FLUID REGULATOR, P200-VM NPT

GG 234264

REGULATOR, PRESS, P200-VM, NPT

Graco 234264 High Pressure Fluid Regulator, 5000 Max psi, 1300-3000 psi Range, 8.2 GPM, SST, Spring Type, 3/8 (f) x 3/8 (f)

Mechanically operated fluid pressure regulators designed primarily for use with low to medium viscosity fluids.

• Actuation Type: Spring

• Includes: Regulator Only
• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 8.2
• Maximum Flow Rate (L/min): 31.04

• Maximum Regulated Pressure (bar): 200
• Maximum Regulated Pressure (kPa): 20000
• Maximum Regulated Pressure (MPa): 20
• Maximum Regulated Pressure (psi): 3000

• Maximum Working Pressure (bar): 360
• Maximum Working Pressure (kPa): 36000
• Maximum Working Pressure (MPa): 36
• Maximum Working Pressure (psi): 5000

• Minimum Regulated Pressure (bar): 90
• Minimum Regulated Pressure (kPa): 9000
• Minimum Regulated Pressure (MPa): 9
• Minimum Regulated Pressure (psi): 1300

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
