Parts
GL-1 INJECTOR, ONE POINT
GG 114901
GG 114901
GL-1 INJECTOR, ONE POINT
Graco 114901 GL-1™ Grease Injector - 1 Injector and Manifold
Custom fit your system with Graco&prime, s adjustable GL-1 series grease injectors. Designed to meet the needs of each lube point, these systems provide years of reliable operation in the harshest operating environments.
Application: High volume output at high pressures for the most demanding applications- The GL-1 injectors are offered both as a stand-alone and a replacement injector for manifold systems for easy customization to a variety of applications
- Includes an adjustable hex head nut to make adjusting the output simple
- No vent holes and fully enclosed press fittings to prevent leaking lubricant
- Rugged, single piece uni-body design built for the harshest environments
- Model: GL-1
- Adjustable: Adjustable
- Application: In-Plant Machinery, Off-Road Equipment
- Compatible Material: Grease
- Compatible Metering Device: Single Line Parallel
- Cycle Indicator: Visual
- Dispense Outlet Size (cm): 0.33
- Dispense Outlet Size (in): 0.13
- Dispense Outlet Size (mm): 3.3
- Dispense Outlet Thread Type: NPT
- For Use With: Single Line Parallel Automatic Lubrication Systems
- Inlet Size (cm): 0.9525
- Inlet Size (in): 3/8
- Inlet Size (mm): 9.525
- Inlet Thread Type: NPT
- Maximum NLGI Grade: #2
- Maximum Operating Pressure (psi): 3500
- Maximum Output Volume (in³): 0.08
- Maximum Reset Pressure (psi): 600
- Maximum Working Pressure (bar): 241
- Maximum Working Pressure (kPa): 24100
- Maximum Working Pressure (MPa): 24.1
- Maximum Working Pressure (psi): 3500
- Minimum Operating Pressure (psi): 1850
- Minimum Output Volume (in³): 0.008
- Outlet Size (cm): 0.9525
- Outlet Size (in): 3/8
- Outlet Size (mm): 9.525
- Outlet Thread Type: NPT
$219.00
GL-1 INJECTOR, FOUR POINT
GG 114904
GG 114904
GL-1 INJECTOR, FOUR POINT
GL-1™ Grease Injectors - 4 Injectors and ManifoldCustom fit your system with Graco's adjustable GL-1 series grease injectors. Designed to meet the needs of each lube point, these systems provide years of reliable operation in the harshest operating environments.
High volume output at high pressures for the most demanding applications The GL-1 injectors are offered both as a stand-alone and a replacement injector for manifold systems for easy customization to a variety of applications Includes an adjustable hex head nut to make adjusting the output simple No vent holes and fully enclosed press fittings to prevent leaking lubricant Convenient top-mounted cycle pin indicator for quick confirmation that the injector is functioning properly Rugged, single piece uni-body design built for the harshest environments
$515.00
