GRACO INC. S10595

GG 562920

MODEL 25 LUBRICATOR

Graco 562920 Manzel Model 25 Lubricator

Manzel Model 25 Force Feed Lubricators are economical, general purpose units of double plunger design for precise metering of lubricants (either mineral oil base or synthetics). All working parts are totally enclosed - away from dust, water and impurities - and self-lubricated at all times by the lubricant in the reservoir.

• General-Purpose Lubrication: automatic, precision metering for all types of machinery.
• Pressures: Up to 1000 psi (69 bar)
• Type Pumping Unit: Clear-Vue. Sight Feed Chamber functions at atmospheric pressure. Shows amount of lubricant being pumped.
• Unitized Construction: Contains complete feed regulating mechanism. Equipped with inlet strainer.
• Displacement, Output: 1/4 to 12 drops per stroke with 5/16 in plunger, 1/6 to 6 drops per stroke with 3/16 in plunger.
• Reservoirs: Single Compartment, sheet metal construction.
• Feed Regulator: External screw-type precisely adjustable while idle or in operation.
• Lubriquip part number 225-001-970

• Model: Manzel
• Series: Model 25

• Compatible Material: Oil

GG 563093

FILTER, CANISTER 10

Graco 563093 Replacement Element for Spin-On Oil Filters - 10 Micron

• 10 micron Replacement Filter Element for assemblies 563092, 563095, 564343
• Lubriquip part number 473-000-262

• For Use With: Meter-Flo Pump Packages, Spin-On Oil Filters

GG 562714

MSP VALVE, ASSY MSP 20S

Graco 562714 Trabon MSP Modular Divider Valve - MSP-20S - 0.040 in cu (0.66 cm cu )

The Trabon MSP Series sets the industry standard for quality, reliability, and ease of use features. It was the original modular-style series progressive divider valve and is still the best!

• Quick change valve sections can be removed from the base assembly without disturbing any lube lines - minimizing labor cost and maximizing your machine uptime
• Accessories such as magnetic and electronic proximity switch cycle indicators provide positive assurance of a successful lube event.
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 106-100-045

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 0.040

• Divider Valve Series: MSP

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 200

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 176
• Maximum Operating Temperature ( degree F): 350

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (psi): 3500

• Minimum Working Pressure (bar): 14

• Minimum Working Pressure (psi): 200

• Number of Outlets: 1

GG 563074

FILTER, INLET RESTRICTOR, NPTF

Graco 563074 MSP Standard Zero Leak Inlet 90 micron Oil Filter/Restrictor, NPT

• MSP Standard Zero Leak Inlet 90 micron Oil Filter/Restrictor, NPT
• Lubriquip part number 463-410-204

GG 563095

FILTER, 10 MICRON

Graco 563095 Spin-On Oil Filter Assembly with External 150 psi Relief Valve - 200 psi, 3/4 in. NPT, 10 Micron

• 10 micron Spin-On Filter Assembly, NPT, External 150 psi (10.3 bar) Relief
• Lubriquip part number 473-000-271

• Maximum Working Pressure (bar): 14
• Maximum Working Pressure (kPa): 1400
• Maximum Working Pressure (MPa): 140
• Maximum Working Pressure (psi): 200

• Port Size (cm): 1.905
• Port Size (in): 3/4
• Port Size (mm): 19.05

GG 563156

VALVE, RELIEF, 1/4 NPT, 750 PSI

Graco 563156 Automatic Relief Indicator for MX Divider Valves, 750 psi (52 bar)

Keep your machine running while lubrication gets to critical points. These performance indicators pinpoint lube line blockages but allow the lube system to continue to supply lubrication to points that are not blocked.

• No time or effort required for reset after blockage is cleared
• Easy information on blocked lines, high system pressure or blocked bearings
• Works with MSP, MX, MXP, MJ and MHH divider valves

• Model: Trabon

• Application: In-Plant Machinery, Off-Road Equipment, Compressor Equipment

• Compatible Material: Oil, Grease

• Connection Size (in): 0.25

• Indicator Type: Automatic Relief Indicators

• Maximum Working Pressure (bar): 51
• Maximum Working Pressure (kPa): 5100
• Maximum Working Pressure (MPa): 5
• Maximum Working Pressure (psi): 750

• Overall Length (cm): 3
• Overall Length (in): 1.37
• Overall Length (mm): 35

GG 562712

MSP VALVE, ASSY MSP 10S

Graco 562712 Trabon MSP Modular Divider Valve - MSP-10S - 0.020 in cu (0.33 cm cu )

The Trabon MSP Series sets the industry standard for quality, reliability, and ease of use features. It was the original modular-style series progressive divider valve and is still the best!

• Quick change valve sections can be removed from the base assembly without disturbing any lube lines - minimizing labor cost and maximizing your machine uptime
• Accessories such as magnetic and electronic proximity switch cycle indicators provide positive assurance of a successful lube event.
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 106-100-025

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 0.020

• Divider Valve Series: MSP

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 200

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 176
• Maximum Operating Temperature ( degree F): 350

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (psi): 3500

• Minimum Working Pressure (bar): 14

• Minimum Working Pressure (psi): 200

• Number of Outlets: 1

GG 563148

SWIVEL, 90 1/8 PORT NITRILE

Graco 563148 Compact 90 degree Angle Swivel - 1/8 inch, Nitrile

The Trabon Straight and Angle Swivels are available in standard ball bearing or compact types. Primarily designed for medium to high pressure service in centralized oil and grease systems, these swivels provide a simple and inexpensive means of making line connections between either stationary, or oscillating surfaces.

• 90 degree Swivel Adapter - 1/8 inch (3.2 mm) NPT x 1/8 inch (3.2 mm) NPT Female
• Lubriquip part number 501-257-000
• Trabon part number 1257

• Angle ( degree ): 90
• Application: On-Road Vehicles

• Compatible Material: Oil, Grease

• Connection Type: Threaded

• For Use With: Pipe

• Material: Steel

• Maximum Working Pressure (bar): 34
• Maximum Working Pressure (kPa): 3400
• Maximum Working Pressure (MPa): 3.4
• Maximum Working Pressure (psi): 500

GG 563161

VALVE, RELIEF, 1/4 NPT, 3000 PSI

Graco 563161 Automatic Relief Indicator for MX Divider Valves, 3000 psi (207 bar)

Keep your machine running while lubrication gets to critical points. These performance indicators pinpoint lube line blockages but allow the lube system to continue to supply lubrication to points that are not blocked.

• No time or effort required for reset after blockage is cleared
• Easy information on blocked lines, high system pressure or blocked bearings
• Works with MSP, MX, MXP, MJ and MHH divider valves

• Model: Trabon

• Application: In-Plant Machinery, Off-Road Equipment, Compressor Equipment

• Compatible Material: Oil, Grease

• Connection Size (in): 0.25

• Indicator Type: Automatic Relief Indicators

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 21
• Maximum Working Pressure (psi): 3000

• Overall Length (cm): 3
• Overall Length (in): 1.37
• Overall Length (mm): 35

GG 563160

VALVE, RELIEF, 1/4 NPT, 2500 PSI

Graco 563160 Automatic Relief Indicator for MX Divider Valves, 2500 psi (172 bar)

Keep your machine running while lubrication gets to critical points. These performance indicators pinpoint lube line blockages but allow the lube system to continue to supply lubrication to points that are not blocked.

• No time or effort required for reset after blockage is cleared
• Easy information on blocked lines, high system pressure or blocked bearings
• Works with MSP, MX, MXP, MJ and MHH divider valves

• Model: Trabon

• Application: In-Plant Machinery, Off-Road Equipment, Compressor Equipment

• Compatible Material: Oil, Grease

• Connection Size (in): 0.25

• Indicator Type: Automatic Relief Indicators

• Maximum Working Pressure (bar): 172
• Maximum Working Pressure (kPa): 17200
• Maximum Working Pressure (MPa): 17
• Maximum Working Pressure (psi): 2500

• Overall Length (cm): 3
• Overall Length (in): 1.37
• Overall Length (mm): 35

GG 563184

FITTING, BLOWOUT 1/4 NPTF 2350 PSI

Graco 563184 Rupture-to-Atmosphere Indicators for MX Divider Valves - 2350 psi, 1/4 inch-18 inch NPT(f) - Grease

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Trabon part number 9206-16

• Compatible Material: Grease

• Connection Size (in): 0.25

• Indicator Type: Rupture-to-Atmosphere Indicator

• Maximum Working Pressure (bar): 162
• Maximum Working Pressure (kPa): 16200
• Maximum Working Pressure (MPa): 16.2
• Maximum Working Pressure (psi): 2350

GG 563131

BLOCK, SPINDL-GARD, .0030

Graco 563131 High Speed Spindl-Gard (HSSG) Block - 0.0030 cu in displacement

• 0.0030 in3 displacement
• Lubriquip part number 484-095-229

GG 563091

FILTER, ASSY LUBE

Graco 563091 In-Line Oil Filter - MSP Standard Inlet Filter, 3500 psi, 1/4-18 NPTF, 10 Micron, Lubriquip part number 473-000-234

• MSP Standard Inlet 10 micron Oil Filter, NPT
• Uses replacement filter element p/n 557134.

• For Use With: MSP Divider Valves

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (MPa): 2410
• Maximum Working Pressure (psi): 3500

• Port Size (cm): 0.635
• Port Size (in): 1/4
• Port Size (mm): 6.35

GG 563200

MHH VALVE, CHECK, 1/8 NPT, REV, 5000

Graco 563200 Single Ball Check Valve - 35 psi Nominal Cracking Pressure, 1/8 in NPSF (F) x 1/8 in NPTF (M), Steel, 5,000 psi

• Lubriquip part number 509-355-030
• Trabon part number 9355-35

• Application: Compressor Equipment

• Ball Material: Steel

• Body Material: Steel

• Compatible Material: Oil, Grease

• Inlet Size (cm): 0.3175
• Inlet Size (in): 1/8
• Inlet Size (mm): 3.175

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (MPa): 34.5
• Maximum Working Pressure (psi): 5000

• Number of Balls: Single Ball

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPS

GG 563198

VALVE, CHECK 1/8 250 PSI

Graco 563198 Single Ball Check Valve - 250 psi Nominal Cracking Pressure, 1/8 in NPTF (M) x 1/8 in NPSF (F), Steel, 5,000 psi

• Single Ball Check Valve
• 250 psi nominal cracking pressure
• 1/8 inch (3.2 mm) NPTF (M) x 1/8 inch (3.2 mm) NPSF (F)
• 5,000 psi max
• Lubriquip part number 509-350-250
• Trabon part number 9350-250

• Application: Compressor Equipment

• Ball Material: Steel

• Body Material: Steel

• Compatible Material: Oil, Grease

• Inlet Size (cm): 0.3175
• Inlet Size (in): 1/8
• Inlet Size (mm): 3.175

• Inlet Thread Type: NPTF

• Maximum Cracking Pressure (bar): 17.2
• Maximum Cracking Pressure (kPa): 1720
• Maximum Cracking Pressure (MPa): 1.72
• Maximum Cracking Pressure (psi): 250

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (MPa): 34.5
• Maximum Working Pressure (psi): 5000

• Number of Balls: Single Ball

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Type: NPSF

GG 563207

VALVE, CHECK, 1/4 NPT, 35

Graco 563207 Single Ball Check Valve - 35 psi Nominal Cracking Pressure, 1/4 in NPTF (M) x 1/4 in NPSF (F), Steel, 5,000 psi

• Double Ball Check Valve
• 35 psi nominal cracking pressure
• 1/4 inch (6.4 mm) NPTF (M) x 1/4 inch (6.4 mm) NPSF (F)
• 5,000 psi max
• Lubriquip part number 509-360-030
• Trabon part number 9360-35

• Application: Compressor Equipment

• Ball Material: Steel

• Body Material: Steel

• Compatible Material: Oil, Grease

• Inlet Size (cm): 0.3175
• Inlet Size (in): 1/8
• Inlet Size (mm): 3.175

• Inlet Thread Type: NPTF

• Maximum Cracking Pressure (bar): 2.41
• Maximum Cracking Pressure (kPa): 241
• Maximum Cracking Pressure (MPa): 0.241
• Maximum Cracking Pressure (psi): 35

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (MPa): 34.5
• Maximum Working Pressure (psi): 5000

• Number of Balls: Single Ball

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Type: NPSF

GG 563150

SWIVEL, 180 1/8 PORT NITRILE

Graco 563150 Compact 180 degree Straight Swivel - 1/8 inch, Nitrile

• 180 degree Compact Swivel - 1/8 inch (3.2 mm)
• Lubriquip part number 501-258-000
• Trabon part number 1258

• Angle ( degree ): 180

• Connection Type: Threaded

GG 563096

FILTER, SPIN-ON 25 MICRON NPT

Graco 563096 Spin-On Filter Assembly - 25 Micron, NPT, External 150 psi Relief

• 25 micron Spin-On Filter Assembly, NPT, External 150 psi (10.3 bar) Relief
• Lubriquip part number 473-000-275

• Maximum Working Pressure (bar): 14
• Maximum Working Pressure (kPa): 1400
• Maximum Working Pressure (MPa): 140
• Maximum Working Pressure (psi): 200

• Port Size (cm): 1.905
• Port Size (in): 3/4
• Port Size (mm): 19.05

GG 563167

GG 563213

SWIVEL, BALL 1/8 180

Graco 563213 180 degree Straight Swivel - 1/8 inch (3.2 mm)

• 180 degree Straight Swivel - 1/8 inch (3.2 mm)
• Lubriquip part number 509-402-000
• Trabon part number 9402

• Angle ( degree ): 180

• Connection Type: Threaded

• For Use With: Pipe

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

GG 562902

TUBE, RESV REPLACE 12LB PLSTC

Graco 562902 Modu-Flo and E-Pump Spare Parts and Accessories - 12 pt./lb. Plastic Replacement Reservoir Assembly, 6 in OD x 13 in long

• Reservoir Repair Kits - Plastic tube with u-cup seal for part numbers 562892 and 562896
• Lubriquip part number 185-100-730

• Compatible Material: Oil, Grease

• Includes: Reservoir

• Material: Plastic

GG 563211

VALVE, CHECK REVERSE 1/4 35 PSI

Graco 563211 Single Ball Check Valve - 35 psi Nominal Cracking Pressure, 1/4 in NPSF (F) x 1/4 in NPTF (M), Steel, 5,000 psi

• Single Ball Check Valve
• 35 psi nominal cracking pressure
• 1/4 inch (6.4 mm) NPSF (F) x 1/4 inch (6.4 mm) NPTF (M)
• 5,000 psi max
• Lubriquip part number 509-365-030
• Trabon part number 9365-35

• Application: Compressor Equipment

• Ball Material: Steel

• Body Material: Steel

• Compatible Material: Oil, Grease

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: SAE

• Maximum Cracking Pressure (bar): 2.41
• Maximum Cracking Pressure (kPa): 241
• Maximum Cracking Pressure (MPa): 0.241
• Maximum Cracking Pressure (psi): 35

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (MPa): 34.5
• Maximum Working Pressure (psi): 5000

• Number of Balls: Single Ball

• Outlet Size (cm): 0.635
• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35
• Outlet Thread Type: NPSF

GG 562855

MSA-100 PUMP, ASSY

Graco 562855 MSA-100 Pneumatic Pump

MSA Series products are used together with main lubrication supply lines where the pump is fed directly with no additional reservoir required. No reservoir makes the MSA Series ideal for locations that are difficult to reach or undesirable to enter. Use the MSA-100 when high operating pressures and larger outputs are required.

• Ideal for applications where space is a premium
• Handles high pressure lubricant feed of direct line intake
• Used with or without a reservoir for the ultimate flexibility

• Model: MSA
• Series: 100

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPSF

• Application: In-Plant Machinery

• Compatible Material: Oil, Grease
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.25
• Fluid Outlet Size (mm): 6.3500
• Fluid Outlet Thread Type: NPSF

• Material: Aluminum

• Maximum Air Inlet Pressure (bar): 9.65
• Maximum Air Inlet Pressure (kPa): 965
• Maximum Air Inlet Pressure (psi): 140

• Maximum Cycle Rate (CPM): 30

• Maximum Fill Inlet Pressure (bar): 34.5
• Maximum Fill Inlet Pressure (kPa): 3450
• Maximum Fill Inlet Pressure (psi): 500

• Maximum Fluid Output Pressure (bar): 207
• Maximum Fluid Output Pressure (psi): 3000

• Maximum Fluid Output Pressure (bar): 207
• Maximum Fluid Output Pressure (psi): 3000

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 206.8
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

• Minimum Air Inlet Pressure (psi): 60

• Overall Depth (cm): 17.6
• Overall Depth (in): 6.94
• Overall Depth (mm): 176

• Overall Height (cm): 14.5
• Overall Height (in): 5.69
• Overall Height (mm): 145
• Overall Width (cm): 32.6
• Overall Width (in): 12.83
• Overall Width (mm): 326

• Power Type: Pneumatic

GG 563072

VALVE, RESTRICTOR VLV

Graco 563072 Air Inlet Restrictor Valve for MSA-10 and MSA-100

• Air Inlet Restrictor Valve
• Lubriquip part number 463-410-080

GG 563196

VALVE, CHECK, 1/8 NPT, 5000

Graco 563196 Single Ball Check Valve - 35 psi Nominal Cracking Pressure, 1/8 in NPTF (M) x 1/8 in NPSF (F), Steel, 5,000 psi

• Single Ball Check Valve
• 35 psi nominal cracking pressure
• 1/8 inch (3.2 mm) NPTF (M) x 1/8 inch (3.2 mm) NPSF (F)
• 5,000 psi max
• Lubriquip part number 509-350-030
• Trabon part number 9350-35

• Application: Compressor Equipment

• Ball Material: Steel

• Body Material: Steel

• Compatible Material: Oil, Grease

• Inlet Size (cm): 0.3175
• Inlet Size (in): 1/8
• Inlet Size (mm): 3.175

• Inlet Thread Type: NPTF

• Maximum Cracking Pressure (bar): 2.41
• Maximum Cracking Pressure (kPa): 241
• Maximum Cracking Pressure (MPa): 0.241
• Maximum Cracking Pressure (psi): 35

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (MPa): 34.5
• Maximum Working Pressure (psi): 5000

• Number of Balls: Single Ball

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Type: NPSF

GG 562950

MODEL 25 PUMP, ASSY, .312, DIA

Graco 562950 Manzel Model 25 Compressor Lubricator Replacement Pump, 5/16 in (7.9 mm), 1000 psi (69 bar)

Provide lubrication to cylinder walls, bearings and other moving parts of equipment such as sugar mills, steam engines, presses and general machinery.

• General-purpose lubrication: automatic, precision metering for all types of machinery
• Clear-Vue pumping unit shows amount of lubricant being pumped
• Self-contained, removable pumping unit. All units interchangeable - remove two pump screws and lift out
• Lubriquip part number 321-410-015
• Manzel part number 60050-B

• Model: Manzel
• Series: Model 25

• Compatible Material: Oil

• Drive Option: Direct Rotary

• Lubricator Feed Type: Force Feed

• Maximum Drive Speed (RPM): 60

• Maximum Fluid Viscosity (SUS): 5000

• Maximum Number of Drops Per Stroke (drops/stroke): 12

• Maximum Working Pressure (bar): 69
• Maximum Working Pressure (kPa): 6900
• Maximum Working Pressure (psi): 1000

• Minimum Drive Speed (RPM): 3

• Minimum Fluid Viscosity (SUS): 100

• Minimum Number of Drops Per Stroke (drops/stroke): 0.25

• Outlet Size (cm): 0.635
• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35
• Outlet Thread Gender: Female
• Outlet Thread Type: NPS

• Overall Depth (cm): 65
• Overall Depth (in): 25.59
• Overall Depth (mm): 650

• Overall Height (cm): 21.6
• Overall Height (in): 8.50
• Overall Height (mm): 215.9
• Overall Width (cm): 15.24
• Overall Width (in): 6
• Overall Width (mm): 152.4

• Piston Size (cm): 0.79
• Piston Size (in): 0.31
• Piston Size (mm): 7.9

• Pump Size (cm): 0.8
• Pump Size (in): 5/16
• Pump Size (mm): 8

GG 563214

SWIVEL, BALL 1/4 90

Graco 563214 90 degree Angle Swivel - 1/4 inch (6.4 mm)

• 90 degree Angle Swivel - 1/4 inch (6.4 mm)
• Lubriquip part number 509-405-000
• Trabon part number 9405

• Angle ( degree ): 90

• Connection Type: Threaded

GG 563215

SWIVEL, BALL 1/4 180

Graco 563215 180 degree Straight Swivel - 1/4 inch (6.4 mm)

• 180 degree Straight Swivel - 1/4 inch (6.4 mm)
• Lubriquip part number 509-406-000
• Trabon part number 9406

• Angle ( degree ): 180

• Connection Type: Threaded

• For Use With: Pipe

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

GG 563226

INDICATOR, RUPTURE 6400 PSI

Graco 563226 Trabon Replacement Rupture Indicator, 1/8-27 NPSF with O-Ring, 6400 psi (441 bar)

Used on MH divider valve applications where lube system pressures exceed 2,500 psi (172 bar).

• High pressure from blockage causes a disc to rupture
• Lubricant forces an indicator pin to protrude, indicating the blockage
• High pressure backs up through the system and trips a switch to shut the system off
• Lubriquip part number 509-499-165

• Model: Trabon

• Application: In-Plant Machinery, Compressor Equipment

• Compatible Material: Oil

• Connection Size (in): 0.125

• Indicator Type: Rupture Indicator

• Maximum Working Pressure (bar): 441
• Maximum Working Pressure (kPa): 44100
• Maximum Working Pressure (MPa): 44
• Maximum Working Pressure (psi): 6400

• Overall Length (cm): 4
• Overall Length (in): 1.77
• Overall Length (mm): 45
• Overall Width (cm): 1.4224
• Overall Width (in): 0.56
• Overall Width (mm): 14.224

GG 563212

SWIVEL, BALL 1/8 90

Graco 563212 90 degree Angle Swivel - 1/8 inch (3.2 mm)

• 90 degree Angle Swivel - 1/8 inch (3.2 mm)
• Lubriquip part number 509-400-000
• Trabon part number 9400

• Angle ( degree ): 90

• Connection Type: Threaded

GG 563223

INDICATOR, RELIEF 5500 PSI

Graco 563223 Trabon Replacement Rupture Indicator, 1/8-27 NPTF, 5500 psi (379 bar)

Trabon Performance Indicators are pressure-sensitive devices that pinpoint excessive pressure in Trabon series progressive lubricating systems. These devices, which are installed in the alternate outlet ports of divider valves, signal a fault either by causing an indicator pin to protrude or by releasing lubricant to the atmosphere. All Performance Indicators respond quickly to protect the lube system and locate lube line blockage.

• High pressure from blockage causes a disc to rupture.
• Lubricant forces an indicator pin to protrude, indicating the blockage.
• High pressure backs up through the system and trips a switch to shut the system off.
• Divider Valve Rupture Indicators w/Memory - 5,500 psi (379 bar)
• Lubriquip part number 509-499-140
• Trabon part number 9499-14

• Model: Trabon

• Application: In-Plant Machinery, Compressor Equipment

• Compatible Material: Oil

• Connection Size (in): 0.125

• Indicator Type: Rupture Indicator

• Maximum Working Pressure (bar): 379
• Maximum Working Pressure (kPa): 37900
• Maximum Working Pressure (MPa): 38
• Maximum Working Pressure (psi): 5500

• Overall Length (cm): 4
• Overall Length (in): 1.77
• Overall Length (mm): 45
• Overall Width (cm): 1.4224
• Overall Width (in): 0.56
• Overall Width (mm): 14.224

GG 563230

MHH VALVE, BALANCING, 1/8-27

Graco 563230 Balancing Valve, 1/8-27

• Lubriquip part number 509-510-000
• Trabon part number 9510

• Adjustable: Adjustable

• Compatible Material: Oil

• Inlet Size (cm): 0.3175
• Inlet Size (in): 1/8
• Inlet Size (mm): 3.175

• Inlet Thread Type: NPSF

• Material: Steel

• Maximum Working Pressure (bar): 448
• Maximum Working Pressure (kPa): 44800
• Maximum Working Pressure (MPa): 44.8
• Maximum Working Pressure (psi): 6500

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Type: NPSF

• Overall Height (cm): 3.81
• Overall Height (in): 1.5
• Overall Height (mm): 38.1
• Overall Length (cm): 10
• Overall Length (in): 3.834
• Overall Length (mm): 97
• Overall Width (cm): 2.54
• Overall Width (in): 1
• Overall Width (mm): 25.4

GG 563235

INDICATOR, MAN RESET 1500 PS MJ/MSP

Graco 563235 Reset Indicator with Memory, 1500 psi (103 bar), 1/8 NPTF - MJ, MH, MS, MXP Divider Valves

Easy information on blocked lines, high system pressure or blocked bearings.

• Provides quick troubleshooting tool with visual indication
• No tools for reset or parts to replace after indication
• Easy information on blocked lines, high system pressure or blocked bearings

• Model: Trabon

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Oil, Grease

• Connection Size (in): 0.125

• Indicator Type: Reset Indicator with Memory

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10
• Maximum Working Pressure (psi): 1500

GG 563232

INDICATOR, MAN RESET 500 PS MJ/MSP

Graco 563232 Reset Indicator with Memory, 500 psi (35 bar), 1/8 NPTF - MJ, MH, MS, MXP Divider Valves

Easy information on blocked lines, high system pressure or blocked bearings.

• Provides quick troubleshooting tool with visual indication
• No tools for reset or parts to replace after indication
• Easy information on blocked lines, high system pressure or blocked bearings

• Model: Trabon

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Oil, Grease

• Connection Size (in): 0.125

• Indicator Type: Reset Indicator with Memory

• Maximum Working Pressure (bar): 34
• Maximum Working Pressure (kPa): 3400
• Maximum Working Pressure (MPa): 3
• Maximum Working Pressure (psi): 500

GG 563237

INDICATOR, MAN RESET 2500 PS MJ/MSP

Graco 563237 Reset Indicator with Memory, 2500 psi (172 bar), 1/8 NPTF - MJ, MH, MS, MXP Divider Valves

Easy information on blocked lines, high system pressure or blocked bearings.

• Provides quick troubleshooting tool with visual indication
• No tools for reset or parts to replace after indication
• Easy information on blocked lines, high system pressure or blocked bearings

• Model: Trabon

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Oil, Grease

• Connection Size (in): 0.125

• Indicator Type: Reset Indicator with Memory

• Maximum Working Pressure (bar): 172
• Maximum Working Pressure (kPa): 17200
• Maximum Working Pressure (MPa): 17
• Maximum Working Pressure (psi): 2500

GG 563234

INDICATOR, MAN RESET 1000 PS MJ/MSP

Graco 563234 Reset Indicator with Memory, 1000 psi (69 bar), 1/8 NPTF - MJ, MH, MS, MXP Divider Valves

Easy information on blocked lines, high system pressure or blocked bearings.

• Provides quick troubleshooting tool with visual indication
• No tools for reset or parts to replace after indication
• Easy information on blocked lines, high system pressure or blocked bearings

• Model: Trabon

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Oil, Grease

• Connection Size (in): 0.125

• Indicator Type: Reset Indicator with Memory

• Maximum Working Pressure (bar): 69
• Maximum Working Pressure (kPa): 6900
• Maximum Working Pressure (MPa): 7
• Maximum Working Pressure (psi): 1000

GG 563251

INDICATOR, CYCLE

Graco 563251 MSP and MHH Divider Valves - Visual Cycle Indicator

The self-contained Visual Cycle Indicator is designed to allow for easy installation to Trabon MSP and Manzel MHH divider valves. The red indicator ring moves with the valve piston, allowing the user to visually determine the timing of each divider valve cycle.

• Makes physical contact with valve piston
• Polycarbonate housing allows for clear view of red indicator ring
• All parts are captured
• Replaces Lubriquip part number 509-932-522

• Model: Trabon

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

• Compatible Material: Oil, Grease

• Indicator Type: Cycle Indicator

• Maximum Working Pressure (bar): 517.11
• Maximum Working Pressure (kPa): 51711
• Maximum Working Pressure (MPa): 51.7
• Maximum Working Pressure (psi): 7500

GG 563258

INDICATOR, MANUAL RESET, O-RING, 2500 PSI

Graco 563258 Reset Indicator with Memory, 2500 psi (172 bar), 1/8 NPSF with O-Ring for MSP, MXP, and MHH Divider Valves

Easy information on blocked lines, high system pressure or blocked bearings.

• Provides quick troubleshooting tool with visual indication
• No tools for reset or parts to replace after indication
• Easy information on blocked lines, high system pressure or blocked bearings

• Model: Trabon

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

• Compatible Material: Oil, Grease

• Connection Size (in): 0.125

• For Use With: MSP, MXP, and MHH Divider Valves

• Indicator Type: Reset Indicator with Memory

• Maximum Working Pressure (bar): 172
• Maximum Working Pressure (kPa): 17200
• Maximum Working Pressure (MPa): 17
• Maximum Working Pressure (psi): 2500

GG 563326

SWITCH, SW BLOWOUT HI PRESS P3

Graco 563326 High Pressure Blowout Switch for 5.68 liter (12 pt.) and 9.46 liter (20 pt.) or 5.44 kg (12 lb.) and 9.06 kg (20 lb.) Reservoirs

• High Pressure Blowout Switch for 5.68 litre (12 pt.) and 9.46 litre (20 pt.) or 5.44 kg (12 lb.) and 9.06 kg (20 lb.) Reservoirs
• Lubriquip part number 521-001-200

• Model: Modu-Flo

• Compatible Material: Oil, Grease

• For Use With: Modu-Flo 12 and 20 pt (5.7 and 9.5 L) or 12 and 20 lb (5.4 and 9.1 kg) cylindrical reservoirs

• Maximum Working Pressure (bar): 100
• Maximum Working Pressure (kPa): 10000
• Maximum Working Pressure (MPa): 10
• Maximum Working Pressure (psi): 1450

GG 563257

INDICATOR, MANUAL RESET, O-RING, 2000 PSI

Graco 563257 Reset Indicator with Memory, 2000 psi (138 bar), 1/8 NPSF with O-Ring for MSP, MXP, and MHH Divider Valves

Easy information on blocked lines, high system pressure or blocked bearings.

• Provides quick troubleshooting tool with visual indication
• No tools for reset or parts to replace after indication
• Easy information on blocked lines, high system pressure or blocked bearings

• Model: Trabon

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

• Compatible Material: Oil, Grease

• Connection Size (in): 0.125

• For Use With: MSP, MXP, and MHH Divider Valves

• Indicator Type: Reset Indicator with Memory

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (MPa): 14
• Maximum Working Pressure (psi): 2000

GG 563319

RESERVOIR, TANK 12PT T1

Graco 563319 12 pt. (5.67 liter) Rectangular Oil Reservoir - Metal

• 12 pt (5.67 liter) Rectangular - Metal
• Lubriquip part number 521-001-060

• Model: Trabon

• Application: Compressor Equipment

• Compatible Material: Oil

• Material: Metal

GG 563316

KIT, ACCESSORY, L/L, 5/12 PT

Graco 563316 Modu-Flo Low Level Switch Assemblies - 15 Amp Low Level Switch for 5 and 12 pt. Cylindrical Oil Reservoirs, SPDT

• 15 amp Low Level Switch for 5 and 12 pt Cylindrical Oil Reservoirs, SPDT
• Lubriquip part number 521-001-030

GG 563261

INDICATOR, RESET 3000 PSI 1/8 NPSF

Graco 563261 Reset Indicator with Memory, 3000 psi (207 bar), 1/8 NPSF with O-Ring - MH, MS, MXP Divider Valves

Easy information on blocked lines, high system pressure or blocked bearings.

• Provides quick troubleshooting tool with visual indication
• No tools for reset or parts to replace after indication
• Easy information on blocked lines, high system pressure or blocked bearings

• Model: Trabon

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

• Compatible Material: Oil, Grease

• Connection Size (in): 0.125

• Indicator Type: Reset Indicator with Memory

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 21
• Maximum Working Pressure (psi): 3000

GG 563327

SWITCH, BLOWOUT HI PRESS P4

Graco 563327 High Pressure Blowout Switch for all Rectangular Reservoirs

• High Pressure Blowout Switch for all Rectangular Reservoirs
• Lubriquip part number 521-001-210

• Model: Modu-Flo

• Compatible Material: Oil, Grease

• For Use With: Modu-Flo Tanks and Reservoirs

• Maximum Working Pressure (bar): 100
• Maximum Working Pressure (kPa): 10000
• Maximum Working Pressure (MPa): 10
• Maximum Working Pressure (psi): 1450

GG 563255

INDICATOR, MANUAL RESET, O-RING, 1000 PSI

Graco 563255 Reset Indicator with Memory, 1000 psi (69 bar), 1/8 NPSF with O-Ring for MSP, MXP, and MHH Divider Valves

Easy information on blocked lines, high system pressure or blocked bearings.

• Provides quick troubleshooting tool with visual indication
• No tools for reset or parts to replace after indication
• Easy information on blocked lines, high system pressure or blocked bearings

• Model: Trabon

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

• Compatible Material: Oil, Grease

• Connection Size (in): 0.125

• For Use With: MSP, MXP, and MHH Divider Valves

• Indicator Type: Reset Indicator with Memory

• Maximum Working Pressure (bar): 69
• Maximum Working Pressure (kPa): 6900
• Maximum Working Pressure (MPa): 7
• Maximum Working Pressure (psi): 1000

GG 563275

SPRA VALVE, SPRAY 4 IN DIA

Graco 563275 Air-lube Control Valve and Nozzle Assembly - 4 in. spray diameter, normal

• Conserves air - air required only during spray interval
• Versatile - can be used with any centralized lube system or mechanical oiler and will handle grease or oil
• External mix nozzle purges itself and prevents clogging
• 4 in. spray diameter, normal
• Lubriquip part number 510-652-000
• Trabon part number 10652

• Compatible Material: Oil, Grease

• Maximum Air Pressure (bar): 11

• Maximum Air Pressure (kPa): 1100
• Maximum Air Pressure (psi): 150

• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 102

• Maximum NLGI Grade: #2

• Overall Width (cm): 2.54
• Overall Width (in): 1
• Overall Width (mm): 25.4

GG 563304

MODU-FLO PUMP, ASSEMBLY, AL-5M

Graco 563304 Modu-Flo AL-5M Pneumatic Pump without Reservoir

Mix and match pumps, reservoir and manifolds in any configuration to meet any application. Replace the pump or reservoir without disconnecting lubrication lines.

• Easy to standardize on components and reduce inventory
• Adjustable pump output for fast, convenient customizing
• Lubriquip part number 521-000-001

• Model: Modu-Flo
• Series: AL-5M

• Application: In-Plant Machinery

• Compatible Material: Oil, Grease
• Compatible Metering Device: Series Progressive

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Cycle Rate (CPM): 30

• Maximum Fluid Output Pressure (bar): 241
• Maximum Fluid Output Pressure (psi): 3500

• Maximum Fluid Output Pressure (bar): 241
• Maximum Fluid Output Pressure (psi): 3500

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (MPa): 31
• Maximum Working Pressure (psi): 3000

• Overall Depth (cm): 5.4
• Overall Depth (in): 2.125
• Overall Depth (mm): 54

• Overall Height (cm): 6.7
• Overall Height (in): 2.26
• Overall Height (mm): 58
• Overall Width (cm): 21
• Overall Width (in): 8.281
• Overall Width (mm): 210

• Power Type: Pneumatic

GG 563287

BLOCK, END MACH MX

Graco 563287 Trabon MX Divider Valve - MX End

• MX end
• Lubriquip part number 510-921-004

• Model: Trabon
• Series: MX

• Application: In-Plant Machinery

GG 563308

MODU-FLO PUMP, ASSY, AL-50

Graco 563308 Modu-Flo AL-50 Pneumatic Pump without Reservoir

Mix and match pumps, reservoir and manifolds in any configuration to meet any application. Replace the pump or reservoir without disconnecting lubrication lines.

• Easy to standardize on components and reduce inventory
• Adjustable pump output for fast, convenient customizing
• Lubriquip part number 521-000-041

• Model: Modu-Flo
• Series: AL-50

• Application: In-Plant Machinery

• Compatible Material: Oil, Grease
• Compatible Metering Device: Series Progressive

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Cycle Rate (CPM): 30

• Maximum Fluid Output Pressure (bar): 241
• Maximum Fluid Output Pressure (psi): 3500

• Maximum Fluid Output Pressure (bar): 241
• Maximum Fluid Output Pressure (psi): 3500

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (MPa): 31
• Maximum Working Pressure (psi): 3000

• Overall Depth (cm): 8.1
• Overall Depth (in): 3.188
• Overall Depth (mm): 81

• Overall Height (cm): 8.1
• Overall Height (in): 3.188
• Overall Height (mm): 81
• Overall Width (cm): 32.5
• Overall Width (in): 12.812
• Overall Width (mm): 325

• Power Type: Pneumatic

GG 563315

VALVE, SOL ASSY 3-WAY

Graco 563315 Trabon Accessories - 3-way pneumatic solenoid valve, 115 VAC

• 3-Way Pneumatic Solenoid Valve, 115 VAC
• Lubriquip part number 521-001-020

• Compatible Material: Oil, Grease

• Maximum NLGI Grade: #2

GG 563272

SWITCH, CYCLE, SPDT

Graco 563272 Cycle Switch (SPDT) and Bracket Assembly - MJ, MSP and MXP Divider Valves

Monitors piston movement to ensure completed lubrication cycle - must have cycle indicator pin

• Provides positive feedback based on actual metering piston movement
• Mounts to MJ, MSP, MXP, or MX divider with cycle pin option with simple install
• Able to be set for normally open or normally closed operation
• Trabon part number 10599

GG 563306

MODU-FLO PUMP, ASSY AL-25

Graco 563306 Modu-Flo AL-25 Pneumatic Pump without Reservoir

Mix and match pumps, reservoir and manifolds in any configuration to meet any application. Replace the pump or reservoir without disconnecting lubrication lines.

• Easy to standardize on components and reduce inventory
• Adjustable pump output for fast, convenient customizing
• Lubriquip part number 521-000-021

• Model: Modu-Flo
• Series: AL-25

• Application: In-Plant Machinery

• Compatible Material: Oil, Grease
• Compatible Metering Device: Series Progressive

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Cycle Rate (CPM): 30

• Maximum Fluid Output Pressure (bar): 241
• Maximum Fluid Output Pressure (psi): 3500

• Maximum Fluid Output Pressure (bar): 241
• Maximum Fluid Output Pressure (psi): 3500

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (MPa): 31
• Maximum Working Pressure (psi): 3000

• Overall Depth (cm): 7.3
• Overall Depth (in): 2.875
• Overall Depth (mm): 73

• Overall Height (cm): 7.3
• Overall Height (in): 2.875
• Overall Height (mm): 73
• Overall Width (cm): 26.4
• Overall Width (in): 10.375
• Overall Width (mm): 264

• Power Type: Pneumatic

GG 563324

MANIFOLD, ASSY RESV TO PUMP

Graco 563324 Pump-to-Reservoir Manifold for Modu-Flo Pumps, NPT, Dry Gauge, Fill Check, Outlet Check, Blowout

• Pump/Reservoir Manifold (NPT) w/Outlet Check Valve, System Fill Check Valve, Blowout Assembly, 0-3,000 psi Pressure Gauge
• Lubriquip part number 521-001-180

• Model: Trabon

• Includes: Outlet Check Valve, System Fill Check Valve, Blowout Assembly, Pressure Gauge

GG 563322

SWITCH, LL GRS RESV

Graco 563322 Low Level Switch, 15 Amp, for all Grease Reservoirs

• Low Level Switch for 5, 6, 12 and 20 pt Cylindrical Grease Reservoirs
• Lubriquip part number 521-001-110

• Inlet Size (cm): 1.2700
• Inlet Size (in): 0.5
• Inlet Size (mm): 12.7000

• Inlet Thread Type: NPT

GG 563307

GG 563332

VALVE, SOL ASSY 24VDC

Graco 563332 Trabon Accessories - 3-way pneumatic solenoid valve, 24 VDC

• 3-Way, 24 VDC Solenoid Valve
• Lubriquip part number 521-002-100

• Compatible Material: Oil, Grease

• Maximum NLGI Grade: #2

GG 563318

KIT, ACCESSORY, L/L, 12/24/40 PT

Graco 563318 Modu-Flo Low Level Switch Assemblies - 15 Amp Low Level Switch for 6 pt. Cylindrical Oil Reservoirs and all Tank Reservoirs, SPDT

• 15 amp Low Level Switch for 6 pt Cylindrical Oil Reservoirs and all Tank Reservoirs, SPDT
• Lubriquip part number 521-001-050

• Inlet Size (cm): 1.2700
• Inlet Size (in): 0.5
• Inlet Size (mm): 12.7000

• Inlet Thread Type: NPSM

GG 563358

E-SERIES PUMP, 1/4NPSF

Graco 563358 E-Series Pump Only - with 1750 psi (121 bar) Rupture Disc

The E-Series pump is a great, minimum cost, entry level alternative to standard pneumatic pump products. This all-in-one pump package comes complete with no assembly required and is easy to install. All pump packages include high-pressure rupture disc assembly and lube outlet check valve. Great for any application where price is a concern and installation time is at a premium.

• Easy field installation of accessories without disturbing existing plumbing
• Smart pump design with few moving parts ensures long-lasting dependability
• Lubriquip part number 521-300-180

• Model: E-Series

• Application: In-Plant Machinery

• Compatible Material: Oil, Grease
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.5
• Fluid Outlet Size (mm): 12.7000
• Fluid Outlet Thread Type: NPSF

• Includes: E-Series Pump, Rupture Disc

• Material: Aluminum, Plastic

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum cST Grade (cST): 30000
• Maximum Cycle Rate (CPM): 10

• Maximum Fluid Output Pressure (bar): 138
• Maximum Fluid Output Pressure (psi): 2000

• Maximum Fluid Output Pressure (bar): 138
• Maximum Fluid Output Pressure (psi): 2000

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 137.9
• Maximum Working Pressure (kPa): 13790
• Maximum Working Pressure (MPa): 13.8
• Maximum Working Pressure (psi): 2000

• Power Type: Pneumatic

GG 563273

SWITCH, SUBMERSIBLE, SPDT

Graco 563273 Cycle Switch (SPDT) and Bracket Assembly, Moisture-Resistant - MJ, MS, MHH and MXP Divider Valves

Monitors piston movement to ensure completed lubrication cycle - must have cycle indicator pin

• Provides positive feedback based on actual metering piston movement
• Mounts to MJ, MSP, MXP, or MX divider with cycle pin option with simple install
• Able to be set for normally open or normally closed operation

GG 563360

E-SERIES PUMP, RESV ASSY GRS LL

Graco 563360 E-Series Pump and Reservoir Assembly - 5 lb (2.26 kg) Plastic Grease, 1/4 in. NPSF, Low Level Switch

The E-Series pump is a great, minimum cost, entry level alternative to standard pneumatic pump products. This all-in-one pump package comes complete with no assembly required and is easy to install. All pump packages include high-pressure rupture disc assembly and lube outlet check valve. Great for any application where price is a concern and installation time is at a premium.

• Easy field installation of accessories without disturbing existing plumbing
• Smart pump design with few moving parts ensures long-lasting dependability
• Lubriquip part number 521-300-360

• Model: E-Series

• Air Inlet Size (in): 0.2502
• Air Inlet Size (mm): 6.35

• Application: In-Plant Machinery

• Compatible Material: Grease

• Maximum Working Pressure (bar): 24
• Maximum Working Pressure (kPa): 2400
• Maximum Working Pressure (MPa): 2.4
• Maximum Working Pressure (psi): 350

• Power Type: Pneumatic

GG 563376

MAXI-FLO PUMP, 115 VAC REMOTE

Graco 563376 Maxi-Flo Electric Pump, 115 VAC, 4 pt. (1.89 liter) Plastic Rectangular Oil Reservoir, Remote Control

Compact design with everything you need to get your single line resistive oil lubrication system installed and running quickly. A standard package comes complete with reservoir, pump, gear motor, and choice of internal or remote control. Simple slide switches allow for easy setup of pump run cycle time. Bright LED indicators for low level and power allow for easy troubleshooting and verification.

• Integrated control with manual run button for easy setup
• Compact design fits anywhere
• 500 psi (34 bar) rating for using with various orifice metering devices

• Model: Maxi-Flo

• Application: In-Plant Machinery

• Compatible Material: Oil
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.125
• Fluid Outlet Size (mm): 3.1750
• Fluid Outlet Thread Type: NPSF

• Includes: 4 pt Plastic Rectangular Oil Reservoir, Remote Control

• Material: Plastic

• Maximum Flow Rate (ci/min): 0.12

• Maximum Fluid Output Pressure (bar): 34
• Maximum Fluid Output Pressure (psi): 500

• Maximum Fluid Output Pressure (bar): 34
• Maximum Fluid Output Pressure (psi): 500

• Maximum SUS Grade (SUS): 30000

• Maximum Working Pressure (bar): 34.5
• Maximum Working Pressure (kPa): 3450
• Maximum Working Pressure (MPa): 3.5
• Maximum Working Pressure (psi): 500

• Minimum SUS Grade (SUS): 60

• Overall Depth (cm): 16.4
• Overall Depth (in): 6.44
• Overall Depth (mm): 164

• Overall Height (cm): 24.1
• Overall Height (in): 9.5
• Overall Height (mm): 241

• Power Type: Electric

GG 563364

E-SERIES PUMP, RESV ASSY GRS LL

Graco 563364 E-Series Pump with 6 lb. (2.72 kg) Plastic Cylindrical Grease Reservoir, Low Level Switch with 2350 psi (162 bar) Rupture Disc

The E-Series pump is a great, minimum cost, entry level alternative to standard pneumatic pump products. This all-in-one pump package comes complete with no assembly required and is easy to install. All pump packages include high-pressure rupture disc assembly and lube outlet check valve. Great for any application where price is a concern and installation time is at a premium.

• Easy field installation of accessories without disturbing existing plumbing
• Smart pump design with few moving parts ensures long-lasting dependability
• Lubriquip part number 521-300-670

• Model: E-Series

• Application: In-Plant Machinery

• Compatible Material: Grease
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.5
• Fluid Outlet Size (mm): 12.7000
• Fluid Outlet Thread Type: NPSF

• Includes: E-Series Pump, Plastic Cylindrical Grease Reservoir, Low Level Switch, Rupture Disc

• Material: Aluminum, Plastic

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum cST Grade (cST): 30000
• Maximum Cycle Rate (CPM): 10

• Maximum Fluid Output Pressure (bar): 138
• Maximum Fluid Output Pressure (psi): 2000

• Maximum Fluid Output Pressure (bar): 138
• Maximum Fluid Output Pressure (psi): 2000

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 137.9
• Maximum Working Pressure (kPa): 13790
• Maximum Working Pressure (MPa): 13.8
• Maximum Working Pressure (psi): 2000

• Minimum Air Inlet Pressure (psi): 40

• Overall Depth (cm): 22.4
• Overall Depth (in): 8.81
• Overall Depth (mm): 224

• Overall Height (cm): 26.7
• Overall Height (in): 10.5
• Overall Height (mm): 267
• Overall Width (cm): 18.4
• Overall Width (in): 7.25
• Overall Width (mm): 184

• Power Type: Pneumatic

GG 563380

BODY, PUMP ASSY

Graco 563380 Lube Master Pump Body

• Bare Pump
• Lubriquip part number 521-700-000

• Model: Lube Master

• Application: In-Plant Machinery

• Compatible Material: Oil, Grease

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 340
• Maximum Working Pressure (kPa): 34000
• Maximum Working Pressure (MPa): 34
• Maximum Working Pressure (psi): 5000

GG 563383

CLUTCH, DRIVE

Graco 563383 Clutch drive with Ratchet Arm for Lube Master Pumps

• Clutch drive with ratchet arm
• Lubriquip part number 521-700-300

• For Use With: LubeMaster Electric Pumps

• Number of Pieces: 19

GG 563425

BLOCK, BASE, MSP/MHH, NPSF

Graco 563425 Trabon MSP Divider Valve - Intermediate Base Plate - NPSF

• Intermediate base plate
• NPSF
• Lubriquip part number 527-000-871

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

• Inlet Size (cm): 0.3175
• Inlet Size (in): 1/8
• Inlet Size (mm): 3.175

• Inlet Thread Type: NPSF

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Type: NPSF

GG 563424

BLOCK, END, MSP/MHH

Graco 563424 Trabon MSP/Manzel MHH Divider Valve Standard End Section

• Standard end section (Must be ordered in multiples of five)
• Must be ordered in multiples of 5
• Lubriquip part number 527-000-851

• Model: Manzel
• Series: MHH

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

• Outlet Thread Type: NPSF

GG 563469

KIT, CROSSPORT, MSP, RH, CS

Graco 563469 Trabon MSP Divider Valve - Right Cross Port Bar

• Right Cross Port Bar - 1 outlet port plug is required for each cross port bar
• Lubriquip part number 527-005-320

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

• Material: Carbon Steel

GG 563470

KIT, CROSSPORT, MSP, LH, CS

Graco 563470 Trabon MSP Divider Valve - Left Cross Port Bar

• Left Cross Port Bar - 1 outlet port plug is required for each cross port bar
• Lubriquip part number 527-005-330

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

• Material: Carbon Steel

GG 563471

KIT, CROSSPORT, MSP, LH/RH, CS

Graco 563471 Trabon MSP Divider Valve - Right and Left Cross Port Bar

• Left and Right Cross Port Bar - 2 outlet port plugs are required for each double cross port bar
• Lubriquip part number 527-005-340

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

• Material: Carbon Steel

GG 563486

SWITCH, PROX MXP 3-PIN W/ IND

Graco 563486 Field Sensitive Mechanical Proximity Cycle, 20-32 VDC, 3-Pin - MXP, MX and MXO Divider Valves

Magnetically-operated sensing devices for sending system data to the controller or PLC.

• Available in 115 VAC or 12-32 VDC
• Available for all series progressive families to provide cycle rates up to 200 CPM
• Pressure ratings up to 10,000 psi (690 bar)
• Select models available with UL and CSA approvals
• Lubriquip part number 527-006-130

• Compatible Material: Oil, Grease

• Material: 303 Stainless Steel, Viton

• Maximum Working Pressure (bar): 517
• Maximum Working Pressure (kPa): 51700
• Maximum Working Pressure (MPa): 52
• Maximum Working Pressure (psi): 7500

• Power Connection Type: 3-Pin BH Mini

GG 563507

FILTER, 138 MICRON INLINE 1/4 NPT

Graco 563507 In-Line Oil and Grease Strainers - High Pressure, 7500 psi, 1/4-18 NPTF, 149 Micron

• 149 micron, 100 Mesh In-Line Block Strainer (NPT)
• Lubriquip part number 527-100-380

• Maximum Working Pressure (bar): 517
• Maximum Working Pressure (kPa): 51700
• Maximum Working Pressure (MPa): 5170
• Maximum Working Pressure (psi): 7500

• Port Size (cm): 0.635
• Port Size (in): 1/4
• Port Size (mm): 6.35

GG 563509

FILTER, 10 MICRON PLUG END

Graco 563509 End Plug Filter Assembly with 10 micron Filter Element, Lubriquip part number 527-100-540

• 10 micron Replacement Filter Element for Graco part numbers 563511, 563513, 563516
• Replacement filter element for Lubriquip part numbers 527-100-230, 527-100-580, 527-100-581, 527-100-780, 527-101-120, 527-101-223

• For Use With: In-Line Oil Filters

GG 563511

FILTER, 10 MICRON INLINE 1/4 NPT

Graco 563511 In-Line Oil Filters - High Pressure, 7500 psi, 1/4-18 NPTF, 10 Micron

• Lubriquip part number 527-100-581
• Direct replacement for Lubriquip part number 527-100-230, 527-100-480, 527-100-580
• Replacement element is Graco part number 563509

• Application: Compressor Equipment

• Maximum Working Pressure (bar): 517
• Maximum Working Pressure (kPa): 51700
• Maximum Working Pressure (MPa): 5170
• Maximum Working Pressure (psi): 7500

• Port Size (cm): 0.635
• Port Size (in): 1/4
• Port Size (mm): 6.35

GG 563510

FILTER, 25 MICRON PLUG END

Graco 563510 End Plug Filter Assembly with 25 micron Filter Element, Lubriquip part number 527-100-550

• 25 micron Replacement Filter Element for Graco part numbers 563512, 563514, 563515
• Replacement filter element for Lubriquip part numbers 527-100-240, 527-100-590 527-100-591, 527-100-790, 527-100-830, 527-101-224

• For Use With: In-Line Oil Filters

GG 563512

FILTER, 25 MICRON INLINE 1/4 NPT

Graco 563512 In-Line Oil Filters - High Pressure, 7500 psi, 1/4-18 NPTF, 25 Micron

• 25 micron In-Line Oil Filter, NPT
• Lubriquip part number 527-100-591
• Direct replacement for Lubriquip part number 527-100-240 and 527-100-590

• Application: Compressor Equipment

• Maximum Working Pressure (bar): 517
• Maximum Working Pressure (kPa): 51700
• Maximum Working Pressure (MPa): 5170
• Maximum Working Pressure (psi): 7500

• Port Size (cm): 0.635
• Port Size (in): 1/4
• Port Size (mm): 6.35

GG 563518

BLOCK, SECT END ASSY MXP

Graco 563518 Trabon MXP Divider Valve - End Section

• End section
• Lubriquip part number 527-300-090

• Model: Trabon
• Series: MXP

• Application: In-Plant Machinery

GG 563579

LUBRISYSTEM PUMP, AIR (NO RES)

Graco 563579 LubriSystem Standard Air Operated Pump without Reservoir

Easy to design, modify and adjust for oil or grease applications large or small. Great for operation of piston distributors. Rugged construction maximizes your productivity - upgrading to the internal timer control completely automates the system. All packages include internal pressure relief, so no need to install extra parts with additional costs. Combine with LubriSystem injectors for easy, low cost system design solutions.

• Ability to serve large systems - up to 100 lube points or more
• Efficient design promotes increased productivity and less downtime
• No reservoir included

• Model: LubriSystem

• Application: In-Plant Machinery

• Compatible Material: Oil, Grease
• Compatible Metering Device: Single Line Parallel

• Includes: Standard Pump

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Fluid Output Pressure (bar): 93
• Maximum Fluid Output Pressure (psi): 1350

• Maximum Fluid Output Pressure (bar): 93
• Maximum Fluid Output Pressure (psi): 1350

• Maximum NLGI Grade: #1

• Maximum Working Pressure (bar): 40
• Maximum Working Pressure (kPa): 4000
• Maximum Working Pressure (MPa): 4
• Maximum Working Pressure (psi): 580

• Minimum Air Inlet Pressure (psi): 40

• Power Type: Pneumatic

GG 563519

BLOCK, BSPLT INTERM MXP 1/4 NPSF

Graco 563519 Trabon MXP Divider Valve - Intermediate Base Plate - NPSF

• Intermediate Base
• Must be ordered in multiples of 2
• 1/4-18 NPSF

• Model: Trabon
• Series: MXP

• Application: In-Plant Machinery

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPSF

• Outlet Size (cm): 0.635
• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35
• Outlet Thread Type: NPSF

GG 563580

LUBRISYSTEM PUMP, HAND

Graco 563580 LubriSystem Hand-Operated Pump - Pump Body without Reservoir

Sturdy construction of aluminum and steel to provide years of service. Compact design can be used in areas where space is limited. Rugged bracket allows the pump package to be mounted in place in any application.

• General machinery lubrication where power is limited or not available
• Bracket-mount design for easy installation
• Rugged design for years of operation
• Lubriquip part number 550-000-520

• Model: LubriSystem

• Application: In-Plant Machinery, Compressor Equipment

• Compatible Material: Oil, Grease

• Includes: Hand Pump Body

• Maximum NLGI Grade: #1

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (psi): 3000

GG 563796

GG 563799

TUBE, 2 BUNDLE 15FT PRECHARGE

Graco 563799 15 ft. Pre-Charged Tube - 2 Tube Bundle, 3/16 in. OD - Orange, Black

• Lubriquip part number 550-450-989

• Application: On-Road Vehicles

• Color: Black, Orange

• Compatible Material: Grease

• Material: Nylon

• Maximum Working Pressure (bar): 56
• Maximum Working Pressure (kPa): 560
• Maximum Working Pressure (psi): 800

• Overall Length (ft): 15
• Overall Length (m): 5

GG 563902

KIT, REPAIR PUMP AL-5M

Graco 563902 Modu-Flo Pump Assembly Repair Kits - AL-5, Single or Double Acting Repair Kit

• AL-5M seal kit
• Lubriquip part number 560-001-021

• For Use With: AL-5M Pumps

• Includes: Piston Spring, Check Valve Spring, Check Valve Seat, Hardware

• Kit Type: Repair Kit

GG 563800

TUBE, 3 BUNDLE 10FT PRECHARGE

Graco 563800 10 ft. Pre-Charged Tube - 3 Tube Bundle, 3/16 in. OD - Blue, Orange, Black

• Lubriquip part number 550-450-990

• Application: On-Road Vehicles

• Color: Black, Orange, Blue

• Compatible Material: Grease

• Material: Nylon

• Maximum Working Pressure (bar): 56
• Maximum Working Pressure (kPa): 560
• Maximum Working Pressure (psi): 800

• Overall Length (ft): 10
• Overall Length (m): 3

GG 563903

KIT, REPAIR PUMP AL-25M

Graco 563903 Modu-Flo Pump Assembly Repair Kits - AL-25, Single or Double Acting Repair Kit

• AL-25M seal kit
• Lubriquip part number 560-001-031

• For Use With: AL-25M Pumps

• Includes: Piston Spring Retainer, Check Valve Spring, Check Valve Seat, Hardware

• Kit Type: Repair Kit

GG 563906

KIT, REPAIR PUMP HL-25M

Graco 563906 HL-25M Seal Kit

• HL-25M seal kit
• Lubriquip part number 560-001-061

• For Use With: HL-25M Pumps

• Includes: Check Valve Spring, Check Valve Seat, Hardware

• Kit Type: Repair Kit

GG 563918

GG 563909

KIT, REPAIR PUMP E-SERIES

Graco 563909 E-Series Pump Repair Kit (Fixed Output)

• Pump Repair Kit (fixed output)
• Lubriquip part number 560-001-210

• For Use With: E-Series Pumps

• Includes: Check Valve Spring, Check Valve Seat, O-Rings, Hardware

• Kit Type: Repair Kit

GG 563923

GG 563928

KIT, REPAIRI ND CYCLE MSP

Graco 563928 Trabon MSP Mounting Accessories and Spare Parts - MSP Cycle Pin Indicator Repair Kit, Gasket

• MSP cycle pin indicator repair kit, gasket
• Lubriquip part number 560-002-050

• Includes: MX Cycle Indicator, MX Cycle Indicator Stem, Hardware

GG 563929

KIT, REPAIR IND CYC

Graco 563929 Trabon MSP Mounting Accessories and Spare Parts - MSP Cycle Pin Indicator Repair Kit, O-Ring

• MSP cycle pin indicator repair kit, O-ring
• Lubriquip part number 560-002-055

• Includes: MX Cycle Indicator Stem, Hardware

GG 563962

KIT, B/O DISC 1450 PS1 YELLOW

Graco 563962 Blowout Disc Kit - (6) Yellow, 1450 psi, 11/16 in.

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• 1,450 psi - yellow
• Lubriquip part number 560-900-270

• Color: Yellow

• Maximum Working Pressure (bar): 100
• Maximum Working Pressure (kPa): 9991
• Maximum Working Pressure (MPa): 10
• Maximum Working Pressure (psi): 1450

• Number of Pieces: 6

• Overall Diameter (cm): 1.7
• Overall Diameter (in): 0.688

• Overall Diameter (mm): 17

GG 563963

KIT, B/O DISC 1750 RED

Graco 563963 Blowout Disc Kit - (6) Red, 1750 psi, 11/16 in.

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• 1,750 psi - red
• Lubriquip part number 560-900-280

• Color: Red

• Maximum Working Pressure (bar): 121
• Maximum Working Pressure (kPa): 12058
• Maximum Working Pressure (MPa): 12.1
• Maximum Working Pressure (psi): 1750

• Number of Pieces: 6

• Overall Diameter (cm): 1.7
• Overall Diameter (in): 0.688

• Overall Diameter (mm): 17

GG 563966

KIT, B/O DISC 2950 BLUE

Graco 563966 Blowout Disc Kit - (6) Blue, 2950 psi, 11/16 in.

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• 2,940 psi - blue
• Lubriquip part number 560-900-320

• Color: Blue

• Maximum Working Pressure (bar): 203
• Maximum Working Pressure (kPa): 20326
• Maximum Working Pressure (MPa): 20.3
• Maximum Working Pressure (psi): 2950

• Number of Pieces: 6

• Overall Diameter (cm): 1.7
• Overall Diameter (in): 0.688

• Overall Diameter (mm): 17

GG 564086

GG 564350

SWIVEL, BEARING, 90DEG, 1/2 NPT

Graco 564350 Ball Bearing 90 degree Angle Swivel - 1/2 inch (12.7 mm)

• 90 degree Angle Swivel - 1/2 inch (12.7 mm)
• Lubriquip part number 503-706-001

• Angle ( degree ): 90

• Connection Type: Threaded

• For Use With: Pipe

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

GG 567251

GG 564406

FILTER, 138 MIC INLINE 1/4-19 BSPP

Graco 564406 General Accessories - In-Line Oil/Grease Filters (High-Pressure) - 149 Micron, 100 Mesh In-Line Block Strainer, BSPP

• 149 micron, 100 Mesh In-Line Block Strainer, BSPP (ISO 1179)
• Lubriquip part number 527-101-130

• Maximum Working Pressure (bar): 517
• Maximum Working Pressure (kPa): 51700
• Maximum Working Pressure (MPa): 5170
• Maximum Working Pressure (psi): 7500

• Port Size (cm): 0.635
• Port Size (in): 1/4
• Port Size (mm): 6.35

GG 564413

MINI METER-FLO PUMP, MOTOR ASSY 5CU/IN

Graco 564413 Miniature Meter-Flo Assembly - Pump, Gear motor, Reducer Assembly, 5 cu in/min (82 cc/min)

Designed for use with virtually any type of Series Progressive or Single Line Resistive oil lubrication system. The Miniature Meter-Flo has a rugged steel reservoir and motor assembly withstands the toughest applications.

• Capable of high volumetric output operating continuously at pressures up to 1,000 psi (69 bar)
• Compact with several options to create a complete system using feedback and control
• Nominal displacements of 5 cu. in./min. (82 cc/mm.)
• Pump, Gear motor and Reducer assembly - no reservoir
• Reservoir has a suction line strainer, return line port, visual level gauge, pressure gauge and filler/strainer with spring return cap
• Options include low level switch, high pressure indicator, and lube cycle timer
• Lubriquip part number 540-800-620

• Model: Miniature Meter-Flo

• Compatible Material: Oil
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.25
• Fluid Outlet Size (mm): 6.3500
• Fluid Outlet Thread Type: NPT

• For Use With: Series Progressive Oil Lubrication Systems, Single Line Resistive Oil Lubrication Systems

• Includes: Pump, Gear Motor, Reducer Assembly

• Material: Metal

• Maximum cST Grade (cST): 15000

• Maximum Flow Rate (ci/min): 5

• Maximum Working Pressure (bar): 69
• Maximum Working Pressure (kPa): 6900
• Maximum Working Pressure (MPa): 6.9
• Maximum Working Pressure (psi): 1000

• Minimum cST Grade (cST): 160

• Minimum Voltage (V ac): 103.5

• Power Connection Type: 3 Wire Hook-Up Inside Junction Box

• Power Type: Electric

GG 570267
