Single Ball Check Valve - 60 psi Nominal Cracking Pressure, 1/8in NPSF (F) x 1/8in NPTF (M), Steel, 5,000 psi

GG 563201

VALVE, CHECK, 1/8 NPT, REV, 5000

Graco 563201 Single Ball Check Valve - 60 psi Nominal Cracking Pressure, 1/8 in NPSF (F) x 1/8 in NPTF (M), Steel, 5,000 psi

• Single Ball Check Valve
• 60 psi nominal cracking pressure
• 1/8 inch (3.2 mm) NPSF (F) x 1/8 inch (3.2 mm) NPTF (M)
• 5,000 psi max
• Lubriquip part number 509-355-060

• Application: Compressor Equipment

• Ball Material: Steel

• Body Material: Steel

• Compatible Material: Oil, Grease

• Inlet Size (cm): 0.3175
• Inlet Size (in): 1/8
• Inlet Size (mm): 3.175

• Inlet Thread Type: NPTF

• Maximum Cracking Pressure (bar): 4.14
• Maximum Cracking Pressure (kPa): 414
• Maximum Cracking Pressure (MPa): 0.414
• Maximum Cracking Pressure (psi): 60

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (MPa): 34.5
• Maximum Working Pressure (psi): 5000

• Number of Balls: Single Ball

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Type: NPSF
