Airpower | Balancers

Balancer

IR BMDLN-8

Medium-Duty Long Spring Cable Balancer, 13.2-17.6 lb Capacity, 8.2' Lift

Description: B Series spring balancers are designed to increase productivity in any situation where repetitive or prompt vertical movement of fixed load is required. They compensate weight of your power tools or other manufacturing equipment and enable operator to lift or lower it with minimal effort.

Features And Benefits:

Rugged construction, cast aluminum body
Stainless steel cable and anti-friction cable guide
Adjustable capacity
Adjustable stroke limiting device
Upper suspension shackle included on balancer for ease of installation
Axial Mounting Circlip to ensure greater durability
Anti-reverse spanner adjustable bushing to protect the balancer from potential damages caused by an incorrect spring unloading
Safety Cap added to the front of the balancer for greater durability by absorbing impact while in motion
Safety device against load dropping due to the spring breakage (>6.5 lb)

Cable Material: Stainless steel
Capacity (lb): 13.2 - 17.6

Color: Red
Duty Rating: Medium Duty

Housing Material: Aluminum
Lift (ft): 8.2
Lock Mechanism: Ratchet
Lower Hook: Spring Clip

Product Length (in): 11.75

Product Width (in): 5.75
Product Weight (lb): 7.5
Reel Height (in): 15
Reel Mount Type: Suspension Shackle
Rotation Type: Fixed

Tension Adjustment: Front Screw with Spanner Wrench

Warranty: 1-year

$371.00
