GRACO INC. S10595

GG OP308-4

Roller

GG 24P315

XD SERIES 40 REEL, BARE, D SPRING, YEL

XD40™, Air/Water, 1 in. (25 mm) Inlet, Bare Reel (1 in. X 50 ft. (25 mm X 15 m) Capacity), NPT, Yellow Graco’s XD40 and XD50 Series Hose Reels are engineered to take a beating and still reliably perform in harsh environments so it’s ready when you need it. Choose from several color options, thread types and hoses. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze and waste oil. Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks. Extensive Hose Offering - Standard models come complete with factory installed hoses on the reel, large selection of optional reels to fit various applications Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop Rugged and Durable Body - Heavy-duty welded spool and ribbed frame for extra strength and toughness over the long haul Meets Worldwide Needs - Built standard with 90° elbow with NPT threads

GG P06LSG

DURA-FLO PUMP, 3400/1000

Dura-Flo NXT 2-Ball Piston Pump, 6:1, Low Noise Exhaust Motor, SST, PTFE/PTFE Packings

Graco’s Dura-Flo pumps with NXT technology provide uniform and easy to control delivery. Ideal for supply applications, these durable pumps feature an NXT motor and can now achieve an even higher range of pressures without compromising flow.

Positive displacement, 2 ball piston design provides uniform and easily controlled delivery High pump pressure and flow performance to handle a broad range of paints and coatings Improved serviceability with fewer parts, faster repairs and lower ownership cost Monitor and protect your pump with DataTrak

GG P06MCK

DURA-FLO PUMP, 3400/1000

Dura-Flo NXT 2-Ball Piston Pump, 6:1, Low Noise Exhaust Motor, DataTrak, CS, UHM with Leather Packings

Graco’s Dura-Flo pumps with NXT technology provide uniform and easy to control delivery. Ideal for supply applications, these durable pumps feature an NXT motor and can now achieve an even higher range of pressures without compromising flow.

Positive displacement, 2 ball piston design provides uniform and easily controlled delivery High pump pressure and flow performance to handle a broad range of paints and coatings Improved serviceability with fewer parts, faster repairs and lower ownership cost Monitor and protect your pump with DataTrak

GG P11LCS

CHECK-MATE PUMP,11:1 400/060 CS SD

Graco P11LCS 11:1 - 60cc Check-Mate Pump with NXT 400 Air Motor, Severe Duty Carbon Steel Construction

Graco Supply Pumps reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials to metering and dispensing systems. Maximize your plant's production capacity.

Application: Long-lasting durability - Check-Mate pumps are a time-tested, proven performer

• NXT 400 Air Motor

  • Low Noise
  • Modular design for easier maintenance
  • Highest technology air motor on the market
• 60cc Check-Mate Lower

  • Severe Duty coatings on rods and cylinder Extends production time
• Standard Threaded Coupler -

Replaceable Seat

• Minimizes service costs

Cast Outlet and Inlet Housing

• Improves structural integrity

NEW Xtreme® Coupler

• Quick-disconnect coupler for easy maintenance

Replaceable Outlet Fitting

• Reduces repair costs

Piston Valve with Floating Piston Seal

• For maximum pressure balance over a range of material viscosities

Replaceable Seat

• Minimizes service costs

Floating Priming Plate

• Provides uniform flow

Cast Outlet and Inlet Housing

• Improves structural integrity

NEW Cartridge Throat Packings

• Allows for easy servicing without removing from ram

Modular Air Valve

• De-icing controls
• Up to 50% quieter than previous models
• Modular air valve - eliminates stalling, easy-to-repair

Hard Part Coatings

• Standard Severe Duty coating on rods and cylinder maximizes wear life

GG P10MCK

DURA-FLO PUMP, 6500/1000

Dura-Flo NXT 2-Ball Piston Pump, 10:1, Low Noise Exhaust Motor, DataTrak, CS, UHM with Leather Packings

Graco’s Dura-Flo pumps with NXT technology provide uniform and easy to control delivery. Ideal for supply applications, these durable pumps feature an NXT motor and can now achieve an even higher range of pressures without compromising flow.

Positive displacement, 2 ball piston design provides uniform and easily controlled delivery High pump pressure and flow performance to handle a broad range of paints and coatings Improved serviceability with fewer parts, faster repairs and lower ownership cost Monitor and protect your pump with DataTrak

GG P10DCK

DURA-FLO PUMP, 6500/1000

Dura-Flo NXT 2-Ball Piston Pump, 10:1, De-Icing Exhaust Motor, CS, UHM with Leather Packings

Graco’s Dura-Flo pumps with NXT technology provide uniform and easy to control delivery. Ideal for supply applications, these durable pumps feature an NXT motor and can now achieve an even higher range of pressures without compromising flow.

Positive displacement, 2 ball piston design provides uniform and easily controlled delivery High pump pressure and flow performance to handle a broad range of paints and coatings Improved serviceability with fewer parts, faster repairs and lower ownership cost Monitor and protect your pump with DataTrak

GG 24P312

Kit, Gun Washer

GG P11LSM

Check-Mate Pump, 11:1 400/060 Ss Ml

GG P11LSS

Check-Mate Pump, 11:1 400/060 Ss Sd

GG 24P313

XD SERIES 40 REEL, BARE, D SPRING, BLUE

Graco 24P313 XD40â„¢, Air/Water, 1 in. (25 mm) Inlet, Bare Reel (1 in. X 50 ft. (25 mm X 15 m) Capacity), NPT, Metallic Blue

Graco’s XD40 and XD50 Series Hose Reels are engineered to take a beating and still reliably perform in harsh environments so it’s ready when you need it. Choose from several color options, thread types and hoses. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze and waste oil.

Application: Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks.

• Extensive Hose Offering - Standard models come complete with factory installed hoses on the reel, large selection of optional reels to fit various applications
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Rugged and Durable Body - Heavy-duty welded spool and ribbed frame for extra strength and toughness over the long haul

• Model: XD
• Series: 40

• Application: Air, Water

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 116

• Frame Type: Box Frame

• Hose Inside Diameter (in): 1
• Hose Inside Diameter (mm): 25.4
• Hose Length (ft): 50
• Hose Length (m): 15

• Hose Reel Type: Bare Reel
• Includes Hose: No
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Type: NPT

• Maximum Working Pressure (psi): 600

• Outlet Size (in): 1
• Outlet Size (mm): 25.4

• Overall Height (in): 26.13
• Overall Height (mm): 664
• Overall Length (in): 26.4
• Overall Length (mm): 671
• Overall Width (in): 16.54
• Overall Width (mm): 420

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Air, Water

GG P10LCS

DURA-FLO PUMP, 6500/1000

10:1 - 1000cc Two-Ball NXT Pump with NXT 6500 Air Motor

Graco’s Xtreme and Dura-Flo pumps with NXT technology provide uniform and easy to control delivery. Ideal for supply applications, these durable pumps feature an NXT motor and can now achieve an even higher range of pressures without compromising flow. Image shown includes datatrack, Datatrack is a option with this solution.

Positive displacement, 2 ball piston design provides uniform and easily controlled delivery High pump pressure and flow performance to handle a broad range of paints and coatings Improved serviceability with fewer parts, faster repairs and lower ownership cost

NXT Air Motor

• Modular design for easier maintenance
• Rugged body armor won’t rust or dent
• Highest technology air motor on the market
• Low Noise exhaust style

Modular Air Valve

• De-icing controls standard
• Up to 50% quieter than previous models
• Modular air valve - reduces stalling, easy-to-repair

Optional Integrated Air Controls

• Lockable easy-turn regulator
• Front-mounted for convenient access
• Compact and modular
• Built-in filtration

Optional DataTrak™ Control

• Runaway protection
• Pump diagnostics
• Material usage

GG 24P316

XD SERIES 40 REEL, BARE, D SPRING, WHT

XD40™, Air/Water, 1 in. (25 mm) Inlet, Bare Reel (1 in. X 50 ft. (25 mm X 15 m) Capacity), NPT, White Graco’s XD40 and XD50 Series Hose Reels are engineered to take a beating and still reliably perform in harsh environments so it’s ready when you need it. Choose from several color options, thread types and hoses. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze and waste oil. Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks. Extensive Hose Offering - Standard models come complete with factory installed hoses on the reel, large selection of optional reels to fit various applications Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop Rugged and Durable Body - Heavy-duty welded spool and ribbed frame for extra strength and toughness over the long haul Meets Worldwide Needs - Built standard with 90° elbow with NPT threads

GG P12LSM

Dura-Flo Pump, 3400/580

GG P12LSS

DURA-FLO PUMP, 3400/580

12:1 - 580cc Dura-Flo Pump with NXT 3400 Air Motor, Severe Duty Stainless Steel Construction

Graco Supply Pumps reliably deliver one-component sealants, adhesives and other low to medium-viscosity materials to metering and dispensing systems. Maximize your plant's production capacity.

Long-lasting durability - Dura-Flo pumps are a time-tested, proven performer NXT 3400 Air Motor

• Low Noise
• Modular design for easier maintenance
• Rugged body armor won't rust or dent
• Highest technology air motor on the market

580cc Dura-Flo Lower

• Severe Duty coatings on rods and cylinder Extends production time

Standard Threaded Coupler -

Replaceable 1 1/2"-11 1/2 NPT Male Outlet Fitting

• Reduces repair costs

Replaceable Seat

• Minimizes service costs

Cast Outlet and Inlet Housing

• Improves structural integrity

Optional DataTrak™ Control

• Runaway protection
• Pump diagnostics
• Material usage

GG 24P317

XD SERIES 40 REEL, BARE, C SPRING, BLU

XD40™, Air/Water/Diesel Fuel/WOE, 1 in. (25 mm) Inlet, Bare Reel (1 in. X 50 ft. (25 mm X 15 m) Capacity), NPT, Metallic Blue Graco’s XD40 and XD50 Series Hose Reels are engineered to take a beating and still reliably perform in harsh environments so it’s ready when you need it. Choose from several color options, thread types and hoses. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze and waste oil. Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks. Extensive Hose Offering - Standard models come complete with factory installed hoses on the reel, large selection of optional reels to fit various applications Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop Rugged and Durable Body - Heavy-duty welded spool and ribbed frame for extra strength and toughness over the long haul Meets Worldwide Needs - Built standard with 90° elbow with NPT threads

GG P12MCD

DURA-FLO PUMP, 3400/580

Dura-Flo NXT 2-Ball Piston Pump, 12:1, Low Noise Exhaust Motor, DataTrak, CS, 3 PTFE / 2 Leather Packings

Graco’s Dura-Flo pumps with NXT technology provide uniform and easy to control delivery. Ideal for supply applications, these durable pumps feature an NXT motor and can now achieve an even higher range of pressures without compromising flow.

Positive displacement, 2 ball piston design provides uniform and easily controlled delivery High pump pressure and flow performance to handle a broad range of paints and coatings Improved serviceability with fewer parts, faster repairs and lower ownership cost Monitor and protect your pump with DataTrak

GG P12MSA

Dura-Flo Pump, 3400/580

GG P14LCM

Check-Mate Pump, 14:1 3400/500 Cs Ml

GG P14RSS

CHECK-MATE PUMP,14:1 3400/500 RS SS SD

Graco P14RSS 14:1 - 500cc Check-Mate Pump with NXT 3400 Air Motor, Severe Duty Stainless Steel Construction

Graco Supply Pumps reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials to metering and dispensing systems. Maximize your plant's production capacity.

Application: Long-lasting durability - Check-Mate pumps are a time-tested, proven performer

• NXT 3400 Air Motor

  • Low Noise, Remote Data Track
  • Modular design for easier maintenance
  • Rugged body armor won't rust or dent
  • Highest technology air motor on the market
• 500cc Check-Mate Lower

  • Severe Duty coatings on rods and cylinder Extends production time
• Standard Threaded Coupler -

Replaceable Seat

• Minimizes service costs

Cast Outlet and Inlet Housing

• Improves structural integrity

GG 24P318

XD SERIES 40 REEL, BARE, C SPRING, YEL

XD40™, Air/Water/Diesel Fuel/WOE, 1 in. (25 mm) Inlet, Bare Reel (1 in. X 50 ft. (25 mm X 15 m) Capacity), NPT, Yellow Graco’s XD40 and XD50 Series Hose Reels are engineered to take a beating and still reliably perform in harsh environments so it’s ready when you need it. Choose from several color options, thread types and hoses. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze and waste oil. Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks. Extensive Hose Offering - Standard models come complete with factory installed hoses on the reel, large selection of optional reels to fit various applications Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop Rugged and Durable Body - Heavy-duty welded spool and ribbed frame for extra strength and toughness over the long haul Meets Worldwide Needs - Built standard with 90° elbow with NPT threads
