GRACO INC. S10595

GG 195947

GG 192452

GG 192685

GG 196093

GG 192987

GG 196178

GG 196243

GG 196180

GG 196264

GG 196309

GG 196358

GG 196712

GG 196471

GG 196729

GG 197265

NOZZLE, MACHINED,1.2 MM

Graco 197265 PRO Xs Gun Fluid Nozzle, 1.2 mm Orifice Size

GG 197307

GG 197315

GG 197304

GG 197325

GG 197327

GG 197449

GG 197477

AIR CAP

Graco 197477 Air Cap

GG 197330

GG 197334

GG 197648

GG 197653

GG 197659

GG 197654

GG 197266

NOZZLE, FLUID,MACH,1.5MM

Graco 197266 PRO Xs Gun Fluid Nozzle, 1.5 mm Orifice Size

GG 197660

GG 197682

GG 198177

GG 198175

GG 198171

GG 197966

GG 197902

GG 197369

GG 197517

GG 197518

GG 197586

GG 197588

GG 198443

GG 19916-00

GG 19F710

ULTRA SPRAYER, 795 XT, STD, NA

Graco 19F710 Ultra 795 XT Standard Series Electric Airless Sprayer, Hi-Boy

The Ultra 795 XT Standard Series delivers an airless spray experience like no other. Featuring a 2.3 HP Xtreme Torque motor, Next Generation Rapid-Response Pressure Control, and the longest life pump in its class, the Ultra 795 XT Standard is sure to change the way you spray.

• Xtreme Torque Motor Technology
  • 15X more torque than traditional motors
  • 8X more magnets provide unmatched power and performance
  • 90% lower running speeds extend motors life
  • Up to 10X quieter
• Rapid-Response Pressure Control
  • Instantly responds to deliver the best finish quality
  • More performance across its full tip size range
  • Industry's largest operating pressure range (50-3,300 psi)
• Selectable Performance Modes
  • Two selectable spray modes offer unique performance levels to boost efficiency on every job
  • Bring on the savings and achieve Xtreme Control with Low Pressure Mode (50 - 2,000 psi)
  • Use High Pressure Mode for Xtreme Performance (500 - 3,300 psi)
• Endurance Vortex Piston Pump with ProConnect
  • Endurance Vortex Rod lasts 3X longer than the closest competitor
  • ProConnect Pump Removal for fast on-the-job service
  • 25% longer pump stroke for longer life before repacking
• TurboClean Cleaning System
  • Industry's fastest pump cleaning system
  • Delivers 3X faster cleaning with 1/2 the water
  • Convenient location
• WatchDog Pump Protection
  • Prevents damage by shutting off pump when it's time to refill
• Durable Filtration
  • Easy Out Filter provides easy maintenance and less clogging
• Upgrades with Modular Accessories
  • QuickReel hose management
  • SmartDisplay XT compatible with BlueLink
  • Endurance Vortex MAXLIFE EXTREME Pump
  • CrushProof Inlet Strainer
  • Rugged FlatProof tires
• Gun, Hose and Tip Included
  • Contractor PC Gun & RAC X LP 517 SwitchTip

• Model: Ultra
• Series: 795 XT
• Product Series: Standard

• Frame Configuration: Hi-Boy

• Maximum Flow Rate (GPM): 1.2

• Maximum Tip Size (in): .033

• Maximum Working Pressure (psi): 3300

• Minimum Working Pressure (psi): 50

GG 19C726

SOLOTECH ST25 PUMP, H25-MPM-FG-SS-A1-A1-0

Graco 19C726 SoloTech h25 Peristaltic Pump, 1 hp BLDC motor with gear reducer, .142-5.22 gpm, FDA Nitrile Hose, SST Sanitary Clamp Barb

With only the hose in contact with the fluid being pumped and no check valves in line, Graco's SoloTech peristaltic pumps are ideal for materials other pumps can't handle.

• Single Roller Design
  • The single roller compresses an engineered hose through a full 360 degrees of rotation. This reduces compressions, temperature, and friction, improving hose life.
• Hose Design
  • SoloTech customers routinely experience fewer failures and perform much less maintenance compared to other pump technology.
• Hose Barb Assembly
  • Easy to install or remove - no special tools needed
  • 316 SST sanitary clamp design for easy cleaning
• Pump Construction
  • Powder-coated aluminum housing reduces pump weight
  • Improved mounting flexibility with adjustable feet
• Pumps are reversible and can be used to empty lines or clear blockages

• Model: SoloTech
• Series: h25

• Barb Material: 316 Stainless Steel

• Gear Ratio: 36.75:1

• Hose Diameter (cm): 2.5
• Hose Diameter (in): 0.98
• Hose Diameter (mm): 25
• Hose Material: FDA Nitrile

• Housing Material: Powder Coated Aluminum
• Inlet Size (cm): 5.1
• Inlet Size (in): 2.0
• Inlet Size (mm): 50.8

• Inlet Thread Type: Tri-Clamp

• Lubricant Material: FDA Glycerin

• Maximum Flow Rate (GPH): 0
• Maximum Flow Rate (GPM): 0
• Maximum Flow Rate (L/h): 0
• Maximum Flow Rate (L/min): 0

• Maximum Fluid Pressure (bar): 8.6
• Maximum Fluid Pressure (kPa): 861.8
• Maximum Fluid Pressure (psi): 125

• Maximum Fluid Pressure (bar): 8.6
• Maximum Fluid Pressure (kPa): 861.8
• Maximum Fluid Pressure (psi): 125

• Maximum Operating Temperature ( degree C): 40
• Maximum Operating Temperature ( degree F): 104

• Maximum Pump Speed (RPM): 0

• Minimum Flow Rate (GPM): 0

• Minimum Pump Speed (RPM): 0

• Minimum Temperature ( degree C): -10
• Minimum Temperature ( degree F): 14

• Motor Type: Brushless DC

• Outlet Size (cm): 5.1
• Outlet Size (in): 2.0
• Outlet Size (mm): 50.8

• Overall Height (cm): 0
• Overall Height (in): 0
• Overall Height (mm): 0
• Overall Length (cm): 0
• Overall Length (in): 0
• Overall Length (mm): 0
• Overall Width (cm): 0.0
• Overall Width (in): 0
• Overall Width (mm): 0.0

• Power Rating (HP): 0
• Power Rating (kW): 0.75

GG 198601

GG 19C706

GG 19M403

THERM-O-FLOW HOSE,HEATED,15-FT,#8,3000 PSI

Graco 19M403 15 ft. (4.6 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 8 (0.401 in. /10.2 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C) Rated at 3000 psi (207 bar, 20.7 Mpa) at Temperatures up to 400 degree F (204 degree C)

GG 19B236

GG 198587

GG 19C703

GG 19D236

GG 19M401

THERM-O-FLOW HOSE, HEATED, 6-FT, #8, 3000 PSI

Graco 19M401 6 ft. (1.8 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 8 (0.401 in. /10.2 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 6
• Hose Length (m): 1.8

• Inside Diameter (in): 0.401
• Inside Diameter (mm): 10.2

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19B643

GG 19D021

GG 19D521

ULTRA SPRAYER, 490 XT, HI-BOY, NA

Graco 19D521 Ultra 490 XT Electric Airless Sprayer, Hi-Boy

The Ultra 490 XT delivers an airless spray experience like no other. Featuring a 1.3 HP Xtreme Torque motor, Next Generation Rapid-Response Pressure Control, elevated performance, and the longest life pump in its class, the Ultra 490 XT is sure to become a staple in your fleet.

• Xtreme Torque Motor Technology
  • 15X more torque than traditional motors
  • 8X more magnets provide unmatched power and performance
  • 90% lower running speeds extend motors life
  • Up to 10X quieter
• Rapid-Response Pressure Control
  • Instantly responds to deliver the best finish quality
  • More performance across its full tip size range
  • Industry's largest operating pressure range (50-3,300 psi)
• Selectable Performance Modes
  • Two selectable spray modes offer unique performance levels to boost efficiency on every job
  • Bring on the savings and achieve Xtreme Control with Low Pressure Mode (50 - 2,000 psi)
  • Use High Pressure Mode for Xtreme Performance (500 - 3,300 psi)
• Endurance Vortex Piston Pump with ProConnect
  • Endurance Vortex Rod lasts 3X longer than the closest competitor
  • ProConnect Pump Removal for fast on-the-job service
• TurboClean Cleaning System
  • Industry's fastest pump cleaning system
  • Delivers 3X faster cleaning with 1/2 the water
  • Convenient location
• WatchDog Pump Protection
  • Prevents damage by shutting off pump when it's time to refill
• Durable Filtration
  • Easy Out Filter provides easy maintenance and less clogging
• Easy Transport
  • Only 31 lbs (Stand)
• Gun, Hose and Tip Included
  • Contractor PC Gun & RAC X LP 517 SwitchTip

• Model: Ultra
• Series: 490 XT

• Frame Configuration: Hi-Boy

• Maximum Flow Rate (GPM): 0.7

• Maximum Tip Size (in): .025

• Maximum Working Pressure (psi): 3300

• Minimum Working Pressure (psi): 50

GG 19A770

GG 19M402

THERM-O-FLOW HOSE, HEATED, 10-FT, #8, 3000 PSI

Graco 19M402 10 ft. (3.0 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 8 (0.401 in. /10.2 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 10
• Hose Length (m): 3

• Inside Diameter (in): 0.401
• Inside Diameter (mm): 10.2

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M407

THERM-O-FLOW HOSE, HEATED, 20-FT, #10, 3000 PSI

Graco 19M407 20 ft. (6.1 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 10 (0.495 in. / 12.6 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 20
• Hose Length (m): 6.1

• Inside Diameter (in): 0.495
• Inside Diameter (mm): 12.6

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M408

THERM-O-FLOW HOSE, HEATED, 25-FT, #10, 3000 PSI

Graco 19M408 25 ft. (7.6 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 10 (0.495 in. / 12.6 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 25
• Hose Length (m): 7.6

• Inside Diameter (in): 0.495
• Inside Diameter (mm): 12.6

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M405

THERM-O-FLOW HOSE, HEATED, 10-FT, #10, 3000 PSI

Graco 19M405 10 ft. (3.0 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 10 (0.495 in. / 12.6 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 10
• Hose Length (m): 3

• Inside Diameter (in): 0.495
• Inside Diameter (mm): 12.6

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M409

THERM-O-FLOW HOSE, HEATED, 30-FT, #10, 3000 PSI

Graco 19M409 30 ft. (9.1 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 10 (0.495 in. / 12.6 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 30
• Hose Length (m): 9.1

• Inside Diameter (in): 0.495
• Inside Diameter (mm): 12.6

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M406

THERM-O-FLOW HOSE, HEATED, 15-FT, #10, 3000 PSI

Graco 19M406 15 ft. (4.6 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 10 (0.495 in. / 12.6 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 15
• Hose Length (m): 4.6

• Inside Diameter (in): 0.495
• Inside Diameter (mm): 12.6

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M410

THERM-O-FLOW HOSE, HEATED, 3FT #12, 3000 PSI

Graco 19M410 3 ft. (0.9 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 12 (0.617 in. / 15.7 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 3
• Hose Length (m): 0.9

• Inside Diameter (in): 0.617
• Inside Diameter (mm): 15.7

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M411

THERM-O-FLOW HOSE, HEATED, 6-FT, #12, 3000 PSI

Graco 19M411 6 ft. (1.8 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 12 (0.617 in. / 15.7 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 6
• Hose Length (m): 1.8

• Inside Diameter (in): 0.617
• Inside Diameter (mm): 15.7

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M413

THERM-O-FLOW HOSE, HEATED, 15-FT, #12, 3000 PSI

Graco 19M413 15 ft. (4.6 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 12 (0.617 in. / 15.7 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 15
• Hose Length (m): 4.6

• Inside Diameter (in): 0.617
• Inside Diameter (mm): 15.7

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M412

THERM-O-FLOW HOSE, HEATED, 10-FT, #12, 3000 PSI

Graco 19M412 10 ft. (3.0 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 12 (0.617 in. / 15.7 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 10
• Hose Length (m): 3

• Inside Diameter (in): 0.617
• Inside Diameter (mm): 15.7

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M414

THERM-O-FLOW HOSE, HEATED, 20-FT, #12, 3000 PSI

Graco 19M414 20 ft. (6.1 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 12 (0.617 in. / 15.7 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 20
• Hose Length (m): 6.1

• Inside Diameter (in): 0.617
• Inside Diameter (mm): 15.7

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M415

THERM-O-FLOW HOSE, HEATED, 25-FT, #12, 3000 PSI

Graco 19M415 25 ft. (7.6 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 12 (0.617 in. / 15.7 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 25
• Hose Length (m): 7.6

• Inside Diameter (in): 0.617
• Inside Diameter (mm): 15.7

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M417

THERM-O-FLOW HOSE, HEATED, 10-FT, #16, 3000 PSI

Graco 19M417 10 ft. (3.0 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 16 (0.867 in. / 22.0 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 10
• Hose Length (m): 3

• Inside Diameter (in): 0.867
• Inside Diameter (mm): 22.0

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M416

THERM-O-FLOW HOSE, HEATED, 6-FT, #16, 3000 PSI

Graco 19M416 6 ft. (1.8 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 16 (0.867 in. / 22.0 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 6
• Hose Length (m): 1.8

• Inside Diameter (in): 0.867
• Inside Diameter (mm): 22.0

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M419

THERM-O-FLOW HOSE, HEATED, 20-FT, #16, 3000 PSI

Graco 19M419 20 ft. (6.1 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 16 (0.867 in. / 22.0 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 20
• Hose Length (m): 6.1

• Inside Diameter (in): 0.867
• Inside Diameter (mm): 22.0

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M420

THERM-O-FLOW HOSE, HEATED, 25-FT, #16, 3000 PSI

Graco 19M420 25 ft. (7.6 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 16 (0.867 in. / 22.0 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65 degree F to 212 degree F (-54 degree C to 100 degree C)

• Hose Heating Type: Heated
• Hose Length (ft): 25
• Hose Length (m): 7.6

• Inside Diameter (in): 0.867
• Inside Diameter (mm): 22.0

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 19M422

THERM-O-FLOW HOSE, HEATED, 15-FT, #20, 3000 PSI

Graco 19M422 15 ft. (4.6 M) Insulated Stainless Steel Braided PTFE Hot Melt Heated Hose, No. 20 (1.13 in. / 28.6 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.

• Hose Heating Type: Heated
• Hose Length (ft): 15
• Hose Length (m): 4.6

• Inside Diameter (in): 1.13
• Inside Diameter (mm): 28.6

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 204
• Maximum Temperature ( degree F): 400

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

GG 19Y249

KIT, REGULATOR, PRESSURE

This item is no longer available. Please contact Graco Customer Service for replacement options.

GG 19Y269

GG 19Y301

KIT, CARTRIDGE, FUSION PC, 3 PK

Graco 19Y301 Fusion ProConnect Cartridge - 3 Pack

Combined with a Fusion PC gun or Fusion AP gun outfitted with the ProConnect Retrofit Kit, the Fusion PC cartridge delivers you a perfect rebuild in seconds. This all-in-one cartridge head replaces multiple individual parts of the fluid section with a single component. Simply replacing the cartridge completely eliminates the need for a time-consuming traditional rebuild, keeping you spraying and minimizing costly downtime.

• Sprays exactly like a Fusion AP
• Integrated check valves for cross-over containment
• 13 parts are replaced by a single ProConnect cartridge
• Spare ProConnect cartridges can replace your back-up guns

• Model: Fusion PC

GG 19Y302

GG 19Y303

GG 19Y308

KIT, CARTRIDGE, FUSION PC, 5 PK

Graco 19Y308 Fusion ProConnect Cartridge - 5 Pack

Combined with a Fusion PC gun or Fusion AP gun outfitted with the ProConnect Retrofit Kit, the Fusion PC cartridge delivers you a perfect rebuild in seconds. This all-in-one cartridge head replaces multiple individual parts of the fluid section with a single component. Simply replacing the cartridge completely eliminates the need for a time-consuming traditional rebuild, keeping you spraying and minimizing costly downtime.

• Sprays exactly like a Fusion AP
• Integrated A/B check valves all but eliminate the possibility of cross-over
• 13 parts are replaced by a single ProConnect cartridge
• Spare ProConnect cartridges can replace your back-up guns

• Model: Fusion PC

GG 19Y349

CONTRACTOR PC COMPACT GUN, LTX, PKGD

Graco 19Y349 Contractor PC Compact Airless Spray Gun with RAC X 517 SwitchTip

The Contractor PC Compact airless spray gun provides all-day comfort and control, fast on-the-job gun rebuild capability and industry-proven Graco durability. Spray longer with 25% lighter weight and 25% smaller size than the Contractor gun with a 50% lighter trigger pull force.

• Finish Jobs Faster with Less Fatigue
  • Delivers the most comfortable and lightest-weight spray experience ever
  • Lightest trigger pull force at all spray pressures
  • Lightest trigger hold force at all spray pressures
• Exclusive ProConnect Replacement Cartridge
  • 1-part, on-the-job gun rebuild
  • Needle and all wear parts in one simple part
  • Simply replace cartridge - it's like getting a brand new gun
• Easy one-finger, ambidextrous trigger lock
• EasyGlide Swivel for effortless hose management

• Model: Contractor
• Series: PC Compact

• Compatible Spray Guard: RAC X
• Compatible Spray Tip: RAC X

• Fluid Inlet Size (in): 1/4
• Fluid Inlet Thread Type: NPSM

• Gun Weight (oz): 18.7

• Includes: RAC X 517 SwitchTip, RAC X Tip Guard

• Maximum Working Pressure (psi): 3600

GG 19Y480

GG 19Y482

GG 19Y486

GG 19Y496

GG 19Y499

GG 19Y509

KIT, MUFFLER, RADIAL PISTON AIR

Graco 19Y509 Radial Piston Air Motor Muffler kit, set of 3

GG 19Y592

KIT, RETRO, 5-10 GA PAIL, RP MTR

Graco 19Y592 Radial Piston Air Motor Retrofit Kit for 5 gallon (18 L) or 10 gallon (38 L) pail agitators. Pail cover, agitator shaft and blade not included.

This kit makes it easy to replace an existing rotary vane motor on a 5 gallon (18 liter) or 10 gallon (38 L) pail agitator with a radial piston air motor.

Application: For wood (top coat, primer) and general finishing applications

• Radial piston air motor driven agitators are reliable, simple and cost-effective solutions for low to medium speed (<500 rpm), low to medium viscosity (<1000 cp) agitation applications.
• Air line lubrication not required
• Easy to maintain and service
• Pail cover, agitator shaft and blade sold separately

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• Maximum Air Inlet Pressure (bar): 5
• Maximum Air Inlet Pressure (kPa): 500
• Maximum Air Inlet Pressure (psi): 70

• Maximum Speed (RPM): 150

• Maximum Working Pressure (bar): 5
• Maximum Working Pressure (kPa): 500
• Maximum Working Pressure (psi): 70

• Motor Type: Pneumatic - Radial Piston

GG 19Z001

SOLOTECH ST10 PUMP, I10-MPM-NR-SS-A1-A1-0

Graco 19Z001 SoloTech i10 Natural Rubber Peristaltic Hose Pump with Natural Rubber Hose, 316 Stainless Steel Barb & BLDC Motor

Graco's SoloTech 10 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.

• More flow per revolution than conventional designs
• Inexpensive to maintain - no valves, seals or glands
• Pumps are reversible and can be used to empty lines or clear blockages

• Model: SoloTech
• Series: i10

• Application: Industrial

• Barb Material: Stainless Steel

• Flow Rate (GPM): 0.67

• Gear Ratio: 37.66:1

• Hose Diameter (cm): 1
• Hose Diameter (in): 0.4
• Hose Diameter (mm): 10
• Hose Material: Rubber

• Housing Material: Powder Coated Aluminum
• Inlet Size (cm): 0.95
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.5

• Inlet Thread Type: Flange

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.5

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Storage Temperature ( degree C): 40
• Maximum Storage Temperature ( degree F): 104

• Minimum Flow Rate (GPM): 0.017

• Minimum Storage Temperature ( degree C): -10
• Minimum Storage Temperature ( degree F): 14

• Motor Type: Brushless DC

• Outlet Size (cm): 9
• Outlet Size (in): 3.54
• Outlet Size (mm): 90

• Overall Height (cm): 53
• Overall Height (in): 21
• Overall Height (mm): 533
• Overall Length (cm): 41
• Overall Length (in): 16.3
• Overall Length (mm): 414
• Overall Width (cm): 33
• Overall Width (in): 13
• Overall Width (mm): 330

• Power Rating (HP): 120
• Power Rating (kW): 89.48
• Power Rating (W): 89484

• Pump Speed (RPM): 2-93

GG 19Z012

SOLOTECH ST10 PUMP, I10-LAC-CS-HS-A1-A1-0

Graco 19Z012 SoloTech i10 Low Speed Hypalon Peristaltic Hose Pump with CSM Hose, Hastelloy-C Barb & AC Motor

Graco's SoloTech 10 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.

• More flow per revolution than conventional designs
• Inexpensive to maintain - no valves, seals or glands
• Pumps are reversible and can be used to empty lines or clear blockages

• Model: SoloTech
• Series: i10

• Application: Industrial

• Barb Material: Hastelloy

• Flow Rate (GPM): 0.08

• Gear Ratio: 157.43:1

• Hose Diameter (cm): 1
• Hose Diameter (in): 0.4
• Hose Diameter (mm): 10
• Hose Material: CSM

• Housing Material: Powder Coated Aluminum
• Inlet Size (cm): 0.95
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.5

• Inlet Thread Type: Flange

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.5

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Storage Temperature ( degree C): 40
• Maximum Storage Temperature ( degree F): 104

• Minimum Flow Rate (GPM): 0.013

• Minimum Storage Temperature ( degree C): -10
• Minimum Storage Temperature ( degree F): 14

• Motor Type: Low Speed AC

• Outlet Size (cm): 9
• Outlet Size (in): 3.54
• Outlet Size (mm): 90

• Overall Height (cm): 42
• Overall Height (in): 16.7
• Overall Height (mm): 424
• Overall Length (cm): 41
• Overall Length (in): 16.2
• Overall Length (mm): 411
• Overall Width (cm): 33
• Overall Width (in): 13
• Overall Width (mm): 330

• Pump Speed (RPM): 2-11

GG 19Z003

SOLOTECH ST10 PUMP, I10-MPM-CS-PV-A1-A1-0

Graco 19Z003 SoloTech i10 Hypalon Peristaltic Hose Pump with CSM Hose, PVDF Barb & BLDC Motor

Graco's SoloTech 10 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.

• More flow per revolution than conventional designs
• Inexpensive to maintain - no valves, seals or glands
• Pumps are reversible and can be used to empty lines or clear blockages

• Model: SoloTech
• Series: i10

• Application: Industrial

• Barb Material: PVDF

• Flow Rate (GPM): 0.67

• Gear Ratio: 37.66:1

• Hose Diameter (cm): 1
• Hose Diameter (in): 0.4
• Hose Diameter (mm): 10
• Hose Material: CSM

• Housing Material: Powder Coated Aluminum
• Inlet Size (cm): 0.95
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.5

• Inlet Thread Type: Flange

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.5

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Storage Temperature ( degree C): 40
• Maximum Storage Temperature ( degree F): 104

• Minimum Flow Rate (GPM): 0.017

• Minimum Storage Temperature ( degree C): -10
• Minimum Storage Temperature ( degree F): 14

• Motor Type: Brushless DC

• Outlet Size (cm): 9
• Outlet Size (in): 3.54
• Outlet Size (mm): 90

• Overall Height (cm): 53
• Overall Height (in): 21
• Overall Height (mm): 533
• Overall Length (cm): 41
• Overall Length (in): 16.3
• Overall Length (mm): 414
• Overall Width (cm): 33
• Overall Width (in): 13
• Overall Width (mm): 330

• Power Rating (HP): 120
• Power Rating (kW): 89.48
• Power Rating (W): 89484

• Pump Speed (RPM): 2-93

GG 19Z036

SOLOTECH ST23 PUMP, I23-MPM-EP-SS-A1-A1-0

Graco 19Z036 SoloTech i23 EPDM Peristaltic Hose Pump with EPDM Hose, 316 Stainless Steel Barb & BLDC Motor

Graco's SoloTech 23 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.

• More flow per revolution than conventional designs
• Inexpensive to maintain - no valves, seals or glands
• Pumps are reversible and can be used to empty lines or clear blockages

• Model: SoloTech
• Series: i23

• Application: Industrial

• Barb Material: Stainless Steel

• Flow Rate (GPM): 4.725

• Gear Ratio: 37.66:1

• Hose Diameter (cm): 2.3
• Hose Diameter (in): 0.91
• Hose Diameter (mm): 23
• Hose Material: EPDM

• Housing Material: Powder Coated Aluminum
• Inlet Size (cm): 2.5
• Inlet Size (in): 1
• Inlet Size (mm): 25

• Inlet Thread Type: Flange

• Maximum Flow Rate (GPM): 4.5
• Maximum Flow Rate (L/min): 17

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Storage Temperature ( degree C): 40
• Maximum Storage Temperature ( degree F): 104

• Minimum Flow Rate (GPM): 0.12

• Minimum Storage Temperature ( degree C): -10
• Minimum Storage Temperature ( degree F): 14

• Motor Type: Brushless DC

• Outlet Size (cm): 10.8
• Outlet Size (in): 4.25
• Outlet Size (mm): 108

• Overall Height (cm): 58
• Overall Height (in): 22.8
• Overall Height (mm): 579
• Overall Length (cm): 50
• Overall Length (in): 19.8
• Overall Length (mm): 503
• Overall Width (cm): 44
• Overall Width (in): 17.2
• Overall Width (mm): 437

• Power Rating (HP): 800
• Power Rating (kW): 597
• Power Rating (W): 596560

• Pump Speed (RPM): 2-95

GG 19Z037

SOLOTECH ST23 PUMP, I23-MPM-EP-PV-A1-A1-0

Graco 19Z037 SoloTech i23 EPDM Peristaltic Hose Pump with EPDM Hose, PVDF Barb & BLDC Motor

Graco's SoloTech 23 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.

• More flow per revolution than conventional designs
• Inexpensive to maintain - no valves, seals or glands
• Pumps are reversible and can be used to empty lines or clear blockages

• Model: SoloTech
• Series: i23

• Application: Industrial

• Barb Material: PVDF

• Flow Rate (GPM): 4.725

• Gear Ratio: 37.66:1

• Hose Diameter (cm): 2.3
• Hose Diameter (in): 0.91
• Hose Diameter (mm): 23
• Hose Material: EPDM

• Housing Material: Powder Coated Aluminum
• Inlet Size (cm): 2.5
• Inlet Size (in): 1
• Inlet Size (mm): 25

• Inlet Thread Type: Flange

• Maximum Flow Rate (GPM): 4.5
• Maximum Flow Rate (L/min): 17

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Storage Temperature ( degree C): 40
• Maximum Storage Temperature ( degree F): 104

• Minimum Flow Rate (GPM): 0.12

• Minimum Storage Temperature ( degree C): -10
• Minimum Storage Temperature ( degree F): 14

• Motor Type: Brushless DC

• Outlet Size (cm): 10.8
• Outlet Size (in): 4.25
• Outlet Size (mm): 108

• Overall Height (cm): 58
• Overall Height (in): 22.8
• Overall Height (mm): 579
• Overall Length (cm): 50
• Overall Length (in): 19.8
• Overall Length (mm): 503
• Overall Width (cm): 44
• Overall Width (in): 17.2
• Overall Width (mm): 437

• Power Rating (HP): 800
• Power Rating (kW): 597
• Power Rating (W): 596560

• Pump Speed (RPM): 2-95

GG 19Z059

SOLOTECH ST23 PUMP, I23-HAC-EP-SS-A1-A1-0

Graco 19Z059 SoloTech i23 High Speed EPDM Peristaltic Hose Pump with EPDM Hose, 316 Stainless Steel Barb & AC Motor

Graco's SoloTech 23 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.

• More flow per revolution than conventional designs
• Inexpensive to maintain - no valves, seals or glands
• Pumps are reversible and can be used to empty lines or clear blockages

• Model: SoloTech
• Series: i23

• Application: Industrial

• Barb Material: Stainless Steel

• Flow Rate (GPM): 4.705

• Gear Ratio: 19.13:1

• Hose Diameter (cm): 2.3
• Hose Diameter (in): 0.91
• Hose Diameter (mm): 23
• Hose Material: EPDM

• Housing Material: Powder Coated Aluminum
• Inlet Size (cm): 2.5
• Inlet Size (in): 1
• Inlet Size (mm): 25

• Inlet Thread Type: Flange

• Maximum Flow Rate (GPM): 4.5
• Maximum Flow Rate (L/min): 17

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Storage Temperature ( degree C): 40
• Maximum Storage Temperature ( degree F): 104

• Minimum Flow Rate (GPM): 0.785

• Minimum Storage Temperature ( degree C): -10
• Minimum Storage Temperature ( degree F): 14

• Motor Type: High Speed AC

• Outlet Size (cm): 10.8
• Outlet Size (in): 4.25
• Outlet Size (mm): 108

• Overall Height (cm): 52
• Overall Height (in): 20.5
• Overall Height (mm): 521
• Overall Length (cm): 50
• Overall Length (in): 19.8
• Overall Length (mm): 503
• Overall Width (cm): 44
• Overall Width (in): 17.2
• Overall Width (mm): 437

• Pump Speed (RPM): 16-94

GG 19Z079

SOLOTECH ST26 PUMP, I26-HAC-EP-PV-A1-A1-0

Graco 19Z079 SoloTech i26 High Speed EPDM Peristaltic Hose Pump with EPDM Hose, PVDF Barb

Graco's SoloTech 26 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.

• More flow per revolution than conventional designs
• Inexpensive to maintain - no valves, seals or glands
• Pumps are reversible and can be used to empty lines or clear blockages

• Model: SoloTech
• Series: i26

• Application: Industrial

• Barb Material: PVDF

• Flow Rate (GPM): 10.175

• Gear Ratio: 19.50:1

• Hose Diameter (cm): 2.6
• Hose Diameter (in): 1
• Hose Diameter (mm): 26
• Hose Material: EPDM

• Housing Material: Powder Coated Aluminum
• Inlet Size (cm): 2.5
• Inlet Size (in): 1
• Inlet Size (mm): 25

• Inlet Thread Type: Flange

• Maximum Flow Rate (GPM): 9.8
• Maximum Flow Rate (L/min): 37.1

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Storage Temperature ( degree C): 40
• Maximum Storage Temperature ( degree F): 104

• Minimum Flow Rate (GPM): 1.7

• Minimum Storage Temperature ( degree C): -10
• Minimum Storage Temperature ( degree F): 14

• Motor Type: High Speed AC

• Outlet Size (cm): 2.5
• Outlet Size (in): 1
• Outlet Size (mm): 25

• Overall Height (cm): 42
• Overall Height (in): 16.5
• Overall Height (mm): 419
• Overall Length (cm): 92
• Overall Length (in): 36.1
• Overall Length (mm): 917
• Overall Width (cm): 55
• Overall Width (in): 21.7
• Overall Width (mm): 551

• Power Rating (HP): 2
• Power Rating (kW): 1.49
• Power Rating (W): 1491

• Pump Speed (RPM): 16-93

GG 19Z076

SOLOTECH ST26 PUMP, I26-HAC-BN-SS-A1-A1-0

Graco 19Z076 SoloTech i26 High Speed Buna-N Peristaltic Hose Pump with Nitrile Hose, 316 Stainless Steel Barb & AC Motor

Graco's SoloTech 26 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.

• More flow per revolution than conventional designs
• Inexpensive to maintain - no valves, seals or glands
• Pumps are reversible and can be used to empty lines or clear blockages

• Model: SoloTech
• Series: i26

• Application: Industrial

• Barb Material: Stainless Steel

• Flow Rate (GPM): 10.175

• Gear Ratio: 19.50:1

• Hose Diameter (cm): 2.6
• Hose Diameter (in): 1
• Hose Diameter (mm): 26
• Hose Material: Nitrile

• Housing Material: Powder Coated Aluminum
• Inlet Size (cm): 2.5
• Inlet Size (in): 1
• Inlet Size (mm): 25

• Inlet Thread Type: Flange

• Maximum Flow Rate (GPM): 9.8
• Maximum Flow Rate (L/min): 37.1

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Storage Temperature ( degree C): 40
• Maximum Storage Temperature ( degree F): 104

• Minimum Flow Rate (GPM): 1.7

• Minimum Storage Temperature ( degree C): -10
• Minimum Storage Temperature ( degree F): 14

• Motor Type: High Speed AC

• Outlet Size (cm): 2.5
• Outlet Size (in): 1
• Outlet Size (mm): 25

• Overall Height (cm): 42
• Overall Height (in): 16.5
• Overall Height (mm): 419
• Overall Length (cm): 92
• Overall Length (in): 36.1
• Overall Length (mm): 917
• Overall Width (cm): 55
• Overall Width (in): 21.7
• Overall Width (mm): 551

• Power Rating (HP): 2
• Power Rating (kW): 1.49
• Power Rating (W): 1491

• Pump Speed (RPM): 16-93

GG 19Z113

SOLOTECH ST30 PUMP, HAC/NR/SS/A1/A1/0/

Graco 19Z113 SoloTech i30 High Speed Natural Rubber Peristaltic Hose Pump with Natural Rubber Hose, 316 Stainless Steel Barb & AC Motor

Graco's SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.

• Pump Construction

  Cast aluminum housing reduces pump weight

  Improved mounting flexibility with adjustable feet

  • Electric Motor

    Choose between AC and Brushless DC models

    Multiple gearbox offerings to meet your exact flow rate needs

    Hazardous location motors available

    • Brushless DC Motor

      Batch dispense mode

      Wider turndown ratio allows for larger flow range

      Maintenance reminders

      • Removable Cover

        Aluminum covers with larger sight window makes it easy to access and see internal parts

        Optional leak detector kit mounts on cover

        • Hose Barb Assembly

          Easy to install or remove - no special tools needed

          Available with PVDF and SST barbs options

          Floating flange for easy installation

          • More flow per revolution than conventional designs
          • Inexpensive to maintain - no valves, seals or glands
          • Pumps are reversible and can be used to empty lines or clear blockages
          • Extended hose life - only one hose compression per revolution




          • Model: SoloTech
          • Series: i30
          • Application: Industrial
          • Barb Material: Stainless Steel
          • Flow Rate (GPM): 16
          • Gear Ratio: 19.5:1
          • Hose Diameter (cm): 3
          • Hose Diameter (in): 1.2
          • Hose Diameter (mm): 30
          • Hose Material: Rubber
          • Housing Material: Powder Coated Aluminum
          • Inlet Size (cm): 3.2
          • Inlet Size (in): 1-1/4
          • Inlet Size (mm): 32
          • Inlet Thread Type: Flange
          • Maximum Flow Rate (GPM): 15.8
          • Maximum Flow Rate (L/min): 59.8
          • Maximum Fluid Pressure (bar): 9
          • Maximum Fluid Pressure (kPa): 900
          • Maximum Fluid Pressure (psi): 125
          • Maximum Fluid Pressure (bar): 9
          • Maximum Fluid Pressure (kPa): 900
          • Maximum Fluid Pressure (psi): 125
          • Maximum Storage Temperature ( degree C): 40
          • Maximum Storage Temperature ( degree F): 104
          • Minimum Flow Rate (GPM): 2.675
          • Minimum Storage Temperature ( degree C): -10
          • Minimum Storage Temperature ( degree F): 14
          • Motor Type: High Speed AC
          • Outlet Size (cm): 12.5
          • Outlet Size (in): 4.92
          • Outlet Size (mm): 125
          • Overall Height (cm): 77
          • Overall Height (in): 30.3
          • Overall Height (mm): 770
          • Overall Length (cm): 67
          • Overall Length (in): 26.5
          • Overall Length (mm): 673
          • Overall Width (cm): 59
          • Overall Width (in): 23.3
          • Overall Width (mm): 592
          • Power Rating (HP): 3
          • Power Rating (kW): 2.24
          • Power Rating (W): 2237
          • Pump Speed (RPM): 15-91

GG 2000187

GG 2000188

GG 2000189
