Parts

IR ATC040-1C

ANGLE TOOL CLAMP

IR BCT-2

Beam Clamp, 2 Ton Capacity

The BCT Series 1-10 metric ton capacity beam clamps provide a temporary or permanent mount to a wide range of tapered or flat beams. They are the ideal rigging device for lifting, pulling or suspending loads. These units have been designed and verified to achieve a minimum design factor of 5:1 for vertical lifting with powered or manual hoists or winches, meeting ASME B30.16 and ASME B30.7. Quick and simple installation is achieved without tools. Units accommodate hook-mounted hoist or load blocks with minimal loss of headroom. The clamp jaws are designed to reduce beam stress by applying the load inside of the flange edge.

Product Application/Uses:

Ideal rigging device for lifting, pulling or suspending loads.

Features and Benefits:

• Quick installation by hand
• Designed and verified to achieve a minimum design factor of 5:1 for vertical lifting with powered or manual hoists or winches, meeting ASME B30.16 and ASME B30.7.
• Metric rated for vertical lifting or in-line pulling at 2200 lbs (1000 kg) per ton.
• Each unit is serialized, supplied with a test certificate and manual.
• Ideal rigging devices for lifting, pulling or suspending loads.
• Units accommodate hook-mounted hoist or load blocks with minimal loss of headroom.
• Low-headroom design adjusts to fit a wide range of flat or tapered beams
• The clamp jaws are designed to reduce beam stress by applying the load inside of the flange edge.

IR DG10-65-5

Spacer (49440-15)

IR DXS2SH12L

DXS2 1/2" SAE Deep Impact Socket

Never lose power from worn sockets and square drive anvils with Drive Xchange System™ Sockets and enjoy easier access into tight spaces with up to ¾” shorter tool length when use with Ingersoll Rand DXS™ impact wrenches. DXS™ direct drive sockets fit tighter and have more load bearing surface compared to traditional square drives to deliver up to 15% better torque transfer and 20% longer wear life.

Features And Benefits

• DXS Drive delivers up to 15% better torque efficiency compared to square drive sockets and reduces overall tool length by up to 3/4" compared to square drive sockets.
• Up to 20% longer life compared to traditional square driven sockets.
• Impact-grade toughness chrome-molybdenum (CR-MO) alloy steel with manganese phosphate finish to resist corrosion.
• Ball nose retention pin for quick, tool-free installation and removal.
• High visibility laser etched markings to easily identify the size you need.
• Relieved 6 point Hex corners help reduce faster rounding.
• Square retention pin conversion kit available for secure connection.
• Complies with ASME B107.110
• Backed by a lifetime limited warranty for peace of mind with proven reliability.
• For use with all Ingersoll Rand DXS2 drive Impacts.

Product Application and Uses: Vehichle Repair and General Industry. For use with all Ingersoll Rand DXS2 Drive Impacts.
Drive Size (in): DXS2
Drive Type: DXS
Finish: Chrome-molybdenum steel
Insulated: No
Non Sparking: No
Number of Points: 6
Product Length (in): 0.85
Product Width (in): 0.85
Product Height (in): 2.95
Product Weight (lb): 0.32
Socket Bit Type: Hex
Socket Depth: Deep
Socket Measurement Type: SAE
Socket Size: 1/2in
Standards/Certifications: ASME B107.110
Warranty: Lifetime Limited
Fastener Holding Magnet: No

For Use With

• 2236QPTIMAX
• 2236QTIMAX
• 2236QTIMAX-2
• 2236QTIMAX-G
• 2236QTIMAX-O
• 2236QTIMAX-R
• W7153
• W7153-AP
• W7153-K22
• W7153-K22-CN
• W7153-K22-IN
• W7153-K22-JP
• W7153-K22-KR
• W7153-K22-SGHK
• W7153-K22B-AN
• W7153-K22B-EU
• W7253-TL

Similar IR

• DXS2SH12
• DXSK2H14L
• DXSK2H14
• DXSK2M15
• DXSK2M15L

IR DXSK2M15

DXS2 Drive Hex Metric Impact Socket Set, 15-Piece

Never lose power from worn sockets and square drive anvils with Drive Xchange System™ Sockets and enjoy easier access into tight spaces with up to ¾” shorter tool length when use with Ingersoll Rand DXS™ impact wrenches. DXS™ direct drive sockets fit tighter and have more load bearing surface compared to traditional square drives to deliver up to 15% better torque transfer and 20% longer wear life.

Features And Benefits

• DXS Drive delivers up to 15% better torque efficiency compared to square drive sockets and reduces overall tool length by up to 3/4" compared to square drive sockets.
• Up to 20% longer life compared to traditional square driven sockets.
• Impact-grade toughness chrome-molybdenum (CR-MO) alloy steel with manganese phosphate finish to resist corrosion.
• Ball nose retention pin for quick, tool-free installation and removal.
• High visibility laser etched markings to easily identify the size you need.
• Relieved 6 point Hex corners help reduce faster rounding.
• Square retention pin conversion kit available for secure connection.
• Complies with ASME B107.110
• Backed by a lifetime limited warranty for peace of mind with proven reliability.
• For use with all Ingersoll Rand DXS2 drive Impacts.
• Includes 15 sockets (12mm, 13mm, 14mm, 15mm, 16mm, 17mm, 18mm, 19mm, 21mm, 22mm, 24mm, 27mm, 30mm, 32mm, 33mm) and foam organizer shadowboard tray.

Includes: 15 sockets (12mm, 13mm, 14mm, 15mm, 16mm, 17mm, 18mm, 19mm, 21mm, 22mm, 24mm, 27mm, 30mm, 32mm, 33mm) and Foam Organizer Shadowboard Tray
Product Application and Uses: Vehichle Repair and General Industry. For use with all Ingersoll Rand DXS2 Drive Impacts.
Drive Size (in): DXS2
Drive Type: DXS
Finish: Chrome-molybdenum steel
Insulated: No
Non Sparking: No
Number of Points: 6
Product Length (in): 16.38
Product Width (in): 5.44
Product Height (in): 2.5
Product Weight (lb): 4.38
Socket Bit Type: Hex
Socket Depth: Standard
Socket Measurement Type: Metric
Socket Size: 12mm
Socket Size: 13mm
Socket Size: 14mm
Socket Size: 15mm
Socket Size: 16mm
Socket Size: 17mm
Socket Size: 18mm
Socket Size: 19mm
Socket Size: 21mm
Socket Size: 22mm
Socket Size: 24mm
Socket Size: 27mm
Socket Size: 30mm
Socket Size: 32mm
Socket Size: 33mm
Standards/Certifications: ASME B107.110
Warranty: Lifetime Limited

For Use With

• 2236QPTIMAX
• 2236QTIMAX
• 2236QTIMAX-2
• 2236QTIMAX-G
• 2236QTIMAX-O
• 2236QTIMAX-R
• W7153
• W7153-AP
• W7153-K22
• W7153-K22-CN
• W7153-K22-IN
• W7153-K22-JP
• W7153-K22-KR
• W7153-K22-SGHK
• W7153-K22B-AN
• W7153-K22B-EU
• W7253-TL

Similar IR

• DXSK2H14
• DXSK2H14L
• DXSK2M15L

IR DXSK2M15L

DXS2 Drive Hex Deep Metric Impact Socket Set, 15-Piece

Never lose power from worn sockets and square drive anvils with Drive Xchange System™ Sockets and enjoy easier access into tight spaces with up to ¾” shorter tool length when use with Ingersoll Rand DXS™ impact wrenches. DXS™ direct drive sockets fit tighter and have more load bearing surface compared to traditional square drives to deliver up to 15% better torque transfer and 20% longer wear life.

Features And Benefits

• DXS Drive delivers up to 15% better torque efficiency compared to square drive sockets and reduces overall tool length by up to 3/4" compared to square drive sockets.
• Up to 20% longer life compared to traditional square driven sockets.
• Impact-grade toughness chrome-molybdenum (CR-MO) alloy steel with manganese phosphate finish to resist corrosion.
• Ball nose retention pin for quick, tool-free installation and removal.
• High visibility laser etched markings to easily identify the size you need.
• Relieved 6 point Hex corners help reduce faster rounding.
• Square retention pin conversion kit available for secure connection.
• Complies with ASME B107.110
• Backed by a lifetime limited warranty for peace of mind with proven reliability.
• For use with all Ingersoll Rand DXS2 drive Impacts.
• Includes 15 deep sockets (12mm, 13mm, 14mm, 15mm, 16mm, 17mm, 18mm, 19mm, 21mm, 22mm, 24mm, 27mm, 30mm, 32mm, 33mm) and foam organizer shadowboard tray.

Includes: 15 deep sockets (12mm, 13mm, 14mm, 15mm, 16mm, 17mm, 18mm, 19mm, 21mm, 22mm, 24mm, 27mm, 30mm, 32mm, 33mm) and Foam Organizer Shadowboard Tray
Product Application and Uses: Vehichle Repair and General Industry. For use with all Ingersoll Rand DXS2 Drive Impacts.
Drive Size (in): DXS2
Drive Type: DXS
Finish: Chrome-molybdenum steel
Insulated: No
Non Sparking: No
Number of Points: 6
Product Length (in): 16.38
Product Width (in): 9.38
Product Height (in): 2
Product Weight (lb): 8.47
Socket Bit Type: Hex
Socket Depth: Deep
Socket Measurement Type: Metric
Socket Size: 12mm
Socket Size: 13mm
Socket Size: 14mm
Socket Size: 15mm
Socket Size: 16mm
Socket Size: 17mm
Socket Size: 18mm
Socket Size: 19mm
Socket Size: 21mm
Socket Size: 22mm
Socket Size: 24mm
Socket Size: 27mm
Socket Size: 30mm
Socket Size: 32mm
Socket Size: 33mm
Standards/Certifications: ASME B107.110
Warranty: Lifetime Limited

For Use With

• 2236QPTIMAX
• 2236QTIMAX
• 2236QTIMAX-2
• 2236QTIMAX-G
• 2236QTIMAX-O
• 2236QTIMAX-R
• W7153
• W7153-AP
• W7153-K22
• W7153-K22-CN
• W7153-K22-IN
• W7153-K22-JP
• W7153-K22-KR
• W7153-K22-SGHK
• W7153-K22B-AN
• W7153-K22B-EU
• W7253-TL

Similar IR

• DXSK2H14
• DXSK2H14L
• DXSK2M15

IR E610H

3/4" DRIVE, 10" EXTENSION

IR E63H

3/4" DRIVE, 3" EXTENSION

IR H-282-12

BUSHING

IR H3R-214-12

12" Chipping Hammer Blank Steel, Hex Shank Round Collar

Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world’s first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Suitable for a wide range of applications, our chipping hammer steels are available with round or hex shanks and oval or round collars.

Includes: (5) Blank Steels
Product Application and Uses: Designed for making customized points. For use with Ingersoll Rand W1A1, W2A1, W3A1, W4A1 chipping hammers.
Chisel Style: Blank
Collar Type: Round
Collar Width (in): 1.125
Housing Material: Steel
Length Under Collar (in): 9.5
Product Length (in): 12
Product Weight (lb): 1.75
Shank Length (in): 2.5
Shank SIze (in): 0.58
Shank Type: Hex

For Use With

• W1A1
• W2A1
• W3A1
• W4A1

IR H80-82A

BUSHING

IR HH1-1191

QUICK CHANGE RETAINER FITS GRVD, QTY 1

IR HH1-1191-4

INSERT SPRING

IR HH1-215D-12

12" Diamond Point Chipping Hammer Steel Round Shank Oval Collar

Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world’s first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Suitable for a wide range of applications, our chipping hammer steels are available with round or hex shanks and oval or round collars.

Includes: (1) Diamond Point Steel
Product Application and Uses: Designed for general demolition. For use with Ingersoll Rand 2DA2SA, 3DA2SA, 4DA2SA, 1A2SA, 2A2SA, 3A2SA, 4A2SA chipping hammers
Chisel Style: Diamond Point
Collar Thickness (in): 0.813
Collar Type: Oval
Collar Width (in): 1.125
Housing Material: Steel
Length Under Collar (in): 9.625
Product Length (in): 12
Product Weight (lb): 1.75
Shank Length (in): 2.375
Shank SIze (in): 0.68
Shank Type: Round

For Use With

• 1A2SA
• 2A2SA
• 2DA2SA
• 3A2SA
• 3DA2SA
• 4A2SA
• 4DA2SA

IR HH1-215S-12

3" Scaling Chipping Hammer Chisel Steels, 12"L Round Shank Oval Collar

Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world’s first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Suitable for a wide range of applications, our chipping hammer steels are available with round or hex shanks and oval or round collars.

Includes: (10) Chipping Hammer Chisel Steels
Product Application and Uses: Designed for general demolition. For use with Ingersoll Rand 2DA2SA, 3DA2SA, 4DA2SA, 1A2SA, 2A2SA, 3A2SA, 4A2SA chipping hammers
Chisel Style: Scaling
Collar Thickness (in): 0.813
Collar Type: Oval
Collar Width (in): 1.125
Housing Material: Steel
Length Under Collar (in): 9.625
Product Length (in): 12
Product Width (in): 3
Product Weight (lb): 2
Shank Length (in): 2.375
Shank SIze (in): 0.68
Shank Type: Round

For Use With

• 1A2SA
• 2A2SA
• 2DA2SA
• 3A2SA
• 3DA2SA
• 4A2SA
• 4DA2SA

IR JC3350-538

ROLL PIN

IR JKST300

JOINT KIT W/TRANSDUCER

IR L36561-100

L36561-100 : Lubricator (Super-Duty Series)

IR M2A120RP945

MERCURY ANGLE GRINDER

IR MC121-32

PIN

IR NS11-25

STOP

IR NS11-A24

Needle Housing Assembly, Round for Ingersoll Rand 172 and 182 Series Percussive Scaler

For Use With

• 172L
• 172LNA1
• 182K1
• 182L
• 182LNA1

IR P4EV-6

4" Saw Blades, Extra Coarse Variable Pitch, 14-18 TPI, 6-Pack for Ingersoll Rand Reciprocating Saw

Bi-metal technology high speed steel increases blade control by 170%. New tooth profile generates smaller but more chips and reduces frictional heat.

Includes: 6 saw blades
Product Application and Uses: Can be used with all standard 1/2" shank air reciprocating saws. Used to cut all woods, composition material, nail embedded wood, non-ferrous metals, plastic.
Finish: Steel
Product Length (in): 4
Product Width (in): 3.5
Product Height (in): 21.5

For Use With

• 429
• 4429
• 529

IR P4FS-6

Air Reciprocating Saw Blades, 4-Inch Fine, 32 TPI, 6 pc.

Air Reciprocating Saw Blades, 6-pack Fine Pitch

Features And Benefits

• Bi-Metal Technology: a solid-state diffusion process that applies high-speed steel to both edges of the backing materials, increasing the contact area by 170%
• New Tooth Profile that reduces frictional heat generated during the cutting process to enhance performance

Includes: 6 fine standard pitch recip saw blades
Product Application and Uses: For use with reciprocating saws to cut all woods, nail embedded wood, composition material, plastic, non-ferrous metals
Blade Material: Bi-Metal
Finish: Steel
Number of Blades Included: 6
Product Length (in): 4.5
Product Width (in): 1.18
Product Height (in): 0.5
Product Weight (lb): 0.7
Teeth per Inch (TPI): 32

For Use With

• 429
• 4429
• 529

IR PF2200-274

PIN
