GG HSHC5B
XD SERIES 30 REEL, 1/2 X 50, GREASE, BLUE
Graco HSHC5B XD30, Grease, 1/2 in. (13 mm) Inlet, 1/2 in. X 50 ft. (13 mm X 15 m) Hose, NPT, Truck/Bench Mount, Metallic Blue
Graco's XD30 Series Hose Reels are used in applications requiring longer-range dispense and higher capacity than the standard XD10 and XD20 Series. The Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (9.1-22.8 meters) hose capacity for a wide variety of applications. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze, windshield washer fluid, pressure wash, waste oil and diesel exhaust fluid (DEF).
Application: Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks.
- Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
- Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
- Optional Adjustable Arm - Easily change the arm position for your application, order with arm (HS models) or without (HN models)
- Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (91-228 meters) hose capacity for a wide variety of applications
- Frame Type: Dual Pedestal
- Hose Inside Diameter (in): 1/2
- Hose Inside Diameter (mm): 12.7
- Hose Length (ft): 50
- Hose Length (m): 15
- Hose Reel Type: Reel with Hose
- Includes Hose: Yes
- Inlet Size (in): 1/2
- Inlet Size (mm): 12.7
- Maximum Working Pressure (psi): 5000
- Mount Location: Truck Mount, Bench Mount
- Outlet Size (in): 1/2
- Outlet Size (mm): 12.7
- Overall Height (in): 27.6
- Overall Height (mm): 701
- Overall Length (in): 25.96
- Overall Length (mm): 659
- Overall Width (in): 9.0
- Overall Width (mm): 229
- Recommended Environment: Indoor, Outdoor
- Recommended Fluid Type: Grease
