Super Duty Impactool

IR 588A1

2-1/2" Air Impact Wrench, Super Duty, 50,000 ft-lb Torque, Thru-hole Retainer, T-handle

Description: The 588A1 Impact Wrench delivers high power, doesn't stall, and delivers smooth, constant speed from its motor.

Features And Benefits:

• Durability: With a cast iron hammer case and bronze end-plate, this wrench is spark proof and corrosion resistant. It will withstand even the harshest conditions.
• Reliability: Doesn't stall, and delivers smooth, constant speed from its motor. Built with the most premium parts in the industry, this wrench is designed to last.
• Power: With a high torque output and maximum power of 50,000 ft-lbs max torque, this wrench makes every job a breeze.
• Built-in lubricator

Product Application and Uses:

These Air Impact Wrenches are designed to remove and install threaded fasteners requiring high torque. Engineered to withstand the harshest working conditions in oilfields, mines, and shipyards.

• Actuation/Throttle Type/Switch Type: Lever
• Air Inlet: 1" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 155
• Average Air Consumption (l/min): 4389

• Blows per Min: 550

• Color: Grey
• Configuration/Handle Type: T-handle
• Drive Size (in): 2-1/2
• Drive Type: Square
• Duty Rating: Super Duty

• End Plates: Bronze
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 110.0 / 121.0

• Hammer Case: Cast Iron
• Handle Material: Composite
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Ball and Cam

• Max Bolt Diameter (in): 3
• Max Free Speed (rpm): 355
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 50000
• Max Torque (in-lb): 599992
• Max Torque (nm): 67790
• Min Hose Size (in): 1
• Motor: Non-Biased

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Product Length (in): 26.63

• Product Weight (lb): 215
• Recommended Forward Torque Range (ft-lb): 12000-25003
• Recommended Forward Torque Range (in-lb): 144002-300040
• Recommended Forward Torque Range (nm): 16270 - 33900
• Retainer Type: Thru-hole

• Side to Center Distance (in): 4
• Side to Center Distance (mm): 102

• Speed Setting: Variable Speed
• Standards/Certifications: CE

• Tool Type: Full-size
• Vanes: 5
• Vibration Level (m/s2): 20.5
• Warranty: 1-year

• Lubrication: 105-LBK1
• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 215-4
• Parts: 588-726

• Parts: 588-A727
