Parts

GG 25M460

GG 25N834

GG 25P701

KIT, FUSION PC, RETRO, RND, 01

Graco 25P701 Fusion ProConnect Retrofit Kit with Round 01 Mix Chamber and 0.042 in (1.06 mm) Orifice Size

Transform your Fusion Air Purge gun into a Fusion PC with the ProConnect Retrofit Kit, allowing you to take full advantage of what the Fusion PC delivers: A perfect rebuild in seconds. The Retrofit Kit is compatible with all Fusion AP guns and is available in multiple mix chamber sizes. Acquire all the advantages of the revolutionary Fusion ProConnect while utilizing your existing Fusion AP handle and fluid manifold.

• A single cartridge replaces the entire fluid section in seconds
• Sprays exactly like a Fusion AP
• Integrated check valves for cross-over containment
• Eliminates the need to purchase fluid section o-rings
• Spare ProConnect cartridges can replace your back-up guns

• Model: Fusion PC
• Series: Round

• Includes: PC42RD Mix Chamber Tip

• Mix Chamber: 01 (.042)

GG 261863

GG 261878

GG 262697

GG 26B800

GG 286817

RAC 5 TIP, SPRAY

Graco 286817 RAC 5 SwitchTip, 817

The Reverse-A-Clean (RAC) 817 RAC 5 SwitchTip produces a 16 to 18 inch fan and has a 0.017 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 45.7
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 457

• Maximum Flow Rate (GPM): 0.31
• Maximum Flow Rate (L/min): 1.17

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 16
• Minimum Fan Width (mm): 406

• Orifice Diameter (in): 0.017

• Pattern Size (in): 16 to 18
• Pattern Size (mm): 406.4 to 457.2

GG 288046

GG 289467

GG 2WL042

GG 420013

GG 626053

GG 626063

GG A9A01019

710 REMOTE, NO NEEDLE, NO SOLENOID

Graco A9A01019 710 Dispensit Valve

The Model 710 Dispense Valve is an On/Off valve designed for a continuous flow of viscous material through a dispense needle in automatic, semi-automatic or manual applications.

• Features and Benefits:

  Dispenses a range of material viscosities and flow rates

  Offers continuous bead dispensing or rapid on/off cycling without reload time

  High-feed pressure-rated needle valve design provides higher flow rates even for narrow bead profiles

  Simple on/off control via PLC for integrated solenoid versions or versions for external pneumatic control

• Model: Dispensit
• Series: 710

• Application: Bonding, Sealing, Gasketing

• Component Type: Single Component

• Maximum Working Pressure (bar): 6.9
• Maximum Working Pressure (kg/cm 2): 7
• Maximum Working Pressure (kPa): 690
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100
• Meter Type: Time Pressure

GG AAM615

TIP, AAM615

Graco AAM615 Fine Finish Spray Tip for G15 and G40 Guns, 0.015 inch (0.381 mm) Orifice Size, 12-14 inches (300-350 mm) Fan Width

Precision-Cut Flat Tips are designed with thinner stains and lacquers in mind to produce the best atomization for the ultimate smooth finish on furniture and similar applications.

• Delivers The Softest Spray Fan

  • Air coming out of the cap is closer and behind the orifice of the tip
  • Zero air cap buildup
  • Better atomization
  • Softer edges and breaks up spits
• Fan Width Control

  • Provides application flexibility to tackle any finishing job
• Added Filtration

  • Includes an additional filter to reduce tip clogs

• Bleed Type: Non-Bleeder

• Compatible Material: CARC, Enamel, Epoxies, Fast-Set, High Solids, Latex, Plural Component Materials, Sealants, Solventborne, Urethane, Waterborne

GG B-210-16B

GG B-510-08

WHEEL,RUBBER,LARGE

GG C04069

GG C04128

GG FFLP412

RAC X FFLP TIP, SPRAY, (412)

Graco FFLP412 Fine Finish Low Pressure RAC X FF LP SwitchTip, 412

Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 412 Fine Finish Low Pressure (FF LP) RAC X SwitchTip. This fine finish tip produces an 8 to 10 inch Fan pattern and has a 0.012 inch orifice, ideal for finishing materials. Reverse the SwitchTip to easily clear clogs.

• Less Prep & Cleanup Time

  Less mess with less overspray

  Put the paint where you want it

• Easiest Pattern Overlap

  Softer spray fan pattern

  Easy to apply any material to any surfance

  Consistent blended finish quality

• Extended Life

  Spraying at half pressure doubles tip life

  Reduced sprayer maintenance - up to 2X life

• Best Tip on the Market

  Works with any airless sprayer

  Longest lasting Fan pattern

  Highest quality finish with a consistent spray pattern

• Easy to Identify Tip Size

  Large raised tip size numbers are always legible - even when covered with paint

• Superior Tip Design

  Locking tab ensures tip stays securely in guard

  Snaps tip in spray or reverse position

  OneSeal tip gasket installs with no tools

  Solvent seal available when using extremely hot solvents

• Model: RAC X
• Series: FF LP SwitchTip

• Compatible Material: Primer, Stains, Varnish, Water-Based Paint, Enamel, Latex, Solvent borne Paints

• For Use With: RAC X HandTite Tip Guard

• Material: Tungsten Carbide

• Maximum Fan Width (cm): 20
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.15
• Maximum Flow Rate (L/min): 0.57

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.012

• Pattern Size (in): 8 to 10
• Pattern Size (mm): 203.2 to 254

GG GC1898

GG GC2187

GG GC2511

GG LPA-134-02
