GRACO INC. S10595
GRACO INC. S10595 branded products
Powerboard for E-Flo DC Advanced Motors
GG 24U939
GG 24U939
Powerboard for E-Flo DC Advanced Motors
$1,100.00
60 Quart Preset Meter - Includes Nozzle/Extension Kit - Rigid Extension - NPT
GG 24Z125
GG 24Z125
METER, PRESET, 60 QRT, RIGID, NPT
Graco 24Z125 60 Quart Preset Meter - Includes Nozzle/Extension Kit - Rigid Extension - NPT
Mechanical meters are ideal for indoor or outdoor use in all size shops, typically handling applications in automotive dealerships, fast lube centers, and service shops. The meter featured is fitted with a multiple nozzle and extension options and are capable of pumping oil up to 8 gpm (30.2 lpm).
Application: Typical applications include Automotive dealerships, Heavy-duty dealerships, Fast lube centers, Fleet service facilities, In-plant, Lube trucks, and Mining.- Preset meter automatically shuts-off flow when preset quantity has been dispensed
- Impact-resistant shroud resists against scratches and protects knob and dial from damage
- Dial and face design made simple, easy to read and set
- Built-in totalizer to manage material usage
- Inlet 1/2 in. NPT with swivel
- Measures fluid in quarts
- Features rigid extension with oil nozzle
- 5 Year Warranty
- Compatible Material: Oil, Antifreeze
- Dispense Type: Preset
- Display Type: Mechanical
- Extension Type: Rigid
- Includes: Bare Meter, Nozzle Kit
- Inlet Size (cm): 1.27
- Inlet Size (in): 1/2
- Inlet Size (mm): 12.7
- Inlet Thread Type: NPT
- Maximum Flow Rate (GPM): 8
- Maximum Flow Rate (L/min): 30
- Maximum Operating Temperature ( degree C): 70
- Maximum Operating Temperature ( degree F): 160
- Maximum Working Pressure (bar): 103.4
- Maximum Working Pressure (kPa): 10340
- Maximum Working Pressure (MPa): 10
- Maximum Working Pressure (psi): 1500
- Meter Accuracy (%): plus/minus 01%
- Meter Pressure Loss (bar): 2
- Meter Pressure Loss (kPa): 200
- Meter Pressure Loss (psi): 30
- Metering Gun Weight (kg): 1.58
- Metering Gun Weight (lb): 3.5
- Minimum Operating Temperature ( degree C): -45
- Minimum Operating Temperature ( degree F): -50
- Nozzle Type: Manual
- Outlet Size (cm): 1.27
- Outlet Size (in): 0.75
- Outlet Size (mm): 12.7
- Outlet Thread Type: ORB
- Recommended Environment: Indoor, Outdoor
$852.00
60 Gallon Preset Meter - Includes Nozzle/Extension Kit - Rigid Extension - NPT
GG 24Z128
GG 24Z128
METER, PRESET, 60 GAL, RIGID, NPT
Graco 24Z128 60 Gallon Preset Meter - Includes Nozzle/Extension Kit - Rigid Extension - NPT
Mechanical meters are ideal for indoor or outdoor use in all size shops, typically handling applications in automotive dealerships, fast lube centers, and service shops. The meter featured is fitted with a multiple nozzle and extension options and are capable of pumping oil up to 8 gpm (30.2 lpm).
Application: Typical applications include Automotive dealerships, Heavy-duty dealerships, Fast lube centers, Fleet service facilities, In-plant, Lube trucks, and Mining.- Preset meter automatically shuts-off flow when preset quantity has been dispensed
- Impact-resistant shroud resists against scratches and protects knob and dial from damage
- Dial and face design made simple, easy to read and set
- Built-in totalizer to manage material usage
- Inlet 1/2 in. NPT with swivel
- Measures fluid in gallons
- Features rigid extension with oil nozzle
- 5 Year Warranty
- Compatible Material: Oil, Antifreeze
- Dispense Type: Preset
- Display Type: Mechanical
- Extension Type: Rigid
- Includes: Bare Meter, Nozzle Kit
- Inlet Size (cm): 1.27
- Inlet Size (in): 1/2
- Inlet Size (mm): 12.7
- Inlet Thread Type: NPT
- Maximum Flow Rate (GPM): 8
- Maximum Flow Rate (L/min): 30
- Maximum Operating Temperature ( degree C): 70
- Maximum Operating Temperature ( degree F): 160
- Maximum Working Pressure (bar): 103.4
- Maximum Working Pressure (kPa): 10340
- Maximum Working Pressure (MPa): 10
- Maximum Working Pressure (psi): 1500
- Meter Accuracy (%): plus/minus 01%
- Meter Pressure Loss (bar): 2
- Meter Pressure Loss (kPa): 200
- Meter Pressure Loss (psi): 30
- Metering Gun Weight (kg): 1.58
- Metering Gun Weight (lb): 3.5
- Minimum Operating Temperature ( degree C): -45
- Minimum Operating Temperature ( degree F): -50
- Nozzle Type: Manual
- Outlet Size (cm): 1.27
- Outlet Size (in): 0.75
- Outlet Size (mm): 12.7
- Outlet Thread Type: ORB
- Recommended Environment: Indoor, Outdoor
$877.00
ProControl 1KE
GG 25B298
GG 25B298
KIT, PROCONTROL 1KE PLUS
Graco 25B298 ProControl 1KE Plus Closed Loop Fluid Pressure/Flow & Atomizing Air Control, ADCM, G3000, Air Regulator, Pressure Transducer, 2 I/P's
This ProControl 1KE Plus package makes one component (1K) fluid management simple and cost-effective. Add component(s) to customize for specific finishing needs.
- Atomizing air control helps manual or automatic paint spray guns consistently produce a high quality finish.
- Flow monitor tracks precisely how much material goes through fluid lines, so that you can improve finishing processes and reduce waste.
- Advanced Display Control Module (ADCM) gives operator instant feedback by showing comprehensive system parameters and material usage on an easy-to-read screen.
- Model: ProControl
- Series: 1KE Plus
- Control Box Voltage (V dc): 15
- Flow Control Type: Fluid Flow Control with Atomizing Air Control
- Maximum Air Inlet Pressure (bar): 7
- Maximum Air Inlet Pressure (psi): 100
- Maximum Fluid Inlet Pressure (bar): 7
- Maximum Fluid Inlet Pressure (psi): 100
- Maximum Fluid Inlet Pressure (bar): 7
- Maximum Fluid Inlet Pressure (psi): 100
- Maximum Operating Temperature ( degree C): 50
- Maximum Operating Temperature ( degree F): 120
- Maximum Working Pressure (bar): 7
- Maximum Working Pressure (MPa): 0.7
- Maximum Working Pressure (psi): 100
- Minimum Operating Temperature ( degree C): 0
- Minimum Operating Temperature ( degree F): 32
- Power Source: Order separate
$18,660.00
Stellair Automatic Air Spray Gun, Conv, 0.030 in (0.8 mm) Nozzle For General Applications w/Fluid Control Knob
GG 25F164
GG 25F164
GUN, AUTO, CONV .042
Graco 25F164 Stellair Automatic Air Spray Gun, Conventional, 0.042 in (1.1 mm) Nozzle for General Industry
Conventional air spray gun delivers stellar results as part of a robotic, reciprocator, flat line or other automated finishing system.
Application: Automatic air spray gun brings all-star performance to many industrial finishing applications, including automotive, industrial metal and plastic components, wood products and architectural structures.- Conventional is the most widely used air spray method, producing Class A, automotive finish quality.
- General industry air caps and nozzles produce a uniform, high quality spray pattern with low atomizing pressure.
- Patented spray pattern alignment and pathing tool ensures accurate and repeatable spray angle. It is easily attached and detached from the gun to keep production moving.
- Small and light size does not weigh down or wear out robot arms, reciprocators or flat line machines.
- Direct stainless steel fluid path cuts the amount of solvent needed to flush the gun, reducing VOC (volatile organic compound) emissions.
- Application: General Industry
- Applicator Type: Automatic
- Body Material: Metal
- Compatible Material: Adhesives, Ceramics, Fast-Set, High Solids, Sealants, Solventborne Paints, Stain, UV Coating, Waterborne
- Fluid Adjustment Knob: N/A
- Fluid Orifice Size (in): 0.042
- Fluid Orifice Size (mm): 1.10
- Gun Model: Stellair
- Gun Series: Automatic
- Gun Type: Conventional Gun
- Gun Weight (g): 430
- Gun Weight (lb): 1
- Manifold Type: Not Included
- Maximum Air Pressure (bar): 7
- Maximum Air Pressure (MPa): 0.7
- Maximum Air Pressure (psi): 100
- Maximum Flow Rate (oz/min): 14
- Maximum Fluid Temperature ( degree C): 49
- Maximum Fluid Temperature ( degree F): 120
- Maximum Fluid Temperature ( degree C): 49
- Maximum Fluid Temperature ( degree F): 120
- Maximum Fluid Working Pressure (bar): 21
- Maximum Fluid Working Pressure (MPa): 2.1
- Maximum Fluid Working Pressure (psi): 300
- Minimum Air Inlet Pressure (bar): 3.4
- Minimum Air Inlet Pressure (MPa): 0.34
- Minimum Air Inlet Pressure (psi): 50
- Needle Tip Material: PEEK
- Nozzle Size (in): 0.042
- Nozzle Size (mm): 1.10
- Overall Height (in): 1.9
- Overall Height (mm): 48.3
- Overall Length (in): 5.10
- Overall Length (mm): 129.5
- Overall Width (in): 1.63
- Overall Width (mm): 41.4
$1,130.00
Fine Finish Spray Tip forG40 Guns, 0.023 inch (0.584 mm) Orifice Size, 10-12 inches (250-300 mm) Fan Width
GG AAM523
GG AAM523
Fine Finish Spray Tip forG40 Guns, 0.023 inch (0.584 mm) Orifice Size, 10-12 inches (250-300 mm) Fan Width
$165.00
Fusion Cs Gun, Round Spray Pattern, 0.052in (1.3mm) Mix Chamber
GG CS02RD
GG CS02RD
FUSION CS GUN, RD0202
Graco CS02RD Fusion CS Gun, Round Spray Pattern, 0.052 in (1.3 mm) Mix Chamber
ClearShot Technology sets the Fusion CS gun apart from every other applicator. With its revolutionary technology, the Fusion CS is poised to virtually eliminate drilling of the mix chamber - increasing your spraying uptime and reducing downtime spent on maintenance. Flexible for polyurea and foam applications, this gun provides you with versatile advantages.
Application: For high output spray polyurethane foam and polyurea applications.- New technology comprised of ClearShot Liquid and disposable, non-reusable ClearShot Cartridge
- Removes foam and keeps mix chamber clear
- Saves almost an hour of maintenance time each spray day
- Easy-to-insert cartridge fits into ergonomic handle
- Variable flow - an industry first
- First plural-component gun with variable flow
- Switch from large to small spray patterns in seconds
- Gives you more maneuverability to spray in small, tight areas
- Ten different settings
- Quick-change front - simpler and cleaner
- Swap out fluid heads in seconds
- Non-stick polymer cover keeps gun head cleaner
- " Air knife" reduces material build-up
- Fast and simple change-outs put an end to lengthy interruptions and keep jobs on schedule
- Model: Fusion CS
- Series: Round
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Gender: Male
- Air Inlet Thread Type: NPT
- Compatible Material: Polyurethane, Polyurea, Spray Polyurethane Foam, No-Heat Foam
- Component A Inlet Size (cm): 1.27
- Component A Inlet Size (in): 1/2-20
- Component A Inlet Size (mm): 12.7
- Component A Inlet Thread Type: UNF
- Component B Inlet Size (cm): 1.42875
- Component B Inlet Size (in): 9/16-18
- Component B Inlet Size (mm): 14.2875
- Component B Inlet Thread Type: UNF
- Component Type: Plural-Component
- Fluid Orifice Size (cm): 0.132
- Fluid Orifice Size (in): 0.052
- Fluid Orifice Size (mm): 1.32
- For Use With: Non-Flammable Foam and Polyurea
- Gun Activation: Manual
- Gun Type: Liquid-Purge
- Gun Weight (g): 1180
- Gun Weight (kg): 1.18
- Gun Weight (lb): 2.6
- Gun Weight (oz): 41.6
- Impingement Port Size (in): 0.052
- Impingement Port Size (mm): 1.30
- Includes: Mix Chamber
- Maximum Air Inlet Pressure (bar): 9
- Maximum Air Inlet Pressure (kPa): 900
- Maximum Air Inlet Pressure (MPa): 0.9
- Maximum Air Inlet Pressure (psi): 130
- Maximum Air Pressure (bar): 9
- Maximum Air Pressure (kPa): 900
- Maximum Air Pressure (MPa): 0.9
- Maximum Air Pressure (psi): 130
- Maximum Flow Rate (kg/min): 11.3
- Maximum Flow Rate (lb/min): 25
- Maximum Flow Rate @ PSI (lb/min): 25
- Maximum Fluid Pressure (bar): 241
- Maximum Fluid Pressure (kPa): 24100
- Maximum Fluid Pressure (MPa): 24.1
- Maximum Fluid Pressure (psi): 3500
- Maximum Fluid Temperature ( degree C): 93
- Maximum Fluid Temperature ( degree F): 200
- Maximum Fluid Pressure (bar): 241
- Maximum Fluid Pressure (kPa): 24100
- Maximum Fluid Pressure (MPa): 24.1
$4,020.00
