VALVE, RELAY 1 1/2 RR152-F30

IR 38600714

VALVE, RELAY 1 1/2 RR152-F30

$2,940.00

Cap Asm for Ingersoll Rand 4429 Reciprocating Saw

$49.00

Extended Air Angle Grinder, 4" Type 27 Wheel, 14,000 RPM, 0.9 HP, 3/8"-24 Thread, Rear Exhaust

Don’t let grinding in tight spaces slow you down. The 440 Series Air Extended Angle Grinders from Ingersoll Rand® deliver dependable performance featuring a powerful 0.9 hp motor that maximizes material removal and reduces job completion time in hard-to-reach areas. At under 4lbs, its lightweight construction, slim grip, and low-profile lever throttle make it an ideal tool for all day use without operator fatigue. An adjustable guard allows for orientation changes in seconds and spindle lock enables quick abrasive changeovers with a single wrench. The 440 Series Air Extended Angle Grinders are offered in three guard sizes from 4” to 5”. For reliable grinding in hard-to-reach areas, keep your operation running with the 440 Series Extended Angle Grinders.

Features And Benefits

Powerful 0.9 hp 14,000 rpm motor maximizes material removal, reducing job completion time in hard-to-reach areas.
Extended angle head with reduced height over spindle provides superior accessibility in confined spaces.
Adjustable guard allows for orientation changes in seconds and spindle lock enables quick abrasive changeovers with a single wrench.
At under 4lbs, its lightweight construction, slim grip, and low-profile lever throttle make it an ideal tool for all day use without operator fatigue.
Left or right auxiliary handle position for operator preference.

Includes: Tool, 1 Wrench, Safety Manual, Auxiliary Handle
Product Application and Uses: Designed for material removal using a rotated abrasive wheel for general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding, construction, aerospace, and metal fabrication.
Actuation/Throttle Type/Switch Location: Handle
Actuation/Throttle Type/Switch Type: Safety Lever
Air Consumption @ Free Speed (cfm): 34
Air Consumption @ Free Speed (l/min): 962
Air Consumption @ Load (cfm): 29
Air Consumption @ Load (l/min): 821
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Average Air Consumption (cfm): 29
Average Air Consumption (l/min): 821
Bearing Type: Ball Bearing
Bearing Type: Needle Bearing
Color: Grey
Configuration/Handle Type: Right Angle
Configuration/Handle Type: Auxiliary Handle
Duty Rating: Standard Duty
Exhaust Location: Rear
Grinder Type: Angle Grinder
Gripping Length (in): 4.8
Guard Material: Steel
Handle Material: Composite
Height Over Spindle (in): 2.9
Housing Material: Aluminum core with composite sleeve
Lock Mechanism: Lever lock in off position
Max Free Speed (rpm): 14000
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Power Source: Air Powered
Product Length (in): 10.57
Product Height (in): 2.9
Product Weight (lb): 3.7
Rated Power (hp): 0.9
Rated Power (kW): 0.67
Side to Center Distance (in): 0.98
Side to Center Distance (mm): 25
Sound Pressure/Power Db(A): 92.2 / 103.2
Special Features: Adjustable Guard and Spindle Lock; Extended Angle Head
Speed Setting: Variable Speed
Standards/Certifications: CE, UKCA
Vibration Level (m/s2): 6.89
Vibration Uncertainy K* (m/s2): 1.18
Warranty: 1-year
Wheel Diameter (in): 4
Wheel Thickness (in): 1/4
Wheel Type: Type 27

Similar IR

4445
445
M2E135RP64
M2E145RP64

$535.00

SLB SAFETY LATCH KIT, 1 TON

IR 45471067

SLB SAFETY LATCH KIT, 1 TON

$15.00

HEAD ASSEMBLY

IR 46125

HEAD ASSEMBLY

$1,730.00

HEAD ASSEMBLY

IR 46126-2

HEAD ASSEMBLY

$4,250.00

MOTOR

IR 4840S2

Inline Multi-Vane Air Motor, 1" Square Shaft, 255 RPM, 3 HP, 292 NM, Reversible

The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.

Features And Benefits

Safety: Meets ATEX Standards
Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
Ease of Service: Without having to worry about repair time, you’ll be able to spend more time focused on the job.

Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Length (in): 2.25
Drive Size (in): 1
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Ratio: 35.6:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 255
Max Pressure (bar): 6.2
Max Torque (ft-lb): 215
Max Torque (in-lb): 2584
Max Torque (nm): 292
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Operating Temperature Range: 0F to 150F
Power Source: Air Powered
Product Length (in): 11.38
Product Width (in): 4
Product Height (in): 4
Product Weight (lb): 20.13
Rated Power (hp): 3
Rated Power (kW): 2.24
Reversible: Reversible
Speed at Max Power (rpm): 125
Standards/Certifications: ATEX
Starting Torque (ft-lb): 161
Starting Torque (nm): 218
Warranty: 1-year

$6,063.00

PAD

IR 49094-1

5" Disc Backup Pad, Adhesive/PSA

For Use With

5151-5
5151-5-HL
5152-5
5152-5-HL

$32.00

SANDING PAD

IR 49835

SANDING PAD

$42.00

MOIL POINT - 24" SHK 1" X 4-1/4" , QTY 1

IR 50050392

24" Moil Point Pavement Breaker/Digger Steel, Hex 1" x 4-1/4" Shank

Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world’s first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Choose from a complete line of tool steels for your pavement breaker, with products for many applications including concrete, asphalt, excavation, and general demolition.

Includes: (1) Moil Point Steel
Product Application and Uses: Ideal for concrete, asphalt, excavation, and general demolition. For use with Ingersoll Rand PB35A pavement breakers.
Chisel Style: Moil Point
Collar Type: Round
Collar Width (in): 1.563
Housing Material: Steel
Length Under Collar (in): 24
Product Length (in): 28.25
Product Weight (lb): 6.75
Shank Length (in): 4.25
Shank SIze (in): 1 x 4-1/4
Shank Type: Hex

For Use With

PB35AL8
PB35AS8

$78.00

MOIL POINT - 18" SHK 1-1/4" X 6" , QTY 5

IR 50055698

18" Moil Point Pavement Breaker/Digger Steel, Hex 1-1/4" x 6" Shank

Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world’s first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Choose from a complete line of tool steels for your pavement breaker, with products for many applications including concrete, asphalt, excavation, and general demolition.

Includes: (10) Moil Point Steels
Product Application and Uses: Ideal for concrete, asphalt, excavation, and general demolition. For use with Ingersoll Rand MX60B, MX90B pavement breakers.
Chisel Style: Moil Point
Collar Type: Round
Collar Width (in): 1.563
Housing Material: Steel
Length Under Collar (in): 18
Product Length (in): 24
Product Weight (lb): 9
Shank Length (in): 6
Shank SIze (in): 1-1/4 x 6
Shank Type: Hex

For Use With
