor, Outdoor
$482.00
SDV15 VALVE, RIGID EXT
GG 247712
GG 247712
SDV15 VALVE, RIGID EXT
SDV15 Series Oil Control Valve - Rigid Extension - 1/2 in. (13 mm) Inlet - NPTFor standard and heavy-duty applications, both indoor and outdoor, the SDV15 control valves are designed to perform in larger dealerships with longer plumbing runs and greater fluid usage. The control valve is compatible with a wide range of nozzles and fluid extensions and is capable of pumping oil up to 15 gpm (56.8 lpm).
Typical applications include Automotive dealerships, Heavy-duty dealerships, Fast lube centers, Fleet service facilities, Service shops, In-plant, Lube trucks, and Mining. Lock-on/Lock-off trigger allows hands free operation Sturdy cast body designed for use in tough environments Inlet 1/2 in. NPT with swivel Features rigid extension with oil nozzle
$469.00
HYDRA-CLEAN SYSTEM, 12:1 CART MT
GG 247549
GG 247549
HYDRA-CLEAN SYSTEM, 12:1 CART MT
Hydra-Clean® 12:1 Cart Mount Pneumatic Pressure Washer PackageClean up your facility the quick, easy and efficient way with Graco Hydra-Clean pressure washers! Designed with Graco’s NXT air motor, it's ideal for industrial and sanitary applications including food processing facilities, heavy duty cleaning, maintenance, shipyards, oil rigs and more.
Ideal for heavy duty cleaning and maintenance for industrial and sanitary applications Great for high pressure cleaning and sanitizing Fits most pressure, flow and material requirements Use with open-head universal drums Designed to use with cold or hot water up to 180°F (82°C) Spray down portability for use in sanitary applications Supports multiple guns Efficient cleaning with water, detergent or chemical solutions
$20,790.00
XDV20 VALVE, RIGID HF
GG 247722
GG 247722
XDV20 VALVE, RIGID HF
XDV20 Series Control Valve - Rigid Extension - 3/4 in. (19 mm) Inlet - NPTFor standard and heavy-duty applications, both indoor and outdoor, the XDV20 control valves are designed to perform in larger dealerships with longer plumbing runs and greater fluid usage. The control valve is compatible with a wide range of nozzles and fluid extensions and is capable of pumping oil up to 20 gpm (75.7 lpm).
High-flow, non-metered oil dispense for Automotive dealerships, Heavy-duty dealerships, Fast lube centers, Fleet service facilities, In-plant, Lube trucks, and Mining. Lock-on/Lock-off trigger allows hands free operation Sturdy cast body designed for use in tough environments Inlet 3/4 in. NPT with swivel Features rigid extension with high flow nozzle
$516.00
SDV15 VALVE, FLEX EXT
GG 247713
GG 247713
SDV15 VALVE, FLEX EXT
SDV15 Series Oil Control Valve - Flexible Extension - 1/2 in. (13 mm) Inlet - NPTFor standard and heavy-duty applications, both indoor and outdoor, the SDV15 control valves are designed to perform in larger dealerships with longer plumbing runs and greater fluid usage. The control valve is compatible with a wide range of nozzles and fluid extensions and is capable of pumping oil up to 15 gpm (56.8 lpm).
Typical applications include Automotive dealerships, Heavy-duty dealerships, Fast lube centers, Fleet service facilities, Service shops, In-plant, Lube trucks, and Mining. Lock-on/Lock-off trigger allows hands free operation Sturdy cast body designed for use in tough environments Inlet 1/2 in. NPT with swivel Features flexible extension with oil nozzle
$469.00
XDV20 VALVE, RIGID
GG 247718
GG 247718
XDV20 VALVE, RIGID
XDV20 Series Control Valve - Rigid Extension - 1/2 in. (13 mm) Inlet - NPTFor standard and heavy-duty applications, both indoor and outdoor, the XDV20 control valves are designed to perform in larger dealerships with longer plumbing runs and greater fluid usage. The control valve is compatible with a wide range of nozzles and fluid extensions and is capable of pumping oil up to 20 gpm (75.7 lpm).
High-flow, non-metered oil dispense for Automotive dealerships, Heavy-duty dealerships, Fast lube centers, Fleet service facilities, In-plant, Lube trucks, and Mining. Lock-on/Lock-off trigger allows hands free operation Sturdy cast body designed for use in tough environments Inlet 1/2 in. NPT with swivel Features rigid extension with high flow nozzle
$516.00
XDV20 VALVE, FLEX HF
GG 247723
GG 247723
XDV20 VALVE, FLEX HF
XDV20 Series Control Valve - Flexible Extension - 3/4 in. (19 mm) Inlet - NPTFor standard and heavy-duty applications, both indoor and outdoor, the XDV20 control valves are designed to perform in larger dealerships with longer plumbing runs and greater fluid usage. The control valve is compatible with a wide range of nozzles and fluid extensions and is capable of pumping oil up to 20 gpm (75.7 lpm).
High-flow, non-metered oil dispense for Automotive dealerships, Heavy-duty dealerships, Fast lube centers, Fleet service facilities, In-plant, Lube trucks, and Mining. Lock-on/Lock-off trigger allows hands free operation Sturdy cast body designed for use in tough environments Inlet 3/4 in. NPT with swivel Features flexible extension with high flow nozzle
$516.00
Flat Pattern Fusion Air-Purge Gun with 0.038 in (0.96 mm) Orifice Size, 0.029 in (0.74 mm) Impingement Port and 16-18 in (406-457 mm) Pattern Size
GG 247117
GG 247117
FUSION AP GUN, AF2929, FT0838
Graco 247117 Flat Pattern Fusion Air-Purge Gun with 0.038 in (0.96 mm) Orifice Size, 0.029 in (0.74 mm) Impingement Port and 16-18 in (406-457 mm) Pattern Size
With long-life mix chamber and durable side seals, Fusion guns are designed to reduce maintenance and downtime, and provide a better mix.
Application: For high output spray polyurethane foam and polyurea applications.- Easy air-blast tip cleaning reduces build-up and tip clogging.
- Long-lasting side seals means less downtime for maintenance
- Quick-release fluid housing - lets you easily change the mix chambers without tools
- Ergonomic handle
- Model: Fusion AP
- Series: Flat
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Compatible Material: Polyurea, Non-Flammable Polyurethane Foam
- Fluid Orifice Size (cm): 0.097
- Fluid Orifice Size (in): 0.038
- Fluid Orifice Size (mm): 0.97
- Gun Type: Air Purge Gun
- Gun Weight (g): 1130
- Gun Weight (kg): 1.1
- Gun Weight (lb): 2.5
- Gun Weight (oz): 40
- Impingement Port Size (in): 0.029
- Impingement Port Size (mm): 0.70
- Includes: AF2929 Mix Chamber, FT0838 Flat Tip
- Maximum Air Inlet Pressure (bar): 9
- Maximum Air Inlet Pressure (kPa): 900
- Maximum Air Inlet Pressure (MPa): 0.9
- Maximum Air Inlet Pressure (psi): 130
- Maximum Air Pressure (bar): 9
- Maximum Air Pressure (kPa): 900
- Maximum Air Pressure (MPa): 0.9
- Maximum Air Pressure (psi): 130
- Maximum Fluid Pressure (bar): 241
- Maximum Fluid Pressure (kPa): 24100
- Maximum Fluid Pressure (MPa): 24.1
- Maximum Fluid Pressure (psi): 3500
- Maximum Fluid Temperature ( degree C): 93
- Maximum Fluid Temperature ( degree F): 200
- Maximum Fluid Pressure (bar): 241
- Maximum Fluid Pressure (kPa): 24100
- Maximum Fluid Pressure (MPa): 24.1
- Maximum Fluid Pressure (psi): 3500
- Maximum Fluid Temperature ( degree C): 93
- Maximum Fluid Temperature ( degree F): 200
- Minimum Air Inlet Pressure (bar): 5.5
- Minimum Air Inlet Pressure (kPa): 550
- Minimum Air Inlet Pressure (MPa): 0.55
- Minimum Air Inlet Pressure (psi): 80
- Mix Chamber: 00 (.029)
- Overall Height (cm): 20.6
- Overall Height (in): 8.1
- Overall Height (mm): 206
- Overall Length (cm): 19.1
- Overall Length (in): 7.5
- Overall Length (mm): 191
- Overall Width (cm): 8.4
- Overall Width (in): 3.3
- Overall Width (mm): 84
- Pattern Size (in): 16-18 in @ 24 in from target
$3,940.00
CHANNEL, XD ENCLOSURE, 1 REEL
GG 24N323
GG 24N323
CHANNEL, XD ENCLOSURE, 1 REEL
Graco 24N323 XD Series Hose Reel Enclosed Reel Mounting Channel - Accommodates 1 Reel
- Number of Pieces: 9
$142.00
HUSKY PUMP, 515AC-PP01AAC3SSSSPOPT
GG 24N097
GG 24N097
HUSKY PUMP, 515AC-PP01AAC3SSSSPOPT
Graco 24N097 Husky 515 AC Pump, PP Center Section, SS Seats, SS Balls & PO Diaphragm
Our Husky air-operated double diaphragm pumps are loaded with features to help you get the job done right, every time, and are built to save you money. The Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability.
- Rugged construction
- Heavy-duty design
- Benefits of the Husky 515 double diaphragm pump
- Delivery up to 15 gpm (56.7 lpm)
- Easy-to-service air valve and ball checks
- Reliable air valve for years of dependable performance
- Lube-free for cleaner operation
- DataTrak™ available to prevent pump runaway and track material usage
Center and end porting options.
No mechanical seals to cause fluid leaks or failures
Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels
Easy-to-service air valve and ball checks
Operates on as little as 20 psi (1.4 bar, 0.14 MPa)
Split manifold option to pump multiple fluids without mixing
- Model: Husky
- Series: 515
- Air Exhaust Port Size (in): 3/8
- Air Exhaust Port Thread Gender: Female
- Air Exhaust Port Thread Type: NPT
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Application: Industrial
- Ball Material: 316 Stainless Steel
- Center Section Material: Polypropylene
- Compatible Material: Antifreeze, Detergents, Resin, Polymers, Motor Oil, Grease & Oil, Hydraulic Fluid, Transmission Fluid, Cutting Oil, Water - Wastewater Treatment, Ink
- Connection Type: Threaded
- Diaphragm Compatible Material: PTFE
- Diaphragm Material: PTFE Overmold
- Fluid Inlet Size (cm): 1.27
- Fluid Inlet Size (in): 1/2
- Fluid Inlet Size (mm): 12.7
- Fluid Inlet Thread Gender: Female
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 1.27
- Fluid Outlet Size (in): 1/2
- Fluid Outlet Size (mm): 12.7
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Fluid Section Material: Acetal
- Manifold Configuration: Center Port
- Manifold O-Ring Material: PTFE
- Material: Acetal
- Maximum Air Consumption (SCFM): 28
- Maximum Air Pressure (bar): 7
- Maximum Air Pressure (kPa): 700
- Maximum Air Pressure (MPa): 0.7
- Maximum Air Pressure (psi): 100
- Maximum Cycle Rate (CPM): 400
- Maximum Flow Rate (GPM): 15
- Maximum Flow Rate (L/min): 56.8
- Maximum Fluid Pressure (bar): 7
- Maximum Fluid Pressure (kPa): 700
Offers long life, increased productivity and lower overall cost of ownership
- Benefits of the Husky 515 double diaphragm pump
Resists corrosion for reliable performance and long life
- Heavy-duty design
$2,080.00
VALVE, VENT, 12VDC, N.O. NPT, DEU RH
GG 24M478
GG 24M478
VALVE, VENT, 12VDC, N.O. NPT, DEU RH
Direct-Mount Vent Valves for G3™ Pumps - NPT, 12 VDC, 500-3500 psi (35-241 bar), Normally Open, RHIndustry leading feature for your lube system needs.
Vent valves are designed to be mounted to the G3 Electric Lubrication Pump to make it simple to install your injector based lube systems. Easily mounts to your G3 pump. Eliminates time and material costs associated with remote mounted vent valves. 12 VDC Normally Open The normally open valve works with the G3 Standard no control pump. With an external control just add power to the pump and valve to run a lube cycle, and remove power from both to vent pressure. Adjustable pressure relief is integrated into the valve, no need to purchase an additional relief valve. Deutsch Power Connection
$441.00
Kit, Air Cap
GG 24N279
GG 24N279
KIT, AIR CAP
Graco 24N279 Air Cap, Black, optimized for medium and heavy viscosity and high solid coatings at standard production rates, round end
$137.50
HUSKY PUMP, 515F-PP01AP3PVPTPOPT
GG 24N095
GG 24N095
HUSKY PUMP, 515F-PP01AP3PVPTPOPT
Husky 515 PVDF Pump, PP Center Section, PVDF Seats, PTFE Balls & PO DiaphragmThe Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.
The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability.
Center and end porting options. No mechanical seals to cause fluid leaks or failures Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels Easy-to-service air valve and ball checks Operates on as little as 20 psi (1.4 bar, 0.14 MPa) Split manifold option to pump multiple fluids without mixing Delivery up to 15 gpm (56.7 lpm) Easy-to-service air valve and ball checks Reliable air valve for years of dependable performance
$2,360.00
HUSKY PUMP, 716S-PP01AS1SSSSPOPT
GG 24N262
GG 24N262
HUSKY PUMP, 716S-PP01AS1SSSSPOPT
Husky 716 SS Pump, PP Center Section, SS Seats, SS Balls & PO DiaphragmThe Husky 716 air operated diaphragm pump features an external controller for remote control capabilities.
Center- and end-porting No mechanical seals which causes fluid leaks or failures Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels Easy-to-service air valve and ball checks 3/4 in (19.05 mm) center- and end-porting No seals to leak or fail Quiet running less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels Easy-to-service air valve and ball checks
$3,540.00
HUSKY PUMP, 515AC-PP01AA3ACPTPOPT
GG 24N096
GG 24N096
HUSKY PUMP, 515AC-PP01AA3ACPTPOPT
Husky 515 1/2 in NPT AC Pump, PP Center Section, AC Seats, PTFE Balls & PO DiaphragmOur Husky air-operated double diaphragm pumps are loaded with features to help you get the job done right, every time, and are built to save you money. The Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability.
Rugged construction
- Resists corrosion for reliable performance and long life
Heavy-duty design
- Offers long life, increased productivity and lower overall cost of ownership
Benefits of the Husky 515 double diaphragm pump
- Center and end porting options.
- No mechanical seals to cause fluid leaks or failures
- Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels
- Easy-to-service air valve and ball checks
- Operates on as little as 20 psi (1.4 bar, 0.14 MPa)
- Split manifold option to pump multiple fluids without mixing
$1,905.00
Kit, Meter, I.S. Corliolis 1/4"
GG 24M261
GG 24M261
KIT, METER, I.S. CORLIOLIS 1/4"
Graco 24M261 Coriolis Meter Kit, Cubemass DCI Meter with 1/4 in (6 mm) metering tube for ProControl 1KS and ProMix 2KS/2KE/3KS
$16,530.00
KIT, ACCESSORY, FILL STUD/CAP
GG 24M644
GG 24M644
KIT, ACCESSORY, FILL STUD/CAP
G-Series Pump Accessories - High Capacity Fill Zerk with Quick Disconnect and Dust Cover For use with G-Series Pumps.High capacity fill zerk with quick disconnect and dust cover
$79.25
HUSKY PUMP, 716A-PP01AA1SSPTPOPT
GG 24N258
GG 24N258
HUSKY PUMP, 716A-PP01AA1SSPTPOPT
Husky 716 AL Pump, PP Center Section, SS Seats, PTFE Balls & PO DiaphragmThe Husky 716 air operated diaphragm pump features an external controller for remote control capabilities.
Center- and end-porting No mechanical seals which causes fluid leaks or failures Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels Easy-to-service air valve and ball checks 3/4 in (19.05 mm) center- and end-porting No seals to leak or fail Quiet running less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels Easy-to-service air valve and ball checks
$1,870.00
HUSKY PUMP, 515P-PP01AP3PPPTPOPT
GG 24N093
GG 24N093
HUSKY PUMP, 515P-PP01AP3PPPTPOPT
Husky 515 1/2 in NPT PP Pump, PP Center Section, PP Seats, PTFE Balls & PO DiaphragmThe Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.
The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability.
Center and end porting options. No mechanical seals to cause fluid leaks or failures Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels Easy-to-service air valve and ball checks Operates on as little as 20 psi (1.4 bar, 0.14 MPa) Split manifold option to pump multiple fluids without mixing Delivery up to 15 gpm (56.7 lpm) Easy-to-service air valve and ball checks Reliable air valve for years of dependable performance
$1,595.00
HUSKY PUMP, 716A-PP01AA1SSSSPOPT
GG 24N259
GG 24N259
HUSKY PUMP, 716A-PP01AA1SSSSPOPT
Graco 24N259 Husky 716 AL Pump, PP Center Section, SS Seats, SS Balls & PO Diaphragm
The Husky 716 air operated diaphragm pump features an external controller for remote control capabilities.
- Center- and end-porting
- No mechanical seals which causes fluid leaks or failures
- Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels
- 3/4 in (19.05 mm) center- and end-porting
- No seals to leak or fail
- Quiet running less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels
- Easy-to-service air valve and ball checks
- Model: Husky
- Series: 716
- Air Exhaust Port Size (in): 3/8
- Air Exhaust Port Thread Gender: Female
- Air Exhaust Port Thread Type: NPT
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Application: Industrial
- Ball Material: 316 Stainless Steel
- Center Section Material: Polypropylene
- Compatible Material: Antifreeze, Detergents, Motor Oil, Grease & Oil, Hydraulic Fluid, Cutting Oil, Water - Wastewater Treatment, Water, Ink
- Connection Type: Threaded
- Diaphragm Compatible Material: PTFE
- Diaphragm Material: PTFE Overmold
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Gender: Female
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 1.905
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Size (mm): 19.05
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Fluid Section Material: Aluminum
- Manifold Configuration: Center Port
- Manifold O-Ring Material: PTFE
- Material: Aluminum
- Maximum Air Consumption (SCFM): 28
- Maximum Air Pressure (bar): 7
- Maximum Air Pressure (kPa): 700
- Maximum Air Pressure (MPa): 0.7
- Maximum Air Pressure (psi): 100
- Maximum Cycle Rate (CPM): 400
- Maximum Flow Rate (GPM): 16
- Maximum Flow Rate (L/min): 60.6
- Maximum Fluid Pressure (bar): 7
- Maximum Fluid Pressure (kPa): 700
- Maximum Fluid Pressure (MPa): 0.7
- Maximum Fluid Pressure (psi): 100
- Maximum Fluid Pressure (bar): 7
- Maximum Fluid Pressure (kPa): 700
- Maximum Fluid Pressure (MPa): 0.7
- Maximum Fluid Pressure (psi): 100
- Maximum Operating Temperature (°C): 107
- Maximum Operating Temperature (°F): 225
- Maximum Solid Size (cm): 0.2383
- Maximum Solid Size (in): 0.09375
- Maximum Solid Size (mm): 2.4
- Minimum Operating Temperature (°C): 4
- Minimum Operating Temperature (°F): 40
- Overall Height (in): 10.43
- Power Source: Air
$1,890.00
GLC CONTROL, 2200
GG 24N468
GG 24N468
GLC CONTROL, 2200
Graco 24N468 GLC 2200 Series Controller
You spend a lot on your equipment. The GLC 2200 controller helps protect components by alerting you to lube events, failures and low lubrication levels. You have peace of mind knowing your investment is protected.
Application: Mount in-cab to control automatic lubrication systems- Easy to mount without having to open up the control box
- LEDs let you know what your system is doing at a glance
- Easy to read digital display makes it simple to program and monitor your equipment
- Simple icon based push buttons make programming easy
- Color coded wiring harness with flying leads and easy to follow wiring diagrams makes installations efficient
- Model: GLC
- Series: 2200
- Amperage (A): 7, 9
- Application: In-Plant Machinery, Off-Road Equipment
- For Use With: Automatic Lubrication Systems
- Intrusion Rating: IP54
- Maximum Operating Temperature (°C): 80
- Maximum Operating Temperature (°F): 176
- Maximum Storage Temperature (°C): 80
- Maximum Storage Temperature (°F): 176
- Maximum Voltage (V dc): 30
- Minimum Operating Temperature (°C): -40
- Minimum Operating Temperature (°F): -40
- Minimum Storage Temperature (°C): -40
- Minimum Storage Temperature (°F): -40
- Power Consumption (W): 1
- Power Source: DC
$564.00
Kit, Air Cap
GG 24N477
GG 24N477
KIT, AIR CAP
Graco 24N477 Air Cap, Black, 15-17 in (381-432 mm) length, light to medium viscosity, round end
$137.50
WB3000 SYSTEM, ISOLATION, WB, AA
GG 24N551
GG 24N551
WB3000 SYSTEM, ISOLATION, WB, AA
Graco 24N551 WB3000 Waterborne Iso Enclosure, Pro Xp60 ES AA WB Gun, Grounded Air/Unshielded WB Fluid Hoses, FM Approved & Compliant with EN50059
Graco&prime, s WB3000 is the dependable way to isolate waterborne coatings when spraying with electrostatic equipment. Ideal for spray booth systems.
- Ideal for high pressure waterborne material spraying with the Pro Xp60 AA WB gun for a superior finish quality and operator comfort
- Merkur ES 30:1 pump is one of the most efficient sprayers designed to use less material and reduce air usage and pulsation
- Standard voltage display allows for easy monitoring of voltage for overall performance
- Electrostatic gun Smart Controls help you analyze performance, adapt to your voltage needs and make troubleshooting easier
- Portable cabinet increases mobility for a wide variety of applications
- Model: WB3000
- Compatible Material: Waterborne, Single Components, Topcoats, Lacquer
- Convertible: Non-Convertible
- Gun Included: 1
- Gun Model: Waterborne
- Gun Technology: Electrostatic
- Gun Type: Electrostatic
- Includes: Standard Electrostatic Air-Assisted Spray Gun, Unshielded Waterborne Fluid Hose
- Maximum Flow Rate (GPM): 0.4
- Maximum Sound Pressure Level (dB(A)): 99
- Maximum Working Pressure (bar): 210
- Maximum Working Pressure (kPa): 21000
- Maximum Working Pressure (MPa): 21
- Maximum Working Pressure (psi): 3000
- Motor Type: Pneumatic
- Number of Guns: 1
- Power Source: Air
- Pressure Type: High Pressure
- Product Type: Spray Package
- Pump Ratio: 30:1
- Pump Sleeve Material: Stainless Steel
- Pump Type: Pneumatic Piston Pump
$42,710.00
Kit, Adapter, 60Kv And 85Kv
GG 24N528
GG 24N528
KIT,ADAPTER, 60KV AND 85KV
Graco 24N528 Gun Flush Box Adapter Kit for 60 kV and 85 kV guns
Application: To convert existing gun flush boxes to hold Pro Xp guns- Coating Type: Standard, Specialty
- Compatible Paint Type: Automotive, Base Coat, Clear Coat, Enamels, High Solids, Metallics, Plural Component Materials, Primers, Solventborne, Urethanes
$748.00
Kit, Gun Covers, 85Kv, 10 Per Box
GG 24N604
GG 24N604
KIT,GUN COVERS, 85KV
Graco 24N604 Gun Covers for 85 kV guns, box of 10
$102.50
Kit, Gun Covers, 40Kv And 60Kv 10/Bx
GG 24N603
GG 24N603
KIT,GUN COVERS, 40KV AND 60KV
Graco 24N603 Gun Covers for 40 kV and 60 kV guns, box of 10
$102.50
Kit, Nozzle, 1.50 Mm
GG 24N616
GG 24N616
KIT, NOZZLE, 1.50 MM
Graco 24N616 Fluid Nozzle for Standard Materials, 1.5 mm Orifice Size
- Coating Type: Standard, Specialty
- Compatible Paint Type: Automotive, Base Coat, Clear Coat, Enamels, High Solids, Metallics, Plural Component Materials, Primers, Solventborne, Urethanes
$137.50
Kit, Nozzle, High Wear, 1.20 M
GG 24N622
GG 24N622
KIT, NOZZLE, HIGH WEAR, 1.20 M
Graco 24N622 High Wear Fluid Nozzle for Abrasive Materials, 1.2 mm (.047 inch) Orifice Size, Blue
$174.50
Kit, Nozzle, High Wear, 1.50 M
GG 24N623
GG 24N623
KIT, NOZZLE, HIGH WEAR, 1.50 M
Graco 24N623 High Wear Fluid Nozzle for Abrasive Materials- 1.50 mm Orifice Size
$170.50
Kit, Air Inlet Swivel
GG 24N626
GG 24N626
KIT, AIR INLET SWIVEL
Graco 24N626 Swivel, Air Inlet, M12 x 1/ npsm (m), left handed thread for 60 kV Electrostatic Air Spray Gun
$65.50
Kit, Packing, Rod Assembly, 40Kv
GG 24N653
GG 24N653
KIT,PACKING,ROD ASSY,40KV
Graco 24N653 40 kV Packing Rod Assembly
$256.50
Kit, Packing Rod Assembly, 85Kv
GG 24N655
GG 24N655
KIT,PACKING ROD ASSY,85KV
Graco 24N655 85 kV Packing Rod Assembly
$386.00
Kit, Power Supply, 85Kv
GG 24N661
GG 24N661
KIT, POWER SUPPLY, 85KV
Graco 24N661 85 kV Gun Power Supply Kit
$4,750.00
Kit, Power Supply, 40Kv
GG 24N659
GG 24N659
KIT, POWER SUPPLY, 40KV
Graco 24N659 40 kV Gun Power Supply Kit
- Coating Type: Abrasive, Metallic, High Conductivity, High Wear
- Compatible Paint Type: Automotive, Base Coat, Clear Coat, Enamels, High Solids, Metallics, Plural Component Materials, Primers, Solventborne, Urethanes
$2,050.00
Kit, Power Supply, 60Kv
GG 24N660
GG 24N660
KIT, POWER SUPPLY, 60KV
Graco 24N660 60 kV Gun Power Supply Kit
$2,990.00
Kit, Valve, Es On/Off, As
GG 24N630
GG 24N630
KIT,VALVE,ES ON/OFF,AS
Graco 24N630 ES On-Off and Fluid Adjustment Valve Kit
$248.50
Kit, Valve, Fan Air
GG 24N634
GG 24N634
KIT, VALVE, FAN AIR
Graco 24N634 Standard Fan Air Adjustment Valve Kit
$171.00
Kit, Gun Body Assy, 85Kv
GG 24N667
GG 24N667
KIT, GUN BODY ASSY, 85KV
Graco 24N667 85 kV Gun Body Assembly Kit
$1,375.00
Kit, Retaining Ring
GG 24N644
GG 24N644
KIT, RETAINING RING
Graco 24N644 Ring for Standad Pro Xp Auto Waterborne AA Gun Models Rear Manifold
$25.60
Kit, Needle, Electrode
GG 24N651
GG 24N651
KIT, NEEDLE, ELECTRODE
Graco 24N651 Standard Electrode Needle Kit
- Electrode assembly with a flexible snap-back wire
- The standard wire is resistant to abrasive fluid wear and also resistant to handling damage
- Coating Type: Standard, Specialty
- Compatible Paint Type: Automotive, Base Coat, Clear Coat, Enamels, High Solids, Metallics, Plural Component Materials, Primers, Solventborne, Urethanes
$68.75
Kit, Fluid Tube, 85Kv
GG 24N697
GG 24N697
KIT,FLUID TUBE,85KV
Graco 24N697 Standard Fluid Tube with Sleeve for 85 kV ProXp Electrostatic Air Spray Gun
$68.50
Kit, Packing Rod Assy, 60Kv
GG 24N654
GG 24N654
KIT, PACKING ROD ASSY, 60KV
Graco 24N654 60 kV Packing Packing Rod Assembly
- Ball Check Size (in): 1
- Ball Material: Silicon Nitride
- Coating Type: Severe Duty
$343.00
