GRACO INC. S10595

GG 625904

GG 626057

GG 626064

GG 805534

GG 805566

GG 805575

GG 94/0350-2/50

GG 94/0351-2/50

GG 94/0360-2/98

GG 94/0463/96

GG 947081

GG 95/0111/00

GG 95/0125/00

GG 95/0228/00

GG 95/0518/00

GG 95/0515/00

GG 95/0805/00

GG 95/0851/87

GG 95/0854/89

GG 97/2215/98

GG 970077

GG AAF308

GG AEF412

GG AEF614

GG AEF616

GG C00004

GG C00006

GG C00007

GG C00009

GG C02032

GG C06061

GG C07560

GG C07124

GG C07131

GG C07133

GG C20003

GG C12509

GG C20987

GG C23350

GG C23136

GG C38132

GG C38161

GG C38312

GG C55568

GG EC5J41

E-FLO PUMP,DC,X2,3000CC,SEALED

Graco EC5J41 E-Flo DC 4-Ball Electric Circulation Pump, 3000cc, 2 x 2 HP, 480V, Advanced, ATEX/FM/IECEx, Sealed Lower, Ultralife Rod/Cylinder, Tri-Clamp, Stand

E-Flo DC (Dual Control) electric pumps are up to five times more efficient than pneumatic pumps, lowering energy bills and saving money. Unique 4-ball lower minimizes pulsation while increasing flow rates. Advanced control module improves performance with Intelligent Paint Kitchen (IPK) compatibility.

• Advanced model lets you easily connect and manage multiple pumps with a single control module.
• Integrated runaway protection prevents pump from premature wear and costly material loss.
• Sealed lower does not require throat seal liquid (TSL), reducing maintenance costs and unplanned downtime. Lower operates independently, allowing the pump to adjust to varying pressure and flow rate demands thousands of times per second.
• Ultralife ceramic coatings on rod and cylinder hold up to the harshest materials, including waterborne.
• Installation simply requires 220 volt single phase power. No VFD (variable frequency drive) needed.

GG EC8J41

GG EM1012

GG ES2614

GG G10W09

MERKUR SYSTEM PUMP 10:01 75CC WA STD

Graco G10W09 10:1 Merkur Pump, 1.2 gpm (4.5 lpm) fluid flow, Wall Mount

Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.

• Proven to outperform and outlast other pumps in their class
• Highest technology air motor on the market
• Low air consumption for increased efficiency

• Model: Merkur

• Compatible Material: Waterborne, Solventborne, High Solids, Single Components, Topcoats, Varnish, Lacquer, Acid Catalysts, Enamel, UV Coating

• Fluid Inlet Size (cm): 1.905
• Fluid Inlet Size (in): 3/4
• Fluid Inlet Size (mm): 19.05
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 0.9525
• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Type: NPT

• Gun Included: 0
• Gun Model: No Applicator
• Gun Technology: Bare Package
• Gun Type: No Applicator

• Hose Inlet Diameter (cm): 0.476
• Hose Inlet Diameter (in): 3/16
• Hose Inlet Diameter (mm): 4.76

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (GPM): 1.2
• Maximum Flow Rate (L/min): 4.5

• Maximum Working Pressure (bar): 69
• Maximum Working Pressure (kPa): 6900
• Maximum Working Pressure (psi): 1000

• Mount Type: Wall Mount

• Power Source: Air

• Pressure Type: High Pressure
• Product Type: Bare Package

• Pump Ratio: 10:1
• Pump Type: Pneumatic Piston Pump

GG G15B17

MERKUR BELLOWS SYSTEM, PUMP, 50CC, STD

Graco G15B17 Merkur Bellows 15:1 Ratio Pump Package with U-Cup Seal, Wall Mount, Fluid Filter

Graco's Merkur bellows piston pumps provide low maintenance with no seals exposed to the atmosphere. These pumps are designed to eliminate conventional throat seals, providing high reliability for moisture-sensitive materials.

• Highest technology air motor on the market
• Low air consumption for increased efficiency
• Simple air motor design and minimal parts reduces repair time
• 300 series stainless steel pump construction provides long-lasting durability

• Model: Merkur
• Series: Bellows

• Application: Supply

• Compatible Material: Waterborne, Solventborne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish, UV Coating

• Fluid Inlet Size (in): 3/4
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 0.9525
• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.53
• Fluid Outlet Thread Gender: Male
• Fluid Outlet Thread Type: NPT

• Gun Model: No Applicator
• Gun Technology: Bare Package
• Gun Type: No Applicator

• Includes: Pump Only Air Controls, Fluid Filter, U-Cup

• Material: Stainless Steel

• Maximum Flow Rate (gpm @ 60 cpm): 0.8

• Maximum Operating Temperature ( degree F): 120

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

• Motor Type: Pneumatic

• Mount Location: Wall Mount
• Mount Type: Wall Mount

• Number of Pieces: 2

• Product Type: Bare Package

• Pump Ratio: 15:1
• Pump Type: Pneumatic Piston Pump

GG G18C03

MERKUR SYSTEM PUMP 18:01 125CC CT STD

Graco G18C03 18:1 Merkur Pump, 2 gpm (7.5 lpm) fluid flow, Cart Mount, Pump/Gun Air Controls, Suction Hose

Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.

• Proven to outperform and outlast other pumps in their class
• Highest technology air motor on the market
• Low air consumption for increased efficiency

• Model: Merkur

• Compatible Material: Waterborne, Solventborne, High Solids, Single Components, Topcoats, Varnish, Lacquer, Acid Catalysts, Enamel, UV Coating

• Fluid Inlet Size (cm): 2.54
• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 1.27
• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7
• Fluid Outlet Thread Type: NPT

• Gun Included: 0
• Gun Model: No Applicator
• Gun Technology: Bare Package
• Gun Type: No Applicator

• Hose Inlet Diameter (cm): 0.476
• Hose Inlet Diameter (in): 3/16
• Hose Inlet Diameter (mm): 4.76

• Includes: Pump and Gun Air Controls, Suction Hose

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (GPM): 2
• Maximum Flow Rate (L/min): 7.5

• Maximum Working Pressure (bar): 124
• Maximum Working Pressure (kPa): 12400
• Maximum Working Pressure (psi): 1800

• Mount Type: Cart Mount

• Power Source: Air

• Pressure Type: High Pressure
• Product Type: Bare Package

• Pump Ratio: 18:1
• Pump Type: Pneumatic Piston Pump

GG G23B38

GG G30C21

MERKUR SYSTEM,PUMP,30:1,25CC,CART,STD

Graco G30C21 30:1 Merkur AA Package, 0.4 gpm (1.5 lpm) fluid flow, Cart Mount, PerformAA 50 Gun, Pump Air Controls, Gun Air/Fluid Hose, Suction Hose

Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.

• Proven to outperform and outlast other pumps in their class
• Highest technology air motor on the market
• Low air consumption for increased efficiency External valve access allows for easy servicing and online replacement to minimize downtime

• Model: Merkur

GG G30W15

MERKUR SYSTEM PUMP 30:1 25CC WALL STD

Graco G30W15 30:1 Merkur AA Package, 0.4 gpm (1.5 lpm) fluid flow, Wall Mount, PerformAA 50 Gun, Pump Air Controls, Gun Air/Fluid Hose, Fluid Filter

Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.

• Proven to outperform and outlast other pumps in their class
• Highest technology air motor on the market
• Low air consumption for increased efficiency External valve access allows for easy servicing and online replacement to minimize downtime

• Model: Merkur

GG G36C13

MERKUR SYSTEM,PUMP,36:1,100CC CART,STD

Graco G36C13 36:1 Merkur AA Package, 1.6 gpm (6 lpm) fluid flow, Cart Mount, PerformAA 50 Gun, Pump Air Controls, Gun Air/Fluid Hose, Fluid Filter, Drain Valve

Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.

• Proven to outperform and outlast other pumps in their class
• Highest technology air motor on the market
• Low air consumption for increased efficiency External valve access allows for easy servicing and online replacement to minimize downtime

• Model: Merkur

GG JC30M9

HIGH-FLO PUMP, 2200/1500, LOW DT, OPN, NPT

Graco JC30M9 High-Flo 4-Ball Pump, CS, 3:1, Low Noise Exhaust, DataTrak, Open Wet Cup Lower, NPT Fittings, Ultralife Rod/Cylinder

Pneumatic High-Flo 4-ball piston pumps provide high output per cycle to reduce pump wear and maintenance. Ideal for low pressure, high flow applications and inherently safe for hazardous locations.

• Slow-moving reciprocating motion does not damage paint like other rotary pumping technologies
• Rugged body armor, won't rust or dent
• De-icing controls eliminate stalling
• DataTrak tracks material usage, monitors and protects your pump

• Model: High-Flo
• Series: 4-Ball

• Application: Circulation

• Compatible Material: Waterborne, Solventborne, High Solids, Xirallic, Metallics, Topcoats, Stains, Varnish, CARC

• Fluid Outlet Size (in): 1-1/2
• Fluid Outlet Size (mm): 38.1
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: Open Wet Cup

• Includes: Carbon Steel Pump, Low Noise Exhaust, DataTrak Monitor, NPT Fittings, Ultralife Rods, Ultralife Cylinder

• Material: Carbon Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 12

• Maximum Flow Rate (GPM): 23.2
• Maximum Flow Rate (L/min): 87.82

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum Working Pressure (bar): 24
• Maximum Working Pressure (kPa): 2400
• Maximum Working Pressure (MPa): 2.4
• Maximum Working Pressure (psi): 350

• Motor Type: Low Noise NXT with DataTrak

• Portable: Non-Portable

• Pump Ratio: 3:1

GG JC40L9

HIGH-FLO PUMP, 2200/1000, LOW N, OPN, NPT

Graco JC40L9 High-Flo 4-Ball Pump, CS, 4:1, Low Noise Exhaust, Open Wet Cup Lower, NPT Fittings, Ultralife Rod/Cylinder

Pneumatic High-Flo 4-ball piston pumps provide high output per cycle to reduce pump wear and maintenance. Ideal for low pressure, high flow applications and inherently safe for hazardous locations.

• Slow-moving reciprocating motion does not damage paint like other rotary pumping technologies
• Rugged body armor, won't rust or dent
• De-icing controls eliminate stalling

• Model: High-Flo
• Series: 4-Ball

• Application: Circulation

• Compatible Material: Waterborne, Solventborne, High Solids, Xirallic, Metallics, Topcoats, Stains, Varnish, CARC

• Fluid Outlet Size (in): 1-1/2
• Fluid Outlet Size (mm): 38.1
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: Open Wet Cup

• Includes: Carbon Steel Pump, Low Noise Exhaust, NPT Fittings, Ultralife Rods, Ultralife Cylinder

• Material: Carbon Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 12

• Maximum Flow Rate (GPM): 16.9
• Maximum Flow Rate (L/min): 63.97

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum Working Pressure (bar): 31
• Maximum Working Pressure (kPa): 3100
• Maximum Working Pressure (MPa): 3.1
• Maximum Working Pressure (psi): 450

• Motor Type: Low Noise NXT

• Portable: Non-Portable

• Pump Ratio: 4:1

GG K60NH1

KING SPRAYER, 60:1, H-P, NF, HD, COMP

Graco K60NH1 King 60:1 Sprayer, Non-Filter, Heavy Duty Cart, Air Controls, Siphon Kit, XTR-7+, 50 ft (15 m) Hose, 6 ft (1.8 m) Whip

High-quality, high-volume, high-pressure. The Graco King pneumatic airless sprayers are the most powerful machines for protective coatings. The system provides the applicator output values, pressure ratios and pumping capacities never seen before. The Graco King units are designed to withstand the harshest environmental conditions and easily handle the toughest protective coatings and corrosion control applications. With 10 different ratios available, there is a sprayer with the correct pressure and flow characteristics for your application.

• Simple Maintenance
  • This air motor has 50% less parts when compared to the NXT valve, making maintenance and troubleshooting easy.
  • All motor parts are easily accessible and require simple maintenance.
• Improved Icing Performance
  • The newly designed poppets and external pilot lines virtually eliminate pilot valve freezing that can result in an instant stop.
  • The icing potential has been reduced by up to 70%
• Less Pulsation
  • With more than 145% higher exhaust capacity in the air valve, you'll achieve a faster, smoother changeover.
  • Eliminating the " wink" in your pattern - it is a difference you will feel.
• New Air Motor
  • Multi gun capabilities Graco's powerful new air motor lets you use multiple guns with almost no perceivable pulsation. A new manifold has been designed to simplify the installation of multiple guns.

• Model: King

• Approved for Hazardous Locations: Yes

• Compatible Material: Protective Coating

• Control Type: Fixed Ratio
• Convertible: Non-Convertible

• Features: Exposed Thermally Isolated Poppets, De-Icing Valve, Tool Box, Trusted XL Motor, Protective Rod Guard, Robust Air Controls, Xtreme Lowers, Improved Siphon Hose, Cart With Wheels

• Fluid Inlet Size (in): 1-1/4
• Fluid Inlet Size (mm): 31.75
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Type: NPT

• Frame Configuration: Heavy-Duty Cart

• Includes: Pump, Lower, Motor, Standard Non-Filter, Heavy Duty Cart, Air Controls, Siphon Kit, Hose, Gun

• Lower Type: Non-Filter

• Material Application: Paints, Primers

• Maximum Air Inlet Pressure (psi): 150

• Maximum Fluid Working Pressure (psi): 6000

• Maximum Sound Pressure Level (dB(A)): 81.48

• Maximum Tip Size (in): Variable

• Maximum Working Pressure (bar): 417
• Maximum Working Pressure (kPa): 41700
• Maximum Working Pressure (MPa): 41.7
• Maximum Working Pressure (psi): 6000

• Motor Type: XL High Performance

• Number of Guns: 1

• Package Options: Air Controls, Siphon Kit, Hose, Gun
• Package Pressure Ratio (Motor/Lower): 60:1 XL6500 / 220cc

• Power Source: Air

• Product Type: Single Leg
• Pump Mount Type: Heavy-Duty Cart

• Pump Rod Type: MaxLife
• Pump Type: Pneumatic Piston Pump

GG L145C1

GG L145C3

GG L145CP

GG L220C4

GG L290C4

GG L60T99

GG L85T73

PRO XP GUN, ES, 85KV, 1.2, AERO

Graco L85T73 Pro Xp85 Air Spray Manual Electrostatic Gun, 85 kV, 0.047 in (1.2 mm) precision high wear nozzle, standard display, aerospace aircap

The aerospace electrostatic spray gun model isn't just for painting airplanes. It's for whenever you need to quickly cover large areas with the finest finish.

• Aerospace air cap, high wear electrode and precision high wear nozzle consistently create an even spray with particles that are the same size.
• Durable components are made for spraying high solid materials and somewhat abrasive coatings at high paint flow rates.

• Model: Pro Xp
• Series: 85
• Product Series: A

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Male
• Air Inlet Thread Type: NPSM

• Application: Electrostatic, Standard
• Applicator Type: Manual

• Coating Type: High Solids, Aerospace

• Compatible Paint Type: Automotive, Base Coat, Clear Coat, Enamels, High Solids, Metallics, Plural Component Materials, Primers, Solventborne, Urethanes

• Display Type: Standard

• Fluid Inlet Size (in): 3/8
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPSM

• Gun Activation: Manual
• Gun Type: Electrostatic
• Gun Weight (g): 676
• Gun Weight (kg): 0.675
• Gun Weight (lb): 1.49
• Gun Weight (oz): 23.81

• Includes: Air Cap, Nozzle, Tool Kit, Gun Cover, Exhaust Tube

• Maximum Fluid Pressure (bar): 7.0
• Maximum Fluid Pressure (kg/cm 2): 7.14
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100
• Maximum Fluid Temperature ( degree C): 48
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Pressure (bar): 7.0
• Maximum Fluid Pressure (kg/cm 2): 7.14
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100
• Maximum Fluid Temperature ( degree C): 48
• Maximum Fluid Temperature ( degree F): 120

• Maximum Paint Resistivity (megohm/cm): Infinity

• Minimum Paint Resistivity (megohm/cm): 25

• Nozzle Size (cm): 0.12
• Nozzle Size (in): 0.047
• Nozzle Size (mm): 1.2

• Overall Length (cm): 26.67
• Overall Length (in): 10.5
• Overall Length (mm): 266.7

GG 24G886

GG 24G887

GG 24H102

GG 24J860

GG 24K361

GG 24K976

GG 24K977

GG 24K981

GG 24K985

GG 24M165

GG 24M419

GG 24N265

GG 24P190

GG 24P192

GG 24P614

GG 24R179

GG 24R185

GG 24R650

GG 24R663

GG 24R734

GG 24R792

GG 24R805

GG 24R895

GG 24T443

GG 24T794

GG 24U854

GG 24X564

GG 24Y843

GG 24Y847

GG 24Y920

GG 24Z498

CSP VALVE, 12OUTLET, BSPP, IND, PKG

Graco 24Z498 CSP Divider Valve, 1/8 inch BSPP, 12 Outlets, Indicator Included

Compact Series Progressive (CSP) valve with broad market versatility. Combine with field-proven G-Series pumps for a complete system solution.

• 1/8 inch BSPP inlet
• Space efficient design with 12 outlets, with indicator
• Outlets can be combined to meet larger bearing needs
• High output pressure - maximum working pressure of 5,076 psi (350 bar) for both oil and grease

• Model: Trabon
• Series: CSP

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Oil, Grease

• Cycle Indicator: Cycle Indicator

• Discharge Per Piston Stroke (in cu ): N/A

• Divider Valve Series: CSP

• Inlet Size (cm): 0.3175
• Inlet Size (in): 1/8
• Inlet Size (mm): 3.175

• Inlet Thread Type: BSPP

• Material: Carbon Steel

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 100
• Maximum Operating Temperature ( degree F): 212

• Maximum Working Pressure (bar): 350
• Maximum Working Pressure (kPa): 35000
• Maximum Working Pressure (psi): 5076

• Minimum Output Volume (cm cu ): 0.2

• Minimum Working Pressure (bar): 15
• Minimum Working Pressure (kPa): 1500

• Minimum Working Pressure (psi): 217.5

• Number of Outlets: 12

• Outlet Thread Gender: Female
• Outlet Thread Type: BSPP

GG 24Z507

CSP VALVE, 12 OUTLET, NPT, IND, PKG

Graco 24Z507 CSP Divider Valve, 1/8 inch NPT, 12 Outlets, Indicator Included

Compact Series Progressive (CSP) valve with broad market versatility. Combine with field-proven G-Series pumps for a complete system solution.

• 1/8 inch NPT inlet
• Space efficient design with 12 outlets, with indicator
• Outlets can be combined to meet larger bearing needs
• High output pressure - maximum working pressure of 5,076 psi (350 bar) for both oil and grease

• Model: Trabon
• Series: CSP

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Oil, Grease

• Cycle Indicator: Cycle Indicator

• Discharge Per Piston Stroke (in cu ): N/A

• Divider Valve Series: CSP

• Inlet Size (cm): 0.3175
• Inlet Size (in): 1/8
• Inlet Size (mm): 3.175

• Inlet Thread Type: NPT

• Material: Carbon Steel

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 100
• Maximum Operating Temperature ( degree F): 212

• Maximum Working Pressure (bar): 350
• Maximum Working Pressure (kPa): 35000
• Maximum Working Pressure (psi): 5076

• Minimum Output Volume (cm cu ): 0.2

• Minimum Working Pressure (bar): 15
• Minimum Working Pressure (kPa): 1500

• Minimum Working Pressure (psi): 217.5

• Number of Outlets: 12

• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

GG 255565

GG 255774

GG 256386
