Super Duty Impactool

IR 2906P1

1/2" Air Impact Wrench, Super Duty, 500 ft-lb Torque, Pin Retainer, Pistol

Description: This heavy duty impact wrench has your back. This tool is safe, reliable and always ready to perform at its peak.

Features And Benefits:

• Durability: The 2906P1 Impact Wrench was built to last. Thanks to its steel hammer case and metal housing, this tool will work after multiple drops and harsh weather conditions.
• Power: Finely tuned twin hammer impact mechanism and a reverse bias motor delivers 500 ft-lbs. of max. torque, and 1200 blows per minute.
• Increased Safety: The square pin drive ensures provides the strongest connection to the socket to increase safety.

Product Application and Uses:

Heavy Industry, Oil&Gas, Foundry

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 23
• Average Air Consumption (l/min): 651

• Blows per Min: 1200

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/2
• Drive Type: Square
• Duty Rating: Super Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 84.2 / 95.2

• Hammer Case: Steel
• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 86.0 / 97.0

• Max Bolt Diameter (in): 9/16
• Max Free Speed (rpm): 5000
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 500
• Max Torque (in-lb): 6001
• Max Torque (nm): 678
• Min Hose Size (in): 3/8
• Motor: Non-Biased

• Number of Power Settings: 6
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 83.3
• Product Length (in): 6.88

• Product Width (in): 8.82
• Product Height (in): 3.39
• Product Weight (lb): 6
• Recommended Forward Torque Range (ft-lb): 40-350
• Recommended Forward Torque Range (in-lb): 480-4204
• Recommended Forward Torque Range (nm): 54.2-475
• Recommended Reverse Torque (ft-lb): 40-350
• Recommended Reverse Torque (nm): 54.2-475
• Retainer Type: Pin Detent

• Side to Center Distance (in): 4.4
• Side to Center Distance (mm): 112

• Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744

• Tool Type: Full-size
• Vanes: 6
• Vibration Level (m/s2): 7.6
• Warranty: 1-year

• Accessories: S64H1316L-PS1
• Accessories: S64H1516L-PS1
• Accessories: S64H34L-PS1
• Accessories: S64H78L-PS1
• Accessories: S64M17L-PS1
• Accessories: S64M18L-PS1
• Accessories: S64M21L-PS1
• Accessories: S64M22L-PS1
• Accessories: S64M24L-PS1
• Accessories: S64M26L-PS1
• Accessories: SK4H13N

• Lubrication: 105-LBK1
• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 2906P-TK1
