GRACO INC. S10595

GG TE30-1222

QUANTM PUMP, QTC-SSFE8SASDPOPTS100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, SD Ball, PO Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include 17-4 Stainless Steel seats, 440-C Stainless Steel balls, and PTFE Overmold diaphragms

GG TE30-1223

QUANTM PUMP, QTC-SSFE8SASDPSPTS100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, SD Ball, PS Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include 17-4 Stainless Steel seats, 440-C Stainless Steel balls, and PTFE/Santoprene 2-Piece diaphragms

GG TE30-1224

QUANTM PUMP, QTC-SSFE8BNBNBN--S200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, BN Seat, BN Ball, BN Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include Buna-N seats, Buna-N balls, and Buna-N diaphragms

GG TE30-1225

QUANTM PUMP, QTC-SSFE8FKFKFK--S200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, FK Seat, FK Ball, FK Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include FKM (Viton) seats, FKM (Viton) balls, and FKM (Viton) diaphragms

GG TE30-1226

QUANTM PUMP, QTC-SSFE8GEGEGEPTS200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, GE Seat, GE Ball, GE Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include G.E.T. (Graco Engineered Thermoplastic) seats, G.E.T. balls, and G.E.T. diaphragms

GG TE30-1227

QUANTM PUMP, QTC-SSFE8SPSPSPPTS200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SP Seat, SP Ball, SP Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include Santoprene seats, Santoprene balls, and Santoprene diaphragms

GG TE30-1228

QUANTM PUMP, QTC-SSFE8SAPTPOPTS200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, PT Ball, PO Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include 17-4 Stainless Steel seats, PTFE balls, and PTFE Overmold diaphragms

GG TE30-1229

QUANTM PUMP, QTC-SSFE8SAPTPSPTS200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, PT Ball, PS Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include 17-4 Stainless Steel seats, PTFE balls, and PTFE/Santoprene 2-Piece diaphragms

GG TE30-1230

QUANTM PUMP, QTC-SSFE8SASDPOPTS200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, SD Ball, PO Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include 17-4 Stainless Steel seats, 440-C Stainless Steel balls, and PTFE Overmold diaphragms

GG TE30-1231

QUANTM PUMP, QTC-SSFE8SASDPSPTS200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, SD Ball, PS Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include 17-4 Stainless Steel seats, 440-C Stainless Steel balls, and PTFE/Santoprene 2-Piece diaphragms

GG TE30-1232

QUANTM PUMP, QTC-SSFE9BNBNBN--S100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, BN Seat, BN Ball, BN Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include Buna-N seats, Buna-N balls, and Buna-N diaphragms

GG TE30-1233

QUANTM PUMP, QTC-SSFE9FKFKFK--S100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, FK Seat, FK Ball, FK Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include FKM (Viton) seats, FKM (Viton) balls, and FKM (Viton) diaphragms

GG TE30-1234

QUANTM PUMP, QTC-SSFE9GEGEGEPTS100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, GE Seat, GE Ball, GE Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include G.E.T. (Graco Engineered Thermoplastic) seats, G.E.T. balls, and G.E.T. diaphragms

GG TE30-1235

QUANTM PUMP, QTC-SSFE9SPSPSPPTS100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SP Seat, SP Ball, SP Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include Santoprene seats, Santoprene balls, and Santoprene diaphragms

GG TE30-1236

QUANTM PUMP, QTC-SSFE9SAPTPOPTS100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, PT Ball, PO Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include 17-4 Stainless Steel seats, PTFE balls, and PTFE Overmold diaphragms

GG TE30-1237

QUANTM PUMP, QTC-SSFE9SAPTPSPTS100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, PT Ball, PS Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include 17-4 Stainless Steel seats, PTFE balls, and PTFE/Santoprene 2-Piece diaphragms

GG TE30-1239

QUANTM PUMP, QTC-SSFE9SASDPSPTS100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, SD Ball, PS Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include 17-4 Stainless Steel seats, 440-C Stainless Steel balls, and PTFE/Santoprene 2-Piece diaphragms

GG TE30-1240

QUANTM PUMP, QTC-SSFE9BNBNBN--S200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, BN Seat, BN Ball, BN Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include Buna-N seats, Buna-N balls, and Buna-N diaphragms

GG TE30-1241

QUANTM PUMP, QTC-SSFE9FKFKFK--S200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, FK Seat, FK Ball, FK Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include FKM (Viton) seats, FKM (Viton) balls, and FKM (Viton) diaphragms

GG TE30-1242

QUANTM PUMP, QTC-SSFE9GEGEGEPTS200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, GE Seat, GE Ball, GE Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include G.E.T. (Graco Engineered Thermoplastic) seats, G.E.T. balls, and G.E.T. diaphragms

GG TE30-1243

QUANTM PUMP, QTC-SSFE9SPSPSPPTS200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SP Seat, SP Ball, SP Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include Santoprene seats, Santoprene balls, and Santoprene diaphragms

GG TE30-1244

QUANTM PUMP, QTC-SSFE9SAPTPOPTS200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, PT Ball, PO Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include 17-4 Stainless Steel seats, PTFE balls, and PTFE Overmold diaphragms

GG TE30-1245

QUANTM PUMP, QTC-SSFE9SAPTPSPTS200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, PT Ball, PS Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include 17-4 Stainless Steel seats, PTFE balls, and PTFE/Santoprene 2-Piece diaphragms

GG TE30-1246

QUANTM PUMP, QTC-SSFE9SASDPOPTS200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, SD Ball, PO Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include 17-4 Stainless Steel seats, 440-C Stainless Steel balls, and PTFE Overmold diaphragms

GG TE30-1247

QUANTM PUMP, QTC-SSFE9SASDPSPTS200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, SD Ball, PS Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include 17-4 Stainless Steel seats, 440-C Stainless Steel balls, and PTFE/Santoprene 2-Piece diaphragms

GG TE30-1248

QUANTM PUMP, QTC-SSFEABNBNBN--S100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, BN Seat, BN Ball, BN Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include Buna-N seats, Buna-N balls, and Buna-N diaphragms

GG TE30-1249

QUANTM PUMP, QTC-SSFEAFKFKFK--S100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, FK Seat, FK Ball, FK Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include FKM (Viton) seats, FKM (Viton) balls, and FKM (Viton) diaphragms

GG TE30-1250

QUANTM PUMP, QTC-SSFEAGEGEGEPTS100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, GE Seat, GE Ball, GE Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include G.E.T. (Graco Engineered Thermoplastic) seats, G.E.T. balls, and G.E.T. diaphragms

GG TE30-1251

QUANTM PUMP, QTC-SSFEASPSPSPPTS100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SP Seat, SP Ball, SP Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include Santoprene seats, Santoprene balls, and Santoprene diaphragms

GG TE30-1252

QUANTM PUMP, QTC-SSFEASAPTPOPTS100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, PT Ball, PO Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include 17-4 Stainless Steel seats, PTFE balls, and PTFE Overmold diaphragms

GG TE30-1253

QUANTM PUMP, QTC-SSFEASAPTPSPTS100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, PT Ball, PS Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include 17-4 Stainless Steel seats, PTFE balls, and PTFE/Santoprene 2-Piece diaphragms

GG TE30-1254

QUANTM PUMP, QTC-SSFEASASDPOPTS100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, SD Ball, PO Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include 17-4 Stainless Steel seats, 440-C Stainless Steel balls, and PTFE Overmold diaphragms

GG TE30-1256

QUANTM PUMP, QTC-SSFEABNBNBN--S200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, BN Seat, BN Ball, BN Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include Buna-N seats, Buna-N balls, and Buna-N diaphragms

GG TE30-1255

QUANTM PUMP, QTC-SSFEASASDPSPTS100

QUANTM i30, 1"NPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, SA Seat, SD Ball, PS Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with NPT End Port
• Internal components include 17-4 Stainless Steel seats, 440-C Stainless Steel balls, and PTFE/Santoprene 2-Piece diaphragms

GG TE30-1257

QUANTM PUMP, QTC-SSFEAFKFKFK--S200

QUANTM i30, 1"BSPT, Stainless Steel Electric Diaphragm Pump, 380-480 VAC 3Ph, FEP AL Center, FK Seat, FK Ball, FK Diaphragm QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump. The stainless-steel fluid section is designed to provide a high level of abrasion and corrosion resistance. With up to 8x more continuous torque at low speeds than conventional motors, this electric pump is an energy-saving workhorse that also delivers lower lifetime costs than less efficient pump technologies and is ideal for applications involving materials that are highly abrasive, paints, solvents or heated materials. This additional resilience means less downtime, which in turn provides a new opportunity to improve your bottom line. This powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework. Revolutionary Design

• Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
• Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
• Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
• Quiet operation reduces plant noise and improves employee safety and health
• Smart pump control provides more accurate flow set points and built-in I/O

Efficient Electric Motor

• FEP Coated Aluminum electric drive
• 380-480 VAC 3Ph motor with 15 ft flying leads
• Non-hazardous

Materials of Construction

• 316 Stainless Steel fluid section with BSPT End Port
• Internal components include FKM (Viton) seats, FKM (Viton) balls, and FKM (Viton) diaphragms

GG SP15.0020

SANIFORCE AODD PUMP, 1590HS.PS01ASSASSFKFKFK31

Graco SP15.0020 SaniForce 1590, 1.5" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, FK Balls, FK Diaphragms

Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 105 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1.5 inch sanitary pump with flow rates up to 105 gpm (397.5 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1590 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: FKM (Viton)

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: FKM (Viton)

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: FKM (Viton)
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 150
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 165

• Maximum Flow Rate (GPM): 105
• Maximum Flow Rate (L/min): 397.5

• Maximum Fluid Operating Temperature (°C): 135
• Maximum Fluid Operating Temperature (°F): 275
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 135
• Maximum Fluid Operating Temperature (°F): 275
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 1.27
• Maximum Solid Size (in): 0.5

GG SP15.0005

SANIFORCE AODD PUMP, 1590HS.PSP1ASSAFL-PSEP21

Graco SP15.0005 SaniForce 1590, 1.5" HS SST Pneumatic Diaphragm Pump, SS Center, FL Checks, PS Diaphragms

Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 80 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1.5 inch sanitary pump with flow rates up to 80 gpm (302.8 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Flapper check enables passage of solids up to 1.2 in. (30.5 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1590 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: 316 Stainless Steel Flapper

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: PTFE/Santoprene 2-Piece

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 2.1 (Standard)

• Maximum Air Consumption (SCFM): 165
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 260

• Maximum Flow Rate (GPM): 80
• Maximum Flow Rate (L/min): 302.8

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 3.05

GG SP15.0019

SANIFORCE AODD PUMP, 1590HS.PS01ASSASSFKFKFK21

SaniForce 1590, 1.5" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, FK Balls, FK Diaphragms Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 105 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 1.5 inch sanitary pump with flow rates up to 105 gpm (397.5 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process Optional leak sensors notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.5 in. (12.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP15.0021

SANIFORCE AODD PUMP, 1590HS.PS01ASSASSPTPOEP21

SaniForce 1590, 1.5" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PO Diaphragms Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 105 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 1.5 inch sanitary pump with flow rates up to 105 gpm (397.5 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process PTFE/EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side Optional leak sensors notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.5 in. (12.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP15.0023

SANIFORCE AODD PUMP, 1590HS.PSP1ASSASSPTPSEP21

SaniForce 1590, 1.5" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PS Diaphragms Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 105 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 1.5 inch sanitary pump with flow rates up to 105 gpm (397.5 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process Optional leak sensors notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.5 in. (12.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP15.0123

SANIFORCE AODD PUMP, 1590PH.PS03ASSASSPTPOEP21

Graco SP15.0123 SaniForce 1590, 1.5" PH SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PO Diaphragms

Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 105 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1.5 inch sanitary pump with flow rates up to 105 gpm (397.5 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• PTFE/EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side
• Equipped with leak sensor to notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1590 PH

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: PTFE

• Center Section Material: Stainless Steel

• Compatible Material: Food, Personal Care, Pharmaceutical

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: PTFE/EPDM Overmold

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care, Pharmaceutical

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 2.1 (Standard)

• Maximum Air Consumption (SCFM): 150
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 165

• Maximum Flow Rate (GPM): 105
• Maximum Flow Rate (L/min): 397.5

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
<

GG SP15.0022

SANIFORCE AODD PUMP, 1590HS.PS01ASSASSPTPOEP31

Graco SP15.0022 SaniForce 1590, 1.5" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PO Diaphragms

Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 105 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1.5 inch sanitary pump with flow rates up to 105 gpm (397.5 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• PTFE/EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1590 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: PTFE

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: PTFE/EPDM Overmold

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 150
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 165

• Maximum Flow Rate (GPM): 105
• Maximum Flow Rate (L/min): 397.5

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure

GG SP15.0126

SANIFORCE AODD PUMP, 1590PH.PSP3ASSASSPTPSEP31

Graco SP15.0126 SaniForce 1590, 1.5" PH SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PS Diaphragms

Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 105 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1.5 inch sanitary pump with flow rates up to 105 gpm (397.5 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• Equipped with leak sensor to notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1590 PH

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: PTFE

• Center Section Material: Stainless Steel

• Compatible Material: Food, Personal Care, Pharmaceutical

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: PTFE/Santoprene 2-Piece

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care, Pharmaceutical

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 150
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 165

• Maximum Flow Rate (GPM): 105
• Maximum Flow Rate (L/min): 397.5

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 1.27
• Maximum S

GG SP15.0028

SANIFORCE AODD PUMP, 1590HS.PS01ASSASSSPSPEP31

Graco SP15.0028 SaniForce 1590, 1.5" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, SP Balls, SP Diaphragms

Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 105 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1.5 inch sanitary pump with flow rates up to 105 gpm (397.5 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1590 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: Santoprene

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: Santoprene

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 150
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 165

• Maximum Flow Rate (GPM): 105
• Maximum Flow Rate (L/min): 397.5

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 1.27
• Maximum Solid Size (in): 0.5

GG SP15.0105

SANIFORCE AODD PUMP, 15903A.PS02ASSASSPTPOEP21

SaniForce 1590, 1.5" 3A SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PO Diaphragms Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 105 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 1.5 inch sanitary pump with flow rates up to 105 gpm (397.5 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process PTFE/EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side Equipped with leak sensor to notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.5 in. (12.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP15.0149

SANIFORCE AODD PUMP, 1590HS.PS01ASSASSBNBNBN21

Graco SP15.0149 SaniForce 1590, 1.5" HS SST Pneumatic Diaphragm Pump, SS Center, BN Seats, BN Balls, BN Diaphragms

Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 105 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1.5 inch sanitary pump with flow rates up to 105 gpm (397.5 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1590 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: Buna

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: Buna

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food and Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: Buna
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 2.1 (Standard)

• Maximum Air Consumption (SCFM): 150
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 165

• Maximum Flow Rate (GPM): 105
• Maximum Flow Rate (L/min): 397.5

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 1.27
• Maximum Solid Size (in): 0.5
• Maximum So

GG SP15.0100

SANIFORCE AODD PUMP, 1590HS.PS01ASSAFL-EOEP21

Graco SP15.0100 SaniForce 1590, 1.5" HS SST Pneumatic Diaphragm Pump, SS Center, FL Checks, EO Diaphragms

Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 80 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1.5 inch sanitary pump with flow rates up to 80 gpm (302.8 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Flapper check enables passage of solids up to 1.2 in. (30.5 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1590 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: 316 Stainless Steel Flapper

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: EPDM Overmold

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 2.1 (Standard)

• Maximum Air Consumption (SCFM): 165
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 260

• Maximum Flow Rate (GPM): 80
• Maximum Flow Rate (L/min): 302.8

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
<

GG SP15.0175

SANIFORCE AODD PUMP, 1590PH.PS03ASSASSEPEOEP21

Graco SP15.0175 SaniForce 1590, 1.5" PH SST Pneumatic Diaphragm Pump, SS Center, SS Seats, EP Balls, EO Diaphragms

Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 105 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1.5 inch sanitary pump with flow rates up to 105 gpm (397.5 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side
• Equipped with leak sensor to notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1590 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: EPDM

• Center Section Material: Stainless Steel

• Compatible Material: Food, Personal Care, Pharmaceutical

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: EPDM Overmold

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care, Pharmaceutical

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 2.1 (Standard)

• Maximum Air Consumption (SCFM): 150
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 165

• Maximum Flow Rate (GPM): 105
• Maximum Flow Rate (L/min): 397.5

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maxim

GG SP15.0024

SANIFORCE AODD PUMP, 1590HS.PSP1ASSASSPTPSEP31

Graco SP15.0024 SaniForce 1590, 1.5" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PS Diaphragms

Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 105 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1.5 inch sanitary pump with flow rates up to 105 gpm (397.5 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1590 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: PTFE

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: PTFE/Santoprene 2-Piece

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 150
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 165

• Maximum Flow Rate (GPM): 105
• Maximum Flow Rate (L/min): 397.5

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 1.27
• Maximum Solid Size (in): 0.5

GG SP15.0163

SANIFORCE AODD PUMP, 1590HS.PS01ASSASSEPEOEP21

Graco SP15.0163 SaniForce 1590, 1.5" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, EP Balls, EO Diaphragms

Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 105 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1.5 inch sanitary pump with flow rates up to 105 gpm (397.5 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1590 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: EPDM

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food and Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: EPDM Overmold

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food and Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 2.1 (Standard)

• Maximum Air Consumption (SCFM): 150
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 165

• Maximum Flow Rate (GPM): 105
• Maximum Flow Rate (L/min): 397.5

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MP

GG SP15.0176

SANIFORCE AODD PUMP, 1590PH.PS03ASSASSEPEOEP31

Graco SP15.0176 SaniForce 1590, 1.5" PH SST Pneumatic Diaphragm Pump, SS Center, SS Seats, EP Balls, EO Diaphragms

Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 105 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1.5 inch sanitary pump with flow rates up to 105 gpm (397.5 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side
• Equipped with leak sensor to notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1590 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: EPDM

• Center Section Material: Stainless Steel

• Compatible Material: Food, Personal Care, Pharmaceutical

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: EPDM Overmold

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care, Pharmaceutical

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 150
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 165

• Maximum Flow Rate (GPM): 105
• Maximum Flow Rate (L/min): 397.5

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Max

GG SP15.0027

SANIFORCE AODD PUMP, 1590HS.PS01ASSASSSPSPEP21

Graco SP15.0027 SaniForce 1590, 1.5" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, SP Balls, SP Diaphragms

Graco's SaniForce 1590, 1.5-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 105 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1.5 inch sanitary pump with flow rates up to 105 gpm (397.5 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1590 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: Santoprene

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: Santoprene

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 2.1 (Standard)

• Maximum Air Consumption (SCFM): 150
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 165

• Maximum Flow Rate (GPM): 105
• Maximum Flow Rate (L/min): 397.5

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 1.27
• Maximum Solid Size (in): 0.5
• M

GG SP1B.0002

SANIFORCE AODD PUMP, 1040HS.PS01ASSASSCWSPEP21

Graco SP1B.0002 SaniForce 1040, 1" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seat, CW Balls, SP Diaphragms

Graco's SaniForce 1040, 1-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 41 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1 inch sanitary pump with flow rates up to 41 gpm (155 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.44 in. (11.2 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1040 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: Polychloroprene Weighted

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: Santoprene

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 2.1 (Standard)

• Maximum Air Consumption (SCFM): 65
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 240

• Maximum Flow Rate (GPM): 41
• Maximum Flow Rate (L/min): 155

• Maximum Fluid Operating Temperature (°C): 80
• Maximum Fluid Operating Temperature (°F): 176
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 80
• Maximum Fluid Operating Temperature (°F): 176
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 1.12
• Maximum Solid Size (in): 0.44
• Maximum Solid Size (mm): 11.2

• Minimum Fluid Operating

GG SP1B.0006

SANIFORCE AODD PUMP, 1040HS.PS01ASSASSPTPOEP21

SaniForce 1040, 1" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PO Diaphragms Graco's SaniForce 1040, 1-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 41 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 1 inch sanitary pump with flow rates up to 41 gpm (155 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process PTFE/EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.42 in. (10.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP1B.0012

SANIFORCE AODD PUMP, 1040HS.PS01ASSASSSPSPEP21

SaniForce 1040, 1" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seat, SP Balls, SP Diaphragms Graco's SaniForce 1040, 1-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 41 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 1 inch sanitary pump with flow rates up to 41 gpm (155 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.44 in. (11.2 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP1B.0009

SANIFORCE AODD PUMP, 1040HS.PSP1ASSASSPTPSEP31

SaniForce 1040, 1" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seat, PT Balls, PS Diaphragms Graco's SaniForce 1040, 1-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 41 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 1 inch sanitary pump with flow rates up to 41 gpm (155 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.44 in. (11.2 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP1B.0004

SANIFORCE AODD PUMP, 1040HS.PS01ASSASSFKFKEP21

SaniForce 1040, 1" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, FK Balls, FK Diaphragms Graco's SaniForce 1040, 1-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 41 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 1 inch sanitary pump with flow rates up to 41 gpm (155 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.42 in. (10.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP1B.0013

SANIFORCE AODD PUMP, 1040HS.PS01ASSASSSPSPEP31

Graco SP1B.0013 SaniForce 1040, 1" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seat, SP Balls, SP Diaphragms

Graco's SaniForce 1040, 1-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 41 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1 inch sanitary pump with flow rates up to 41 gpm (155 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.44 in. (11.2 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1040 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: Santoprene

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: Santoprene

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 65
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 240

• Maximum Flow Rate (GPM): 41
• Maximum Flow Rate (L/min): 155

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 1.12
• Maximum Solid Size (in): 0.44
• Maximum Solid Size (mm): 11.2

• Minimum Fluid Operating Temperature

GG SP1B.0036

SANIFORCE AODD PUMP, 1040PH.PSP3ASSASSPTPSEP21

SaniForce 1040, 1" PH SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PS Diaphragms Graco's SaniForce 1040, 1-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 41 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 1 inch sanitary pump with flow rates up to 41 gpm (155 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process Equipped with leak sensor to notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.42 in. (10.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP1B.0034

SANIFORCE AODD PUMP, 1040PH.PS03ASSASSPTPOEP21

SaniForce 1040, 1" PH SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PO Diaphragms Graco's SaniForce 1040, 1-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 41 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 1 inch sanitary pump with flow rates up to 41 gpm (155 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process PTFE/EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side Equipped with leak sensor to notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.42 in. (10.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP1B.0008

SANIFORCE AODD PUMP, 1040HS.PSP1ASSASSPTPSEP21

SaniForce 1040, 1" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seat, PT Balls, PS Diaphragms Graco's SaniForce 1040, 1-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 41 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 1 inch sanitary pump with flow rates up to 41 gpm (155 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.44 in. (11.2 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP1B.0056

SANIFORCE AODD PUMP, 1040HS.PS01ASSASSBNBNBN21

Graco SP1B.0056 SaniForce 1040, 1" HS Pneumatic Diaphragm Pump, SS Center, BN Seats, BN Balls, BN Diaphragms

Graco's SaniForce 1040, 1-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 41 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 1 inch sanitary pump with flow rates up to 41 gpm (155 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.42 in. (10.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 1040 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: Buna

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: Buna

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food and Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: Buna
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 2.1 (Standard)

• Maximum Air Consumption (SCFM): 65
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 240

• Maximum Flow Rate (GPM): 41
• Maximum Flow Rate (L/min): 155

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 1.07
• Maximum Solid Size (in): 0.42
• Maximum Solid Size (mm): 10.7

• Minimum Fluid Operating Temperature (°C): -4

GG SP2B.0004

SANIFORCE AODD PUMP, 2150HS.PS01ASSASSCWSPEP21

Graco SP2B.0004 SaniForce 2150, 2" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, CW Balls, SP Diaphragms

Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 2150 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: Polychloroprene Weighted

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: Santoprene

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 2.1 (Standard)

• Maximum Air Consumption (SCFM): 200
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 135

• Maximum Flow Rate (GPM): 180
• Maximum Flow Rate (L/min): 681

• Maximum Fluid Operating Temperature (°C): 80
• Maximum Fluid Operating Temperature (°F): 176
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 80
• Maximum Fluid Operating Temperature (°F): 176
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 1.27
• Maximum Solid Size (in): 0.5
<

GG SP2B.0006

SANIFORCE AODD PUMP, 2150HS.PS01ASSASSPTEOEP21

SaniForce 2150, 2" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, EO Diaphragms Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side Optional leak sensors notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.5 in. (12.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP2B.0007

SANIFORCE AODD PUMP, 2150HS.PS01ASSASSPTEOEP31

Graco SP2B.0007 SaniForce 2150, 2" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, EO Diaphragms

Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 2150 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: PTFE

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: EPDM Overmold

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 200
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 135

• Maximum Flow Rate (GPM): 180
• Maximum Flow Rate (L/min): 681

• Maximum Fluid Operating Temperature (°C): 104
• Maximum Fluid Operating Temperature (°F): 220
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 104
• Maximum Fluid Operating Temperature (°F): 220
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8

GG SP2B.0014

Saniforce Aodd Pump, 2150Hs.Ps01Assassptspep21

GG SP2B.0012

SANIFORCE AODD PUMP, 2150HS.PSP1ASSASSPTPSEP21

SaniForce 2150, 2" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PS Diaphragms Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process Optional leak sensors notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.5 in. (12.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP2B.0013

SANIFORCE AODD PUMP, 2150HS.PSP1ASSASSPTPSEP31

Graco SP2B.0013 SaniForce 2150, 2" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PS Diaphragms

Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 2150 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: PTFE

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: PTFE/Santoprene 2-Piece

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 200
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 135

• Maximum Flow Rate (GPM): 180
• Maximum Flow Rate (L/min): 681

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 1.27
• Maximum Solid Size (in): 0.5
• Ma

GG SP2B.0011

SANIFORCE AODD PUMP, 2150HS.PS01ASSASSPTPOEP31

SaniForce 2150, 2" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PO Diaphragms Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process PTFE/EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side Optional leak sensors notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.5 in. (12.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP2B.0009

SANIFORCE AODD PUMP, 2150HS.PS01ASSASSFKFKFK31

Graco SP2B.0009 SaniForce 2150, 2" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, FK Balls, FK Diaphragms

Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 2150 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: FKM (Viton)

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: FKM (Viton)

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: FKM (Viton)
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 200
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 135

• Maximum Flow Rate (GPM): 180
• Maximum Flow Rate (L/min): 681

• Maximum Fluid Operating Temperature (°C): 135
• Maximum Fluid Operating Temperature (°F): 275
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 135
• Maximum Fluid Operating Temperature (°F): 275
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 1.27
• Maximum Solid Size (in): 0.5

GG SP2B.0008

SANIFORCE AODD PUMP, 2150HS.PS01ASSASSFKFKFK21

SaniForce 2150, 2" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, FK Balls, FK Diaphragms Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process Optional leak sensors notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.5 in. (12.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP2B.0015

Saniforce Aodd Pump, 2150Hs.Ps01Assassptspep31

GG SP2B.0082

SANIFORCE AODD PUMP, 21503A.PS02ASSASSPTPOEP21

SaniForce 2150, 2" 3A SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PO Diaphragms Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process PTFE/EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side Equipped with leak sensor to notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.5 in. (12.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP2B.0017

SANIFORCE AODD PUMP, 2150HS.PS01ASSASSSPSPEP31

Graco SP2B.0017 SaniForce 2150, 2" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, SP Balls, SP Diaphragms

Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 2150 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: Santoprene

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: Santoprene

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 200
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 135

• Maximum Flow Rate (GPM): 180
• Maximum Flow Rate (L/min): 681

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 1.27
• Maximum Solid Size (in): 0.5
• Maximum S

GG SP2B.0010

SANIFORCE AODD PUMP, 2150HS.PS01ASSASSPTPOEP21

SaniForce 2150, 2" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PO Diaphragms Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process PTFE/EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side Optional leak sensors notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.5 in. (12.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP2B.0118

SANIFORCE AODD PUMP, 2150PH.PS03ASSASSPTPOEP21

SaniForce 2150, 2" PH SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PO Diaphragms Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process PTFE/EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side Equipped with leak sensor to notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.5 in. (12.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP2B.0016

SANIFORCE AODD PUMP, 2150HS.PS01ASSASSSPSPEP21

SaniForce 2150, 2" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, SP Balls, SP Diaphragms Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process Optional leak sensors notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.5 in. (12.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP2B.0120

SANIFORCE AODD PUMP, 2150PH.PSP3ASSASSPTPSEP21

SaniForce 2150, 2" PH SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, PS Diaphragms Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process Equipped with leak sensor to notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.5 in. (12.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP2B.0078

SANIFORCE AODD PUMP, 21503A.PS02ASSASSPTEOEP21

SaniForce 2150, 2" 3A SST Pneumatic Diaphragm Pump, SS Center, SS Seats, PT Balls, EO Diaphragms Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side Equipped with leak sensor to notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.5 in. (12.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP2B.0165

SANIFORCE AODD PUMP, 2150HS.PS01ASSASSEPEOEP31

Graco SP2B.0165 SaniForce 2150, 2" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, EP Balls, EO Diaphragms

Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 2150 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: EPDM

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: EPDM Overmold

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food and Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 200
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 135

• Maximum Flow Rate (GPM): 180
• Maximum Flow Rate (L/min): 681

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8

GG SP2B.0173

SANIFORCE AODD PUMP, 2150PH.PS03ASSASSEPEOEP31

Graco SP2B.0173 SaniForce 2150, 2" PH SST Pneumatic Diaphragm Pump, SS Center, SS Seats, EP Balls, EO Diaphragms

Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side
• Equipped with leak sensor to notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 2150 PH

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: EPDM

• Center Section Material: Stainless Steel

• Compatible Material: Food, Personal Care, Pharmaceutical

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: EPDM Overmold

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care, Pharmaceutical

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 200
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 135

• Maximum Flow Rate (GPM): 180
• Maximum Flow Rate (L/min): 681

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid

GG SP2B.0172

SANIFORCE AODD PUMP, 2150PH.PS03ASSASSEPEOEP21

Graco SP2B.0172 SaniForce 2150, 2" PH SST Pneumatic Diaphragm Pump, SS Center, SS Seats, EP Balls, EO Diaphragms

Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side
• Equipped with leak sensor to notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 2150 PH

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: EPDM

• Center Section Material: Stainless Steel

• Compatible Material: Food, Personal Care, Pharmaceutical

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: EPDM Overmold

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care, Pharmaceutical

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 2.1 (Standard)

• Maximum Air Consumption (SCFM): 200
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 135

• Maximum Flow Rate (GPM): 180
• Maximum Flow Rate (L/min): 681

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid P

GG SP3B.0008

SANIFORCE AODD PUMP, 3250HS.PP01ASSASSFKFKFK21

SaniForce 3250, 3" HS SST Pneumatic Diaphragm Pump, Poly Center, SS Seats, FK Balls, FK Diaphragms Graco's SaniForce 3250, 3-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 230 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 3 inch sanitary pump with flow rates up to 230 gpm (870 lpm) and pressures up to 100 psi (6.9 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process Optional leak sensors notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.75 in. (19 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP3B.0006

SANIFORCE AODD PUMP, 3250HS.PP01ASSASSPTEOEP21

SaniForce 3250, 3" HS SST Pneumatic Diaphragm Pump, Poly Center, SS Seats, PT Balls, EO Diaphragms Graco's SaniForce 3250, 3-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 230 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 3 inch sanitary pump with flow rates up to 230 gpm (870 lpm) and pressures up to 100 psi (6.9 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side Optional leak sensors notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.75 in. (19 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP3B.0009

SANIFORCE AODD PUMP, 3250HS.PP01ASSASSFKFKFK31

Graco SP3B.0009 SaniForce 3250, 3" HS SST Pneumatic Diaphragm Pump, Poly Center, SS Seats, FK Balls, FK Diaphragms

Graco's SaniForce 3250, 3-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 230 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 3 inch sanitary pump with flow rates up to 230 gpm (870 lpm) and pressures up to 100 psi (6.9 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.75 in. (19 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 3250 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 3/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: FKM (Viton)

• Center Section Material: Polypropylene

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: FKM (Viton)

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food, Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: FKM (Viton)
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 290
• Maximum Air Pressure (bar): 6.9

• Maximum Air Pressure (kPa): 690
• Maximum Air Pressure (MPa): 0.69
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 190

• Maximum Flow Rate (GPM): 230
• Maximum Flow Rate (L/min): 870

• Maximum Fluid Operating Temperature (°C): 135
• Maximum Fluid Operating Temperature (°F): 275
• Maximum Fluid Pressure (bar): 6.9
• Maximum Fluid Pressure (kPa): 690
• Maximum Fluid Pressure (MPa): 0.69
• Maximum Fluid Pressure (psi): 100

• Maximum Fluid Operating Temperature (°C): 135
• Maximum Fluid Operating Temperature (°F): 275
• Maximum Fluid Pressure (bar): 6.9
• Maximum Fluid Pressure (kPa): 690
• Maximum Fluid Pressure (MPa): 0.69
• Maximum Fluid Pressure (psi): 100

• Maximum Solid Size (cm): 1.9
• Maximum Solid Size (in): 0.75

GG SP2B.0144

SANIFORCE AODD PUMP, 2150HS.PS01ASSASSBNBNBN21

Graco SP2B.0144 SaniForce 2150, 2" HS SST Pneumatic Diaphragm Pump, SS Center, BN Seats, BN Balls, BN Diaphragms

Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.5 in. (12.7 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 2150 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: Buna

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: Buna

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food and Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: Buna
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 2.1 (Standard)

• Maximum Air Consumption (SCFM): 200
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 135

• Maximum Flow Rate (GPM): 180
• Maximum Flow Rate (L/min): 681

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Operating Temperature (°C): 82
• Maximum Fluid Operating Temperature (°F): 180
• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 1.27
• Maximum Solid Size (in): 0.5
• Maximum Solid Size (

GG SP2B.0164

SANIFORCE AODD PUMP, 2150HS.PS01ASSASSEPEOEP21

SaniForce 2150, 2" HS SST Pneumatic Diaphragm Pump, SS Center, SS Seats, EP Balls, EO Diaphragms Graco's SaniForce 2150, 2-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 180 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 2 inch sanitary pump with flow rates up to 180 gpm (681 lpm) and pressures up to 120 psi (8 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side Optional leak sensors notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.5 in. (12.7 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP3B.0016

SANIFORCE AODD PUMP, 3250HS.PP01ASSASSSPSPEP21

SaniForce 3250, 3" HS SST Pneumatic Diaphragm Pump, Poly Center, SS Seats, SP Balls, SP Diaphragms Graco's SaniForce 3250, 3-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 230 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 3 inch sanitary pump with flow rates up to 230 gpm (870 lpm) and pressures up to 100 psi (6.9 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process Optional leak sensors notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.75 in. (19 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP3B.0012

SANIFORCE AODD PUMP, 3250HS.PPP1ASSASSPTPSEP21

SaniForce 3250, 3" HS SST Pneumatic Diaphragm Pump, Poly Center, SS Seats, PT Balls, PS Diaphragms Graco's SaniForce 3250, 3-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 230 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 3 inch sanitary pump with flow rates up to 230 gpm (870 lpm) and pressures up to 100 psi (6.9 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process Optional leak sensors notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.75 in. (19 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP3B.0103

SANIFORCE AODD PUMP, 3250HS.PP01ASSASSEPEOEP31

Graco SP3B.0103 SaniForce 3250, 3" HS SST Pneumatic Diaphragm Pump, Poly Center, SS Seats, EP Balls, EO Diaphragms

Graco's SaniForce 3250, 3-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 230 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 3 inch sanitary pump with flow rates up to 230 gpm (870 lpm) and pressures up to 100 psi (6.9 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side
• Optional leak sensors notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.75 in. (19 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 3250 HS

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 3/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: EPDM

• Center Section Material: Polypropylene

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: EPDM Overmold

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food and Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 290
• Maximum Air Pressure (bar): 6.9

• Maximum Air Pressure (kPa): 690
• Maximum Air Pressure (MPa): 0.69
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 190

• Maximum Flow Rate (GPM): 230
• Maximum Flow Rate (L/min): 870

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 6.9
• Maximum Fluid Pressure (kPa): 690
• Maximum Fluid Pressure (MPa): 0.69
• Maximum Fluid Pressure (psi): 100

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 6.9
• Maximum Fluid Pressure (kPa): 690
• Maximum Fluid Pressure (MPa)

GG SP3B.0013

SANIFORCE AODD PUMP, 3250HS.PPP1ASSASSPTPSEP31

SaniForce 3250, 3" HS SST Pneumatic Diaphragm Pump, Poly Center, SS Seats, PT Balls, PS Diaphragms Graco's SaniForce 3250, 3-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 230 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership. Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials. 3 inch sanitary pump with flow rates up to 230 gpm (870 lpm) and pressures up to 100 psi (6.9 bar) Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves Externally serviceable air valves deliver leading efficiency and reduce downtime. Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process Optional leak sensors notify users when processes may be compromised 316L stainless steel wetted section All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21 Pass solids up to 0.75 in. (19 mm) Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

GG SP3B.0095

SANIFORCE AODD PUMP, 32503A.PP02ASSASSEPEOEP31

Graco SP3B.0095 SaniForce 3250, 3" 3A SST Pneumatic Diaphragm Pump, Poly Center, SS Seats, EP Balls, EO Diaphragms

Graco's SaniForce 3250, 3-inch air-operated double diaphragm (AODD) pump provides a hygienic solution for customers needing to pump flow rates up to 230 gpm. It offers a quick knock-down design for easy cleaning and a low cost of ownership.

Application: Ideal for food processing and personal care markets. Common applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from the original container to smaller receptacles. Suitable to pump products like flavorings, purees, sauces and other low to medium viscosity materials.

• 3 inch sanitary pump with flow rates up to 230 gpm (870 lpm) and pressures up to 100 psi (6.9 bar)
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions
• Graco double diaphragm pumps stall under pressure preventing pump failures from clogged lines or closed valves
• Equipped with inlet and outlet tri-clamp connections, offering a quick knockdown design for easy cleanability and a swift maintenance process
• EPDM overmolded diaphragm design reduces areas that harbor bacteria while improving wear and diaphragm life with no exposed diaphragm plate on the fluid side
• Equipped with leak sensor to notify users when processes may be compromised
• 316L stainless steel wetted section
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Pass solids up to 0.75 in. (19 mm)
• Single piece manifolds reduce tri-clamps and gaskets creating a cleaner fluid path and design

• Model: SaniForce
• Series: 3250 3A

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 3/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: EPDM

• Center Section Material: Polypropylene

• Compatible Material: Edible Oil, Food, Personal Care

• Compressor Required: Yes
• Connection Type: Tri-Clamp

• Diaphragm Material: EPDM Overmold

• Fluid Section Material: 316L Stainless Steel

• For Use With: Food and Personal Care

• Hazardous Location Approval: ATEX, IECEx

• Manifold Configuration: Center Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel
• Material Certification: EN 1024:2004 Type 3.1 (Serialized)

• Maximum Air Consumption (SCFM): 290
• Maximum Air Pressure (bar): 6.9

• Maximum Air Pressure (kPa): 690
• Maximum Air Pressure (MPa): 0.69
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 190

• Maximum Flow Rate (GPM): 230
• Maximum Flow Rate (L/min): 870

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 6.9
• Maximum Fluid Pressure (kPa): 690
• Maximum Fluid Pressure (MPa): 0.69
• Maximum Fluid Pressure (psi): 100

• Maximum Fluid Operating Temperature (°C): 121
• Maximum Fluid Operating Temperature (°F): 250
• Maximum Fluid Pressure (bar): 6.9
• Maximum Fluid Pressure (kPa): 690
• Maximum Fluid Pressur
