GRACO INC. S10595

GG 286113

RAC 5 TIP, SPRAY

Graco 286113 RAC 5 SwitchTip, 113

The Reverse-A-Clean (RAC) 113 RAC 5 SwitchTip is designed for narrower surfaces. The 113 SwitchTip has a 0.013 inch orifice and produces a 2 to 4 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 10.2
• Maximum Fan Width (in): 2
• Maximum Fan Width (mm): 102

• Maximum Flow Rate (GPM): 0.18
• Maximum Flow Rate (L/min): 0.68

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 2
• Minimum Fan Width (mm): 51

• Orifice Diameter (in): 0.013

• Pattern Size (in): 2 to 4
• Pattern Size (mm): 50.8 to 101.6

GG 286213

RAC 5 TIP, SPRAY

Graco 286213 RAC 5 SwitchTip, 213

The Reverse-A-Clean (RAC) 213 RAC 5 SwitchTip is designed for narrower surfaces. The 213 SwitchTip has a 0.013 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 15.2
  • Maximum Fan Width (in): 4
  • Maximum Fan Width (mm): 152
  • Maximum Flow Rate (GPM): 0.18
  • Maximum Flow Rate (L/min): 0.68
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 4
  • Minimum Fan Width (mm): 102
  • Orifice Diameter (in): 0.013

GG 279022

KING SPRAYER, CONTRACTOR, 70:1, B150

Graco 279022 Contractor King 70:1 Air Powered Airless Sprayer, Big 150 (2-F Gun)

Introducing the newest member of the King family The Contractor King 70:1. Designed around single-person mobility and high performance, this affordable line of air-powered sprayers is the perfect addition to every Contractors fleet.

• Proven King quality with Anti-icing technology

  Field-proven design virtually eliminates icing to keep you spraying

  Durable aluminum, steel and composite construction for years of service

  Delivers superior finish with no pulsation, even with multiple guns

  Simple design for easy serviceability

  Oversized porting for maximum air flow

• Easy to move and transport

  Nearly 38 kg lighter than comparable models for easy, one-person handling

  Chrome-plated, welded-steel frame for years of service

  Integrated lifting points for easy positioning on any jobsite

  Flat proof tires resist jobsite debris for maximum convenience

• Simple maintenance with proven design and performance

  QuickChange Endurance pump, for quick and for easy on-the-job pump removal and maintenance

  Chromex Rod and Stainless Steel cylinder for maximum life and performance

  Fleet-friendly design uses the same wear parts as your other King sprayers

  Xtreme Seal UHMWPE & Leather packings for ultimate durability with most materials

  QuickAccess intake valve for easy access to lower ball check

• Big 150 package includes:

  2-Finger Silver Plus HP Gun

  XHD 417 and XHD 519 SwitchTips with XHD guard

  1/4x 1.8m Extreme Duty Airless whip hose

  3x 3/8x 15m Extreme Duty Airless hose (45m in total)

• Big 150 Package Includes:

  Silver Plus Gun OR Silver Plus HP Gun (2 Finger Model)

  XHD 417, XHD 519 SwitchTips and Guard

  1/4 in x 6 ft Extreme Duty Airless Whip Hose

  3 - 3/8 in x 50 ft Extreme Duty Airless Hose (150 ft total)

• Model: Contractor King
• Series: 70:1
• Product Series: Big 150

• Approved for Hazardous Locations: Yes

• Gun Included: 1
• Gun Model: Silver Plus HP Gun

• Includes: Silver Plus HP Airless Spray Gun, 3 - 3/8 in x 50 ft Xtreme-Duty Airless Hose, 1/4 in x 6 ft Xtreme-Duty Airless Whip Hose, XHD RAC 417 SwitchTip, XHD RAC 519 SwitchTip, XHD RAC Tip Guard, Hose Fittings

• Maximum Flow Rate (GPM): 2.9

• Maximum Working Pressure (psi): 7250

• Package Options: Big 150
• Package Pressure Ratio (Motor/Lower): 70:1 XL6500 motor/180cc Lower

• Pump Ratio: 70:1 (7250 psi)
• Pump Type: Endurance

GG 282404

XP SYSTEM, 4:1, 220/54, BF, CH, HS

Graco 282404 XP50 Hazardous Location Spray Package, Cart, 4:1 Mix Ratio, Hopper, Solvent Pump, Heaters, XTR Gun, 240V

Two-component spraying made easy and affordable. Graco XP50 Plural-Component Sprayers are designed to pump, mix and atomize medium to high solid coatings with superior results. When you upgrade from hand mixing, youll find that the XP provides excellent return on investment, by reducing material waste and by using less clean-up solvent. Flexible options for mix ratio, pressure and flow rate - choose the right system for the application. If you occasionally change materials, the Graco XP Sprayers are the right choice. That's because you can change the ratio by simply changing out one or two pump lowers. Available in 1:1, 1.5:1, 2:1, 2.5:1, 3:1 and 4:1 mix ratios.

• Reduced material waste
• No more throwing away unused mixed material at the end of the day
• Save money by using less clean-up solvent
• Easy to operate - minimal training required
• Reduced maintenance costs
• Rated for 5000 psi (345 bar) to handle viscous materials and long hose lengths

• Series: XP50

• Air Inlet Size (in): 3/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPSM

• Applicator Type: Automatic Airless, Manual Airless

• Compatible Material: Protective Coatings, Primer, Epoxies, Polyurethane, Two-Component Coating, Solvents

• Component Type: Plural-Component
• Configuration: Cart Mount with 7 gallon (26.5 Liter) Hopper

• Fluid Inlet Size (in): 1-1/4
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPSM

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Flush Type: Solvent

• Hose Length (ft): 35
• Hose Length (m): 10.7

• Includes: Cart, Material Hoses, XTR-5 Gun, NXT 6500 Air Motor, Hoppers, IS Fluid Heater, Flush Pump

• Material Application: Coatings, Paints, Primers

• Maximum Air Consumption (SCFM): 60 scfm/gpm at 100 psi
• Maximum Air Inlet Pressure (bar): 12.07
• Maximum Air Inlet Pressure (kPa): 1207
• Maximum Air Inlet Pressure (MPa): 1.21
• Maximum Air Inlet Pressure (psi): 175

• Maximum Cycle Rate (CPM): 40

• Maximum Flow Rate (cc/min): 10970

• Maximum Flow Rate (GPM): 2.9
• Maximum Flow Rate (L/min): 10.97

• Maximum Fluid Temperature ( degree C): 71
• Maximum Fluid Temperature ( degree F): 160
• Maximum Fluid Viscosity (cP): 20000

• Maximum Fluid Temperature ( degree C): 71
• Maximum Fluid Temperature ( degree F): 160
• Maximum Fluid Viscosity (cP): 20000

• Maximum Hose Length (ft): 300
• Maximum Hose Length (m): 91.4

• Maximum Operating Temperature ( degree C): 54
• Maximum Operating Temperature ( degree F): 130

• Maximum Spray Pressure (bar): 344

• Maximum Spray Pressure (kPa): 34400
• Maximum Spray Pressure (MPa): 34
• Maximum Spray Pressure (psi): 5000

• Maximum Working Pressure (bar): 331
• Maximum Working Pressure (kPa): 33100
• Maximum Working Pressure (MPa): 33
• Maximum Working Pressure (psi): 4800
• Measuring Type: Fixed Mechanical Positive Displacement

• Minimum Flu

GG 277355

GG 277366

GG 286215

RAC 5 TIP, SPRAY

Graco 286215 RAC 5 SwitchTip, 215

The Reverse-A-Clean (RAC) 215 RAC 5 SwitchTip is designed for narrower surfaces. The 215 SwitchTip has a 0.015 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 15.2
  • Maximum Fan Width (in): 4
  • Maximum Fan Width (mm): 152
  • Maximum Flow Rate (GPM): 0.24
  • Maximum Flow Rate (L/min): 0.91
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 4
  • Minimum Fan Width (mm): 102
  • Orifice Diameter (in): 0.015

GG 286219

RAC 5 TIP, SPRAY

Graco 286219 RAC 5 SwitchTip, 219

The Reverse-A-Clean (RAC) 219 RAC 5 SwitchTip is designed for narrower surfaces and thick materials. The 219 SwitchTip has a 0.019 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.38
• Maximum Flow Rate (L/min): 1.44

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.019

• Pattern Size (in): 4 to 6
• Pattern Size (mm): 101.6 to 152.4

GG 286217

RAC 5 TIP, SPRAY

Graco 286217 RAC 5 SwitchTip, 217

The Reverse-A-Clean (RAC) 217 RAC 5 SwitchTip is designed for narrower surfaces. The 217 SwitchTip has a 0.017 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 15.2
  • Maximum Fan Width (in): 4
  • Maximum Fan Width (mm): 152
  • Maximum Flow Rate (GPM): 0.31
  • Maximum Flow Rate (L/min): 1.17
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 4
  • Minimum Fan Width (mm): 102
  • Orifice Diameter (in): 0.017

GG 286221

RAC 5 TIP, SPRAY

Graco 286221 RAC 5 SwitchTip, 221

The Reverse-A-Clean (RAC) 221 RAC 5 SwitchTip is designed for narrower surfaces and thick materials. The 221 SwitchTip has a 0.021 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.021

• Pattern Size (in): 4 to 6
• Pattern Size (mm): 101.6 to 152.4

GG 286223

RAC 5 TIP, SPRAY

Graco 286223 RAC 5 SwitchTip, 223

The Reverse-A-Clean (RAC) 223 RAC 5 SwitchTip is designed for narrower surfaces and thick materials. The 323 SwitchTip has a 0.023 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.57
• Maximum Flow Rate (L/min): 2.16

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.023

• Pattern Size (in): 4 to 6
• Pattern Size (mm): 101.6 to 152.4

GG 286309

RAC 5 TIP, SPRAY

Graco 286309 RAC 5 SwitchTip, 309

The Reverse-A-Clean (RAC) 309 RAC 5 SwitchTip is designed for narrow surfaces and thinner materials. The 309 SwitchTip has a 0.009 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Clear Coating, Lacquer, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 20.3
  • Maximum Fan Width (in): 6
  • Maximum Fan Width (mm): 203
  • Maximum Flow Rate (GPM): 0.09
  • Maximum Flow Rate (L/min): 0.34
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 6
  • Minimum Fan Width (mm): 152
  • Orifice Diameter (in): 0.009

GG 286235

RAC 5 TIP, SPRAY

Graco 286235 RAC 5 SwitchTip, 235

The Reverse-A-Clean (RAC) 235 RAC 5 SwitchTip is designed for narrower surfaces and thicker materials. The 235 SwitchTip has a 0.035 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 1.31
• Maximum Flow Rate (L/min): 4.96

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.035

• Pattern Size (in): 4 to 6
• Pattern Size (mm): 101.6 to 152.4

GG 286313

RAC 5 TIP, SPRAY

Graco 286313 RAC 5 SwitchTip, 313

The Reverse-A-Clean (RAC) 313 RAC 5 SwitchTip is designed for narrow surfaces. The 313 SwitchTip has a 0.013 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.18
• Maximum Flow Rate (L/min): 0.68

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.013

GG 286311

RAC 5 TIP, SPRAY

Graco 286311 RAC 5 SwitchTip, 311

The Reverse-A-Clean (RAC) 311 RAC 5 SwitchTip is designed for narrow surfaces and thin materials. The 311 SwitchTip has a 0.011 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Clear Coating, Lacquer, Oil-Based Stain

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.12
• Maximum Flow Rate (L/min): 0.45

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.011

GG 286317

RAC 5 TIP, SPRAY

Graco 286317 RAC 5 SwitchTip, 317

The Reverse-A-Clean (RAC) 317 RAC 5 SwitchTip is designed for narrow surfaces. The 317 SwitchTip has a 0.017 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 20.3
  • Maximum Fan Width (in): 6
  • Maximum Fan Width (mm): 203
  • Maximum Flow Rate (GPM): 0.31
  • Maximum Flow Rate (L/min): 1.17
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 6
  • Minimum Fan Width (mm): 152
  • Orifice Diameter (in): 0.017

GG 286315

RAC 5 TIP, SPRAY

Graco 286315 RAC 5 SwitchTip, 315

The Reverse-A-Clean (RAC) 315 RAC 5 SwitchTip is designed for narrow surfaces. The 315 SwitchTip has a 0.015 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.015

GG 286321

RAC 5 TIP, SPRAY

Graco 286321 RAC 5 SwitchTip, 321

The Reverse-A-Clean (RAC) 321 RAC 5 SwitchTip is designed for narrow surfaces and thick materials. The 321 SwitchTip has a 0.021 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 20.3
  • Maximum Fan Width (in): 6
  • Maximum Fan Width (mm): 203
  • Maximum Flow Rate (GPM): 0.47
  • Maximum Flow Rate (L/min): 1.78
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 6
  • Minimum Fan Width (mm): 152
  • Orifice Diameter (in): 0.021

GG 286319

RAC 5 TIP, SPRAY

Graco 286319 RAC 5 SwitchTip, 319

The Reverse-A-Clean (RAC) 319 RAC 5 SwitchTip is designed for narrow surfaces and thick materials. The 319 SwitchTip has a 0.019 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 20.3
  • Maximum Fan Width (in): 6
  • Maximum Fan Width (mm): 203
  • Maximum Flow Rate (GPM): 0.38
  • Maximum Flow Rate (L/min): 1.44
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 6
  • Minimum Fan Width (mm): 152
  • Orifice Diameter (in): 0.019

GG 286323

RAC 5 TIP, SPRAY

Graco 286323 RAC 5 SwitchTip, 323

The Reverse-A-Clean (RAC) 323 RAC 5 SwitchTip is designed for narrow surfaces and thick materials. The 323 SwitchTip has a 0.023 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.57
• Maximum Flow Rate (L/min): 2.16

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.023

• Pattern Size (in): 6 to 8
• Pattern Size (mm): 152.4 to 203.2

GG 286327

RAC 5 TIP, SPRAY

Graco 286327 RAC 5 SwitchTip, 327

The Reverse-A-Clean (RAC) 327 RAC 5 SwitchTip is designed for narrow surfaces and thicker materials. The 327 SwitchTip has a 0.027 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.77
• Maximum Flow Rate (L/min): 2.91

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.027

• Pattern Size (in): 6 to 8
• Pattern Size (mm): 152.4 to 203.2

GG 286325

RAC 5 TIP, SPRAY

Graco 286325 RAC 5 SwitchTip, 325

The Reverse-A-Clean (RAC) 325 RAC 5 SwitchTip is designed for narrow surfaces and thicker materials. The 325 SwitchTip has a 0.025 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.54

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.025

• Pattern Size (in): 6 to 8
• Pattern Size (mm): 152.4 to 203.2

GG 286409

RAC 5 TIP, SPRAY

Graco 286409 RAC 5 SwitchTip, 409

The Reverse-A-Clean (RAC) 409 RAC 5 SwitchTip produces an 8 to 10 inch fan and has a 0.009 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.09
• Maximum Flow Rate (L/min): 0.34

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.009

• Pattern Size (in): 8 to 10
• Pattern Size (mm): 203.2 to 254

GG 286331

RAC 5 TIP, SPRAY

Graco 286331 RAC 5 SwitchTip, 331

The Reverse-A-Clean (RAC) 331 RAC 5 SwitchTip is designed for narrow surfaces and thicker materials. The 331 SwitchTip has a 0.031 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 20.3
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 1.03
• Maximum Flow Rate (L/min): 3.90

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.031

• Pattern Size (in): 6 to 8
• Pattern Size (mm): 152.4 to 203.2

GG 286411

RAC 5 TIP, SPRAY

Graco 286411 RAC 5 SwitchTip, 411

The Reverse-A-Clean (RAC) 411 RAC 5 SwitchTip produces an 8 to 10 inch fan and has a 0.011 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Clear Coating, Lacquer, Oil-Based Stain

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.12
• Maximum Flow Rate (L/min): 0.45

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.011

GG 286413

RAC 5 TIP, SPRAY

Graco 286413 RAC 5 SwitchTip, 413

The Reverse-A-Clean (RAC) 413 RAC 5 SwitchTip produces an 8 to 10 inch fan and has a 0.013 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.18
• Maximum Flow Rate (L/min): 0.68

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.013

GG 286415

RAC 5 TIP, SPRAY

Graco 286415 RAC 5 SwitchTip, 415

The Reverse-A-Clean (RAC) 415 RAC 5 SwitchTip produces an 8 to 10 inch fan and has a 0.015 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.015

GG 286417

RAC 5 TIP, SPRAY

Graco 286417 RAC 5 SwitchTip, 417

The Reverse-A-Clean (RAC) 417 RAC 5 SwitchTip produces an 8 to 10 inch fan and has a 0.017 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.31
• Maximum Flow Rate (L/min): 1.17

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.017

GG 286421

RAC 5 TIP, SPRAY

Graco 286421 RAC 5 SwitchTip, 421

The Reverse-A-Clean (RAC) 421 RAC 5 SwitchTip produces an 8 to 10 inch fan and has a 0.021 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 25.4
  • Maximum Fan Width (in): 8
  • Maximum Fan Width (mm): 254
  • Maximum Flow Rate (GPM): 0.47
  • Maximum Flow Rate (L/min): 1.78
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 8
  • Minimum Fan Width (mm): 203
  • Orifice Diameter (in): 0.021

GG 286419

RAC 5 TIP, SPRAY

Graco 286419 RAC 5 SwitchTip, 419

The Reverse-A-Clean (RAC) 419 RAC 5 SwitchTip produces an 8 to 10 inch fan and has a 0.019 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 25.4
  • Maximum Fan Width (in): 8
  • Maximum Fan Width (mm): 254
  • Maximum Flow Rate (GPM): 0.38
  • Maximum Flow Rate (L/min): 1.44
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 8
  • Minimum Fan Width (mm): 203
  • Orifice Diameter (in): 0.019

GG EC5941

E-FLO PUMP, DC, 3000CC, SEALED

Graco EC5941 E-Flo DC 4-Ball Electric Circulation Pump, 3000cc, 2x2 HP, Advanced, ATEX/FM/IECEx, Sealed, Ultralife Rod/Cylinder, Tri-Clamp, Stand

E-Flo DC (Dual Control) electric pumps are up to five times more efficient than pneumatic pumps, lowering energy bills and saving money. Unique 4-ball lower minimizes pulsation while increasing flow rates. Advanced control module improves performance with Intelligent Paint Kitchen (IPK) compatibility.

• Sealed lower has longer maintenance cycles, plus it can be used for every pumping application in your mix room, including catalyzed coatings
• Minimal pulsation at changeover provides a more consistent finish
• Electric motor eliminates icing – giving you smoother pump operation and better finished product

• Model: E-Flo
• Series: DC 4-Ball

• Application: Circulation

• Compatible Material: Solvent borne, High Solids, Xirallic, Metallics, Varnish, CARC

• Fluid Inlet Size (in): 1-1/2
• Fluid Inlet Size (mm): 38.1

• Fluid Outlet Size (in): 1-1/2
• Fluid Outlet Size (mm): 38.1
• Fluid Section Type: Sealed

• Includes: Advanced Control Input, Stand

• Input Voltage (V ac): 240

• Material: Stainless Steel

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 15.9
• Maximum Flow Rate (L/min): 60.19

• Maximum Input Amperage (A): 20

• Maximum Operating Temperature (°C): 40
• Maximum Operating Temperature (°F): 104

• Maximum Working Pressure (bar): 27.6
• Maximum Working Pressure (kPa): 2760
• Maximum Working Pressure (MPa): 2.8
• Maximum Working Pressure (psi): 400

• Minimum Operating Temperature (°C): 0
• Minimum Operating Temperature (°F): 32

• Motor Type: AC

• Portable: Non-Portable

• Power Rating (HP): 4

GG EC3D50

E-FLO PUMP, 2HP, 1500, ADV, NPT, OPN

Graco EC3D50 E-Flo DC 4-Ball Electric Circulation Pump, 1500cc, 2 HP, 480V, Advanced, ATEX/FM/IECEx, Open Wet Cup Lower, Ultralife Rod/Cylinder, NPT

E-Flo DC (Dual Control) electric pumps are up to five times more efficient than pneumatic pumps, lowering energy bills and saving money. Unique 4-ball lower minimizes pulsation while increasing flow rates. Advanced control module improves performance with Intelligent Paint Kitchen (IPK) compatibility.

• Advanced model lets you easily connect and manage multiple pumps with a single control module.
• Minimal pulsation at changeover provides a more consistent finish.
• Open wet cup lower includes Ultralife ceramic coating for improved durability.
• Installation simply requires 220 volt single phase power. No VFD (variable frequency drive) needed.
• Meets requirements of these approval agencies: ATEX, FM, IECEx

• Fluid Inlet Size (in): 1.5
• Fluid Inlet Size (mm): 38.1
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT
• Fluid Inlet Type: NPT

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 2.54
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: 4-Ball, Open Wet Cup

• Includes: Advanced Control Input, No Mounting

• Maximum Continuous Cycle Rate (CPM): 12

• Maximum Operating Temperature ( degree C): 40
• Maximum Operating Temperature ( degree F): 104

• Maximum Voltage (V ac): 480

• Maximum Working Pressure (bar): 26
• Maximum Working Pressure (kPa): 2600
• Maximum Working Pressure (MPa): 2.6
• Maximum Working Pressure (psi): 377

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Minimum Voltage (V ac): 380

• Overall Depth (cm): 50.5
• Overall Depth (in): 19.88
• Overall Depth (mm): 505

• Overall Height (cm): 115.6
• Overall Height (in): 45.51
• Overall Height (mm): 1156
• Overall Width (cm): 43.2
• Overall Width (in): 17
• Overall Width (mm): 432

GG EKE005

GG EC6J41

E-FLO PUMP, DC, X2, 4000CC, SEALED

Graco EC6J41 E-Flo DC 4-Ball Electric Circulation Pump, 4000cc, 2 x 2 HP, 480V, Advanced, ATEX/FM/IECEx, Sealed Lower, Ultralife Rod/Cylinder, Tri-Clamp, Stand

E-Flo DC (Dual Control) electric pumps are up to five times more efficient than pneumatic pumps, lowering energy bills and saving money. Unique 4-ball lower minimizes pulsation while increasing flow rates. Advanced control module improves performance with Intelligent Paint Kitchen (IPK) compatibility.

• Advanced model lets you easily connect and manage multiple pumps with a single control module.
• Minimal pulsation at changeover provides a more consistent finish.
• Sealed lower does not require throat seal liquid (TSL), reducing maintenance costs and unplanned downtime.
• Lower operates independently, allowing the pump to adjust to varying pressure and flow rate demands thousands of times per second.
• Pump can run alone to keep production running, if lower maintenance is required.

• Fluid Inlet Size (in): 1.5
• Fluid Inlet Size (mm): 38.1
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: Tri-Clamp
• Fluid Inlet Type: Tri-Clamp

• Fluid Outlet Size (in): 1.5
• Fluid Outlet Size (mm): 3.81
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: Tri-Clamp
• Fluid Section Type: 4-Ball, Sealed Bellows

• Includes: Advanced Control Input, Stand

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Operating Temperature ( degree C): 40
• Maximum Operating Temperature ( degree F): 104

• Maximum Voltage (V ac): 480

• Maximum Working Pressure (bar): 19
• Maximum Working Pressure (kPa): 1900
• Maximum Working Pressure (MPa): 1.9
• Maximum Working Pressure (psi): 276

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Minimum Voltage (V ac): 380

• Overall Depth (cm): 46.7
• Overall Depth (in): 18.39
• Overall Depth (mm): 467

• Overall Height (cm): 151.6
• Overall Height (in): 59.69
• Overall Height (mm): 1516
• Overall Width (cm): 72.4
• Overall Width (in): 28.5
• Overall Width (mm): 724

GG EKH003

GG EFR2AJRC

EFR SYSTEM, 240V, ADM, 50, 100, CS

Graco EFR2AJRC 2:1 EFR Metering System 240 Volt with 50cc Low Volume and 100cc High Volume Z pumps Carbon Steel Manifold

The Graco Electric Fixed Ratio (EFR) system is a meter, mix and dispense system for two component sealant and adhesive delivery. Ideal for applications requiring precision dispense, the EFR provides superior control over material and dispensing of gaskets, beads, shots and potting applications. Trust in the EFR, which is accurate, versatile and easy to use.

• Model: EFR

GG EKH004

GG EKN003

GG EKH005

GG EKN004

GG EKN005

GG EM0011

KIT, MOTOR,1HP, STANDARD

Graco EM0011 E-Flo DC Motor, 1 hp, Basic Controls, 220V, ATEX/FM/IECEX

GG EM0012

KIT, MOTOR,1HP, ADVANCED

Graco EM0012 E-Flo DC Motor, 1 hp, Advanced Controls, 220V, ATEX/FM/IECEX

GG EM1021

GG EM1022

KIT,MOTOR,2HP,ADVANCED

Graco EM1022 E-Flo DC Motor, 2 hp, Advanced Controls, 340-480V, ATEX/FM/IECEX

GG EM1025

KIT,MOTOR,X2,2HP,ADVANCED

GG EMC1382

GG EMC1384

GG EMC4163

E-FLO SP SUPPLY UNIT, D60, CM100SM, SP, 240V, ADM

Graco EMC4163 E-Flo SP 20L 3 in (7.6 cm) Supply, 100cc MaxLife Check-Mate Stainless Steel, Flat Stainless Steel Platen, Single PTFE Wiper, 240V

The E-Flo SP electric supply pump is designed for industrial and automotive sealant and adhesive application. This advanced pump will drastically increase efficiency, improve system control capabilities, optimize process performance, and provide critical performance data.

• Improve process and system performance
• Advanced material control
• Significant energy savings
• Extremely quiet motor
• Prevent downtime
• Lower maintenance costs

• Display Type: ADM
• Drum Size (Gal): 5
• Drum Size (L): 20

• Maximum Working Pressure (psi): 6000

• Platen Material: Stainless Steel
• Platen Size (Gal): 5
• Platen Size (L): 20
• Platen Style: Single Wiper

• Pump Material: Stainless Steel Maxlife

• Pump Size (cc): 100
• Pump Type: Check-Mate

• Ram Post Diameter (in): 3

GG EMC8163

E-FLO SP SUPPLY UNIT, D60, CM200SM, SP, 240V, ADM

Graco EMC8163 E-Flo SP 20L 3 in (7.6 cm) Supply, 200cc MaxLife Check-Mate Stainless Steel, Flat Stainless Steel Platen, Single PTFE Wiper, 240V

The E-Flo SP electric supply pump is designed for industrial and automotive sealant and adhesive application. This advanced pump will drastically increase efficiency, improve system control capabilities, optimize process performance, and provide critical performance data.

• Improve process and system performance
• Advanced material control
• Significant energy savings
• Extremely quiet motor
• Prevent downtime
• Lower maintenance costs

• Display Type: ADM
• Drum Size (Gal): 5
• Drum Size (L): 20

• Maximum Working Pressure (psi): 3900

• Platen Material: Stainless Steel
• Platen Size (Gal): 5
• Platen Size (L): 20
• Platen Style: Single Wiper

• Pump Material: Stainless Steel Maxlife

• Pump Size (cc): 200
• Pump Type: Check-Mate

• Ram Post Diameter (in): 3

GG EMC7273

E-FLO SP SUPPLY UNIT,D200,CM200SS,PT,240V,ADM

Graco EMC7273 E-Flo SP 200L 3 in. Supply, 200cc Severe Duty Check-Mate Stainless Steel, PTFE Coated Platen, Dual EPDM Wiper, 240V

GG EMC8164

E-FLO SP SUPPLY UNIT, D60, CM200SM, SP, 480V, ADM

Graco EMC8164 E-Flo SP 20L 3 in. Supply, 200cc MaxLife Check-Mate Stainless Steel, Flat Stainless Steel Platen, Single PTFE Wiper, 480V

The E-Flo SP electric supply pump is designed for industrial and automotive sealant and adhesive application. This advanced pump will drastically increase efficiency, improve system control capabilities, optimize process performance, and provide critical performance data.

• Improve process and system performance
• Advanced material control
• Significant energy savings
• Extremely quiet motor
• Prevent downtime
• Lower maintenance costs

• Display Type: ADM
• Drum Size (Gal): 5
• Drum Size (L): 20

• Maximum Working Pressure (psi): 3900

• Platen Material: Stainless Steel
• Platen Size (Gal): 5
• Platen Size (L): 20
• Platen Style: Single Wiper

• Pump Material: Stainless Steel Maxlife

• Pump Size (cc): 200
• Pump Type: Check-Mate

• Ram Post Diameter (in): 3

GG EQ1846

COUPLER, AIR 3/4 QD (F), 3/4 NPT (M), BR

• Connection Type: Quick-Disconnect, Threaded

GG EQ5179

GG F0200043

GG ES7D61

GG F0200104

GG FA1111

SANIFORCE AODD PUMP, 1040FG-PA01AS13SSPTPTPT21

Graco FA1111 SaniForce 1040 S/S AODD Pump with 316 S/S Seats & PTFE O-Rings, Balls & Diaphragms

Graco's SaniForce 1040 air-operated double diaphragm sanitary pumps have one of the best, most durable, lube-free air valves in the industry. Ideal for applications requiring high flow rates and portability, Graco's dependable diaphragm pumps offer a wide range of food-grade elastomers including Santoprene, PTFE and overmolded EPDM/PTFE.

• 1.5 in (38 mm) Tri-clamp connection
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)
• High volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from original container to smaller receptacles - up to 10,000 cps
• Suitable to pump such products as: concentrated fruit juices, sauces, pastes, starches, wine, food-grade oil, jams and jellies

• Model: SaniForce
• Series: 1040

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: PTFE

• Center Section Material: Aluminum

• Compatible Material: Edible Oil, Food and Personal Care

• Connection Type: Tri-Clamp

• Diaphragm Compatible Material: PTFE
• Diaphragm Material: PTFE

• Fluid Inlet Size (cm): 3.81
• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 38.1

• Fluid Outlet Size (cm): 3.81
• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 38.1
• Fluid Section Material: 316L Stainless Steel

• For Use With: Food and Personal Care

• Manifold Configuration: End Port
• Manifold O-Ring Material: PTFE
• Material: Stainless Steel

• Maximum Air Consumption (SCFM): 50
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 256

• Maximum Flow Rate (GPM): 41
• Maximum Flow Rate (L/min): 151

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 0.3175
• Maximum Solid Size (in): 0.125
• Maximum Solid Size (mm): 3.175

• Power Source: Pneumatic

• Pump Ratio: 1:1

GG FAA040094

GG FAA040072

GG FAA040096

GG FAA040132

GG FAA040308

GG FAA040309

GG FAA040310

GG FAA040512

GG FAA040514

GG FAA040513

GG FAA040586

GG FAA040565

GG FAA060015

GG FD2111

SANIFORCE AODD PUMP, 1590FG-PS01AS13SSPTPTPT21

Graco FD2111 SaniForce 1590 S/S AODD Pump with Sanitary Clamp Connection, S/S Center Section & Seats, PTFE O-Rings, Balls & Diaphragms

Graco's SaniForce 1590 air-operated double diaphragm sanitary pumps have one of the best, most durable, lube-free air valves in the industry. Ideal for applications requiring high flow rates and portability, Graco's dependable diaphragm pumps offer a wide range of food-grade elastomers including Santoprene, PTFE and overmolded EPDM/PTFE.

• SaniForce 1590 Double Diaphragm Pump

  2 in (51 mm) tri-clamp connection

  90 gpm (341 lpm) in a compact, portable size

  Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)

  All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21

  High volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from original container to smaller receptacles - up to 15,000 cps

  Suitable to pump such products as: concentrated fruit juices, sauces, pastes, starches, wine, food-grade oil, jams and jellies

  • Patented, lube-free air valve

    Three-way pilot valve for no-stick operation

    316 series stainless steel rod design for long life and corrosion resistance

    1040, 1590 and 2150 SaniForce pumps use common center sections

    100% externally serviceable air valve

    • PTFE/EPDM Overmolded Diaphragms

      Available on the SaniForce 1040, 1590, 2150 and SaniForce HS 1590 and 3150

      Improve wear and diaphragm life with no exposed diaphragm plate on the fluid side

      Longer diaphragm life in abrasive applications that still require PTFE




      • Model: SaniForce
      • Series: 1590
      • Air Exhaust Port Size (in): 3/4
      • Air Exhaust Port Thread Gender: Female
      • Air Exhaust Port Thread Type: NPT
      • Air Inlet Size (in): 1/2
      • Air Inlet Thread Gender: Female
      • Air Inlet Thread Type: NPT
      • Application: Sanitary
      • Ball Material: PTFE
      • Center Section Material: Stainless Steel
      • Compatible Material: Edible Oil, Food and Personal Care
      • Connection Type: Tri-Clamp
      • Diaphragm Compatible Material: PTFE
      • Diaphragm Material: PTFE
      • Fluid Inlet Size (cm): 5.08
      • Fluid Inlet Size (in): 1-1/2
      • Fluid Inlet Size (mm): 50.8
      • Fluid Outlet Size (cm): 5.08
      • Fluid Outlet Size (in): 1-1/2
      • Fluid Outlet Size (mm): 50.8
      • Fluid Section Material: 316L Stainless Steel
      • For Use With: Food and Personal Care
      • Manifold Configuration: End Port
      • Manifold O-Ring Material: PTFE
      • Material: Stainless Steel
      • Maximum Air Consumption (SCFM): 130
      • Maximum Air Pressure (bar): 8
      • Maximum Air Pressure (kPa): 800
      • Maximum Air Pressure (MPa): 0.8
      • Maximum Air Pressure (psi): 120
      • Maximum Cycle Rate (CPM): 200
      • Maximum Flow Rate (GPM): 90
      • Maximum Flow Rate (L/min): 341
      • Maximum Fluid Pressure (bar): 8
      • Maximum Fluid Pressure (kPa): 800
      • Maximum Fluid Pressure (MPa): 0.8
      • Maximum Fluid Pressure (psi): 120
      • Maximum Fluid Pressure (bar): 8
      • Maximum Fluid

GG FD2213

SANIFORCE AODD PUMP, 1590FG-PS01AS13SSPTPOEP21

Graco FD2213 SaniForce 1590 with Sanitary Clamp Connection

Graco's SaniForce 1590 air-operated double diaphragm sanitary pumps have one of the best, most durable, lube-free air valves in the industry. Ideal for applications requiring high flow rates and portability, Graco's dependable diaphragm pumps offer a wide range of food-grade elastomers including Santoprene, PTFE and overmolded EPDM/PTFE.

• SaniForce 1590 Double Diaphragm Pump

  2 in (51 mm) tri-clamp connection

  90 gpm (341 lpm) in a compact, portable size

  Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)

  All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21

  High volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from original container to smaller receptacles - up to 15,000 cps

  Suitable to pump such products as: concentrated fruit juices, sauces, pastes, starches, wine, food-grade oil, jams and jellies

  • Patented, lube-free air valve

    Three-way pilot valve for no-stick operation

    316 series stainless steel rod design for long life and corrosion resistance

    1040, 1590 and 2150 SaniForce pumps use common center sections

    100% externally serviceable air valve

    • PTFE/EPDM Overmolded Diaphragms

      Available on the SaniForce 1040, 1590, 2150 and SaniForce HS 1590 and 3150

      Improve wear and diaphragm life with no exposed diaphragm plate on the fluid side

      Longer diaphragm life in abrasive applications that still require PTFE




      • Model: SaniForce
      • Series: 1590
      • Air Exhaust Port Size (in): 3/4
      • Air Exhaust Port Thread Gender: Female
      • Air Exhaust Port Thread Type: NPT
      • Air Inlet Size (in): 1/2
      • Air Inlet Thread Gender: Female
      • Air Inlet Thread Type: NPT
      • Application: Sanitary
      • Ball Material: PTFE
      • Center Section Material: Stainless Steel
      • Compatible Material: Edible Oil, Food and Personal Care
      • Connection Type: Tri-Clamp
      • Diaphragm Compatible Material: PTFE
      • Diaphragm Material: PTFE Overmold
      • Fluid Inlet Size (cm): 5.08
      • Fluid Inlet Size (in): 1-1/2
      • Fluid Inlet Size (mm): 50.8
      • Fluid Outlet Size (cm): 5.08
      • Fluid Outlet Size (in): 1-1/2
      • Fluid Outlet Size (mm): 50.8
      • Fluid Section Material: 316L Stainless Steel
      • For Use With: Food and Personal Care
      • Manifold Configuration: End Port
      • Manifold O-Ring Material: EPDM
      • Material: Stainless Steel
      • Maximum Air Consumption (SCFM): 130
      • Maximum Air Pressure (bar): 8
      • Maximum Air Pressure (kPa): 800
      • Maximum Air Pressure (MPa): 0.8
      • Maximum Air Pressure (psi): 120
      • Maximum Cycle Rate (CPM): 200
      • Maximum Flow Rate (GPM): 90
      • Maximum Flow Rate (L/min): 341
      • Maximum Fluid Pressure (bar): 8
      • Maximum Fluid Pressure (kPa): 800
      • Maximum Fluid Pressure (MPa): 0.8
      • Maximum Fluid Pressure (psi): 120
      • Maximum Fluid Pressure (bar): 8
      • Maximum Fluid Pressure (kPa): 800
      • Maximum Fluid Pressure (MPa):

GG FD1113

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSPTPOPT21

Graco FD1113 SaniForce 1040 Diaphragm Pump for Barrel-to-Barrel Transfer and Pump-Over

Graco's SaniForce 1040 air-operated double diaphragm sanitary pumps have one of the best, most durable, lube-free air valves in the industry. Ideal for applications requiring high flow rates and portability, Graco's dependable diaphragm pumps offer a wide range of food-grade elastomers including Santoprene, PTFE and overmolded EPDM/PTFE.

• 1.5 in (38 mm) Tri-clamp connection
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)
• High volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from original container to smaller receptacles - up to 10,000 cps
• Suitable to pump such products as: concentrated fruit juices, sauces, pastes, starches, wine, food-grade oil, jams and jellies

• Model: SaniForce
• Series: 1040

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: PTFE

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food and Personal Care

• Connection Type: Tri-Clamp

• Diaphragm Compatible Material: PTFE
• Diaphragm Material: PTFE Overmold

• Fluid Inlet Size (cm): 3.81
• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 38.1

• Fluid Outlet Size (cm): 3.81
• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 38.1
• Fluid Section Material: 316L Stainless Steel

• For Use With: Food and Personal Care

• Manifold Configuration: End Port
• Manifold O-Ring Material: PTFE
• Material: Stainless Steel

• Maximum Air Consumption (SCFM): 50
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 256

• Maximum Flow Rate (GPM): 41
• Maximum Flow Rate (L/min): 151

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Operating Temperature ( degree C): 104
• Maximum Operating Temperature ( degree F): 220

• Maximum Solid Size (cm): 0.3175
• Maximum Solid Size (in): 0.125
• Maximum Solid Size (mm): 3.175

• Overall Height (in): 16.1

• Power Source: Pneumatic

• Pump Ratio: 1:1

GG FD1222

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSSPSPEP21

Graco FD1222 SaniForce 1040 S/S AODD Pump with Flange Connection, 316 S/S Seats, EPDM O-Rings, Santoprene Balls & Diaphragms

Graco's SaniForce 1040 air-operated double diaphragm sanitary pumps have one of the best, most durable, lube-free air valves in the industry. Ideal for applications requiring high flow rates and portability, Graco's dependable diaphragm pumps offer a wide range of food-grade elastomers including Santoprene, PTFE and overmolded EPDM/PTFE.

• 1.5 in (38 mm) Tri-clamp connection
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)
• High volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from original container to smaller receptacles - up to 10,000 cps
• Suitable to pump such products as: concentrated fruit juices, sauces, pastes, starches, wine, food-grade oil, jams and jellies

• Model: SaniForce
• Series: 1040

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Sanitary

• Ball Material: Santoprene

• Center Section Material: Stainless Steel

• Compatible Material: Edible Oil, Food and Personal Care

• Connection Type: Tri-Clamp

• Diaphragm Compatible Material: Santoprene
• Diaphragm Material: Santoprene

• Fluid Inlet Size (cm): 3.81
• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 38.1

• Fluid Outlet Size (cm): 3.81
• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 38.1
• Fluid Section Material: 316L Stainless Steel

• For Use With: Food and Personal Care

• Manifold Configuration: End Port
• Manifold O-Ring Material: EPDM
• Material: Stainless Steel

• Maximum Air Consumption (SCFM): 50
• Maximum Air Pressure (bar): 8

• Maximum Air Pressure (kPa): 800
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120

• Maximum Cycle Rate (CPM): 256

• Maximum Flow Rate (GPM): 41
• Maximum Flow Rate (L/min): 151

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 0.3175
• Maximum Solid Size (in): 0.125
• Maximum Solid Size (mm): 3.175

• Power Source: Pneumatic

• Pump Ratio: 1:1

GG FD9222

SANIFORCE AODD PUMP, 2150FG-PS01AS14SSSPSPEP21

Graco FD9222 SaniForce 2150 Diaphragm Pump

Graco's SaniForce 2150 air-operated double diaphragm sanitary pumps have one of the best, most durable, lube-free air valves in the industry. Ideal for applications requiring high flow rates and portability, Graco's dependable diaphragm pumps offer a wide range of food-grade elastomers including Santoprene, PTFE and overmolded EPDM/PTFE.

• SaniForce 2150 Double Diaphragm Pump

  2-1/2 in (63.5 mm) Tri-clamp connection

  Flow rates up to 150 gpm (567 lpm) (568 lpm)

  Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)

  All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21

  High volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from original container to smaller receptacles - up to 20,000 cps

  Suitable to pump such products as: concentrated fruit juices, sauces, pastes, starches, wine, food-grade oil, jams and jellies

  • Patented, lube-free air valve

    Three-way pilot valve for no-stick operation

    Long-lasting 16 Series stainless steel rod design for long life and corrosion resistance

    1040, 1590 and 2150 SaniForce pumps use common center sections

    100% externally serviceable air valve

    • PTFE/EPDM Overmolded Diaphragms

      Overmolded diaphragm plate with PTFE on the fluid side and EPDM on the air side on Gracos PTFE/EPDM diaphragms so theres no place to harbor bacteria

      Improve wear and diaphragm life with no exposed diaphragm plate on the fluid side

      Longer diaphragm life in abrasive applications that still require PTFE

      Available on the SaniForce 1040, 1590, 2150 and SaniForce HS 1590 and 3150




      • Model: SaniForce
      • Series: 2150
      • Air Exhaust Port Size (in): 3/4
      • Air Exhaust Port Thread Gender: Female
      • Air Exhaust Port Thread Type: NPT
      • Air Inlet Size (in): 1/2
      • Air Inlet Thread Gender: Female
      • Air Inlet Thread Type: NPT
      • Application: Sanitary
      • Ball Material: Santoprene
      • Center Section Material: Stainless Steel
      • Compatible Material: Edible Oil, Food and Personal Care
      • Connection Type: DIN
      • Diaphragm Compatible Material: Santoprene
      • Diaphragm Material: Santoprene
      • Fluid Inlet Size (cm): 6.35
      • Fluid Inlet Size (in): 2
      • Fluid Inlet Size (mm): 63.5
      • Fluid Outlet Size (cm): 6.35
      • Fluid Outlet Size (in): 2
      • Fluid Outlet Size (mm): 63.5
      • Fluid Section Material: 316L Stainless Steel
      • For Use With: Food and Personal Care
      • Manifold Configuration: End Port
      • Manifold O-Ring Material: EPDM
      • Material: Stainless Steel
      • Maximum Air Consumption (SCFM): 175
      • Maximum Air Pressure (bar): 8
      • Maximum Air Pressure (kPa): 800
      • Maximum Air Pressure (MPa): 0.8
      • Maximum Air Pressure (psi): 120
      • Maximum Cycle Rate (CPM): 165
      • Maximum Flow Rate (GPM): 150
      • Maximum Flow Rate (L/min): 568
      • Maximum Fluid Pressure (bar): 8
      • Maximum Fluid Pressure (kPa): 800
      • Maximum Fluid Pressure (MPa): 0.8
      • Maximum Fluid Pressure (psi): 120
      • Maximum Fluid Pressure (bar): 8
      • Maximum Fluid Pressure (kPa): 800
      • Maximum Fluid Pressure (MPa): 0.8

GG FFLP110

RAC X FFLP TIP, SPRAY, (110)

Graco FFLP110 Fine Finish Low Pressure RAC X FF LP SwitchTip, 110

Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 110 Fine Finish Low Pressure (FF LP) RAC X SwitchTip. This fine finish tip produces a 2 to 4 inch Fan pattern and has a 0.010 inchorifice, ideal for finishing materials. Reverse the SwitchTip to easily clear clogs.

• Less Prep & Cleanup Time
  • Less mess with less overspray
  • Put the paint where you want it
• Easiest Pattern Overlap
  • Softer spray fan pattern
  • Easy to apply any material to any surfance
  • Consistent blended finish quality
• Extended Life
  • Spraying at half pressure doubles tip life
  • Reduced sprayer maintenance - up to 2X life
• Best Tip on the Market
  • Works with any airless sprayer
  • Longest lasting Fan pattern
  • Highest quality finish with a consistent spray pattern
• Easy to Identify Tip Size
  • Large raised tip size numbers are always legible - even when covered with paint
• Superior Tip Design
  • Locking tab ensures tip stays securely in guard
  • Snaps tip in spray or reverse position
  • OneSeal tip gasket installs with no tools
  • Solvent seal available when using extremely hot solvents

• Model: RAC X
• Series: FF LP SwitchTip

• Compatible Material: Primer, Stains, Varnish, Water-Based Paint, Enamel, Latex, Solventborne Paints

• For Use With: RAC X HandTite Tip Guard

• Material: Tungsten Carbide

• Maximum Fan Width (cm): 5
• Maximum Fan Width (in): 2
• Maximum Fan Width (mm): 102

• Maximum Flow Rate (GPM): 0.11
• Maximum Flow Rate (L/min): 0.42

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 2
• Minimum Fan Width (mm): 51

• Orifice Diameter (in): 0.010

• Pattern Size (in): 2 to 4
• Pattern Size (mm): 50.8 to 101.6

GG FAR655K

GG FD5111

SANIFORCE AODD PUMP, 515FG-PP01AS13SSPTPTPT21

Graco FD5111 SaniForce 515 AODD Pump with Flange Connection, S/S Seats, PTFE O-Rings & Balls & 2-Piece PTFE Diaphragms

Gracos SaniForce 515 air-operated double diaphragm sanitary pump provides a solution to customers needing a pump with lower flow rates, a quick knock-down design for easy cleaning and a low cost of ownership - ideal for the food processing and personal care markets. Popular applications include transferring flavorings, purees, sauces and other low to medium viscosity materials.

• SaniForce 515 Double Diaphragm Pump
  1 in (25.4 mm) Tri-clamp connectionAll fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21Fluid pressure to 100 psi (7 bar, 0.7 MPa)Flow rates of 15 gpm (56.7 lpm)Applications include high volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from original container to smaller receptacles - up to 10,000 cpsSuitable to pump products like: flavorings, purees, sauces and other low to medium viscosity materials
  • SaniForce 515 Drum Siphon Kit

    Great for quickly unloading 55 gallon (208 liter) drums of low to medium viscosity materials

    The SaniForce 515 Drum Kit (Graco part # 262828) comes standard with:

    316 SST drum length suction tube

    316 SST mounting bracket

    316 SST bung adapter

    316 SST tri-clamp clamps (2)

    FDA-compliant gaskets

    • PTFE/EPDM Overmolded Diaphragms

      Overmolded diaphragm plate with PTFE on the fluid side and EPDM on the air side on Gracos PTFE/EPDM diaphragms so theres no place to harbor bacteria

      Improve wear and diaphragm life with no exposed diaphragm plate on the fluid side

      Longer diaphragm life in abrasive applications that still require PTFE

      Available on the SaniForce 515, 1040, 1590, 2150 and SaniForce HS 1590 and 3150




      • Model: SaniForce
      • Series: 515
      • Air Exhaust Port Size (in): 3/8
      • Air Exhaust Port Thread Gender: Female
      • Air Exhaust Port Thread Type: NPT
      • Air Inlet Size (in): 1/4
      • Air Inlet Thread Gender: Female
      • Air Inlet Thread Type: NPT
      • Application: Sanitary
      • Ball Material: PTFE
      • Center Section Material: Polypropylene
      • Compatible Material: Edible Oil, Food and Personal Care
      • Connection Type: Tri-Clamp
      • Diaphragm Compatible Material: PTFE
      • Diaphragm Material: PTFE
      • Fluid Inlet Size (cm): 2.54
      • Fluid Inlet Size (in): 1/2
      • Fluid Inlet Size (mm): 25.4
      • Fluid Outlet Size (cm): 2.54
      • Fluid Outlet Size (in): 1/2
      • Fluid Outlet Size (mm): 25.4
      • Fluid Section Material: 316L Stainless Steel
      • For Use With: Food and Personal Care
      • Manifold Configuration: End Port
      • Manifold O-Ring Material: PTFE
      • Material: Stainless Steel
      • Maximum Air Pressure (bar): 6.9
      • Maximum Air Pressure (kPa): 690
      • Maximum Air Pressure (MPa): 0.7
      • Maximum Air Pressure (psi): 100
      • Maximum Cycle Rate (CPM): 182
      • Maximum Flow Rate (GPM): 16
      • Maximum Flow Rate (L/min): 60.6
      • Maximum Fluid Pressure (bar): 6.9
      • Maximum Fluid Pressure (kPa): 690
      • Max

GG FFLP212

RAC X FFLP TIP, SPRAY, (212)

Graco FFLP212 Fine Finish Low Pressure RAC X FF LP SwitchTip, 212

Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 212 Fine Finish Low Pressure (FF LP) RAC X SwitchTip. This fine finish tip produces a 4 to 6 inch Fan pattern and has a 0.012 inch orifice, ideal for finishing materials. Reverse the SwitchTip to easily clear clogs.

• Less Prep & Cleanup Time

  Less mess with less overspray

  Put the paint where you want it

• Easiest Pattern Overlap

  Softer spray fan pattern

  Easy to apply any material to any surfance

  Consistent blended finish quality

• Extended Life

  Spraying at half pressure doubles tip life

  Reduced sprayer maintenance - up to 2X life

• Best Tip on the Market

  Works with any airless sprayer

  Longest lasting Fan pattern

  Highest quality finish with a consistent spray pattern

• Easy to Identify Tip Size

  Large raised tip size numbers are always legible - even when covered with paint

• Superior Tip Design

  Locking tab ensures tip stays securely in guard

  Snaps tip in spray or reverse position

  OneSeal tip gasket installs with no tools

  Solvent seal available when using extremely hot solvents

• Model: RAC X
• Series: FF LP SwitchTip

• Compatible Material: Primer, Stains, Varnish, Water-Based Paint, Enamel, Latex, Solvent borne Paints

• For Use With: RAC X HandTite Tip Guard

• Material: Tungsten Carbide

• Maximum Fan Width (cm): 10
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.15
• Maximum Flow Rate (L/min): 0.57

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.012

• Pattern Size (in): 4 to 6
• Pattern Size (mm): 101.6 to 152.4

GG FFLP210

RAC X FFLP TIP, SPRAY, (210)

Graco FFLP210 Fine Finish Low Pressure RAC X FF LP SwitchTip, 210

Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 210 Fine Finish Low Pressure (FF LP) RAC X SwitchTip. This fine finish tip produces a 4 to 6 inch Fan pattern and has a 0.010 inch orifice, ideal for finishing materials. Reverse the SwitchTip to easily clear clogs.

• Less Prep & Cleanup Time

  Less mess with less overspray

  Put the paint where you want it

• Easiest Pattern Overlap

  Softer spray fan pattern

  Easy to apply any material to any surfance

  Consistent blended finish quality

• Extended Life

  Spraying at half pressure doubles tip life

  Reduced sprayer maintenance - up to 2X life

• Best Tip on the Market

  Works with any airless sprayer

  Longest lasting Fan pattern

  Highest quality finish with a consistent spray pattern

• Easy to Identify Tip Size

  Large raised tip size numbers are always legible - even when covered with paint

• Superior Tip Design

  Locking tab ensures tip stays securely in guard

  Snaps tip in spray or reverse position

  OneSeal tip gasket installs with no tools

  Solvent seal available when using extremely hot solvents

• Model: RAC X
• Series: FF LP SwitchTip

• Compatible Material: Primer, Stains, Varnish, Water-Based Paint, Enamel, Latex, Solvent borne Paints

• For Use With: RAC X HandTite Tip Guard

• Material: Tungsten Carbide

• Maximum Fan Width (cm): 10
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.11
• Maximum Flow Rate (L/min): 0.42

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.010

• Pattern Size (in): 4 to 6
• Pattern Size (mm): 101.6 to 152.4

GG FD1213

SANIFORCE AODD PUMP, 1040FG-PS01AS13SSPTPOEP21

Graco FD1213 SaniForce 1040 S/S AODD Pump with Flange Connection, 316 S/S Seats, EPDM O-Rings, PTFE Balls & PTFE Overmolded Diaphragms

Graco's SaniForce 1040 air-operated double diaphragm sanitary pumps have one of the best, most durable, lube-free air valves in the industry. Ideal for applications requiring high flow rates and portability, Graco's dependable diaphragm pumps offer a wide range of food-grade elastomers including Santoprene, PTFE and overmolded EPDM/PTFE.

• 1.5 in (38 mm) Tri-clamp connection
• All fluid contact materials are FDA-Compliant and meet the United States Code of Federal Regulations (CFR) Title 21
• Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)
• High volume evacuation of liquid concentrates from holding vessels or repackaging of fluids from original container to smaller receptacles - up to 10,000 cps
• Suitable to pump such products as: concentrated fruit juices, sauces, pastes, starches, wine, food-grade oil, jams and jellies

• Model: SaniForce
• Series: 1040

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
